Roberts Radio iStream User Manual

DAB / FM and WiFi Internet Radio with Music Player and Last.fm
ROBERTS
Enjoy Listening
Please read this manual before use
Contents
Introduction ......................................................................................... 2-9
iStream internet radio features ............................................................ 2
Before you can use this product .......................................................... 3
About this instruction manual............................................................... 4
Controls and connections ................................................................. 5-6
Battery operation ................................................................................. 7
Navigation controls ........................................................................... 8-9
Internet Radio - the basics................................................................. 19
Searching for a radio station by name ............................................... 23
Selecting a new or popular station .................................................... 24
Selecting a podcast / BBC Listen Again ............................................ 25
Presetting stations ............................................................................. 26
Last Listened ..................................................................................... 27
Use with Windows, Apple Mac, Linux, USB memory ........................ 33
Display modes ................................................................................... 40
Prune servers .................................................................................... 46
Wake On LAN .................................................................................... 46
Windows 7 'Play To' function ............................................................. 47
Last.fm - the basics ........................................................................... 48
Set up a Last.fm user account ........................................................... 49
Display modes ................................................................................... 54
Your listening history.......................................................................... 55
Deleting details of a Last.fm account................................................. 56
Scrobbling - On / Off control .............................................................. 56
Selecting a DAB radio station ............................................................ 58
Finding new DAB radio stations ........................................................ 61
Manual Tuning .................................................................................. 62
Dynamic Range Control settings ...................................................... 63
Station order setup ............................................................................ 64
Prune stations.................................................................................... 65
FM mode ..........................................................................................66-71
Manual tuning .................................................................................... 67
Display modes ................................................................................... 68
Scan setting ....................................................................................... 69
Stereo / Mono switching .................................................................... 70
Presetting stations in DAB and FM modes ........................................ 71
Clock and Alarms .......................................................................... 72-80
Automatically updating the clock ....................................................... 72
Setting the clock format .................................................................... 73
Disabling alarms ............................................................................... 79
Snooze timer .................................................................................... 79
Sleep timer ....................................................................................... 80
Brightness and contrast controls .................................................. 83-84
Headphone socket and Line out socket ............................................ 85
Auxiliary input socket ......................................................................... 86
Factory reset...................................................................................... 87
Software update ................................................................................ 88
Network proles ................................................................................. 89
Software version display.................................................................... 90
Audio FAQ ......................................................................................... 90
Accessing audio les via UPnP using Windows Vista and XP ....93-94
Audio codecs .................................................................................... 95
Guarantee............................................................................. Back page
Introduction
iStream internet radio features
Introduction .
The Roberts iStream provides the following features in an attractive compact unit:-
● Listen to local, regional, national and international broadcasts using FM, DAB and Internet radio
● Listen to over 1000 radio stations from around the country, and over 10,000 from around the world without using your PC.
● Listen to previously broadcast material from the BBC (using Podcasts / Listen Again)
● Listen to podcasts from a wide range of broadcasters.
● 30 radio station presets (10 Internet Radio, 10 DAB and 10 FM).
● Use the Music Player to play your music collection from your computer (using Windows Media Player 11 or 12). Connection to Apple and Linux based computers is also possible.
● Playback of audio les from USB memory devices.
● MP3, WMA, AAC, FLAC, WAV and Real Audio formats are supported (Real Audio for Internet Radio only).
● The iStream connects wirelessly to your home computer network.
● WiFi Protected Setup (WPS) is supported for simpler setting up with compatible wireless routers.
● Works with Last.fm, an on-line music service with millions of tracks available. It plays personalised radio stations based on your choice of artists, songs, listening history and similar tracks based on the preferences of other Last.fm listeners with similar music tastes.
● All radio station presets, network conguration details and user settings are retained in the event of a power failure.
● Large clock display with time and date when in Stand-by.
● Two alarm timers with snooze feature to wake you to either buzzer or a radio alarm (alarms only operate when mains powered).
● Adjustable sleep timer, can be set to turn the radio off after a delay of between 15 and 120 minutes.
● Easy-to-read graphic display.
● Adjustable display backlight.
● Auxiliary input socket for playing audio from MP3 players, iPods or other audio equipment.
● Line output socket for connecting the audio signal to an external amplier or recorder.
● Stereo headphone socket for private listening.
● Mains or battery powered operation using supplied mains adapter, or 4 x LR20 (D size) alkaline cells (not included).
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
2
Before you can use this product
Before you can use your internet radio, you must have the following:
● A broadband Internet connection (not required for DAB, FM or Music Player functions).
● A wireless access point (WiFi) connected to your broadband Internet Service Provider, preferably via a router. In many cases the broadband modem, router and wireless access point will be a single combined unit supplied by your Internet Service Provider or bought from a computer store.
● If your wireless network is congured to use Wired Equivalent Privacy (WEP) or WiFi Protected Access (WPA/WPA2) data encryption then you either need to know the WEP, WPA or WPA2 key used for encryption so that you can get the radio to communicate with the network, or your router needs to offer WiFi Protected Setup (WPS).
