Philips FW-C30, FW-C3 User Manual

Download

C35

FW-

C30

avec Changeur de 3 CD

Mini Hi-Fi Systems

Toll Free Help Line

Ligne d'assistance en service libre Linea de ayuda telefónica sin cargo

800-531-0039

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM1

3139 116 19372 (ENG)

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Return your Warranty Registration card today to

ensure you receive all the benefits you’re entitled to.

• Once your Philips purchase is registered, you’re eligible to receive all the privileges of owning a Philips product.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your Philips warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Know these

ssaaffeettyy

This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical shock. For the

t s

safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.

symbols

• So complete and return the Warranty Registration Card enclosed with your purchase at once. And take advantage of these important benefits.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

For Customer Use

Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.

Model No. _______________________________

Serial No. ________________________________

WARNING:

HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION:

blade of plug to wide slot, and fully insert.

TO PREVENT FIRE OR SHOCK

To prevent electric shock, match wide

MAC5097

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM2

3139 116 19372 (ENG)

Visit our World Wide Web Site at http://www.philipsusa.com

Congratulations on your purchase, and welcome to the “family!”

Dear Philips product owner:

Thank you for your confidence in Philips.You’ve selected one of the best-built, best-backed products available today.And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the Philips “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

•

Hurry!

And most importantly you can count on our uncompromising commitment to your total satisfaction.

All of this is our way of saying welcome–and thanks for investing in a Philips product.

Sincerely,

Robert Minkhorst President and Chief Executive Officer

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM3

P.S. Remember, to get the most from your Philips

product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

3139 116 19372 (ENG)

This symbol warns the user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any inside part of this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1. Read these instructions – All the safety and

2. Keep these instructions – The safety and

3. Heed all warnings – All warnings on the

4. Follow all instructions – All operating and

5. Do not use this apparatus near water –

6. Clean only with a damp cloth. The appliance

7. Install in accordance with the

8. Do not install near any heat sources such

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM4

IMPORTANT SAFETY INSTRUCTIONS – Read before operating equipment

9. Do not defeat the

operating instructions should be read before the appliance is operated.

operating instructions should be retained for future reference.

appliance and in the operating instructions should be adhered to.

use instructions should be followed.

for example, near a bathtub, washbowl, kitchen sink, laundr y tub, in a wet basement or near a swimming pool, etc.

should be cleaned only as recommended by the manufacturer.

manufacturers instructions. Do not block any of the ventilation openings. For

example, the appliance should not be situated on a bed, sofa, rug, or similar surface or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked

on or pinched particulary at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified

by the manufacturer.

12. Use only with a cart, stand,

tripod, bracket, or table specified

by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning

storms or when unused for long periods of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

EL 4562-E004: 99/3

AC Polarized

Plug

WARNING

To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure.

The set complies with the FCC-Rules, Part 15 and with 21 CFR 1040.10.

Canada

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.

3139 116 19372 (ENG)

AUDIO SYSTEM

One Year Free Labor

One Year Free Service on Parts

This product must be carried in for repair.

WHO IS COVERED?

You must have proof of purchase to receive warranty service. A sales receipt or other document showing that you purchased the product is considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product. For one year thereafter, all parts will be repaired or replaced, and labor is free.After one year from the day of purchase, you pay for the replacement or repair of all par ts, and for all labor charges. All parts, including repaired and replaced parts, are covered only for the original warranty period.When the warranty on the product expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product.

• product repair and/or part replacement because of misuse, accident, unauthorized repair or other cause not within the control of Philips Consumer Electronics Company.

• reception problems caused by signal conditions or cable or antenna systems outside the unit.

• a product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications.

• incidental or consequential damages resulting from the product. (Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.This includes, but is not limited to, prerecorded material, whether copyrighted or not copyrighted.)

LIMITED WARRANTY

• a product that is used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics Company. In countries where Philips Consumer Electronics Company does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of purchase.Attach it to this owner’s manual and keep both nearby. Also keep the original box and packing material in case you need to return your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service. Adjustments of the controls discussed there may save you a service call.

TO GET WARRANTY SERVICE IN U.S.A., PUERTO RICO OR U.S. VIRGIN ISLANDS...

Take the product to a Philips factory service center (see enclosed list) or authorized service center for repair.When the product has been repaired, you must pick up the unit at the center. Centers may keep defective parts. (In U.S.A., Puerto Rico and U.S.Virgin Islands, all implied warranties, including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the duration of this express warranty. But, because some states do not allow limitations on how long an implied warranty may last, this limitation may not apply to you.)

TO GET WARRANTY SERVICE IN CANADA...

Please contact Philips at:

1-800-661-6162 (French Speaking) 1-800-363-7278 (English Speaking)

(In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or fitness for a particular purpose. Philips is not liable under any circumstances for any direct,indirect, special, incidental or consequential damages, howsoever incurred, even if notified of the possibility of such damages.)

REMEMBER...

Please record the model and serial numbers found on the product below.Also, please fill out and mail your warranty registration card promptly. It will be easier for us to notify you if necessary.

MODEL # ____________________________________

SERIAL # ____________________________________

This warranty gives you specific legal rights.You may have other rights which vary from state/province to state/province.

Philips Service Solutions Group, P.O. Box 2976,

Longview,Texas 75606, USA,(903) 242-4800

EL4965E006 / MAC 4110 / 12-98

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM5

3139 116 19372 (ENG)

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM6

3139 116 19372 (ENG)

GENERAL INFORMATION SAFETY INFORMATION

General Information

• The typeplate (which contains the serial number) is located at the rear of the system.

• Recording is permissible if copyright or other rights of third parties are not infringed.

• This device complies with the Federal Communications Commission (FCC) rules, part 15 and with 21 CFR 1040.10. Operation is subject to the following two conditions: – This device may not cause

harmful interference, and

– This device must accept any

interference received, including interference that may cause undesired operation.

Environmental Information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Accessories (Supplied)

– Remote control – Batteries (two AA size) for remote

control – AM loop antenna – FM wire antenna – AC power cord – SS39 Surround Speakers

(for model FWC3 & C35 only)

Safety Information

• Before operating the system, check that the operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer. The typeplate is located at the rear of your system.

