REFCO ENVIRO User Manual

Instruction Manual Recovery Station
ENVIRO
46 84 5 93
Instructi on M an ua l ENVIRO English
OPERATING INSTRUCTIONS
ENVIR O
Table of Contents
2. Safety…………………………………………………………3
2.1 P erson nel Qualif icati ons…… …………… ………3
2.2 Special Hazards………… …… …… …… …… …… 4
2.3 Labels / Safe ty M ar ki ngs…………………… …… 7
3. Technical Specifications…………………………………8
4. Parts Description……………………………………………9
5. Instruction of Operation Panel…………………………10
6. Electrical Diagram…………………………………………1
7. Operation……………………………………………………12
8. Recovery Method…………………………………………14
9. Self-Purge Method…………………………………………16
10. Liquid Push / Pull Mode…………………………………17
11. FAQ and Trouble Shooting……………… ……………20
12. Maintenance………………………………………………22
13. Service……………………………………………………23
14. Recycling………………………………………………… 23
1
English Ins tr uc tion Manual ENV IR O
1. General Inf ormation
Thank you for pur ch as in g the ENVIRO Refrig er an t Recovery Mach in e! ENV IRO combines an innovative refrige rant gas compres­sio n syste m with a rugg ed, mou lde d case that i s desig ned to offer m ax im um pr ot ec tion fr om dama ge during transit and normal hand li ng. With normal use and with care as prescribed in this Manual, you r ENVIRO wi ll give you years of trouble-free operation.
Safety First!
When found on the machine, this inte rnational sym­bol is i nt en ded to a le rt t he u se r to the presence of impor­tant operating, safety and maintenance (servicing) instruc­tions in this Manual. As used in the Manual, it is intended to draw y ou r at te ntion to critical ite ms . It is im po rtant t o r ea d t hi s e nt ir e M an ua l a nd be fa mi li ar with its contents b ef or e us in g the machine!
The ENVIRO is a Recov ery Mach ine for a bro ad range of refrigerants. Recovering refrigerants into a separate stor­age c yl in de r i nv ol ve s a process of g as compr es si on , resulting in high pressures within the mach in e, t he c on­necting hoses and the st orage c ylinder. High-pressure sys tems mus t always be treated with care and respect to pre vent ca re less accidents.
1
Instructi on M an ua l ENVIRO Engl is h
Product Saf et y:
The ENVIRO has been designed to meet the requirements of t he S ta nd ar d fo r Re fr ig er an t Re co very M ac hines, A RI and certificati on . If an ap proved cyli nder wit h overfill is no t available always use an a pp ro ve d sc al e to monit or the cylinders capacit y. Additionally, a pp roved refrigerant hoses must be used which have shut-off d ev ic es w it hi n 30 0mm of t he e nd s to reduce the like li ho od of refrigerant le ak ag e t o the atmo­sphere when chang in g cy li nd ers or setups.
Responsib il it y:
Onl y a qualified technician who has been prop erl y traine d in the ca re an d use of s uc h e quipment and in the recov­ery process itself mu st o nl y op er ate the ENVIRO.
The op er ating in structions are p art of the prod uc t an d must be st ored i n cl os e pr ox imity to t he E NV IRO wh er e they should be read il y ac ce ssible to qualifi ed p er so nnel at all times. The qualif ie d p ersonnel must ha ve car ef ul ly read and understood the operat in g in st ru ctions prior to op erating the device. The manufacturer shall not be liable for any damage whatso­eve r arising through i mproper us e, failure to comply w it h the se opera tin g ins tru ctions, assignment of in ade quately qualified perso nn el , or una ut ho rised modificatio n of the ENVIRO. The General Terms and Co nditions as set out in the sale s documentati on s ha ll apply. Subject to te ch ni ca l modificatio ns .
2
English Ins tr uc tion Manual ENV IR O
Key to symbols
WARNING!
… indic ates a po tentially hazardous si tuation that co ul d result in serious injury or death if not avoide d.
DANGER!
… in di ca te s el ec tr ical h az ar d. Fai lu re to c omply with t he se safet y instruct io ns may re sult i n seri­ous injury or dea th .
2. Safety
WARNING!
Bef ore setup an d operation of the devic e, ensure tha t it i s not damaged in any way. Fa ilure to com­ply co ul d result in s er io us physi ca l injury and/or material dama ge .
DANGER!
Risk of death by el ec tr ocution.
2.1 Personnel Q ua li fications
WARNING!
Risk of injury through use by unqualified personnel! Improper hand li ng o f the device can le ad t o se ri­ous personal an d ma te rial damage.
