Register your product and get support at
www.philips.com/welcome
CED1700
EN User manual
ZH-CN Ⴌ߀൱Ҭ
ZH-TW Ԛʹ˫
ES Manual del usuario
PT-BR Manual do Usuário
Contents
1 Important 4
Safety 4
Notice 4
Introduction 5
What’s in the box 6
Overview of the main unit 7
Overview of the remote control 9
6 Adjust sound 25
Adjust volume 25
Mute 25
Select preset equalizer 25
Adjut fader/balance 25
Adjust Subwoofer value 25
Set Dynamic Bass Boost (DBB) 26
7 Adjust settings 27
Adjust general settings 27
Adjust Bluetooth settings 27
English
2 Get started 10
Install the car audio 10
Install remote control battery 14
Turn on 15
Set date and time 15
3 Listen to radio 16
Tune to a radio station 16
Store radio stations in memory 16
Tune to a preset station 16
Play with RDS 17
4 Play 19
Load discs 19
Connect USB device 19
Insert SD/MMC card 20
Play/Pause 20
Repeat 20
Skip/search 20
Search within a title/folder 21
Random play 21
Select audio language 21
Select subtitle language 21
Rotate pictures 22
Zoom 22
8 Others 28
Listen to other devices 28
Reset 28
Remove the unit 28
Replace fuse 28
9 Product information 30
10 Troubleshooting 32
About Bluetooth device 33
11 Glossary 34
5 Play with Bluetooth device 23
Pair the Bluetooth-enabled devices 23
Make a call 23
Receive call 24
Listen to music from Bluetooth device 24
Adjust Bluetooth settings 24
EN
3
1 Important
Safety
Read and understand all instructions •
before you use the apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
Use of controls or adjustments or •
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground •
(earth) 12 V DC operation only.
To reduce the risk of traffic accident, do •
no watch video during driving.
To ensure safe driving, adjust the volume •
to a safe and comfortable level.
Improper fuses can cause damage or •
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware •
for a safe and secure installation.
To avoid short circuit, do not expose the •
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation •
slots or other openings on the apparatus.
Never place any objects other than discs •
into the disc tray/slot.
Visible and invisible laser radiation when •
open. Avoid exposure to beam.
Risk of damage to the screen! Never •
touch, push, rub or strike the screen with
any object.
Never use solvents such as benzene, •
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Clean the apparatus with soft, damp •
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
The apparatus shall not be exposed to •
dripping or splashing.
Do not place any sources of danger on •
the apparatus (e.g. liquid filled objects,
lighted candles).
Notice
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
The Bluetooth
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips
is under license.
®
word mark and logos are
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Other trademarks and trade names are those
of their respective owners.
This apparatus includes this label:
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
4
EN
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
This product complies with the radio
interference requirements of the European
Community.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment
and human health.
2010 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specifications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the car entertainment system, you can
enjoy:
Audio/video/JPEG pictures from•
DVD, VCD or CD•
USB devices•
SD/SDHC/MMC cards •
External devices•
FM or AM (MW) radio•
Audio from Bluetooth-enabled devices•
Besides, you can make/receive phone calls with
Bluetooth-enabled devices and quickly find
the destination you seek with external GPS
navigation box (Philips model CEA100).
English
EN
5
What’s in the box
Check and identify the contents of your
package:
ab
cd
ef
R-CHL-CHR-CHL-CH
e ISO standard connector
f Audio and Video cable
g Screws
- M5x8mm x 4 pcs
h Rubber cushion
i Remote control battery
j User manual
k Quick start guide
l Warranty card
gih
jlk
a Main unit and front panel
b Remote control
c Trim plate
d Hexagon head screw
6
EN
Overview of the main unit
English
a RESET
b
c Remote sensor
d Touch panel
e
f +/-
g DIMMER
h
Open the front panel to insert/eject •
disc/card.
/MUTE
Turn the unit on or off.•
Turn mute on or off.•
Increase/decrease volume.•
Adjust dimmer settings.•
Press and hold to enter or exit GPS •
navigation system
g
f
e
h TILT
Adjust the position of the front •
panel.
Press and hold to close the front •
panel.
d
c
b
a
EN
7
i
i Built-in microphone
j SD/SDHC/MMC card slot
k Disc slot
j
k
8
EN
Overview of the remote
t
t
control
x
x
w
w
v
v
u
u
s
s
r
r
q
q
p
p
o
o
n
n
m
m
$8',2
'9'
2.
