Pioneer XW-HTD630A User Manual
Digital Wireless
Rear Speaker System
’
Ensemble d
fil pour transmission numérique
enceintes arrière sans
XW-HTD630A
Operating Instructions
Mode d’emploi
IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product's enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
READ INSTRUCTIONS — All the safety and
operating instructions should be read before
the product is operated.
RETAIN INSTRUCTIONS — The safety and
operating instructions should be retained for
future reference.
HEED WARNINGS — All warnings on the
product and in the operating instructions should
be adhered to.
FOLLOW INSTRUCTIONS — All operating and
use instructions should be followed.
CLEANING — Unplug this product from the wall
outlet before cleaning. The product should be
cleaned only with a polishing cloth or a soft dry
cloth. Never clean with furniture wax, benzine,
insecticides or other volatile liquids since they
may corrode the cabinet.
ATTACHMENTS — Do not use attachments not
recommended by the product manufacturer as
they may cause hazards.
WATER AND MOISTURE — Do not use this
product near water — for example, near a
bathtub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming
pool; and the like.
ACCESSORIES — Do not place this product on
an unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a
child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.
CART — A product and cart
combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the
product and cart combination to
overturn.
VENTILATION — Slots and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the product and to
protect it from overheating, and these openings
must not be blocked or covered. The openings
should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer’s instructions have been adhered
to.
POWER SOURCES — This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company.
LOCATION – The appliance should be installed
in a stable location.
NONUSE PERIODS – The power cord of the
appliance should be unplugged from the outlet
when left unused for a long period of time.
GROUNDING OR POLARIZATION
• If this product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other), it will fit into the
outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
• If this product is equipped with a three-wire
grounding type plug, a plug having a third
(grounding) pin, it will only fit into a grounding
type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet,
contact your electrician to replace your
obsolete outlet. Do not defeat the safety
purpose of the grounding type plug.
H002_En
POWER-CORD PROTECTION — Power-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
LIGHTNING — For added protection for this
product during a lightning storm, or when it is
left unattended and unused for long periods of
time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power-line surges.
POWER LINES — An outside antenna system
should not be located in the vicinity of
overhead power lines or other electric light or
power circuits, or where it can fall into such
power lines or circuits. When installing an
outside antenna system, extreme care should
be taken to keep from touching such power
lines or circuits as contact with them might be
fatal.
OVERLOADING — Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY — Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
SERVICING — Do not attempt to service this
product yourself as opening or removing covers
may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
DAMAGE REQUIRING SERVICE — Unplug this
product from the wall outlet and refer servicing
to qualified service personnel under the
following conditions:
• When the power-supply cord or plug is
damaged.
• If liquid has been spilled, or objects have fallen
into the product.
• If the product has been exposed to rain or
water.
• If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the
operating instructions as an improper
adjustment of other controls may result in
damage and will often require extensive work
by a qualified technician to restore the product
to its normal operation.
• If the product has been dropped or damaged in
any way.
• When the product exhibits a distinct change in
performance — this indicates a need for
service.
REPLACEMENT PARTS — When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have the
same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock, or other hazards.
SAFETY CHECK — Upon completion of any
service or repairs to this product, ask the
service technician to perform safety checks to
determine that the product is in proper
operating condition.
WALL OR CEILING MOUNTING — The product
should not be mounted to a wall or ceiling.
HEAT — The product should be situated away
from heat sources such as radiators, heat
registers, stoves, or other products (including
amplifiers) that produce heat.
English
WARNING:
WATERPROOF. TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE AND DO NOT PUT ANY
WATER SOURCE NEAR THIS APPARATUS, SUCH
AS VASES, FLOWER POTS, COSMETICS
CONTAINERS, MEDICINE BOTTLES, ETC.
THIS APPARATUS IS NOT
[For U.S. model]
IMPORTANT NOTICE
The serial number for this equipment is located
on the rear case. Please write this serial
number on your enclosed warranty card and
keep it in a secure area. This is for your
security.
H006A_En
WARNING:
Handling the cord on this product or cords
associated with accessories sold with the
product will expose you to lead, a chemical
known to the State of California and other
governmental entities to cause cancer and
birth defects or other reproductive harm.
Wash hands after handling
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/
TV technician for help.
H010_En
Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
user's right to operate the equipment.
H011_En
CAUTION:
This product satisfies FCC regulations when
shielded cables and connectors are used to
connect the unit to other equipment. To
prevent electromagnetic interference with
electric appliances such as radios and
televisions, use shielded cables and connectors for connections.
WARNING:
FOR THE FIRST TIME, READ THE FOLLOWING
SECTION CAREFULLY. THE VOLTAGE OF THE
AVAILABLE POWER SUPPLY DIFFERS
ACCORDING TO COUNTRY OR REGION. BE SURE
THAT THE POWER SUPPLY VOLTAGE OF THE
AREA WHERE THIS UNIT WILL BE USED MEETS
THE REQUIRED VOLTAGE (E.G., 230V OR 120V)
WRITTEN ON THE REAR PANEL.
