Peugeot 807 2003 Owner Manual

12-05-2003

Pages

Checks 139 - 142
Access 105 - 112
Fuel filler flap 113
Changing a wheel 144 - 145
Changing a bulb 146 - 147

YOUR 807 AT A GLANCE

1

Each model may only be fitted with some of the equipment shown, according to its specification and the technical
requirements in the country of first registration of the vehicle.

Pages

Seats 89 - 104
Steering wheel controls 114 - 117
Instrument dials 26 - 27
Ventilation, air conditioning 84 - 88
Mirrors 122 - 123

12-05-2003

YOUR 807 AT A GLANCE

2

12-05-2003

17 -Electric mirror controls.

Window controls.
Rear window locking control.

18 -Steering lock and ignition.
19 -Dynamic stability control

(ESP/ASR) switch.

20 -Headlamp height adjust-

ment.

21 -Fuse box.
22 -Handbrake.
23 -Steering wheel adjustment

control.

24 -Battery/Fuse box.
25 -Heated seat switches.
26 -Storage.
27 -Gear lever.
28 -Cooled compartment.
29 -Ashtray/Can holder.
30 -Storage compartment or

remote control keypad.

31 -Lighter/12 V accessories

socket.

32 -Hazard warning lights switch.
33 -Air conditioning controls.

34 -Passenger compartment

temperature sensor.

35 -Passenger lower glove box.
36 -Passenger air bag.
37 -Side vent.
38 -Bonnet release.
39 -Passenger air bag disarming

switch*.

* According to country.

YOUR 807 AT A GLANCE

3

1 - Side window demisting

vents.

2 - Speaker (tweeter).
3 - Windscreen demisting

vents.

4 - Passenger upper glove box.
5 - Brightness sensor.
6 - Instrument panel/Multifunc-

tion display.

7 - RB3, RD3, RT3 audio

equipment with flap.

8 - Central vents.
9 - Driver's upper glove box.
10 -Lights and direction indica-

tors stalk.

11 - Cruise control controls.
12 -Check unit.
13 -Driver's air bag.

Horn.

14 -Windscreen wash-wipe

stalk.
Trip computer stalk.

15 -Audio remote control stalk.
16 -Interior alarm disarming

switch.

12-05-2003

Automatic switching on of
lights

To activate or disarm this function,
place the key in the accessories
position, the lighting stalk in posi­tion 0 and press for more than two
seconds on the end of the stalk.

Front fog lamps and rear fog
lamps (ring B)

Front fog lamps (1st rota­tion of the ring forwards).

Front fog lamps
and rear fog
lamps (2nd rota­tion of the ring for­wards).

To switch off: rotate the push ring

B rearwards.

YOUR 807 AT A GLANCE

STEERING WHEEL
STALKS

LIGHTING
Front and rear lights (ring A)

Lights off.

Side lights on.

Dipped/main beam
headlamps on.

Automatic switch­ing on of lights.

114

WINDSCREEN WIPERS
Front

2 Rapid wipe
1 Normal wipe

I Intermittent wipe

or

AUTO Automatic wipe

0 Off

 Single wipe

Wash-wipe: pull the stalk
towards you.

Automatic wipe

In the AUTO position, a
rain sensor controls the
automatic operation of
the wipers. The wipers

adapt their speed to the
intensity of the rainfall.

Rear

Off Intermittent Wash-

wipe wipe

116

10

12-05-2003

YOUR 807 IN DETAIL

102

SEAT BELTS
Front and 2nd row rear side

seat belts

The 2nd row front and rear side
seats are fitted with pre-tensioners
and force limiters.

To adjust the height:

☞ To lower the attachment point,

squeeze control 1 and slide it
downwards.

☞ To raise the attachment point,

slide control 1 upwards.

To lock

☞ Pull the strap, then insert the

buckle into the stalk.

Pre-tensioning and
force-limiting seat belts

Safety in the event of a frontal impact
has been improved by the introduc­tion of pre-tensioning and force-limit­ing seat belts. Depending on the
seriousness of the impact, the pre­tensioning system instantly tightens
the seat belts firmly against the body
of the occupant.

The pre-tensioning seat belts are
armed when the ignition is on.

The force-limiting device reduces the
pressure of the seat belt against the
occupant's body in the event of an
accident.

3rd row rear side seat belts

The 3rdrow rear side seats are fitted
with two seat belts which are both
three-point inertia reel belts with
force limiter.

To install the seat belt, move the
spring hook from position B to
position A then insert the buckle into
the stalk.

2nd and 3rd row rear centre
seat belts

The 2ndrow rear centre seat and the
rear bench seat centre seat have an
integrated three-point inertia reel
seat belt.

12-05-2003

YOUR 807 IN DETAIL

103

T o be effective, a seat belt
must be tightened as
close to the body as pos­sible.

If the seats are fitted with arm­rests, the lap section of the seat
belt must always pass under the
armrest.

Sitting with your back to the road
while the vehicle is moving is pro­hibited.

Depending on the nature and the
seriousness of the impact, the
pre-tensioners may be triggered
before and independently of the air
bags.

In all cases, the air bag warning
light comes on.

Following a collision, have the
system checked by a PEUGEOT
dealer.

The system has been designed to
be fully operational for ten years.

For greater safety, have it checked
by a PEUGEOT dealer after this
period.

POSSIBLE SEAT CONFIGURATIONS

Examples of various arrangements combining pleasure and practicality:

5 seats

6 seats "Pullman"

12-05-2003

YOUR 807 IN DETAIL

103

T o be effective, a seat belt
must be tightened as
close to the body as pos­sible.

If the seats are fitted with arm­rests, the lap section of the seat
belt must always pass under the
armrest.

Sitting with your back to the road
while the vehicle is moving is pro­hibited.

Depending on the nature and the
seriousness of the impact, the
pre-tensioners may be triggered
before and independently of the air
bags.

In all cases, the air bag warning
light comes on.

Following a collision, have the
system checked by a PEUGEOT
dealer.

The system has been designed to
be fully operational for ten years.

For greater safety, have it checked
by a PEUGEOT dealer after this
period.

POSSIBLE SEAT CONFIGURATIONS

Examples of various arrangements combining pleasure and practicality:

5 seats

6 seats "Pullman"

12-05-2003

7 seats with access to 3rd row

8 seats with bench seat

5 seats with picnic position

"Cargo" configuration

YOUR 807 IN DETAIL

104

The various operations modifying the existing configuration must be carried out with the engine switched off (see
section on ''Seats'').

It is prohibited to be in a rearwards facing position when the vehicle is being driven.
The centre seat may be installed in the central position in the 2nd row and in the left side position in the 3rd row.

12-05-2003

THE KEYS

The keys allow you to switch on the
ignition and to independently operate
the locks on the driver's door and
passenger door, the fuel filler cap,
the glove box, the passenger air bag
disarming switch and the child safety
lock.

Central locking

From the driver's door or passenger
door, the keys allow you to lock,
deadlock or unlock the doors and
tailgate, as well as fold back the
exterior mirrors.

If one of the doors or the tailgate is
open, the central locking does not
work.

The remote control performs the
same functions at a distance.

YOUR 807 IN DETAIL

105

The remote control

Version with single locking

Press button A to lock the vehicle.
This is confirmed by fixed lighting of

the direction indicators for approxi­mately two seconds.

Vehicles fitted with deadlocking

Warning: deadlocking renders the
internal and external door locking
controls inoperative.

Never leave anyone inside the vehi­cle when the vehicle is deadlocked.

Pressing button A locks the vehicle.
This is confirmed by fixed lighting of

the direction indicators for approxi­mately two seconds.

A second press on button A within
five seconds of locking changes this
to deadlocking.

This is confirmed by fixed lighting of the
direction indicators for two seconds.

Note: if the deadlocking is operated
from inside the vehicle, it will change
to normal locking when the vehicle is
started.

Unlocking/Ventilation
Press button B to unlock the vehicle.

This is confirmed by rapid flashing of
the direction indicators.
A second press on button B within
five seconds of unlocking opens the
windows.

Note: if the vehicle is locked and
unlocking is activated inadvertently,
unless the doors are opened within
30 seconds, the vehicle will lock
automatically.

Opening/Closing the electric
sliding side doors

Pressing button C opens or closes
the rear right door.

Pressing button D opens or closes
the rear left door.

Note: this press unlocks the vehicle
before opening the corresponding
door.

Folding/opening out the key

To tuck away the key blade, press
button E, then fold it down into the
remote control module.

To open out the key, press button E.

Pressing button A, in addition to
locking or deadlocking, permits
automatic closing of the windows
and places the sunroofs in the par­tially open position, if they were
open.

To close them completely, you
must press their switch before
leaving the vehicle.

12-05-2003

Changing the battery of the
remote control

The information “battery flat” is given
by an audible signal accompanied by
the message ''Remote control bat-
tery low'' on the multi-function dis­play.

To replace the battery, unclip the
casing using a coin at the ring
(CR1620/3 volt battery).

If the remote control does not work
after the battery has been changed,
re- programme the remote control.

Programming the
remote control

☞ Switch off the ignition.
☞ Switch the ignition on again.
☞ Press button A immediately.
☞ Switch off the ignition and remove

the remote control key from the
ignition lock. The remote control is
now working again.

CONFIDENTIAL CARD

The confidential card contains the
identification code necessary for any
work carried out by a PEUGEOT
dealer on the system. This code is
hidden by a film, which should be
removed only if necessary.

Keep your card in a safe place,
never inside the vehicle.

Key in ignition

The message ''Key in ignition'' on
the multi-function display, accompa­nied by a buzzer on opening the
driver’s door, indicates that the key
has been left in the ignition.

YOUR 807 IN DETAIL

106

ELECTRONIC ENGINE
IMMOBILISER

This locks the engine management
system as soon as the ignition has
been switched off and therefore
prevents starting of the vehicle by
anyone who does not have the key.

The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code is
recognised and starting is possible.