086,&
'9'
0(18
a
Mute or unmute audio.•
b
Open the front panel to insert/eject •
disc/card.
c VOLUME +/-
d
e
f
g
h TILT
Adjust volume.•
/REJECT
Terminate call.•
Reject incoming call.•
Return to previous menu or exit.•
Adjust repeat mode.•
Access home menu. •
Adjust the position of the front •
panel.
7,/7
'9'
7,7/(
92/80 (
$8',2
',00(5
a
a
b
b
c
c
d
d
e
e
f
f
g
g
h
h
i
i
j
j
k
k
l
l
i AUDIO
j DVD TITLE
k DIMMER
l SW
m DBB
n EQ
o DVD MENU
p DVD AUDIO
q NAVI
r
s
t /RECEIVE
u OK
v
w
x
Access speaker fader/banlance menu.•
Select DVD subtitle language.•
Access illuminate dimmer settings.•
Turn o n /of f s ubwoofer.•
Turn on or off Dynamic Bass Boost •
(DBB) sound.
Access equalizer setting menu.•
Access DVD main menu.•
Select audio language or audio •
channel.
Enter/exit the navigation system.•
Adjust shuffle play mode.•
Start or pause play.•
Answer phone.•
Dial number.•
Confirm selection.•
/
Skip to previous/next track/chapter.•
Play fast backward/forward.•
Tune for radio station.•
Turn the unit on or off.•
/
Skip to the previous/next preset •
station.
Skip to the previous/next folder.•
Search backward/forward for DVD •
video.
Move c• ursor up/down.
English
EN
9
2 Get started
Caution
Use of controls or adjustments or •
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground •
(earth) 12 V DC operation only.
Always install this unit in the car dashboard. •
Other locations can be dangerous as the rear
of the unit heats up during use.
To avoid short-circuit: before you connect, •
ensure that the ignition is off.
Ensure that you connect the yellow and red •
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with •
electrical tape.
Ensure that the leads do not get caught under •
screws orin parts that will move (e.g. seat rail).
Ensure that all ground (earth) leads are run to •
a common ground (earth) point.
Use only the supplied mounting hardware for a •
safe and secure installation.
Improper fuses can cause damage or fire. •
When you need to change the fuse, consult a
professional.
Note on the power supply lead (yellow)
When you connect other devices to this •
system, ensure that the rating of the car
circuit is higher than the total fuse value
of all the connected devices.
Notes on speaker connection
Never connect speaker wires to the •
metal body or chassis of the car.
Never connect speaker wires with stripes •
to one another.
Connect wires
Caution
Ensure that all loose leads are insulated with •
electrical tape.
1 Check the car’s wiring carefully, then
connect them to the supplied ISO wires.
Connector Connect to
1Yellow wireThe +12V car battery
which is live at all times.
2Blue wireThe electric antenna
control lead or power
supply lead of the
antenna booster
If there is no electric
antenna or antenna
booster, or it is manually
operated telescopic
antenna, it is not
necessary to connect this
lead.
10
EN
3Black wireA metal surface of the
car
First connect the black
ground (earth) lead, then
connect the yellow and
red power supply leads.
4Red wire The +12V power terminal
which is live in the
accessory (ACC) position
of the ignition switch
If there is no accessory
position, connect to the
+12V car battery terminal
that is always live. Be
sure to connect the black
ground (earth) lead to a
metal surface of the car
first.
5 Green and
green/black
wires
6 White and
white/black
wires
7 Gray and
gray/black
wires
8 Purple and
purple/black
wires
Left speaker (Rear)
Left speaker (Front)
Right speaker (Front)
Right speaker (Rear)
Note
The video blocking system under parking •
brake not engaged only control this unit’s
display, and will not affect the video output
through the rear RCA video output.
If watch moving video from Disc or AV-In •
source but parking brake is not properly
connected, the video signal will be blocked
by the system, and the below display will be
shown on TFT:
English
2 Connect the other end of the supplied
standard connector to the car audio
system.
Caution
In order to avoid any accident, the driver must •
not watch video while driving. This unit is
designed to not allow watching moving video
while driving. Park your car in a safe place and
engage the parking brake before watching
moving video.
EN
11
R-CH
R-CH
L-CH
L-CH
1
5
6
7
2
3
4
Connector/
Obeject
1 Pink wire Extension wire
2 2.5m extension
wire(Not
included)
12
EN
Connect to/with
Parking brake (-)
"
!
0
9
8
/
3 Brake switch
4Ground
5 ISO wires Connected in step 1
above.
6 Grey wire Rear line out Left/
Right
§
&
$%
P
R
N
D
2
L
Loading...
