Cat. No. 17-1101
OWNER’S MANUAL
Please read before using this equipment.
CT-400
Handheld Cellular Phone
17-110 1.fm Page 2 Wednesday, Ju ly 21, 1999 9: 57 AM
FEATURES
Your RadioShack CT-400 Handheld Cellular
Phone combines advanced technology and design
simplicity. To complement its small size and easyto-use design, the CT-400 provides a full range of
features.
Easy-to-Read Digital Display
— the supertwist
liquid-crystal display provides essential call information and can be easily read from almost any angle.
Specia l Ce llu lar Ser vic e Fe atur es
— the phone is
preprogrammed to work with special (subscriptiononly) messaging services offered by many cellular
carriers, incl uding calling line ID and voice mail notification.
One-Touch Dialing Memory
— lets you dial an
important number at the touch of a single button.
Memory Dialing
— lets you store up to 40 phone
numbers and names in memory, and dial any
stored number by simply entering its one- or twodigit memory number (1–40).
Call Register Lists
— let you quickly review and
redial any of the last 10 numbers that you called,
and (if you subscribe to the appropriate cellular
services) the numbers for any of the last 10 calls
you missed or received.
Keyguard
— helps prevent accidental key presses
when the phone is in a pocket or bag, for example.
©
1997 Tandy Corporation.
RadioShack is a registered trademark used by Tandy Corporation.
All Rights Reserved.
2
17-110 1.fm Page 3 Wednesday, Ju ly 21, 1999 9: 57 AM
Security Features — to prevent unauthorized
phone use, you can set up to three different levels
of call restrictions (to allow only incoming calls, for
example) while still allowing calls to the preprogrammed emergency number.
One-Touch Emergency Dialing — lets you dial
the emergency number preprogrammed into your
WXYZ
phone, by briefly holding down the key.
9
Scratchpad Memory — lets you temporarily store
a number (during a call, for example), then easily
dial it or store it in memory.
Ample Talk and Standby Time — the supplied
battery (fully charged) provides about 1 hour, 40
minutes of talk time or 21 hours of standby time.
Silent Service — lets you set the phone to quietly
beep instead of ring when it receives a call, to
avoid disturbing others.
Call Timers — let you keep track of the individual
and cumulative call times (air-time), and includes a
timer that you can reset at any time.
Two Phone Number Capability — lets you use
this one phone with two different cellular services,
with a different phon e num ber from each.
We recomme nd yo u recor d your phon e’s Ele ctron ic Se rial Number (ESN) here. The number is on the handset
under the battery.
3
17-110 1.fm Page 4 Wednesday, Ju ly 21, 1999 9: 57 AM
CONTENTS
A Look at the Display ................. .. ............ ......... 6
Preparation ........................................................ 8
Installing the Battery ..................................... 8
Important Battery Tips .................................. 8
Charging the Battery .................................. 10
When to Recharge the Battery ........... . 11
Discharging Batteries ................................. 12
Basic Operation ............................................... 13
Turning the Phone On/Off .......................... 13
Making a Call ............................................. 13
Signal Strength .............. .. ............ ....... 14
Receiving a Call ......................................... 15
Adjusting the Volume ................................. 16
Making Emergency Calls ........................... 16
Last 10 Number Redial .............................. 18
Menu Overview ................................................ 19
Security Features ............................................ 21
Selecting a Call Restriction Level ............... 21
Turning One-Touch Emergency
Dialing On/Off ............................................. 23
Turn ing Keyguard On/Off ............. .. ............ 24
Cellular Systems ............................................. 25
Selecting the Active Phone Number .......... 25
Setting the Cellular System Type ............... 26
Roaming ..................................................... 28
SID Screening ............................................ 29
Special Phone Services ............................. 31
Calling Line ID .................................... 31
Message Waiting ......... .. .......... .. ......... 31
Other Services .................................... 32
Special Features .............................................. 33
Call Timers ................................................. 33
4
17-110 1.fm Page 5 Wednesday, Ju ly 21, 1999 9: 57 AM
Backlight Control ........................................ 34
Keypad Tones ............................................ 35
Ring Volum e ......... .. .. ........ .. ... ....... .. ... ....... . 36
Ring Type . ........ .. ... ....... .. ... ....... .. ... ............. 37
Changing the Lock Code ........................... 37
Using the Call Register .............................. 39
Clearing the Call Lists ......................... 40
Using Calling Card Dialing ......................... 41
Storing/Clearing a Calling
Card Nu m b er ........ .. ... ....... .. ... ....... ... .. . 41
Using a Stored Calling
Card Nu m b er ........ .. ... ....... .. ... ....... ... .. . 43
Using Touch-Tone Services ................... .. .. 44
Adding a Pause .................................. 45
Adding a Wait ..................................... 45
PIN Code Dialing ....................................... 46
Memory Features ............................................ 48
Storing a Number and Name in Memory ... 48
Using Number Quick Store ................. 51
One-Touch/Speed Dialing .............. ............ 51
Memor y S cr o lling .... ....... ... .. ....... ... .. ........ .. . 52
Clearing a Memory ..................................... 52
Using Scratchpad Memory ........ ................. 54
Accessories ..................................................... 55
Safety Information ........................................... 56
Traffic Safe ty ...... ... ..................... ... .. ........ .. . 56
Operating Environment .............................. 56
Emergency Calls ........................................ 58
FCC Regulations ........................................ 58
Troubleshooting .............................................. 59
Care and M a in t en a n c e . ....... ... .. ....... ... .. ........... 60
Spec ific ation s ... ..... .. ..... ..... ..... .. ..... ..... .. ..... ..... . 61
5
17-110 1.fm Page 6 Wednesday, Ju ly 21, 1999 9: 57 AM
A LOOK AT THE DISPLAY
AB
ABC
MENU
Indicates t he type of network selected:
........ ............ A system only
A
........ ............ B system only
B
.................. Both systems
AB
No Indicator
..... Home area only
See “Setting the Cellular System
Type” on Page 26.
Appears when you have a message
waiting in your voice mailbox.
See “Message Waiting” on Page 31.
C
B
Appears when you press to enter
A
letters .
See “Storing a Number and Name in
Memory” on Page 48.
Appears when you press to select
MENU
a menu function.
See “Menu Overview” on Page 19.
Indicates the number of a selected
menu function or memory.
See “Menu Overview” on Page 19 or
“Memory Features” on Page 48.
6
17-110 1.fm Page 7 Wednesday, Ju ly 21, 1999 9: 57 AM
ON
ROAM
IN USE
NO SVC
Appears when the phone is on.
See “Turning the Phone On/Off” on
Page 13.
Appears when you roam using your
home system. Flashes when you roam
using a non-home system.
See “Roaming” on Page 28.
Appears during a call.
See “Making a Call” on Page 13 or
“Receiving a Call” on Page 15.
Appears when you are not within a
supported cell ular service area.
See “Setting the Cellular System
Type” on Page 26.
NO
flashes when SID screening is set
to on and service is not available (see
“SID Screening” on Page 29).
Indicates the cellular signal strength.
The higher the bar, the stronger the
signal.
See “Signal Strength” on Page 14.
Indicates the battery charge level. The
higher the bar, the more charge left in
the battery.
See “When to Recharge the Battery”
on Page 11.
7
17-110 1.fm Page 8 Wednesday, Ju ly 21, 1999 9: 57 AM
PREPARATION
INSTALLING THE BATTERY
To install the battery, place
it flat against the back of
the phone with the tab facing up and toward the top
of the phone. Then slide
the battery toward the top
of the phone until it snaps
into place .