If the system does not function cor­rectly, contact a PEUGEOT dealer as

soon as possible.

Locating your vehicle

To locate your vehicle, if you have
locked it, in a car park:

☞ press button A. The courtesy

lights come on and the direction
indicators flash for a few
seconds.

12-05-2003

YOUR 807 IN DETAIL

107

Make a careful note of the number on each key. The key number is coded on the label attached to the key.
If the keys are lost, your PEUGEOT dealer can rapidly supply you with new keys.
The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a

possibility that it may unlock your vehicle, without you being aware of it.

The remote control does not operate when the key is in the ignition, even when the ignition is switched off, except for
reprogramming.

However, do not operate the deadlocking function if there is anyone inside the vehicle.
Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult

in an emergency.
As a safety precaution (with children on board), remove the ignition key when you leave the vehicle, even for a short time.
Do not repeatedly press the button of your remote control out of range of your vehicle.
You run the risk of stopping it from working and the remote control would have to be reprogrammed.

When purchasing a second-hand vehicle:
– ensure that you are given the confidential card;
– have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones

which can start the vehicle.

Do not make any modifications to the electronic engine immobiliser system.

12-05-2003

Changing the battery of the
remote control

The information “battery flat” is given
by an audible signal accompanied by
the message ''Remote control bat-
tery low'' on the multi-function dis­play.

To replace the battery, unclip the
casing using a coin at the ring
(CR1620/3 volt battery).

If the remote control does not work
after the battery has been changed,
re- programme the remote control.

Programming the
remote control

☞ Switch off the ignition.
☞ Switch the ignition on again.
☞ Press button A immediately.
☞ Switch off the ignition and remove

the remote control key from the
ignition lock. The remote control is
now working again.

CONFIDENTIAL CARD

The confidential card contains the
identification code necessary for any
work carried out by a PEUGEOT
dealer on the system. This code is
hidden by a film, which should be
removed only if necessary.

Keep your card in a safe place,
never inside the vehicle.

Key in ignition

The message ''Key in ignition'' on
the multi-function display, accompa­nied by a buzzer on opening the
driver’s door, indicates that the key
has been left in the ignition.

YOUR 807 IN DETAIL

106

ELECTRONIC ENGINE
IMMOBILISER

This locks the engine management
system as soon as the ignition has
been switched off and therefore
prevents starting of the vehicle by
anyone who does not have the key.

The ignition key has an electronic
chip which has a special code. When
the ignition is switched on, the code is
recognised and starting is possible.

If the system does not function cor­rectly, contact a PEUGEOT dealer as

soon as possible.

Locating your vehicle

To locate your vehicle, if you have
locked it, in a car park:

☞ press button A. The courtesy

lights come on and the direction
indicators flash for a few
seconds.

12-05-2003

YOUR 807 IN DETAIL

107

Make a careful note of the number on each key. The key number is coded on the label attached to the key.
If the keys are lost, your PEUGEOT dealer can rapidly supply you with new keys.
The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a

possibility that it may unlock your vehicle, without you being aware of it.

The remote control does not operate when the key is in the ignition, even when the ignition is switched off, except for
reprogramming.

However, do not operate the deadlocking function if there is anyone inside the vehicle.
Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult

in an emergency.
As a safety precaution (with children on board), remove the ignition key when you leave the vehicle, even for a short time.
Do not repeatedly press the button of your remote control out of range of your vehicle.
You run the risk of stopping it from working and the remote control would have to be reprogrammed.

When purchasing a second-hand vehicle:
– ensure that you are given the confidential card;
– have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones

which can start the vehicle.

Do not make any modifications to the electronic engine immobiliser system.

12-05-2003

THE ALARM

This provides two types of protec­tion:

– exterior protection: it sounds if a

door, the tailgate or the bonnet is
opened.

– interior protection: it sounds if the

volume inside the passenger com­partment changes (breaking of a
window or a movement inside the
vehicle).

Setting the alarm

☞ Switch off the ignition and get out

of the vehicle.

☞ Set the alarm within five minutes

of getting out of the vehicle, by
locking or deadlocking using the
remote control (the red indicator
light, located in the centre of the
fascia and visible from the out­side, flashes once per second).

Note: if you wish to lock your vehicle
without setting the alarm, use the
door lock.

When the alarm is triggered, the
siren sounds and the direction indi­cator lights flash for thirty seconds.

After triggering, the alarm remains
set.

Warning: if the alarm has been trig­gered ten times in succession, on
the eleventh time it becomes inac­tive.

Note: if the red warning light, located
in the centre of the fascia, flashes
rapidly, the alarm has been triggered
while you were away from your vehi­cle. To stop it flashing, insert the
remote control key and switch on the
ignition.

Disarming

Unlock the vehicle with the remote
control key (the red indicator light,
located in the centre of the fascia,
goes out).

To set the alarm with exterior
protection only

If, while you are away from the vehi­cle, you wish to leave a window par­tially open or a pet inside the vehicle,
you should choose exterior protec­tion only.

☞ Close the sunroofs,

☞ Switch off the ignition,
☞ In the next ten seconds, press

button A, located on the left-hand
side of the fascia, until the red
indicator light is on continuously,

☞ Get out of the vehicle,
☞ Within the next five minutes, set

the alarm by locking or deadlock­ing using the remote control (the
red indicator light, located in the
centre of the fascia, flashes once
a second).

Note: when the alarm is set but the
remote control does not operate:

☞ Unlock the doors with the key and

open the door. The alarm is trig­gered.

☞ Switch on the ignition in the next ten

seconds. The alarm is disarmed.

Incorrect operation

When the ignition is switched on, if
the red indicator light, located in the
centre of the fascia, comes on for ten
seconds, there is a fault in the siren
connection.

Contact a PEUGEOT dealer to have
the system checked.

Do not make any modifi­cations to the alarm sys­tem as this could cause
faults.

YOUR 807 IN DETAIL

108

12-05-2003

Precautions regarding the
passenger air bag

☞

activate the
air bag for an
adult passen­ger,

☞

disarm the
air bag if you
install a rear
facing child
seat.

Do not place your feet or any
object on the instrument panel.

Operating check

When the passenger air
bag is disarmed, the warn­ing light comes on when
the ignition is switched on

(2nd key notch), accompa­nied by an audible signal and the
message "Passenger air bag dis-

armed".
Air bag fault

If this warning light comes

on, accompanied by an

audible signal and the

message "Air bag fault",

consult a PEUGEOTdealer
to have the system
checked.

* According to country.

YOUR 807 AT A GLANCE

CRUISE CONTROL

The cruise control makes it possi­ble to maintain a constant vehicle
speed programmed by the driver
(above 25 mph [40 km/h] or
37 mph [60 km/h], depending on
the engine, with at least 4th gear
engaged), without the accelerator
pedal being pressed.

Switching on

☞ Place the knob 1 in the

ON position. The

warning light comes
on, accompanied by
an audible signal.

Storing a speed

☞

Press button 2 or 3to store the
speed at which you are driving.

☞

Press button 2 to reduce the
stored speed or button 3 to
increase it.

Deactivating the stored speed

☞

Press button 4 or the brake or
clutch pedal.

Recalling the stored speed

☞

Press button 2 or 3.

Cancelling the stored speed

☞

Place the knob 1 in the OFF
position.

Note: the stored speed is can­celled when the ignition is
switched off.

FRONT, SIDE AND
CURTAIN AIR BAGS

Disarming the passenger air
bag*

☞

With the ignition off, insert the
key into control 1 and turn it:

– "ON" position, passenger air

bag activated,

– "OFF" position, passenger air

bag disarmed.

136

11

12-05-2003

YOUR 807 IN DETAIL

111

Tailgate release

This enables the tailgate to be
unlocked in the event of a central
locking fault.

☞ Fold back a 2nd row rear seat,
☞ Fold back a 3rd row rear seat or

the bench seat to gain access to
the lock from inside the boot,

☞ Insert a small screwdriver into

hole B in the lock and push it
towards the left to unlock the
tailgate.

TAILGATE

Simultaneous locking or unlock­ing of the tailgate and the doors

The tailgate is locked or unlocked by
the remote control or the driver's
door or passenger door lock.

To open, operate the handle A and
lift the tailgate.

Note: The tailgate locks automatically
when the vehicle is being driven at
more than 6 mph (10 km/h) and
unlocks when one of the front doors is
opened.

"Tailgate open" warning

When the engine is running or the
vehicle is being driven, you are
warned if the tailgate is not closed
correctly by a diagram on the multi­function display, accompanied by an
audible signal.

PARTIALLY OPENING REAR
WINDOWS

To partially open the rear windows,
tilt the lever and push it fully to lock
the windows in the open position.

12-05-2003

Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.

In the event of contact during opera­tion of the roof, you must reverse the
movement of the roof. To do this,
press the switch concerned.

When the driver operates the roof
switch, he must ensure that no one
is preventing correct closing of the
roof.

The driver must ensure that the pas­sengers use the sunroof correctly.

Be aware of children when operat­ing the roof.

YOUR 807 IN DETAIL

112

SUNROOFS

You have three sunroofs each with
an independent control.

However, the front passenger's
control can also operate the two
rear sunroofs simultaneously.

•

to partially open the roof: press
and hold part A of the switch.

•

to open the roof completely:
press part A of the switch briefly.

•

to close it completely: press part
B of the switch briefly, then keep it

pressed.

•

safety auto-reverse

When the sunroof is sliding closed
and meets an obstacle, it stops then
partially opens again.

Notes:

In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice), if the sunroof
does not close, press section A of
the control until the roof is fully open,
then close the roof.

Continue to press the control for
approximately one second after
closing.

Following reconnection of the battery, in
the event of a malfunction, release the
control and press it again until the roof
is fully closed. Continue to press the
control for approximately five seconds
after closing.

The safety auto-reverse function is
not active during these operations.

