Philips DCB293/79 user manual

Download

www.philips.com/welcome

DCB293

EN User manual

Contents

1 Important 4

Safety 4 Notice 5

2 Your Micro Hi-Fi System 7

Introduction 7 What’s in the box 7 Overview of the main unit 8 Overview of the remote control 9

3 Get started 11

Placement 11 Prepare the remote control 11 Connect power 11 Auto install radio stations 12 Set clock 12 Turn on 12

4 Play 13

Play a disc 13 Play from USB 13 Play iPod/iPhone 13

7 Other features 20

Set the alarm timer 20 Set the sleep timer 20 Play from an external device 20 Listen through headphone 20

8 Product information 21

Speciﬁcations 21 USB playability information 22 Supported MP3 disc formats 22 Maintenance 22

9 Troubleshooting 23

English

5 Listen to radio 15

Listen to Digital Audio Broadcasts (DAB+) 15 Listen to FM radio 17

6 Play options 18

Pause/resume play 18 Skip to a track 18 Search within a track 18 Select repeat/shufﬂe play options 18 Program tracks 18 Display time 18 Adjust volume level 18 Mute sound 19 Select a preset sound effect 19 Enhance bass 19

1 Important

Safety

Important Safety Instructions

a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

h Do not install near any heat sources

such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

i Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

j Only use attachments/accessories

speciﬁed by the manufacturer.

k Use only with the cart, stand, tripod,

bracket, or table speciﬁed by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

l Unplug this apparatus during lightning

storms or when unused for long periods of time.

m Refer all servicing to qualiﬁed service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

n Battery usage CAUTION – To prevent

battery leakage which may result in bodily injury, property damage, or damage to the unit:

Install all batteries correctly, + and - • as marked on the unit. Do not mix batteries (old and new • or carbon and alkaline, etc.). Remove batteries when the unit is • not used for a long time.

o Apparatus shall not be exposed to

dripping or splashing.

p Do not place any sources of danger on

the apparatus (e.g. liquid ﬁlled objects, lighted candles).

q Where the MAINS plug or an appliance

coupler is used as the disconnect device, the disconnect device shall remain readily operable.

Warning

Never remove the casing of this apparatus. • Never lubricate any part of this apparatus. • Never place this apparatus on other electrical • equipment. Keep this appar atus away from direct sunlight, • naked ﬂames or heat.

•

Never look into the laser beam inside this apparatus. Ensure that you always have easy access to the

•

power cord, plug or adaptor to disconnect this appar atus from the power.

Hearing safety

Notice

Listen at a moderate volume.

Using headphones at a high volume can • impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss. Sound can be deceiving. Over time your • hearing ‘comfor t level’ adapts to higher volumes of sound. So af ter prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting. • Slowly increase the sound until you can • hear it comfortably and clearly, without distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even • at normally ‘safe’ levels, can also cause hearing loss. Be sure to use your equipment • reasonably and take appropriate breaks.

Be sure to observe the following guidelines when using your headphones.

Listen at reasonable volumes for • reasonable periods of time. Be careful not to adjust the volume as • your hearing adapts. Do not turn up the volume so high that • you can’t hear what’s around you. You should use caution or temporarily • discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may create a trafﬁc hazard and is illegal in many areas.

Any changes or modiﬁcations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment.

This product complies with the radio inter ference requirements of the European Community.

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste.Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

English

Environmental information

All unnecessar y packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

The making of unauthorized copies of copy-protected material, including computer programs, ﬁles, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offence. This equipment should not be used for such purposes.

Windows Media and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

This apparatus includes this label:

Note

The type plate is located on the bottom of the • apparatus.

2 Your Micro Hi-

What’s in the box

Fi System

Congratulations on your purchase, and welcome to Philips! To fully beneﬁt from the support that Philips offers, register your product at www.philips.com/welcome.