The radio will typically work within a 10-20 metre radius from your wireless access point. The actual range achieved will depend upon the building type, other nearby wireless networks, and possible interference sources. DAB and FM radio functions can operate wherever the radio is able to receive a suitable broadcast signal.
IMPORTANT: Before you continue, make sure that your wireless access point or router is powered up and working with your broadband Internet service (use your computer to verify this). To get this part of the system working you must read the instructions supplied with the wireless access point or router.
3
About this instruction manual
Introduction .
This instruction manual is split into sections for each of the different operating modes of your Roberts iStream internet radio. Each section is clearly identied by the shaded heading in the top right hand corner of each pair of pages.
Before using the Internet Radio and Music Player functions, you will need to connect your radio to your computer network using the WiFi connection. This is covered in the section titled Conguration.
The Internet Radio section describes how to nd radio stations to listen to. These can be radio stations that you already know and listen to conventionally, or new stations you may search for. You may set up stations that you like as Favourites so that they are more readily accessible.
The section for the Music Player describes how you may play music les that you may have stored on a computer connected to your network. The use of Shared Media (using UPnP) and USB playback is explained.
The Last.fm section explains the use of the radio in conjunction with the Last.fm internet based music streaming service.
The two sections for DAB Radio and FM Radio describe how to use the radio to listen to conventional radio broadcasts.
The section titled Clock and Alarms describes the different ways by which the clock in the radio may be set, as well as explaining the use of the alarms, snooze and sleep timer features.
The Display and Audio section shows how to adjust the display, use the equaliser and connect your internet radio to other audio equipment.
Conguration
Internet Radio
Music Player
Last.fm
DAB Radio
FM Radio
Clock and Alarms
Display and Audio
(page 10)
(page 19)
(page 33)
(page 48)
(page 57)
(page 66)
(page 72)
(page 81)
The Information section includes troubleshooting, specications and warranty information.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
Information
(page 87)
4
Controls and connections
Top view
2 3 4
5
1
14
1. On-Off / Volume control
2. Headphone socket
3. Auxiliary input socket
4. USB socket
5. Forward button
6. Tuning / Select / Snooze control
7. Last.fm button
8. Preset / Play-Pause button
9. Back button
10. LCD display
78910111213
11. Mode button
12. Menu button
13. Info button
14. Low battery indicator
6
5
Controls and connections - cont.
Rear view
16
17
18
15. Telescopic aerial (antenna cable socket behind)
16. WiFi antenna (internal)
17. Line output socket
18. DC in socket
Introduction .
15
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
6
Battery operation
We recommend for economy that the iStream is used via the AC adaptor whenever possible with battery operation for occasional use only. Inserting the adaptor plug into the DC input socket will disconnect the batteries.
If using batteries, only alkaline types should normally be used. Battery life will vary according to the use of the radio, but between 30 and 60 hours should be possible. WiFi use takes much more power than DAB listening, for example.
To install batteries in your radio follow these steps.
1. Release the catch securing the rear door of your radio.
2. Insert four LR20 (D size) batteries into the spaces in the compartment. Take care to ensure all batteries are inserted with the correct polarity as shown inside just above the battery compartment.
3. Close the rear door and secure the catch.
The low battery indicator lighting, reduced power, audio distortion or the radio switching itself off are all signs that the batteries may need replacing.
If the radio is not to be used for any extended period of time it is recommended that the batteries are removed from the radio.
Rechargeable Nickel Metal Hydride (NiMH) cells can be used in the radio but must be charged outside the radio using an external charger. Note that commercially available D size NiMH cells have a capacity which is only a small fraction of that of D size Alkaline cells and so they will power the radio for only a few hours before needing recharging. Never mix batteries
of different types, capacities or brands in the radio.
IMPORTANT: The batteries should not be exposed to excessive heat such as sunshine, re or the like. After use, disposable batteries should if possible be taken to a suitable recycling centre. On no account should batteries be disposed of by incineration.
7
1
Navigation controls
These pages describe the basic means of controlling your iStream internet radio. Detailed instructions for each operating mode are given in the later sections of this book.
1. Pressing and holding the On/Off control brings your internet radio out of the Stand-by mode if running from the mains or switches it on if using batteries.
Pressing and holding the On/Off control while the internet radio is in use will cause
it to return to the Stand-by mode with the clock display when running from the mains, or will switch it off after a short delay when running on batteries.
The On/Off control is designed not to respond to a very short press of the control.
2. Pressing the Mode button gives you access to each of the operating modes in turn: Internet Radio, Music Player, Last.fm, DAB radio, FM radio and Auxiliary Input.
3. Pressing the Menu button will access the menu system.
4. Many operations require the user to make a selection from the menu. This is done using the Tuning/Select control. Turn the control clockwise or anti-clockwise to highlight the desired menu item then press the control to select that item.
