Register your product and get support at
www.philips.com/welcome
EN User manual
DA Brugervejledning
DE Benutzerhandbuch
ES Manual del usuario
FR Mode d’emploi
IT Manuale utente
NL Gebruiksaanwijzing
SV Användarhandbok
DCB146
3
English
EN
Contents
1 Important 4
Safety 4
Notice 5
2 Your Micro Hi-Fi System 7
Introduction 7
What’s in the box 7
Overview of the main unit 8
Overview of the remote control 9
3 Get started 11
Prepare the remote control 11
Connect speakers 11
Connect power 12
Set clock 12
Turn on 12
4 Play 13
Play a disc 13
Play iPod 13
5 Play options 14
Pause/resume play 14
Skip to a tr
ack 14
Search within a track 14
Select repeat/shuffle play options 14
Program tracks 14
Adjust volume level 14
Mute sound 15
Enhance bass 15
6 Listen to radio 15
Listen to Digital Audio Broadcasts (DAB) 15
Listen to FM radio 17
Reset to factory setting 18
7 Other features 19
Set the alarm timer 19
Set the sleep timer
19
Play from an external device 20
Listen through headphone 20
8 Product information 20
Specifications 20
Maintenance 2
1
9 Troubleshooting 22
4
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and - •
as marked on the unit.
Do not mix batteries (old and new •
or carbon and alkaline, etc.).
Remove batteries when the unit is •
not used for a long time.
Batteries (battery pack or batteries •
installed) shall not be exposed to
excessive heat such as sunshine, fire
or the like.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
q Where the plug of the Direct Plug-
in Adapter is used as the disconnect
device, the disconnect device shall
remain readily operable.
1 Important
Safety
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
j Only use attachments/accessories
specified by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
EN
5
Be sure to observe the following guidelines
when using your headphones.
Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as •
your hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio
interference requirements of the European
Community.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol
is attached to a product it means that the
product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Warning
Never remove the casing of this apparatus. •
Never lubricate any part of this apparatus. •
Never place this apparatus on other electrical •
equipment.
Keep this apparatus away from direct sunlight,
•
naked flames or heat.
Never look into the laser beam inside this
•
apparatus.
Ensure that you always have easy access to the
•
power cord, plug or adaptor to disconnect this
apparatus from the power.
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.
Sound can be deceiving. Over time your •
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.
To establish a safe volume level:
Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfor tably and clearly, without
distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even •
at normally ‘safe’ levels, can also cause
hearing loss.
Be sure to use your equipment •
reasonably and take appropriate breaks.
English
EN
6
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
Norge
Typeskilt finnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er derfor
ikke frakoplet nettet så lenge apparatet er
tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
This apparatus includes this label:
Note
The type plate is located at the rear of the •
apparatus.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment
and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
EN
7
2 Your Micro Hi-
Fi System
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this unit, you can enjoy audio from discs,
iPod players and listen to tuner/Digital Audio
Broadcasting (DAB) radio stations, or other
external devices.
The unit offers Dynamic Bass Boost (DBB) to
enrich sound.
The CD player of the unit supports Audio Discs
including CD-Recordables and CD-Rewritables
What’s in the box
Check and identify the contents of your
package:
Main unit and two speakers•
Remote control•
4 x iPod adaptors•
Quick start guide•
User manual •
English
EN
8
g /
Skip to the previous/next track.•
Search within a track.•
Tune to a radio station.•
Adjust hour/minute digits. •
Select 12 hour or 24 hour format.•
h Dock for iPod
i VOL +/-
Adjust volume.•
j
Stop play or erase a program.•
k SCAN
Search and store DAB stations.•
Tune to a FM radio station or •
program FM radio stations.
l
Star t or pause play.•
Overview of the main unit
a
Turn on the unit, or switch to •
standby mode, or switch to Eco
Power standby.
b Display panel
Show current status.•
c IR
Remote control sensor. •
d SOURCE
Select a source: CD, iPod, FM/DAB, •
or AUX.