3
Instructi on M an ua l ENVIRO Engl is h
The activiti es de sc ribed in these o pe ra ti ng instructi on s should only be c ar ri ed out by skill ed pers on ne l in pos­session of the qu al if ications outl in ed b el ow. Kee p unqualifi ed personnel away from ha zar dous areas.
Skilled per so nn el
Skilled personnel are workers who, th ro ug h th ei r sp e­cialist tr ai ning a nd operation al knowledge of t he recov­ery machin e, ar e capable o f carrying ou t the described work and independently identi fy in g po te nt ia l ha zards.
ONLY QUA LIFIED SERV IC E PERSONNEL SHOULD OPERATE THIS UNIT. MOST STATES AN D COUNTRIES, MAY REQUIR E THE USER TO B E LICENSED. PLE AS E CH ECK WITH YO UR L OC AL GOVERNMEN T AGE NCY.
2.2 Special Haz ar ds
Before start in g th e Eq ui pm en t as su re that it is well grou nd ed . Risk of seri ou s in ju ry a nd d ea th !
While us in g th e electric al wire, the wi re must be well connecte d an d gr ounded. Risk of serious i nj ur y and death!
Only a qualified elect ri ci an sh ould perform wire connection ac cording t o the t ec hn ic al stan da rd and circuit dia gr am . Risk of serious i nj ur y and death!
4
English Ins tr uc tion Manual ENV IR O
Be sure t he power is o ff before e xa mi ni ng o r repairing the recovery unit. R isk of s er io us in ­jury and death!
Use onl y authorized ref illable refrige rant tanks. The Unit requ ires the use of recover y tan ks wi th a minimu m wor king pre ssure of 40 bar (580psi ). Do n ot overfill t he recovery tank. Tank is full a t 80% capac it y. T he re should b e enough sp ac e for liquid expansion. Overfilling of the tank may cause a violent explo­sion.
A Charging scale is required to prevent overfilling.
It is compu lso ry t o we ar s afe ty g oggles, and pro­tective gl ov es whi le working wi th refri ge ra nt s to pro tect skin and eyes fro m refrigerant gas and liq­uid. Avo id a ny c on tact with caust ic g as o r liquid. Risk of serious i nj ur y!
Be sure t ha t a ny room w he re work is bei ng co n­ducted is thoro ug hl y ventilated.
When using an extension cord, the cord should be a minimum of 1.5 mm (15 awg) and no longer than
2
7.5 m. Otherwise Volta ge m ay d ro p an d da mage the compres so r! The ca bl e mu st be compl et el y unrolled.
5
Instructi on M an ua l ENVIRO Engl is h
Input pressure of the unit should not exce ed 26 bar (377 psi).
Kee p un it in a horizontal po sit ion only, other wis e unexpected vi br ations, noi se or a br as ions may occur.
Avoid exposing the equipmment to the sun or rain.
USE CAUTION WHEN OPERATION OUTDOORS. Be certain that the power cord, the overfill cylinder safety co rd and th e unit itself are no t pl aced in water or other pote nt ia ll y dangerous locat io ns . While the ENVIRO is very safe to oper at e, u si ng in en vi ro nments such as hard rain o r s an d dust storms must be av oi de d.
FLAMMABLE ENVIRONMENTS ARE DANGEROUS wh en any mach ine is used bec au se moto rs an d sw itc he s c an ge ne rat e s pa rks . Th is eq uip men t s h o u l d b e u s e d i n l o c a t i o n s w i t h m e ch a n i c a l ven tilation provi ding at lea st four air changes p er hour, or the eq uipme nt shou ld be located at leas t 50cm above the fl oo r. DO NOT USE THIS EQUIPMENT IN THE VICIN ITY OF SPILLED OR OPEN CONTAINERS OF GASOLINE OR ANY OTH ER F LA MM ABLE LIQUID.
6
English Ins tr uc tion Manual ENV IR O
Do not block the ve nt il ation opening o f th e un it .
If t he o ve rl oad pr otector pops, repositio n it after 5 minutes.