Introduction

With this unit, you can enjoy audio from discs, USB devices, iPod players, iPhone and listen to tuner/Digital Audio Broadcasting (DAB) radio stations, or other external devices. The unit offers Digital Sound Control (DSC) and Dynamic Bass Boost (DBB) to enrich sound. The unit supports the following media formats:

Check and identify the contents of your package:

Main unit• Remote control• Power adaptor• 1 x MP3 link cable• Mounting kit (2 dowels and 2 screws)• Quick star t guide• User manual • Wall mounting instructions•

English

Overview of the main unit

n m

l k

c d

g h

Jack for a USB mass storage device. •

b MP3 LINK

Audio input jack (3.5mm) for an • external audio device.

c SOURCE

Select a source: CD, iPod, FM/DAB, • USB, or MP3 link.

Skip to the previous/next track.• Search within a track.• Tune to a radio station.• Adjust hour/minute digits. • Select 12 hour or 24 hour format.•

e Display panel

Show current status.•

f Disc compartment g Eco-power indicator

Turn on the unit, or switch to • standby mode, or switch to Eco Power standby.

i Dock for iPod/iPhone

Remote control sensor. •

Open/close the disc compartment.•

k /MENU

Stop play or erase a program.• Access and exit a menu. •

l VOLUME + / -

Adjust volume.•

/ENTER

Star t or pause play.• Conﬁrm a selection.• Access the iPod menu.• In FM mode, switch between mono • and stereo signals.

p o

Jack for the headphone.•

Overview of the remote control

b c

e f

h i j

l m n

OPEN/CLOSE

PRESET/ALBUM

ENTER

MP3 LINK

USB

DISPLAY MENU

RDS

VOL

456

789

PROG/

CLOCK SET

SLEEP/ TIMER

MODE/

SCAN

DSC DBB

TUNER

DAB

Turn on the unit, or switch to • standby mode, or switch to Eco Power standby.

b OPEN/CLOSE

Open or close the disc • compartment.

c CD

Select disc source.•

Navigate in the iPod/DAB menu.• Skip to the previous/next album.• Skip to the previous/next radio • station.

Navigate in the iPod/DAB menu.• Skip to the previous/next album. • Skip to the previous/next track.• Search within a track. • Tune to a radio station.• Adjust hour/minute digits.• Select 12 hour or 24 hour format.•

/ENTER

Star t or pause play.• Conﬁrm a selection. • Access the iPod menu.• In FM mode, switch between mono • and stereo signals.

g USB/MP3 LINK

Select USB device source.• Select external audio device source.•

h RDS/DISPLAY (RDS not available)

Display time. • Display DAB information. • Select display information during play.•

Mute or restore volume.•

j VOL +/-

Adjust volume.•

k Numeric keypad

Select a track from a disc directly.• Select a preset radio station. •

l PROG/CLOCK SET

Program tracks.• Program radio stations.• Set the clock.•

m SLEEP/TIMER

Set the sleep timer.• Set the alarm timer.•

English

n DSC

Select a preset sound setting.•

o DBB

Turn on or off dynamic bass • enhancement.

p MODE/SCAN

Select repeat/shufﬂe play mode. • Scan FM/DAB radio stations. •

/MENU

Stop play or erase a program.• Access and exit a menu. •

r iPod/iPhone

Select iPod/iPhone source.•

s DAB/ TUNER

Select DAB/tuner source. •

3 Get started

Caution

Use of controls or adjustments or • performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the rear of the apparatus. Write the numbers here: Model No. __________________________ Serial No. ___________________________

English

Note

If you are not going to use the remote control • for a long time, remove the batteries. Do not use old and new or different types of • batteries in combination. Batteries contain chemical substances, so they • should be disposed of properly.

Connect power

Placement

You can place the unit on a ﬂat surface or mount the unit on a wall.

Mount on a wall

To wall mount the unit, see the included separate sheet of wall mounting instructions.

Prepare the remote control

Caution

Risk of explosion! Keep batteries away from • heat, sunshine or ﬁre. Never discard batteries in ﬁre.

To insert the remote control battery:

1 Open the battery compartment. 2 Inser t 2 AAA batteries (not supplied)

with correct polarity (+/-) as indicated.