Disarming of the 2nd and 3rd row
controls:

– press the rear electrical functions

disarming switch.
Note: the sunroof shutter is manual.
To open it, lift the handle and slide it

rearwards.
To close it, slide it forwards until the

handle locks.

12-05-2003

YOUR 807 IN DETAIL

113

FILLING
THE FUEL TANK

Low fuel level

When the tank’s minimum
level is reached, this warning
light comes on, accompanied
by the message ''Fuel level
low'' on the multi-function
display.

You have enough fuel left to cover
approximately 30 miles (50 km).

If the warning light flashes, this indi­cates a fuel gauge malfunction.

Contact a PEUGEOT dealer.
If the warning light flashes, accom-

panied by the message "Fuel circuit
disarmed", this indicates that the
fuel supply has been cut off.

Restore the supply (refer to the cor­responding section).

The tank must be filled with fuel with
the engine off.

☞ Open the fuel filler flap.
☞ Insert the key then turn it to the

left.

☞ Remove the cap and attach it to

the clip located on the inside of
the flap.

A label on the inside of the flap
indicates which type of fuel to use.

If you fill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.

The capacity of the tank is approx­imately 18 gallons (80 litres).

☞ After filling the tank, lock the cap

and close the flap.

When the fuel filler flap is
open, a system limits the
opening of the rear left
sliding side door.

The key cannot be removed from
the cap's lock until the cap is refit­ted on the tank.

OPENING THE BONNET

From inside:

– lift the cover at the left foot of the

passenger seat.
– pull the control upwards.
From outside: lift the catch and

raise the bonnet.

Bonnet strut

Secure the strut to hold the bonnet
open.

Before closing the bonnet, replace
the strut in its housing.

To close

Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked.

"Bonnet open" warning

This warning is linked to the alarm
option only.

With the engine running or the vehi­cle moving, a diagram on the multi­function display, accompanied by an
audible signal, warns you that the
bonnet is not properly closed.

12-05-2003

Direction indicators
(flashers)

Left: downwards.
Right: upwards.

YOUR 807 IN DETAIL

114

Dipped beam/main beam change

Pull the stalk fully towards you.

Lights-on buzzer

When the ignition is switched off,
when the driver’s door is opened, a
buzzer sounds, accompanied by the
message ''Side lights on'' on the
multi-function display if you have left
your lights on.

Front and rear fog lights

Rotate ring B forwards to switch on
and rearwards to switch off. The sta­tus is confirmed by the light on the
instrument panel.

Front fog lights (1st rotation
of the ring forwards)

These operate with the side lights
and the dipped beam headlamps.

Front and rear fog
lights (2nd rotation of
the ring forwards)

These operate with the side lights
and the dipped beam headlamps.

Note: to switch off the front and rear
fog lights, turn the ring rearwards
twice in succession.

In clear weather or in
rain, both day and night,
rear fog lights dazzle and
are prohibited.

Do not forget to switch
them off when they are no longer
needed.

Automatic switching on of the
lights switches off the rear fog
lamps, but the front fog lamps
remain on.

LIGHTING CONTROL

Front and rear lights

Selection is by turning ring A.

Lights off

Side lights on

Dipped beam/
Main beam

Automatic switching
on of lights

12-05-2003

AUTOMATIC SWITCHING ON
OF LIGHTS

Side lights and dipped beam head­lamps switch on automatically if the
light is poor, or during continuous
operation of the windscreen wipers.
They switch off when the light
becomes bright enough or the wind­screen wipers stop.

Note: In foggy weather, the bright­ness sensor can detect sufficient
light. As a consequence, the lights
will not come on automatically.

This function is active when the
vehicle is supplied to the customer.

To disarm or activate the function:
☞ Start with the key in the acces-

sories position (1

st

notch),

☞ Place the lights stalk in position 0,
☞ Press the end of the stalk for more

than two seconds.

Note: after the ignition is switched off
and depending on the brightness, the
lights remain on for approximately
45 seconds or until the vehicle is
locked.

Do not cover the brightness sen­sor located in the centre of the
fascia. It is used for automatic
switching on of the lights.

Operating check

Activation

Activation of this function is accom­panied by an audible signal and the
message ''Automatic lighting

active'' on the multi-function display.

Disarming

Disarming of the function is accom­panied by an audible signal.

Note: the function is disarmed tem­porarily when the driver uses the
manual lighting controls.

YOUR 807 IN DETAIL

115

12-05-2003

YOUR 807 IN DETAIL

116

WINDSCREEN
WIPER STALK

Front windscreen wiper with
intermittent wipe

2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
I Intermittent wipe.
0 Off.

 Single wipe (press downwards).

In the Intermittent position, the wip­ing speed is in proportion to the vehi­cle speed.

Front windscreen wiper with
automatic wipe

2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).

AUTO Automatic wipe.

0 Off.

 Single wipe (press downwards).

In the AUTO position, the wiping
speed is in proportion to the intensi­ty of the rainfall.

After the ignition has been
switched off, if the stalk was in a
wipe position, you must reactivate
this function:

– move the stalk to any position,
– then move it back to the required

position.

Special position of front
windscreen wiper

In the minute following switching off
of the ignition, any action on the
stalk positions the wipers against the
windscreen uprights.

This action enables you to position
the wiper blades for winter parking,
cleaning or replacement (See section
"Practical information - Changing a
wiper blade").

To park the wipers after this has
been done, switch on the ignition
and operate the stalk.

Windscreen and headlamp wash

Pull the windscreen wiper stalk
towards you. The windscreen wash
then the windscreen wipers operate
for a fixed period.

The windscreen wash and headlamp
wash operate simultaneously for two
seconds, only if the headlamps are
on.

12-05-2003

Rear windscreen wash

Turn ring A past the first
notch: the windscreen wash
then the windscreen wiper
operate for a specified time.

YOUR 807 IN DETAIL

117

Rear windscreen wiper

Turn ring Ato the first notch.
The wiping speed is
inversely proportional to the

speed of the vehicle.

Automatic rear windscreen wiping

☞ place the front wipers stalk in a

position other than 0.

☞ engage reverse gear.
☞ the rear wiper operates with inter-

mittent wiping.

Note: this function cannot be dis­armed if a bicycle carrier is fitted.
Therefore, you must fit a special bicy­cle carrier, approved by PEUGEOT,
or contact a PEUGEOT dealer.

Do not cover the rain
sensor located at the
bottom centre of the
windscreen.

When using an automatic car
wash, switch off the ignition or
check that the wiper control is not
in the automatic position.

In winter it is advisable to wait for
the windscreen to completely
clear of ice before operating the
automatic wipe.

In winter, in the presence
of a considerable amount
of snow or ice, switch on
the rear screen demister.

Once de-icing is com­plete, remove the snow or ice
which has accumulated on the
rear wiper blade. You can now
operate the rear windscreen
wiper.

Automatic timed windscreen
wipers

The automatically timed wiping is
controlled by a rain sensor fitted on
the windscreen.

In the AUTO position, the wind­screen wipers operate automatically
and adapt their speed to the inten-

sity of the rainfall.

Operating check
Activation

When the function is activated, the
message ''Automatic windscreen
wipers activated'' appears on the
multifunction display.

12-05-2003

Rear windscreen wash

Turn ring A past the first
notch: the windscreen wash
then the windscreen wiper
operate for a specified time.

YOUR 807 IN DETAIL

117

Rear windscreen wiper

Turn ring Ato the first notch.
The wiping speed is
inversely proportional to the

speed of the vehicle.

Automatic rear windscreen wiping

☞ place the front wipers stalk in a

position other than 0.

☞ engage reverse gear.
☞ the rear wiper operates with inter-

mittent wiping.

Note: this function cannot be dis­armed if a bicycle carrier is fitted.
Therefore, you must fit a special bicy­cle carrier, approved by PEUGEOT,
or contact a PEUGEOT dealer.

Do not cover the rain
sensor located at the
bottom centre of the
windscreen.

When using an automatic car
wash, switch off the ignition or
check that the wiper control is not
in the automatic position.

In winter it is advisable to wait for
the windscreen to completely
clear of ice before operating the
automatic wipe.

In winter, in the presence

of a considerable amount

of snow or ice, switch on

the rear screen demister.

Once de-icing is com­plete, remove the snow or ice
which has accumulated on the
rear wiper blade. You can now
operate the rear windscreen
wiper.

Automatic timed windscreen
wipers

The automatically timed wiping is
controlled by a rain sensor fitted on
the windscreen.

In the AUTO position, the wind­screen wipers operate automatically
and adapt their speed to the inten-

sity of the rainfall.

Operating check
Activation

When the function is activated, the
message ''Automatic windscreen
wipers activated'' appears on the
multifunction display.

12-05-2003

FILLING WITH FUEL

This operation must be carried out with the engine switched off.

☞ Open the fuel filler flap.
☞ Insert the key then turn it to the left.
☞ Remove the cap and hook it onto the clip on the inside of the flap.

A label on the inside of the flap shows which type of fuel to use.
When you fill your tank, do not continue after the third cut-off of the pump.

This could cause a malfunction.

The capacity of the tank is approximately 17 gallons (80 litres).

☞ After filling the tank, lock the cap and close the flap.

Low fuel level warning light

From the time this light comes on, accompanied by the
message "Fuel level low", the range remaining is
approximately 30 miles (50 km).

113

YOUR 807 AT A GLANCE

Inside the vehicle: lift the cover

at the left foot of the passenger
seat and pull the control upwards.

OPENING THE BONNET

Outside the vehicle: lift the con-

trol, raise the bonnet and secure
the strut to keep the bonnet
open.

12

12-05-2003

YOUR 807 IN DETAIL

121

ELECTRIC WINDOWS

1 - Driver's electric window

switch.

2 - Passenger electric window

switch.

3 - Rear right electric window

switch.

4 - Rear left electric window

switch.

5 - Rear electric windows disarm-

ing switch (child safety).

– red strip visible: switches acti-

vated.

– red strip covered: switches

disarmed.

