English
Important safety information
Read this important information carefully before you use the appliance and its accessories and save it for future reference. The accessories supplied may vary for different products.
Danger
-Never vacuum up water or any other liquid. Never vacuum up flammable substances and do not vacuum up ashes until they are cold.
-Never immerse the appliance or the adapter in water or any other liquid, nor rinse it under the tap.
Warning
-Check if the voltage indicated on the adapter corresponds to the local mains voltage before you connect the appliance.
-Always check the appliance before you use it. Do not use the appliance or the adapter if it is damaged. Always replace a damaged part with one of the original type.
-The adapter contains a transformer. Do not cut off the adapter to replace it with another plug, as this causes a hazardous situation.
-This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
-Always keep the magnetic charging disc away from very small children.
-The plug must be removed from the socketoutlet before cleaning or maintaining the appliance.
-Unplug the adapter if you are not going to use the appliance for some time.
-Do not let the motorized brush move over the mains cords of other appliances or other cables as this may cause a hazard.
-Keep loose clothing, hair and body parts away from the motorized brushes.
-Do not cover or block the ventilation openings when the appliance is operating.
-To prevent damage, do not use the appliance if the filter is not present in the dust container.
-Do not block the appliance inlet when operating.
-This appliance contains a rechargeable battery that can only be replaced by a skilled person. Do not open the appliance to replace the rechargeable battery.
-The rechargeable battery may only be replaced by qualified service engineers. Take the appliance to an authorized Philips service center to have the battery replaced when you can no longer recharge it or when it runs out of power quickly.
-Do not store the appliance at a temperature above 40 °C or below 5 °C.
-Do not use the appliance in a room with a temperature above 40 °C.
-Do not incinerate, disassemble or expose the appliance to temperatures above 60 °C. The rechargeable battery may explode if overheated.
-This vacuum cleaner is designed for household use only. Do not use this vacuum cleaner to vacuum up building waste, cement dust, ashes, fine sand, lime and similar substances. Never use the vacuum cleaner without any of the filters. This could damage the motor and shorten the life of the vacuum cleaner. Always clean all parts of the vacuum cleaner as shown in the user manual. Do not clean any parts with water and/or cleaning agents if this is not specifically shown in the user manual.
Caution
-Only charge the appliance with the adapter supplied. Only use 25V adapter ZD12D250050EU or 29V adapter ZD12D290050EU.
-During charging, the adapter becomes warm to the touch. This is normal.
-Do not plug in, unplug or operate the appliance with wet hands.
-Do not remove the adapter from the wall socket by pulling at the cord (Fig. 1). Always unplug the appliance by first detaching the magnetic connector from the magnetic charging disk (Fig. 2).
-Always switch off the appliance after use and before you charge it.
-Never block the exhaust air openings during vacuuming.
-Do not clean the dust container and the dust container lid in the dishwasher. They are not dishwasher-proof.
-Make sure to wash the sponge filter at least once every two weeks to ensure best performance.
-Do not clean the filter with scouring pads or abrasive cleaning agents.
-Always use the vacuum cleaner with the filter unit assembled.
-If you clean the filter with water, make sure that it is completely dry before you put it back into the dust container. Do not dry the filter in direct sunlight, on the radiator or in the tumble dryer.
-Replace the filter if it can no longer be cleaned properly or if it is damaged (see 'Ordering accessories').
-Use and store the appliance at a temperature between 5 °C and 40 °C.
-Make sure that the appliance is installed with the wall fixture mounted to the wall according to the instructions in the user manual.
-Be careful when you drill holes in the wall to attach the wall fixture, to avoid the risk of electric shock.
-If you use the appliance to vacuum fine sand, lime, cement dust and similar substances, the pores of the filter will become blocked. Clean the filter regularly.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields.
Ordering accessories
To buy accessories or spare parts, visit www.philips.com/parts-and- accessories or go to your Philips dealer. You can also contact the Philips Consumer Care Center in your country (see the international warranty leaflet for contact details).
Warranty and support
If you need information or support, please visit www.philips.com/support or read the international warranty leaflet.
Recycling
-This symbol means that this product shall not be disposed of with normal household waste (2012/19/EU) (Fig. 3).
-This symbol means that this product contains a built-in rechargeable battery which shall not be disposed of with normal household waste (Fig. 4) (2006/66/EC). Please take your product to an official collection point or a Philips service center to have a professional remove the rechargeable battery.
