REMKO
TANK SYSTEMS
Hot water storage tank
HPS 500, MPS 800, MPS 1000
Operation · Technology
Edition GB-F07
Contents
Safety notes
Environmental protection and recycling
Warranty
Intended use
Operation
Description
Decommissioning
Care and maintenance
Installation instructions for qualified personnel
Installation
Fitting the insulation
Connection examples
Commissioning
4
5
5
5
5
6
6
7
7-8
8-9
10-13
14-15
16
Unit dimensions and technical data
Read these operating instructions carefully before
commissioning / using these units!
These instructions are an integral part of the unit and must
always be kept in the vicinity of the installation location or
on the unit itself.
This operating manual is a translation of the German original.
Subject to modifications; no liability accepted for errors or
misprints!
17-19
3
REMKO HPS 500, MPS 800, MPS 1000
Safety notes
Carefully read the operating manual
before placing the unit in service for the
first time. It contains useful tips and notes
such as hazard warnings to prevent
injury and material damage . Failure to
follow the directions in this manual can
result in endangerment to persons, the
environment and the equipment itself
and will void any claims for liability.
■ Keep this manual in the vicinity of the
units.
■ The units and components should be
set up and installed only by qualified
personnel.
■ The set-up, connection, and
operation of the units and their
components must be in accordance
with the operating conditions
stipulated in this manual and comply
with all applicable local regulations.
■ Modification of units and components
supplied by REMKO is not permitted
and can cause malfunctions.
■ Units and components may not be
operated in areas where there is an
increased risk of damage. Observe
the minimum clearances.
■ The electrical supply is to be adapted
to the requirements of the units.
■ The operational safety of units and
components is only assured if they are
fully assembled and used as intended.
Safety devices may not be modified
or bypassed.
■ Do not operate units or components
with obvious defects or signs of damage.
■ The equipment and components must
be kept an adequate distance from
flammable, explosive, combustible,
abrasive and dirty areas or
atmospheres.
■ Installation, repair and maintenance
work may be carried out only
by authorised specialists. Visual
inspections and cleaning can be
performed by the operator as long
as power is disconnected from the
equipment.
■ To preclude any danger from the unit,
take appropriate hazard-prevention
measures when performing
installation, repair or maintenance
work or cleaning the units.
4
Environmental
protection and
recycling
Disposal of packaging
All products are packed for transport
in environmentally friendly materials.
You can make a valuable contribution
to reducing waste and sustaining raw
materials by only disposing of packaging
at approved collection points.
Disposal of
components
The manufacturing process for the units
is subject to continuous quality control.
Only high-grade materials are processed,
the majority of which are recyclable.
You can also contribute to environmental
protection by only disposing
of components in accordance with local
regulations and in an environmentally
safe manner, e.g. through authorised
disposal and recycling specialists or
at collection points.
Intended use
The storage tanks are employed for
the storage of hot water in all types of
warm water central heating systems
(solid fuel/oil-fired boilers, heat pumps,
solar energy systems, gas/electric
instantaneous water heaters) within
enclosed spaces and for the storage of
cold water for cooling processes or heat
recovery purposes.
Any different or additional use shall
be classed as non-intended use.
The manufacturer/supplier assumes no
liability for damages arising from such
use. The user bears the sole risk in such
cases.
Intended use also includes working
in accordance with the operating
manual and installation instructions
and complying with the maintenance
requirements.
Operation
Manual operation is not necessary.
Warranty
The warranty conditions are listed in the
"General terms and conditions".
Please contact your contractual partner
in the first instance.
5
REMKO HPS 500, MPS 800, MPS 1000
Description
The storage tanks are employed for
the storage of hot water in all types of
warm water central heating systems
(solid fuel/oil-fired boilers, heat pumps,
solar energy systems, gas/electric
instantaneous water heaters) within
enclosed spaces and for the storage of
cold water for cooling processes or heat
recovery purposes.
The tank volume can be adapted to
your particular needs by connecting
several storage tanks to form batteries.
The storage tanks may be used
universally, either as parallel storage
(hydraulic switch) or series storage.
The insulation of the HPS 500 and
MPS 800/1000 hot water tanks consists of
a 100 mm thick layer of silver-grey flexible
foam.