You have two options:

Manual operation:

☞ press or pull switch 1, without

going beyond the point of resis­tance. The window stops when
the switch is released.

Automatic operation:

☞ press or pull switch 1, beyond

the point of resistance: the win­dow opens or closes completely
when the switch is released.
Pressing the switch again stops
the movement of the window.

Note: the electrical functions of the
electric windows are disarmed one
minute after switching off the ignition.

Safety auto-reverse

When the window rises and meets
an obstacle, it stops and partially
lowers again.

Notes:

In the event of unwanted opening of
the window on closing (for example,
in the presence of ice), press the
switch until the window is fully open,
then pull it again until the window
closes. Continue to hold the switch
for approximately one second after
the window has closed.

Following reconnection of the battery,
in the event of a malfunction, release
the switch and pull it again until the
window is fully closed.

Continue to hold the switch for
approximately one second after the

Disarming

For the safety of your children, press
switch 5 to disarm all of the electrical
controls in the rear:

☞ electric windows,
☞ sliding side doors,
☞ sunroofs.

Always remove the igni­tion key on leaving the
vehicle, even for a short
time.

In the event of contact during
operation of the windows, you
must reverse the movement of the
window.

To do this, press the switch con­cerned. When the driver operates
the passenger electric wndow
switches, he must ensure that no
one is preventing correct closing
of the windows.

The driver must ensure that the
passengers use the electric win­dows correctly.

Be aware of children when operat­ing the windows.

window has closed.

The safety auto-reverse function
is not active during these opera­tions.

12-05-2003

YOUR 807 IN DETAIL

123

SUN VISOR WITH ILLUMINA T­ED COURTESY MIRROR

With the ignition on, the mirror is
automatically lit up when the flap is
opened.

SIDE BLINDS

Side blinds are available in the rear
2nd and/or 3rd rows.

Pull the side blind by the centre tab.
Position the blind's attachment(s) on

the corresponding hook(s).

REAR SCREEN SUN BLIND

Pull the blind by the central tab, and
then position its attachments on the
corresponding hooks.

Manual interior mirror

The interior mirror has two positions:
– day (normal),
– night (anti-dazzle).
To change from one to the other,

push or pull the lever on the lower
edge of the mirror.

AREAS FOR TOLL CARDS/
CAR PARK TICKETS

The athermic windscreen has two
non-reflective zones located either
side of the base of the interior mirror.
They are intended for affixing toll
cards and/or car park tickets.

CHILD MONITORING MIRROR

This mirror enables the driver or front
passenger to observe all the rear
seats.

Fitted on its own ball joint and able to
retract into its housing in the roof, it
provides a panoramic view of the
rear interior of the vehicle.

12-05-2003

HORN

Press one of the spokes or
the centre of the steering
wheel.

YOUR 807 IN DETAIL

124

MANUAL ADJUSTMENT OF
THE HEADLAMPS

Depending on the load in your vehi­cle, adjusting the beam of your head­lamps is recommended.

0-1 or 2 people in the front seats.
1-5 people.
2-6 to 8 people.
3-Driver + maximum authorised

loads.

Initial setting is position 0.

AUTOMATIC ADJUSTMENT
OF THE HEADLAMPS

Refer to the paragraph on Lighting
under the section entitled 'Towing a
trailer...'.

HAZARD WARNING LIGHTS

Press the button, the direction indi­cators flash.

They can operate with the ignition
off.

STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT

When the vehicle is stationary,
unlock the steering wheel by lower­ing the lever A.

Adjust the height and depth of the
steering wheel, then lock by pushing
lever A fully upwards.

Automatic lighting of hazard
warning lights*

When braking in an emergency,
depending on the force of decelera­tion, the hazard warning lights come
on automatically. They switch off
automatically the first time you accel­erate.

It is also possible to switch them off
by pressing the button.

* According to destination.

12-05-2003

YOUR 807 IN DETAIL

125

COURTESY LIGHTS

Off.

Come on when a door is opened.

Permanently on, with the key in the accessories position or the ignition on.

1 - Front courtesy light
2 - 2nd row rear courtesy light
3 - 3rd row rear courtesy light
4 - Front map reading lights
5 - 2nd row rear map reading lights
6 - 3rd row rear map reading lights

The front and rear courtesy lights
come on when the ignition key is
removed, on unlocking the vehicle or
on opening one of the doors.

They gradually go off after the ignition
has been switched on, after the vehi­cle is locked or after the last door is
closed.

☞ With the ignition off, pressing

switch 1turns on the front courtesy
light for ten minutes.

☞ With the ignition off, pressing

switch 2 or 3 turns on the corre­sponding rear courtesy light for
ten minutes.

The front and rear map reading lights
are switched on by operating the cor­responding switch. These are active
when the key is in the accessories
position (1st notch) or the ignition is on.

12-05-2003

YOUR 807 IN DETAIL

126

12-05-2003

YOUR 807 IN DETAIL

127

FRONT INTERIOR LAYOUT

1. Driver's upper glove box

T o open, press the button.
T o close, press the cover .
It includes special compartments

for storing a pen, a mobile tele­phone, coins or tokens and credit
cards.

2. Audio equipment concealing
flap

Lower the flap fully to lock it in
place.

Press the flap to raise it.

3. Central storage compartment

4. Passenger's upper glove box

T o open, press the button.
T o close, press the cover .
It includes special compartments

for storing a pair of spectacles,
keys, five CDs and four audio
cassettes or nine audio CDs.

5. Passenger's lower glove box

This is fitted with a lock.
T o open the glove box, lift the

handle.
The light comes on when the

cover is opened.
It contains three sockets for the

connection of video equipment
and access to the fascia fuse
box.

It includes special compartments
for storing maps, a packet of ciga­rettes, an A4 document etc.

6. Lighter or 12 V socket for
accessories

This permits the connection of a
mobile telephone charger, a
baby's bottle warmer, etc.

7. Cooled compartment

It can hold up to three cans.
Slide the closer, located at the

top, to open or close the air inlet.

8. Can holder and ashtray

This retractable and lit support
contains up to two can holders, a
removable ashtray and a loca­tion for the lighter when it is used
as a 12 V socket.

9. Storage compartment or
remote keypad

The storage compartment must
not be used as an ashtray.

10. Storage compartment

11. Door tray with storage space
for a bottle of water

12-05-2003

YOUR 807 IN DETAIL

128

12-05-2003

YOUR 807 IN DETAIL

129

REAR INTERIOR LAYOUT

1. Access handle

2. Grab handle and coat hook

3. Door tray with storage for
a can and a bottle of water
or for the portable bin with
ashtray

4. High load retaining net
fastenings

Open the covers of the upper
fastenings at the 3rd row.

Install the ends of the metal bar
in these fastenings.

Secure the two tray strap hooks
in the stowing rings on the floor.

Pull the two straps taut.
Secure the two hooks on the

elastic parts of the tray in these
rings.

Note: the rings are located
directly below the corresponding
upper fastenings.

5. Storage compartment

6. Can holder

7. Storage compartment

8. Bottle holder or portable bin
with ashtray

9. Luggage retaining net
"low load" version fastenings

Fold the net in two.
Secure the two centre hooks in

the stowing rings on the floor.
Secure the net's remaining four

hooks on the tailgate pillars.

10. 12 V socket for accessories

This permits the connection of a
mobile telephone charger, a
baby's bottle warmer, ...

11. Luggage retaining net

Secure the net's four hooks in
their stowing rings on the floor.

12. Load space cover

T o install it:
– position one end of the roller in

the 2nd row,

– compress the opposite end of

the roller and position it,
– release it to allow it to engage,
– unroll the cover as far as the

rear shelf,
– secure the two hooks under

the rear shelf,
T o remove it:
– remove the cover hooks from

under the rear shelf,
– return the cover into its roller,
– compress it and remove it from

its support at the 2nd row.

13. Rear shelf with umbrella
holder

T o remove the shelf:
– pull it rearward
– lift it slightly, then remove it

T o store it:
– either hooked onto the load

space cover

– or behind the seats or the rear

bench seat

12-05-2003

AUTOMATIC GEARBOX 'PORSCHE TIPTRONIC SYSTEM'

The four speed automatic gearbox offers a choice between the comfort of
automatic integral regulation enhanced by a snow programme, or the
pleasure of manual gear changing.

Gear selection gate

☞ Move the lever in the gate to select one of the functions.

Once the function is selected, the indicator light for that function is dis­played on the instrument panel screen.



: snow programme.

Park: to park or to start the engine, with the handbrake on or off.
Reverse: to reverse (select this function with the vehicle stationary and the

engine at idle).

Neutral: to start the engine or to park, with the handbrake on.

Note: if position N is engaged by mistake
while the car is moving, allow the engine
to return to idling speed before engaging
function D to accelerate.

Drive: for automatic gear changing.

Manual: for manual gear changing.
To change the four gears manually:

☞ Push the lever to the + symbol to

change up to the next gear and pull the
handle towards the – symbol to
change down to the next gear.

Note: the



(snow) programme does not

operate when in manual mode.

Moving Off

With the engine running, to move
off from position P:

☞ It is essential to press the

brake pedal to exit position
P

☞ Select the function required R,

D or M, then gradually release

the pressure on the brake
pedal; the vehicle will move off
immediately.

You can also move off from posi­tion N:

☞ Release the handbrake, with

your foot on the brake.

☞ Select function R, D or M then

gradually release the pressure
on the brake pedal; the vehi­cle will move off immediately.

When the engine is idling with
the brakes not applied, if function
R, D or M is selected, the vehicle
moves without the accelerator
being pressed.

For this reason, do not leave
children unattended inside the
car, with the engine
running.

134

YOUR 807 AT A GLANCE

13

12-05-2003

When this warning light
comes on, connected to the

STOP warning light, accom-

panied by a buzzer and the

message 'Braking fault', it
indicates that there is a malfunction of
the electronic brake force distribution,
which can cause a loss of control of
the vehicle when braking.

