CB1200-I PELLET INSERT
DO NOT
DISCARD
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
C
US
Installation and Operation
CB1200MI-MBK
DO NOT DISCARD THIS MANUAL
• Important operating and
maintenance instruc-
tions included.
Owner’s Manual
Model:
NOTICE
•
Read, understand and
follow these instructions for safe installa-
tion and operation.
•
Leave this manual with
party responsible for use
and operation.
• Do not store or use gasoline or other am-
•
•
www.quadrare.com
WARNING
Please read this entire manual
before installation and use of this
pellet fuel-burning room heater.
Failure to follow these instructions
could result in property damage,
bodily injury or even death.
mable vapors and liquids in the vicinity of this
or any other appliance.
Do not overre - If any external part starts to
glow, you are overring. Reduce feed rate.
Overring will void your warranty.
Comply with all minimum clearances to com-
bustibles as specied. Failure to comply may
cause house re.
CAUTION
Tested and approved for wood pellets and shelled
eld corn fuel only. Burning of any other type of fuel
voids your warranty.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
• Alert children and adults to hazards of high
High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other ammable
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and national
• Consult local building, re ofcials or authorities having jurisdic-
7014-188B
WARNING
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
replace.
temperatures.
materials away.
CAUTION
codes and regulations.
tion about restrictions, installation inspection, and permits.
February 3, 2010
R
CB1200-I Pellet Insert
R
R
and Welcome to the Quadra-Fire Family!
Safety and clearance section located on inside of hopper lid./Serial Number section located under top on inside of hopper body.
La section se réfé dux distances et mescres de sécurité est située à l'intérieut du couvércle de la tré la bôitre à feu.
La section du numéro de série est située en dessous du couvercle à l'intérieur de la trémie.
Listed Solid Fuel Room Heater/Pellet Type Insert. Also suitable for
Mobile Home Installation. This appliance has been tested and listed for
use in Manufactured Homes in accordance with OAR 814-23-9000
through 814-23-909.
R
1200-I Pellet Insert
1445 Highway North, Colville, WA 99114
www.quadrafire.com
Tested to: ASTM E1509-95, UL127, ULC S628-93, ULC S610-M87,
ULC/ORD C1482-M1990, Room Heating Pellet Burning Type, (UM) 84-HUD
FOR USE
ONLY WITH PELLETIZED WOOD OR SHELLED FIELD CORN FUEL.
Input Rating Maximum 5.5 lb fuel/hr.
Electrical Rating:
115 VAC, 60 Hz, Start 4.1 Amps, Run 1.1 AMPS.
Route power cord away from unit. Do not route cord under or in front of
appliance.
DANGER:
Risk of electrical shock. Disconnect power supply before
servicing. Replace glass only with 5mm ceramic available from your dealer.
To start, set thermostat above room temperature, the stove will light
automatically. To shutdown, set thermostat to below room temperature. For
further instruction refer to owner's manual
.
Keep viewing and ash removal doors
tightly closed during operation.
Masonry or Zero Clearance Minimum Clearances to Combustible
Maçonnene ou zéro distance foyer distances minimales à tout matériel combustible.
7014-080C
U.S. ENVIRONMENTAL PROTECTION AGENCY OMNI Test Laboratories, Inc., Beaverton, Or Report/Rapport 061-S-12-2
This model is exempt from EPA certification under 40 CFR 60.531 by definition [Wood Heater (A) "Air-to-Fuel Ratio"].
7014-080C
1200-I PELLET INSERT
A Louvers to combustible wall
B Insert top to mantel
C Front Facing
D* Hearth Extension - Front
E* Hearth Extension - Side
6” (152mm)
12” (305mm)
3” (76mm)
6" (152mm)
8” (203mm)
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER L'ÉTIQUETTE
SERIAL NO.
/ NUMÉRO DU
Report / Rapport
#061-S-13-2
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER L'ÉTIQUETTE
Made in China/Fait Aux Chine
Testé à: ASTM E1509-95, UL127, ULC628-M93, ULC S610-M87, ULC/ORD
C1482-M1990, Room Heating Pellet Burning Type, (UM) 84-HUD POUR USAGE
AVEC LES BOULETTES DE BOIS OU DE COMBUSTIBLE DE MAIS ÉCOSSÉ DES
CHAMPS.
