Always there to help you

GC4880 series

User manual

4239 000 99812

3 4

g h i

ENGLISH 6

РУССКИЙ 12 УКРАЇНСЬКА 18

TÜRKÇE 24

ҚАЗАҚ 30

GC4880 series

6 ENGLISH

Introduction

Congratulations on your purchase and welcome to Philips! To fully beneﬁt from the support that Philips oers, register your product at www.philips.com/welcome.

Product overview (Fig. 1)

1 Spray nozzle 2 Water ﬁlling door 3 Spray button 4 Steam slider a. Dry setting ( )

b. ECO setting ( c. MAX setting ( ) 5 Steam boost trigger

6 Safety auto-o light (speciﬁc types only) 7 Mains cord 8 Temperature indicator light 9 Water tank 10 Temperature dial 11 Calc clean button 12 Soleplate 13 Quick Calc Release lock 14 Quick Calc Release tray 15 Typeplate

ECO

)

Important

Read the separate important information leaet and this user manual carefully before you use the appliance. Keep both documents for future reference.

Using the appliance

Filling the water tank

Note: Your appliance has been designed to be used with tap water. If you live in an area with hard water, fast scale build-up may occur. Therefore, it is recommended to use 100% distilled or demineralized water to prolong the lifetime of your appliance.

1 Open the water lling door. 2 Tilt the iron backwards and ll the water tank with tap

water up to the maximum level.

Note: Do not fill the water tank beyond the MAX indication.

ENGLISH 7

Do not put perfume, vinegar, starch, descaling agents, ironing aids or other chemicals in the water tank.

3 Close the water lling door ( ‘click’).

Temperature and steam setting

Table 1:

Warning: Do not use steam or steam boost at low temperature, as indicated in the below table. Otherwise, hot water may leak from the iron.

Fabric type Temperature

setting

Linen MAX Cotton ●●● Yes Wool ●● Silk ●● No Synthetic

fabric (e.g. acrylic, nylon, polyamide, polyester)

1 Refer to Table 1 to set the temperature dial to the

appropriate setting for your garment.

2 Refer to Table 1 to set the appropriate steam setting for

your garment.

Note: Make sure that the steam setting you select is suitable for the set ironing temperature.

3 Put the iron on its heel and plug it in. The temperature

light goes on to indicate that the iron is heating up.

4 When the temperature light goes out, the iron has reached

the correct temperature and you could start ironing.

● No

Steam setting

/ ECO

ECO

Steam boost

Yes

ENGLISH8

Features

Spray function

- Press the spray button to moisten the article to be ironed.

This helps to remove stubborn creases.

Steam boost function

- Use steam boost function at a temperature dial setting

between ●●● to MAX.

- Press and release the steam boost trigger for a powerful

boost of steam to remove stubborn creases.

Ironing with extra steam

- For extra steam during ironing, press and hold the steam

boost trigger.

Vertical steam

- You can use the steam boost function when you hold the iron in vertical position for removing creases from hanging clothes, curtains etc.

ECO steam setting / Dry ironing

- You could choose ECO setting in the steam slider to save energy, yet to achieve satisfactory ironing results.

- To iron without steam, select dry setting in the steam slider.

ENGLISH 9

Safety auto-o (specic types only)

The safety auto-o function automatically switches o the iron if it has not been used for 30 seconds resting on its soleplate or 8 minutes resting on its backplate. The auto-o light will light up.

- To let the iron heat up again, pick up the iron or move it slightly. The auto-o light goes out.

Cleaning and maintenance

Cleaning

1 Unplug the iron and let it cool down. 2 Pour any remaining water out of the water tank from the

water lling door.

3 Wipe akes and any other deposit o the soleplate with a

damp cloth and a non-abrasive (liquid) cleaning agent.

To keep the soleplate smooth, avoid hard contact with metal objects. Never use a scouring pad, vinegar or other chemicals to clean the soleplate.

Quick Calc Release

IMPORTANT: To prolong the life time of your appliance and to maintain good steaming performance, use Quick Calc Release function once every 1 month. If water in your area is very hard, use this function more frequently.

Note: Make sure that the iron has been unplugged for at least 1 hour and has completely cooled down, before you use Quick Calc Release.

1 Put the iron on a levelled surface and push up the Quick

Calc Release lock at the back of the iron.

2 Take out the Quick Calc Release tray. 3 Pour out scales in the tray into a sink or dustbin. Clean the

tray using tap water. Remove any excess water from the tray.

ENGLISH10

Do not pour water, vinegar, descaling agents or other chemicals into the iron from the opening of the Quick Calc Release.

Do not use vinegar, descaling agents or other chemicals to wash the tray.

4 Wipe o the scales in the opening of the Quick Calc

Release tray with a damp cloth.

5 Insert the tray back into the iron. 6 Push down the Quick Calc Release lock.

Do not use the iron when the Quick Calc Release tray is not locked.

If you break or lose the tray, contact a consumer care center in your country (see the worldwide guarantee leaet for contact details).

Calc-clean function

IMPORTANT: Besides Quick Calc Release function, you should also perform calc-clean once every 1 month to prolong the life of your iron. If water in your area is very hard, or you see scales coming out from the soleplate during ironing, use this function more frequently.

1 Make sure the iron is unplugged and the steam slider is set

to dry setting.