To remove the battery, be sure the phone is turned
off, then hold down the tab, slide the battery down,
and lift it off the phone.
Tab
IMPORTANT BATTERY TIPS
• You must fully charge a new battery at least 24
hours before you firs t use it. See “Charging the
Battery” on Page 10.
• Use only the supplied charger and use only
batteries recommended for this phone.
• A new battery’s full performance is achieved
only after two or three complete charge and
discharge cycles.
• When you are not using the charger, disconnect it from power. Do not leave the charger
connected for more than a week, since overcharging coul d shorten the battery’s life.
• If left unused, a fully charged battery discharges itself in about a week.
8
17-110 1.fm Page 9 Wednesday, Ju ly 21, 1999 9: 57 AM
• When the battery is not in use, store it uncharged in a cool and dark place.
• The battery is a sealed unit with no serviceable parts. Do not try to open the case.
• You can purchase additional standard or extended capacity batteries through your local
RadioShack store.
• A battery can be charged and discharged hundreds of times, but it eventually wears out.
When the operating time (talk time and standby time) is noticeably shorter than normal, it is
time to get a new battery.
• Leaving the batt ery in a hot or cold place, such
as in a closed car in the summer or winter, reduces the battery’s capacity and life. Always
try to keep the battery between 59° and 77°F
(15° and 25°C). A phone with a battery that is
too hot or too cold might not work, even when
the battery is ful ly charged, until the battery returns to a normal temperature. Nickel metal
hydride (NiMH) batteries are particularly limited in temperatures below 14°F (–10°C).
• Use the battery only for its intended purpose.
• Never use any charger or battery that is damaged or worn out.
9
17-110 1.fm Page 10 Wednesday, J uly 21, 1999 9: 57 AM
• Do not short circuit the battery. Accidental
short circuiting can occur when a metal object
(coin, paper clip, pen, or similar) directly connects the battery’s + and – terminals (the metal strips on the back of the battery), such as
when you carry a spare battery in your pocket
or purse. Short circuiting the terminals might
damage the battery or the object connected to
it.
• Do not dispose of batteries in a fire!
Nickel Cadmium and Nickel Metal
Hydride batteries must be recycled
NiCd
NiMH
or disposed of properly. They must
not be disposed of in municipal
waste.
CHARGING THE BATTERY
Once you install the battery on the phone, follow
these steps to charge the battery using the supplied charger .
1. Insert the charger’s
barrel plug into the
jack on the bottom of
the phone.
2. Connect the charger’s AC plug to a standard
AC outlet. The phone beeps and its battery
charge bar appears and begins to scroll.
10
17-110 1.fm Page 11 Wednesday, J uly 21, 1999 9: 57 AM
Notes:
• You can use your phone during charging,
but charging takes longer.
• For the fastest charging, be sure the phone
is turned off, if you are not expecting a call.
• If the battery is too hot or cold, charging
stops until the battery temperature returns
to normal.
3. The battery charge bar stops scrolling when
the battery is fully charged. Disconnect the
charger from the AC outlet first, then disconnect it from the phone.
Using the supplied battery (fully charged), you
have about 1 hour, 40 minutes of talk time or 21
hours of standby ti m e.
When to Re ch arge the Battery
Your phone displays the battery charge bar whenever the phone is on to keep you informed about
the battery’s power level. The higher the bar, the
more power left in the battery.
11
17-110 1.fm Page 12 Wednesday, J uly 21, 1999 9: 57 AM
You can recharge the battery (as described in
“Charging the Battery” on Page 10) at any time.
However, when your phone gives you these lowbattery i ndications, r echarge the battery as soon as
possible:
• When only a few minutes of talk time remain,
the phone sounds a warning tone and displays
BATTERY LOW
• When the battery charge level is too low for
the phone to operate, the phone displays
CHARGE
tone. The phone automatically turns off about
10 seconds later.
at regular interva ls.
BATTERY
RE-
and sounds a warning
Note: The phone does
ing tones if silent service is set to ON (see “Ring
Type” on Page37).
not
sound low batt ery warn-
DISCHARGING BATTERIES
Rechargeable batteries last longer and perform
better if occasionally allowed to fully discharge.
You can do this by leaving the phone on until the
phone automatically turns off or you can use the
battery discharge feature of any approved accessory available for your phone.
Do not try to discharge the battery by any other
means.
12
17-110 1.fm Page 13 Wednesday, J uly 21, 1999 9: 57 AM
BASIC OPERATION
TURNING THE PHONE ON/OFF
Note:
Extend the antenna fully. Avoid touching the
antenna with the phone turned on.
The phone must be turned on before you ca n m ake
or answer calls. To turn on the phone, hold down
P
W
R
(above and to the upper right of the display) until the phone beeps. The phone performs a short
self-test , then it briefly displays the activated phone
number (see “Selecting the Active Phone Number”
on Page 25). The phone is ready to use when the
signal streng th and bat tery charge bars appear.
P
W
To turn off the phone, hold down until the
phone beeps.
MAKING A CALL
R
1. Use the number keys to enter the phone number you want to dial. Include the area code, if
necessary.
Note:
If you make a mistake, repeatedly press
CLR
to delete digits one at a time, or hold down
CLR
to clear all digits.
2. Press to dial the phone number. The
phone displays
SEND
IN USE
and the phone num-
ber you dialed.
13
17-110 1.fm Page 14 Wednesday, J uly 21, 1999 9: 57 AM
Notes:
•
PIN CALL
appears if PIN code dialing is
set to ON (see “PIN Code Dialing” on
Page 46).
NO SVC
• (no service) appears and three
beeps sound if you are outside the cellular
service area. See “Signal Strength.”
•
NOT ALLOWED
briefly appears if you try to
make a restricted call (see “Selecting a Call
Restriction Level” on Page 21).
3. To end the call, press .
END
Signal Strength
The vertical bar on the left of the display
shows the strength of the cellular signal
your phone is receiving. The higher the
bar, the stronger the signal.
If the signal strength is low, try movi ng to
a different location. If you are using the
phone in a building, try moving closer to
a window.
NO SVC
If appears, the phone is outside the cellular service area. This means you cannot make or
receive calls until you move the phone back inside
the cellular service area.
14
17-110 1.fm Page 15 Wednesday, J uly 21, 1999 9: 57 AM
RECEIVING A CALL
When the phone receives an incoming call, it rings
and flashes
except .
P
W
R
Notes:
• After the first ring, if you subscribe to calling
line ID service through your cellular carrier
(see “Calling Line ID” on Page 31), the phone
automatically displays the calling party’s
phone number. T he phone will also display the
caller’s name if the name and number are programmed into your phone (see “Storing a
Number and Name in Memory” on Page 48) .
• If you selected silent service (see “Ring Volume” on Page 36), the phone does not ring.
Instead, the keypad and display backlights
flash,
information appears), and the phone beeps
once.
• If keyguard is set to ON (see “Turning Keyguard On/Off” on Page 24), you can answer a
call only by pressing .
. To answer a call, press any key
CALL
flashes on the display (or caller
CALL
SEND
To end the call, press . To clear calling line ID
information from the display (if any), press .
END
CLR
15
17-110 1.fm Page 16 Wednesday, J uly 21, 1999 9: 57 AM
If you do not answer a call
CALLS
MISSED
(where NN is the number of calls)
until you press any key (except ). It also stores
, the phone displays
P
W
R
NN
the caller’s number (if available) in the missed call
register. See “Using the Call Register” on Page 39.