3 Close the battery compartment.

Caution

Risk of product damage! Ensure that the power • voltage corresponds to the voltage printed on the back or underside of the apparatus. Risk of electric shock! When you unplug the

•

AC adaptor, always pull the plug from the socket. Never pull the cord. Before connecting the AC adaptor, ensure you

•

have completed all other connections.

1 Connect the power adaptor to:

the • DC IN jack on the main unit. the wall outlet.•

Auto install radio stations

When you connect power and no radio stations are stored, the unit automatically begins to store radio stations.

1 Connect the unit to the power supply.

[ » AUTO INSTALL PRESS - PLAY KEY](auto install press - play key) is

displayed.

2 Press on the main unit to start

installation.

The unit automatically stores radio » stations with sufﬁcient signal strength.

When all the available radio stations » are stored, the ﬁrst preset radio station is broadcast automatically.

Set clock

7 Press PROG/CLOCK SET to conﬁrm.

The minute digits are displayed and » begin to blink.

8 Press / to set the minute. 9 Press PROG/CLOCK SET to conﬁrm the

clock setting.

Turn on

1 Press .

The unit switches to the last selected » source.

Switch to standby

1 Press again to switch the unit to

standby mode.

The clock (if set) appears on the » display panel.

Note

You can set the clock in the standby mode • only.

1 Press and hold PROG/CLOCK SET to

enter the clock setting mode.

» [SET CLOCK] (set clock) scrolls on

the screen.

» [Synch On] (synch on) is displayed.

2 Press / to select [Y] or [N].

• [Y]: the unit reads the DAB/RDS time and sets the clock automatically.

• [N]: the unit turns off the time synchronization.

3 Press PROG/CLOCK SET to conﬁrm. 4 Press / repeatedly to select 12 hour

or 24 hour format.

5 Press PROG/CLOCK SET to conﬁrm.

The hour digits are displayed and begin » to blink.

6 Press / to set the hour.

To switch the unit to Eco Power Standby mode:

1 Press and hold for more than 2

seconds.

The backlight on the display panel » turns off.

Tip

The unit switches to Eco Power Standby mode • after 15 minutes in standby mode.

To switch between standby mode and Eco Standby Mode:

1 Press and hold for more than 2

seconds.

4 Play

Play iPod/iPhone

Play a disc

1 Press CD to select the disc source. 2 Press to open the disc compartment. 3 Inser t a disc with the printed side facing

outward.

4 Press to close the disc compar tment.

Play starts automatically. If not, press »

Play from USB

Note

Ensure that the USB device contains playable • audio content.

1 Inser t the USB device into the socket.

You can enjoy audio from iPod/iPhone through this Micro Hi-Fi system.

Compatible iPod/iPhone

Apple iPod and iPhone models with a 30 -pin dock connector:

iPod classic, iPod touch, iPod nano, iPod • 5th generation (video), iPod with color display, iPod mini iPhone, iPhone 3G, iPhone 3GS•

Play an iPod/iPhone player

Note

When an iPod/iPhone player is loaded, the unit • switches to iPod source automatically.

1 Push to open the dock compar tment.

English

2 Press USB to select the USB source.

Play starts automatically. If not, press »

To select a folder, press • / . To select an audio ﬁle, press •

/ .

2 Place the iPod/iPhone player in the dock.

3 Press iPod to select iPod source.

To pause/resume play, press • To skip to a track, press • To search during play, press and • hold

/ , then release to resume

normal play.

Charge the iPod/iPhone

When the unit is connected to power, the docked iPod/iPhone begins to charge.

/ .

5 Listen to radio

Listen to Digital Audio Broadcasts (DAB+)

Digital Audio Broadcasting (DAB+), is a way of broadcasting radio digitally through a network of transmitters. It provides you with more choice, better sound quality and more information.

1 Press SOURCErepeatedly to select

[DAB+].

When you enter the DAB+ mode for » the ﬁrst time, the unit automatically scans DAB+ radio stations. The unit stores all available DAB+ radio stations and then broadcasts the ﬁrst available station.