If there are more than ve items in a menu, then the display will automatically scroll
up or down so that the additional items become visible. A sliding bar on the right will give an indication showing the current portion of the menu that is displayed.
If there are many items in a menu, then the internet radio allows the menu to 'wrap
around' in either direction. This can make it easier to reach items at the end of a long menu, such as a list of countries or Internet radio stations.
Introduction .
1
2
4
3
5. In addition to the Select control, pressing the Forward button may also be used to make selections from the displayed menu.
If an error is made when navigating the menus, it is generally possible to go back
to a higher level menu by pressing the Back button.
6. The Info button allows the display of information relating to the radio station or music le being played.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
5
5
6
8
Navigation controls cont.
Text entry
There are several occasions when you may need to enter text characters into your radio. For example, when setting up the WiFi connection, or when searching for artists or albums. When entering text you can use the Tuning/Select control alone or in conjunction with some of the buttons. The rotary control allows you choose from all of the available characters, while the buttons allow you to move up and down or left and right through the character list displayed.
1. Rotate the Tuning/Select control to highlight each character as needed and press the control to enter each character into the radio.
Alternatively
2. To highlight the next character in the character display press the Forward button. Press and hold to move more quickly.
3. To highlight the previous character in the character display press the Back button. Press and hold to move more quickly.
4. To move up a line in the character display press the Preset button. Press and hold to move more quickly.
5. To move down a line in the character display press the Last.fm button. Press and hold to move more quickly.
6. To enter the highlighted text press and release the Tuning/Select control.
7. The Info button allows quick access to the Backspace control. You can then use the Tuning/Select control to access the OK and Cancel options. Press Info again to go back to the character selection.
9
1,6
2
4
7
3
5
Conguration
Connecting your radio to your computer network
1. Place your radio on a at surface and plug the cable from the mains adaptor into the DC input socket located at the rear of your radio (marked 'DC') ensuring that the plug is pushed fully into the socket.
2. Plug the mains adaptor into a wall socket and switch on the socket.
IMPORTANT: The mains adaptor is used as the means of connecting
the radio to the mains supply. The mains socket used for the radio must remain accessible during normal use. In order to disconnect the radio from the mains, the mains adaptor should be removed from the mains socket outlet completely.
3. When you apply power, the display on the radio will light up and say: 'ROBERTS' and 'STARTING' with a progress indicator. The rst time that you use your radio (or after a Factory Reset) the display will show 'Setup wizard' and 'YES' will be highlighted on the screen. Press the Tuning/Select control to start the setup wizard. You will then have a choice to set the clock to use the 12 or 24 hour format.
You are recommended to run the setup wizard, but if you do not wish
to then rotate the Tuning/Select control until 'NO' is highlighted on the display then press the control. This will lead to the main menu.
4. Rotate the Tuning/Select control to highlight the desired clock format (either 12 or 24 hour) then press the control to enter your selection.
A menu allowing you to specify the auto update option for the clock
will appear on the display. The default of 'Update from Network' will be the best option for most users.
Conguration .
3,4
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
10
Connecting to your computer network - cont.
5. Rotate the Tuning/Select control to choose an auto-update option for the clock. This can be updated from DAB or FM radio, from the Network, or not updated. The default is to auto update from the network. If you choose any other option, go to step 8. Otherwise you will rst need to select the correct time zone and daylight savings setting, see steps 6 and 7. If you choose 'No update' you will need to set the clock manually later, see page 74. Press the control to conrm your choice.
6. Rotate the Tuning/Select control to highlight the time zone which is applicable to your location. Press the control to enter the setting.
7. You will then need to set the Daylight Savings option according to your location (Daylight Savings is also known as Summer/Winter time or BST/GMT adjustment).
Rotate the Tuning/Select control to highlight 'YES' to turn on daylight
savings if required or 'NO' if you do not wish to use daylight savings then press the control to conrm the setting.
In the UK, 'ON' is equivalent to British Summer Time and 'OFF' is
equivalent to Greenwich Mean Time.
8. The display will then show a list of WiFi regional options for the network set up (for the UK choose 'Most of Europe'). Rotate the Tuning/Select control to highlight the required region and then press the control to select it. Your radio will then scan for available WiFi networks.
9. The radio will enter the Network Settings Wizard and will display 'Scanning...'. After a short while the display will show a list of the available WiFi networks.
5-9
11
Connecting to your computer network - cont.
10. You will rst need to identify your network in the list of network names presented by the Network Wizard. If no networks are found then you may have to get your wireless router working (please see the instructions supplied with it) or you may be too far from the router.
When the radio nds your wireless network, it displays the Network
Name (SSID) for the wireless access point on the screen. This is a name that is allocated to the access point in your router by the person who set up the network - for example: 'Jones family' or 'Paul's network'. If the router supports WiFi Protected Setup, then '[WPS]' will be shown in front of the SSID.
It is possible, and in some locations highly likely, that your radio will
nd more than one wireless network, in which case you should choose which one you need to connect to.
