Enclosure Mounting Pad Foot Kit
(Cat 598-N5)
56 x 30 Enclosure
ATTENTION: To prevent electrical shock, disconnect from power source before installing or servicing. Install
in suitable enclosure. Keep free from contaminants.
1
(2) locations
center holes only
typical each mounting foot
Note: Enclosure needs to be elevated to allow
assembly of mounting pad feet. Use blocks or
a heavy duty table.
2
9.686"
33.842"
(2) locations
typical each mounting foot
1
175-200 lb-in
11.00"
typical each side panel of enclosure
2
(2) locations
175-200 lb-in
Custom Enclosure
1
C
L
1
C
L
C
L
Firmly abut pad foot on
bottom of enclosure and
strike diagonals from the
corners of the square
hole as illustrated and
center punch. Center
locations (2) per side.
C
2
L
C
L
3
C
L
2
Drill holes 7/16" dia.
(4) holes total typical
C
L
C
L
2
C
L
1
C
L
Custom Enclosure (Cont'd)
3
C
L
4
With pad foot attached
by (2) bolts strike
diagonals from the
corners of the square
holes as illustrated and
center punch. (4)
locations each side and
(4) each underside.
5
C
L
6
C
L
C
L
Custom Enclosure (Cont'd)
3
1
Drill holes 7/16" dia.
(16) holes total
9.686"
C
L
1
2
C
L
C
L
3
175-200 lb-in
42052-079-01 (1)
Printed in U.S.A.
Enclosure width + 3 - 11/32"
11.00"