All storage tanks are produced from
high-quality steel acc. to DIN EN
10025/10111, and are provided with an
anti-rust coating on the outside.
Immersion heater elements can be
screwed into the in-built 6/4" socket in
the storage tanks.
For retrofitting a fin-tube heat
exchanger a D240 blank flange cover is
included.
The storage tanks have 9 (11 for the
MPS 1000) 6/4" IG connection threads
as well as inflow restrictors.
To enable to use of sensor/thermometer
immersion sleeves, the unit incorporates
four 1/2" socket screw threads.
Decommissioning
Temporary shutdown
1. Disconnect the electrical connection
at all poles.
2. Drain the tank in areas where it is at
risk from frost and before the
onset of winter.
3. Then also drain all cold water pipes
leading to the heating elements
and to the unit itself as well as all
water-carrying valves, fittings
and lines (even the heating circuit
= register) back as far as the frost proof section of the domestic water
system (domestic water connection).
! ATTENTION
When emptying the tank, hot
water may escape!
! ATTENTION
When placing the tank back into
service, ensure that it is filled with
water and that water which is free
of bubbles is escaping from the
valves!
Permanent decommissioning
Ensure that equipment and components
are disposed of in accordance with local
regulations, e.g. through authorised
disposal and recycling specialists or at
collection points.
REMKO GmbH & Co. KG or your
contractual partner will be pleased to
provide a list of certified firms near you.
6
Care and maintenance
Care
■
Only clean the units with a damp
cloth (adding, for instance, a liquid
household cleaner).
Do not use any sharp, scouring
or solvent-based cleaners.
Maintenance
■
We recommend concluding
a maintenance contract with
a specialist firm, which includes
annual maintenance services.
NOTE
This ensures the operational
reliability of your equipment!
■
Regularly check the function of
the safety valve.
The expansion water amount at maximum
heat (approx. 80°C) represents approx.
3.5% of the tank capacity.
When the safety valve test knob is
lifted or turned to the “Test” position,
the water must flow unhindered out of
the safety valve body into the drainage
funnel.
! ATTENTION
This can cause the cold water
supply and parts of the storage tank
connection fitting to become hot!
If the tank is not heated or when warm
water is removed, no water should be
dripping from the safety valve. If this
does occur, either the pressure in the
water pipe is greater than the permitted
value, or the safety valve is defective.
If the pressure in the water pipe is higher
than permitted, a pressure relief valve
must be used.
Installation instructions
for qualified personnel
General instructions prior to installation
■
Ensure that the area in which the
unit is to be operated is free of frost
and easily accessible for required
maintenance, repairs and even
for the possible replacement of
the unit (e.g. avoid overly narrow
thoroughfares and doorways).
■
When installing the storage tank in
unusual locations, such as in lofts,
residential units with floors that
are sensitive to water, storerooms,
etc. take account of the possibility
of leaking water, and ensure that
a facility is in place to catch the
water, including appropriate drainage
methods.
■
The unit may only be positioned and
operated on level surfaces.
7
REMKO HPS 500, MPS 800, MPS 1000
■
When planning the unit's installation
surface and selecting the installation
location, note the total weight of the
storage tank, including the weight
of the water (the nominal capacity),
in order to ensure that the statics
of the load-bearing surface are not
exceeded.
■
Ensure proper clearance from firing
systems.
■
Make sure that units with enclosures,
which are installed in small, tight
spaces or in suspended ceilings
have the connection block (water
and electric connections and heater
installation) still freely accessible and
that there us no buildup of heat.
■
Leave at least 500mm of space
free for the removal of the heating
flange.
■
Check the contents of the packaging
for completeness and check the
unit for visible transport damage.
Immediately notify your contractual
partner of any deficiencies.
NOTE
Installation may only be performed
by authorised specialists.
Preparation of the hot water must
be in compliance with the latest
applicable standards.
Installation
General Information
■
Do not continually top up the water
level in the storage tank. This will
avoid corrosion damage to the tank.
■
If aggressive water is an issue, please
note that special models of the tank
can be tested (address all queries to
your contractual partner)
■
In hard water areas, connect
a standard descaling device upstream
of the tank.
■
The unit must be assembled on site.
■
For all connecting sockets, ensure
that the thread is fully engaged.
! CAUTION
The storage tank is not suitable for
preparing drinking water!