11. Rotate the Tuning/Select control to see the SSID for each wireless network that has been found. If your network is shown proceed to step 13 on the next page. If it is not shown then proceed to step 12.
If you make a mistake at any point, use the Back option to go back to
the previous screen.
12. If your network is not found, it may be because the router is congured not to broadcast the SSID. You should then use the Tuning/Select control to highlight and select the '[Manual cong]' option in order to enter the network details manually. This is described in 'Manual Network Conguration', see page 16.
If your network name is being broadcast, and it was not found, then
try re-scanning (press the Back button), and if necessary try moving your radio to a location closer to your access point / router.
Conguration .
11,12
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
12
Connecting to your computer network - cont.
13. When the SSID for the wireless network you wish to connect to is highlighted on the screen, press the Tuning/Select control. If WiFi Protected Setup (WPS) was indicated, you will see an additional menu at this point, otherwise proceed to step
14.
Choose one of the WPS menu options as required for your router (WPS may be via
push button, or using an identication number).
'Push Button' - the display prompts you to press the WPS button on your router and
then the Tuning/Select control on the radio. The two devices should then connect with the encryption key sent automatically to the radio.
'PIN' - the display shows an identication number which you must enter into your
router using a web browser (refer to your router's user documentation). You should then press the Tuning/Select control on the radio. The two devices should then connect with the encryption key sent automatically to the radio.
'Skip WPS' - if you wish to enter the encryption key yourself (or if it was previously
entered).
If you chose Push Button or PIN the screen will then show 'Connecting...' and then
'Setup wizard completed'. Press the Tuning/Select control to exit setup wizard and then go to paragraph 17 on the next page.
14. If your network is congured without an encryption key, the screen should say 'Connecting...', and then 'Setup wizard completed'. Press the Tuning/Select control to exit the setup wizard and show the main menu. If this is the case then you have successfully connected your radio to your network, so please go to paragraph 17 on the next page.
15. If the screen displays 'Key:', it is because the network is using one of the encryption systems: Wired Equivalent Privacy (WEP) or WiFi Protected Access (WPA). You will need to enter the correct WEP or WPA key into the radio to allow it to communicate with your wireless network. If you do not have the WEP or WPA key, then you should obtain it from the person who set up your network. Some wireless routers may come with an encryption key already set up by the supplier, in which case you should refer to the documentation provided with it. WPA is used here to also include WPA2.
13
Connecting to your computer network - cont.
WEP keys are 10 or 26 characters long (using 0 - 9, and A - F). Some wireless
routers can also use pass-phrases for WEP but these are not supported. WPA keys are usually set up using a pass-phrase of between 8 and 63 characters. Your radio accepts pass-phrases for WPA keys.
16. To enter the WEP or WPA key, characters are selected and entered using the Tuning/Select control. As you rotate the control, the highlight scrolls through the available characters as well as the three controls on the right. The character currently highlighted will be entered when you press the Tuning/Select control.
Do this as needed until the complete key has been entered. Remember, WEP
keys only use the numbers 0-9 and letters A-F. WPA keys are sensitive to upper and lower case characters. You must enter the key exactly or the radio will not connect to the network.
The three controls on the right-hand side of the screen have special functions. You
can quickly access these by pressing the Info button and then use the Tuning/ Select control as needed. See also 'Text Entry' on page 9.
select ' ' to erase a character just entered (long press to clear)
select ' ' when the complete key has been entered
select ' ' to cancel and re-run the Network Wizard
If a WEP or WPA key has previously been entered for the selected SSID then the
display will show 'Key: [Set]'. If you have previously entered a different key, you must clear this by selecting the ' ' symbol. This will remove the '[Set]' indication.
After the nal character of the WEP or WPA key has been entered, highlight the ' '
symbol and press the Tuning/Select control. The screen will show 'Connecting...' and then 'Setup wizard completed'. Press the Tuning/Select control to the exit setup wizard. The radio should now be able to connect to the network.
Conguration .
13-16
16
17. Once connected to the network your radio will display the main menu. Press and hold the On/Off button to put the radio into Stand-by mode. It should then display the time as obtained from the Internet. If the time displayed is not correct for any reason, it can easily be adjusted later, see page 74, 'Manually setting the clock'. The clock display will switch off after 30 seconds if the radio is running on batteries.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
17
14
Connecting to your computer network - cont.
If you have followed the steps on the preceding pages successfully, your radio will have connected to your router, and then made a connection to the Internet and set its clock. If this is the case, then you can try listening to radio stations via the Internet as described on page 19 onwards.
Note: The clock display when in Stand-by mode is only maintained when the radio is powered from the mains. If you are powering the radio from batteries, then the clock display will be switched off after about 30 seconds and the radio will shut down completely in order to minimise battery usage. The clock will be reset to the current time the next time that you switch on the radio.
Changing the network connection
From time to time, you may nd that you need to connect to different computer networks. The Internet setup menu allows you to change your radio’s network settings, scan for an alternative wireless network, or to manually congure the network parameters.