The last selected DAB+ radio station » broadcasts automatically.

Tip

If no DAB+ service is available, • [NO DAB STATION] is displayed, and then [Station list] is displayed.

Scan DAB+ radio stations automatically

You can perform full scan to search for DAB+ radio stations.

1 In DAB+ mode, press MODE/SCAN.

The unit scans all available DAB+ » radio stations and broadcasts the ﬁrst available station.

Tune to DAB+ radio station manually

1 Press DAB/TUNER repeatedly to select

[DAB+].

2 Press / to select [Manual Tune]. 3 Press ENTER to conﬁrm.

4 Press / to navigate DAB+ radio

stations.

5 Press ENTER to conﬁrm.

Program DAB+ radio stations manually

You can program a maximum of 30 preset DAB+ radio stations.

1 Tune to a DAB+ radio station. 2 Press PRESET +/- to select a preset

number.

3 Press and hold PROG/CLOCK SETfor

two seconds.

The preset number of the saved » station appears.

Listen to a preset DAB+ radio station

1 Press SOURCErepeatedly to select

[DAB+].

2 Press PRESET +/- to select a preset

number.

3 Press ENTER to conﬁrm.

Show DAB+ information

1 Tune to a DAB+ radio station. 2 Press repeatedly to scroll through the

following information (if available):

Dynamic label segment (DLS) » Program type (PTY) » Ensemble Name » Time » Channel and frequency » Bit rate and audio status » Signal error rate »

Use DAB+ menu

1 In the DAB+ mode, press MENU to

enter the DAB+ menu.

English

2 Press / to scroll the menu options:

• [Station list]

• [Full scan]

• [Manual tune]

• [DRC] (dynamic range control)

• [Prune]

• [System]

3 To select an option, press ENTER. 4 Repeat step 2-3 if sub-option is available

under one option.

DRC

Dynamic range control (DRC) adds or removes a degree of compensation for the differences in the dynamic range between radio stations.

• [DRC off] (DRC is switched off.)

• [DRC high] (DRC is switched on; the default setting recommended for noisy environment.)

• [DRC low] (DRC is set to half normal level)

Full scan

Full scan is used to perform a wide range of DAB+ radio search.

1 In the DAB+ mode, press MENU to

enter the menu options.

2 Press / repeatedly until [Full scan] is

displayed.

3 Press ENTER to conﬁrm the selection.

Full scan starts automatically. »

Manual tune

With this feature, you can tune to a speciﬁc channel/frequency manually. In addition to antenna orientation for better radio reception, the optimal reception can also be obtained with this feature.

1 In the DAB+ mode, press MENU to

display the “Manual tune” option.

2 Press ENTER to conﬁrm the selection.

The display shows a channel and its » frequency.

3 Press / repeatedly until the desired

channel/frequency appears.

4 Press ENTER to conﬁrm the selection.

Tip

You may press • DISPLAY to change the service information on the display. You may adjust the position of the antenna to • obtain the optimal signal strength.

Press • MENU to exit manual tune function.

Prune

With this feature, you can clear all the invalid stations from the station list.

1 In the DAB+ mode, press MENU to

enter the menu options.

2 Press / repeatedly until [Prune] is

displayed.

3 Press ENTER to conﬁrm the selection.

» [Y] or [N] is displayed.

4 Press / to switch between [Y] and

[N].

5 Press ENTER to conﬁrm.

System

With this feature, you can:

• know the software version of the unit

1 In the DAB+ mode, press MENU to

enter the menu options.

2 Press / repeatedly until [System] is

displayed.

3 Press ENTER to conﬁrm.

» [SW version] is displayed.

4 Press ENTER again.

The software version of the main unit » is displayed.

• reset DAB/FM stations

1 In the DAB+ mode, press MENU to

enter the menu options.

2 Press / repeatedly until [System] is

displayed.

3 Press ENTER to conﬁrm.

» [SW version] is displayed.

4 Press / to switch to [Tuner Reset]. 5 Press ENTER to conﬁrm. 6 Press / to switch between [Y] and

[N].

