Philips FW-V55/21 User Manual

FW-
V55
VCD Mini Hi-Fi System
Video CD version 2
pg 01-28/V55/21-En 6/8/01, 9:11 AM1
3139 115 20042
English
Melayu
Optimum disc playability : ensuring excellent picture quality
Philips components and modules for the various CD applications have always enjoyed an excellent reputation in the market place for super disc playability - the ability to play discs which may be scratched, soiled or not fully according to the standard specification. This position has been underlined by tests showing the superior performance of the various Philips players, as well as by the positive experiences of millions of individual consumers around the world.
Constantly improving performance
As the penetration of the CD system has increased, and new applications like CD­ROM and Video CD have become commonplace, Philips Components - as the CD technology inventor and as one of the major suppliers of CD player modules in the industry - has constantly improved the performance of its products.
One of the ways in which this benefits users is by optimum disc playability. This is an important parameter for CD players other than CD Audio, and especially for the Video CD applications, because any loss of data from the disc will at best cause disturbances in the reproduced picture, and at worst can cause the player to lose track so that disc playing fails.
Presenting Super Error Correction
To ensure consistently good results when playing Video CD discs of all quality grades and conditions, Philips has introduced further improvements in the system's playability. These developments together are called Super Error Correction, a proprietary Philips technology optimizing the system's ability to handle less-than­perfect discs with the minimum disturbance to normal playing.
By effectively eliminating virtually all errors arising under normal playing conditions, Super Error Correction ensures that the picture quality as seen by the user is independent of disc play. The video encoding and processing during mastering of the disc, and the MPEG-1 decoding and video encoding in the signal processing stages, are now the only limiting factors for picture quality.
2
pg 01-28/V55/21-En 6/8/01, 9:11 AM2
® ErCoS is a registered trademark of Philips Electronics N.V.
3139 115 20042
CLASS 1
LASER PRODUCT
English .....................................4
.................................................29
English
Bahasa Melayu ....................53
Melayu
3
pg 01-28/V55/21-En 6/8/01, 9:11 AM3
3139 115 20042
English
4
pg 01-28/V55/21-En 6/8/01, 9:11 AM4
3139 115 20042
CONTENTS GENERAL INFORMATION SAFETY INFORMATION
General Information ................. 5
Safety Information .................... 5
Preparation .......................... 6 - 7
Controls ............................... 8 - 10
Operating The System .... 11 - 13
CD / VCD / MP3-CD ......... 13 - 18
Tuner .................................. 19 - 20
Tape ................................... 20 - 21
AUX/CDR ...................................22
Karaoke ..................................... 22
Recording ......................... 23 - 24
Clock ................................. 24 - 25
Timer..........................................25
Specifications ......................... 26
Maintenance ............................ 27
Troubleshooting .............. 27 - 28
IMPORTANT:
PLEASE NOTE THAT THE
VOLTAGE SELECTOR
LOCATED AT THE REAR OF
THIS SYSTEM IS PRESET AT
220V FROM THE FACTORY.
FOR COUNTRIES THAT
OPERATE AT 110V, PLEASE
ADJUST TO 110V BEFORE YOU
SWITCH ON THE SYSTEM.
General Information
• The type plate (which contains the serial number) is located at the rear of the system.
• Recording is permissible if copyright or other rights of third parties are not infringed.
Environmental Information
All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).
Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
Accessories
Remote controlBatteries (two AA size) for remote
control
AM loop antennaFM wire antennaAC power cordOne Video cinch cable
(Supplied)
Safety Information
Before operating the system, check that the operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer. The typeplate is located at the rear of your system.
When the system is switched on, do not move it around.
Place the system on a solid base (e.g. a cabinet).
Place the system in a location with adequate ventilation to prevent internal heat build-up in your system. Allow at least 10 cm clearance from the rear and the top of the unit and 5 cm from each side.
Do not expose the system to excessive moisture, rain, sand or heat sources.
• Under no circumstances should you repair the system yourself, as this will invalidate the warranty!
• If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens of the disc unit inside the system. Should this occur, the disc player will not operate normally. Leave the power on for about one hour with no disc in the system until normal playback is possible.
• Electrostatic discharge may cause unexpected problems. See whether these problems disappear if you unplug the AC power cord and plug it in again after a few seconds.
• To disconnect the system from the power supply completely, remove the AC power plug from the wall socket.
English
5
pg 01-28/V55/21-En 6/8/01, 9:11 AM5
3139 115 20042
PREPARATION
English
Rear Connections
A AM Loop Antenna
Connection
STANDBY ON
E
V
L
E
R
L
E
F
C
O
O
N
O
T
W
R
B
O
U
L
S
MIN MAX
CUT OFF FREQUENCY
HIGH POWER SUBWOOFER
60Hz 150Hz
F
AUDIO OUT
Connect the supplied loop antenna to the AM ANTENNA terminal. Place the AM loop antenna far away from the system and adjust its position for the best reception.
