Sagem MYV-76 User Manual

User Guide

English

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (GSM 900 MHz and DCS 1800 MHz or PCS 1900 MHz) depending on the roaming arrangements with your network provider. We remind you that this phone is approved to meet European standards.

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Ensure that your SIM card is a 3 V SIM type t hat is compatible with your phone. Inserting an incompatible card will be indicated

by a message when your phone is switched on. Contact Vodafone. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card.

In order to display the IMEI on your phone's screen, type: *#06#.

Technical features

Weight: 104 g Size: 110 x 47 x 19 mm Original battery: Li-ion 920 mAh Multimedia objects supported:

Audio formats: iMelody, Midi, wave, AAC, AAC+ AMR, MP3, M4A Graphic formats: wbmp, bmp, png, gif, gif animés, jpeg, .3gp

Size of memory available for messages:

100 SMS Size of memory available for MMS, the phonenook and the multimedia objects: up to 8 Mb Maximum size of each message:

SMS: < 160 characters

MMS: < 100 Kb for outgoing messagezs, 300 Kb for incoming messages (depends on the phone configuration and on

Vodafone reservations Using temperature: from - 10 °C to + 55 °C

)

Menus ............................................................................................................................................ 7

Your phone package - Accessories............................................................................................ 8

Description ................................................................................................................................... 9

Installing your Vodafone SIM card and the battery .............................................................................. 11

Necklace attachment ........................................................................................................................... 11

Inserting the memory card (microSD™) .............................................................................................. 12

Using the memory card........................................................................................................................ 12

Idle screen .................................................................................................................................. 13

Activating your phone ............................................................................................................... 14

Information on the SIM card ................................................................................................................ 14

Getting started ..................................................................................................................................... 15

PIN number.......................................................................................................................................... 15

Setting time and date........................................................................................................................... 16

Network................................................................................................................................................ 16

First call ............................................................................................................................................... 16

Receiving a call.................................................................................................................................... 17

Switching off ........................................................................................................................................ 17

Using your phone....................................................................................................................... 18

Improving antenna performance.......................................................................................................... 18

Increase the battery life of your phone ................................................................................................ 18

Charging the battery ............................................................................................................................ 19

Contacts ...................................................................................................................................... 20

Using the phonebook........................................................................................................................... 20

Storing a new contact .......................................................................................................................... 20

Displaying a contact............................................................................................................................. 21

Calling a contact .................................................................................................................................. 21

Contacts options .................................................................................................................................. 21

Groups ................................................................................................................................................. 23

4 Contents

Messages .................................................................................................................................... 24

Creating a message............................................................................................................................. 24

Receiving messages............................................................................................................................ 26

Inbox ....................................................................................................................................................27

Drafts ................................................................................................................................................... 27

Sent messages ....................................................................................................................................27

Outbox ................................................................................................................................................. 27

Voicemail ............................................................................................................................................. 28

Templates ............................................................................................................................................28

Messaging settings ..............................................................................................................................28

Local information.................................................................................................................................. 29

Memory ................................................................................................................................................ 29

Camera ........................................................................................................................................ 30

Taking and saving a photo................................................................................................................... 30

Taking a video...................................................................................................................................... 31

My Items ...................................................................................................................................... 32

Pictures ................................................................................................................................................ 32

Sounds................................................................................................................................................. 33

Videos .................................................................................................................................................. 33

Exchanging objects with a PC and your phone ................................................................................... 33

Music Player ............................................................................................................................... 34

Creating a playlist ................................................................................................................................ 34

Playing your music............................................................................................................................... 34

Vodafone live!............................................................................................................................. 35

Games and applications ............................................................................................................ 36

Organiser & Tools ...................................................................................................................... 37

Alarm.................................................................................................................................................... 37

Timer.................................................................................................................................................... 37

Calendar .............................................................................................................................................. 37

Calculator and converter...................................................................................................................... 38

Todo..................................................................................................................................................... 39

Contents 5

Settings ....................................................................................................................................... 40

Phone settings ..................................................................................................................................... 40

Display settings.................................................................................................................................... 42

Messaging settings .............................................................................................................................. 43

Call settings ......................................................................................................................................... 43

Networks settings ................................................................................................................................ 44

Security settings .................................................................................................................................. 45

Player settings ..................................................................................................................................... 47

Synchronisation settings...................................................................................................................... 47

Browser settings .................................................................................................................................. 47

Camera settings................................................................................................................................... 47

Video settings ...................................................................................................................................... 47