• When the system is switched on, do not move it around.

• Place the system on a solid base (e.g. a cabinet).

• Place the system in a location with adequate ventilation to prevent internal heat build-up in your system. Allow at least 10cm (4 inches) clearance from the rear and the top of the unit and 5cm (2 inches) from each side.

• Do not expose the system to excessive moisture, rain, sand or heat sources.

• Under no circumstances should you repair the system yourself, as this will invalidate the warranty!

• If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens of the CD unit inside the system. Should this occur, the CD player will not operate normally. Leave the power on for about one hour with no disc in the system until normal playback is possible.

• Electrostatic discharge may cause unexpected problems. See whether these problems disappear if you unplug the AC power cord and plug it in again after a few seconds.

• To disconnect the system from the power supply completely, remove the AC power plug from the wall socket.

CLASS 1

LASER PRODUCT

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM7

3139 116 19372 (ENG)

Rear Connections

PREPARATION

surr.

(for model FWC3 & FWC35 only)

surr.

–

SUBWOOFER

OUT

AUX IN

–

AUDIO OUT

FM ANTENNA

300Ω

AM ANTENNA

MAINS

VOLTAGE SELECTOR

110V- 127V

220V- 240V

STANDBY ON

MIN MAX

CUT OFF FREQUENCY

HIGH POWER SUBWOOFER

60Hz 150Hz

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM8

3139 116 19372 (ENG)

PREPARATION

A AM Loop Antenna

Connection

Connect the supplied loop antenna to the AM ANTENNA terminal. Place the AM loop antenna far away from the system and adjust its position for the best reception.

B FM Wire Antenna

Connection

Connect the supplied FM wire antenna to the FM AERIAL (FM ANTENNA)

300 Ω terminal. Adjust the position of

the FM antenna for the best reception.

Outdoor Antenna

For better FM stereo reception, connect an outdoor FM antenna to the

FM AERIAL (FM ANTENNA) 300 Ω terminal using a 300 Ω dipole wire.

FM AERIAL 300Ω

FM ANTENNA 300Ω

C Speakers Connection

• Connect the right speaker to Front terminal R, with the colored wire to + and the black wire to -.

• Connect the left speaker to Front terminal L, with the colored wire to + and the black wire to -.

• Clip the stripped portion of the speaker wire as shown.

12 mm

unlock lock

D Rear Surround

Speakers' Connection

(for models FWC3 & FWC35 only)

Connect the black (non-marked) wires to the black REAR SURROUND terminals and the colored (marked) wires to the grey REAR SURROUND terminals.

E Subwoofer Out

Connection

Connect the optional active subwoofer to the SUBWOOFER OUT terminal. The subwoofer reproduces just the low bass sound effect (e.g. explosions, the rumble of spaceships, etc.). Be sure to follow the instructions supplied with the subwoofer.

F Connecting other

equipment to your system

You can connect the audio left and right OUT terminals of a TV, VCR, Laser Disc player, DVD player or CD Recorder to the AUX IN terminals at the rear of the system.

G AC Power Supply

After all other connections have been made, connect the AC power cord to the system and to the wall outlet.

Inserting batteries into the Remote Control

• Insert the batteries (Type R06 or AA) into the remote control as shown in the battery compar tment.

• To avoid damage from possible battery leakage, remove dead batteries or batteries that will not be used for a long time. For replacement, use type R06 or AA batteries.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM9

3139 116 19372 (ENG)

3 CD ROTARY CHANGER SYSTEM

CD REWRITABLE COMPATIBLE

CD SYNCHRO RECORDING

CONTROLS

)

(

STANDBY-ON

TAP E 1

PLAY/REC

FW-

CONTROL

C10

JOG

OPTIMAL

▲

DISC CHANGE

CHANGER

MINI HIFI SYSTEM

CD1 • 2 • 3 FM •AM

JAZZ

ROCK

TECHNO

▲

DISC 2

DISC 1

TAPE 1 • 2

▲▲▲

▲

TUNING

STOP•CLEAR

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

FULL AUTO STOP

TAPECD TUNER

PLAY• PAUSE PREV NEXT

DISC 3

▲

PRESET

▲

OPEN•CLOSE

3 CD ROTARY CHANGER SYSTEM

CD REWRITABLE COMPATIBLE

CD SYNCHRO RECORDING

AUX

MASTER VOLUME

▲

VIDEO

•

TAP E 2

PLAYBACK

$ %

CD DIRECT

PAUSE

REPEAT

VOLUME

MUTE

DSC DBB

TUNERTAPE 1/2CD

SLEEP AUXDIM

∞

≤

SHUFFLE

@ #

™

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM10

3139 116 19372 (ENG)

Controls on the system and remote control

1 STANDBY ON

– to switch the system on or to

standby mode.

– to use for EASY SET.

2 PROGRAM

for CD ............to program CD tracks.

for TUNER ... to program preset

radio stations.

for CLOCK ..to select 12- or 24-

hour in clock setting mode.

3 DIGITAL SOUND

CONTROL DISPLAY PANEL

– to view the desired DSC display.

4 JOG CONTROL/DSC

– to select the desired equalizer

display: OPTIMAL, JAZZ, ROCK or TECHNO.

5 DBB (DYNAMIC BASS

BOOST)

– to switch on bass boost to

enhance bass response or to switch off bass boost.

6 DISPLAY SCREEN

– to view the current setting of the

system.

7 CD CAROUSEL TRAY 8 DISC CHANGE

– to change CD(s).

9 OPEN•CLOSE

– to open or close the CD carousel

tray.

CONTROLS

0 DISC 1 / DISC 2 / DISC 3 (CD

DIRECT PLAY)

– to select a CD tray for playback. ! SOURCE – to select the

following:

CD / (CD 1•2•3)

– to select CD mode. When CD

playback is stopped, press to select disc tray 1, 2 or 3.

TUNER / (FM•AM)

– to select Tuner mode. When in

tuner mode, press to select the waveband: FM or AM.

TAPE / (TAPE 1• 2)

– to select Tape mode.

AUX / (VIDEO)

– to select sound from an external

source (e.g. TV, VCR, Laser Disc player, DVD player or CD Recorder).

