Philips Institutional Television User Manual

Installing the TV

• Place your TV on a stable and strong base.

• Leave at least a free pace of 5 cm on both
sides and 10 cm from the top for good
ventilation of the set.

• Do not cover the ventilation openings with
items such as newspapers, cloths etc.

Connecting the mains

Insert the main plug into the wall socket and
switch on. Please refer to the specification at
the back of the TV for the correct operating
voltage.

Installing the remote control

• Remove the cover at the back of the remote
control.

• Insert the correct type and size batteries into
the compartment making sure they are the
right way around.

• You can secure your batteries by fastening
an appropriate screw into the hole of the
battery cover.

Tips and Alerts

• Never try repairing the set by yourself,
always contact a qualified technician.

• Your TV contains material which can be
recycled and reused by specialized
companies. Please find out about local
regulations on the disposal of your old TV
set.

• TV consumes energy in the stand-by mode.
Energy consumption contributes to air and
water pollution. We advise you to switch off
your TV overnight instead of leaving it in
stand-by mode.

Accessing the Set-up Menu

Accessing the Set-up Menu, while the set is in
the Security High state, can only be done by a
T374AH Institutional Setup remote Menu
command. While the set is in the Security
Standard State the Setup Menu may be
accessed with a normal guest cursor remote
control by a sequence of numbers
(319753MUTE).

• Language

The Language function is shown in the
Menu as "LANGUAGE", and its valid states
are "ENGLISH", "DEUTSCH", "FRANCAIS",
"ITALIANO".

• No. of Programs

This item of the Setup Menu is activated by
highlighting the item using the cursor
up/down keys, then pressing the cursor right
key. Number of TV, Pay TV, Radio and Info
programs can be set and stored.

• TV Installation

When this menu is open, all the protections
are inactive. To exit any menu press Menu
button.

Input

The "Input" menu item selects the desired
input source that will be assigned to the
program. Possible values are Front End,
AV1, and AV2YC (internal interface, for
system TVs only).

System

Sets for East regions will have 2 states,
WEST EU (PAL/SECAM-BG) and EAST
EU (PAL/SECAM-DK).
Sets for West regions will have 3 states,
WEST EU (PAL/SECAM-BG), UK (PAL-I),
FRANCE (SECAM-L/L').

Manual Search

3 digits can be entered for a frequency in
MHz or right cursor for auto search;
during frequency entry the not yet entered
digits are displayed as dashes "-".

Program no.

The programme type can be selected with
the cursor left/right buttons. These
buttons will toggle between all available
types: "TV", "INFO", "PAY-TV"; if the radio
is external (no radio tuner is present in
the chassis), "RADIO" is displayed, if the
radio is internal there will be a separate
radio installation menu. If the program
number of a certain type is 0, the
corresponding type is not displayed.

1

PHILIPS Institutional TV - Instructions for use

GB

Store

The present program information, is
stored after pressing the cursor left/right
button. Press Menu to exit without storing.

Fine Tune

Using the "control left/right" commands
starts fine-tuning.

Protection

This bit indicates whether the selected
program has a protection or not. With the
cursor left/right keys the protection can
toggle between "ON" and "OFF".

Label

This menu item will be used to add a
label/name for each program. Pressing
the left/right buttons you may enter or exit
the label field; pressing the up/down
cursor you may insert alphanumeric
characters.

Teletext Language

This menu enables the user to select the
teletext character set to be used for the
selected channel. With cursor left/right
you can select a letter corresponding to
the different language clusters.

Video Blank

This item can change between "ON" and
"OFF" to indicate if a picture mute is
necessary.

Audio Mute

This item can change between "ON" and
"OFF" to indicate if a sound mute is
necessary.

Remarks

TV up/down, INFO up/down, PAY-TV
up/down and RADIO up/down are active in
menu mode and the TV reacts the same
way as in TV mode.

• Radio Installation (if radio present)

This menu appears only if an internal radio
is installed. The following subset of the TV
installation menu items is displayed and has
the same functionality: search, program,
label, protection, store, exit. The frequency
range for internal radio is 87.50 - 108.00
MHz FM. Beside program "RAD XX"
appears, where XX is the selected program
number; the type is RAD and is not
selectable.

Search

The Search function is activated by
pressing the "+" or Cursor Right button
via the local keyboard or remote control.

Program

The user can cursor down to the
"Program" menu item until it is highlighted
and select a program number via the
Digits, Cursor Right, or Cursor Left
commands.

Protection

This menu item will be used to "Protect"
or "Lock" each program individually.

Label

This menu item will be used to add a
label/name for each program.

Store

This menu item is used to store the
information displayed in the Radio
installation sub menu.

• Clock Installation (if clock present)

The Clock Installation menu is displayed
when the Clock Installation menu item is
selected by highlighting the Clock
Installation menu item with either Cursor Up
or Cursor Down.

Display Standby

This menu item will be used to set the
intensity of the display of the clock when
the TV is in standby mode.

Display On

This menu item will be used to set the
intensity of the display of the clock when
the TV is in the On mode.

Time Setting

This menu item will be used to set the
time for the clock.

Teletext Downloading

This menu item will be used to activate or
deactivate the time downloading function.

Teletext Program

This menu item will be used to select the
channel from which to retrieve the correct
time from the teletext. When this item is
selected the TV set tunes to the selected
program.

2