Stop immediately.

In both cases, consult a Peugeot
dealer.

ANTI-LOCK BRAKING
SYSTEM (ABS) AND THE
ELECTRONIC BRAKE FORCE
DISTRIBUTION (EBFD)

The ABS, in conjunction with the
electronic brake force distribution,
increases the stability and manoevra­bility of your vehicle, particularly on
poor or slippery road surfaces.

Note: when changing wheels (tyres
and rims), make sure that these are
approved.

The anti-lock braking system comes
into operation automatically when
there is a risk of wheel lock.

When this warning light
comes on, accompanied by
a buzzer and the message
"ABS fault", it indicates

that there is a malfunction of
the ABS, which can cause a loss of
control of the vehicle when braking.

YOUR 807 IN DETAIL

130

T o return to normal operation, pull
the lever upwards until a click is
heard.

Illumination of this light,

accompanied by an audible

signal and the message

"handbrake on" on the

multi-function display, indi­cates that the handbrake is still on or
has not been properly released.

HANDBRAKE

Applying

When parking, pull the handbrake to
immobilize your vehicle.

Warning: when parking on a slope,
direct your wheels towards the
pavement and pull the handbrake.

Releasing

Pull on the handle and press the
button to release the handbrake.

Disengaging

Apply the handbrake.
Pull the button located at the end of

the handbrake forwards.
The handbrake lever lowers.
You can now pivot the seat.

EMERGENCY BRAKING
ASSISTANCE SYSTEM

In an emergency, this system
enables the optimum braking pres­sure to be reached more quickly,
thus reducing the stopping distance.

It is triggered by the speed at which
the brake pedal is activated. The
effect of this is a reduction in the
resistance of the pedal and an
increase in braking efficiency.

Normal operation of the ABS may
make itself felt by slight vibrations
of the brake system.

In emergency braking, press
very firmly without releasing
the pressure.

12-05-2003

Operation of the ASR and ESP
systems

When one of these two sys­tems is operating, this light
flashes.

YOUR 807 IN DETAIL

131

Disarming the ESP/ASR
systems

In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),
it could prove useful to disarm the
ASR and ESP systems to make the
wheels spin and regain grip.

☞ Press switch 1, situated under the

steering wheel on the left of the
fascia.

The indicator light comes on

accompanied by the mes-

sage "ESP/ASR disarmed":

the ESP and ASR systems

no longer act on the engine
operation, but continue to act on the
brakes.

They engage again:

☞ automatically above 20 mph

(30 kmh),

☞ manually by pressing the switch

1 again.

Operating check

When a malfunction of the
systems occurs, the indica­tor light comes on accompa­nied by an audible signal

and the message
"ESP/ASR not operational" on the
multifunction display.
Contact a PEUGEOT dealer to have
the system checked.

TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP)

These systems are linked and com­plement the ABS.

The ASR system optimises drive to
prevent the wheels skidding, by acting
on the brakes of the drive wheels and
on the engine. It also allows the direc­tional stability of the vehicle to be
improved on acceleration.

If there is a variation between the tra­jectory followed by the vehicle and
that required by the driver, the ESP
system automatically acts on the
engine and the brake of one or more
wheels, in order to put the vehicle
back on course.

The ESP system offers
increased safety during
normal driving, but should
not incite the driver to take

risks or to drive at high speed.
The operation of the system is

ensured to the extent to which the
recommendations of the manufac­turer regarding the wheels (tyres
and wheel rims), the braking com­ponents, the electronic compo­nents and the assembly and
repair procedures within the
PEUGEOT network are observed.

After an impact, have the system
checked by a PEUGEOT dealer.

12-05-2003

Changing a memorised speed

T o memorise a speed higher than
the previous one:

☞ press button 3;
☞ release it when you have

reached the required speed.

T o memorise a speed lower than the
previous one:

☞ press button 2;
☞ release it when you have

reached the required speed.

Cancelling the cruise control

☞ place knob 1 in the OFF position

or switch off the ignition.

The warning light goes out to indi­cate that the cruise control is off.

YOUR 807 IN DETAIL

132

CRUISE CONTROL

Cruise control enables the vehicle to
maintain a steady speed pro­grammed by the driver, regardless
of the road characteristics and with­out the driver having to touch the
accelerator or brake pedals.

In order for it to be memorised, the vehi­cle speed must be greater than 25 mph
(40 km/h) or 37 mph (60 km/h) and
fourth or fifth gear must be engaged.

Operation

☞ Place knob 1 in the ON

position.

A speed can be memorised.

Illumination of this indicator light
indicates that the cruise control is on.

☞ Place knob 1 in the OFF position

to cancel.

Memorising a speed

As soon as you reach the chosen
speed, press button 2 or 3. This
memorises the speed, which will be
maintained automatically.

Note: It is possible to accelerate and
drive momentarily at a speed greater
than the speed stored. When the
accelerator pedal is released, the
vehicle will return to the stored speed.

Cancelling the memorised speed

If you wish to cancel the memorised
speed:

☞ Press button 4 or the brake or

clutch pedal.

Recalling the memorised speed

After cancellation, press button 4.
Your vehicle will return to the last
memorised speed.

Do not use cruise control
on slippery roads or in
heavy traffic.

12-05-2003

YOUR 807 IN DETAIL

133

REAR PARKING ASSISTANCE

This system consists of four proximity
sensors, located in the rear bumper,
and a special speaker.

This detects any obstacle (person,
vehicle, tree, gate, etc.) behind the
vehicle. Nevertheless, it cannot
detect obstacles located just below
the bumper.

An object, such as a stake, a road­works cone or any other similar
object may be detected at the begin­ning of the manoeuvre, but may no
longer be detected when the vehicle
comes close to it.

Note: this function will be disarmed
automatically when the vehicle is
towing a trailer or when a bicycle car­rier is fitted (vehicle fitted with towing
attachment or bicycle carrier recom­mended by PEUGEOT).

In bad or wintry weather, ensure that
the sensors are not covered with
mud, frost or snow.

Deactivation

☞ Change to neutral, the system is

again inactive.

Activation

The system is activated as soon as
reverse gear is engaged; an audible
bleep shows that it is active.

The proximity information is given by
an audible signal, which becomes
more rapid as the vehicle approaches
the obstacle.

When the distance between the rear
of the vehicle and the obstacle is
less than approximately twenty-five
centimetres, the audible signal
becomes continuous.

Detection zone

If there is an operating
fault, the audible signal will
be a short bleep followed
by a long bleep when
changing to reverse gear.

12-05-2003

YOUR 807 IN DETAIL

134



: snow programme

Park: to immobilise the vehicle or start the engine,

with the handbrake on or off.

Reverse: to reverse (select this function with the

vehicle stationary, engine at idle).

Neutral: to start the engine and to park, with the

handbrake on.
Note: if function N is engaged inadvertently while

driving, allow the engine to return to idle before
engaging function D to accelerate.

Drive: for driving in automatic mode.
Manual: for driving in manual mode.

Moving off

With the engine running, to move off
from position P:

☞ it is essential to press the

brake pedal to exit position P,

☞ select function

R, D or M, then

gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.

Y ou can also move of f from position

N:

☞ release the handbrake, with your

foot on the brake

☞ select function

R, D or M, then

gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.

WARNING

When the engine is at idle, brakes
not applied, if function R, D or M is
selected the vehicle moves even
without the accelerator being
pressed.

For this reason, do not leave chil-

dren unsupervised inside the
vehicle, with the engine running.

When maintenance operations need
to be carried out with the engine run­ning, apply the handbrake and select
position P.

"PORSCHE TIPTRONIC SYSTEM" AUTOMATIC GEARBOX

The four speed automatic gearbox offers a choice between the comfort of
integral automatic operation, enhanced by a snow programme, or the
pleasure of manual gear changing.

Gear selection gate

☞ Move the lever in the gate to select a function.

Once the function is selected, the corresponding indicator light appears on
the instrument panel display.

If the battery is flat and the lever is in position P, it will be impossible to
change to another position.

12-05-2003

YOUR 807 IN DETAIL

135

Automatic operation

Automatic changing of the four
gears:

☞ select function D in the gate.
The gearbox always selects the most

suitable gear according to the follow­ing parameters:

– the style of driving,
– the road profile,
– the vehicle load.
The gearbox is then operating in

auto-adaptive mode, without any
action on your part.

WARNING

Never select function N when the
vehicle is moving.

Never select functions P or R unless
the vehicle is stationary.

Never change between functions to
optimise braking on a slippery surface.

Notes

For immediate maximum accelera­tion without touching the gear lever,
press the accelerator pedal down as
far as it will go (kickdown). The gear­box will automatically change down
or maintain the gear selected until
maximum engine speed is reached.

When braking, the gearbox will auto­matically change down in order to
provide efficient engine braking.

If you take your foot off the accelera­tor suddenly, the gearbox will not
change to a higher gear for reasons
of safety.

Snow programme

In addition to the auto-adaptive
programme, there is a special pro­gramme.

The programme is displayed on the
instrument panel screen.

The Snow programme improves
starting and drive when traction is
poor.

☞ Press button



once the vehicle
has been started and function D
selected.

The gearbox adapts to driving on
slippery roads.

Note: you can return to the auto­adaptive programme at any time.

☞ Press button



again to switch

off the programme you are in.

Manual operation

Manual changing of the four gears:

☞ select function M in the gate,
☞ push the lever to the + sign to

change to a higher gear,

☞ pull the lever to the – sign to

change to a lower gear.

You can change from position D
(driving in automatic mode) to posi­tion M (driving in manual mode) at
any time.

Note

It is only possible to change from one
gear to another if the vehicle speed
and engine speed permit. If they do
not, the vehicle will operate tem­porarily in automatic mode.

When the vehicle is stationary or
moving very slowly, the gearbox
automatically selects gear M1.

The



(snow) programme does not

operate in manual mode.