2.3 Labels / Safe ty M ar kings
Identificat io n pl ate
4684 593 110V, 60H z, 0.55 kW
7
Instructi on M an ua l ENVIRO Engl is h
3. Technica l Specificatio ns
Refrige ra nt
Categor y
Categor y
Categor y
Power
Motor
Motor Spe ed
Current
Compres so r
High Pres su re Protect io n
Recover y Sp eed
Gas
Liquid
Push/Pu ll M ode Ambient
Temperatu re
Dimensi on s
Net Wei ght
R-12, R-1 34 a, R-40 1C , R-406A, R -5 00
R-22, R-4 01 A, R-40 1B , R-402B, R-407C, R -4 07D, R- 40 8A, R-409 A, R-411A , R-411B , R- 412A, R -5 02, R-509
R-402A, R -4 04A, R- 40 7A, R-407 B, R-410A , R-5 07
M5V CA 60 Hz
0.55 kW
1750rpm @6 0Hz
7A@60Hz
Oil-les s, a ir-co ol ed, 1-pis to n
38.5bar /3 850kP a (5 58psi)
Categor y
0.66 lb/m in
4.41 lb/m in
10.14 lb/ mi n
0°C-40° C/ 32-10 4° F
15.7′(L )× 9 (W)× (H).8′ 13.6′
32 lb/14. 5k g
Categor y
0.84 lb/m in
4.85 lb/m in
12.35 lb/ mi n
Categor y
1.10 lb/m in
5.07 lb/m in
13.89 lb/ mi n
8
English Ins tr uc tion Manual ENV IR O
4. Part s Descr iption
Component
No.
Front Panel
1
Solenoid Val ve
2
3
Control Valv e
Copper Pipes
4
Junction Box Co ve r
5
6
Compressor
Running Capac it or
7
9
Component
No.
Starting Capa ci to r
8
9
Fan
Fan Cover
10
Power Supply Co rd
11
Base
12
13
Cover
Instructi on M an ua l ENVIRO Engl is h
5. Inst ruction of Operation Pa nel
INTAK E PORT INL ET FILTER I NCL. O -RIN G FILTE R THRED AD APTE R
10
English Ins tr uc tion Manual ENV IR O
6. Electrica l Diagram
ITEM
11
1
2
3
4
5
6
Graphic s Code
XS
SA
FR
SP1
M1
SV
Descrip ti on
Power Out le t
Power Swi tc hes
Overl oa d Pr otect io n Device
High Pres su re Swit ch gear
Compres so r Motor
Solenoi d Valve
Remarks
Instructi on M an ua l ENVIRO Engl is h
7. Oper ation
1.
Do not mi x different ref rigerants tog ether i n one tan k, or they cannot be se pa ra ted or used.
2.
The switch sh ou ld be at“P os it ion 0”before opera ti on . All the valves must be closed, the input and output fittings sh oul d b e cov ere d w it h p rot ect iv e c aps w hen th e uni t is no t i n o p era t ion . T he ai r m o ist u re is har m ful t o t h e rec overy result and will sho rten the li fe span of the unit .
3.
A filter drier should always be used and should be replaced fr equ ent ly. And ea ch ty p e of re fri ger ant m ust h ave i t s own filter. For the sak e of en surin g the n ormal oper ation of the uni t, please use the filter specified by our company. Hig h quality filter drier wi ll bring hi gh quali ty s er vi ces.
4.
Special caut io n i s n ee de d w hen recoveri ng fr om bu rn t system, and two d ry f il ters are needed .
5.
The unit has an Internal High Press ure Shut-Off Sw itc h. If the pressure ins ide the system is abo ve 38.5 bar, com­pressor will automatica ll y shut off the power. To restart the compressor, plea se lower t he internal p ressure and hit the High Pres su re b utton, then tur n.
When High Pressur e Pr ot ec tion is initiated , pl ea se fi nd out the cause and deal wi th i t be fo re r estarting the unit. Cause of High Pressure Protec ti on a nd Tr ou bl e Sh oot­ing:
12
English Ins tr uc tion Manual ENV IR O
a.
The input value o f th e re frigerant tan k is c lo se d — open the valve to s ol ve t he problem.
b.
The co nn ec ting hos e between t he rec ov er y unit an d refrigerant tank is stu ck — cl os e al l the valve s an d replace the con ne ct ing hose.
c.
The tempera tu re of the ref ri ge ra nt tank is to o hi gh, pressures is too high — give it some time to cool down and the pressur e wi ll c ome back to norma l.
6.
An electric sca le n ee ds to be used toget he r wi th t he re­covery unit to mo ni to r the recover pro ce ss .
7.
In order to gain maxim um re covery spe ed , a hose w it h inner d ia me ter b ig ge r than 4m m is re commended a nd the hose should b e sh or ter than 1.5m.
8.
While recover in g la rge amounts of li qu id , us e the Push/Pull Mod e.
9.
After recove ri ng , m ake sure ther e i s n o r efrigerant l ef t in the unit. Rea d t he Pu rg e Operation c ar ef ul ly. Liqui d refrigerant remaining in the un it may be exp an de d and damage the comp on en ts.
10.