Connectivity................................................................................................................................ 48

Bluetooth.............................................................................................................................................. 48

Infrared ................................................................................................................................................ 49

Serial speed......................................................................................................................................... 49

Headset ............................................................................................................................................... 49

Synchronize ......................................................................................................................................... 49

USB Mode ........................................................................................................................................... 49

Care and safety information...................................................................................................... 51

SAR ..................................................................................................................................................... 51

Advice for limiting exposure to radiofrequency (RF) fields .................................................................. 51

Safety................................................................................................................................................... 52

Environment......................................................................................................................................... 53

Warranty...................................................................................................................................... 54

End User Licence Agreement (EULA), for the software ......................................................... 57

Java™.......................................................................................................................................... 61

Troubleshooting ......................................................................................................................... 65

Index ............................................................................................................................................ 68

6 Contents

Menus

Entertainment

Vodafone live!

Vodafone live! Enter URL Bookmarks History Browser settings What’s New? More Games More Sounds More Pictures News Sport

Music Player

Camera

Messaging

Create Message Inbox Drafts Sent Messages

Menus 7

Outbox Messenger Vodafone Mail Voicemail Templates Messaging Settings Local info. Memory

My Items

Pictures Sounds Videos Ghosts

Organiser & Tools

Alarm Applications Timer Calendar Calculator To do

Contacts

Call Log

Alarm

Connectivity

Bluetooth Infrared Serial speed Headset Synchronize USB Mode

Settings

Phone settings Display settings Messaging Settings Call settings Networks settings Security settings Player Settings Synchro. settings Browser settings Camera settings Video settings

Your phone package - Accessories

When you open the box, check that all items are present:

1 - Phone 2 - Charger 3 - Battery 4 - User guide 5 - Wellphone CD 6 - Quick start guide

Accessories

We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories. You can order the following accessories:

- Stereo pedestrian kit

- Bluetooth pedestrian kit

- Additional battery

- Additional charger

- USB cable (with associated drivers) and serial cable to connect your phone to a PC (*)

- Cigar lighter charger

- Necklace

- Memory card (microSD™)

For more information : www.planetsagem.com and www.sagem.com

(*)

Warning

: the USB cable equipped with a charge connector is an extra connector. If the battery has run down, we

advise you the use of the charger provided with the phone.

8 Your phone package - Accesso ries

Description

Red key

: Hold down: Switch on/off

In a call context: Reject a call - hang up In menus: Return to idle screen.

Green key

: Long press: Activate/Deactivate hands-free mode.

In call context: Call - receiving a call.

Right key

: In idle screen: Access to Vodafone live!.

In menus: Access to the selection shown on screen in the tab (*).

Left key

: In idle screen: Access to menus.

In menus: Access to the selection shown on screen in the tab (*).

Previous choice / increase value / up. During call: Increase volume. In idle screen: Access to Vodafone live!

Next choice / reduce value / down. During call: Reduce volume. In idle screen: Access to Contacts.

Previous input field / move left / select a tab at the top of the screen. In idle screen: Access to message creating.

Next input field / move right / select a tab at the top of the screen.

In idle screen: Access to In idle screen: access to the icons of the main menus.

When pressing OK followed by one of the twelve keys of the keypad, you can display a menu directly. For instance, pressing Phonebook. In the menus: context-sensitive access to different functions. During a call: take a call.

When composing a message:

to another (T9, ABC, 123). Long press: upper case/lower case Hold down: In idle screen: Silent mode. In call reception mode: Short press stops ring tone. In ring tone setting mode: Activate / deactivate ring tone. Stops sound in video or message playing, or in a game. A long press on 1 will automatically call your Vodafone voicemail box. A long

1 to 9

press on the keys

(*) In this manual, when a function is chosen by pressing on this key, square brackets

are used (e.g.: [

Description 9

Save

My Items

Short press: switches from one input mode

to 9 directly displays the phonebook.

]).

then 8 displays the

Camera lens

IrDA

10 Description

Mirror

Zoom (in photo or video preview screen) Volume setting (in call)

Photo taking key

Installing your Vodafone SIM card and the battery

The SIM card is inserted under the phone's battery. Ensure that the phone is switched off and the charger disconnected.

1 Turn the phone back and slide the lock button up to remove the back cover. 2 Take out battery if already installed. 3 Slide the SIM card, with cut corner as shown on t he phone, into the card holder

with fold face down.

4 Place the battery by positioning first the top of it, as shown on the battery. 5 Replace the back cover, making it slide.