Hint: To quickly store the displayed caller’s number (if available) into the first empty speed-dial
memory, hold down for about 2 seconds (see
OK
“Using Number Quick Store ” on Page 51).
ADJUSTING THE VOLUME
To increase or decrease the earpiece volume during a call, press (to increase) or (to decrease).
The phone displays
VOLUME
and a horizontal bar indicating the volume level. The
more filled bar segments, the
higher the volume.
MAKING EMERGENCY CALLS
The primary local emergency number (such as
911) is programmed into your phone at the time of
activation. To prevent unwanted emergency calls,
however, your phone’s one-touch emergency dialing feature is preset to OFF. To set it to ON, see
“Turning One-Touch Emergency Diali ng O n/Off” on
Page 23.
16
17-110 1.fm Page 17 Wednesday, J uly 21, 1999 9: 57 AM
To quickly dial the emergency number
WXYZ
9
until t he phone displays
EMERG. CALL TRY
, hold down
Notes:
• The emergency nu mb er programmed i nto your
phone might not be valid in all areas. (For example, not all areas have 911 service.) If you
use the phone outside its primary ser vice ar ea,
you might have to manually dial an em ergency
number if it is different from the one programmed into your phone.
• One-touch emergency dialing does not operate if keyguard is t urned on (see “Turning Keyguard On/Off” on Page 24) or if one-touch
emergency dialing is turned off.
Important: When you make an emergency call,
give your name and cell ular phone number, as well
as the locati on of the incident. Remem ber that your
phone might be the only means of communication
at the accident scene. Do not end the call until you
are advised you may do so.
.
17
17-110 1.fm Page 18 Wednesday, J uly 21, 1999 9: 57 AM
LAST 10 NUMBER REDIAL
Follow these steps to view and dial the last 10
phone numbers called.
1. Hold down to clear the display (if necessary).
2. Press . The phone displays the last number dialed.
3. To scroll through the last 10 numbers dialed,
repeatedly press or . As you press
the key, the phone displays the phone number
and its corresponding redial memory number
(
L0–L9
Note:
ry, the phone briefly displays
EMPTY
4. To dial a displayed number, press again.
CLR
SEND
).
If no number is stored in a redial memo-
LOCATION
.
SEND
Hint:
To quickly store one of the last 10 numbers
you dialed into the first empty speed-dial memory,
recall that number, then hold down for about 2
OK
seconds (see “Using Number Quick Store” on
Page 51).
18
17-110 1.fm Page 19 Wednesday, J uly 21, 1999 9: 57 AM
MENU OVERVIEW
This section lists your phone’s menu functions, the
shortcut keys (if any) you can use to access the
functions, and the pages in this manual where you
can find full descriptions of the fu nctions.
To select a specific men u funct ion
, press that func-
tion’s shortcut keys (if any).
To scroll forward or backward through all menu
functions
, press then (forward) or
(backward). Press to select a displayed func-
MENU
OK
tion.
You See Shortcut/Description
MENU
1
STORE TO
MEMORY
FIND
NAME
ERASE
NAME
RESTRICT
CALLS
SYSTEM
SELECT
CALL
TIMERS
Stores names and phone
numbers
MENU
ABC
2
Recalls names and phone
numbers
MENU
DEF
3
Erases names and phone
numbers
MENU
GHI
4
Sets a call restriction level
MENU
JKL
5
Selects cellular system
type
MENU
MNO
6
Displays the le ngth of calls
and reset s the timers
See
Pg.
48
52
52
21
26
33
19
17-110 1.fm Page 20 Wednesday, J uly 21, 1999 9: 57 AM
You See Shortcut/Description
MENU
PQRS
7
LIGHTS
Sets the display and keypad backl ights
MENU
TUV
8
KEYPAD
TONES
RINGING
VOLUME
RINGING
Turns keypad tones on/off
MENU
WXYZ
9
Selects t he ring volume
Selects the ring type 37
TYPE
EMERGENCY
KEY 9
NAM SELECT
CALLING
CARD
CHANGE
LOCKCODE
SID SCREEN
CALL
REGISTER
KEYGUARD
Turns emer g e nc y onetouch dialing on/off
Displays and selects the
active c ellular number
Selects and activates the
calling card option
Changes the 4-digit lock
code
Turns SID screening
on/off
Show s mi ssed, r ec ei v ed,
and dialed call lists
MENU
Turns keyguard on/off
See
Pg.
34
35
36
23
25
41
37
29
39
24
20
17-110 1.fm Page 21 Wednesday, J uly 21, 1999 9: 57 AM
SECURITY FEATURES
SELECTING A CALL
RESTRICTION LEVEL
Your phone is preset to let you (or anyone else)
dial any typ e of number (local or long distance) and
freely access any inf ormation stored in its memory.
To prevent unauthorized use of your phone, however, you can enter your 4-digit lock code (see
“Changing the Lock Code” on Page 37) and set
any of these varying levels of call restrictions.
Restriction
Level
ALLOW
ALL
INCOMING
ONL Y
MEMORY
ONL Y
Description
No restrictions (default setti ng).
All incoming calls can be answered. Outgoing calls are restricted to the preprogrammed
emergency number and whatever
number you stored in Memory 40.
The memory cannot be acc essed
or changed.
All incoming calls can be
answered. Outgoing calls are
restricted to numbers stored in
memory (includi ng the preprogrammed emergency number). The memory cannot be
changed.
21
17-110 1.fm Page 22 Wednesday, J uly 21, 1999 9: 57 AM
Important: You can dial the pre-programmed
emergency number and the number stored in
Memory 40
regardless
of which cal l restricti on level
you select.
Follow the se steps to select a cal l restriction level.
MENU
GHI
1. Press . The phone displays the cur-
4
rent setting.
2. Repeatedly press or until you see
the setting you want to use, then press to
OK
select that setting.
The phone prompts you for your 4-digit lock
code (
LOCKCODE?
3. Enter your lock code, then press .
).
OK
Note: If you enter the wrong lock code, the
phone displays
CODE ERROR
. Start again at
Step 1 and enter the correct code.
If you select ed any setting except ALLOW ALL, the
phone briefly displays
NOT ALLOWED
when any-
one tries to use a restr icted feature.
22
17-110 1.fm Page 23 Wednesday, J uly 21, 1999 9: 57 AM
TURNING ONE-TOUCH
EMERGENCY DIALING ON/OFF
One-touch emergency dialing lets you call the primary emergency number programmed into your
WXYZ
phone, by holding down for about 2 seconds.
One-touch emergency dialing is preset to OFF. To
turn it on or back off at any tim e, follow these steps.
1. Press then repeatedly press or
MENU
until the ph one displays
2. Press . The phone displays
OK
if one-touch emergency dialing is ON, or
EMERG. 9 OFF
3. P ress or to sele ct t he
then press to store your selection.
OK
9
EMERGENCY KEY 9
if it is O F F.
EMERG.9 ON
other setting
.
,
23
17-110 1.fm Page 24 Wednesday, J uly 21, 1999 9: 57 AM
TURNING KEYGUARD ON/OFF
You can use keyguard to disable the phone’s keypad and prevent accidental key presses (when the
phone is in a purse or pocket, for example).
To turn on keyguard
END
for about 2 seconds (this is handy when you
, press or hold down
MENU
are ending a call, for exam ple).
When keyguard is on:
• The phone displays
KEYGUARD ACTIVE
til you press a key .
• When you press any key, the phone displays
PRESS MENU
to prompt you to turn off key-
guard.
