Philips LFH612, LFH617, LFH632, LFH633 User Manual

Register your product and get support at
www.philips.com/welcome
EN User manual
LFH0612
LFH0617
LFH0632
LFH0633
Table of contents
1Welcome 3
Product highlights 3
Safety 4 Hearing safety 4 Disposal of your old product 4
3 Your Voice Tracer digital recorder 5
Whatʹs in the box? 5 Overview 6
4Get started 7
Insert the battery 7 Power on/off 7 Keypad lock (HOLD function) 7 Using the Voice Tracer with a computer 8
5Record 9
Record with the built-in microphone 9 Record with an external microphone 10 Add index marks 10
6 Playback 11
Playback of a recording 11 Playback functions 11 Repeated playback 12
7 Delete 13
Deleting files and index marks 13
8 Customize settings 14
9 Update the firmware 16
10 Frequently asked questions 17
11 Technical data 18
Table of contents 2
1Welcome
Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, visit our Website for support information such as user manuals, software downloads, warranty information and more:
www.philips.com
Product highlights
• ClearVoice – for dynamic enhancement of quiet recording passages giving excellent speech intelligibility
• Instant one-touch recording – from power off to recording with a single key press
• Record in the popular MP3 format
• Speedily transfer recordings and data via high-speed USB 2.0
• Voice-activated recording for hands-free note taking
• USB mass storage ensures maximum compatibility
• Organize recordings quickly and easily with four file folders
Table of contents
Wel co me 3
2Important
Safety
• To avoid a short circuit, do not expose the product to rain or water.
• Do not expose the device to excessive heat caused by heating equipment or direct sunlight.
• Protect the cables from being pinched, particularly at plugs.
• Back up your files. Philips is not responsible for any loss of data.
Hearing safety
Observe the following guidelines when using your headphones:
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume higher as your hearing adapts.
• Do not turn up the volume so high that you can’t hear what’s around you.
• You should use caution or temporarily discontinue use in potentially hazardous situations.
• Do not use headphones while operating a motorized vehicle, cycling, or skateboarding, etc. It may create a traffic hazard and is illegal in many areas.
Important (for models supplied with headphones):
Philips guarantees compliance with the maximum sound power of its audio players as determined by relevant regulatory bodies, but only with the original model of provided headphones. If these headphones need replacement, we recommend that you contact your retailer to order a Philips model identical to that of the original.
Disposal of your old product
• Your product is designed and manufactured with high quality materials and components that can be recycled and re-used.
• When this crossed-out wheeled bin symbol is attached to a product, it indicates that the product is covered by the European Directive 2002/96/EC.
• Become informed about your local separate collection system for electrical and electronic products.
• Act according to your local rules and do not dispose of old products with normal household waste. The correct disposal of old products will help prevent potential negative consequences for the environment and human health.
• Batteries (including built-in rechargeable batteries) contain substances that may pollute the environment. All batteries should be disposed of at an official collection point.
Table of contents
Important 4
3 Your Voice Tracer digital recorder
Digital
recorder
battery
1 × AAA
Quick start guide USB cable
Hands-free headset (LFH0632/LFH0633 only)
Whatʹs in the box?
LFH0612
LFH0617
LFH0632
LFH0633
LFH0642
LFH0646
LFH0652
Quick start guide
Register your product and get support at
www.philips.com/welcome
Table of contents
Your Voice Tracer digital recorder 5
Overview
MENU
j/DEL
g
INDEX/ a
Record/ play indicator Display Hold switch Index, Folder, Repeat (INDEX/ a) Fast rewind, File selection, Set menu option (h) Menu (MENU) Power on/off, Play/Pause, Play speed (f ) Speaker Strap hole Volume up, Menu item selection (+) Record, Pause, Power On (g) Fast forward, File selection, Set menu option (b) Stop, Display, Delete (j / DEL) Volume down, Menu item selection (–) Microphone jack (MIC) USB socket Headphones jack (EAR) Integrated microphone
123
456
789
101112131415161718
5
2
1
3
4
6
7
9
8
14
13
12
11
10
15
16
17
18
f
Table of contents
Your Voice Tracer digital recorder 6
