Portable MP3-CD Player

EXP311 EXP313

Audio

# $

8 7

A L

B U

• T IT

L E

S E

A R

ALBUM • TITLE

F F

• R

• H

Y A L

P IS D

DBB

ESP

5 4

)

(

EnglishFrançaisEspañolDeutsch

English ––––––––––––––––––––––––––––––––––––––––––– 6

Français ––––––––––––––––––––––––––––––––––––––––– 26

Español –––––––––––––––––––––––––––––––––––––––––– 46

Deutsch ––––––––––––––––––––––––––––––––––––––––– 66

Quick start –––––––––––––––––––––––––––––––––––––––––– 7

Controls ––––––––––––––––––––––––––––––––––––––––––––– 8

General information

Maintenance –––––––––––––––––––––––––––––––––––––––– 9 Environmental information ––––––––––––––––––––––––––––– 9 MP3 music ﬁles –––––––––––––––––––––––––––––––––– 10–11

Power supply

Batteries –––––––––––––––––––––––––––––––––––––––––– 12 Mains adapter –––––––––––––––––––––––––––––––––––––– 13

Headphones –––––––––––––––––––––––––––––––––––––––– 13

Basic functions

Playing a disc ––––––––––––––––––––––––––––––––––––––– 14 Pause –––––––––––––––––––––––––––––––––––––––––––– 15 Volume and sound –––––––––––––––––––––––––––––––––– 15 Selecting and searching on all discs –––––––––––––––––––––– 16 Selecting albums and tracks on MP3-CDs –––––––––––––––– 17

Features

Track and album information ––––––––––––––––––––––––––– 18 Beep ––––––––––––––––––––––––––––––––––––––––––––– 18 Programming track numbers –––––––––––––––––––––––––– 19 Clearing the programme ––––––––––––––––––––––––––––– 19 Playing tracks repeatedly or in random order – MODE –––––– 20 Storing the last position played – RESUME –––––––––––––––– 21 Locking all buttons – HOLD ––––––––––––––––––––––––––– 21 ESP and powersaving –––––––––––––––––––––––––––––––– 22

Accessories

Belt clip ––––––––––––––––––––––––––––––––––––––––––– 22 In-car connections (supplied or optionally available) ––––––––– 23

Troubleshooting ––––––––––––––––––––––––––––––––– 24–25

Contents

English

Quick start

English

!!!

12p

3 #

4 HOLD ➠ OFF 5 PLAY 2; 6 VOL E

I T

This set complies with the radio interference requirements of the European Community.

O F

•

R E

S U

•

H O

L D

L I

E O

T /

ESP

DISPLA

E L

T I

•

B L

A E

•

F F

•R E S

U M

•

H O L

L I

N E

O U

C H

M M

•

ALBUM • TITLE

L O

ESP

O F

•

R E S

U M

•

H O

I N

O U

DBB

. L

O V

N E P

1 OPEN 2

opens the CD lid

2 VOL E

adjusts the volume

3 2;

switches the set on, starts playback and interrupts playback

4 ESP

Electronic Skip Protection

prevents music interruptions caused by shocks or vibrations

5 DBB

Dynamical Bass Boost, selects the

bass enhancement

6 §

skips forward and searches forward

7 +

MP3-CD only: selects the next album or skips forward

8 DISPLAY

selects the track and album information for MP3-CDs

9 display 0 −

MP3-CD only: selects the previous album or skips backward

! ∞

skips backward and searches backward

@ OFF·RESUME·HOLD

OFF switches RESUME and HOLD off RESUME stores the last position played HOLD locks all buttons

# 9

stops playback, clears a programme and switches the set off

$ PROGRAM

programs tracks and lets you review the programme

% MODE

selects playback options such as

SHUFFLE and REPEAT

^ LINE OUT/p

3.5 mm line out socket to connect – the headphones – this set to the audio input

of your stereo equipment

& 4.5V DC

to connect the mains adapter (supplied or optionally available)

* battery compar tment ( type plate ) belt clip hole

Controls, refer to the illustrations on page 3

English

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Maintenance

Do not touch the lens A of the set.

Do not expose the set, batteries or discs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight).

The lens may cloud over when the set is suddenly moved from cold to warm surroundings. Playing is not possible then. Leave the set in a warm environment until the moisture evaporates.

Active mobile phones in the vicinity of this set may cause malfunctions.

Avoid dropping the set; this may cause damage.