W
H
A
J
I
L
surr.
D
6
pg 01-28/V55/21-En 6/8/01, 9:11 AM6
VIDEO
OUT
AC
MAINS
~
VOLTAGE SELECTOR
R
surr.
G
B FM Wire Antenna
Connection
Connect the supplied FM wire antenna to
E
AUDIO IN
LRLR
SUB-
WOOFER
AUX/CDR IN
OUT LINE OUT
FM ANTENNA 75
AM ANTENNA
REAR SURROUND
+
L
– –
R
+
110V­127V
220V­240V
FRONT
+
L
– –
R
+
B
LR
C
the FM ANTENNA 75 terminal. Adjust the position of the FM antenna for the best reception.
Outdoor Antenna
For better FM stereo reception connect an outdoor FM antenna to the FM ANTENNA 75 terminal using a 75 coaxial wire.
C Speakers Connection
Connect the right speaker to Front terminal R, with the colored wire to + and the black wire to -.
Connect the left speaker to Front terminal L, with the colored wire to + and the black wire to -.
Clip the stripped portion of the speaker wire as shown.
12 mm
unlock
lock
3139 115 20042
PREPARATION
CAUTION:
– For optimal sound performance, it is
recommended to use the supplied speakers.
– Do not connect more than one speaker
to any one pair of +/- speaker terminal.
– Do not connect speakers with
impedance lower than the speakers supplied. Please refer to SPECIFICATION section of this manual.
D Rear Surround Speakers’
Connection
Connect the optional Rear Surround Speakers to the REAR SURROUND terminals. Be sure to follow the instructions supplied with the Rear Surround Speakers.
E Line Out Connection
ready)
You can connect the audio left and right LINE OUT terminals to a optional CD Recorder ANALOG IN terminals. This allows you to record in an analog format.
You can also install additional optional front active speakers away from the system (e.g. in another room) to reduce the inconvenience of running long speaker wires across rooms. You can place as many remote speakers as you like provided they operate at the same radio frequency.
(wireless
Connect the wireless radio frequency transmitter to the LINE OUT terminals. Place the active speakers at your preferred location. Be sure to follow the instructions supplied with the active speakers.
Note: – Availability of wireless transmitter and
its peripherals are subjected to the approval of local authorities. Please check with respective local safety or approving authority.
F Connecting other
equipment to your system
You can connect the audio left and right OUT terminals of a TV, VCR, Laser Disc player, DVD player or CD Recorder to the AUX/CDR IN terminals at the rear of the system.
G Subwoofer Out Connection
Connect the optional active subwoofer to the SUBWOOFER OUT terminal. The subwoofer reproduces just the low bass sound effect (e.g. explosions, the rumble of spaceships, etc.). Be sure to follow the instructions supplied with the subwoofer.
H Video Out Connection
Connect the VIDEO OUT terminal at the rear of the system to the TV or VCR VIDEO IN for viewing or recording.
I Adjusting the Operating
Voltage
(for specific version only))
Before connecting the AC power cord to the wall outlet, make sure that the voltage selector at the rear of the system is set to the local power line voltage. If not, reset the selector before connecting to the wall outlet.
J AC Power Supply
After all other connections have been made, connect the AC power cord to the system and to the wall outlet.
Inserting batteries into the Remote Control
Insert the batteries (Type R06 or AA) into the remote control as shown in the battery compartment.
To avoid damage from possible battery leakage, remove dead batteries or batteries that will not be used for a long time. For replacement, use type R06 or AA batteries.
English
7
pg 01-28/V55/21-En 6/8/01, 9:11 AM7
3139 115 20042
CONTROLS
English
# @
DISC CHANGE
DISC 1 DISC 2 DISC 3
OPEN•CLOSE
$
!
0
1
9 8
7
6
5
4
3 ≥
§
VCD
3
CHANGER
VCD MINI HIFI SYSTEM
STANDBY ON
CLOCK/ TIMER
D
U
B
(H
S
D
)
R
E
C
PROG
PROGRAM REPEAT
NEWS
T.A.