• To answer a call, you must press . During
SEND
the call, key guard automatically turns off.
• When you press to end a call, keyguard
END
automatically turns back on.
• You cannot turn of f the phone.
• You cannot use one-touch emergency dialing.
However, you can manually dial the emergency number programmed into your phone (911,
for example) and press t o place the call.
SEND
The phone does not display any digit until you
have entered the ent ire number .
To turn off keyguard
plays
NOW PRESS
ly displays
KEYGUARD OFF
, press . The phone dis-
. Press . The phone brief-
MENU
.
un-
24
17-110 1.fm Page 25 Wednesday, J uly 21, 1999 9: 57 AM
CELLULAR SYSTEMS
SELECTING THE ACTIVE
PHONE NUMBER
Every cellular telephone has at least one NAM
(Number Assignment Module), which is used to
store its phone number.
Your phone has two NAMs. If you subscribe to two
cellular services (for example, competitive cellular
systems in your area or cel lula r system s in diff erent
cities), each of your phone’s NAMs was programmed with a different phon e num ber at the time
of activation.
If your phone is programmed with two different
numbers, follow these steps to select the active
number (the number you want to use to make and
receive calls).
1. Press , then repeatedly press or
2. Press . The phone displays the active
3. Press or to select the other number
MENU
until the phone displays
OK
NAM SELECT
phone number.
then press to store your selection.
OK
.
,
Notes:
• Yo u cannot change th e active number during a
call. If you try to, the phone displays
PROGRESS
and exits the menu.
CALL IN
25
17-110 1.fm Page 26 Wednesday, J uly 21, 1999 9: 57 AM
• If you want to receive calls on both num bers at
the same time
warding through your cellular service providers, you can set both numbers on your phone
to forward to the other number if not answered. Contact your cellular service providers for details.
and
you subscribe to call for-
SETTING THE CELLULAR
SYSTEM TYPE
Every cellular market area has two cellular service
providers. One of the providers is designated
vider A
and the other
Your phone is activated to operate based on your
cellular service provider’s designation (A or B). If
you travel to a city where you do not subscribe to
cellular service, however, you can select any of
these system settings on your phone (based on
how you want the phone to operate in that city).
Provider B
.
Pro-
Notes:
• Using the phone in a city where you do not
subscribe to a cellular service is referred to as
roaming
• The designation (A or B) that appears with the
setting is based on the selected phone number’s NAM.
26
. See “Roaming” on Page 28.
17-110 1.fm Page 27 Wednesday, J uly 21, 1999 9: 57 AM
• Usually, it is less expensive to use the same
provider type for cellular service when you are
in your home city and when you roam. To do
this, you need to know whether your cellular
service provider is type A or B in your home
city and in each city where you plan to travel.
• It is possible for a cellular service provider to
be (or have agreements with) Provider A in
some cities and Provider B in others.
HOME TYPE (A or B) — Use this setting if you are
roaming and your home cit y cellular service provider is the same provider type as in the city you have
travelled to (for example, if the company is Provider A in both cities).
NON-HOME TYPE (A or B) — Use this setting if
you are roaming and your home city cellular service provider is the opposite provider type from the
city you have travelled to (for example, the company is Provi der A in your home city a nd Provider B in
the other city).
HOME AREA — Use this setting if yo u do not want
to roam (you can only use the phone within the
area covered by your home cellular service provider).
BOTH SYSTEMS — Use this setting if you want
the phone to use
either
Provider A or Provider B.
The phone uses its home type system when possible and the non-home type system when service is
not available on its home type system.
27
17-110 1.fm Page 28 Wednesday, J uly 21, 1999 9: 57 AM
Follow these steps to set the cellular system type.
MENU
JKL
1. Press . The phone displays the cur-
5
rent setting.
2. Repeatedly press or until you see the
setting yo u want to use, then press to store
OK
that setting.
ROAMING
Using the phone in a city where you do not subscribe to a cellular service is referred to as
ing
. When you ro am , turns on steadily if the
ROAM
phone is using its home type system, and flashes
when it is using a cellular system that is different
from your home type system (non-home type system).
In some areas, the cellular system’s computer automatically recognizes roaming telephones. In other areas, you must contact the service provider
before it can recognize your phone. The operator
needs to know your telephone number, your
phone’s ESN (Electronic Serial Number), and how
you plan to pay for your calls. There is normally an
additional charge for roaming calls.
roam-
Note:
Your phone’s ESN is under the phone’s battery. (However, the roaming cellular service providers can usually automatically determine your
phone’s ESN when you call.)
28
NO SVC
17-110 1.fm Page 29 Wednesday, J uly 21, 1999 9: 57 AM
SID SCREENING
If two different cellular market areas are located
close to one another, a call designated for t he A (or
B) carrier in one market can sometimes be placed
using the A (or B) carrier located in the other market area. This can result in unwanted roaming and
higher charges.
At the time of activat ion, a code i s programmed i nto
your phone that uniquely identifies your cellular
carrier. To prevent unwanted roaming, your
phone’s System IDentity (SID) screening feature
lets you set your phone to look for your designated
carrier’s code signal each time you place a call, so
the calls you place use
Notes:
• If SID screening is set to ON and the phone
cannot locate your designated carrier’s code
signal, only emergency calls to the emergency
number programmed into your phone can go
through. Other calls will not go through, and
the phone will not roam. appears
NO
(with flashing).
• When SID screening is set to OFF, your phone
automatically roams according to the selected
cellular system type (see “Setting the Cellular
System T ype” on Page 26).
only
your carr ier.
29
17-110 1.fm Page 30 Wednesday, J uly 21, 1999 9: 57 AM
Follow these steps to turn SID screening on or off.
1. Press , then repeatedly press or
2. Press . The phone displays the current set-
MENU
until the phone displays
OK
ting (
SID SCRN ON
Note:
If no SID information has been pro-
SID SCREEN
or
SID SCRN OFF
.
).
grammed into your phone, the message
ALLOWED
appears and the phone exits the
NOT
menu.
3. Press or to select the other setting
then press to store your selection.
OK
The phone prompts you for your 4-digit lock
code (
LOCKCODE?
4. Enter your lock code, then press .
Note:
If you enter the wrong lock code, the
phone displays
).
CODE ERROR
OK
. Start again at
Step 1 and enter the correct code.
,
30
OK
17-110 1.fm Page 31 Wednesday, J uly 21, 1999 9: 57 AM
SPECIAL PHONE SERVICES
Calling Line ID
If you subscribe to calling line identification service
with your cellular carrier, your phone is preset to
automatically display the caller’s phone number (if
available) each time it receives a call. If you stored
the caller’s phone number with a name in the
phone’s memory (see “Storing a Number and
Name in Memory” on Page 48), that stored name
appears.
Hint:
To quickly store the displayed caller’s number into the first empty speed-dial memory, display
the record then hold down for about 2 seconds
(see “Using Number Quick Store” on Page 51).
Message Waiting
If you subscribe to voice mail service with your cellular carrier, calls you do not answer are sent to
your vo ice mailbox . A voice ma ilbox is somew hat
like an answering machine, because you must call
it and enter a password or personal identification
code to listen to your messages. (For information
about using your voice mailbox, contact your cellular carrier.)
31
17-110 1.fm Page 32 Wednesday, J uly 21, 1999 9: 57 AM
When your phone is turned on and receives voice
mail notification from your cellular carrier, it displays to notify you that you have one or more
messages waiting in your mailbox. When you call
your mailbox and listen to your message(s),
disappears.