The steps outlined below describe how you can do this - see also the section 'Network proles' on page 89. If you have no need to do this, however, please skip to page 19.
Conguring the radio to use an alternative WiFi connection
1. From the Network settings menu select 'Network wizard'. This will present you with details of any WiFi networks that are found. Scroll down the list using the Tuning/Select control to the desired network name. Press the control to select this network.
The radio will then use its WiFi system to communicate with the network. Depending on the settings
for the new network you may need to enter an encryption key (see pages 13-14). By default the radio will then acquire an IP address and other network settings from your router using DHCP.
15
Manual network conguration
If you do not wish to use DHCP for automatic conguration, or if your network is congured with a hidden SSID, then you will need to enter some network settings manually. (Note - a hidden SSID may prevent casual observers from detecting your network, but it is not recommended as a means of network security.)
1. From the radios Network settings menu, select 'Manual settings'. There are as many as nine settings screens, shown by the '1 of 9' progress marker in the top right corner of the display.
2. The next menu asks whether you wish to use DHCP to congure your network parameters (IP address, subnet mask, gateway address, etc.). Unless you are familiar with networking and related terminology, we recommend that you allow the use of DHCP. Choose 'DHCP enable' unless you need to specify the network details manually.
If you chose 'DHCP enable', please skip to step 6 on page 17 in order to set up the wireless connection
details.
If you chose 'DHCP disable' the next step is to set up the IP address.
3. The manually specied IP address should be chosen to be compatible with the settings in your router and must be a unique address on your network. If you are using DHCP for some devices and static (manually congured) IP addresses for others, the IP address used should fall outside the range that the router may allocate using DHCP. Typically, the rst three groups of digits will be the same for all devices on your network. To enter the IP address, rotate the Tuning/Select control to set the value for each group of digits and then press the control to enter the value and to move on to the next group. When the IP address has been entered, the subnet mask should be entered. The subnet mask denes which parts of the IP address are common across your network. For most small networks the subnet mask will be 255.255.255.0 and this is entered in the same way.
4. The Gateway address is normally the IP address of the router through which the radio connects to the internet and is entered in the same way as the previous addresses.
Conguration .
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
16
Manual network conguration - cont.
5. In most installations the DNS settings (DNS = Domain Name Server) will be set to the same IP address as your router. In this case the secondary DNS may be left at zero.
To enter the DNS address, rotate the Tuning/Select control to set the value for each group of digits
and then press the control to enter the value and to move on to the next group. Repeat this until all eight groups of digits have been entered.
6. The next step is to set up the WiFi connection, starting with the name of the wireless network (SSID) followed by the encryption options and password.
To enter the SSID, characters are selected and entered using the Tuning/Select control. As you rotate
the control, the radio scrolls through the available characters as well as the three controls on the right. The character currently highlighted will be entered when you press the Tuning/Select control. See also 'Text Entry' on page 9.
Do this as needed until the complete network name has been entered. The SSID setting is sensitive
to upper and lower case characters and symbols. You must enter it exactly as set up in your router.
The three controls on the right-hand side of the screen have special functions. You can quickly access
these by pressing the Info button and then use the Tuning/Select control as needed:
select ' ' to erase a character just entered (long press to clear); Info again to continue select ' ' when the complete SSID has been entered select ' ' to cancel and go back to the DNS settings screen
7. Having entered the SSID, you must enter details of the encryption system used on your wireless network. This should be the same as specied in your router settings. If your network does not use encryption, then select the 'Open' option. Your radio should then connect to the network, so skip to step 11. If your network uses WEP (Wired Equivalent Privacy) select the 'Pre-Shared Key' option then go to step 8. The remaining options are for WPA or WPA2 (WiFi Protected Access) - see step 9.
8. If you chose 'Pre-Shared Key' in step 7, you should then choose the WEP option. The key should be entered using only the numbers 0-9 and the letters A-F. The key will be 10 characters long for 64-bit encryption and 26 characters long for 128-bit encryption. The radio will accept lower-case letters a-f as equivalent to upper-case A-F. Spaces or special symbols are not permitted in WEP keys. Text entry is by the same method as described above in step 6. See also 'Text entry' on page 9.
17
Manual network conguration - cont.
The three controls on the right-hand side of the screen have special functions. You can quickly access
these by pressing the Info button and then use the Tuning/Select control as needed:
select ' ' to erase a character just entered (long press to clear); Info again to continue select ' ' when the complete encryption key has been entered select ' ' to cancel and go back to the SSID settings screen
Once the key is entered the radio should connect to your network. Please skip to step 11.
9. WPA and WPA2 are similar, although WPA2 offers a higher level of security. Whichever you selected in step 7, you then have to specify the variant used. They are TKIP (Temporal Key Integrity Protocol) and AES (Advanced Encryption Standard). As previously, the setting should match that used by your router. Some routers allow both to be specied, and the router will use whichever variant is supported by the connected device. AES is regarded as the more secure option if it is available.