-Follow your country’s rules for the separate collection of electrical and electronic products and rechargeable batteries. Correct disposal helps prevent negative consequences for the environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when you discard the product. Before you remove the battery, make sure that the product is disconnected from the wall socket and that the battery is completely empty.
Take any necessary safety precautions when you handle tools to open the product and when you dispose of the rechargeable battery.
1Remove the dust container from the appliance.
2Pull the display cover from the top of the handgrip (Fig. 5).
3Undo the screw of the handle cover and pull the handle cover off the appliance (Fig. 6).
4Undo the bottom cover screw (1) and then remove the side panels. (Fig. 7)
5Remove the bottom cover screws on the left and right side (1). Then remove the bottom cover (2) (Fig. 8).
6Disconnect the battery connector and the display connector from the printed circuit board (Fig. 9).
7Undo the battery frame screws (Fig. 10).
8Remove the battery from the appliance and dispose of it according to the rules (Fig. 11).
Troubleshooting
This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Center in your country.
Problem |
Possible cause |
Solution |
|
|
|
The appliance does not work when I push the button.
When the battery is empty,the bottom segment of the display flashes red.
To charge the battery, connect the appliance to the charging base or attach the handheld vacuum cleaner directly to the magnet on the charging base.
|
You have to push the |
Push the slider forward to |
|
slider forward to |
setting 1 to switch on. |
|
switch on the |
Increase the suction power |
|
appliance. |
further by pushing the slider |
|
|
to setting 2 to clean dirty |
|
|
surfaces. |
|
|
|
The appliance has |
The filter and the |
Clean the filter and the |
a lower suction |
cyclone are dirty. |
cyclone. Make sure that you |
power than usual. |
|
wash the sponge filter at |
|
|
least once every two weeks if |
|
|
you use the appliance |
|
|
regularly. |
|
|
|
|
You have not |
Make sure that you attach |
|
attached the dust |
the dust container lid to the |
|
container lid properly |
dust container and the dust |
|
to the dust container. |
container to the appliance |
|
You have not |
properly. |
|
attached the dust |
|
|
container to the |
|
|
appliance properly. |
|
|
In both cases, there |
|
|
will be a loss of |
|
|
suction power. |
|
|
|
|
|
An object may be |
Remove the tube and check |
|
stuck inside the tube. |
for blockages. |
|
|
|
Dust escapes from |
The filter is dirty. |
Clean the filter. |
the appliance. |
|
|
|
|
|
|
The filter is not |
Make sure that the filter is in |
|
present in the |
the appliance and assembled |
|
appliance. |
correctly. |
|
|
|
|
Something blocks |
Check the cyclone for objects |
|
the cyclone. |
stuck in it and remove any |
|
|
object that blocks the |
|
|
cyclone. |
|
|
|
|
If dust falls out of the |
Empty the dust container and |
|
dust container, the |
attach the dust container lid |
|
dust container lid is |
correctly. |
|
probably not |
|
|
attached properly to |
|
|
the dust container. |
|
|
|
|
The appliance does |
You selected a too |
Reduce the suction power by |
not move smoothly |
high suction power. |
choosing setting 1. |
across the floor |
|
|
when cleaning a |
|
|
carpet. |
|
|
|
|
|
The brush does not |
The brush |
Clean the brush with a pair of |
turn anymore. |
encounters too much |
scissors or by hand. |
|
resistance. |
|
|
|
|
|
The brush may stop |
Switch off the appliance and |
|
turning when it |
then switch it back on again. |
|
encounters too much |
|
|
resistance from high- |
|
|
pile carpet. |
|
|
|
|
|
You have not |
Follow the instructions in the |
|
installed the roller |
cleaning chapter of the user |
|
brush in the nozzle |
manual to slide the roller |
|
properly after |
brush into the nozzle |
|
cleaning. |
properly and secure it inside |
|
|
the nozzle by snapping home |
|
|
the locking lever. |
FC6727, FC6726, |
You have not |
FC6725, FC6723: |
attached the nozzle |
The LEDs in the |
to the appliance or |
nozzle do not |
handheld properly. |
come on. |
|
Attach the nozzle to the appliance or handheld properly.
