* Not received when the Rx Poly Key Press(PAFT) parameter (PART VIEW:MIDI) is OFF.
Control Change
* If the corresponding Controller number is selected for the MFX Control Source1,
2, 3 or 4 parameter (TONE EDIT:MFX CTRL) or the PCM Synth Tone Matrix Control1,
2, 3 or 4 Source parameter (TONE EDIT PCMS:MTRX CTRL1-4), the corresponding
eect will occur.
* When the Control Source Select parameter (SYSTEM:CONTROL) is set to SYSTEM,
if a controller number that corresponds to the System Control Src1, 2, 3 or 4
parameter (SYSTEM:CONTROL) is selected, the specied eect will apply if the MFX
Control Source1, 2, 3 or 4 parameter (TONE EDIT:MFX CTRL) or the PCM Synth Tone
Matrix Control1, 2, 3 or 4 Source parameter (TONE EDIT PCMS:MTRX CTRL1-4) is set
to SYS CTRL1, SYS CTRL2, SYS CTRL3 or SYS CTRL4.
* When the Control Source Select parameter (SYSTEM:CONTROL) is set to STUDIO
SET, if a controller number that corresponds to the Tone Control Src1, 2, 3 or 4
parameter (STUDIO SET COMMON:CONTROL) is selected, the specied eect
will apply if the MFX Control Source1, 2, 3 or 4 parameter (TONE EDIT:MFX CTRL)
or the PCM Synth Tone Matrix Control1, 2, 3 or 4 Source parameter (TONE EDIT
PCMS:MTRX CTRL1-4) is set to SYS CTRL1, SYS CTRL2, SYS CTRL3 or SYS CTRL4.
Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received when the Rx Bank Select parameter (SYSTEM:MIDI) is OFF.
* Not received when the Rx Bank Select(BS) parameter (PART VIEW:MIDI) is OFF.
1PS
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
* Not received when the Rx Expression(EXP) parameter (PART VIEW:MIDI) is OFF.
* Not received when the Partial Rx Expression parameter (TONE EDIT PCMS:CTRL or
TONE EDIT PCMD:COMMON) is OFF.
Motional Surround Control 1 (Controller number 12)
Status 2nd byte 3rd byte
BnH 0CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 40H - 7FH (Left - Center - Right),
* The Part L-R parameter (MOTIONAL SURROUND EDIT:PART) will change.
* Valid when the Motional Surround is ON.
Motional Surround Control 2 (Controller number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 40H - 7FH (Back - Center - Front),
* The Part F-B parameter (MOTIONAL SURROUND EDIT:PART) will change.
* Valid when the Motional Surround is ON.
Motional Surround Control 3 (Controller number 14)
* The Reso Oset parameter (PART VIEW:OFFSET) will change.
Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
* The PartEx Ambience Send Level parameter (MOTIONAL SURROUND EDIT:PART)
will change.
* Valid when the Motional Surround is ON.
Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
0-63 = OFF, 64-127 = ON
* Not received when the Rx Hold-1(HOLD) parameter (PART VIEW:MIDI) is OFF.
* Not received when the Partial Rx Hold-1 parameter (TONE EDIT PCMS:CTRL or TONE
EDIT PCMD:COMMON) is OFF.
Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
0-63 = OFF, 64-127 = ON
* The Porta Switch parameter (PART VIEW:PITCH) will change.
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* The Release Oset parameter (PART VIEW:OFFSET) will change.
Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* The Attack Oset parameter (PART VIEW:OFFSET) will change.
* The Cho Send Level parameter (PART VIEW: LEVEL/CH) will change.
RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specied by RPN
ll = lower byte (LSB) of parameter number specied by RPN
General Purpose Controller 6 (Tone Variation 2)
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, rst RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then Data Entry (Controller
numbers 6 and 38) should be sent to set the value. Once RPN messages are received,
Data Entry messages that is received at the same MIDI channel after that are
recognized as changing toward the value of the RPN messages. In order not to make
any mistakes, transmitting RPN Null is recommended after setting parameters you
need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specied in
semitone steps.
* The Bend Range parameter (PART VIEW:PITCH) will change.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 -
+4096 x 100 / 8192 cent)
* The Fine Tune parameter (PART VIEW:PITCH) will change.
* The Coarse Tune parameter (PART VIEW:PITCH) will change.
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecied.”
Once this setting has been made,
subsequent
Parameter values that were previously set
will not change.
mm, ll: ignored
* Not received when the Rx Program Change parameter (SYSTEM:MIDI) is OFF.
* Not received when the Rx Program Change(PC) parameter (PART VIEW:MIDI) is OFF.
* Not received when the Rx Ch Press(CAFT) parameter (PART VIEW:MIDI) is OFF.