8
■
It is essential to bleed the storage
tank.
Central heating connection
Before being placed into service,
the heat distribution system must be
flushed in order to remove any soiling
(e.g. scale) from the heating circuit.
You have the option to connect another
heat generator (e.g. a solar-thermal
system) using a fin-tube heat exchanger
(special accessory) in a closed system.
! ATTENTION
However, under no circumstances
may the supply and return lines
be blocked, as otherwise the water
in the register will not have room
to expand and there is a risk of
damage to the heat exchanger!
NOTE
Installation may only be performed
by authorised specialists.
Storage tank with electric booster
heaters (immersion heater elements)
Electric booster heaters (immersion
heater elements) must be equipped
with a safety temperature limiter
which stops heating the storage tank
at a temperature of max. 130°C.
The choice of connection components
(connecting pieces, circulation, safety
valve combination, etc.) must be such
that, in the event of a malfunction of
the temperature control, the connection
components will maintain temperatures
of 130°C, avoiding possible damage.
■
Use one of the 1 1/2" sockets to install
an electric booster heater
(see chapter “Connection examples”).
Connection examples On the MPS
1000, either a solid fuel boiler or rather
one or two immersion heater elements
can be fitted.
■
Please note that the electric
booster heater must not be used as
a permanent heating system.
■
Please note that the inflow restrictor
must first be bent back with a pipe or
similar.
■
It is essential to bleed the storage
tank.
■
A contactor is required for automatic
activation of the electric booster
heater via the heat pump manager.
9
REMKO HPS 500, MPS 800, MPS 1000
Fitting the insulation
To install the insulation, proceed as follows:
1. Open the packaging and lift the
insulation section with the holes in
it, with the matting on the inside,
over the connections. In order to
avoid danger to those under your
supervision (e.g. children suffocating),
all packaging must be disposed of
immediately or else cut up.
2. Engage the section of insulation-with
no holes into the hooked closure
strip of the previously attached
insulation section.
3. Snap the supplied installation strip
cover over the hooked closure strip.
This will prevent the hooked closure
strip from opening during the rest of
the installation process.
4. After attaching the installation strip
cover, the insulation can be sealed
with the second hooked closure strip.
If the insulation consists of three
sections, repeat the two previous
steps.
10
5. Insert the round section of insulation
on top of the tank and fix it in place
by pressing down lightly.
! CAUTION
In order to achieve optimum heat
insulation, there must not be an air
gap between the round section and
the insulation.
6. Position the insulation cover and
attach it properly to the insulation
using the openings in the top of the
hooked strip.
7. Attach the supplied collars to the
connections.
If necessary, bend the clamping
tongues of the collar into the centre.
This ensures that the collars are
properly seated on the pipes and
sockets.
If fitting the collars later on, the
material must be cut through at
the predetermined breaking point
specified for the collars.
11
REMKO HPS 500, MPS 800, MPS 1000
The insulation must not be bent or
pushed in, as this risks damage (stress
whitening). Any stress whitening which
occurs through improper handling can
be carefully removed or minimised with
a hot-air blower.
! CAUTION
Depending on the heating output
of the hot-air blower, it may be
necessary to maintain a minimum
distance between the insulation
and the blower. Naked flames are
prohibited.
Fitting the collars
When fitting the collars, please
note the following steps:
NOTE
During operation, the tank
temperature must not consistently
exceed 110°C.
1. Remove the collars from the
packaging in their delivered
condition.
2. Bend the clamping tongues inwards
at an acute angle.
12
3. Slide the completed collar
centrally on to the socket/pipe.
6. Adjust the O-ring as necessary.
4. Fit the O-ring onto the socket/pipe,
starting from the bottom.
5. Slide the O-ring over the top edge
of the socket or pipe.
7. Attach the completed collar to
the connections.