Consommahon maximale à l'entrée (sans pertes) 2.5 kg/h.
Puissance Électrique: 115 VAC, 60 Hz, Début 4.1 Amps, Courir 1.1 Amps,
Éloignez le fil électrique de l'appareil. Ne pas faire passer le fil électrique au
dessus ou en dessous de l'appareil.
DANGER: Il y a risque de décharge électrique. Déconnectez le fil électrique de la
prise de contact avant le service.
Remplacez la vitre seulement avec une vitre céramique de 5 mm disponible chez
votre fournisseur.
Pour allumer, monter la température du thermostat au dessus de la température de
la pièce, le poêle s'allumera automatiquement. Pour éteindre, descendre la
température du thermostat en dessous de la température de la pièce. Pour des
instructions supplémentaires, référez vous au manuel du propriétaire. Gardez la
porte d'ouverture et la porte des cendres fermées hermétiquement durant
l'opération.
Appareil de chauffage inséré de combustible solide/de type de boulettes. Accepté dans
l'installation dans les maisons mobiles. Cet appareil a été testé et enregistré pour
l
'usage dans les Maisons Mobiles en accord avec OAR 814-23-9000 jusqu'à 814-23-909.
*See hearth protection note above
A Lucarne au mur combustible
B Dessus de l'insert à la tablette de cheminée
C Revêtement facial
D* Protechion de sol - frontal
E* Protechon ole sol - côté
*Voir les notes sur la protechion ole sol ci-dessus.
152mm
305mm
76mm
152mm
203mm
QUADRA-FIRE
SIDE WALL
A
B
C
D
E
CAUTION:
HOT WHILE IN OPERATION DO NOT TOUCH. KEEP CHILDREN, CLOTHING AND FURNITURE
AWAY. CONTACT MAY CAUSE SKIN BURNS. SEE NAMEPLATE AND INSTRUCTIONS. Operate this unit with
fuel hopper lid closed. Failure to do so may result in emissions products' combustion from the hopper
under certain conditions. Maintain hopper seal in good condition. Do no over fill the hopper.
ATTENTION:
CHAUD LORS DE L'OPÉRATION. NE PAS TOUCHER. GARDEZ LES ENFANTS ET LES VÊTEMENTS LOIN DE
L'ESPACE DÉSIGNÉ DE L'INSTALLATION. LE CONTACT PEUT CAUSER DES BRÛLURES À LA PEAU. VOIR L'ÉTIQUETTE ET LES
INSTRUCTIONS. Opérez cet appareil avec le couvercle de la trémie fermé. Le défaut de ne pas suivre les instructions peut résulter,
sous certaines conditions, en une combustion des émissions des produits venant de la trémie. Ne pas remplir la trémie trop pleine.
MANTEL
2009 2010 2011 JAN FEB MAR APR MAY JUNE JULY AUG SEPT OCT NOV DEC
SAMPLE
007C
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
C
US
Hearth & Home Technologies welcomes you to our tradition
of excellence! In choosing a Quadra-Fire appliance, you
have our assurance of commitment to quality, durability, and
performance.
This commitment begins with our research of the market,
including ‘Voice of the Customer’ contacts, ensuring we
make products that will satisfy your needs. Our Research
and Development facility then employs the world’s most
advanced technology to achieve the optimum operation of
our stoves, inserts and replaces. And yet we are old-fashioned when it comes to craftsmanship. Each unit is meticu-
lously fabricated and surfaces are hand-nished for lasting
beauty and enjoyment. Our pledge to quality is completed
as each model undergoes a quality control inspection.
From design, to fabrication, to shipping:
We wish you and your family many years of enjoyment in
the warmth and comfort of your hearth appliance. Thank
you for choosing Quadra-Fire.
NOTE: Consult insurance carrier, local building inspector, re
ofcials or authorities having jurisdiction over restrictions,
installation inspection and permits.
CLEARANCE TO COMBUSTIBLES LABEL LOCATED INSIDE HOPPER LID
SERIAL NUMBER & MANUFACTURE DATE LABEL LOCATED UNDER TOP ON INSIDE OF HOPPER BODY
Test Lab &
Report No.
Model Name
Page 2
7014-188B
Manufactured Date
Serial Number
February 3, 2010
R
R
R
CB1200-I Pellet Insert
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the replace or to property.