Necklace attachment

You can insert a necklace or wrist strap into into the notch located in the right bottom of the inside part of the phone.

Description 11

Inserting the memory card (microSD™)

1 Turn the phone on to its back and slide the lock button up, then unclip the back cover. 2 Remove the front cover by pushing on the two side clips. 3 Insert the memory card pushing it until you hear a «click ».

Note:

Take care not to mark the display screen with your fingers.

4 Hold the front cover facing down. Place the keypad into that, and then clip the electronic board into place, first at the top

and then down the side and at the bottom. Replace the back cover.

Important:

5 6 To remove the memory card, carefully press it in to make it pop out.

Slide the rear-cover lock button back down again into the lock position.

12 3

Memory card slot

Charger and accessories connector

4 56

Using the memory card

The memory card is very fragile. Take care when you insert or remove the memory card. Some memory cards must be formatted with a PC before first use with the phone.

12 Description

Idle screen

The idle screen may contain the following information:

1 - The title bar icons:

Battery

Silent mode

Only emergency call is possible

Signal strength level (5 bars)

GPRS channel present

2 - Date and time, in digital or analog mode 3 - Network provider 4 - Thumbnail centred on bottom line:

It shows that the menus can be accessed by pressing OK. Other functions can be directly accessed by pressing The following information may also be displayed: « 1 message received » or « 1 call » (incoming call failed). It can be deleted

by pressing key briefly.

Idle screen 13

S, T, W, X

(see chapter

Description

Activating your phone

Information on the SIM card

To use your phone, you need a Vodafone SIM card. It contains personal information that you can modify: Secret codes (PIN(s): Personal Identification Numbers), these codes allow you to protect access to your SIM card and phone Phonebook Messages How special services work. Your phone is compatible with the SIM 3V cards.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact Vodafone immediately. Please keep your SIM card out of reach of young children.

14 Activating your phone

Getting started

Switch on the phone by pressing the key. A short animation appears. When you switch on your phone for the first time, follow instructions displayed on the screen. After entering your PIN code, the phone activates the Vodafone settings and switches on again ; enter your PIN code again

then the date and time, make your choice for the following settings: time zone, daylight savings, skin, wallpaper, screensaver, ring tone, volume, vibrate and voicemail number. If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

PIN number

If access to the Vodafone SIM card is protected, the device prompts you to enter the PIN number: Enter the code

for security reasons. Press [ If your phone indicates that the SIM is missing, press the key to switch off your phone and check that the SIM card is correctly installed.

Activating your phone 15

between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen

] to validate.

Warning

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter « **05* ».

- Enter the PUK (Personal Unblocking Key) code provided by your network provider, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the Vodafone SIM card is definitely locked. You must then contact your network provider to obtain a new card.

Setting time and date

When you use your phone for the first time, you need to set the date and time. You will be automatically proposed to enter date and time when using your phone for the first time, or after having removed

the battery.

Setting the date:

Set the date by entering it directly in numerical form or by using Use the

key (or

Once the date is correct, press the key to validate.

Setting the time:

key) to access the next (or last) data input field.

Same procedure as for setting the date.

T S

keys to increase or decrease the default values.

Network

From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on the screen. You are then ready to send or receive a call.

If the network’s name appears, calls are possible. If the icon and a network name are displayed, calls are possible on a roaming network provider. If the icon is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

First call

Dial the number you want to ring. Press the key. During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call. While a call is connecting, the phone icon is flashing. You can adjust the sound level (volume) using the

16 Activating your phone

T S

keys.

At the end of the conversation press the key to hang up.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the network you can obtain the emergency service with or without SIM card or when the keypad is locked. It is enough to be in an area served by a network. To obtain the international emergency service, dial

112

then press the key.

Receiving a call

When you receive a call, the number of your caller is displayed when it is presented by the network. Press the key or [ To refuse the call, press the key or [ To stop the ring tone or the vibrate, without refusing the call, press the key.

Hands-free mode

During a call, press the key and validate pressing OK (or ) or press OK twice to switch into hands-free mode.

WARNING:

All the numbers corresponding to incoming and outgoing calls are logged in the

When on a call, pressing [ to mute mode, displaying menus, displaying the phonebook.

Pressing [

] to answer, and speak.

Refuse

in this mode do not bring the phone up to your ear.

Options

] allows you to have access to different functions: switching to hands-free mode, switching

Mute on

] allows you to switch off the microphone temporarily.