The appliance is |
The magnetic |
not charging. |
connector is not not |
|
connected correctly |
|
to the charging disk |
|
or the adapter is not |
|
inserted into the wall |
|
socket properly. |
Make sure that the magnetic connector is connected properly to the charging disk and that the adapter is inserted into the wall socket properly.
|
You have not |
Make sure that you use the |
|
connected the |
correct adapter and cord. |
|
correct adapter and |
|
|
cord. |
|
|
|
|
|
|
If you have checked the |
|
|
above and the appliance still |
|
|
does not charge, take it to a |
|
|
Philips service center or |
|
|
contact the Consumer Care |
|
|
Center via |
|
|
www.philips.com/support. |
|
|
|
FC6727, FC6726: |
The roller brush is |
Remove hairs from the brush |
The mini turbo |
blocked. |
with a pair of scissors (see |
brush does not |
|
user manual). |
function properly. |
|
|
|
|
|
|
The roller brush is |
Keep the mini turbo brush |
|
blocked by fabric or |
aligned with the surface and |
|
surfaces during |
do not push the turbo brush |
|
cleaning. |
into soft surfaces. |
|
|
|
|
The mini turbo brush |
Make sure that the top and |
|
is not fully closed. |
bottom parts of the mini |
|
|
turbo brush are properly |
|
|
connected and there is no |
|
|
gap between the two parts. |
|
|
Check if the locking ring is in |
|
|
closed position (see user |
|
|
manual). |
|
|
|
When I use my |
Your vacuum cleaner |
Discharge the appliance by |
vacuum cleaner I |
builds up static |
frequently holding the tube |
sometimes feel |
electricity. The lower |
against other metal objects in |
static electricity |
the air humidity, the |
the room (for example the |
shocks. |
more static electricity |
legs of a table or chair, etc.). |
|
the appliance builds |
You can also raise the air |
|
up. |
humidity level in the room. |
|
|
|
|
You vacuumed up |
Empty the dust container and |
|
fine sand, lime or a |
clean the filter according to |
|
similar substance. |
the instructions in the user |
|
This also causes |
manual. |
|
static electricity. |
|
|
|
|
The bottom |
The battery is empty. |
To charge the battery, |
segment of the |
|
connect the appliance to the |
display flashes red. |
|
charging base or attach the |
|
|
handheld vacuum cleaner |
|
|
directly to the magnet on the |
|
|
charging base. |
|
|
|
All segments of the |
An error has |
First try to recharge the |
display flash |
occurred. |
appliance, empty the dust |
quickly. |
|
container and clean the filter. |
|
|
If this does not help, take the |
|
|
appliance to a Philips service |
|
|
center or contact the |
|
|
Consumer Care Center via |
|
|
www.philips.com/support. |
Русский
Важные сведения о безопасности - Дополнение к эксплуатационной документации
Перед началом эксплуатации прибора и аксессуаров к нему внимательно ознакомьтесь с этой важной информацией и сохраните ее для дальнейшего использования в качестве справочного материала. Входящие в комплект аксессуары могут различаться в зависимости от вида продукта.
Опасно!
-Запрещается убирать при помощи пылесоса воду и другие жидкости. Запрещается применять пылесос для уборки огнеопасных веществ или неостывшего пепла.
-Запрещается погружать прибор или адаптер в воду или в любую другую жидкость, а также промывать их под краном.
Предупреждение
-Перед подключением прибора убедитесь, что номинальное напряжение, указанное на адаптере, соответствует напряжению местной электросети.
-Перед использованием всегда проверяйте прибор. Не используйте прибор или адаптер, если они повреждены. Для замены поврежденной детали выбирайте оригинальные комплектующие.
-В конструкцию адаптера входит трансформатор. Запрещается заменять оригинальный штекер адаптера: это опасно.
-Данным прибором могут пользоваться дети старше 8 лет и лица с ограниченными возможностями сенсорной системы или ограниченными умственными или физическими способностями, а также лица с недостаточным опытом и знаниями, но только под присмотром других лиц или после инструктирования о безопасном использовании прибора и потенциальных опасностях. Не позволяйте детям играть с прибором. Дети могут осуществлять очистку и уход за прибором только под присмотром взрослых.
-Всегда храните магнитный зарядный диск в месте, недоступном для маленьких детей.
-Перед очисткой или выполнением технического обслуживания прибора всегда извлекайте вилку из розетки электросети.
-Если вы не планируете пользоваться прибором в течение длительного времени, отсоедините адаптер.