Hint: If you subscribe to voice mail service, you
can store the number you call to reach your mailbox in your phone’s one-touch dial lo cation (Memory 1) for easy access. See “Storing a Number and
Name in Memory” on Page 48.
Other Se rv i ces
Your cellular service provider might offer other special options that let you receive or make a second
call or conference two calls together using your
phone’s key.
SEND
Contact your cellular carrier for details about these
special serv ices or billing.
32
17-110 1.fm Page 33 Wednesday, J uly 21, 1999 9: 57 AM
SPECIAL FEATURES
CALL TIMERS
Your phone has four call timers that let you check
the length of your calls in minutes and seconds (for
example, 12345:12 equals 12,345 minutes and 12
seconds). You can view the timers at any time
(even during a call), and you can reset all the call
timers (except one).
Note:
The actual time invoic ed for cal ls by your cellular service provider might vary from the time
shown on your phone, depending on network features, rounding-off for billing, and so on.
Follow these steps to view or reset the timers.
MENU
MNO
1. Press .
2. Press or to scroll through the timer
displays.
LAST
rent call.
TOTAL 1
have made on the active phone number (not
including the call in progress, if any).
TOTAL 2 —
have made on the phone number that is
active.
LIFE
calls you have made using both of your phone
numbers (cannot be reset).
6
— Shows the length of the last or cur-
— Shows the length of all calls you
Shows the length of all calls you
not
— Shows the combined length of all
33
17-110 1.fm Page 34 Wednesday, J uly 21, 1999 9: 57 AM
CLEAR TIMERS
— Rese ts all c all tim ers ex-
cept for LIFE.
3. To clear the timers, press when the phone
displays
CLEAR TIMERS
OK
. The phone
prompts you to enter your 4-digit lock code
(
LOCKCODE?
press . The phone briefly displays
CLEARED
). Enter your lock code and
OK
TIMERS
to confirm that the timers have
been reset.
To exit the timer display
timers , pr e ss .
CLR
without
clearing the
BACKLIGHT CONTROL
Your phone is preset to turn on its di splay and keypad backlight s each time you press a key , then tur n
them off within about 15 seconds after the last keypress.
To set the phone so the backlights do not turn on
(to conserve battery power, for example), or to set
them to turn on again, fol low these steps.
MENU
PQRS
1. Press . The phone displays the current setting (
2. Press or to select the other setting.
3. Press to store your selection.
7
LIGHTS ON
OK
or
LIGHTS OFF
).
34
17-110 1.fm Page 35 Wednesday, J uly 21, 1999 9: 57 AM
When you select the sett ing LIGHTS ON:
• and the phone is used as a portable phone or
connected to a charger, the lights turn on for
15 seconds when you press a key or receive a
call.
• and the phone is connect ed to a handsfree car
kit, the lights remain on continuously.
When you select the sett ing LIGHTS OFF:
• and the phone is used as a portable phone or
connected to a charger, the lights do not turn
on at all.
• and the phone is connect ed to a handsfree car
kit, the lights turn on for 15 seconds when you
press a key.
KEYPAD TONES
Your phone is preset to sound a tone each time a
key is pressed. To turn the keypad tones off or on
at any time, follow these steps.
MENU
TUV
1. Press . The phone displays the current setting (
OFF
8
KEYTONES ON
or
KEYTONES
).
2. Press or to select the ot her setting.
3. Press to store your selection.
Note:
OK
Your phone automatically turns off the keypad tones if you select SILENT SERVICE (see
“Ring Volume” on Page 36).
35
17-110 1.fm Page 36 Wednesday, J uly 21, 1999 9: 57 AM
RING VOLUME
You can select one of these three ring volumes for
the phone:
•
RINGING LOW
•
RINGING HIGH
•
SILENT SERVICE
ring. Instead, the keypad and display backlights flash,
the phone sounds a short beep when a call is
received. This setting also turns off the
phone’s keytones (ev en if the ke ytones feature
is set to ON).
Follow these steps to set the ring volume.
1. Press . The phone displays the cur-
MENU
rent setting (
, or
LOW
2. Repeatedly press or to scroll through
the settings .
3. When you hear or see the setting you want to
use, press to store that sett ing.
— the ring is quiet.
— the ring is loud.
— the phone does not
flashes on the display, and
CALL
WXYZ
9
RINGING HIGH, RINGING
SILENT SERVICE
OK
).
Note:
If you select SILENT SERVICE, the phone
displays
SILENT
when there is no call in progress
and when you are not using another function.
36
17-110 1.fm Page 37 Wednesday, J uly 21, 1999 9: 57 AM
RING TYPE
Follow these steps to select from five different ring
patterns that your phone can sound when it receives a call.
1. Press , then repeatedly press or
2. Press . The phone displays the current set-
MENU
until the phone displays
OK
ting (
RINGING TYPE 1
RINGING TYPE
to 5).
.
3. Repeatedly press or to scroll through
the other settings. The phone sounds a sample ring for each setting.
4. When you hear or see the setting you want to
use, press to store that setting.
OK
CHANGING THE LOCK CODE
At the time of activation, your phone is programmed with, and you were given, a 4-digit lock
code which is required to change the settings of
some menu functions (such as SID screening, call
restrictions, and calling card dialing).
To change your 4-digit lock code, follow these
steps.
1. Press , then repeatedly press or
MENU
until the phone displays
CHANGE LOCKCODE
37
.
17-110 1.fm Page 38 Wednesday, J uly 21, 1999 9: 57 AM
2. Press . The phone prompts you for your 4-
3. Enter your 4-digit lock code, then press .
OK
digit lock code (
LOCKCODE?
).
OK
The phone prompts for the new lock code
(
NEW CODE?
).
Note: If you enter the wrong lock code, the
phone displays
CODE ERROR
. Start again at
Step 1 and enter the correct code.
4. Enter the new 4-digit lock code, the n press .
OK
The phone prompts you to confirm the new
lock code (
CONFIRM
).
5. Enter the new lock code again, then press
to store it.
STORED
appears briefly to confirm
the change.
OK
38
17-110 1.fm Page 39 Wednesday, J uly 21, 1999 9: 57 AM
USING THE CALL REGISTER
Your phone automatically stores calls in these
thre e l ists:
•*
MISSED CALLS
number for up to the last 10 calls you did not
answer
•
DIALED CALLS
aled for up to the last 10 calls made from this
phone
•*
RECEIVED CALLS
phone number for up to the last 10 calls you
answered
*
Requires a subscription to calling line ID service
through your cellular carrier — see “Calling Line
ID” on Page 31
.
Follow these steps to view any of the call lists or
dial any number stored in a list.
1. Press . The phone displays
MENU
REGISTER
2. Press , then repeatedly press or
until you see the list you want to view.
3. Press to select the displayed list, then repeatedly press or to scroll through the
calls in the list.
To dial a displayed num ber
OK
OK
— lists the caller’s phone
— lists the phone number di-
— lists the caller’s
.
, simply press .
CALL
SEND
39
17-110 1.fm Page 40 Wednesday, J uly 21, 1999 9: 57 AM
To quickly store the displayed number into the
first empty speed-dial memory
, hold down
for about 2 seconds (see “Using Number
Quick Store” on Page 51).
Note: If a list is empty, the phone briefly displays
LOCATION EMPTY
then clears the dis-
play.
4. When you finish, hold down to exit the list
CLR
and clear the display.