e PRESET +/-
Select a preset FM station.•
Select a preset DAB station.•
f Dock
Select the source iPod.•
Turn on the unit from standby mode.•
e
d
h
g
c
b
f
a
i
j
k
l
m
EN
9
Overview of the remote
control
a
Turn on the unit, or switch to •
standby mode, or switch to Eco
Power standby.
b Source select keys
Select sources•
Turn on the unit from standby mode.•
c MUTE
Mute or restore volume.•
d SLEEP/TIMER
Set the sleep timer.•
Set the alarm timer.•
r
p
n
q
m
o
c
e
g
i
k
a
f
h
j
l
d
b
m MENU
Enter iPod menu.•
Access to advance setup options •
under DAB mode.
Under FM/DAB mode, press •
and hold to turn on or off clock
synchronizing.
Top View
n PULL TO OPEN
Open/close the disc compartment.•
n
PULL T O OPEN
English
EN
10
q DISPLAY/CLOCK
Display clock. •
Set the clock.•
r RDS/INFO
Select different types of DAB station •
information.
Under FM mode, select RDS •
information.
e MENU
Enter iPod menu.•
In FM/DAB mode, press to access •
advanced setup options.
In FM/DAB mode, press and hold to •
turn on or off clock synchronizing.
f
/
Navigate iPod menu.•
Select preset FM/DAB station.•
g
/
Tune to a FM radio frequency.•
Change DAB stations, or navigate •
DAB menu options.
Under CD/iPod mode, skip to •
previous/next track or fast search
back and forward within a track/CD.
Adjust the hours and minutes during •
clock/timer setting.
h PROG
Under DISC mode, program tracks •
and review the program.
Program radio stations.•
i REPEAT
Repeat a track/disc /all programmed •
tracks.
j SHUFFLE
Play CD tracks in random order.•
k
Stop play or erase a program.•
Adjust volume.•
l VOL +/-
Adjust volume.•
m DBB
Turn on or off dynamic bass •
enhancement.
n
Star t or pause play.•
o OK
Confirm a selection. •
p SCAN
Scan FM/DAB radio stations.•
EN
11
Note
If you are not going to use the remote control •
for a long time, remove the batteries.
Do not use old and new or different types of
•
batteries in combination.
Batteries contain chemical substances, so they
•
should be disposed of properly.
Connect speakers
Note
Insert the stripped por tion of each speaker •
wire into the socket completely.
For optimal sound, use the supplied speakers
•
only.
Connect only speakers with impedance that is
•
the same or higher than the supplied speakers.
Refer to the Specifications section of this
manual.
To insert each speaker wire: Hold down the
socket flap. Insert the speaker wire fully. Release
the socket flap.
1 For the right speaker, find the sockets on
the main unit marked ‘RIGHT’.
2 Insert the red wire to the red (+) socket.
3 Get started
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
rear of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Prepare the remote control
Caution
Risk of explosion! Keep batteries away from •
heat, sunshine or fire. Never discard batteries
in fire.
To insert the remote control battery:
1 Open the battery compartment.
2 Inser t 2 AAA batteries with correct
polarity (+/-) as indicated.
3 Close the battery compartment.
3
1
2
English
EN
12
Tip
You can also set clock automatically by •
synchronizing with the DAB or RDS time.
See details in the “Automatic clock setting via
RDS”.
Turn on
1
Press .
The unit switches to the last selected »
source.
Switch to standby
1 Press again to switch the unit to
standby mode.
The clock (if set) appears on the »
display panel.
To switch the unit to Eco Power Standby
mode:
1 Press and hold for more than 2
seconds.
Message » [ECO POWER] displays.
Then clock (if set) displays. »
To switch between standby mode and Eco
Standby Mode:
1 Press and hold for more than 2
seconds.
3 Inser t the black wire into the black (-)
socket.
4 For the left speaker, find the sockets on
the main unit marked ‘LEFT’.
5 Repeat steps 2-3.
Connect power
Caution
Risk of product damage! Ensure that the power •
voltage corresponds to the voltage printed on
the back or underside of the apparatus.
Risk of electric shock! When you unplug the
•
AC adaptor, always pull the plug from the
socket. Never pull the cord.