10. The radio will then require you to enter the encryption key. This must be a string of between 8 and 63 characters and must be identical to the key which has been entered into your router. Note - the
encryption key is sensitive to the use of upper and lower case letters and symbols. Take care to enter the key exactly, or the radio will not be able to connect to your router. See also 'Text Entry' on page 9.
The three controls on the right-hand side of the screen have special functions. You can quickly access
these by pressing the Info button and then use the Tuning/Select control as needed:
select ' ' to erase a character just entered (long press to clear); Info again to continue select ' ' when the complete encryption key has been entered select ' ' to cancel and go back to the TKIP / AES options screen
Once the key is entered the radio should connect to the network.
11. While the radio is trying to connect to the network, it will display 'Processing...' when checking the encryption key and then 'Connecting...'. If the connection is made successfully, the radio will return to the Network settings menu. If the unit cannot connect, then it will display a 'Failed to connect' message and will return to the SSID entry screen (step 6).
Once connected, the network settings are stored in the radio. The settings are retained when the radio
is disconnected from the mains.
You may now use the Back and Mode buttons to access the functions of your internet radio.
Conguration .
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
18
Internet Radio
Internet Radio - the basics
Before you can use your radio to listen to broadcasts via the Internet, it is necessary to have connected it to your computer network using the wireless (WiFi) connection.
There are literally many thousands of radio broadcasts available via the Internet as well as 'Podcasts'. Your radio provides several ways of searching for broadcasts in order to make nding and choosing them easier. Once you have found radio stations which you like, you may either store them as presets within the radio, or add them to a list of your favourite stations which your radio can access. The number of presets is limited (there are ten memory presets available on the internet radio), but you can store as many favourites as you like.
You may search for an internet radio station by Location. If you know the name of the station and the country from which a station is broadcast this may be the easiest method to nd a station. It is also a great way to experience radio from other parts of the world.
You may also search for an internet radio station by Genre. If you prefer a particular type of music, Blues for example, you may search for a radio station that broadcasts that type of music, and you can choose from a list of Blues radio stations regardless of location, or taking location into account.
If you know part of the name of an internet radio station, you can enter it into the radio and it will search for stations that match that name. This can be helpful if you are unsure of the location or genre of a particular station.
The iStream radio connects to a radio station database which serves many users in many countries. This means that there is a very wide range of programme content available. You can also search for stations which have been recently added to those available (new stations) or you can search for the most popular.
19
Selecting a radio station by location
1. Press and hold the On/Off control to switch the radio on. Then press the Mode button to select the Internet radio mode display.
2. Press the Menu button to enter the main Internet radio menu. Rotate the Tuning/Select control until 'Station list' is highlighted on the display and then press the control to select the option.
Internet Radio .
1
3. Rotate the Tuning/Select control until 'Stations' is highlighted on the display and the press the control to select.
Note that the menu may offer one or more local selections based upon
the country in which the unit is being used, according to your internet IP address ('United Kingdom' and 'BBC' stations, for example).
4. Rotate the Tuning/Select control until 'Location' is highlighted on the display and then press the control to select.
5. Rotate the Tuning/Select control to scroll through the list of continents. When the desired continent is highlighted press the control to enter your selection.
6. The display will show a list of countries within the chosen continent. If there are many countries shown you can scroll through the list continually in either direction. For example, if the chosen continent was Europe, then to nd the United Kingdom scroll up from the top of the list to the bottom by turning the Tuning/Select control anti-clockwise. Press the Tuning/Select control to choose the desired country.
7. You will typically nd that you then have the option to select either 'All Stations' or one of a number of categories. The lists are always sorted alphabetically, and long lists will wrap around from top to bottom or bottom to top.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
2
2-6
20
Selecting a radio station by location - cont.
8. Rotate the Tuning/Select control to highlight your chosen radio station and then press the control to enter your selection. The display will show 'Connecting...' while the radio connects to the new station. The station should then start playing. Adjust the volume as needed.
9. If the station has on-demand content, that is, it gives the option of listening to programmes which have already been broadcast or to Podcasts, there will be an additional screen showing the radio station name as well as a 'Podcasts' option.
These are selected using additional menus, determined by the radio
station and the content. There may simply be a list of programmes, or there may also be options to chose from broadcasts on particular dates or days of the week. The examples shown here are typical.
Podcasts and Listen Again content can also be accessed separately
from the main Internet Radio menu, see page 25.
If your radio cannot connect to a radio station
Note: If your radio is unable to connect to an internet radio station it will generally either display 'Network Error' or 'Stopped'. This can be for many reasons, but typically will be due to one of the following:
The radio station may not be broadcasting at the present time.
The radio station may not be able to accommodate any more connections
from internet listeners.
The broadcaster may limit listening to specic countries or regions
There may be network congestion (either locally or at a distance)
which is affecting the reliability of the connection.
If your radio can connect, but the audio is not continuous and the radio keeps having to reconnect, this may be due to the radio station only having limited connection capacity.
Please also refer to the section 'Troubleshooting' on page 91.