Operating abnormality

Any operating abnormality is indicat­ed by an audible signal, accompa­nied by the message "Automatic
gearbox faulty" on the multi-function
display and flashing of the Snow
warning light on the instrument panel.

In this situation the gearbox operates
in downgrade mode (locked in 3rd
gear). You may feel a substantial
knock when changing from P to R
and from N to R (this will not cause
any damage to the gearbox).

Do not exceed 60 mph (100 km/h),
keeping within the limit of local
speed restrictions.

Contact a PEUGEOT dealer as soon
as possible.

12-05-2003

YOUR 807 IN DETAIL

136

MANUAL GEARBOX

Reverse*

T o change to reverse gear, lift the
ring under the gear lever knob and
push the gear lever to the left then to
the front.

Reverse gear can only be engaged
when the vehicle is stationary with
the engine idling.

* According to engine.

AIR BAGS

The air bags have been designed to
maximise the safety of the occupants
in the event of serious collisions.
They work in conjunction with the
force-limiting seat belts. The elec­tronic detectors register and analyse
any abrupt deceleration of the vehi­cle: if the triggering threshold is
reached, the air bags inflate instantly
and protect the occupants of the
vehicle.

Immediately after the impact, the air
bags deflate rapidly so that they do
not hinder the visibility of the occu­pants nor their exit if necessary from
the vehicle.

The air bags are not deployed in the
case of collisions which are not seri­ous, for which the seat belt is suffi­cient to ensure maximum protection.
The seriousness of a collision
depends on the nature of the obsta­cle and the speed of the vehicle at
the moment of the collision.

Air bags only operate when the
ignition is switched on.

Note: the gas escaping from the air

bags can be a minor irritant.

FRONT AIR BAGS

These are folded in the centre of the
steering wheel for the driver and in
the fascia for the front passenger.
They are deployed simultaneously,
except in cases where the passenger
air bag is disarmed.

Front air bag fault

If this warning light comes
on, accompanied by an
audible signal and the mes­sage "Air bag fault" on the
multifunction display, con­tact a PEUGEOT dealer to
have the system checked.

12-05-2003

REAR PARKING
ASSISTANCE

This system, installed in the rear
bumper, detects any obstacle
(person, vehicle, tree, barrier, ...)
behind the vehicle.

Switching on

With the engine running, the sys­tem is activated when reverse
gear is engaged. A bleep indi­cates that it is active.

The proximity information is
given by an audible signal, con­sisting of bleeps which becomes
more rapid as the vehicle
approaches the obstacle.

When the distance between the
rear of the vehicle and the obsta­cle is less than approximately
twenty-five centimetres, the audi­ble signal becomes continuous.

☞ When you change to

neutral, the system
becomes inactive
again.

TYRE UNDER-INFLATION
DETECTION

Sensors check the pressure of
the tyres while driving and trigger
a warning in the event of a mal­function (speed above 15 mph
[25 km/h]).

Tyre(s) under-inflated

When this message appears on
the multifunction display, accom­panied by an audible signal, have
the pressure of the tyres checked
as soon as possible.

Tyre(s) punctured

The appearance of this message,
accompanied by an audible sig­nal, is followed by illumination of
the STOP warning light.

Stop immediately, avoiding any
sharp action on the steering
wheel or the brakes.

Change the damaged (punctured
or significantly under-inflated)
wheel and have the pressure of
the tyres checked as soon as
possible.

Note: if the damaged wheel is
stored in the boot temporarily, it
will transmit this message again
as a reminder that it must be
repaired, which will prevent
another warning of the same type
being displayed.

The spare wheel does not have a
sensor.

X tyre pressure sensor(s)
missing

The appearance of this message,
accompanied by an audible
warning, indicates that one wheel
(or more) is no longer detected.

Consult a PEUGEOT dealer to
have the faulty sensor(s)
replaced.

This message is also
displayed when one of
the wheels is removed

from the vehicle (for
repair) or when a wheel is fitted
which is not equipped with a
sensor (winter tyres).

This system does not eliminate
the need to have the pressure
of the tyres checked regularly.

133 143

YOUR 807 AT A GLANCE

14

12-05-2003

PRACTICAL INFORMATION

141

CHECKING THE LEVELS

Oil level

Check the level regularly and top up
between changes (maximum con­sumption is 0.5 l per 600 miles
(1 000 km).

Note: checking is carried out with
the vehicle level, engine cold, using
the oil level gauge on the control
module or the dipstick.

Dipstick

There are two marks
on the dipstick:

A = maximum.
Never fill past this

mark.
B = minimum.

To maintain the reliabi­lity of engines and
emission control sys­tems, the use of addi­tives in engine oil is
prohibited.

Oil change

According to the information given in
"PEUGEOT SERVICING".

Note: Prevent used oil from coming
into prolonged contact with the skin.

Viscosity selection

In all cases, the oil selected must
meet the manufacturer's require­ments.

Brake fluid level:

– The level must always be between

the DANGER and MAXIMUM
marks in the reservoir.

– If the level drops substantially,

contact a PEUGEOT dealer imme­diately.

Fluid change:

– must be carried out according to

the manufacturer's schedule

– use fluids recommended by the

manufacturer, which fulfil DOT4
standards.

Note: brake fluid is harmful to health
and very corrosive. Avoid any con­tact with the skin.

Coolant level

Use fluid recommended by the manu­facturer.

When the engine is warm, the tem­perature of the coolant is controlled
by the engine fan. As this fan can
operate with the ignition off and
because the cooling system is pres­surised, wait for at least one hour
after the engine has stopped before
carrying out any work.

Unscrew the cap two turns to allow
the pressure to drop to prevent any
risk of scalding. When the pressure
has dropped, remove the cap and
top up the level.

Note: The coolant does not need to
be changed.

Used oil

Do not dispose of used oil, brake
fluid or coolant into drains or onto the
ground.

Power steering reservoir

Open the reservoir, with the engine
at ambient temperature. The level
should always be above the MINI
mark and close to the MAXI mark.

Windscreen and headlamp*
wash level

For best quality cleaning and for
your safety, we recommend that you
use products recommended by
PEUGEOT.

Measure the fluid level using the dip­stick incorporated in the reservoir
cap (vehicles fitted with headlamp
wash).

Close the air hole on the cap and
remove it, then check the level.

* According to destination.

12-05-2003

PRACTICAL INFORMATION

142

Only use products recom­mended by PEUGEOT.

To ensure best perfor-

mance from compo­nents as important as the power
steering and the braking system,
PEUGEOT selects and offers
quite specific products.

CHECKS
Battery

At the start of winter, have your bat­tery checked by a PEUGEOT dealer.

Air filter and passenger
compartment filter

Have the filter elements replaced
regularly. If you drive in dusty con-

ditions, change them twice as
often.

Brake pads

Brake pad wear depends on the
style of driving, in particular for vehi­cles which are used in town, over
short distances.

It may be necessary to check the
thickness of the pads, even between
services.

Handbrake

Where the handbrake travel is too
great or there is a reduction in the
performance of the system, the
handbrake should be adjusted, even
between services.

Have the system checked by a
PEUGEOT dealer.

Fuel supply cut-off

In a serious collision, a mechanism
automatically prevents fuel from
reaching the engine.

The flashing of this warning
light is accompanied by the
message "Fuel circuit dis-
armed" on the multifunction
display.

To re-establish the fuel supply:

☞ switch off the ignition.
☞ remove the key.
☞ check that there is no odour or

leakage of fuel outside the vehicle.

☞ put the key back in the ignition
☞ switch on the ignition and start.

Manual gearbox

This does not need an oil change.
Check the level, according to the
manufacturer's service schedule.

Automatic gearbox

This does not need an oil change.
Have the level checked by a
PEUGEOT dealer in accordance
with the manufacturer's service
schedule.

Oil filter

Change the filter regularly, in accor­dance with the service schedule.

12-05-2003

143

TYRE UNDER-INFLATION
DETECTION

Sensors check the tyre pressure
during driving, and trigger a warning
in the event of malfunction (speed
greater than 15 mph [25 km/h]).

Flat tyre

When the message "Tyres deflated"
appears on the multifunction display,
accompanied by an audible signal,
have the tyre pressure checked as
soon as possible.

Puncture

The message "Punctured tyre(s)"
appears on the multifunction display,
accompanied by an audible signal
and followed by illumination of the
"STOP" warning light.

Stop immediately, avoiding any sud­den movement of the steering wheel
and the brakes.

Change the damaged (punctured or
very deflated) tyre, and have the tyre
presure checked as soon as possible.

Note: if the damaged tyre is
temporarily stored in the boot, it will
again emit this message to remind
you of the necessity of having it
repaired. This will prevent another
warning of the same type being
displayed.

Sensor(s) not detected

When the message "X tyre pres­sure sensor(s) missing" appears

on the multifunction display, accom­panied by an audible signal, this indi­cates that under-inflation detection is
absent from one (or several) tyre(s).

Contact a PEUGEOT dealer to
replace the faulty sensor(s).

Note: this message is also displayed
when one of the tyres is away from
the vehicle (being repaired) or when
a wheel without a sensor is fitted.

PRACTICAL INFORMATION

All repairs and changing
of tyres on a wheel fitted
with this system must
be carried out by a
PEUGEOT dealer.

The tyre under-inflation detec­tion system is a driving aid
which does not take the place
of vigilance or the responsibility
of the driver.

This system does not remove the
need to have the tyre pressure
checked regularly (including the
spare wheel), to ensure that the
dynamic performance of the vehicle
remains at its best and to avoid
premature wear of the tyres, in
particular in the case of arduous
driving (heavy load, high speed).

The system may temporarily be
disturbed by radio broadcasts on
a frequency close to it.

12-05-2003

PRACTICAL INFORMATION

144

CHANGING A WHEEL

Parking the vehicle

☞ If possible, park the vehicle on

level, stable and non-slippery
ground.

☞ Apply the handbrake, switch off

the ignition and engage first or
reverse gear (position P for the
automatic gearbox).