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH
(-8192 - 0 - +8191)
* Not received when the Rx Pitch Bend(BEND) parameter (PART VIEW:MIDI) is OFF.
* Not received when the Partial Rx Bender parameter (TONE EDIT PCMS:CTRL) is OFF.
Channel Mode Messages
* Not received when the Rx Switch parameter (PART VIEW:LEVEL/CH) is OFF.
All Sounds O (Controller number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, all notes currently sounding on the corresponding
channel will be turned o.
Reset All Controllers (Controller number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, the following controllers will be set to their reset
values.
Controller Reset value
Pitch Bend Change +/-0 (center)
Polyphonic Key Pressure 0 (o)
Channel Pressure 0 (o )
Modulation 0 (o)
Breath Type 0 (min)
Foot Type 0 (min)
Expression 127 (max)
However the controller will be at
minimum.
Hold 1 0 (o)
Sostenuto 0 (o)
Soft 0 (o )
Hold 2 0 (o)
RPN unset; previously set data will not change
NRPN unset; previously set data will not change
All Notes O (Controller number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When All Notes O is received, all notes on the corresponding channel will be
turned o. However, if Hold 1 or Sostenuto is ON, the sound will be continued until
these are turned o.
OMNI OFF (Controller number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes O is received.
OMNI ON (Controller number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes O is received. OMNI ON
* The same processing will be carried out as when All Notes O is received.
* The Mono/Poly parameter (PART VIEW:LEVEL/CH) will change.
POLY (Controller number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes O is received.
* The Mono/Poly parameter (PART VIEW:LEVEL/CH) will change.
System Realtime Message
Timing Clock
Status
F8H
* Received when Sync Mode parameter (SYSTEM:SYNC/TEMPO) is set to SLAVE.
Active Sensing
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of
all further messages. While monitoring, if the interval between messages exceeds
420 ms, the same processing will be carried out as when All Sounds O, All Notes
O and Reset All Controllers are received, and message interval monitoring will be
halted.
System Exclusive Message
Status Data byte Status
F0H iiH, ddH, ......,eeH F7H
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer
whose Exclusive message this is. Roland’s manufacturer ID is
41H.
ID numbers 7EH and 7FH are extensions of the MIDI standard;
Universal Non-realtime Messages (7EH) and Universal Realtime
Messages (7FH).
dd,...,ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
Of the System Exclusive messages received by this device, the Universal Non-realtime
messages and the Universal Realtime messages and the Data Request (RQ1)
messages and the Data Set (DT1) messages will be set automatically.
Universal Non-realtime System Exclusive Messages
Identity Request Message
Status Data byte Status
F0H 7EH, dev, 06H, 01H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH, 7FH)
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When this message is received, Identity Reply message (p. 8) will be transmitted.
Universal Realtime System Exclusive Messages
Master Volume
Status Data byte Status
F0H 7FH, 7FH, 04H, 01H, llH, mmH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
01H Sub ID#2 (Master Volume)
llH Master Volume lower byte
mmH Master Volume upper byte
F7H EOX (End Of Exclusive)
6
* The lower byte (llH) of Master Volume will be handled as 00H.
* The Master Level parameter (SYSTEM:SOUND) will change.
MIDI Implementation
vvH size LSB
sum checksum
F7H EOX (End Of Exclusive)
Master Fine Tuning
Status Data byte Status
F0H 7FH, 7FH, 04H, 03H, llH, mmH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
03H Sub ID#2 (Master Fine Tuning)
llH Master Fine Tuning LSB
mmH Master Fine Tuning MSB
F7H EOX (End Of Exclusive)
* The Master Key Shift parameter (SYSTEM:SOUND) will change.
Data Transmission
This instrument can use exclusive messages to exchange many varieties of internal
settings with other devices.
The model ID of the exclusive messages used by this instrument is 00H 00H 64H.
Data Request 1 (RQ1)
This message requests the other device to transmit data. The address and size
indicate the type and amount of data that is requested.
When a Data Request message is received, if the device is in a state in which it is able
to transmit data, and if the address and size are appropriate, the requested data is
transmitted as a Data Set 1 (DT1) message. If the conditions are not met, nothing is
transmitted.
* The size of data that can be transmitted at one time is xed for each type of data.
And data requests must be made with a xed starting address and size. Refer to the
address and size given in Parameter Address Map (p. 9).
* For the checksum, refer to p. 29.
* Not received when the Rx Exclusive parameter (SYSTEM:MIDI) is OFF.