8,9
8
21
Selecting a radio station by genre
1. Press the Menu button to enter the main Internet radio menu. Rotate the Tuning/Select control until 'Station list' is highlighted on the display and then press the control to select.
2. Rotate the Tuning/Select control until 'Stations' is highlighted on the display and then press the control to select.
3. Rotate the Tuning/Select control until 'Genre' is highlighted on the display and then press the control to select.
Internet Radio .
1
4. Rotate the Tuning/Select control to scroll through the list of content types. This menu is normally cyclic - you can scroll the list continually in either direction. When the chosen genre is highlighted, press the Tuning/Select control.
5. You then have the choice of 'All Stations' of the chosen genre, or a list of countries. Note if a country is not shown then the station may still appear in the 'All Stations' list. Rotate and then press the Tuning/Select control to choose as needed.
6. A list of radio stations is then shown. Rotate the Tuning/Select control until the desired station name is highlighted on the display.
7. Press the Tuning/Select control to select the station. The display will show 'Connecting...' while it nds the new station. If the radio is unable to connect this may be for one of the reasons explained on page 21.
8. Adjust the Volume control as needed to set the listening level.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
1-7
8
22
Searching for a radio station by name
There may be occasions when you know the name of a radio station but you do not know the location or genre. This facility allows you to search for the station using a part (or parts) of the radio station name.
1. Press the Menu button to enter the main Internet radio menu. Rotate the Tuning/Select control until 'Station list' is highlighted on the display and then press the control to select.
2. Rotate the Tuning/Select control until 'Stations' is highlighted on the display and then press the control to select.
1
3. Rotate the Tuning/Select control until 'Search stations' is highlighted on the display and then press the control to select.
4. To enter the search word(s) rotate the Tuning/Select control to highlight each character for the search in turn, and press the Tuning/Select control to enter. If you make an error rotate the control or use the Info button to access the delete character ' ' on the screen and then press the Tuning/Select control. Rotate the control or press Info again to go back to the character selection. After the nal character of the search has been entered, use the Info button and then the Tuning/ Select control to highlight the ' ' symbol on the screen and then press the control to nish. See also 'Text Entry' page 9.
5. The radio will search for radio stations that match your search data. If you include a space between two search items the radio will look for station names which include both items. Thus a search for 'ROCK 100' could nd a station called '100 Classic Rock Hits' as well as a station called '100.FM Rocks'
6. Rotate the Tuning/Select control to highlight the station that you wish to listen to and press the control to conrm your choice. The display will show 'Connecting...' while it nds a new station.
23
1-6
Selecting a new or popular station
As described in the section 'Internet Radio - the basics' on page 19, your radio connects via the Internet to a database of radio stations. This option is provided to highlight stations which are newly added to the list of those available, or stations which are particularly popular with listeners around the world. Your radio allows you to easily choose stations from these two categories, using menus very similar to those used when nding stations by location and genre.
1. Press the Menu button to enter the main Internet radio menu. Rotate the Tuning/Select control until 'Station list' is highlighted on the display and then press the control to select.
2. Rotate the Tuning/Select control until 'Stations' is highlighted on the display and then press the control to select.
3. Rotate the Tuning/Select control until 'Popular stations' or 'New stations' is highlighted on the display. Press the Tuning/Select control to enter your choice.
4. Rotate the Tuning/Select control to highlight the station that you wish to listen to and then press the control to enter your choice. The display will show 'Connecting...' while the new station is found.
If the radio is unable to connect to a particular radio station this may be for one of the reasons explained on page 21.
Internet Radio .
1
1-4
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
24
Selecting a podcast / BBC Listen Again
Some radio stations allow you to listen to programmes that have already been broadcast. The BBC's Listen Again service is an example of this. In addition, radio broadcasters and individuals may make programmes which are intended normally to be downloaded into a computer or copied onto a portable media player. These are commonly known as Podcasts.
On your radio, both Listen Again programmes and Podcasts are grouped together as Podcasts, and the same menu is used to access and listen to both types of programming. Listen Again programmes are also accessible via the Stations menu (see pages 20-21).
1. Press the Menu button to enter the main Internet radio menu. Rotate the Tuning/Select control until 'Station list' is highlighted on the display and then press the control to select.
2. Rotate the Tuning/Select control until 'Podcasts' is highlighted on the display and then press the control to select.
3. You may then search by location, genre, or using part of the name of the podcast. The searches operate in exactly the same way as when searching for a conventional radio station.
Searching by location is done rst by continent, then by country. You
may then list 'All shows' or search within a country by genre.
Searching by genre is more direct, since once the genre is chosen
the next menu display shows a list of available podcasts.
Searching by name operates in the same way as when searching
for a named radio station, selecting the ' ' symbol when you have entered the text. You may enter one or more pieces of text which will be used for the search.
1
1-4
4. Rotate the Tuning/Select control and then press the control to conrm your chosen podcast. The display will show 'Connecting...' while it nds the new programme.