Clearing the Call Lists
To clear the entries from
1–3 in “Using the Call Register” and select
in Step 2. The phone prompts you to enter
LISTS
your 4-digit lock code (
lock code and press . The display clears to confirm that the lists have been cle ared. To exit the call
register di splay
without
all
call li sts, f ollow St eps
CLEAR
LOCKCODE?
OK
clearing t he lists, press .
). Enter your
CLR
OK
40
17-110 1.fm Page 41 Wednesday, J uly 21, 1999 9: 57 AM
USING CALLING CARD DIALING
Storing/Clearing a Calling Card
Number
The calling card feature lets you store a longdistance cal li ng card number in the phone’s memory, so you can place long-distance calls from this
phone using that number.
Follow these steps to select a calling card type and
enter your calling card number.
1. Press , then repeatedly press or
2. Press . The phone prompts you for your 4-
3. Enter your 4-digit lock code, then press .
4. Find your long distance card carrier and ac-
MENU
until the phone displays
OK
digit lock code (
LOCKCODE?
CALLING CARD
)
.
OK
The phone displays the type of the last card
selected, or
NO CARD
if no card carrier has
been selected.
Note:
If you enter the wrong lock code, the
phone displays
CODE ERROR
. Start again at
Step 1 and enter the correct code.
cess number in the following table. Then repeatedly press or until you see your
carrier’s card t ype, then press .
OK
41
17-110 1.fm Page 42 Wednesday, J uly 21, 1999 9: 57 AM
Card T ype
(You See)
A
B
C
D
Carrier
Name
Sprint
MCI
SNET
MCI
MCI
GTE
AT&T
Sprint
PacTel
AT&T10
Sprint
Ameritech
Carrier Access
Number
1-800-877-8000
1-800-950-1022
1-800-555-5321
1-800-888-8000
1-800-674-0700
1-800-225-5483
1-800-225-5288
1-800-277-7468
1-800-522-2020
10288
100333
(Press at
OK
ACCESS NUM-
prompt)
BER?
E
The phone prompts you for that carrier’s network access number (
5. If you must dial a number (such as an 800
number) to access the carrier, enter that number. Then press . (If you do not have to dial
an access number, simply press .)
The phone prompts you for the card number
(
CARD ID CODE?
MCI 1-800-999-9000
ACCESS NUMBER?
OK
OK
).
).
42
17-110 1.fm Page 43 Wednesday, J uly 21, 1999 9: 57 AM
Note: To exit without changing the calling card
settings (if you are changing only the access
number , for example), press .
6. Enter the card number, then press .
The phone briefl y displays
CLR
STORED
OK
to confirm
that the selected card information is activated
and stored.
To clear a stored calling card number, follow Steps
1–4 and select the setting
NO CARD
in Step 4. The
phone erases all card information and exits the
menu.
Using a Stored Calling Card Number
Follow these steps to make a long-d istance call using the calling card number you stored.
1. Enter the desired area code and phone number, then hold down until the phone displays
CARD CALL
remains on the display until the access number is sent to the network, then the phone
prompts you to wait for a tone or voice prompt
(
WAIT FOR PROMPT
Note: If no calling card is stored in memory,
the phone makes a normal call to the phone
number you entered.
SEND
and IN
).
USE. CARD CALL
43
17-110 1.fm Page 44 Wednesday, J uly 21, 1999 9: 57 AM
2. When you hear the carrier’s calling card tone
or voice prompt, press .
SEND
CARD CALL
appears on the display, then the phone prompts
you to wait for another tone or voice prompt
(
WAIT FOR PROMPT
).
3. When you hear the next tone or prompt (if
any), press again, then continue with the
SEND
call as you normally would.
Notes: This procedure might not apply to all calling
card options. For more information, look at the
back of your calling card or contact your long distance carrier.
USING TOUCH-TONE SERVICES
To use your cellular phone to control answering
machines and special telephone services (such as
bank-by-phone or voicemail), simply enter touchtone commands using your phone’s keypad after
the service answe rs.
Or, you can store the service’s command sequence in a speed-dial memory (see “Storing a
Number and Name in Memory” on Page 48), then
follow these steps after the service answers.
1. Recall the memory that contai ns the command
sequence.
MENU
2. Press . The phone sends the commands as touch tones.
SEND
44
17-110 1.fm Page 45 Wednesday, J uly 21, 1999 9: 57 AM
Adding a Pause
Some services, such as voicemail, require you to
enter an access code then pause before entering
additional digits. To include a pause in a sequence
MENU
when storing it in memory, press . The
phone displays
the phone pauses for 2
. When you send the sequence,
p
1
/2 seconds where you en-
#
tered a pause. If you need a longer pause, enter
multiple pauses , one after the other.
Adding a Wait
If you do not know in advance how long you must
wait before sending additional commands, insert a
wait in your sequence by pressi ng at
the appropri ate place. The phone di splays
you send the sequence, the phone waits for you to
SEND
press before it sends the rest of the stored sequence.
MENU
# #
w
. When
45
17-110 1.fm Page 46 Wednesday, J uly 21, 1999 9: 57 AM
PIN CODE DIALING
For security, some cellular service carriers require
you to dial a personal identification number (PIN) in
addition to the phone number each time you place
a call. Th is is sometim es referre d to as “PIN cod e
dialing.”
Notes:
• This servi ce is not requir ed (or availabl e) on all
networks. Check with your local service provider.
• If you subscribe to this service, a PIN code is
assigned or selected at the time you activate
your phone.
If you subscribe to PIN code diali ng with your cellular carrier, you can store the PIN code into your
phone’s memory and set the phone to send the
code at the press of a button when you place a call.
Follow these steps to program your PIN code and
turn PIN code dialing on or off.
PQRS4GHI
#
1.Enter
JKL5JKL
5
(this spells # PIN CALL #).
7
#
The phone prompts for your PIN code (
)
CODE?
MNO2ABC2ABC
6
PIN
2. To store your PIN code in the phone’s memory
and turn on PIN code dialing, enter your PIN
code (maximum of 4 digits), then press .
PIN CALL ON
appears briefly.
OK
46
17-110 1.fm Page 47 Wednesday, J uly 21, 1999 9: 57 AM
To turn off PIN code dialing, simply press
without entering a number.
PIN CALL OFF
appears briefly.
When PIN code dialing is set to ON, the phone displays
PIN CALL
after you press to place a
call. When you hear the tone, press again to
SEND
SEND
automatically dial your stored PIN code.
Notes:
• When PIN code dialing is set to ON, you can
place a call to the emergency number programmed into your phone (as usual) without
sending the PIN code.
• If you place a call using a cellular service that
does not support PIN code dialing (and PIN
code dialing is set to ON),
PIN CALL
ap-
pears, but the call is connected without press-
SEND
ing the second time.
OK
47
17-110 1.fm Page 48 Wednesday, J uly 21, 1999 9: 57 AM
MEMORY FEATURES
STORING A NUMBER AND
NAME IN MEMORY
Your phone has 40 speed-dial memory locations.
Each locatio n can hold a phone number of up to 32
digits and a name of up to 16 characters.
Follow these steps to store a phone number and
name in memory.
Note:
If you do not press a key for about 15 seconds during these steps, the phone exits the memory mode and (depending on the step) clears the
display, turns off the backlight, or displays
MENU
STORED
. Press to return to the previous
1
prompt.
1. Hold down to clear the display, then press
MENU
.
CLR
1
The phone prompts you to enter the name
(
NAME?
ABC
) and appears indicating that the
phone is in alpha mode.
