R&S
RT-ZF5
Ethernet Probing Fixture
Manual
(=QGB2)
1333231802
Version 03
This manual describes the R&S RT-ZF5 Ethernet probing fixture (1333.0896.02).
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1333.2318.02 | Version 03 | R&S®RT-ZF5
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®RT-ZF5 is indicated as R&S RT-ZF5.
R&S®RT-ZF5
Safety information
1 Safety information
The product documentation helps you to use the product safely and efficiently.
Keep the product documentation nearby and offer it to other users.
Safety information warns you about the potential dangers and gives instructions
how to prevent personal injuries or damage caused by dangerous situations.
Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.
Intended use
The equipment under test (EUT) is a signal quality test and development board,
indented to be used at laboratory or test and measurement areas. These areas
are used for analysis, testing and servicing and where equipment is operated by
trained personnel.
Operating site
Only use the product indoors, and keep it dry. The product has no casing and is
sensitive to moisture and humidity.
The product is suitable for pollution degree 2 environments where nonconductive
contamination can occur. For more information on environmental conditions such
as ambient temperature, see the specifications.
Installation
Make sure to connect only Ethernet devices with RJ-45 interface that are
designed according to IEEE802.3 10BASE-T, 100BASE-T/TX, 100BASE-T1,
1000BASE-T, or 10GBASE-T.
ESD and EMI impact
The product is sensitive to electrostatic discharge (ESD) because of open modules. Protect the work area against electrostatic discharge to avoid damage to
electronic components. Always work at a static-approved workstation.
Electromagnetic interference (EMI) can affect the measurement results. To avoid
any impact, use only USB cables shorter 3 m.
3Manual 1333.2318.02 ─ 03
R&S®RT-ZF5
Disposal
In line with EN 50419, the product cannot be disposed of in the normal
household waste. Even disposal via the municipal collection points for
waste electrical and electronic equipment is not permitted.
Rohde & Schwarz has developed a disposal concept for the ecofriendly disposal
or recycling of waste material. Rohde & Schwarz fully assumes its obligation as a
producer to take back and dispose of electrical and electronic waste. Contact
your local service representative to dispose of the product.
Product description
Deliveries
2 Product description
The R&S RT-ZF5 test fixture is a multipurpose fixture to probe or tap Ethernet signals up to the 10GBASE-T standard.
The fixture can be used to separate the directions of a full duplex connection for
decoding applications like R&S RTO/RTO6/RTP-K57 (100BASE-T1).
The R&S RT-ZF5 can also be used for compliance testing of energy-efficient
Ethernet (100BASE-TX and 1000BASE-T). For compliance testing, it is used in
combination with:
●
R&S RTO/RTO6/RTP oscilloscope
●
EEE: R&S RTO-K86 (1333.1992.02), R&S RTP-K86 (1337.8833.02): requires
R&S RTO/RTO6/RTP-K22
●
R&S ScopeSuite software
For data, see the "R&S RT-ZFxx Oscilloscope Test Fixtures - Specifications" at
www.rohde-schwarz.com/brochure-datasheet/rto.
2.1 Deliveries
The R&S RT-ZF5 delivery package contains the following items:
●
R&S RT-ZF5 test board
●
Manual
4Manual 1333.2318.02 ─ 03
R&S®RT-ZF5
Product description
Board description
2.2 Board description
The R&S RT-ZF5 Ethernet probing fixture has three labeled sections, which are
designed for specific test cases. You can cut the board at the section limits and
use each section as a separate board.
"Directional Probe" section
Separates the signals on a (differential) full duplex Ethernet connection (like
1000BASE-T or 100BASE-T1) into a forward signal and a backward signal. The
fixture supports all four Ethernet lanes in parallel. The couplers deliver -15 dB of
the original signal amplitude.
" Load and Probe" section
Terminates the signals with 100 Ω and offers pins for differential probing.
"DUT and Link Partner" section
Used to tap the connection between two Ethernet devices. It offers pins for differential and single-ended probes to ground probe connections.
5Manual 1333.2318.02 ─ 03
R&S®RT-ZF5
RT-ZF5
R
S
Ethernet Probing Fixture
Directional
Probe
FWD REV FWD REV
X118
Product description
Board description
X126
X117
X115
X100
DUT
Load and Probe DUT and Link Partner
C B
D
X200
DUT
X113
X111
FWD REV FWD REV
A D
X210
DUT
X125
X116
X123
X114
X121
X112
X119
C B
X124
X122
X101
Link
Partner
X120
A
X211
Link
Partner
Figure 2-1: R&S RT-ZF5 Ethernet probing fixture
6Manual 1333.2318.02 ─ 03
R&S®RT-ZF5
Connecting the board
Figure 2-2: Wiring diagram of the Directional Probe section
3 Connecting the board
The appropriate DUT and probe connection depends on the test case. The
R&S ScopeSuite software provides a step-by-step guide that shows the required
setup for each test case.
The test preparation and measurements of the test cases are described in the
"R&S®RTO, R&S®RTP Ethernet Compliance Tests, Test Procedures Manual".
4 Contacting customer support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz product, contact our customer
support center. A team of highly qualified engineers provides support and works
7Manual 1333.2318.02 ─ 03
R&S®RT-ZF5
Contacting customer support
with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde & Schwarz products.
Contact information
Contact our customer support center at www.rohde-schwarz.com/support, or fol-
low this QR code:
Figure 4-1: QR code to the Rohde & Schwarz support page