Clean the set with a soft, slightly dampened lint-free cloth. Do not use any cleaning agents; they may have a corrosive effect.

To clean a disc, wipe it in a straight line from the centre towards the edge using a soft, lint-free cloth. Cleaning agents may damage the disc.

Environmental information

All redundant packing material has been omitted. We have done our utmost to make the packaging easily separable into three mono materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packing materials, exhausted batteries and old equipment.

General information

English

MP3 music ﬁles

The music compression technology MP3 (MPEG 1 Audio Layer 3) reduces the digital data of an audio CD signiﬁcantly while maintaining CD-like sound quality.With MP3 you can record up to 10 hours of CD-like music on a single CD-ROM.

How to get music ﬁles

Either download legal music ﬁles from the internet to your computer hard disc or create them from your own audio CDs. For this, insert an audio CD into your computer´s CD-ROM drive and convert the music using an appropriate encoder software.To achieve a good sound quality, a bit rate of 128 kbps or higher is recommended for MP3 music ﬁles.

How to organize music ﬁles

In order to easily handle the large number of music ﬁles on a CD-ROM, you can organize them in folders (“albums”).

The tracks of an album will be played in alphabetical order. If you want to arrange them in a cer tain order, let the ﬁle names start with numbers. For example:

001-ONEWORLD.MP3 002-FIRESTARTER.MP3 003-DEEP.MP3

Albums will be arranged in alphabetical order, but subfolders (albums within another album) will be played immediately after the album in which they are located. Albums without MP3 ﬁles will be skipped.

If there are MP3 ﬁles which you did not put into an album, you will ﬁnd them in the album VARIOUS with album number 0. VARIOUS is the ﬁrst album that will be played.

When playing a disc with CD Audio tracks and MP3 ﬁles, the CD Audio tracks will be played ﬁrst.

General information

English

How to make a CD-ROM with MP3 ﬁles

Use your computer´s CD burner to record (“burn”) the music ﬁles from your hard disc on a CD-ROM. Use either ISO 9660 disc format or UDF. Some CD burner software like e. g.“DirectCD” support the UDF format.

Make sure that the ﬁle names of the MP3 ﬁles end with .mp3.

Supported formats

This set supports: – Disc format: ISO 9660, Joliet, Multisession, UDF,

Enhanced Music CD, Mixed Mode CD – MP3 bit rate: 32–320 kbps and variable bit rate – Total number of music ﬁles and albums: around 350

(with a typical ﬁle name length of 20 characters)

Note:The number of music ﬁles that can be played depends on the length of the ﬁle names. With short ﬁle names more ﬁles will be supported.

All trademarks used are owned by their respective owners.

General information

English

Batteries (supplied or optionally available)

Inserting batteries

Open the battery compar tment and insert 2 alkaline batteries of type AA (LR6, UM3).

Do not mix old and new or different types of batteries.

Indication of empty batteries

● Replace the batteries or connect the

mains adapter as soon as Ablinks and REPLACE BATTERIES is scrolled.

Remove batteries if they are empty or if the set will not be used for a long time.

Batteries contain chemical substances, so they should be disposed of properly.

Average playing time of 2 alkaline batteries under normal conditions:

Audio disc MP3-CD

ESP on 11 hours 11 hours

ESP and powersaving on 15 hours 23 hours

Power supply

English

Mains adapter (supplied or optionally available)

Use only the AY 3170 mains adapter (4.5 V/ 300 mA direct current, positive pole to the centre pin). Any other product may damage the set.

1 Make sure the local voltage corresponds to

the adapter´s voltage.

2 Connect the mains adapter to 4.5V DC on

the set and to the wall socket.

Note: Always disconnect the adapter if you are not using it.

Headphones (SBC HE 205)

● Connect the supplied headphones to

LINE OUT/p.

Note: LINEOUT/p can also be used for connecting this set to your HiFi system. Set VOL E on this set to position 8 and adjust volume and sound with your HiFi system.

Use your head when using headphones

Hearing safety Do not play your headphones at a high volume. Hearing experts advise that continuous use at high volume can permanently damage your hearing.

Trafﬁc safety Do not use headphones while driving a vehicle. It may create a hazard and it is illegal in many countries. Even if your headphones are an open-air type designed to let you hear outside sounds, do not turn up the volume so high that you cannot hear what is going on around you.

