Philips MCD135 78 User Manual

Register your product and get support at
Registre su producto y obtenga asistencia en
Cadastre seu produto e obtenha suporte em

www.philips.com/welcome

MCD135

EN User manual 3

ES Manual del usuario 25

PT-BR Manual do Usuário 51

Contents

1 Congratulations 4

Feature introduction 4
What’s in the box 5
Overview of the main unit 6
Overview of the remote control 7

2 Important 8

Safety 8
Notice 8

3 Before use 10

Place the product 10
Install/replace the battery of
remote control 10

4 Connect 11

Connect speakers 11
Connect TV 11
Connect a USB storage device 12
Connect power 12

5 Get started 13

Turn on 13
Set the clock 13
Find the correct viewing channel 13
Select the correct TV system 13
Select a language for on-screen-display
messages 13

8 Setup 19

Interface for setup menu 19
Change a setting 19
System setup 19
Language setup 20
Audio setup 20
Video setup 20

9 Product information 20

Specifications 20
Supported disc formats 21
USB playability information 21

10 Troubleshooting 22

English

6 Play 14

Basic operation 14
Play a disc 14
Play recored files 14
Play control 16

7 Other features 17

Listen to FM radio 17
Play audio from an external device 18
Listen through headphone 18
Turn on/off automatically 18

EN

3

1 Congratulations

Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
back of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________

Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.

Caution

Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.

Feature introduction

This product can play videos and audios, and
display pictures from discs and USB storage
devices.
For the details of supported media, refer to
“Specifications”.

Recordable

ReWritable

This apparatus includes this label:

Class II equipment symbol:

This symbol indicates that this product has a
double insulation system.

4

EN

DVD region code Countries

Latin America

Sound effect

This product supports the sound output by
DSC (Digital Sound Effect) and DBB (Dynamic
Bass Boost).

What’s in the box

Check and identify the contents of your
package:

Main unit•
2 speakers•
Remote control•
Audio and video cables (white, red and •
yellow connectors)
USB cable (100 mm)•
Power cord•
User manual•
Quick star t guide•

To fully enjoy the features of this product, you
need the following cables.

MP3 link cable (3.5 mm plug)•
Component video cables •

Contact local retailers to purchase these
additional cables.

English

EN

5

Overview of the main unit

g

o

n

m
l

k

j

i
h

a

b
c

d

e

f

a

Eject or close the disc compartment. •

b IR sensor
c LCD display
d Disc compartment
e VOLUME

Increase/decrease the volume level. •

f Pull to open
g

Connect a USB storage device. •

h MP3 LINK

Connect an MP3 link cable (3.5 mm plug). •

6

EN

i

Socket for headphones. •

j

Start, pause or resume the play. •

k

/

Skip to the previous or next title, •
chapter, track, or file.
Search fast backward or forward. •

l

Stop the play.•

m SOURCE

Select a media source (disc, USB •
storage device, FM tuner, or external
device connected through MP3 link
cable).

n DBB

w

t
s

q

r

o

p

u

v

Enable or disable the DBB (Dynamic •
Bass Boost) feature.

o

Turn on or off the unit.•
Switch to standby mode. •

Overview of the remote control

x

OK

DSC

VOL

PROG

2

1

5

4

8

7

0

MUTE

3

6

9

e SLEEP/TIMER
f

/

g /
h DBB
i VOL +/-
j MUTE
k AUDIO
l ZOOM
m SUBTITLE

a

b

c

d
e

f

g

h

i

j

k

l

m
n

n GOTO
o ANGLE/PROG
p Numeric buttons
q
r /
s
t DSC
u OK
v REPEAT A-B
w SYSTEM MENU
x MODE

English

a
b Source selection keys
c DISPLAY/CLOCK
d DISC MENU

EN

7

2 Important

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects filled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.

Sound can be deceiving. Over time your •
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfortably and clearly, without
distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even •
at normally ‘safe’ levels, can also cause
hearing loss.
Be sure to use your equipment •
reasonably and take appropriate breaks.

Be sure to observe the following guidelines
when using your headphones.

Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as •
your hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.

8

EN

Notice

This product complies with the radio
interference requirements of the European
Community.