• [Y]: reset all DAB/FM radio stations.

• [N]: preset radio stations remain unchanged.

7 Press ENTER to conﬁrm.

Listen to FM radio

2 Press PROG/CLOCK SET to activate

program mode.

3 Press / to allocate a number to

this radio station, then press and hold

PROG/CLOCK SET to conﬁrm.

4 Repeat the above steps to program other

stations.

Tip

To overwrite a programmed station, store • another station in its place.

English

Tune to a radio station

1 Press TUNER to select FM. 2 Press / to tune to a speciﬁc

frequency.

Play starts automatically. »

Tip

You can press • MODE/SCAN to tune to the next station with strong reception automatically.

Program radio stations automatically

You can program a maximum of 30 preset radio stations (FM).

1 In the tuner mode, press and hold

MODE/SCAN to activate automatic

program mode.

All available stations are programmed » in the order of waveband reception strength.

The ﬁrst programmed radio station is » broadcast automatically.

Select a preset radio station

1 In tuner mode, press / to select a

preset number.

2 Press /ENTER to conﬁrm.

You can also press the numeric buttons • to select a preset number directly. You can press • between mono and stereo signals.

Tip

Position the antenna as far as possible from • TV, VCR or other radiation source.

•

For optimal reception, fully ex tend and adjust the position of the antenna.

/ENTER to switch

Program radio stations manually

You can program a maximum of 30 preset radio stations (FM).

1 Tune to a radio station.

6 Play options

Pause/resume play

2 To resume normal play, press

MODE/SCAN repeatedly until no option

is displayed.

1 During play, press to pause/resume

play.

Skip to a track

For CD:

1 Press / to select another track.

To select a track directly, you can • also press a key on the numerical keypad.

For MP3 disc and USB:

1 Press to select an album or a folder. 2 Press / to select a track or a ﬁle.

Search within a track

1 During play, press and hold / . 2 Release to resume normal play.

Select repeat/shufﬂe play options

Program tracks

Note

You can program tracks only when the play • stops.

You can program a maximum of 40 tracks.

1 Press PROG/CLOCK SET to activate the

program mode.

[ » P] is displayed.

2 For MP3/WMA tracks, press / to

select an album.

3 Press / to select a track, then press

PROG/CLOCK SET to conﬁrm.

4 Repeat steps 2 to 3 to program more

tracks.

5 Press to play the programmed tracks.

During play, [ » P] is displayed.

To erase the program, in the stop • position, press

Display time

1 Press DISPLAY to display time.

1 During play, press MODE/SCAN

repeatedly to select a repeat option or the shufﬂe play mode.

• [

]: the current track is played

repeatedly.

]: all tracks in the current

album are played repeatedly.

]: all tracks are played

repeatedly.

]: all tracks are played

randomly.

Tip

In Eco Standby mode, time is displayed for 90 • seconds.

Adjust volume level

1 During play, press VOL +/- to increase/

decrease the volume level.

Mute sound

1 During play, press to mute/unmute

sound.

Select a preset sound effect

1 During play, press DSC repeatedly to

select:

[• POP] (pop) [• JAZZ] (jazz) [• ROCK] (rock) [• CLASSIC] (classic) [• FLAT] (ﬂat - all equalizers off)

Enhance bass

1 During play, press DBB to turn on or off

dynamic bass enhancement.

If DBB is activated, [DBB] is displayed. »

English

7 Other features

Set the alarm timer

This unit can be used as an alarm clock. The disc/radio/USB/iPod is activated to play at a preset time.

To deactivate sleep timer

1 Press SLEEP/TIMER repeatedly until

[OFF] (off) is displayed.

When sleep timer is deactivated, » disappears on the display.

Play from an external device

Note

Ensure that you have set the clock correctly. •

1 Press to switch to standby mode. 2 Press and hold SLEEP/TIMER for more

than two seconds.

A prompt to select the source is » displayed.

3 Press CD, iPod, TUNER, DAB, or USB to

select a source.