Before connecting the AC adaptor, ensure you
•
have completed all other connections.
1 Connect the power adaptor to the wall
outlet.
Set clock
Note
You can set the clock in the standby mode •
only.
1 Press and hold CLOCK/DISPLAY on the
remote control for 2 seconds.
2 Press PROG repeatedly to select 12 hour
or 24 hour format.
3 Press CLOCK/DISPLAY to confirm the
selection.
The hour digits blink. »
4 Press / to set the hour.
5 Press CLOCK/DISPLAY to confirm the
hour setting.
The minute digits blink. »
6 Press / to set the minute.
7 Press CLOCK/DISPLAY to confirm the
setting.
EN
13
To pause/resume play, press • .
To skip to a track, press •
/ .
To search during play, press and •
hold
/ , then release to resume
normal play.
To navigate the iPod menu and •
confirm a selection, press MENU,
/ and OK on the remote control.
Charge the iPod
When the unit is connected to power and in
the standby mode and power-on mode, the
docked iPod begins to charge.
Note
In Eco power standby mode, iPod cannot be •
charged.
4 Play
Play a disc
1
Press DISC to select the disc source.
2 Lift the CD door on the top of the
system to open the CD compar tment.
3 Inser t a disc with the printed side facing
up and press down the CD door to close
the CD compartment.
4 Press to start playback.
Play iPod
This system is equipped with a dock used for
iPod. You can enjoy audio from the docked
player through the powerful speakers of the
system.
Compatible iPod
Apple iPod models with 30-pin dock
connector as follows:
iPod Nano 1st /2nd/3rd/4th/5th •
generation,
iPod 5th generation (video),•
iPod touch 1st/2nd generation,•
iPod classic.•
Play from iPod
1 Select a dock adaptor (supplied) that
matches your iPod type.
2 Press PUSH TO OPEN to open the dock
on the main unit.
3 Snap the suitable dock adaptor into the
dock on the main unit.
4 Plug your iPod into the dock adaptor.
5 Press iPod on the remote control to
select iPod source.
The connected iPod plays automatically. »
English
EN
14
Tip
Press • once during playback to stop repeat/
shuffle playback.
Press
• again to cancel repeat/shuffle play
mode.
Note
Repeat mode and shuffle mode cannot be •
activated simultaneously.
Program tracks
Note
You can program tracks only when the play •
stops.
You can program a maximum of 20 tracks.
1 Press PROG to activate program mode.
Program number » [01] flashes.
2 Press / to select a track
3 Repeat steps 1 to 2 to program more
tracks.
4 Press to play the programmed tracks.
To review the program:•
Stop playback and press PROG.
To erase the program:•
Pressonce in the stop mode or twice
during playback.
» [PROG] disappears on the display.
Adjust volume level
1
During play, press VOL +/- to increase/
decrease the volume level.
5 Play options
Pause/resume play
1
During play, press to pause/resume
play.
Skip to a track
1
Press / on the remote control once
or repeatedly to select desired track.
Search within a track
1
During play, press and hold / .
2 Release to resume normal play.
Select repeat/shuffle play
options
To select repeat play mode:
1 During play, press REPEAT repeatedly to
select a repeat option.
Rep all: repeats the entire disc/•
programme.
Rep one: plays the current track •
continuously.
To select shuffle play mode:
1 During play, press SHUFFLE repeatedly
to turn the shuffle play mode on/off.
Tracks of the entire disc are played in »
random order.
To resume normal play, press •
REPEAT/SHUFFLE repeatedly until no
shuffle/repeat option is displayed.
EN
15
6 Listen to radio
Listen to Digital Audio
Broadcasts (DAB)
Digital Audio Broadcasting (DAB), is a way
of broadcasting radio digitally through a
network of transmitters. It provides you with
more choice, better sound quality and more
information.
For the first time when DAB mode is switched
on.
1 Press SOURCEon the main unit
repeatedly to select DAB.
The system performs auto scan. »
All the available DAB stations is stored. »
The radio tunes to the first available »
station
Tip
The display shows a rectangle. The position •
of the rectangle indicates the degree of signal
strength. (The further towards the right, the
greater the signal strength.)