@ MODE SELECTION

SEARCH à á (TUNING à á )

for CD ............ to search backward/

forward.

for TUNER .... to tune to a lower or

higher radio frequency.

for CLOCK ..to set the hour (on

the system only).

STOP•CLEAR Ç

for CD ............ to stop CD playback

or to clear a program. for TUNER ... to stop programming.

for DEMO ....(on the system only)

to start or stop

demonstration mode.

PLAY É / PAUSE Å

for CD ............to start or interrupt

playback.

PREV í / NEXT ë(PRESET 4 3 )

for CD ............to skip to the

beginning of the current, previous, or next track.

for TUNER ... to select a preset

station in memory.

for CLOCK .. to set the minute (on

the system only).

# MASTER VOLUME

– to increase or decrease the

volume.

$ n

– to connect headphones.

% DIM

– to select different brightness for

the display screen : DIM 1, DIM 2, DIM 3 or DIM OFF.

^ CLOCK•TIMER

– to view the clock, set the clock or

set the timer.

& TAPE DECK 2 * TAPE DECK 2 OPERATION

PLAYÉ ...... to start playback.

à ..................... to rewind the tape.

á ..................... to fast forward the

tape.

STOP•OPEN…to stop playback

or to open the tape door.

PAU S E ......... to interrupt playback.

( TAPE DECK 1 OPERATION

RECORD ... to start recording.

PLAYÉ ...... to start playback.

à ..................... to rewind the tape.

á ..................... to fast forward the

tape.

STOP•OPEN…to stop playback/

recording or to open the tape door.

PAUSE .........to interrupt playback

or recording.

) TAPE DECK 1 ¡ REPEAT

– to repeat a CD track, a disc, or all

available discs.

™ MUTE

– to switch off the sound temporarily.

£ SHUFFLE

– to play all the available discs and

their tracks in random order.

≤ SLEEP

– to switch the system to standby

mode at a selected time.

∞ B

– to switch the system to standby

mode.

Notes for remote control: – First select the source you wish

to control by pressing one of the source select keys on the remote control (e.g. CD ,TUNER etc.).

– Then select the desired function

(É, í, ë, etc .).

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM11

3139 116 19372 (ENG)

3 CD ROTARY CHANGER SYSTEM

•

CD REWRITABLE COMPATIBLE

•

CD SYNCHRO RECORDING

•

OPERATING THE SYSTEM

MINI HIFI SYSTEM

FW-

C10

STANDBY-ON

JOG

OPTIMAL

TECHNO

JAZZ

ROCK

CD1 • 2 • 3FM •AM

▲▲▲

▲

TUNING

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

CONTROL

Important: Before you operate the system, complete the preparation procedures.

Demonstration mode

The system has a demonstration mode that shows the various features offered by the system. When the system is

switched on for the first time, the demonstration mode will start automatically.

Notes: – During the demonstration, if you press

any source (or standby-on) button, the system will switch to the respective mode (or standby).

– When the system is switched to

standby mode, the demonstration will resume five seconds later.

STOP•CLEAR

TAPE 1 • 2

TAPECD TUNER

PLAY• PAUSE PREV NEXT

VIDEO

AUX

▲

PRESET

To stop the demonstration mode

• Press and hold Ç(on the system

only) for five seconds when the

system is in demonstration mode.

™ The demonstration will stop. ™ "DEMO OFF" is displayed. ™ The system will switch to standby

mode.

Note: – Even though the AC power cord is

removed from and reconnected to the wall socket, the demonstration will remain off until it is switched on again.

To start the demonstration mode

• Press and hold Ç(on the system

only) for five seconds when the

system is in standby mode. ™ The demonstration will begin.

MASTER VOLUME

Easy Set

EASY SET allows you to store all available radio stations automatically.

• Press and hold STANDBY ON (on

the system only) for five seconds when the system is in standby or demonstration mode. ™ “EASY SET” will be displayed,

and followed by “TUNER” and then “AUTO”.

™ EASY SET will star t searching for

all radio on FM band and then followed by radio stations on AM band.

™ All available radio stations with

sufficient signal strength will be stored. Up to 40 presets may be stored.

Notes: – EASY SET will start with the FM band,

if there are still presets available, the system will continue to store the AM band.

– When EASY SET is used, all previously

stored radio stations will be replaced.

– The last preset radio station will

appear on the display when EASY SET is completed.

Switching the system ON

• Press CD, TUNER, TAPE or AUX.

You can also switch on the system by pressing any one of the CD DIRECT PLAY buttons.

Switching the system to standby mode

• Press STANDBY ON or B on

the remote control. ™ The system will switch to standby

mode.

Selecting the Source

• Press the respective source selection

button: CD, TUNER, TAPE or AUX. ™ The display indicates the selected

source.

Note: – For an external source, make sure you

have connected the audio left and right OUT terminals of the external equipment (TV, VCR, Laser Disc player, DVD player or CD Recorder) to the AUX IN terminals.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM12

3139 116 19372 (ENG)

DIM mode

You can select the desired brightness for the display.

• Press DIM to select DIM 1, DIM 2,

DIM 3 or DIM OFF display mode.

™ The DIM display lights up. ™ "DIM 1", "DIM 2", "DIM 3" or

"DIM OFF" will be displayed depending on the mode selected.

DIM OFF - normal brightness with Spectrum Analyzer On

DIM 1 - normal brightness with Spectrum Analyzer Off

DIM 2 - half brightness with Spectrum Analyzer On

OPERATING THE SYSTEM

DIM 3 - half brightness with Spectrum Analyzer Off and all LEDs on the system will be switched off.

Sound Control

VOLUME ADJUSTMENT

Adjust MASTER VOLUME to increase or decrease the sound level.

For Personal Listening

Connect the headphones plug to the n socket at the front of the system. The speakers will be muted.

DIGITAL SOUND CONTROL (DSC)

The DSC feature enables you to enjoy special sound effects that have preset equalizer settings, providing the best music reproduction.

• Adjust JOG CONTROL to select

OPTIMAL, JAZZ, ROCK or TECHNO. ™ The Digital Sound Control display

panel will light up respectively.

