Raymarine ST30 User Manual

ST30 Round Bidata

Owner’s Handbook

Document number: 81075_4 Date: 1st April 2001

Preface

Important information

WARNING

Although your ST30 instrument is designed to give accurate and reliable performance, it should serve only as an aid to navigation and should never lead to the erosion of good seamanship. Always maintain a permanent watch and be aware of situations as they develop.

EMC conformance

All Raymarine equipment and accessories are designed to the best industry standards for use in the leisure marine environment.

The design and manufacture of Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) standards, but correct installation is required to ensure that performance is not compromised.

Handbook information

To the best of our knowledge, the information in this handbook was correct when it went to press. However, the Raymarine policy of continuous product improvement may change product specifications without notice. Consequently, unavoidable differences may occur between the product and the handbook from time to time, for which Raymarine cannot accept liability.

ii ST30 Round Bidata Owner’s Handbook

Preface

Contents

iii

Important information .......................................................... i

WARNING......................................................................... i

EMC conformance ............................................................. i

Handbook information ....................................................... i

Preface.................................................................................. vii

Parts supplied..................................................................... viii

Chapter 1: Operation .............................................................1

1.1 Introduction ................................................................. 1

1.2 Depth key functions .................................................... 2

Water depth ................................................................. 2

Shallow alarm .............................................................. 2

Adjusting shallow depth ........................................ 2

Silencing the shallow alarms ................................. 3

Turning shallow alarm ON and OFF ..................... 3

Offset ........................................................................... 3

Default display ............................................................ 3

Loss of signal .............................................................. 3

1.3 Speed key functions .................................................... 4

Speed ........................................................................... 4

Trip distance ................................................................ 4

Resetting Trip Distance ......................................... 4

Ships log ...................................................................... 4

1.4 LCD illumination ........................................................ 5

Chapter 2: Maintenance and Fault Finding ........................ 7

2.1 Maintenance ................................................................ 7

Servicing and safety .................................................... 7

Cleaning the instrument ............................................... 7

iv ST30 Round Bidata Owner’s Handbook

Condensation ............................................................... 7

Cables .......................................................................... 8

2.2 Fault finding ................................................................ 8

Chapter 3: Installation........................................................... 9

3.1 Introduction ................................................................. 9

EMC installation guidelines ....................................... 9

Suppression ferrites ................................................... 10

Connections to Other Equipment ......................... 10

3.2 Installing the instrument ............................................ 10

3.3 Connecting the power supply direct .......................... 12

3.4 Power via SeaTalk ..................................................... 13

3.5 Adding an independent lighting switch ..................... 13

3.6 Installing the Biducer transducer .............................. 14

Cable connections ..................................................... 14

3.7 Calibration requirement ............................................ 14

Chapter 4: Calibration ......................................................... 15

4.1 Introduction ............................................................... 15

EMC conformance .................................................... 15

4.2 Basic calibration ....................................................... 15

Offset entry ................................................................ 16

Depth units ................................................................ 17

Speed and log units ................................................... 17

Log calibration .......................................................... 17

Procedure ............................................................. 18

Exiting basic calibration ............................................ 18

4.2 Intermediate calibration ............................................ 18

Software version ........................................................ 19

Repeater..................................................................... 19

Saving intermediate calibration ................................. 19

Preface

Exit intermediate calibration without saving ............. 19

Default display .......................................................... 20

4.3 Extended calibration ................................................. 20

Calibration ................................................................. 21

Boat show .................................................................. 21

Depth and speed damping ......................................... 21

Saving extended calibration ...................................... 21

Exit extended calibration without saving .................. 21

Specification ......................................................................... 23

vi ST30 Round Bidata Owner’s Handbook

Preface

vii

Thank you for purchasing a Raymarine product. We are sure your ST30 instrument will give you many years of trouble-free operation.

This instrument is designed to provide reliable performance, even under the most demanding conditions.

depth

speed

bidata

depth

speed

D1601-2

viii ST30 Round Bidata Owner’s Handbook

Parts supplied

bidata

depth

speed

depth speed

ST30 Round Bidata instrument Sealing gasket Display bezel

SeaTalk

(1 black & 1 grey supplied)

Thumb nuts (x2)

Fixing studs (x2)

2 m (6.5 ft) power cable

SeaTalk

Interconnection cable

ST30 Round Bidata

Owner's Handbook

Owner's Handbook Warranty document and fitting template included in Handbook

"C" bracket

Worldwide Distributors

Worldwide Service Centre

Handbook

Biducer

Cue Card

Notes: The items shown are supplied for an ST30 Round Bidata system. If an instrument is purchased separately, a transducer is not included. If any item is not present, contact your Raymarine Dealer. If the ST30 Round Bitata is to be flush mounted, do not fit a display bezel .

D1603-3

Chapter 1: Operation

1.1 Introduction

The ST30 Round Bidata instrument is designed for the powerboat market, and displays speed and depth information simultaneously on a split LCD. The Bidata can also display trip and log distances, sound a user-defined shallow alarm, and function as a repeater.

The instrument can be surface or flush mounted and fits the standard

85.7 mm (3 3/8 inch) diameter facia apertures, common on many sports boats.

The Bidata uses an easy-to-install transom mount transducer (Biducer) combining both speed and depth elements in a single housing.

If the Bidata is used in conjunction with a SeaTalk autopilot, the speed input provided by the instrument enhances the pilot's steering performance.

depth

speed

bidata

depth

speed

D1601-2

The operating procedures are presented as a combination of flow charts and text. Unless otherwise stated, the illustrated key presses are momentary.

The Bidata can display depth and speed information in metric and imperial units. These are set during basic calibration (see Chapter 4, Calibration).

2 ST30 Round Bidata Owner’s Handbook

1.2 Depth key functions

The following flow chart shows the depth key functions.

bidata

depth

speed

depth speed

WATER DEPTH

SHALLOW ALARM

OFFSET

Water depth

Depth is displayed in feet (0 to 400 ft) or metres (0 to 120 m).

Shallow alarm

The shallow alarm displays the depth (feet or metres) at which point audible and visual alarms will be triggered. These alarms can be silenced by pressing the speed or depth key.

Adjusting shallow depth

1. From the shallow depth alarm display, press depth and speed together momentarily to display CAL.

2. Press depth and speed together again momentarily to enter edit mode (+ and - displayed).

3. Press depth to increase and speed to reduce the displayed value.

4. Press and hold depth and speed together for 2 seconds, to exit edit mode and save the new value.

D1763-2