MP3•CD
CD1 • 2 • 3
-
SHUFFLE
REC
TIMER
LW
AM
MW
FM
60Hz
250Hz
500Hz
BAND
TUNER AUX
STOPCLEARSEARCH TUNING
ALBUM
+
SOUND NAVIGATION
INCREDIBLE SURROUND
DIGITAL
SOUND CONTROL
STEREO
8KHz
4KHz
2KHz
1KHz
CDR/VIDEO
TAPE 1 • 2
TAPEVCD
PLAY PAUSE PREV NEXT
MP3-CD
-
DYNAMIC BASS BOOST
TITLE
PRESET
BACK FRONT
HSD
A. REV
SIDE
+
MP3-CD
PLAYBACK
PBC
RETURN
LEVEL
%
%
^
OSD
VCD.CD 1/2/3
1
4
7
& *
(
MIC
MIC
)
¡ ™
£
8 ™ (
(
3 £
& *
ª
º
TITLE
-
í
à
ALBUM
-
DBB DSC
PBC RETURN
ZOOM
VOCAL
AUX
2
5
8
0
VOLUME
ÅÉ
Ç
IS
RESUME
-
KEY CONTROL
TUNER
DIGEST
2
TAPE 1/2
3
6
9
REPEATPROG
TITLE
ë
á
ALBUM
+
A-B
SLOW
Ö
ECHO
+
#
·
°
+
( 2
fl fi
‹ ¤
2
8
pg 01-28/V55/21-En 6/8/01, 9:11 AM8
3139 115 20042
CONTROLS
Controls on the system and remote control
1 STANDBY ON
– to switch the system on or to standby
mode.
– to use for EASY SET.
2 DIGITAL SOUND CONTROL (DSC)
– to select the desired sound effect :
OPTIMAL, CLASSIC, TECHNO, JAZZ, ROCK or VOCAL.
3 INCREDIBLE SURROUND
– to switch on or off the surround sound
effect.
4 n
to connect headphones.
5 REC (RECORD)
to start recording on tape deck 2.
6 DUB (HIGH SPEED DUBBING
[HSD])
to dub a tape in normal or fast speed.
7 JOG
to select the desired equalizer display.to select the desired DSC setting. You
must select the DSC feature first.
– to select the desired level of
Incredible Surround Sound. You must select the Incredible Surround Sound feature first.
8 PROGRAM (PROG)
for VCD/CD/MP3-CDto program
disc tracks.
for TUNER ..... to program preset radio
stations.
for CLOCK ..... to select 12 or 24 hour
9 CLOCK/TIMER
– to view the clock, set the clock or set
the timer.
0 DISPLAY SCREEN
– to view the current setting of the
system.
! DISC CAROUSEL TRAY @ DISC 1 / DISC 2 / DISC 3
(DISC DIRECT PLAY)
to select a disc tray for playback.
# DISC CHANGE
to change disc(s).
$ OPENCLOSE
to open or close the disc carousel tray.
% SOURCE – to select the following:
VCD / (CD 123) / (MP3CD)
– to select VCD/CD/MP3 mode. When
VCD/CD/MP3-CD playback is stopped, press to select the disc tray 1, 2 or 3.
Adjusting the TV System
– to select corresponding PAL or NTSC
system of your TV set (exception Multi-system TV).
TUNER / (BAND)
– to select Tuner mode. When in tuner
mode, press to select the waveband: FM or MW.
TAPE / (TAPE 1 2)
– to select Tape mode. When tape
playback is stopped, press to select either tape deck 1 or 2.
in clock setting mode
(on the system only)
.
AUX / (CDR/VIDEO)
– to select sound from an external
source (e.g. TV, VCR, Laser Disc player, DVD player or CD Recorder). When in Aux mode, press to select either AUX or CDR.
^ A. REV (AUTO REVERSE)
available in tape deck 2 only.to select the desired play modes
( å / / ).
& PBC (PLAYBACK CONTROL)
– to switch on or off PBC mode
(for VCD
version 2.0 only).
* RETURN
– for VCD with PBC on to return to the
previous MENU level during playback
(for VCD version 2.0 only).
( MODE SELECTION
SEARCHTUNING à á (ALBUM
for MP3-CD onlyto select previous/
for VCD onlyto move the zoom
for VCD/CD/MP3-CDto search
for TUNER ..... to tune to a lower or
for TAPE ........ to rewind or fast
for CLOCK ..... to set the hour
--
++
-/
+)
--
++
next Album at stop mode
picture to the left or right.
backward/forward during playback.
higher radio frequency.
forward a tape.
system only)
(on the
.
STOPCLEAR Ç
for VCD/CD/MP3-CDto stop disc
for TUNER ..... to stop programming.
for TAPE ........ to stop playback or
for DEMO ......
PLAY PAUSE ÉÅ
for VCD/CD/MP3-CDto start or
for VCD onlyto watch a still picture.
for TAPE ........ to start playback.
PREV í / SIDE / NEXT ë (PRESET 43 ) (TITLE
for MP3-CD onlyto select previous/
for VCD onlyto move the zoom
for VCD with PBC on ..........................
...................... to select next or
...................... to select next or
for VCD/CD ... to skip to the previous,
for TUNER ..... to select a preset
for TAPE ........ to select tape side
playback or to clear a program.
recording.
(on the system only)
start or stop demonstration mode.
interrupt playback.
--
++
-/
+)
--
++
next Title.
picture down or up.
previous MENU.
previous VCD track during playback.
or next track.
station in memory.
(back or front) in tape deck 2 only.
to
English
9
pg 01-28/V55/21-En 6/8/01, 9:11 AM9
3139 115 20042