™ “OPTIMAL, JAZZ, ROCK or

TECHNO” and the respective flag

will be displayed.

Note: – When ”OPTIMAL” sound is selected,

DBB will be switched on automatically.

DYNAMIC BASS BOOST (DBB)

The DBB mode enhances the bass response.

• Press DBB to switch on bass

response.

™ The DBB button lights up. ™ “DBB ON” and the DBB flag will

be displayed.

To switch off DBB

• Press DBB again.

™ The DBB button light is switched

off.

™ “DBB OFF” will be displayed.

Note: – Some CDs or tapes might be recorded

in high modulation, which causes a distortion at high volume. If this occurs, switch off DBB or reduce the volume.

MUTE (only on remote control) This feature allows you to temporarily switch off the sound of the system without switching off the system when you require a moment of silence.

• Press MUTE on the remote control

to switch off the sound. ™ "MUTE" and the MUTE flag will be

displayed.

• Press MUTE again on the remote control or increase the MASTER VOLUME to switch on the sound.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM13

3139 116 19372 (ENG)

DISC 2

DISC 3

TAPE 1 • 2

TAPECD TUNER

▲

PRESET

PLAY• PAUSE PREV NEXT

OPEN•CLOSE

VIDEO

AUX

▲

MASTER VOLUME

STANDBY-ON

DISC CHANGE

CHANGER

MINI HIFI SYSTEM

FW-

C10

JOG

CONTROL

OPTIMAL

TECHNO

JAZZ

ROCK

DISC 1

CD1 • 2 • 3 FM • AM

▲▲▲

▲

TUNING

STOP•CLEAR

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

Warning!

1) This system is designed for conventional CDs. Do not use any accessories such as disc stabilizer rings or CD treatment sheets, etc., which may damage the CD mechanism.

2) Do not load more than one disc into each tray.

3) When the CD changer is loaded with CDs, do not turn over or shake the system. This may jam the changer.

You may load three discs in the CD changer for continuous playback without interruption.

Discs for playback

This system can play all digital audio CD, finalized digital audio CD-Recordable and finalized digital audio CDRewritable format discs.

Loading the CD Changer

1 Press CD to select CD mode. 2 Press OPEN•CLOSE.

™ The CD carousel tray slides out.

3 Load a CD with the printed side up

in the right tray.

• You can load another disc in the left tray.

• To load the third disc, press the DISC CHANGE button. ™ The CD carousel tray will rotate

until the empty tray is ready for loading.

4 Press OPEN•CLOSE to close the

CD carousel tray. ™ The total number of tracks and

the playing time of the selected disc appear on the display.

Note: – To ensure good system performance,

wait until the CD changer completely reads the disc(s) before proceeding.

CD Direct Play

• You can play a CD directly by

pressing the DISC 1, DISC 2 or DISC 3 button. The CD player will stop at the end of playback of the selected disc. ™ A lit button indicates that a disc is

loaded in the disc tray.

™ A flashing button indicates that a

disc is playing.

Playing a CD

1 PressÉ to start playback.

™ The disc tray, track number and

elapsed playing time of the current track appear on the display.

• To interrupt playback, pressÅ.

™ The playing time flashes.

• To resume playback, pressÉ again. 2 To stop playback, press Ç.

Note: – All the available discs will play once,

then stop.

Disc Change

You can change the outer two discs while the third inner disc is stopped or is playing.

1 Press DISC CHANGE.

™ The CD carousel tray slides out.

2 Replace the discs in the left and right

disc trays.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM14

3139 116 19372 (ENG)

• If you press DISC CHANGE again

during playback, the CD will stop playing. ™ The CD carousel tray will rotate

until the inner tray is rotated out and is ready for changing.

3 Press OPEN•CLOSE to close the

CD carousel tray.

Selecting a desired track

Selecting a desired track when playback is stopped 1 Press í or ë until the desired

track appears on the display.

2 PressÉ to start playback.

™ The selected track number and

elapsed playing time appear on the display.

Selecting a desired track during playback

• Press í or ë until the desired

track appears on the display. ™ The selected track number and

elapsed playing time appear on the display.

• If you press í once it will skip to

the beginning of the current track and play the track again.

Note: – Pressingí during shuffling can only

skip to the beginning of the current track.

Searching for a particular passage during playback

• Press and hold à or á until the

desired passage is located. ™ The volume will be reduced.

• Play returns to normal when à or á is released.

Programming Tracks

Programming tracks of a loaded CD is possible when playback is stopped. The display will indicate the total tracks stored in the program. Up to 40 tracks can be stored in the memory in any order. When 40 tracks are stored and you attempt to store another track, the display will show “PROGRAM FULL”.

1 Load the desired discs in the disc

trays.

2 Press PROGRAM to start

programming.

™ The PROG flag starts flashing. ™ It will cancel any previously

selected repeat mode.

3 Press the CD (CD 1•2•3) or DISC

1/2/3 button to select the disc.

4 Pressí or ë to select the desired

track.

5 Press PROGRAM to store the

track.

• Repeat steps 3 to 5 to store other discs and tracks.

6 Press Ç once to end programming.

™ The total number of tracks

programmed and total playing time appear on the display.

Notes: – If the total playing time is more than

“99:59“ or if one of the programmed tracks has a number greater than 30, then “--:--” appears on the display instead of the total playing time.

– If the system is reading the discs,

programming is not possible, “READING” will be displayed and followed by ”DISC X”. ”X” is the current read disc number.

– During programming, if no button is

pressed within 20 seconds, the system will exit program mode automatically.

Reviewing the program

Reviewing of the program is possible only when playback is stopped.

• Pressí or ë repeatedly to review

the programmed tracks.

• Press Ç to exit review mode.

Playing the program

1 Press É to star t program playback.

™ “PLAY PROGRAM” will be

displayed.

™ The track number and elapsed

playing time of the current track will appear on the display.

• If you press REPEAT during

program playback, the current track or all programmed tracks will be played repeatedly. ™ “TRACK” or "PROGRAM" will be

displayed.

™ The REP and PROG flags appear

on the display.