4 Press SLEEP/TIMER to conﬁrm.

The clock digits are displayed. » The hour digits begin to blink. »

5 Press / to set the hour. 6 Press SLEEP/TIMER to conﬁrm.

The minute digits begin to blink. »

7 Press / to set the minute.

The timer is set and activated. »

is displayed.

Set the sleep timer

You can also listen to an external audio device through this unit.

1 Press USB/MP3 LINK to select the MP3

link source.

2 Connect the supplied MP3 link cable to:

the • MP3 LINK jack (3.5mm) on the unit. the headphone jack on an external • device.

3 Star t to play the device (see the device

user manual).

Listen through headphone

1 Plug a headphone into the socket on

the unit.

This unit can switch to standby automatically after a set period of time.

1 When the unit is turned on, press

SLEEP/TIMER repeatedly to select a set

period of time (in minutes).

When sleep timer is activated, » displayed.

8 Product

information

Note

Product information is subject to change • without prior notice.

Speciﬁcations

Ampliﬁer

Total output power 2 x 10 W RMS Frequency

response Signal to noise ratio > 60 dB MP3 link input 0.5 V RMS 20 k

Disc

Laser type Semiconductor Disc diameter 12 cm /8 cm Support disc CD-DA, CD-R, CD-

Audio DAC 24 Bits / 44.1 kHz Total harmonic

distortion Frequency

response Signal to noise ratio > 55 dBA

80 Hz - 16 kHz, ± 3 dB

RW, MP3-CD, WMACD

< 1.5%

60 Hz -16 kHz (44.1 kHz)

Tuner

Tuning Range FM: 87.5 -

108MHz DAB: 174.92 -

239.20 MHz Tuning grid (FM) 50 KHz Sensitivity

- Mono, 26dB S/N Ratio

- Stereo, 46dB S/N Ratio Search Selectivity < 28 dBf Total Harmonic Distortion < 2% Signal to Noise Ratio >55 dB Number of presets 30 (FM)

< 22 dBf > 43 dBf

30 (DAB)

Speakers

Speaker impedance 2 x 10 W, 4

General information

AC power 100 - 240V~, 50/60Hz Operation Power

Consumption 15 W Standby Power

Consumption < 2 W Eco Power Standby

Power Consumption < 1 W USB Direct Version 2.0/1.1 Dimensions

- Main Unit (W x H x D) 565 x 245 x 104 mm

Weight

- Main Unit 2.7 kg

English

USB playability information

Compatible USB devices:

USB ﬂash memory (USB 2.0 or USB 1.1)• USB ﬂash players (USB 2.0 or USB 1.1)• memory cards (requires an additional • card reader to work with this unit)

Supported formats:

USB or memory ﬁle format FAT12, • FAT16, FAT32 (sector size: 512 bytes) MP3 bit rate (data rate): 32-320 Kbps and • variable bit rate WMA v9 or earlier• Directory nesting up to a maximum of 8 • levels Number of albums/ folders: maximum 99• Number of tracks/titles: maximum 999• ID3 tag v2.0 to v2.3• File name in Unicode UTF8 (maximum • length: 128 bytes)

Supported MP3 disc formats

ISO9660, Joliet• Maximum title number: 999 (depending • on ﬁle name length) Maximum album number: 99• Supported sampling frequencies: 32 kHz, •

44.1kHz, 48 kHz Supported Bit-rates: 32-320 (kbps), • variable bit rates ID3 tag v2.0 to v2.3• Directory nesting up to a maximum of 8 • levels

Clean discs

When a disc becomes dirty, clean it with • a cleaning cloth. Wipe the disc from the centre out.

Do not use solvents such as benzene, • thinner, commercially available cleaners, or antistatic spray intended for analogue records.

Clean the disc lens

After prolonged use, dirt or dust may • accumulate at the disc lens. To ensure good play quality, clean the disc lens with Philips CD lens cleaner or any commercially available cleaner. Follow the instructions supplied with cleaner.

Maintenance

Clean the cabinet

Use a soft cloth slightly moistened with • a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.