2 Fill the water tank to the MAX indication.

Do not pour vinegar or other descaling agents into the water tank.

3 Plug in the iron and set the temperature dial to MAX. 4 Unplug the iron when the temperature light goes out. 5 Hold the iron over the sink. Keep pushing the calc clean

button and gently shake the iron forth and back until all water in the water tank has been used up.

Scales is ushed out, steam and boiling water also come out of the soleplate.

Note: Repeat steps 2 to 5 if the water that comes out of the iron still contains scale particles.

6 Take out the Quick Calc Release tray, empty the water in

the tray. Hold the iron vertically to allow small amount of water to ow out.

7 Insert the tray back to the iron and lock it. 8 Plug in the iron and let the iron heat up to dry the soleplate. 9 Unplug the iron when the temperature indicator light goes out. 10 Move the iron gently over a piece of cloth to remove any

water stains on the soleplate.

Storage

1 Unplug the iron and empty the water tank. Let it cool

down in a safe place.

2 Wind the mains cord around the backplate of the iron and

store it on its heel.

Troubleshooting

This chapter summarises the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/ support for a list of frequently asked questions or contact the Consumer Care Centre in your country (see the worldwide guarantee leaet for contact details).

Problem Possible cause Solution

ENGLISH 11

The steam boost function does not work properly (water leaks out of the soleplate).

Flakes and impurities come out of the soleplate during ironing.

Water leaks from the water ﬁlling door.

Water or steam leaks from the back part of the iron.

You have used the steam boost function too often within a very short period.

You have used the steam boost function at a too low temperature.

Scales are formed inside the soleplate.

You have overﬁlled the water tank.

You have not locked the Quick Calc release tray properly.

The Quick Calc release tray is damaged.

Wait for a few seconds before you use the steam boost function again.

Set an ironing temperature at which the steam boost function can be used (●●● to MAX).

Use the Calc-clean function (see chapter ‘Cleaning and maintenance’, section ‘Calcclean function’).

Do not ﬁll the water tank beyond the MAX indication. Pour excess water out of the water tank.

Take out the Quick Calc Release tray and clean it using tap water. Use a piece of cloth to wipe o scales in the opening of the back part of the iron. Put back the tray and lock it. (See chapter ‘Cleaning and maintenance’, section ‘Quick calc release function’).

Contact a consumer care center in your country (see the world wide guarantee leaet for contact details).

12 РУССКИЙ

Введение

Поздравляем с покупкой и приветствуем в клубе Philips! Чтобы воспользоваться всеми преимуществами поддержки Philips, зарегистрируйте продукт на веб-сайте www.philips.com/welcome.

Описание изделия (рис. 1)

1 Разбрызгиватель 2 Дверца наливного отверстия 3 Кнопка разбрызгивателя 4 Переключатель режимов подачи пара a. Глажение без пара ( )

b. Режим ECO ( c. Режим MAX ( ) 5 Кнопка парового удара

6 Индикатор автовыключения (только некоторые модели) 7 Сетевой шнур 8 Индикатор нагрева 9 Резервуар для воды 10 Дисковый регулятор нагрева 11 Кнопка очистки от накипи 12 Подошва 13 Фиксатор системы быстрой очистки от накипи 14 Подставка системы быстрой очистки от накипи 15 Табличка

ECO

)

Важно

Перед использованием прибора внимательно ознакомьтесь с буклетом с важной информацией и данным руководством пользователя. Сохраните эти документы для дальнейшего использования в качестве справочного материала.

Использование прибора

Заполнение резервуара для воды

Примечание. Прибор подходит для использования с водопроводной водой. Если вода в вашем регионе очень жесткая, в приборе может быстро образовываться накипь. Поэтому для продления срока службы прибора рекомендуется использовать дистиллированную или деминерализованную воду.

1 Откройте дверцу наливного отверстия. 2 Наклоните утюг назад и наполните резервуар водопроводной

водой до отметки максимального уровня.

Примечание. Не заполняйте резервуар для воды выше отметки максимального уровня (MAX).

РУССКИЙ 13

Не добавляйте в резервуар для воды духи, уксус, крахмал, химические средства для удаления накипи, добавки для глажения или другие химические средства.

3 Закройте дверцу наливного отверстия (должен прозвучать

щелчок).

Выбор температурного режима и режима подачи пара

Таблица 1.

Предупреждение. Не используйте функцию парового удара или глажение с паром при низкой температуре (см. таблицу ниже). В противном случае из утюга может начать вытекать горячая вода.

Тип ткани Настройка

температуры

Лен MAX

Хлопок ●●● Да

Шерсть ●●

Silk ●● нет

Синтетические ткани (например, акрил, нейлон, полиамид, полиэстер)

1 Чтобы выбрать температурную настройку, подходящую для

конкретного типа ткани, ознакомьтесь с таблицей 1.

2 Чтобы выбрать настройку пара, подходящую для конкретного

типа ткани, ознакомьтесь с таблицей 1.

Примечание. Убедитесь, что выбранный режим подачи пара соответствует установленной температуре глажения.

3 Поставьте утюг вертикально и подключите к сети. Загорится

индикатор нагрева. Это значит, что утюг нагревается.

4 Если индикатор нагрева погас, значит, утюг нагрелся до заданной

температуры, можно начинать глажение.

● нет

Режим подачи пара

/ECO

Экорежим

"Паровой удар"

Да

нет