2 Press Ç to stop program playback.

Notes: – If you press any of the CD DIRECT

PLAY buttons, the system will play the selected disc or track and the stored program will be ignored temporarily. The PROG display also will disappear temporarily from the display. It will reappear when playback of the selected disc ends.

– REPEAT DISC mode will be cancelled

when program playback begins.

Erasing the program (when

playback is stopped)

• Press Ç.

™ “PROGRAM CLEARED” will be

displayed.

Note: – The program will be erased when the

system is disconnected from the power supply or when the CD carousel tray is opened.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM15

3139 116 19372 (ENG)

CD TUNER

Shuffle (only on remote control)

In shuffle mode, the system plays all the available discs and their tracks in random order. Shuffle may be used also when tracks are programmed.

To shuffle all the discs and tracks 1 Press SHUFFLE.

™ “SHUFFLE” will be displayed. ™ The SHUF flag, the disc and the

track selected at random appear on the display.

• The discs and the tracks will be played in random order until you pressÇ.

• If you press REPEAT during shuffling, the current track or all available discs will be played repeatedly. ™ “TRACK” or “ALL DISC” will be

displayed.

™ The REP. and SHUF. flags appear

on the display.

2 Press SHUFFLE again to resume

normal playback. ™ The SHUF flag disappears from

the display.

Note: – REPEAT DISC mode will be cancelled

when shuffle is selected.

Repeat (only on remote control)

You can play the current track, a disc or all available discs repeatedly.

1 Press REPEAT on the remote

control to select the various repeat modes. ™ “TRACK”, “DISC”, “ALL DISC”

or “OFF” will be displayed.

™ The REP flag appears on the

display.

• The selected track, selected disc or all available discs will now be played repeatedly until you pressÇ.

2 Press REPEAT until the "OFF"

mode is displayed to resume normal playback. ™ The REP flag disappears from the

display.

Notes: – REPEAT DISC mode is not available

during program play or shuffle mode.

– You can also repeat shuffling a

program.

™ “TRACK“ or “PROGRAM" will be

displayed.

™ The REP, PROG, and SHUF flags

appear on the display.

MINI HIFI SYSTEM

FW-

C10

STANDBY-ON

JOG

OPTIMAL

TECHNO

JAZZ

ROCK

CD1 • 2 • 3 FM • AM

▲▲▲

▲

TUNING

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

CONTROL

Note: – For 'EASY SET' feature, please refer to

page 12.

Tuning to radio stations

1 Press TUNER (FM•AM) to select

TUNER mode. ™ “TUNER” will be displayed.

A few seconds later, the current radio frequency will be displayed.

2 Press TUNER (FM•AM) again to

select the desired waveband : FM or AM.

3 Press à or á for more than one

second, then release. ™ The display will show “SEARCH”

until a radio station with sufficient signal strength is found.

STOP•CLEAR

TAPE 1 • 2

TAPECD TUNER

PLAY• PAUSE PREV NEXT

VIDEO

AUX

▲

PRESET

• Repeat this procedure until the desired station is reached.

• To tune to a weak station, briefly press à or á repeatedly until the display shows the desired frequency and/or when the best reception has been obtained.

MASTER VOLUME

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM16

3139 116 19372 (ENG)

Storing Preset Stations

You can store up to 40 radio stations in the memory. When a preset radio station is selected, the preset number appears next to the frequency on the display.

Automatic programming 1 Press TUNER (FM•AM). 2 Press PROGRAM for more than

one second. ™ The PROG flag starts flashing and

“AUTO” will be displayed.

™ The system will search for ever y

available station in the FM waveband first, then search the AM waveband.

™ All available stations will be stored

automatically. The frequency and preset number will be displayed briefly.

™ The system will stop searching

when all the available radio stations are stored or when the memory for 40 preset radio stations is used.

™ The system will remain tuned to

the last stored preset radio station.

Notes: – You can cancel the automatic

programming by pressing PROGRAM or

(on the system only).

TUNER

– If you want to reserve a section of

preset numbers, for example preset numbers 1 to 9, select preset 10 before starting automatic programming, only the preset numbers 10 to 40 will be programmed.

Manual programming 1 Press TUNER (FM•AM). 2 Press TUNER (FM•AM) again to

select the desired waveband : FM or AM.

3 Press PROGRAM for less than one

second.

™ The PROG flag starts flashing. ™ The next available preset number

will be displayed for selection.

4 Press à or á to tune to the

desired frequency.

• If you wish to store the radio station

to another preset number, press 4 or 3 to select the desired preset number.

5 Press PROGRAM again.

™ The PROG flag disappears and

the radio station will be stored.

• Repeat steps 3 – 5 to store other preset radio stations.

Notes: – When 40 radio stations are stored and

you attempt to store another radio station, the display will show "PROGRAM FULL”. If you want to change an existing preset number, repeat steps 3 – 5.

– You can cancel manual programming

by pressing Ç (on the system only).

– During programming, if no button is

pressed within 20 seconds, the system will exit program mode automatically.

Tuning to Preset Radio Stations

• Press 4 or 3 to select the desired

preset number. ™ The preset number, radio

frequency, and waveband appear on the display.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM17

3139 116 19372 (ENG)

TAPE

STANDBY-ON

TAPE 1

MINI HIFI SYSTEM

FW-

C10

Loading a tape

1 Press STOP•OPEN. 2 The tape deck door opens. 3 Load the tape with the open side

JOG

OPTIMAL

TECHNO

CD1 • 2 • 3FM •AM

▲▲▲

TUNING

JAZZ

PROGRAM CLOCK•TIMER DIM

ROCK

SOUND NAVIGATION - JOG

▲

CONTROL

STOP•CLEAR

TAPE 1 • 2

TAPECD TUNER

▲

PRESET

PLAY• PAUSE PREV NEXT

▲

VIDEO

AUX

MASTER VOLUME

downward and the full spool to the left.

Rewind/Fast Forward

When playback is stopped 1 You can rewind or fast forward a

tape by pressing à or á , respectively. ™ The tape will stop automatically at

the end of rewinding or fast forwarding.

2 Press STOP•OPEN to stop

rewinding or fast forwarding.