Data set 1 (DT1)
Status Data byte Status
F0H 41H, dev, 00H, 00H, 64H, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... H, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 10H - 1FH, 7FH)
00H Model ID #1 (INTEGRA-7)
00H Model ID #2 (INTEGRA-7)
64H Model ID #3 (INTEGRA-7)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the
data to be sent
bbH Address: upper middle byte of the starting address
of the data to be sent
ccH Address: lower middle byte of the starting address
of the data to be sent
ddH Address LSB: lower byte of the starting address of the
data to be sent.
eeH Data: the actual data to be sent. Multiple bytes
of data are transmitted in order starting
from the address.
: :
H Data
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of
data, and data will be transmitted from the specied starting address and size.
Refer to the address and size given in Parameter Address Map (p. 9).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and
each packet will be sent at an interval of about 20 ms.
* Regarding the checksum, please refer to p. 29.
* Not received when the Rx Exclusive parameter (SYSTEM:MIDI) is OFF.
Status data byte status
F0H 41H, dev, 00H, 00H, 64H, 11H, aaH, bbH, F7H
ccH, ddH, ssH, ttH, uuH, vvH, sum
Byte Remarks
F0H Exclusive status
41H ID number (Roland)
dev device ID (dev: 10H - 1FH, 7FH)
00H model ID #1 (INTEGRA-7)
00H model ID #2 (INTEGRA-7)
64H model ID #3 (INTEGRA-7)
11H command ID (RQ1)
aaH address MSB
bbH address
ccH address
ddH address LSB
ssH size MSB
ttH size
uuH size
7
MIDI Implementation
2. Data Transmission
System Realtime Messages
Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.
System Exclusive Messages
Universal Non-realtime System Exclusive Message and Data Set 1 (DT1) are the only
System Exclusive messages transmitted by the INTEGRA-7.
Universal Non-realtime System Exclusive Message
Identity Reply Message (INTEGRA-7)
Receiving Identity Request Message (p. 6), the INTEGRA-7 send this message.
Status Data byte Status
F0H 7EH, dev, 06H, 02H, 41H, 64H, 02H, F7H
00H, 00H, 00H, 00H, 00H, 00H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Reply)
41H ID number (Roland)
64H 02H Device family code
00H 00H Device family number code
00H 00H 00H 00H Software revision level
F7H EOX (End of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of
data, and data will be transmitted from the specied starting address and size.
Refer to the address and size given in Parameter Address Map (p. 9).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and
each packet will be sent at an interval of about 20 ms.
Data Transmission
Data set 1 (DT1)
Status Data byte Status
F0H 41H, dev, 00H, 00H, 64H, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... H, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH, 7FH)
00H Model ID #1 (INTEGRA-7)
00H Model ID #2 (INTEGRA-7)
64H Model ID #3 (INTEGRA-7)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the
data to be sent
bbH Address: upper middle byte of the starting address
of the data to be sent
ccH Address: lower middle byte of the starting address
of the data to be sent
ddH Address LSB: lower byte of the starting address of the
data to be sent.
eeH Data: the actual data to be sent. Multiple bytes
of data are transmitted in order starting
from the address.
: :
H Data
sum Checksum
F7H EOX (End Of Exclusive)
8
3. Parameter Address Map
* Transmission of “#” marked address is divided to some packets. For example, ABH in
hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this
order.
* “<*>” marked address or parameters are ignored when the INTEGRA-7 received
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Studio Set Common |
| 00 04 00 | Studio Set Common Chorus |
| 00 06 00 | Studio Set Common Reverb |
| 00 08 00 | Studio Set Common Motional Surround |
| 00 09 00 | Studio Set Master EQ |
| 00 10 00 | Studio Set MIDI (Channel 1) |
| 00 11 00 | Studio Set MIDI (Channel 2) |
| : | |
| 00 1F 00 | Studio Set MIDI (Channel 16) |
| 00 20 00 | Studio Set Part (Part 1) |
| 00 21 00 | Studio Set Part (Part 2) |
| : | |
| 00 2F 00 | Studio Set Part (Part 16) |
| 00 50 00 | Studio Set Part EQ (Part 1) |
| 00 51 00 | Studio Set Part EQ (Part 2) |
| : | |
| 00 5F 00 | Studio Set Part EQ (Part 16) |
+------------------------------------------------------------------------------+
* PCM Synth Tone
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | PCM Synth Tone Common |
| 00 02 00 | PCM Synth Tone Common MFX |
| 00 10 00 | PCM Synth Tone PMT (Partial Mix Table) |
| 00 20 00 | PCM Synth Tone Partial (Partial 1) |
| 00 22 00 | PCM Synth Tone Partial (Partial 2) |
| 00 24 00 | PCM Synth Tone Partial (Partial 3) |
| 00 26 00 | PCM Synth Tone Partial (Partial 4) |
| 00 30 00 | PCM Synth Tone Common 2 |
+------------------------------------------------------------------------------+