Power supply/Headphones

English

F F

•

S U

•

H O

L I

Playing a disc

With this set you can play – audio discs (pre-recorded audio CDs,

ﬁnalized audio CDRs and CDRWs)

– MP3-CDs (CD-ROMs with MP3 ﬁles)

1 Push the OPEN 2 slider to open the CD lid.

2 Insert a disc, printed side up, by pressing gently

on the disc´s centre so that it ﬁts onto the hub. Close the lid by pressing it down.

3 Press 2; to star t playback.

➜ READ CD is displayed. Playback starts.

Audio disc:The current track number and the elapsed playing time are displayed.

MP3-CD:The ﬁlename is scrolled once.

4 To stop playback, press 9.

➜ Audio disc: The number of tracks and the

total playing time of the disc are displayed. MP3-CD:The number of albums and the number of tracks are displayed.

5 To remove the disc, hold it by its edge and

press the hub gently while lifting the disc.

Notes:

After pressing 2; it may take some time until

the ﬁrst MP3 track is played.

The display switches off 20 seconds after

pressing 9. After 90 seconds the set switches off automatically.

Basic functions

English

ESP

. L O

ALBUM

• TITLE

E L

• M

B L

R A

E S

OGRAM

F F

•

RES

•

O L

I N

P IS D

DBB

ESP

MODE

. L

Pause

1 Press 2; to interrupt playback.

➜ The elapsed playing time blinks.

2 To resume playback press 2; again.

Volume and sound

Volume adjustment

● Adjust the volume by using VOL E.

Sound adjustment

1 Press DBB for a moderate bass enhancement.

➜ appears and DBB 1 is displayed.

2 Press DBB again for a strong bass

enhancement.

➜ appears and DBB 2 is displayed.

3 Press DBB again to switch the bass

enhancement off.

➜ disappears and DBB OFF is displayed.

Basic functions

English

DBB

ITLE

ESP

Selecting and searching on all discs

Selecting a track during playback

● Brieﬂy press ∞ or § once or several times to

skip to the beginning of the current, previous or subsequent track.

➜ Playback continues with the selected track.

Searching for a passage during playback

1 Keep ∞ or § pressed to ﬁnd a particular

passage in backward or forward direction.

➜ Searching star ts and playback continues at a low volume.

2 Release the button at the desired passage.

➜ Normal playback continues.

Note: During SHUFFLE ALBUM, SHUFFLE ALL, REPEAT SHUFFLE ALBUM,

REPEAT SHUFFLE ALL, REPEAT, REPEAT ALBUM or while playing a programme,

searching is only possible within the current track.

Basic functions

English

E L

ALBUM

• TITLE

• UM B

L A

H C

A E

OGRAM

P IS D

ESP

MODE

Selecting albums and tracks on MP3-CDs

Selecting an album during playback

● Brieﬂy press − or + once or several times to

skip to the ﬁrst track of the current, previous or subsequent album.

➜ The ﬁrst track of the selected album is

played.

Selecting a track during playback

1 Keep − or + pressed to skip quickly to previous or subsequent MP3 tracks.

➜ Skipping star ts and speeds up after 5 seconds.

2 Release the button at the desired track.

➜ Playback continues with the selected track.

Note:To skip from track to track at low speed, use ∞ or §.

Basic functions

English

L IT

• T M

U B L

H C

R A

ALBUM

• TITLE

Y A L

MODE

OGRAM

ESP

Track and album information (for MP3 tracks only)

● Press DISPLAY repeatedly during playback to

select the following track information: – the track number and the elapsed playing

time, – ALBUM: the album´s folder name, – ARTIST: the ar tist´s name (if this ID3 tag

information is available), – TITLE: the track´s title (if this ID3 tag

information is available), – FILENAME: the track´s ﬁle name.

Note:The ID3 tag is part of an MP3 ﬁle and contains various track information such as the track´s title or the artist´s name. Complete the ID3 tag information with your MP3 encoder software before burning the MP3-CD.

Beep

A beep conﬁrms that you have pressed a button or that the batteries are empty.

● Keep DBB pressed for 2 seconds to switch

beep either on or off:

➜ BEEP is displayed: Beep is switched on. ➜ NO BEEP is displayed: Beep is switched off.

Features

English

BUM • TITLE

ITLE

ESP

Programming track numbers

You can select up to 50 tracks and store them in the memor y in a desired sequence.You can store any track more than once.

1 Select a track with ∞, §, − or +.

2 Press PROGRAM to store the track.

➜ PROGRAM appears and P with the number

of stored tracks is displayed.

3 Select and store all desired tracks in this way.

4 If necessary press 9 to stop normal playback.

Press 2; to star t playback of the programme.