Continuous Playback From

TAPE 2

4 Close the tape deck door.

Tape Playback

1 Press TAPE to select TAPE mode.

FULL AUTO STOP

LAY

▲

™ "TAPE" will be displayed.

2 Load the tape into the selected tape

deck.

3 Press PLAYÉ to start playback.

• To interrupt playback, press PAUSE.

• To resume playback, press PAUSE

again.

4 Press STOP•OPEN to end

playback.

Tape Deck 2 to Tape Deck 1

1 Press TAPE to select TAPE mode. 2 Load the tapes in tape decks 1 and 2. 3 Press PLAY 2 on tape deck 2. 4 Press PAUSE on tape deck 1. 5 Press PLAY 2 on tape deck 1.

™ Playback will begin with tape deck

2 and will continue with tape deck 1 when playback on tape deck 2 ends.

6 Press STOP•OPEN if you want to

stop playback before the end of the tape in tape deck 1 or tape deck 2.

Notes: – During rewinding or fast forwarding of a

tape, it is also possible to listen to another source (e.g. CD, TUNER or AUX).

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM18

3139 116 19372 (ENG)

– Before playing a tape, check and

tighten slack tape with a pencil. Slack tape may get jammed or may burst in the mechanism.

– C-120 tape is extremely thin and is

easily deformed or damaged. It is not recommended for use in this system.

– Store the tapes at room temperature

and do not put them too close to a magnetic field (for example, a transformer, TV or speaker).

TAPE AUX

MINI HIFI SYSTEM

FW-

C10

STANDBY-ON

JOG

OPTIMAL

TECHNO

JAZZ

ROCK

CD1 • 2 • 3 FM •AM

▲▲▲

▲

TUNING

STOP•CLEAR

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

PLAY• PAUSE PREV NEXT

CONTROL

Selecting External Equipment

If you have connected the audio out terminals of the external equipment (TV, VCR, Laser Disc player, DVD player or CD Recorder) to the AUX IN terminals, you can hear the enhanced sound from the system.

• Press AUX to select the external

equipment. ™ "AUX" will be displayed.

Note: – All the sound control features (e.g. DSC ,

DBB, etc.) are available for selection.

TAPE 1 • 2

TAPECD TUNER

AUX

MASTER VOLUME

VIDEO

▲

PRESET

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM19

3139 116 19372 (ENG)

STANDBY-ON

TAPE 1

RECORDING

MINI HIFI SYSTEM

FW-

C10

– For recording, use only tape of IEC type

I (normal tape).

– The tape is secured at both ends with

leader tape. At the beginning and end

Notes:

JOG

OPTIMAL

TECHNO

JAZZ

ROCK

CD1 • 2 • 3 FM •AM

▲▲▲

▲

TUNING

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

CONTROL

STOP•CLEAR

TAPE 1 • 2

TAPECD TUNER

▲

PRESET

PLAY• PAUSE PREV NEXT

▲

VIDEO

AUX

MASTER VOLUME

TAPE 2

of tape, nothing will be recorded for six to seven seconds.

– The recording level is set automatically,

regardless of the position of Volume, DBB or DSC.

– To prevent accidental recording, break

out the tab on the left shoulder of the tape side you want to protect.

One Touch Recording

• For One Touch Recording, as soon as you press RECORD, the current source (CD, TUNER or AUX) will be recorded on tape deck 1.

FULL AUTO STOP

▲

1 Load a blank tape in tape deck 1. 2 Press RECORD on tape deck 1 to

start recording. ™ The REC star ts flashing.

3 Press PAUSE to interrupt

recording.

4 Press STOP•OPEN on tape deck 1

to stop recording.

CD Synchro Start Recording

During CD synchro start recording,

• Do not fast forward/rewind your tape in tape deck 2.

• Do not listen to another source.

1 Load a blank tape into tape deck 1

and a disc into the disc tray.

2 Press CD.

• You can program the tracks in the order you want them to be recorded (see Programming Tracks). If you do not, the tracks are recorded according to the order on the selected disc.

3 Press RECORD on tape deck 1 to

start recording. ™ The REC star ts flashing.

4 Press STOP•OPEN on tape deck 1

to stop recording, then press Ç to stop CD playback.

Dubbing tapes (from tape deck 2

to tape deck 1)

1 Load the prerecorded tape into tape

deck 2 and a blank tape into tape deck 1.

• Make sure both tapes have their full spool to the left.

2 Press PAUSE on tape deck 1. 3 Press RECORD on tape deck 1. 4 Press PLAYÉ on tape deck 2.

™ The REC star ts flashing.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM20

3139 116 19372 (ENG)

• Recording will start automatically. 5 Press STOP•OPEN on tape deck 1

and tape deck 2 to stop dubbing.

Notes: – At the end of side A, flip the tapes to

side B and repeat the procedure.

– Dubbing of tapes is only possible from

tape deck 2 to tape deck 1.

– To ensure good dubbing, use tapes of

the same length.

Recording from other sources (only on tape deck 1)

1 Load a blank tape into tape deck 1. 2 Press CD, TUNER or AUX.

• Start playback of the selected source. 3 Press RECORD on tape deck 1 to

start recording. ™ The REC star ts flashing.

4 Press PAUSE to interrupt

recording.

5 Press STOP•OPEN on tape deck 1

to stop recording.

Note: – During recording, it is not possible to

listen to another sound source.

RECORDING CLOCK

MINI HIFI SYSTEM

FW-

C10

STANDBY-ON

JOG

OPTIMAL

TECHNO

JAZZ

ROCK

CD1 • 2 • 3FM •AM

▲▲▲

▲

TUNING

PROGRAM CLOCK•TIMER DIM

SOUND NAVIGATION - JOG

CONTROL

View Clock

You can view the clock (if it is set) if the system is in Standby mode or when any sound source is selected (CD, TUNER, etc.). The clock will be displayed for about seven seconds.

• Press CLOCK•TIMER briefly.

™ “10:38 PM or 22:38” (the

current time in either 12- or 24hour mode) will be displayed depending on whether you have selected 12- or 24-hour mode.

™ “--:--” will be displayed if the

clock is not set.