If th e unit is to b e stored or not us ed for an y len gt h of tim e, we recommend t hat it be completely eva cuated of any r es id ua l refri ge ra nt and pu rged wi th dry ni tr og en.
11.
Connection hose with check valve is recommend ed , i t can prevent ref ri ge rant loss.
12.
The in ta ke port is equipped wit h fi lt er screen; p lease wash it frequen tl y to k eep it clean.
13
Instructi on M an ua l ENVIRO Engl is h
13.
If it is diff ic ult to start th e un it , please turn the Swit ch two rounds to balance the intern al pr es su re an d m ak e it easier to star t th e un it.
14.
The Low Pressure Gauge shows the pressure of the intake po r t of the c o mp r es s or an d t he Hi g h Pre ssu r e Gau ge shows the press ur e of t he outlet port.
15.
After Using, pl ea se t urn the knob to "0" p os it io n.
8. Recovery Me thod
1.
Tur n th e Switch to posit io n "1 ".
2.
Correctly and f ir ml y connect the hos es . (See Connecti on D ra wing)
3.
Con nect th e unit to the right power supply (as sho wn on the Name Plate) , tu rn t he power on to star t th e un it .
4.
Open the valve of t he r ef rigerant tank .
14
English Ins tr uc tion Manual ENV IR O
5.
Open the liquid v al ve o n the manifold ga ug e.
6.
Slo wly turn the Switch to position "2" for faste r rec overy.
Notice:
a.
If l iq ui d im pa ct in g oc cu rs in the c om pr essor wh en a t position “2 ”, plea se turn t he knob t o positio n “start” slowly. The reading of low pressure gauge will decr­ease until the impacting stops, but the pressure should uld be above“0”, because the intake port cannot intake when the pr es su re is “0”. If it is difficult to start or restart afte r power off , please turn the kn ob to posit io n “START ”, then tur n on the power and hit the R ES ET button.
b.
If the knob i s tu rne d to position “1” and th e unit it run­nin g, a stable recovery o f liquid refrigerant ca n occur, in the compressor when at position “1”, slowly turn the kno b clockwise to po sit ion “start”. The reading of low pressure gauge will decrease until the impacting stops. The pre ssure s hould be above “0”, because it cannot intake if the pre ss ur e is “0”.
7.
Whe n liq uid recovery is finished, turn the Switch to posi­tion "2" for fa st er r ec overy.
8.
After the low pressure gauge shows zero, start the purge operation.
15
Instructi on M an ua l ENVIRO Engl is h
9. Self-Purg e Method
1.
No ne ed to t urn o ff the power; t urn t he Sw itch to position "3" to start pu rg in g.
2.
Purging ends wh en t he r equired vacuu m is r ea ch ed.
a.
Close the valve o n th e re frigerant tan k.
b.
Close the check v al ve s on the connecti ng h os es .
c.
Close the liqui d va lv e and gas valve on th e ma ni fo ld gauge. Clo se the conn ecting valve between the refrigeration
d.
system and th e ma ni fo ld valve. Tur n th e power off , an d di sconnect all th e ex te rn al
e.
hoses. Cap the intake po rt a nd t he outlet port.
f .
16
English Ins tr uc tion Manual ENV IR O
WARNING!
After each use th e un it m ust be purged, to m ak e sure there is no re fr ig erant left in the u ni t. Remaining liq ui d re frigerant may e xp an d an d damage the comp on en ts.
10. Liquid Pus h / Pull Mode
1.
Tur n th e Switch to posit io n "1 ".
2.
Cor rectly and firmly connect the hoses (Se e Connection Diagram).
3.
Tur n th e power on to start t he u ni t.
When recove ri ng m or e than 10 kgs of liqu id refrigerant , Pu sh /Pull is recomm en de d.
WARNING!
An e le ctric sc ale ne ed s to be used together with the rec overy unit to monitor the recover process . Once the siphon is started, it can overfill the recov­ery tank. The sipho n can continue eve n if the machine is t ur ne d o ff. You must manually close the valves on the tank and the unit to prevent over­filling.
17
Instructi on M an ua l ENVIRO Engl is h
4.
Open the gas valve and liquid valve of the refrigerant tank.
5.
Tur n the Switc h t o position "2 " to star t P us h/Pull Mod e operation rec ov er y.
6.
When th e showing o f electri c scale i s not cha ng in g or changing v er y s lowly, it means that th e liquid re co ve ry is fi ni shed, a nd it 's time for gas r ec ov ery. (T he ho se s need to be re-conne ct ed and plea se foll ow the Purge Operation to pu rg e th e gas refrigera nt .)
7.
Clo se th e gas valve on the refrigerant tank and then turn the power off .
8.