To add additional tracks to the programme, stop playback of the programme by pressing 9 and continue with step 1.

To review the programme, keep PROGRAM pressed for more than 3 seconds.

➜ All stored tracks are displayed in sequence.

Clearing the programme

1 If necessary press 9 to stop playback.

2 Press 9 to clear the programme.

➜ PROGRAM CLEARED is scrolled, PROGRAM

disappears and the programme is cleared.

Notes:

The programme will also be cleared if you interrupt the power supply or open

the CD lid or if the set switches off automatically.

After storing 50 tracks, PROGRAM FULL is scrolled.

Features

English

BUM • TITLE

Playing tracks repeatedly or in random order – MODE

1 Press MODE repeatedly during playback to

select either: – SHUFFLE ALBUM (with MP3-CDs only):

All tracks of the current album are played in

random order once. – SHUFFLE ALL: All tracks of the disc are

played in random order once. – REPEAT SHUFFLE ALBUM (with MP3-CDs only):

All tracks of the current album are played

repeatedly in random order. – REPEAT SHUFFLE ALL: All tracks of the disc

are played repeatedly in random order. – REPEAT:The current track is played

repeatedly. – REPEAT ALBUM (with MP3-CDs only):

All tracks of the current album are played repeatedly. – REPEAT ALL:The entire disc is played repeatedly.

➜ Playback star ts in the selected mode after 2 seconds.

2 To return to normal playback, press MODE repeatedly until REPEAT and

SHUFFLE disappear.

Note:While playing a programme, you can select either SHUFFLE PROGRAM,

SHUFFLE REPEAT PROGRAM or REPEAT PROGRAM.

Features

English

ALBUM • TITLE

PRO

Storing the last position played – RESUME

You can store the last position played.When restarting, playback will continue from where you have stopped.

1 Switch the slider to RESUME during playback

to activate RESUME.

➜ RESUME appears.

2 Press 9 whenever you want to stop playback.

3 Press 2; to resume playback.

➜ Playback continues from where you have

stopped.

To deactivate RESUME, switch the slider to OFF.

➜ RESUME disappears.

Locking all buttons – HOLD

You can lock all buttons of the set. When you press any key, no action will take place.

● Switch the slider to HOLD to activate HOLD.

➜ RESUME appears and HOLD is displayed.All

buttons are locked.When pressing any key, HOLD is displayed.

To deactivate HOLD, switch the slider to OFF.

➜ RESUME disappears.

Features

English

PROGRAM

•

ESP and powersaving

With a conventional portable disc player the music may skip or stop if the player is shaken or jarred.The Electronic Skip Protection protects this set against loss of sound caused by light vibrations or shocks. Continuous playback is ensured. ESP does not protect the set against damage caused by dropping! Powersaving increases the batter y playing time.

● Press ESP repeatedly during playback to

switch ESP and powersaving on or off:

➜ ESP ON: appears and ESP is switched

on.

➜ ESP OFF: disappears. ESP is switched

off to achieve the highest sound quality for CD Audio tracks.

➜ POWERSAVING: appears.

ESP and powersaving are switched on. The battery playing time is increased and the skip protection time slightly decreased.

Belt clip

1 Align the belt clip as indicated in the illustration

and press on the clip to insert its shaped pin into the hole in the set.

2 Turn the clip clockwise as indicated to lock the

belt clip to the set.

To detach, gently lift the belt clip where LIFT is indicated and turn it counter-clockwise.

Features/Accessories

English

ITLE

DBB

ESP

In-car connections (supplied or optionally available)

Use only the AY 3545 or AY 3548 car voltage converter (4.5 V DC, positive pole to the centre pin) and the AY 3501 car adapter cassette. Any other product may damage the set.

1 Put the set on a horizontal, vibration-free and

stable surface. Make sure it is in a safe place, where the set is neither a danger nor an obstacle to the driver and the passengers.

2 Plug the voltage converter into the cigarette

lighter socket (only for a 12 V car battery, negative grounding), then connect the

wired end with the 4.5V DC input socket on the set.

3 If necessary, clean the cigarette lighter socket to obtain a good electrical

contact.

4 Turn down the volume and connect the adapter cassette plug to

LINE OUT/p on the set.

5 Carefully insert the adapter cassette into the car radio’s cassette

compartment.

6 Make sure the cord does not hinder your driving.

7 Set VOL E on the set to position 8. Star t playback on the set and adjust

the sound with the car radio controls.