BEFORE PLUGGING IN THE UNIT
H012_En
H041A_En
[For Canadian model]
CAUTION: TO PREVENT ELECTRIC SHOCK, DO
NOT USE THIS (POLARIZED) PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER
OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
ATTENTION: POUR PREVENIR LES CHOCS
ELECTRIQUES NE PAS UTILISER CETTE FICHE
POLARISEE AVEC UN PROLONGATEUR UNE
PRISE DE COURANT OU UNE AUTRE SORTIE
DE COURANT, SAUF SI LES LAMES PEUVENT
ETRE INSEREES A FOND SANS EN LAISSER
AUCUNE PARTIE A DECOUVERT.
H007A_2L
[For Canadian model]
This Class B digital apparatus complies with
Canadian ICES-003.
[Pour le modèle Canadien]
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
H009_2L
Operating Environment
Operating environment temperature and
humidity:
+5ºC – +35ºC (+41ºF – +95ºF); less than 85%RH
(cooling vents not blocked)
Do not install in the following locations
÷ Location exposed to direct sunlight or strong
÷ artificial light
÷ Location exposed to high humidity, or poorly
ventilated location
WARNING:
SUCH AS LIGHTED CANDLE, SHOULD BE
PLACED ON THE APPARATUS. IF NAKED FLAME
SOURCES ACCIDENTALLY FALL DOWN, FIRE
SPREAD OVER THE APPARATUS THEN MAY
CAUSE FIRE.
NO NAKED FLAME SOURCES,
H045_En
H044_En
VENTILATION:
When installing this unit, make sure to
leave space around the unit for ventilation
to improve heat radiation (at least 10 cm at
top, 10 cm at rear, and 10 cm at each side).
WARNING: Slot and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the product
and to protect it from overheating, to
prevent fire hazard, the openings should
never be blocked and covered with items,
such as newspapers, table-cloths, curtains,
etc. Also do not put the apparatus on the
thick carpet, bed, sofa, or fabric having a
thick pile. H040 En
[For U.S. model]
Changes or modifications not expressly
approved by the manufacturer (party
responsible) for Compliance could not void
the user’s authority to operate the equipment.
[For Canadian model]
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the device.
[Pour le mod
L'utilisation de l'appareil est soumise aux deux
conditions suivantes: (1) il ne provoque pas de
brouillage, et (2) il peut supporter tous les
brouillages, y compris ceux qui sont en
mesure de provoquer une anomalie de fonctionnement de l'appareil.
èle Canadien
]
[For Canadian model]
To prevent radio interference to the licensed
service, this device is intended to be operated
indoors and away from windows to provide
maximum shielding. Equipment (or its
transmit antenna) that is installed outdoors is
subject to licensing.
[Pour le mod
Pour éviter le brouillage radioélectrique des
émetteurs ayant une licence, cet appareil doit
être utilisé à l'intérieur des habitations et loin
des fenêtres de manière à assurer la protection maximale. Un équipement (ou son
antenne d'émission) lorsqu'il est installé à
l'extérieur ne peut être utilisé qu'après obtention d'une licence.
èle Canadien
]
Power cord caution
Handle the power cord by the plug part. Do
not pull out the plug by tugging the cord, and
never touch the power cord when your hands
are wet, as this could cause a short circuit or
electric shock. Do not place the unit, a piece
of furniture, or other object on the power cord
or pinch the cord in any other way. Never
make a knot in the cord or tie it with other
cords. The power cord should be routed so
that they are not likely to be stepped on. A
damaged power cord can cause a fire or give
you an electric shock. Check the power cord
once in a while. If you find it damaged, ask
your nearest Pioneer authorized service
center or your dealer for a replacement.
Radio wave reflections
The radio waves received by the receiver
include the wave coming directly from the
transmitter (direct wave) and waves coming
from various directions due to reflections by
walls, furniture and building (reflected
waves). The reflected waves due to obstacles
and reflecting objects further produce a
variety of reflected waves as well as variation
in reception condition depending on
locations. If the audio cannot be received
properly due to this phenomenon, try moving
the location of the wireless speaker a little.
Also note that audio may be interrupted due
to the reflected waves when a person crosses
or approaches the space between the
transmitter and wireless speaker.
We do not assume any liability for the
damages incurred due to improper use of the
product by the user or third party, malfunction
during use, other troubles or use of the
product, unless indemnity for damages is
admitted by the law.
For safety in operation
Do not use the system in the proximity of
electronic equipment that requires highaccuracy control or handling of very low-level
signals.
