Rocktron V10 User Manual
V10
ELECTRIC GUITAR AMPLIFIER
User ’s Manual
Rocktron -A Division of GHS Corporation
2813 Wilber Avenue
Battle Creek MI 49015
USA
Rocktron Phone: 1-(269)-968-3351
Email: info@rocktron.com
Check us out on the web at:
www.rocktron.com
V elocity is a registered trademark of GHS Corporation Battle Creek MI, USA
May be covered by one or more of the following: U.S. Patents #4538297, 4647876, 4696044, 4745309, 4881047, 4893099,
R
5124657, 5263091, 5268527, 5319713, 5333201, 5402498 and 5493617.
Other patents pending. Foreign patents pending.
Y our Rocktron Velocity V10 amplifier has been designed to comply with the following Standards
and Directives as set forth by the European Union:
Council Directive(s): 89/336/EEC, 73/23/EEC, 76/769/EC, 1994/62/EC, 2000/
Standard(s): EN55022, EN50082-1, EN60065
This means that this product has been designed to meet stringent guidelines on how much RF
energy it can emit, and that it should be immune from other sources of interference when properly
used. Improper use of this equipment could result in increased RF emissions, which may or may not
interfere with other electronic products.
To insure against this possibility, always use good shielded cables for all audio input connections.
This will help insure compliance with the Directive(s).
V10 Specifications
53/EC, 2002/95/EC
Power Output
Speakers
EQ
Headphone Output
Channels
Dimensions
W eight
Power Requirements
Fuse
10 W atts
1 x 6.5” Custom Voiced Velocity Speaker by Rocktron
Bass
Treble
One 1/4” jack
DISTOR TION Switch
256mm(W) x 152mm(D) x 304mm(H)
10” x 6” x 12”
9.9lbs (4.5KG)
100 Volts AC 50/60Hz or 1 17 Volts AC, 60Hz
or 220/240 Volts AC, 50/60Hz, as specified on chassis
100-120V - use F500mA
220-240V - use F300mA
Copyright © 2006 GHS Corporation
All Rights Reserved.
2006-0001
Rev. 8/01/06