If there is no DAB coverage currently available,
•
or DAB signal is too weak in your area, no
DAB station will be found, and message [No
DAB Station] displays, then displays [Station
List].
Tune to DAB radio station manually
1 Under DAB mode, press /
repeatedly until your desired station
name displays.
2 Press OK to confirm the selection.
The radio immediately tune to the »
selected station.
About station display symbols•
You may see some symbols displayed
before the station names as follows:
•
: Indicates that the station is one
of ten most-listened stations by you
based on DAB radio’s monitoring.
Mute sound
1
During play, press MUTE to mute/unmute
sound.
Enhance bass
1
During play, press DBB to turn on or off
dynamic bass enhancement.
If DBB is activated, [DBB] is displayed. »
English
EN
16
Display DAB information
On the display of DAB broadcasting, the first
line shows station name, and the second line
shows the service information for the current
station. 7 types of service information are
available.
1 Press INFO/RDS repeatedly to cycle
through the display information (if
available).
Dynamic label segment (DLS) »
Program type (PTY) »
Ensemble Name »
Time »
Channel and frequency »
Bit rate and audio status »
Signal error rate »
Use DAB menu
1 In the DAB mode, press MENU to enter
the DAB menu.
The first setup option » [Manual tune]
displays.
2 Press / to scroll the menu options:
• [Station list]
• [Full scan]
• [Manual tune]
• [DRC]
• [Prune]
• [System]
3 To select an option, press OK.
4 Repeat step 2-3 if sub-option is available
under one option.
Full scan
Full scan is used to perform a wide range of
DAB radio search.
1 In the DAB mode, press MENU to enter
the menu options.
2 Press / repeatedly until [Full scan]
displays.
3 Press OK to confirm the selection.
Full scan starts automatically. »
• ?: Indicates that the station is not
currently available, or not active.
•
: Indicates that the station is a
primary station with secondary
service.
•
: Indicates that the station is a
secondary station.
Scan for new DAB stations
New stations and services will be regularly
added in the DAB broadcast. To make new
DAB stations and service available on your
DAB radio, a search is needed.
1 Under DAB mode, press SCAN.
The unit starts to scan for DAB »
stations.
Program DAB radio stations manually
You can program a maximum of 30 preset
DAB radio stations.
1 Tune to a DAB station.
2 Press PROG on the remote control to
activate programming.
3 Press / on the remote control to
allocate a number (1-30) for the preset.
4 Press and hold PROG to confirm.
The preset number of the saved »
station appears.
Note
If a DAB station is already stored under a •
preset location, new DAB station assigned
to this location will overwrite the old DAB
station.
DAB station presets will not overwrite FM
•
presets.
Listen to a preset DAB radio station
1 Press PRESET +/- to select a preset
number.
2 Press OK to confirm the selection.
EN
17
You should be able to hear the »
difference in compression immediately.
Note
The best way to determine which of these •
DRC value settings suits you best is to
experiment with them on a variety of source
material.
Prune
This option will list active stations and remove
any stations that are in the list but have no
service in your area from the service list.
Those invalid stations in the service list have
a question mark (?) displayed in front of the
station name.
1 Select Prune stations and press OK.
All stations that have a question mark »
will be deleted from the service list.
System
• [SW version]: Display software version
of the unit.
• [Factory reset]: Reset all the settings of
this unit to factory default. Press OK to
confirm reset.
Listen to FM radio
Tune to a radio station
1 Press TUNER on the remote control
repeatedly until the desired waveband
(FM) displays.
2 Press SCAN.
The radio automatically tunes to a »
station with sufficient signal strength.
3 Repeat the step 2 until you find the
desired station.
Tip
To tune to a station with weak signal, press •
/ repeatedly until optimal reception is found.
Manual tune
With this feature, you can tune to a specific
channel/frequency manually. In addition to
antenna orientation for better radio reception,
the optimal reception can also be obtained
with this feature.
1 In DAB mode, press MENU to display the
[Manual tune] option.
2 Press OK to confirm the selection.
The display shows a channel and its »
frequency.