Call Log

Switching off

Press the key (long press). The end message is displayed. The phone switches off.

Activating your phone 17

Using your phone

Improving antenna performance

The antenna is integrated in your phone, under the back cover at the top. Avoid putting your fingers on this area when the phone is switched ON. If your fingers obstruct the antenna, the phone may have to operate with a higher power level than usual; decreasing its efficiency quickly. It could also affect the

quality of your communications.

Non ionising radiation

To obtain maximum satisfaction from your phone, use it in a vertical position. Your personal safety can only be improved by doing so.

Increase the battery life of your phone

- Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.

- Don't obstruct the antenna with your fingers.

- Activation of IrDA or Bluetooth functions reduces the phone battery life. We advise you to deactivate them when not in use.

18 Using your phone

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time. It reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the empty battery icon flashes. In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off quickly.

To recharge the battery

Connect the charger to a socket. Plug the end of the cable into the bottom connector of the phone. The phone is then charging up. The battery icon scrolls up and down to indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable. When charging, the battery may warm up, this is normal.

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc).

Using your phone 19

Contacts

The phonebook allows you to store numbers that you call regularly. These numbers can be stored in the SIM card or in the phone.

To store a contact in the phone memory, the following fields can be filled: last name, first name, numbers, email, URL, address, company, comments, ringtone, photo. To store a contact in the SIM card, only the last name and number fields must be filled.

Using the phonebook

Display the

Contacts

The location where the contact is stored (SIM card or phone) is indicated by the icon at the top of the screen when the cursor is located on a contact.

Storing a new contact

Adding a contact in the SIM card memory

- In the phonebook, press [

- Select

- Enter the last name and press OK.

- Enter the number and press OK.

- Press [

20 Contacts

menu. The list of your contacts appears.

contact stored in the SIM card

contact stored in the phone

contact stored in the Fixed Dialling. See activation.

Options Add SIM contact SIM card

Fixed directory

Save

] to store it.

and press OK.

PIN2 number

and

Fixed dialling

page 45 for more details about this

Adding a contact in the phone memory

- Press [

Options

- Select

- Enter the last name and press OK.

- Enter the number and press

- Fill in other fields if you want.

- Press [

Add phone contact

Save

] to store it.

and press OK.

Displaying a contact

Select a contact from the list and press OK. The name, the phone number and the order number with which the contact is stored are displayed.

Note:

By directly pressing one character, the phone will display the first contact saved in the phonebook, starting with it.

To display the different options, select a contact from the list and press [

Options

Calling a contact

Several ways:

- Select a contact. Press the key to start the call.

- Select a contact, press OK, his number is displayed, press [

- Direct call from the idle screen (only for the contacts stored in the SIM card memory): type the number with which the

contact was saved then (example : 21 ) or the number then , the number is displayed, confirm.

Call

] to start the call.

Contacts options

To display the various options, select a contact and press [

Edit contact

Modify what you want and validate then select

Send message

To send a SMS or a MMS to a contact (see chapter

Send by

To send a contact details by SMS, MMS, IrDA or Bluetooth (see chapters

Contacts 21

Options

Save

once the modifications completed.

Messages

and

Connectivity

Copy one to SIM / Copy one to phone

This allows you to copy your phonebook contacts from one memory to the other. Only the name and the first phone number will be copied.

My numbers

You can create the entries corresponding to your own numbers in order to consult them when necessary. Enter the different details and validate.

Memory

Select

SIM

Telephone

Phone: the screen displays the amount of memory used. The memory capacity is shared between the phonebook and various other features. If you lack memory, check if you can free some space. SIM: available memory only for contacts.

and OK.

Delete/Delete all

This allows you to delete the contact selected or all the contacts

Set as my card/Business card

The details of a contact stored in the phone memory can be saved in a business card.

Set as my card

- Select

- Select the Business card item to see it, edit it, send it by SMS, MMS or IrDA or exchange it with a PC (see chapter

Connectivity/Synchronize

and [OK]. The details are saved as

Business card

Synchronise

You can synchronize your phonebook with your archives stored in Vodafone’s network depending on the options offered by your subscription. The local synchronisation with your computer is only computer originated, from Wellphone software; you have only to activate infrared, Bluetooth, or configure your USB connection in your phone.

Contacts synchronisation with a computer

Install Wellphone, software provided on CD, and click on DIRECTSYNC: you can synchronise your contacts stored in the phone memory with those of your Lotus Notes™ or Microsoft Outlook™ bases

22 Contacts

+ 50 hidden pages