Access to the spare wheel

☞ Open the tailgate.
☞ Pull and turn the towing eye to

unlock the lifting tool and access
the bolt.

☞ Unscrew the bolt fully, using the

wheelbrace 1 to unwind the lifting
tool cable.

☞ Detach the spare wheel through

the rear of the vehicle.

☞ Take out the hinged hook via the

wheel shaft to release it.

Tools

The following tools are located in the
engine compartment

1 - Wheelbrace.
2 - Jack
3 - Removable towing eye.
4 - Alloy wheel embellisher remover

Removing the wheel

☞ Place a chock 3 if possible under

the wheel diagonally opposite to
the one to be changed.

☞ Remove the trim, using the wheel-

brace 1, pulling at the valve pas­sage hole.

☞ Loosen the wheel bolts (for vehi-

cles fitted with alloy wheels,
remove the wheel embellisher 4).

☞ Remove the cover from the jack

support holder.

☞ Detach the jack fixing strap and

take it out from the bottom of the
jack support holder.

☞ Place the jack 2in contact with one

of the four locating points A on the
sub-frame (the one which is closest
to the wheel to be changed).

☞ Extend the jack 2 until its base is

in contact with the ground. Ensure
that the centre line of the base of
the jack is straight above the
locating point A.

☞ Raise the vehicle.
☞ Unscrew the bolts and remove the

wheel.

12-05-2003

PRACTICAL INFORMATION

145

Anti-theft bolts*

If your wheels are fitted with an anti­theft bolt (one per wheel), unscrew
the bolt using one of the anti-theft
sockets which were given to you on
delivery of your vehicle along with
the duplicate keys and confidential
card and the wheelbrace 1.

Note: make a careful note of the
code number on the head of the anti­theft socket. This willl enable you to
obtain a duplicate anti-theft socket.

* According to specification and country.

Fitting a wheel

☞ Position the wheel using the cen-

tralising tool, fitted on the hub.

☞ Tighten the bolts by hand.
☞ Partly tighten the bolts using the

wheelbrace 1.

☞ Fold the jack 2 completely and

remove it.

☞ Fully tighten the bolts using the

wheelbrace 1.

☞ Replace the wheel trim, starting

by placing the wheel trim notch
opposite the valve, and press it on
using the palm of the hand.

☞ Refit the wheel, with the valve

towards the top, under the vehicle
with the lifting tool, in line with the
illustration.

☞

Tighten fully and check that the
wheel is lying flat against the rear
floor.

For your safety, always
change the wheel:

– on level, stable, non-slippery

ground,

– with the handbrake on and the

ignition switched off,

– with first or reverse gear

engaged (position P for the
automatic gearbox),

– with the vehicle chocked.

Never go underneath a vehicle
that is supported only by a jack
(use a ramp).

After changing the wheel:

– have the tightening of the bolts

and the tyre pressure checked
by a PEUGEOT dealer as soon
as possible.

– have the punctured wheel

repaired and refit it to the vehicle
as soon as possible.

– ask a PEUGEOT dealer to check

that the spare wheel is fitted
correctly.

☞ Fold down the ring to lock the

lifting tool.

☞ Put the tools in the engine com-

partment.

12-05-2003

PRACTICAL INFORMATION

154

CHANGING A WINDSCREEN
WIPER BLADE

Placing the wiper blades in the
maintenance position

☞ Less than a minute after switching

off the ignition, operate the wipers
stalk to position the wiper blades
along the windscreen uprights
(maintenance position).

Changing a front wiper blade

☞ Lift the wiper arm, then disconnect

the windscreen-wash pipe.

☞ Unclip the blade and remove it.
☞ Fit the new blade.
☞ Reconnect the windscreen-wash

pipe and push back the wiper arm.

To return the windscreen wipers
to their normal position, switch on
the ignition and operate the
wipers stalk.

Changing the rear wiper blade

☞ Lift the wiper arm, then unclip the

blade and remove it.

☞ Fit the new blade and push back

the wiper arm.

ECONOMY MODE FUNCTION

After the engine has stopped, with
the key in the accessories position,
certain functions (windscreen wiper,
electric windows, courtesy lights,
audio equipment etc.) can only be
used for thirty minutes, to prevent
discharging the battery.

Once the thirty minutes are over, the
message "Economy mode active"
appears on the multifunction display
and the active functions are put on
standby.

A flat battery will prevent
the engine from starting.

12-05-2003

BATTERY

To charge the battery using a battery charger:

– Disconnect the battery,
– Follow the instructions for use given by the battery charger manufacturer,
– Reconnect starting with the negative (–) terminal,
– Check that the terminals and connectors are clean. If they are covered with

sulphate (white or greenish deposit), disconnect them and clean them.

To start the vehicle from another battery:

– Connect the red cable to the positive (+) terminals of the two batteries,
– Connect one end of the green or black cable to the negative (–) terminal of the

slave battery,

– Connect the other end of the green or black cable to an earth point on the bro-

ken down vehicle as far as possible from the battery,
Operate the starter, let the engine run.
Wait for the engine to return to idle, then disconnect the cables.

It is advisable to disconnect the battery if the vehicle is not to be used for
a period of more than one month.

PRACTICAL INFORMATION

155

– Before disconnecting

the battery, you must
wait for 2 minutes after
switching off the igni­tion.

– Never disconnect a terminal

when the engine is running.

– Never charge a battery without

first disconnecting the terminals.

– Close the windows and sunroof

before disconnecting the battery.
If they do not operate normally
following reconnection of the
battery, they must be reintialised
(see sections "Electric windows ­Safety auto-reverse" and "Sun­roof - Safety auto-reverse".

– After every reconnection of the

battery, switch on the ignition
and wait 1 minute before
starting to allow the electronic
systems to be initialised. If slight
difficulties are experienced
after this, please contact a
PEUGEOT dealer.

12-05-2003

PRACTICAL INFORMATION

156

TOWING YOUR VEHICLE
Without lifting (4 wheels on the road)

You should always use a tow bar.
The removable towing eye is inside the engine compartment.

From the front:

☞ Unclip the cover by pressing the bottom part,
☞ Screw in the removable towing eye until it locks.

From the rear:

☞ Unclip the top of the cover using a coin,
☞ Screw in the removable towing eye until it locks.

Lifting (2 wheels on the road only)

It is preferable to raise the vehicle using professional lifting equipment.

When towing with the
engine switched off,
there is no braking or
steering assistance.

Special features
of the automatic gearbox

When being towed with four wheels
on the road, it is essential to observe
the following rules:

– selector lever in position N,
– tow the vehicle at a speed below

30 mph (50 km/h) over a distance
limited to 30 miles (50 km) maxi­mum,

– do not add oil to the gearbox.

12-05-2003

TOWING A TRAILER,
CARAVAN, BOAT ETC...

Only use original PEUGEOT tow
bars which have been tested and
approved from the design stage of
your vehicle.

The tow bar must be fitted by a
PEUGEOT dealer.

Driving advice

Distribution of loads: distribute the

load in the trailer so that the heaviest
loads are as close as possible to the
axle and the nose weight is close to
the maximum authorised without,
however, exceeding it.

Cooling: towing a trailer on a slope
increases the coolant temperature.

As the fan is electronically controlled,
its cooling capacity is not dependent
on the engine speed.

On the contrary, use a high gear to
lower the engine speed, and reduce
your speed.

In all cases, pay attention to the
coolant temperature.

Note: in certain cases of particularly
arduous use (towing the maximum
load up a steep slope in high tem­peratures), the engine automatically
limits its power. In this case, cutting
off the air conditioning allows the
engine power to be recovered, and
therefore the towing speed to be sig­nificantly increased (approximately
12 mph [20 km/h] more).

If the coolant temperature warning
light comes on, stop the vehicle and
switch off the engine as soon as pos­sible.

Tyres: check the tyre pressures of the
towing vehicle and of the trailer,
observing the recommended pressure.

Brakes: towing increases the brak­ing distance. Drive at a moderate
speed, change down early and brake
gradually.

Side wind: sensitivity to side wind is
increased. Drive smoothly and at a
moderate speed.

Lighting

Manual adjustment

Adjust your headlamps so as not to
dazzle other road users (see section
on ''Manual adjustment of head­lamps''). Check the electrical sig­nalling of the trailer.

Automatic beam correction

For vehicles with Xenon bulbs, this
system automatically corrects the
height of the beam, whatever the
load of the vehicle. The driver is then
assured of having optimum lighting
and not causing a nuisance to other
road users.

PRACTICAL INFORMATION

157

12-05-2003

PRACTICAL INFORMATION

158

USING ROOF BARS

To use the transverse roof bars, release the four locking levers provided for this
purpose.

From the left-hand side, slide them in their rails to the required notch.
Lock the four locking levers located at the base of the feet of each bar.
Note: when the roof bars are not in use, position them at the rear stop to avoid

excess consumption.
Use accessories approved by Automobiles PEUGEOT and follow the manufac-

turer's fitting instructions.

Maximum authorised weight on the roof rack 220 lbs. (100 kg)

Removal and refitting
of the roof bars

– Remove the bolt, the stop and the

two washers at each location A.
– Move the bars to the locations A.
– Lift the two bars to remove them.
– Imperative: refit the bolt, the stop

and the two washers at each loca-

tion A.
To refit, proceed in the reverse order.

Direction of use:

12-05-2003

REAR VIDEO KIT

This video assembly will enable the
rear passengers to pass the time
pleasantly while watching their
favourite film or playing their
favourite game, by means, in partic­ular, of the connection of a DVD
player or games console.

The rear video kit consists of:
– a 4/3, 6.8 inch, LCD colour monitor,
– two high frequency, wireless,

stereo headphones,
– a remote control,
– a base with two wired headphone

outputs, a courtesy light with its

switch and a monitor release button,
– three audio/video sockets in the

glove compartment.