3 Press / repeatedly until the desired
channel/frequency appears.
4 Press OK to confirm the selection.
Tip
You can press • INFO/RDS to change the
service information on the display.
You can adjust the position of the antenna to
•
obtain the optimal signal strength.
Dynamic Range Control (DRC)
DRC adds or removes a degree of
compensation for the differences in the
dynamic range between radio stations.
There are three levels of compensation:
• [DRC Off]: No compensation applied.
(the default)
• [DRC Low]: Maximum compensation
applied.
• [DRC High]: Medium compensation
applied.
1 In DAB mode, press MENU to enter the
menu options.
2 Press / repeatedly until[DRC]
displays.
3 Press OK to enter the sub-menu.
The current DRC level displays on the »
first line.
4 Press / to select a DRC value
» [DRC Off], [DRC Low] and [DRC
High] displays on the second line.
5 Press OK to confirm the selection.
English
EN
18
Display RDS information
1 Tune to the desired RDS radio station on
the FM waveband.
2 Press INFO/RDS on the remote control
repeatedly to switch through the
following information (if available):
Station name•
Program type (for example: News, •
Sport, etc.)
Radio text messages•
Frequency•
Note
•
[NO Radio Text], [NO PTY], [NO Name],
[Mono], [00:00:00] or [0-0-0000] displays if
no RDS signal is available..
Display RDS information
When the unit is on, the clock can be
automatically set by synchronizing with the
time signal broadcasts with the RDS signal.
This only works if the RDS station is sending
this time signal.
When clock synchronizing is turned on, clock
is synchronized with the time set by DAB or
RDS, and manually set clock is overwritten.
To turn on or off clock synchronizing:
1 In DAB or FM mode, press and hold
MENU on the main unit for around 2
seconds to switch it on or off.
Note
Some RDS radio station may be transmitting •
a real time clock at a minute interval. The
accuracy of the transmitted time depends on
the transmitting RDS radio station.
Reset to factory setting
1
Under DAB/FM mode, press MENU to
enter the menu options.
Program radio stations automatically
You can program a maximum of 30 preset
radio stations (FM).
1 In the tuner mode, press and hold SCAN
to activate programming.
All available stations are programmed. »
The first programmed radio station is »
broadcast automatically.
Program radio stations manually
1 Tune to a radio station.
2 Press PROG on the remote control to
activate programming.
3 Press / to allocate a number to this
radio station
4 Press and hold PROG to confirm the
setting.
The preset number and the frequency »
of the preset station display.
5 Repeat the above steps to program other
stations.
Tip
To overwrite a programmed station, store •
another station in its place.
Select a preset radio station
1 In tuner mode, press / on the remote
control until the desired preset station
displays.
FM stations with RDS
Radio Data System (RDS) is a service that
sends additional broadcast information along
with FM stations.
If you listen to a FM station with RDS signal,
“RDS” displays.
EN
19
7 Other features
Set the alarm timer
This unit can be used as an alarm clock. The
disc/radio/iPod is activated to play at a preset
time.
Note
Ensure the clock is set correctly before set the •
alarm.
1 In standby mode, press and hold
TIMER/SLEEP for more than two
seconds.
2 Press DISC, iPod, TUNER or DAB to
select sound source.
3 Press TIMER/SLEEP to confirm.
The hour digits of the clock blinks. »
4 Press / to set the hour.
5 Press TIMER/SLEEP to confirm.
The minute digits blinks. »
6 Press / to set the minute.
7 Press TIMER/SLEEP to confirm.
The timer is set and activated. »
Note
If CD/iPod source is selected and no disc/iPod •
player is in place, tuner will be activated at
preset time.
To activate and deactivate TIMER:
In standby mode, press briefly TIMER/•
SLEEP once.
Display shows •
if activated, and
disappears if deactivated.
Set the sleep timer
This unit can switch off automatically after a set
period of time.
2 Press / repeatedly until [System]
displays on the display panel.
3 Press OK to access the system menu.
» [Factory Reset] displays.
4 Press OK to enter factory reset menu.
The display panel shows options » [Yes]
and [No] under [Factory Reset].