25
Presetting stations
With so many Internet radio stations available, it is desirable to have a means of rapidly selecting the stations that you listen to most frequently. Your radio has ten memory presets which can easily be set to store the details of any Internet radio station. The radio station presets are retained in the radio's memory even when the radio is switched off.
Please see also the sections 'Last Listened' on page 27 and 'Conguring My Favourite Stations' on page 30.
Storing a preset
1. Press and hold the On/Off control to switch on your radio. Tune to the required station using one of the methods described on the preceding pages.
2. Press and hold the Preset button. The display will show a 'Save to Preset' menu.
3. Use the Tuning/Select control to scroll through the preset list until you reach an unused preset or a preset that you wish to change. Press and release the Tuning/Select control to store the preset. 'Preset stored' will be shown on the display. Repeat this procedure as needed for the remaining presets.
4. Stations which are already stored in the presets may be over-written by following the procedure above.
Recalling a preset
Internet Radio .
2
1-4
1
2
1. Select the Internet radio mode using the Mode button.
2. Press and release the Preset button to display the 'Recall from Preset' menu. Use the Tuning/Select control to select the desired preset station. Press and release the Tuning/Select control. Your radio will then connect to the station stored in the preset memory. The preset used will be shown at the bottom of the display screen.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
2
26
Last Listened
It is often helpful to be able to go back to a station that you have recently listened to. Your radio has a 'Last Listened' feature which provides you with quick access to the ten most recently listened to radio stations or podcasts. As each new radio station is listened to the oldest item is deleted from the list. The Last Listened list is stored when the radio is disconnected from the mains.
1. With the radio switched on and in Internet radio mode, press the Menu button. The rst item on the menu is 'Last listened'. With this item highlighted press the Tuning/Select control.
1
2. The display will then show a list of the last ten Internet radio stations or podcasts. Rotate the Tuning/Select control to highlight whichever you wish to listen to and then press the control to cause your radio to reconnect to that radio station or podcast.
Display modes
Your radio has a range of display options when in Internet Radio mode. Note that not all information may be available for all Internet radio stations
1. Press the Info button to cycle through the different options.
a. Programme information Displays information from the
broadcaster about the radio station or scrolling text messages such as artist/track name, phone number etc (this display not available for all stations).
b. Description Displays a basic description of the
current radio station.
27
1,2
a
1
b
Display modes - cont.
c. Genre Displays programme type information
e.g. Pop, Classic, News, etc. and the location of the current radio station.
d. Reliability Displays the reliability of the data
stream from the station currently being received.
Internet Radio .
c
e. Format Displays the bit rate and format of the
station being received.
f. Playback buffer Displays status when connecting to and
playing a radio station. This indicates the reliability of the data stream to your radio. If there are no bars shown to the right of the dividing line then the data stream reliability may be poor.
g. Date Displays the current date.
Additional or alternative information may be displayed when listening to Podcasts. Categories displayable can include...
Episode name Show description
Show genre Show language
Episode URL Bit rate
Codec Sampling rate
Whenever the radio is displaying an information screen (as opposed to a menu screen), the time is displayed in the top-right corner of the display, and a WiFi strength indicator is shown in the bottom-right corner.
If you need any further advice, please call our Technical Helpline on 020 8758 0338 (Mon-Fri)
d
e
f
g
28
Customising your radio
In addition to storing your favourite radio stations in the radio presets, your radio allows you to create customised lists of stations which can appear in two special menus on the radio called 'My Favourites' and 'My Added Stations'.
Your radio uses a database which is accessed via the Internet in order to nd out which radio stations are available and how it should connect to them. You are able to add your personal selections to this database. These will only be accessible by you using your PC or your radio. You can choose the stations which will appear in the 'My Favourites' menu from the large selection already listed. Additionally, if you nd a radio station that is not listed then you may also add the Internet address (URL) of the station's audio stream to your selection. It will then appear on your radio via the 'My Added Stations' menu item.
Registering an account
1. Go to the web site http://www.wiradio-frontier.com using the Internet browser on your computer. Click on the ‘Register here’ link and follow the on-screen instructions to register an account. During the registration process the web site asks for an access code. This allows it to uniquely identify your internet radio from the many others that it also provides data for. To obtain the access code, please follow these steps.
2. With your radio switched on and in Internet radio mode, press the Menu button, then select 'Station list' using the Tuning/Select control.
3. Scroll down the Station list menu to the item called 'Help'. Press the Tuning/Select control to enter the Help menu.
29
4. In the Help menu, select the menu item 'Get access code'. Provided that the radio is connected to the Internet, a code will be displayed of typically seven characters (upper case letters and numbers). Make a note of this code for the next step. If you need to re-register later you must repeat this process to get a fresh access code.
5. You should then use the code displayed by the radio to ll in the Access Code eld on the web page when you set up your account.
Once you have your account set up, if you have other radios which use the same database, you may also add them to your account. You will need to get an access code from each radio in order to add it to the account. They may then share your favourite and added radio station details.
Loading...
+ 70 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
