USER MANUAL
NEOS218PX
passive subwoofer
KEY FEATURES
• Premium transducer
• 100 mm (4 in) Interleaved Sandwich Voice coil (ISV)
• 4000 W program power handling
• Double Silicon Spider (DSS) for superior excursion control and linearity
• Double Demodula ng Rings (DDR) for lower distor on
• Improved heat dissipa on via mul -cell air diff ractor and mul ple backplate vents
• Weather protected cone and plates for outdoor usage
• Plywood cabinets with die-cast handles, pole holder and four rugged 80mm wheels for an easy transport.
INTRODUCTION
NEOS PX series represents the highest expression of PROEL GROUP Research & Development applied in loudspeaker systems. A natural evolu on
of the NEOS Series, it incorporates the latest technologies developed by PROEL in advanced sound reinforcement systems able to provide premium
sound, maximum performance and up-to-date features.
The NEOS PX are designed for the use both as high-performance mobile systems for live applica ons and for advanced fi xed installa ons.
The NEOS PX are able to provide an excep onal sound defi ni on together with very high dynamics and low distor on in an ultra-compact
package.
TECHNICAL SPECIFICATION
AcousƟ cal Frequency Response Diagram
System type Sub-woofer, vented
Low frequency driver 2 x 18’’ woofer - 4” VC
Frequency response from 30 Hz
Coverage omnidirec onal
Max SPL 137 dB
Electrical
Nominal Impedance 8 + 8 ohm
Power Handling Con nuous 2000 W
Power Handling Peak 4000 W
Sensi vity 101 dBspl @ 1W / 1m
Suggested Crossover Frequency 80 Hz - 125 Hz
Connectors IN - LINK: Speakon® (NL4MP)
Mechanical
Construc on 15, 18 and 24 mm birch plywood
Finish An -scratch black paint
Pole holder 1 top - 1 side
Dimensions (W x H x D) 590 x 990 x 790 mm
Weight 80.5 kg (177.3 lbs)
110.0
dBSPL
100.0
90.0
80.0
70.0
60.0
10k5k2k1k500200100502020 20kHz
MECHANICAL DRAWING
Pole Holder
39.6"
100.5 cm
58.5 cm
23.0"
79.0 cm
31.1"
Pole Holder
OPTIONAL ACCESSORIES
ASO25 2 in 4 out analog loudspeaker processor
PC240 2 in 4 out digital loudspeaker processor
PC260 2 in 6 out digital loudspeaker processor
KP210BK Sub-Speaker pole
NL4FX Neutrik Speakon® PLUG
see www.proel.com for detailed descrip on and other available accessories.
SPARE PARTS
NL4MP Neutrik Speakon® panel socket
AC102 80 mm Caster
98NEOS18SW8 18’’ woofer - 4” VC
REAR PANEL
INPUT - External amplifi er power input. The connec ons depend by the confi gura on se ngs accordingly the following table:
INPUT
SINGLE SPEAKER SUB DUAL SPEAKER SUB
1+ / 1- INPUT 1+ / 1- INPUT 1ST WOOFER
2+ / 2- INTERNALLY N.C. 2+ / 2- INPUT 2ND WOOFER
LINK - Power output for connec ng the unit to another speaker. The INPUT and LINK connectors are in parallel to each other.
PRODUCT LABEL - In this label are wri en the most important data informa on about the passive loudspeaker, model, impedance, maximum
applicable con nuous power, serial number.
The NEOS218PX doesn’t contain a built-in crossover fi lter so the two loudspeaker are directly connected to the amplifi er outputs. For this reason,
an external crossover is required in order to fi lter properly the sub-woofer and to combine it with top units.
The crossover can be either analog or digital, however we recommend the PROEL ASO25 as analog processor or the PROEL PC240/260 as digital
processor.
In the following table PROEL suggest the PROCESSOR parameters for PC240/260; these parameters could be used to set also other equipment
obtaining similar acous c result.
Filter High Pass Filter Low Pass Filter Parametric EQ
Frequency 29 Hz from 80 to 125Hz 35 Hz
Type Bu erworth 24 dB/oct. Bu erworth 18 dB/oct. Q = 0.7 / OCT. = 1.9
Gain - - +4 dB
LIMITED WARRANTY
Proel warrants all materials, workmanship and proper opera on of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to func on properly during the applicable warranty period, the owner should inform about these defects the
dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descrip on. This warranty does not extend to damage resul ng from
improper installa on, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is s ll
valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defec veness.
• This unit package has been submi ed to ISTA 1A integrity tests. We suggest you control the unit condi ons immediately a er unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspec on.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately no fi ed to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its loca on or posi on does not interfere with its proper ven la on and hea ng dissipa on.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the opera ng instruc ons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condi ons.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connec on.
– Make sure that power supply mains line has a proper earth connec on.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me.
CE CONFORMITY
Proel products comply with direc ve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direc ve 2006/95/CE (LVD), as stated in EN
60065 standard.