Close all the valves and disconnect all the external hoses. Con nect the hoses according to the Recovery Operation to do the gas refri ge ra nt recovery.
9.
PURGE
18
English Ins tr uc tion Manual ENV IR O
WARNING!
When the re ading on th e electr ic scale sh ow s that the ref ri gerant in the tank reaches 80% capacity, please tu rn the po wer o ff and cl ose the valves on the t an k.
19
Instructi on M an ua l ENVIRO Engl is h
11. FAQ and Tro uble Shooting
Fault
Fan is not revolvi ng
Compres so r doesn’t w or k
Compres so r can’t sta rt (blocke d)
Compres so r start s bu t stops wit hi n a few minutes
Cause Solution
Mechani ca l damag e
1. Shut off by High Press ur e
2. Inte rn al l ine fau lt of the un it
1. Exte rn al p ressu re is too hi gh
2. Moto r fa il ure or other c om po nent damag e
1. High Pre ss ure Prote ct io n cause d by mis- op er ation shuts t he u ni t off , if : Outle t va lv e close d, refri ge ra nt tank valve c lo se d
2. Moto r Ov er load Prote ct io n shuts the mot or o ff
1. Replac e th e fan
2. Fact or y se rvice i s neede d
1. Lower th e pr essur e of the un it -P ress High- pr es sure Butto n to r es et
2. Profes si onal exami na ti on is requi re d- Facor y servi ce i s ne eded
1. Turn th e kn ob aroun d tw ic e and turn to p os it ion "1" , then re st ar t.
2. Fact or y se rvice i s neede d
1. Read car ef ully th e Opera ti on M anual and fol lo w th e instr uc ti ons whi le opera ti ng
2. Give t he m ot or some time to r es ta rt
20
English Ins tr uc tion Manual ENV IR O
Fault
Compres so r start s bu t stops wit hi n a few minutes
Low recover y speed
Not enoug h vacuum
21
Cause Solution
3. Circui t br eaker shut of f
1. Th e pr essure of t he refri ge ra nt tank i s too hig h
2. Piston r in g on the compr es so r is damag ed
1. Hose con ne ction loose ne d
2. Leakag e of t he unit
3. Cool the c ir cuit break er d ow n and resta rt a ft er 5 minut es
1. Coolin g th e tank down ca n he lp t o bring d ow n th e press ur e
2. Fact or y se rvice i s neede d
1. Tighten t he conne ct in g hoses
2. Fact or y se rvice i s neede d
Instructi on M an ua l ENVIRO Engl is h
12. Mai ntenanc e
1.
Your ENVIRO wi ll provide many sea sons of reliable se r­vic e if it is pr operly mainta ine d. Th e actual mai nte nance requirement s ar e mi nimal but impor ta nt .
2.
Keep the unit clean by wiping it down with a damp cloth to remove d irt, o il s, e tc . pr io r to storage for the da y. St an­dard household dete rg en t o r i so pr opyl alcohol may be use d if the un it is par tic ularly dirty; i n all cas es, exercise care t o prev en t liqu id s from entering the u nit. G as oline and other solvents are to be avoided as they can damage the ENVIRO pl as ti c en closure and the y ar e ha za rdous.
3.
Cle an i nlet particle filte r re gul arly. Discard inte rna l filter screen if it is heavil y conta mi na te d a nd repl ac e wit h a new screen. Re place scree n as per sk etch for efficien cy.
4.
Ens ure that the I nle t and Dischar ge p orts are prot ect ed and kept clean by rep lacing the pl ast ic caps after eve ry use. For best results, keep a FILTER p er ma ne ntly c on­nected to the INL ET port and chang e it r eg ularly.
5.
Cha nge HOSES periodi cally as they dev elo p leaks and a build-up of contamin ant s over t ime. Change hoses a t least once per se as on .
6.
Whe n per for mance declines it is li kely that the c omp res­sor seals require repla cing. T his is normal with us e an d may occur after a year or two or more often, de pe nd in g upon the condit io ns t hat are
22
English Ins tr uc tion Manual ENV IR O
pre valent during the recov ery op erations. Contact yo ur Who lesaler for a ssi stance in sel ect ing the pr ope r main­tenance kit.
13. Ser vice
DO NOT CH AN GE any of th e o ri gi nal compon en ts as the safety of the m achine could be c ompromised. All servic e work must be perform ed at a R EF CO ap pr oved facility in order to mainta in t he s afety rating an d th e Warra nt y, if ap­plicable.
14. Rec ycling
For disposal, p le as e bring your reco ve ry m ac hine to an offic ia l re cy cling locatio n.
23
Loading...
