Planet IPOE-173S Installation Manual

1. Package Contents

Power Output

V+

V+

12V

DC Voltage

24V

Power Output

12V

DC Voltage

24V

V+

V+

Power Output

V+

V+

12V

DC Voltage

24V

Power Output

12V

DC Voltage

24V

V+

V+

Thank you for purchasing PLANET Industrial 802.3bt PoE++
Splitter, IPOE-173S. “PoE Splitter” mentioned in this manual refers
to the IPOE-173S.

Open the box of the PoE Splitter and carefully unpack it. The box
should contain the following items:

PoE Splitter x 1 User’s Manual x 1 RJ45 Dust Cap x 2

2.2 4-pin Power Output Terminal Block

If there is no power socket in your network environment, PLANET
IPOE-173S provides DC power for this Ethernet device conveniently.
The IPOE-173S splits the transmission of the power and data.

From top to down, there are Negative (V-), Negative (V-), Positive
(V+) and Positive (V+), and two sets of DC power output contact.

Power Output

3. Installation

 Wiring the Power Outputs

Please follow the steps below to insert the power wires.

Step 1: Please nd one terminal block connector within two DC

power outputs shown below:

1 V-

Step 5: Connect the network copper cable (RJ45) from an

802.3bt PoE++ PSE to the IPOE-173S Splitter where the
power and data are separately transmitted to a PD as

shown in the gure below:

802.3bt PoE++
PSE

802.3bt PoE++ Data in

10/100/1000T Copper

Data Out

DC

DC+

Non-PoE

-

Device

DIN-rail Bracket w/Screws kit

x 1

Wall-mount Plate w/Screws kit

x 1

If any of these are missing or damaged, please contact your dealer
immediately.

- 1 -

2. Hardware Introduction

2.1 Front Panel and LED Indicators

The front panels of the Industrial PoE+ Injector Hubs consist of
Ethernet interfaces and LED indicators.

30W 60W 90W

PoE Input

Industrial 802.3bt PoE++ Splitter

PoE IN

10/100/1000T

Data Out

10/100/1000T

Power Output

V+

V+

12V

24V

DC Voltage

12V 24V

Figure 2-1:

Front View of IPOE-173S

 PoE input indicators

LED Color Function

Lights to indicate the

30W Green

PoE Splitter is working in

802.3at PoE mode.

Lights to indicate the

60W Green

PoE Splitter is working in

802.3bt type 3 PoE mode.

Lights to indicate the

90W Green

PoE Splitter is working in

802.3bt type 4 PoE mode.

 DC output voltage indicators

LED Color Function

12V Amber

24V Green

Lights to indicate the PoE
Splitter’s output is in 12V
DC mode

Lights to indicate the PoE
Splitter’s output is in 24V
DC mode

- 2 -

V+

V+

12V

24V

DC Voltage

12V 24V

Figure 2-2: Terminal Block of IPOE-173S

It comes with two DC outputs --12V, 5.8A or 24V,

2.9A, totaling 70 watts of DC output power, which
means that DC1 + DC2 cannot be over the 70-watt

Note

DC output power limit. Otherwise, it might cause the
power output to malfunction or damage.

- 3 -

2.3 DC Voltage DIP Switch

It provides two kinds of DC power output through its DIP switch
and its voltage and current are shown below:

Power Output

V+

V+

12V

24V

DC Voltage

12V 24V

Figure 2-3: DIP Switch of IPOE-173S

1. Please check the power requirements of the device
carefully that is going to get the power from the
IPOE-173S.

2. If the power requirement is higher than the IPOE­173S can supply, current overload might shut down

Caution

Caution

the IPOE-173S itself. Thus, it will also shut down
your device as well.

3. Please ensure the output voltage is correct for
remote device. Otherwise, it will damage your
remote device.

Do not switch on/off the Power DIP during operation.
Otherwise, it will damage your IPOE-173S and remote
device. If you want to switch from one output voltage
to another via DIP switch, plug out the “PoE In”
cable and wait for 3 seconds until the PoE Input LEDs
are completely OFF.

