Installation Instructions
Antiglare Overlay for PanelView Plus 400 and 600
Terminals
Catalog Number(s) 2711P-RGxx
Topic Page
Important User Information 2
Before You Begin 3
Antiglare Overlay Description 4
Cleaning the Terminal 6
Attaching the Overlay 6
Remove the Overlay 7
Additional Resources 7
This document provides instructions on how to install the protective antiglare
overlay on the PanelView Plus 400 and 600 terminals.
2 Antiglare Overlay for PanelView Plus 400 and 600 Terminals
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication
SGI-1.1 available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com
equipment and hard-wired electromechanical devices. Because of this difference, and also because of the
wide variety of uses for solid state equipment, all persons responsible for applying this equipment must
satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot
assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
) describes some important differences between solid state
WARNING
IMPORTANT
ATTENTION
SHOCK HAZARD
BURN HAZARD
Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
Identifies information that is critical for successful application and understanding of
the product.
Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard and recognize the consequences.
Labels may be on or inside the equipment (for example, drive or motor) to alert people
that dangerous voltage may be present.
Labels may be on or inside the equipment (for example, drive or motor) to alert people
that surfaces may reach dangerous temperatures.
Publication 2711P-IN022B-EN-P - October 2008
Antiglare Overlay for PanelView Plus 400 and 600 Terminals 3
Before You Begin
Observe the following guidelines before installing the overlay.
• Make sure your hands are clean and dry.
• Handle the overlay by the edges to prevent marking it with fingerprints or
lint.
Remove lint or marks on the overlay before proceeding.
• Do not touch the adhesive ring.
Required Materials
The following items are required for installing the overlay:
• Windex™ or similar glass cleaner
• Clean, lint-free cloth
Publication 2711P-IN022B-EN-P - October 2008
4 Antiglare Overlay for PanelView Plus 400 and 600 Terminals
Antiglare Overlay Description
The antiglare overlay for the PanelView Plus 400 Grayscale terminal covers the
entire front of the bezel including the keypad.
400 Grayscale Antiglare Overlay
400 Grayscale Antiglare
Overlay 2711P-RGK4
The antiglare overlay for the PanelView Plus 400 Color Keypad and Keypad/Touch
Screen terminals cover the touch screen and keypad portions of the bezel
independently.
400 Color Keypad/Touch Antiglare Overlay
400 Color Keypad/Touch
Overlay 2711P-RGB4
Publication 2711P-IN022B-EN-P - October 2008
Antiglare Overlay for PanelView Plus 400 and 600 Terminals 5
The antiglare overlay for the PanelView Plus 600 Touch Screen terminal covers only
the touch screen portion of the bezel.
600 Touch Screen Antiglare Overlay
600 Touch Screen Antiglare
Overlay 2711P-RGT6
The antiglare overlay for the PanelView Plus 600 Keypad and Keypad/Touch
Screen terminals cover the touch screen and keypad portions of the bezel
independently.
600 Keypad/Touch Screen Antiglare Overlay
600 Keypad/Touch Screen
Antiglare Overlay 2711P-RGK6
Publication 2711P-IN022B-EN-P - October 2008
6 Antiglare Overlay for PanelView Plus 400 and 600 Terminals
The antiglare overlay has a protective layer over the adhesive side of the overlay
which can be removed by pulling back on the tab.
TIP
Adhesive Ring
DO NOT remove the protective layer until you are ready to install the overlay.
Protective Layer
Tab
Cleaning the Terminal
Use Windex™ or a similar glass cleaner to remove grease, fingerprints, streaks and
lint from the terminal screen. Any marks you do not remove will be trapped
underneath the overlay. Grease will also affect the adhesion of the overlay.
Attaching the Overlay
1. Grasp the tab and partially peel back the protective layer covering the
adhesive side of the overlay from one of the short sides.
Hold the peeled-back portion of the overlay protective layer out of the way
as you perform the next step.
Overlay
Bezel
Protective Layer
(Covers Adhesive)
Publication 2711P-IN022B-EN-P - October 2008
Antiglare Overlay for PanelView Plus 400 and 600 Terminals 7
2. Center the antiglare overlay on the terminal and carefully position the
exposed adhesive surface on the terminal.
3. Slowly peel off the rest of the overlay protective layer, while using a soft
cloth to press the antiglare overlay on the screen.
Make sure that the overlay lies flat without bubbles or warps.
4. With the soft cloth or the flat surface of a fingernail, press around the edges
of the overlay to completely seal it and remove any air bubbles trapped in
the adhesion.
Remove the Overlay
If it is necessary to remove the overlay, lift up a corner and slowly pull the overlay
off. Use isopropyl alcohol to remove any residual adhesive.
Removing the overlay greatly reduces the effectiveness of the adhesive. We
recommend that you do not reuse the overlay.
Additional Resources
These documents contain additional information concerning related Rockwell
Automation products.
Resource Description
PanelView Plus User Manual,
publication 2711P-UM001
Wiring and Grounding Applications for
PanelView Plus devices Technical Data,
publication 2711P-TD001
Provides an overview of the PanelView Plus and PanelView
Plus CE terminals and gives information on how to install,
operate, configure, and troubleshoot these devices.
Provides additional information on wiring and grounding the
PanelView Plus and PanelView Plus CE terminals.
You can view or download publications at
http://literature.rockwellautomation.com. To order paper copies of technical
documentation, contact your local Rockwell Automation distributor or sales
representative.
Publication 2711P-IN022B-EN-P - October 2008