13
REMKO HPS 500, MPS 800, MPS 1000
Connection example HPS 500
A
Legend
A: Outdoor module
B: Indoor module WKF
C: Storage tank HPS 500
FB: Floor heating cycle
B
WW
FBKKKW
C
AB
A
B
S08
KK: Cooling cycle
KW: Cold water
WW: Warm water
ZK: Circulation
ZK
EFS
A
AB
B
14
Connection example MPS 800 / MPS 1000
B
AB
AB
A
B
A
Legend
A: Outdoor module
B: Indoor module WKF
C: External heatg generator (max. 20 kW)
D: Storage tank MPS 800 or MPS 1000
C
WWKW
FB
D
A
B
S08
S02
ZK
EFS
M
RES
HGM
FB: Floor heating cycle
KW: Cold water
WW: Warm water
ZK: Circulation
15
REMKO HPS 500, MPS 800, MPS 1000
Commissioning
NOTE
Commissioning should only be
performed and documented by
specially trained personnel.
1.
Check all connections, even those
which were sealed at the factory
(flange), for leak-tightness.
2. Then check all pipes for any leaks
and, if necessary, fix them.
3. Test the safety module and valves
for function.
Fitting the flange installation port
Flange ring
Seal
Supporting disc
During the heating process, all expansion
water generated in the internal boiler
must be captured by an appropriate
expansion vessel.
Flange installation port
Depending on the design of your
system, fin-tube heat exchangers may
be attached to the boiler flanges.
■
First tighten the nuts by hand.
■
Then tighten the nuts, in the
sequence specified below, to
a torque of 20 Nm to max. 25 Nm.
16
Flange plate
Unit dimensions and technical data
h
6/4“
Operating
pressure
[bar]
6/4“
Øg
240
exterior
1/2“
6/4“
6/4“
6/4“
6/4“
40°
6/4“
Test
pressure
[bar]
b
a
d
c
Tilt height
[mm]
Weight
[kg]
HPS 500,
Unit type
Nominal
capacity
[l]
6/4“
6/4“
f
i
e
6/4“
6/4“
40°
Flange
bolts, 12x M12.1
Max.
operating
temperature
[°C]
HPS 500 500 95 3 4,5 1670 113
Unit type
a b c d e f g (Ø) h i
Dimensions in mm
HPS 500 220 620 1010 1390 1250 1640 650 340 1725
We reserve the right to modify the dimensions and constructional design as part of the ongoing
technical development process.
17
REMKO HPS 500, MPS 800, MPS 1000
MPS 800/1000
Sensor strips
1694/2050
1430/1710
1230/1470
1030/1250
630/745
500/580
260/
310
Tilt height without insulation: 1750/2090 mm
Diameter with insulation: 990/990 mm
Height with insulation: 1735/2135 mm
6/4" IG
6/4" IG
40°
60°
6/4" IG
6/4" IG
ø 790
6/4" IG
6/4" IG
6/4" IG
1/2" IG
1/2" IG
1/2" IG
ø 240
1/2" IG
40°
6/4" IG
6/4" IG
6/4" IG
6/4" IG
60°
Unit type
Nominal
capacity
[l]
Max.
operating
temperature
[°C]
Operating
pressure
[bar]
Test
pressure
[bar]
Tilt height
[mm]
MPS 800 800 95 3 4,5 1750 157
MPS 1000 1000 95 3 4,5 2090 176
We reserve the right to modify the dimensions and constructional design as part of the ongoing
technical development process.
18
Weight
[kg]
Technical data for the insulation
Description Value
Mass per unit area kg/m
2
1,7
Insulation thickness mm 100
Thermal conductivity λ
(calculated)
Standby energy consumption
W/mK 0,038
See rel. product folder for details
(acc. to EN 60379)
Thermal resistance °C Max. continuous load 110 °C (inside)
Fire class B2 acc. to DIN 4102
Number of parts
2 (or 3), divided outside of the
connection levels
Min. 70% of recycled material in the raw
Environmental compatibility
materials, even the matting itself is
recyclable
Toxicologically harmless Yes
CFC and HCFC-free Yes
Other properties
Good sound insulation, kind to the skin
and safe to allergy sufferers
We reserve the right to modify the dimensions and constructional design as part of the ongoing technical
development process.
19
REMKO INTERNATIONAL
... and right in your own location too!
Benefit from our experience and advice
REMKO GmbH & Co. KG
Air conditioning and heating technology
Im Seelenkamp 12 D-32791 Lage
Postfach 1827 D-32777 Lage
Telephone +49 5232 606-0
Fax +49 52 32 6 06-2 60
e-mail info@remko.de
Website www.remko.de
We reserve the right to make technical changes, and provide no warranty as to the accuracy of this data!
Loading...