• The system may affect the electronic
equipment, causing malfunction or
accident. Examples of such electronic
equipment:
Hearing aid, cardiac pacemaker, other
electrical medical equipment, fire alarm,
automatic door, and other automated
control equipment.
If you use a pacemaker or other electrical
medical equipment, consult the
manufacturer or dealer to check the
effects of radio waves on it.
Do not use the system in places where its use
is prohibited, for example near aircraft
equipment and in hospitals.
• The system may affect electronic
equipment or electrical medical
equipment, causing an accident. Follow
the instructions given by the aircraft
company or medical institution.
Contents
Contents ..........................................6
What’s in the box . . . . . . . . . . . . . . . . . . . . . 6
Connecting Up ................................7
Rear panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rear panel connections . . . . . . . . . . . . . . . . 8
Placing the speakers and wireless speaker
system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Controls and Displays ..................10
Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Wireless speaker . . . . . . . . . . . . . . . . . . . . . 10
Additional Information ................13
Taking care of the unit . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . 15
Specifications. . . . . . . . . . . . . . . . . . . . . . . . 16
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Transmitter
• Wireless speaker
• AC adapter
• RCA stereo cord
• These operating instructions
• Warranty card
6
En
Connecting Up 01
Chapter 1
Connecting Up
Rear panel
Transmitter
English
R
L
IN
WIRELESS
31
Wireless speaker
1 WIRELESS IN L/R jacks
2 AC power cable
3 DC IN inlet
2
7
En
Connecting Up01
Rear panel connections
• When connecting, make sure that all components are switched off and unplugged.
1 WIRELESS IN L/R jacks
Connect the WIRELESS IN L/R jacks on the
transmitter to the PREOUT (SURROUND L/R)
jacks on the rear panel of the AV receiver
(VSX-D414), using the supplied RCA stereo
cord.
R
L
IN
WIRELESS
RL RL
SURROUND
PREOUT
L
R
2 AC power cable
Plug the AC power cable into a power outlet.
3 DC IN inlet
Connect the supplied AC adapter to the DC
IN inlet on the rear panel of the unit, then
plug into a power outlet.
To power outlet
8
En
VSX-D414
Connecting Up 01
Placing the speakers and wireless speaker system
Where you put your speakers in the room has
a big effect on the quality of the sound. The
following guidelines should help you to get
the best sound from your system.
• The illustration below shows a typical
speaker setup using the wireless speaker
for multichannel sound.
• The subwoofer can be placed on the floor.
Ideally, the other speakers should be at
about ear-level when you’re listening to
them. Putting the speakers on the floor
(except the subwoofer), or mounting
them very high on a wall is not recommended.
• For the best stereo effect, place the front
speakers 6–9 ft. / 2–3 m apart, at equal
distance from the TV.
• For best surround sound, make sure to
place the wireless speaker directly
behind the center of the listening position
and no higher than ear level.
• Install the center speaker above or below
the TV so that the sound of the center
channel is localized at the TV screen.
• To compensate for channel delay with
this system, you should adjust the surround speaker distance setting in
ing your receiver setup
(in the receiver
Choos-
manual) so that it is equal to the front
speaker distance setting.
• If you choose to install the center speaker
on top of the TV, be sure to secure it by
suitable means to reduce the risk of damage or injury resulting from the speaker
falling from the TV in the event of external
shocks such as earthquakes.
• Make sure that all speakers are securely
installed. This not only improves sound
quality, but also reduces the risk of damage or injury resulting from speakers
being knocked over or falling in the event
of external shocks such as earthquakes.
English
VSX-D414 AV receiver
Transmitter/
Front left
CHANNEL
DVD/LDDVD 5.1 TV/SATDVR/VCR
CD-R/
AM
FM
TAPE/MD
CD
ADVANCED
STEREO/
SIGNAL
MIDNIGHT/
VSB
SPEAKER
TUNING
STATION
TONE
QUICK SETUP
STANDARD
STANDBY/ON
SURROUND
DIRECT
SELECT
LOUDNESS
MODE
IMPEDANCE
MULTI JOG
LISTENING MODE
INPUT ATTFL DIMMER
TUNER EDIT
MPX MUTE
CLASS
PHONES
MULTI JOG
XW-HTD630A wireless speaker
Sub-
VSX-D514
woofer
AUDIO/VIDEOMULTI-CHANNELRECEIVER
MULTI JOG
ENTER
MASTER VOLUME
UPDOWN
Front right
Center
to power outlet
9
En
Controls and Displays02
Chapter 2
Controls and Displays
Transmitter
Wireless speaker
1
2
3
CHANNEL
4
21 3
10
TUNED
POWER
OFF
WIRELESS
MODE
ON
SURROUND
AUTO
CHANNEL
1 2 3 4
STEREO
AUTO MANUAL
VOLUME
MIN MAX
10
En
4 6
5
7 9
8
Loading...