- 4 -

2 V-

3 V+

DC Output 2

DC Output 1

4 V+

The wire gauge for the terminal block should be in the

Note

Step 2: Insert the Negative/Positive DC wires into the V– / V+

Step 3: Connect the other end of DC power wires to the power

Step 4: Install the terminal block on PLANET IPOE-173S Splitter.

range of 12 ~ 24 AWG.

- 5 -

terminal; Terminals 1 and 3 for Power 1; Terminals 2 and
4 for Power 2.

devices. Tighten the wire-clamp screws for preventing the
wires from loosening.

Powered

Device

1

Maximum Output 70 Watts

Powered

Device

1

Total Maximum

Output 70 Watts

Powered

Device

2

- 6 -

Make sure the IPOE-173S output voltage (DC
12V/24V) is correct before applying power to a remote

Caution

device.

- 7 -

4.ProductSpecications

Product IPOE-173S

Hardware Specications

PoE Input Port 1 10/100/1000 BASE-T RJ45

Data Output

Interface

Port

DC Out Plug
Connector

DIP Switch 12V/24V DC output

LED Indicators

Data Rate 10/100/1000Mbps

Dimensions (W x D x H) 32 x 87.8 x 135 mm

Weight 445g

Installation DIN-rail/wall mountable

Enclosure IP30 metal case

Power Requirements

1 10/100/1000 BASE-T RJ45

1 removable 4-pin terminal block

PoE Input:
30W (Green)
60W (Green)
90W (Green)

DC Voltage:
12V (Amber)
24V (Green)

802.3bt PoE++ or 4-pair 802.3at
PoE+
PoE DC 48 ~ 56V

- 8 -

Power

Top View

Taiwan

15thNov., 2019

.

Place

Date

Legal Signature

Consumption

System on with
PoE input

Full loading with
maximum
12V DC, 5.8A

5.4 watts

81.6 watts

output

Power
Output

Network
Cable

802.3 bt type 3
PoE++ input

802.3 bt type 4
PoE++ input

802.3 bt PoE++
input
(60W+)

802.3at PoE+
input
(30W)

12V DC, 4.5A (max.)
24V DC, 2.2A (max.)

12V DC, 5.8A (max.)
24V DC, 2.9A (max.)

4-pair UTP Cat. 5e, 6, up to 100m
(328ft)

2-pair UTP Cat. 5, 5e, 6, up to
100m (328ft)

Power over Ethernet

PoE Standard

802.3 bt PoE++
4-pair 802.3at PoE+

Power Output DC 12V/24V by DIP switch control

End-span + Mid-span

PoE Power Supply Type

End-span
Mid-span

1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)

Power Pin Assignment

or 1/2 (-), 3/6 (+); 4/5 (+), 7/8
(-)

5. Physical Dimensions

Dimensions (W x D x H): 32 x 87.8 x 135 mm

40.00

28.00

18.0028.00

PoE IN

PoE Input

30W 60W 90W

Industrial 802.3bt PoE++ Splitter

DIN-Rail Kit

135.00

10/100/1000T

Data Out

48.80

10/100/1000T

Power Output

24V

12V 24V

DC Voltage

V+

V+

12V

Mounting Kit

Rear View

Side View

Side View Front View

87.80

Mounting Kit

97.10

Bottom View

32.00

- 9 -

Standards Conformance

IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast
Ethernet
IEEE 802.3ab 1000BASE-T Gigabit

Standards Compliance

Ethernet
IEEE 802.3at Power over Ethernet
Plus
IEEE 802.3bt 4-pair Power over
Ethernet Type 4

Regulatory Compliance FCC Part 15 Class A, CE

Environment

Operating Temperature -40~ 75 degrees C

Storage Temperature -40~ 85 degrees C

Humidity 5 ~ 95% (non-condensing)

Unit: mm

- 11 -