2. To enter a name, repeatedly (if necessary)
press each key that contains the letter you
want to enter until that letter appears, then
OK
press . (For example, to enter RAY, press
PQRS
7
three times, once, three
times, then .) The phone prompts you to
OK
enter the phone number
ABC
2
(NUMBER?)
To proceed without entering a name, press
OK
.
NOT
WXYZ
9
.
48
17-110 1.fm Page 49 Wednesday, J uly 21, 1999 9: 57 AM
Notes:
• Within about 2 seconds after you stop
pressing a key, the cursor automatically
moves to the next position. To move it sooner , press .
• If you make a mistake, press to erase
CLR
each wrong letter, then try again.
• Press to enter a space or to en-
#
ter punctuation (
–, &, .
, and :).
1
3. Enter the area code (if necessary) and phone
number, then press .
OK
The phone suggests the first empty speed-dial
memory (such as
STORE TO 5?
) or, if memory is full, prompts you to enter a speed-dial
memory number (
To store the number in the suggested speed-
4.
dial memory
STORE TO?
, press .
OK
).
To store the number in a different mem ory
ter that memory’s two-digit number then press
OK
.
To store the number in the one-touch location
OK
1
press .
The phone displays
STORED
.
Notes:
• If you try to store to a memory num ber high-
er than 40, the phone displays
LOCATION
Press to return to the previous
and exits the memory function.
MENU
1
INVALID
prompt.
, en-
,
49
17-110 1.fm Page 50 Wednesday, J uly 21, 1999 9: 57 AM
• If the selected memory is full, the phone
prompts you to replace the contents (
PLACE
CONTENT?
).
To replace the contents, press . The
phone displays
STORED
.
• If both the name and phone number are already stored (a duplicate), the phone displays
ALREADY STORED
, then it prompts
you to move the information to the first
empty speed-dial memory (such as
5?). Press to store the number in
TO
OK
the suggested location, or enter the desired
location number then press .
OK
• To exit the memory function without storing
the number, press . The phone displays
NOT STORED
store. Hold down to clear the display.
CLR
and the number you tried to
CLR
Hints:
Using Memory Location 1
•
1
down for about 2 seconds (see “One-
— You can hold
Touch/Speed Dialing” on Page 51) to quickly
dial the number stored in memory location 1.
For convenience, store a frequently called
telephone number (such as your home or office number) in thi s location.
Using Memory Location 40
•
— Setting the
phone to use the call restriction level
(see “Selecting a Call Restriction
ONLY
ING
Level” on Page 21) does not prevent you from
speed-dialing the number stored in memory location 40. If you plan to use this call restriction
RE-
OK
MOVE
INCOM-
50
17-110 1.fm Page 51 Wednesday, J uly 21, 1999 9: 57 AM
level, store a frequently called telephone number (such as your home number or some ot her
“priority” number) in memory location 40.
Using Number Quick Store
To quickly store a phone number in the first unused
speed-dial memory, enter the phone number, then
hold down for about 2 seconds. The phone
briefly displays
OK
STORED
and the speed-dial mem-
ory number it selected.
If all speed-dial memory locations are full, the
phone briefl y displays
NO SPACE
, then the number
you tried to store reappears. To store the number,
clear a memory location (see “Clearing a Memory”
on Page 52), then try again.
ONE-TOUCH/SPEED DIALING
To speed dial the number stored in Memory 1
1
down for about 2 seconds.
, hold
To speed dial a number stored in any other memory
, enter that memory’s number, then press .
Note:
If the selected memory is empty, the phone
displays
LOCATION EMPTY
.
SEND
51
17-110 1.fm Page 52 Wednesday, J uly 21, 1999 9: 57 AM
MEMORY SCROLLING
To scroll forward or backward through all names or
numbers stored in memory
or last memory location), press (if you want to
view names), then repeatedly press ( forward)
or (backward). The phone displays the stored
name or phone number and its corresponding
memory number.
(beginning with the first
C
B
A
To begin scrolling from a specific memory number
first enter that number, then press or . If
the selected memory is empty, the phone displays
LOCATION EMPTY
, then it displays the next
memory in sequenc e.
To begin scrolling from a specific name or letter(s)
press , enter the name or letter(s), then press
C
B
A
or . If the name or letter(s) you entered
are not stored in memory, the phone displays
NAME NOT FOUND
, then it displays the next name
in sequence.
To dial a displayed number, press .
SEND
CLEARING A MEMORY
MENU
DEF
1. Press . The phone displays
and
NAME?
2.
If you stored a name in the memory location
you want to clear
to recall that name.
3
, repeatedly press or
ERASE?
stored name appear.
52
ABC
and the
,
,
CLR
17-110 1.fm Page 53 Wednesday, J uly 21, 1999 9: 57 AM
If you stored only a number in the memory location you want to clear
, press so
disappears. The phone displays
C
B
ABC
A
LOCATION?
Enter the memory number, or repeatedly press
or , to recall the number you want to
clear.
ERASE?
3. To clear the selected memory, press . The
phone briefly displays
operation, then it displays
and the stored number appear.
OK
ERASED
to confirm the
ERASE?
and the
next stored number or name in memory sequence.
Repeat Steps 2 and 3 for each memory you
want to clear.
Note: To exit without clearing the selected
memory, press . The phone displays
ERASED
then exits the memory mode.
CLR
NOT
4. When you finish, pre ss to exit.
53
17-110 1.fm Page 54 Wednesday, J uly 21, 1999 9: 57 AM
USING SCRATCHPAD MEMORY
Your phone’s scratchpad memory lets you temporarily store a phone number
useful, for example, when you don’t have a pencil
and paper handy! Follow these steps to store a
number in the scrat chpad memory.
1. Be sure the display is clear, then enter the
number you want to stor e.
MENU
2. Press , then press .
3. Press so
press to store the number in the scratch-
1
#
OK
STORE TO #?
pad memory. (Any number previously stored in
the scratchpad memory is replaced by the new
number .)
Note:
The scratchpad memory is automatically
cleared each tim e you turn off the phone.
To recall the scratchpad memory
or . (If the scratchpad memory is empty,
the phone display s
LOCATION EMPTY
during
a call. This is
OK
appears, then
, press then
.)
#
To dial the number stored in scratchpad memory
recall it, then press .
SEND
To quickly transfer a number from the scratchpad
memory to the first empty speed-dial memory
call the sc ratchpad memory, then hold down for
, re-
OK
about 2 seconds (see “Using Number Quick Store”
on Pa ge 51) .
54
,
17-110 1.fm Page 55 Wednesday, J uly 21, 1999 9: 57 AM
ACCESSORIES
A new, extensive range of accessories is available
for your phone through your local RadioShack
store. You can select the accessories that best
meet your needs.
Important:
phone manufacturer. Using any other type invalidates any approval or warranty applying to the
phone, and might be dangerous.
Here are a few practical rules for accessory operation:
• Keep the accessories out of the reach of chil-
• When you disconnect any accessory’s power
• Regularly check all cellular phone equipment
• Have only qualified personnel install complex
Use only accessories approved by the
dren.
cord, pull the plug, not the cord.
in your vehicle to be sure it is mounted and operating properly.
car accessories.
55
17-110 1.fm Page 56 Wednesday, J uly 21, 1999 9: 57 AM
SAFETY INFORMATION
TRAFFIC SAFETY
• Do not use a handheld phone while driving a
vehicle. If using a handheld phone, park the
vehicle before taking or making a call.
• Always secure the phone in its holder; do not
place the phone on the passenger seat or
where it c an bre ak loose i n a collis ion or s udden stop.
