DS400X &
DS500X
Digital Fishfinders
Owner’s Handbook
Document number: 81234-2
Date: April 2004
Page 2
ii
Page 3
DS400X and DS500X Digital Fishfinders iii
Preface
This handbook describes the Raymarine DS400X and DS500X Digital
Fishfinders.
Conventions Used
Throughout this handbook, the labelled keys are shown in bold capitals; for
example, MENU. The software menu names and options are shown in
normal capitals; for example, AUTOMATIC.
Operating procedures, which may consist of a single key-press or a sequence
of numbered steps, are indicated by a ➤ symbol in the margin.
Technical Accuracy
The technical and graphical information contained in this handbook, to the
best of our knowledge, was correct as it went to press. However, the
Raymarine policy of continuous improvement and updating may change
product specifications without prior notice. As a result, unavoidable
differences between the product and handbook may occur from time to time,
for which liability cannot be accepted by Raymarine.
Warranty
To register your DS400/500X Digital Fishfinder ownership, please take a
few minutes to fill out the warranty registration card found at the end of this
handbook. It is very important that you complete the owner information and
return the card to the factory in order to receive full warranty benefits.
Page 4
iv DS400X and DS500X Digital Fishfinders
Important Information
This handbook contains important information on the installation and
operation of your new equipment. In order to obtain the best results in
operation and performance, please read this handbook thoroughly.
Raymarine’s Product Support representatives, or your authorized dealer, are
available to answer any questions you may have.
Intended Use
Raymarine DS400X and DS500X Digital Fishfinders are intended for
recreational fishfinding.
EMC Conformance
All Raymarine equipment and accessories are designed to the best industry
standards for use in the recreational marine environment.
Their design and manufacture conforms to the appropriate Electromagnetic
Compatibility (EMC) standards, but correct installation is required to ensure
that performance is not compromised. Although every effort has been taken
to ensure that they will perform under all conditions, it is important to
understand what factors could affect the operation of the product.
The guidelines given here describe the conditions for optimum EMC
performance, but it is recognized that it may not be possible to meet all of
these conditions in all situations. To ensure the best possible conditions for
EMC performance within the constraints imposed by any location, always
ensure the maximum separation possible between different items of
electrical equipment.
For optimum EMC performance, it is recommended that wherever
possible:
• Raymarine equipment and cables connected to it are:
• At least 3 ft (1 m) from any equipment transmitting or cables carrying
radio signals, e.g., VHF radios, cables and antennas.
• More than 7 ft (2 m) from the path of a radar beam. A radar beam can normally be assumed to spread 20 degrees above and below the radiating element.
Page 5
DS400X and DS500X Digital Fishfinders v
• Raymarine specified cables are used. Cutting and rejoining these cables
can compromise EMC performance and must be avoided unless doing so
is detailed in the installation manual.
• If a suppression ferrite is attached to a cable, this ferrite should not be
removed. If the ferrite needs to be removed during installation it must be
reassembled in the same position.
Safety Notices
1. PRODUCT INSTALLATION. This equipment must be installed and
operated in accordance with the instructions contained in this handbook.
Failure to do so could result in poor product performance, personal injury
and/or damage to your boat.
2. HIGH VOLTAGE. The display unit, transducer cable, and transducer
contain high voltages. Adjustments require specialized service procedures
and tools only available to qualified service technicians - there are no user
serviceable parts or adjustments.
3. NAVIGATION AID. This unit is only an aid to navigation. Its accuracy
can be affected by many factors, including equipment failure or defects,
environmental conditions, and improper handling or use. It is the user’s
responsibility to exercise common prudence and navigational judgments.
This fishfinder should not be relied upon as a substitute for such prudence
and judgment.
4. ULTRASONIC ENERGY. The transducer transmits high frequency
energy while in use. The unit should be turned off when swimmers or divers
are in close proximity to the transducer. (There is a lack of scientifically
sound standards or guidelines for exposure levels and limits to ultrasound.
This notice is precautionary only.)
WARNING:
Do not disconnect the transducer cable without first powering off the
display unit. Removal of the transducer cable from the DS400/500X
while power is turned on can cause sparks.
Mount unit where it is well ventilated and free from gasoline fumes.
Page 6
vi DS400X and DS500X Digital Fishfinders
Raymarine Products and Services
Raymarine products are supported by a network of Authorized Service
Representatives. Raymarine’s Technical Services representatives or your
local dealer will be available to answer any questions you may have. For
information on Raymarine products and services, contact either of the
following:
United States Raymarine, Incorporated
22 Cotton Road, Unit D
Nashua, New Hampshire
03063-4219 USA
Telephone:1-603-881-5200
1-800-539-5539
Fax: 1-603-864-4756
Europe Raymarine Limited
Anchorage Park
Portsmouth, Hampshire
PO3 5TD England
Telephone: +44 (0) 23 9269 3611
Fax: +44 (0) 23 9269 4642
Or, you may contact us on the World Wide Web at:
www.raymarine.com
© Raymarine Limited 2004
Page 7
vii
Contents
Preface ................................................................................................................... iii
Conventions Used ................................................................................... iii
Technical Accuracy .................................................................................iii
Warranty ..................................................................................................iii
Important Information ........................................................................................iv
Intended Use ............................................................................................ iv
EMC Conformance ................................................................................. iv
Safety Notices ........................................................................................... v
Raymarine Products and Services ...........................................................vi
Chapter 1: Overview ............................................................................................1
1.1 Introduction ...................................................................................... 1
Features ......................................................................................... 2
General .......................................................................................... 3
Transducer .............................................................................. 3
Chapter 2: Installation .........................................................................................5
2.1 Introduction ...................................................................................... 5
2.2 Unpacking and Inspecting the Components ..................................... 5
2.3 Selecting the Equipment Location ................................................... 6
Mounting Location ....................................................................... 6
2.4 Cable Runs ....................................................................................... 7
2.5 Mounting the Fishfinder ................................................................. 10
Bracket Mounting ....................................................................... 10
Console Mounting (optional) ..................................................... 10
2.6 System Connections ....................................................................... 12
DC Power and NMEA Connection ............................................. 12
Transducer Connection ............................................................... 14
Chapter 3: Getting Started ................................................................................15
3.1 Introduction .................................................................................... 15
3.2 Powering on the Fishfinder ............................................................ 15
3.3 Simulator Mode .............................................................................. 15
3.4 LCD Display .................................................................................. 16
3.5 Interpreting the Sounder Image ...................................................... 17
Target Indications ....................................................................... 18
3.6 Keypad Operation .......................................................................... 19
3.7 Using the Variable Range Marker (VRM) ..................................... 20
3.8 Selecting the Display Page .............................................................21
3.9 Menu Operation ............................................................................. 23
Menu Structure ........................................................................... 23