Always remove the voltage converter from the cigarette lighter socket when the set is not in use.

Note: If your car radio has a LINE IN socket, it is better to connect the set to this socket instead of using the adapter cassette. Connect LINE OUT/p of the set with the LINE IN socket of your car radio with an appropriate cable.

Accessories

English

4.5V DC

LINE OUT

12 V

A L B

U M

•

T I

T L E

S E A

T I T

•

UM LB A

A L P S I

C R A E S

DBB

P S E

O R P

F F

•RE S

U M E

•

O L D

L I

N E O

U T

N E

L O V

WARNING

Under no circumstances should you try to repair the set yourself as this will invalidate the guarantee. If a fault occurs, ﬁrst check the points listed, before taking the set for repair. If you are unable to solve a problem by following these hints, consult your dealer or service centre.

Problem Solution

No power, playback – Insert the batteries correctly. does not start – Replace the batteries.

– Connect the mains adapter securely.

HOLD indication – Deactivate HOLD. and/or no reaction – Disconnect the set from the power supply to controls or take out the batteries for a few seconds.

No sound or – Press 2; to resume playback. bad sound quality – Adjust the volume.

– Check and clean the connections. – Keep this set away from active mobile

phones or strong magnetic ﬁelds.

INSERT CD – Insert a disc, label upwards. or – Clean or replace the disc. NO AUDIO FILE – Wait until the steamed up lens has cleared. indication – Make sure you have inser ted an audio disc

or an MP3-CD.

UNFINALIZED CD – Make sure the inserted CDR or CDRW is indication ﬁnalized.

Troubleshooting

English

Problem Solution

Music ﬁle is not played – Make sure that the ﬁle names of the

MP3 ﬁles end with .mp3

Missing directories on – Make sure the total number of ﬁles MP3-CD and albums on your MP3-CD does not

exceed 350.

– Only albums with MP3 ﬁles are shown.

The disc skips tracks – Clean or replace the disc.

– Make sure REPEAT, SHUFFLE and PROGRAM

are not selected.

Music skips – Play the music ﬁle on your computer. If the or popping sound problem persists, encode the audio track when playing an again and make a new CD-ROM. MP3 ﬁle

Music is interrupted – Switch ESP on. and OOPS indication

In-car use: – Clean the cigarette lighter socket. No power, playback – Switch on the ignition of your car. does not start

In-car use: – Insert the adapter cassette correctly. No sound or – Change the autoreverse direction of bad sound quality your car cassette player.

– Let the set adjust to the temperature

in the car.

Troubleshooting

English

Mise en service rapide –––––––––––––––––––––––––––––––– 27

Commandes ––––––––––––––––––––––––––––––––––––––––– 28

Informations générales

Entretien ––––––––––––––––––––––––––––––––––––––––––– 29 Informations relatives à l’environnement ––––––––––––––––––– 29 Les ﬁchiers de musique MP3 ––––––––––––––––––––––––– 30–31

Alimentation

Piles ––––––––––––––––––––––––––––––––––––––––––––––– 32 Adaptateur de secteur ––––––––––––––––––––––––––––––––– 33

Ecouteurs –––––––––––––––––––––––––––––––––––––––––––– 33

Fonctions de base

Lecture d'un disque ––––––––––––––––––––––––––––––––––– 34 Pause –––––––––––––––––––––––––––––––––––––––––––––– 35 Volume et son ––––––––––––––––––––––––––––––––––––––– 35 Sélection et recherche sur tous les disques ––––––––––––––––– 36 Sélection d'albums et de pistes sur les CD-MP3 ––––––––––––– 37

Fonctions

Informations sur une piste et un album –––––––––––––––––––– 38 Signal acoustique ––––––––––––––––––––––––––––––––––––– 38 Programmation des numéros de piste ––––––––––––––––––––– 39 Effacement du programme ––––––––––––––––––––––––––––– 39 Lecture répétée ou aléatoire de pistes – MODE –––––––––––– 40 Mise en mémoire de la dernière position de lecture – RESUME –– 41 Verrouillage de tous les boutons – HOLD ––––––––––––––––– 41 ESP et fonction économie d'énergie –––––––––––––––––––––– 42

Accessories

Clip ceinture –––––––––––––––––––––––––––––––––––––––– 42 Branchements en voiture (fournis ou disponibles séparément) ––– 43

Guide de dépannage ––––––––––––––––––––––––––––––– 44–45

Table des matières

Français

+ 60 hidden pages