• Never use a phone alert device that operates
your vehicle’s lights or horn. This is illegal in
most areas.
Remember, always put road safety first!
OPERATING ENVIRONMENT
• Remember to follow all special regulations and
always turn off your phone whenever you are
required to do so, or when it might c ause interference or be dangerous.
• Any radio transmitting equipment, including
cellular phones, might interfere with inadequately protected medical devices. Consult a
physician or the manufacturer of the medical
device if you have any questions. Other electronic equipment might also be subject to i nterference.
• As with other mobile radio transmitting equipment, for your safety, only use your phone in
the normal operating position (held to your ear
with the antenna pointing over your shoulder).
56
17-110 1.fm Page 57 Wednesday, J uly 21, 1999 9: 57 AM
• Turn off the phone while getting gasoline (at a
filling s tation) . Observ e restric tion s on the use
of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants, or
around blastin g operations.
• Do not store or carry flammable liqui ds, gases,
or explosive materials in the same compartment as a cellular phone or any of its parts or
accessories.
• Only qualified personnel should install or service the phone in a vehicle. Faulty installation
or service m ight be da ngerous and cou ld invalidate the phone’ s warranty.
• Electronic fuel injection systems, electronic
anti-lock braking systems, electronic cruise
control systems, and other electronic systems
can malfunction due to the lack of protection
from radio signals. Check regularly that all cellular phone equipment in your vehicle is
mounted and operating properly.
• Turn off your cellular phone when in an aircraft. The use of cellular phones in an aircraft
might be dangerous to the operation of the ai rcraft, disrupts the cellular networks, and is illegal.
Failure to observe these instructions could lead to
suspension or denial of cellul ar telephone services,
legal action, or bot h.
57
17-110 1.fm Page 58 Wednesday, J uly 21, 1999 9: 57 AM
EMERGENCY CALLS
IMPORTANT!
operates using radio signals, cellular, and land line
networks, as well as user-programmed functions.
These factors make it impossible to guarantee connection in all conditions. Therefore, you should
never rely solely upon any cellular phone for essential communications (such as medical emergencies).
Remember, to make or receive any calls, the
phone must be turned on and in a service ar ea with
adequate cellu lar signal strength.
You might not be able to make emergency calls on
all cellular phone networks or when ce rt ain network
services or phone features are set. Check with
your local ser vice providers.
This phone, like any cellular phone,
FCC REGULATIONS
A cellular phone might cause TV or radio interference, even when it is operating normally. The FCC
can require you to stop using your cellular phone if
you cannot eliminate the interference. If you require assistance, contact your local RadioShack
store.
This device complies with Parts 15 and 68 of
Rules
. Operation is subject to the condition that
this device does not cause harmful interfer ence.
58
FCC
17-110 1.fm Page 59 Wednesday, J uly 21, 1999 9: 57 AM
TROUBLESHOOTING
If the power does not come on or stay on:
• Make sure the battery is properly installed and
charged.
• Be sure that the contacts on the battery and
the charging stand are clean. If they are not,
clean them with a soft clot h or pencil eraser.
• The battery charge might be too low for operation. Check the display and listen for the low
battery warning tone.
If the power comes on, but the phone does not
work:
• Make sure that the antenna is properly installed and, if your phone has an extendable
antenna, make sure that the antenna is extended to its full length.
• Check to see if there is an error message on
the display after turning it on. If so, contact
your local Rad ioShack store for assistance.
59
17-110 1.fm Page 60 Wednesday, J uly 21, 1999 9: 57 AM
CARE AND MAINTENANCE
Your RadioShack CT-400 Handheld Cellular Phone is an
example of superior design and craftsmanship and
should be treated with care. These suggestions allow you
to enjoy this phone for many years.
• Keep the phone and all its par ts and accessories out
of the reach of children.
• Keep the phone dry. Precipitation, humidity and liquids mi ght contai n minerals tha t corrode electronic
circuits.
• Do not use or store the phone in dusty, dirty areas.
Its moving parts can be damag ed.
• D o not stor e the phon e in hot areas. Tempera ture
extrem es can short en the life of elec troni c devi ces,
damage batteries, and warp or melt plastic parts.
• Do not store the phone in cold areas. When the
phone wa rms up (to its no rmal operat ing tempera ture), moisture can form inside the phone, which
could damage the phone’s electronic circuits.
• Do n ot attem pt to ope n t he ph one. Non -ex pert h an dling of the phone can damage it.
• Do not drop, knock, or shak e the phone. Rough handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the phone. Wipe it with a
soft cl oth slig htly damp en ed in a mi ld so ap and w ater solution.
Modify ing or tampering with your phone’s internal components could violate its warranty and void your FCC authorization to use it. If the phone or any of its accessories are
not working properly, take them to your loca l RadioShack
store for assistance.
60
17-110 1.fm Page 61 Wednesday, J uly 21, 1999 9: 57 AM
SPECIFICATIONS
Dimensions ........................ Width: 21/8 in (54 mm)
Height (without antenna): 6 in (152.4 mm)
Depth: 1
Weight ............................................ 7.6 oz. (215 g)
Transmitting Power .............. 0.6 W (+2 dB –4 dB)
Operating Voltage
Battery ................................................... 4.8 V
Input to Charger ......... 120 V (AC), 12 V (car)
Frequency Band ........ 824.040–848.970 MHz (TX)
869.040–893.970 MH z (RX)
Number of Channels ....................................... 832
Memories ...................................... 40 Speed Dial,
7
/16 in (37 mm)
with Supplied Battery
1 Scratchpad
Specifications are typical; individual units might
vary. Specifications are subject to change and improvement without noti ce.
61
17-110 1.fm Page 62 Wednesday, J uly 21, 1999 9: 57 AM
NOTES
62
17-110 1.fm Page 63 Wednesday, J uly 21, 1999 9: 57 AM
63
y
y
)
y
y
y
17-110 1.fm Page 64 Wednesday, J uly 21, 1999 9: 57 AM
Limited One-Year Warrant
This product is warranted by RadioShack against manufacturing defects
in material and workmanship under normal use for one (1) year from the
date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers. In the event of a product defect during the warranty period, take the product and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless otherwise provided by law: (a) correct
the defect by product repair without charge for parts and labor; (b) replace the product with one of the same or similar design; or (c) refund the
purchase price. All replaced parts and products, and products on which a
refund is made, become the property of RadioShack. New or reconditioned parts and products may be used in the performance of warrant
service. Repaired or replaced parts and products are warranted for the
remainder of the original warranty period. You will be charged for repair or
replacement of the product made after the expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or maintenance,
alteration, lightning or other incidence of excess voltage or current; (b
any repairs other than those provided by a RadioShack Authorized Service Fac ility; (c) consumables such as fuses or batteries; (d) cosmetic
damage; (e) transportation, shipping or insurance costs; or (f) costs of
product removal, installation, set-up service adjustment or reinstallation.
EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS
WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE
WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS
PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY
WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE
PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY,
INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING
FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow the limitations on how long an implied warrant
lasts or the exclusion of incidental or consequential damages, so the
above limitations or exclusions may not apply to you. This warranty gives
ou specific legal rights, and you may also have other rights which var
from state to state.
RadioShack Customer Relations, Dept. W, 100 Throckmorton St.,
Suite 600, Fort Worth, TX 76102
We Service What We Sell
1/97
A Division of Tandy Corporation
RadioShack
Fort Worth, Texas 76102
9351410
10/97 Printed in Canada
Loading...