5 Press / to select [Yes].
6 Press OK to confirm the DAB/FM factory
reset.
English
EN
20
8 Product
information
Note
Product information is subject to change •
without prior notice.
Specifications
Amplifier
Total output power 2 x 2 W RMS
Frequency response 125 Hz - 16 kHz
Signal to noise ratio ≥ 60 dBA (IEC)
Impedance loudspeakers 8
Disc
Laser type Semiconductor
Disc diameter 12 cm /8 cm
Support disc CD-R, CD-RW
Audio DAC 24 Bits / 44.1 kHz
Frequency range 125 Hz -16 kHz
Signal to noise ratio 65 dBA
Tuner
Tuning Range FM: 87.5 - 108MHz
DAB: 174.92 - 239.20
MHz
FM 26dB Sensitivity 20 μV
Total Harmonic
Distortion
< 5%
Speakers
Bass reflex system
Dimensions
(w x h x d) 134 x 230 x 152 mm
1 During playback, press TIMER/SLEEP
repeatedly to select a set period of time
(in minutes).
When sleep timer is activated, »
displays.
To deactivate sleep timer
1 Press TIMER/SLEEP repeatedly until [00]
displays.
»
disappears on the display.
Play from an external device
You can also listen to an external audio device
through this unit.
1 Press AUX on the remote control to
select AUX source.
2 Use an audio cable (not supplied) to
connect DCB146’s AUX jack (3.5 mm,
located on the back panel) to AUDIO
OUT or headphone jack on the external
device (such as CD player or VCR).
3 Start to play the device (see the device
user manual).
Listen through headphone
1
Plug a headphone into the HEADPHONE
socket (3.5 mm, located on the back
panel).
EN
21
Clean the disc lens
After prolonged use, dirt or dust may •
accumulate at the disc lens. To ensure
good play quality, clean the disc lens
with Philips CD lens cleaner or any
commercially available cleaner. Follow the
instructions supplied with cleaner.
General information
AC power 220 - 230V~, 50Hz
Operation Power
Consumption 15 W
Standby Power
Consumption < 2 W
Eco Power Standby
Power Consumption < 1 W
Dimensions
- Main Unit
(W x H x D) 148 x 233 x 216 mm
Weight
- Main unit with
speakers 3.65 kg
Maintenance
Clean the cabinet
Use a soft cloth slightly moistened with •
a mild detergent solution. Do not use
a solution containing alcohol, spirits,
ammonia or abrasives.
Clean discs
When a disc becomes dirty, clean it with •
a cleaning cloth. Wipe the disc from the
centre out.
Do not use solvents such as benzene, •
thinner, commercially available cleaners,
or antistatic spray intended for analogue
records.
EN
English
22
Reduce the distance between the remote •
control and the unit.
Insert the battery with its polarities (+/– •
signs) aligned as indicated.
Replace the battery. •
Aim the remote control directly at the •
sensor on the front of the unit.
Poor radio reception
Increase the distance between the unit •
and your TV or VCR.
Fully extend the DAB/FM antenna. •
Clock/timer setting erased
Power has been interrupted or the power •
cord has been disconnected.
Reset the clock/timer. •
Timer does not work
Set the clock correctly. •
Switch on the timer. •
9 Troubleshooting
Warning
Never remove the casing of this apparatus. •
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome). When you contact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
Ensure that the AC power plug of the •
unit is connected properly.
Ensure that there is power at the AC •
outlet.
To save power, the unit switches to Eco •
Standby mode automatically after 15
minutes in standby mode.
No sound
Adjust the volume. •
No response from the unit
Disconnect and reconnect the AC power •
plug, then turn on the unit again.
No disc detected
Insert a disc. •
Check if the disc is inserted with the print •
side facing inward.
Wait until the moisture condensation at •
the lens has cleared.
Replace or clean the disc. •
Use a finalized CD or correct format disc. •
Remote control does not work
Before pressing any function button, first •
select the correct source with the remote
control instead of the main unit.
EN
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: DCB146_12_UM_V1.1
Loading...