9 Troubleshooting

Warning

Never remove the casing of this apparatus. •

To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www. philips.com/welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available.

Remote control does not work

Before pressing any function button, ﬁrst • select the correct source with the remote control instead of the main unit. Reduce the distance between the remote • control and the unit. Inser t the battery with its polarities (+/– • signs) aligned as indicated. Replace the battery. • Aim the remote control directly at the • sensor on the front of the unit.

Cannot display some ﬁles in USB device

The number of folders or ﬁles in the USB • device has exceeded a certain limit. This phenomenon is not a malfunction. The formats of these ﬁles are not • supported.

English

No power

Ensure that the AC power plug of the • unit is connected properly. Ensure that there is power at the AC • outlet. To save power, the unit switches to Eco • Standby mode automatically after 15 minutes in standby mode.

No sound

Adjust the volume. •

No response from the unit

Disconnect and reconnect the AC power • plug, then turn on the unit again.

No disc detected

Insert a disc. • Check if the disc is inserted with the print • side facing inward. Wait until the moisture condensation at • the lens has cleared. Replace or clean the disc. • Use a ﬁnalized CD or correct format disc. •

USB device not supported

The USB device is incompatible with the • unit. Try another one.

Poor radio reception

Increase the distance between the unit • and your TV or VCR. Fully ex tend the DAB/FM antenna. •

Clock/timer setting erased

Power has been interrupted or the power • cord has been disconnected. Reset the clock/timer. •

Timer does not work

Set the clock correctly. • Switch on the timer. •

sense and simplicity

PHILIPS CONSUMER ELECTRONICS

WARRANTY POLICY FOR AUSTRALIA

Philips provides its Consumer Electronics products with a 1 Year Manufacturers Warranty.

The benefits given to the purchaser by this warranty are in addition to all other rights and remedies, which the purchaser has in respect of the product under the Trade Practices Act or other Commonwealth or State Law.

The conditions contained in this warranty replace and override the provision of the Philips

orld-Wide Guarantee for products purchased in Australia and used in Australia.

Please record the following information for your records and keep in a safe place.

It is essential that you retain your original purchase receipt to make a warranty claim.

If you require assistance with the operation of the product, its features or specifications, you may call the Philips Technology Care Centre on 1300 363 391 where support is provided by our trained staff.

If the product fails within 12 months from the date of purchase, please return the faulty product to the place of purchase.

Conditions of Warranty

a. All claims for warranty can only be made at the place of purchase and a copy of the purchase

b. The warranty period is valid from the original date of purchase of the product. c. This warranty extends only to defects in material or workmanship occurring under normal use of

d. Philips may, at its discretion choose to repair rather than replace this product. e. If a replacement product is supplied, it is warranted for the remainder of the warranty period,

f. This Manufacturers Warranty is limited to 3 months for products used in commercial applications. g. Product accessories are covered by the same warranty period. If an accessory is faulty, please

h. This Manufacturers Warranty is neither transferable nor valid in countries other than Australia.

This Warranty does not cover:

a. Service costs arising from failure to correctly adjust the controls of the product or to observe

b. Product failures caused by misuse, neglect, accidental breakage, transit damage, un-authorised

c. Reception problems, replacement of worn or used batteries or other consumables. d. Second hand products or refurbished products. e. Products failure, caused by other products.

Model number : ……………………………………………………… Serial number : ……………………………………………………… Date of purchase : ……………………………………………………… Retailer : ………………………………………………………

receipt is required for any warranty claim.

the product when operated in accordance with the instructions.

from the original date of purchase.

contact the Philips Technology Care Centre on 1300 363 391.

the instructions, or inspections that reveal that the product is in normal working order.

repairs or modification by un-authorised persons, external fires, lightning strikes, floods, vermin infestation or liquid spillage.

Effective 1st July 2009

Version 1.3: 1st July 2009

DCB293_79_UM_V1.1

Philips DCB293/79 user manual

Specifications and Main Features

Frequently Asked Questions

User Manual