TAPE 1 • 2

PLAY• PAUSE PREV NEXT

STOP•CLEAR

Clock Setting

The clock can be set in either 12- or 24-hour mode, e.g. “12:00 AM“ or “00:00“. Before setting the clock, you must be in the View Clock mode.

1 Press CLOCK•TIMER to select

2 Press PROGRAM to select 12- and

3 Set the hour with à or á on the

4 Set the minute with í or ë on

MASTER

VIDEO

TAPECD TUNER

▲

PRESET

AUX

VOLUME

clock mode.

24- hour mode. ™ If 12-hour mode is selected,

“12:00“ starts flashing and the

AM lights up.

™ If 24-hour mode is selected,

“00:00” starts flashing.

system.

the system.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM21

3139 116 19372 (ENG)

5 Press CLOCK•TIMER again to

store the setting. ™ The clock star ts.

• To exit without storing the setting,

press Çon the system.

Notes: – During clock setting, if no button is

pressed within 90 seconds, the system will exit clock setting mode automatically.

– When a power interruption occurs, the

clock setting is erased.

Timer Setting

• The system can switch on to CD or TUNER mode automatically at a preset time. It can serve as an alarm to wake you up.

• Before setting the timer, make sure the clock is set correctly.

• The timer will always be switched on once it is set.

• The volume of the timer will increase from the minimum level until the volume level before the set is switched to standby mode.

1 Press and hold CLOCK•TIMER

for more than two seconds to select timer mode.

TIMER SLEEP TIMER

™ “12:00 AM” o r “ 00:00" or the

last timer setting starts flashing depending on whether you have selected 12- or 24-hour mode.

™ The TIMER star ts flashing. ™ The selected source is lit while

other available sources are flashing.

2 Press CD or TUNER to select the

desired source.

• Before selecting CD, make sure a CD is loaded in the CD carousel tray.

3 Press à or á on the system to set

the hour for the timer to start on the system.

4 Press í or ë on the system to set

the minute for the timer to start.

5 Press CLOCK•TIMER to store

the start time .

™ The timer is now set. ™ The TIMER remains on the display.

• At the preset time, the timer will be activated. ™ The selected source will be

played.

Notes: – During timer setting, if no button is

pressed within 90 seconds, the system will exit timer setting mode automatically.

– If the source selected is TUNER, the

last tuned frequency will be switched on.

– If the source selected is CD, playback

will begin with the first track of the selected disc or program. If the CD trays are empty, the TUNER will be selected instead.

– The timer will not activate if a recording

is in progress.

To switch off the TIMER 1 Press and hold CLOCK•TIMER

for more than two seconds.

2 Press Ç on the system to cancel the

timer.

™ The timer is now switched off. ™ The display will show "CANCEL"

and the TIMER disappears.

To start the TIMER again (for the same preset time and source)

1 Press and hold CLOCK•TIMER

for more than two seconds.

2 Press CLOCK•TIMER again to

store the start time.

™ The timer is now on. ™ The TIMER appears on the display.

Sleep Timer (only on remote

control)

This feature allows you to select a length of time after which the system will switch to the standby mode automatically.

1 Press SLEEP on the remote control

repeatedly to select a period of time. ™ The selections are as follows (time

in minutes):

60 ™ 45 ™ 30 ™ 15 ™ OFF ™ 60 …

™ “SLEEP XX” or “OFF” will be

displayed. "XX" is the time in minutes.

2 When you reach the desired length

of time, stop pressing the SLEEP button. ™ After this amount of time passes,

the system will switch to the standby mode.

To switch off the Sleep Timer

• Press SLEEP repeatedly until "OFF"

is displayed, or press the STANDBY ON button.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM22

3139 116 19372 (ENG)

Specifications

AMPLIFIER

Output power

FWC35 & C3 ............................................ 2 x 25 W FTC

Surround Channel ...................................... 2 x 2 W, 6 Ω

FWC30 .........................................................2 x 25 W FTC

Signal-to-noise ratio ....................................... ≥ 67 dBA (IEC)

Frequency response ...................................... 50 – 15,000 Hz

Input sensitivity

AUX In ............................................................................. 700 mV

Output

Speakers ...............................................................................≥ 6 Ω

Headphones ................................................. 32 Ω – 1000 Ω

(1) (6Ω,60Hz - 12.5kHz, 10% THD)

CD PLAYER

Number of programmable tracks ...................................... 40

Frequency response ...................................... 20 – 20,000 Hz

Signal-to-noise ratio .................................................... ≥ 80 dBA

Channel separation .......................................≥ 60 dB (1 kHz)

Total harmonic distor tion ........................................ < 0.003%

TUNER

FM wave range ................................................87.5 – 108 MHz

AM wave range ............................................... 530 – 1700 kHz

Number of presets ..................................................................... 40

Antenna

FM ................................................................ 300 Ω dipole wire

AM......................................................................... Loop antenna

SPECIFICATIONS

TAPE DECK

Frequency response

Normal tape (type I) ............... 80 – 12,500 Hz (8 dB)

Signal-to-noise ratio

(1)

Normal tape (type I) ........................................... ≥ 48 dBA

Wow and flutter ...................................................... ≤ 0.4% DIN

(1)

SPEAKERS

System ................................. 2 way; double port bass reflex

Impedance ..................................................................................... 6 Ω

Woofer ................................................................................ 1 x 5.25"

Tweeter ................................................................................... 1 x 2.5"

Dimensions (w x h x d) ........ 8.27 x 12.20 x 9.45 (inch)

............................................................ 210x 310x 240 (mm)

Weight............................................................. 6.38 pounds each

................................................................................... 2.9 kg each

SS39 SURROUND SPEAKERS

(FWC3 & FWC35 only)

System .................................................................... closed satellite

Impedance ..................................................................................... 6 Ω

Woofer ................................................................. 1 x 3" full range

Dimensions (w x h x d) ........................ 7 x 7 x 3.54 (inch)

............................................................... 178x 178x 90 (mm)

Weight............................................................. 1.32 pounds each

................................................................................... 0.6 kg each

GENERAL INFORMATION

Material ........................................................................... Polystyrene

AC Power ................................................................ 120 V / 60 Hz

Power Consumption

Active .................................................................................... 70 W

Standby ............................................................................ < 15 W

Dimensions (w x h x d) .. 10.43 x 12.20 x 13.40 (inch)

............................................................ 265x 310x 340 (mm)

Weight (without speakers) ................................14.3 pounds

............................................................................................... 6.5 kg

Subject to modification

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM23

3139 116 19372 (ENG)

Maintenance

Cleaning the Cabinet

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

Cleaning Discs

• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner, commercially available cleaners, or antistatic spray intended for analog records.

Cleaning the CD lens

• After prolonged use, dirt or dust may accumulate at the CD lens. To ensure good playback quality, clean the CD lens with Philips CD Lens Cleaner or any commercially available cleaner. Follow the instructions supplied with cleaner.

MAINTENANCE TROUBLESHOOTING

Cleaning the Heads and the Tape Paths

• To ensure good recording and playback quality, clean the heads, the capstan(s), and pressure roller(s) after every 50 hours of tape operation.

• Use a cotton swab slightly moistened with cleaning fluid or alcohol.

• You can also clean the heads by playing a cleaning tape once.

Demagnetizing the heads

• Use a demagnetizing tape available at your dealer.

Warning! Under no circumstances should you try to repair the set yourself as this will invalidate the guarantee. Do not open the set as there is a risk of electric shock.

• If a fault occurs, check the points listed below before taking the system for repair.

• Should any problems persist after you have made these checks, consult your nearest dealer or service center.

CD Player Operation

“NO DISC” is displayed.

• The disc is inser ted upside down.

™ Place CD with printed side up.

• Moisture condensation at the lens.

™ Wait until lens has adjusted to normal

room temperature.

• There is no disc in the CD tray.

™ Insert a CD.

• The CD is dirty, badly scratched or

warped.

™ Clean or replace the CD.

• The CD lens is dirty or dusty.

™ See section under Maintenance (page

24).

“DISC NOT FINALIZED” is displayed.

• The CD-RW or CD-R disc is not properly recorded for use with a standard CD player.

™ Read the instruction booklet of your

CD-Rewritable or CD-Recorder on how to finalize a recording.

• The CD is badly scratched or dir ty.

™ Replace or clean CD.

Radio Reception

Poor radio reception.

• The signal is too weak.

™ Adjust the antenna. ™ Connect an external antenna for

better reception.

• The TV or VCR is too close to the stereo system.

™ Separate the stereo system from the

TV or VCR.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM24

3139 116 19372 (ENG)

Tape Deck Operation

“RECORDING ACTIVE” is displayed.

• A recording is in progress.

™ Stop the recording or wait until it is

finished.

Recording or playback cannot be made or there is a decrease in audio level.

• Dirty tape heads, capstans or pressure rollers.

™ See section on tape deck maintenance

(page 24).

• Magnetic build-up in the record/ playback head.

™ Use demagnetizing tape.

General

System does not react when any button is pressed.

• Electrostatic discharge.

™ Press STANDBY ON to switch the

system off. Remove the AC power plug from the wall outlet, then reconnect the power plug and switch on the system again.

TROUBLESHOOTING

No or poor sound.

• Volume is not turned up.

™ Adjust VOLUME.

• The headphones are connected.

™ Disconnect the headphones.

• Speakers are not connected or are connected wrongly.

™ Check that the speakers are

connected correctly.

™ Make sure the stripped speaker wire is

clamped.

Reversed left and right sound.

• Speakers are connected wrongly.

™ Check the speaker connections and

location.

Lack of bass sound or apparently imprecise physical location of musical instruments.

• Speakers are connected wrongly.

™ Check the speaker connection for

proper phasing, colored/black wires to colored/black terminals.

Remote control has no effect on the system.

• Wrong source is selected.

™ Select the source (CD, TUNER, etc.)

before pressing the function button, (É, í, ë, etc.).

• The distance to the system is too large.

™ Reduce the distance.

• Batteries are inser ted incorrectly.

™ Insert the batteries with their polarities

(+/– signs) as indicated.

• Batteries are exhausted.

™ Replace the batteries.

Timer is not working.

• Clock is not set.

™ Set the clock.

• Timer is not switched on.

™ Press CLOCK•TIMER to switch on the

timer.

• Recording is in progress.

™ Stop recording.

Clock setting is erased.

• There was a power failure.

™ Reset the clock.

System displays features automatically; buttons flash continuously.

• Demonstration mode is switched on.

™ Press and hold Ç (on the system) for

five seconds to switch off the demonstration.

All lighted buttons are not lit.

• Display is switch on in DIM 3 mode.

™ Press DIM until DIM OFF display mode

is shown.

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM25

3139 116 19372 (ENG)

TABLE OF CONTENTS

President Message ............................ 2 - 3

Important Safety Instructions ............... 4

Limited Warranty ....................................5

Model Illustration ...................................6

General Information...............................7

Safety Information .................................7

Preparation ....................................... 8 - 9

Controls ......................................... 10 - 11

Operating The System .................. 12 - 13

CD.................................................. 14 - 16

Tuner ............................................. 16 - 17

Tape ............................................... 18 - 19

AUX .......................................................19

Recording ...................................... 20 - 21

Clock .....................................................21

Timer .....................................................22

Sleep Timer ......................................... 22

Specifications........................................23

Maintenance.........................................24

Troubleshooting ............................ 24 - 25

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM26

3139 116 19372 (ENG)

☞

2 6

PAGE GUIDE

789

19 20

22 23

FRONT

PAG E

TABLE

CONTENTS

10 14

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM27

11 12 13 15 16 17

BLANK

PAG E

BLANK

PAG E

BLANK

PAGE

BLANK

PAGE

PAG E

GUIDE

BACK

PAG E

3139 116 19372 (ENG)

FW 890P

English

FW-C35 FW-C30

FW-C3

Philips Consumer Electronics Company

A Division of Philips Electronics North America Corporation, Knoxville, Tennessee 37914-1810, USA

3139 116 19372 (ENG) IB8167T001 SL-9947/37-3

pg 01-28/C3-35-30/37-Eng 1 12/14/99, 9:48 AM28

Printed In China

3139 116 19372 (ENG)

Philips FW-C30, FW-C3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