The monitor's remote control incor­porates the following controls:

1. "POWER" button to switch the
monitor on/off.

2. "SOURCE" button for selection of
the input source, AV1 or AV2.

3. "SETUP" button for selection of
the settings.

4. "VOL ▼" and "VOL ▲" buttons to
change the settings or
increase/decrease the volume at
the wired headphones.

5. Housing for the two LR03 batteries.

6. "MUTE" button to cut off/restore

the volume at the wired head­phones.

7. "DOMELIGHT" button to switch
the courtesy light on/off remotely.

PRACTICAL INFORMATION

159

The monitor has left/right and
up/down position adjustment. It can
also be stored in its base by folding it
and pushing it to lock it. Once stored,
the supply, and that of the wireless
headphones, is cut off automatically
after approximately fifteen minutes.

The rear video kit accepts all types of
audio/video source, PAL/NTSC com­patible, such as: DVD player, cam­corder, games console, ...

These sources are connected to the
three audio/video sockets, AV1, in
the glove compartment only as the
AV2 sockets are not available.

12-05-2003

PRACTICAL INFORMATION

160

The various controls are incorporat­ed in the wireless headphones:

A-Housing for the two LR03 batteries.
B - Headphones on/off button.
C - Headphones volume adjustment

control. To get the best out of the
headphones, you must adjust
them to your own size and adjust
the volume by rotating control C.

This video assembly is
intended to be operated
and used by the rear pas­sengers only.

Note: the courtesy light can be con­trolled directly by means of its switch
in the on or off position or remotely
by means of the remote control in the
intermediate position.

By pressing buttons 4 and 5, you can
adjust the brightness, the contrast,
the colours, ...

For further details, refer to the oper­ating manual "ALPINE video kit".

12-05-2003

PRACTICAL INFORMATION

161

ACCESSORIES FOR YOUR 807

For your PEUGEOT only use accessories and original parts approved by the manufacturer.
These accessories and parts are all adapted to your PEUGEOT, after being tested and approved for reliability and safety,

which PEUGEOT cannot guarantee for other products.
A wide choice of original accessories, approved by PEUGEOT, is available through the dealer network. They all carry the

PEUGEOT guarantee.

– Safety : Anti-theft alarm, window engraving, wheel locks, first aid kit...

– Comfort : Arm rest, covers compatible with side air bags, mats, boot tray, sunroof, luggage net, door

deflectors, cool box secured on the slides...

– Communication : Audio systems, telephone, hands-free kit, speakers, amplifier, CD changer, navigation

systems, rear video kit, DVD player...

– Customising : Alloy wheels, trims, aluminium or PVC door sills, aluminium interior trim kit, mud flaps...

– Leisure : Tow bar, roof bars, roof box, snow chains, ski carrier, tailgate bicycle carrier, interior bicycle

carrier...

– Children : Booster seats and child seats, Isofix KIDDY seat, side sun blinds and rear blind...

– Maintenance products : Screenwash, interior and exterior maintenance and cleaning products...

Before installing any electrical accessory on your vehicle, contact a PEUGEOT dealer.

12-05-2003

2 litre 16V Manual 22.9 (12.3) 38.7 (7.3) 31.0 (9.1) 218

2 litre 16V Automatic 20.6 (13.7) 38.7 (7.3) 29.4 (9.6) 230

2.2 litre 16V Manual 22.4 (12.9) 36.2 (7.8) 29.1 (9.7) 231

2 litre 16V turbo

diesel HDI Manual 30.7 (9.2) 47.9 (5.9) 40.4 (7.0) 186

2 litre turbo

diesel HDI Manual 30.1 (9.4) 47.9 (5.9) 39.2 (7.2) 189

16V PEF

2 litre turbo

diesel HDI Automatic – – – –

16V PEF

2.2 litreturbo

diesel HDI Manual 27.9 (10.1) 47.9 (5.9) 38.2 (7.4) 199

16V PEF

TECHNICAL DATA

164

Fuel consumption values correct at time of printing.

Consumption As per directive 99/100

Engine Gearbox Model Urban Extra-urban Mixed Emission

codes driving driving driving by mass

(MPG [litres/100 km]) (MPG [litres/100 km]) (MPG [litres/100 km]) of CO2(g/km)

EBRFNC/IF
EARFNC/IF

EB3FZC/IF
EA3FZC/IF

EBRHWB
EARHWB

EBRHTB
EARHTB

EBRHTE
EARHTE

EB4HWB
EA4HWB

EBRFNF/IF
EARFNF/IF

12-05-2003

TECHNICAL DATA

167

DIMENSIONS (in mm)

12-05-2003

TECHNICAL DATA

168

IDENTIFICATION FEATURES OF YOUR 807

A. Manufacturer's plate.
B. Model serial number.
C. Tyres and paint colour reference.

The label C on the driver's door gives:
– the wheel and tyre sizes,
– the brands of tyres approved by the manufacturer,
– the tyre pressures (the tyre pressure must be checked when the tyre is cold, at least once a month),
– the paint colour reference.

12-05-2003

PEUGEOT SERVICING

Your vehicle's servicing schedule is based on level A services (engine oil change, checks and top-ups) and level C services
(level A + workshop operations carried out every 36,000/40,000 miles (60 000 km)) in accordance with the tables on the fol­lowing pages.

Irrespective of the conditions in which your vehicle is used, the interval between two level A services may not exceed:

• For petrol engines, 20,000 miles (30 000 km) or 2 years.

• For HDI turbo diesel engines, 12,000 miles (20 000 km) or 2 years.

The extension of the service intervals means that the engine oil must be checked regularly: topping up of the oil
between two oil changes is normal.

It is for this reason that your PEUGEOT dealer invites you to an intermediate visit between each service. The date
of the intermediate visit is not shown by the service indicator.

It is to be carried out between two services.
A PEUGEOT professional will carry out a quick check, and will top up the levels if necessary (oil, coolant, screenwash up to

2 litres).

If the oil level is too low there is a risk of serious damage to the engine: check the engine oil level at least every
3,000 miles (5 000 km).

This extended servicing has been made possible by modifications to our vehicles and to the lubricants:
THUS IT IS ESSENTIAL TO ONLY USE ENGINE LUBRICANTS THAT ARE SUITED TO YOUR ENGINE AND RECOM-

MENDED BY THE MANUFACTURER (see "Lubricants" pages).

Arduous conditions of use
This applies if the vehicle is used in certain particularly arduous conditions such as continuous door-to-door use, town

use (e.g. taxi), repeated short journeys, with the engine cold in low temperatures or for long stays in hot countries
with temperatures often above 30 °C, cold countries with temperatures often below minus 15 °C, countries with a dusty
atmosphere, and countries whose lubricants or fuels do not conform to our recommendations.

It is then necessary to follow an "Arduous conditions" servicing schedule, which includes special operations and shorter ser­vice intervals:

• Every 12,000 miles (20 000 km) or every year for petrol vehicles.

• Every 10,000 miles (15 000 km) or every year for HDI Turbo Diesel engine vehicles.

PEUGEOT SERVICING

18

12-05-2003

PEUGEOT SERVICING

19

Leve

l

Operations Description of operation

1st service

A C Intermediate

-

Oil filter



-

Fuel filter* (petrol)



-

Fuel filter element (diesel)



-

Air filter element



-

Spark plugs (petrol)



-

Engine oil 

-

Bleed fuel filter (diesel)



-

Engine oil (check + top-up)



-

Manual gearbox oil (check + top-up)



-

Battery (check + top-up) if cap is removable



-

Screen wash front/rear (check + top-up)



-

Coolant (check + top-up) 

-

Brake fluid (check + top-up)



-

Power steering fluid (check + top up according to specification

)



-

Operation of lights and indicators



-

Condition of glass, headlamp and light lenses and mirrors



-

Horn



-

Windscreen washer jets 

-

Condition of wiper blades



-

Condition and tension of the ancillary drive belts 

-

Handbrake



-

Condition of hydraulic circuits (hoses and covers) 

-

Condition of rubber boots and gaiters 

-

Brake pads  o

-

Play in hubs, link rods, ball joints, flexible mountings 

-

Shock absorbers



-

Rear drum brake lining wear 

-

Condition and pressure of tyres (including spare wheel) 

-

Emission control check as per current legislation (petrol) 

-

Smoke opacity (diesel) 

- Passenger compartment filter (according to specification)  o

- Visual check of the whole vehicle



-

Courtesy vehicle





: All driving conditions o: Arduous conditions * According to destination

DRAIN/REFILL

REPLACE

LEVEL

SERVICE*

ROAD TEST

CHECK

A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT

12-05-2003

PEUGEOT SERVICING

20

THE SERVICE LEVELS

Each vehicle has its own servicing cycle, defined by the manufacturer in terms of its engine type.

This cycle consists of alternating 2 types of service, A and C, intermediate visits and a few additional operations specific to
your vehicle; these correspond to key stages in the life of your 807.

At the first and each subsequent service, your dealer will advise you of the type and content of the next service due.

MAINTENANCE CYCLE FOR YOUR PETROL ENGINE 807

2 litre and 2.2 litre petrol engines: service every 2 years or 20 000 miles (30 000 km) maximum

1st service at 6,000 miles (10 000 km) or 6 months*.

This is necessary in order to benefit

from the warranty.

MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)

These services are to be carried out with a minimum of synthetically based oil, but they may also be carried out with syn-
thetic based oil or fuel economy oil (except 2.2 litre petrol engine).

Arduous conditions of use (see corresponding section).

80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)

Intermediate top-up visit included in
the fixed interval services.

* Whichever comes first.

12-05-2003

PEUGEOT SERVICING

21

Intermediate top-up visit included in
the fixed interval services.

MAINTENANCE CYCLE FOR YOUR 807 TURBO DIESEL HDI

2 litre HDI and 2.2 litre HDI turbo diesel engines: service every 2 years or 12,000 miles (20 000km) maximum

These services are to be carried out with synthetically based oil. Fuel Economy oil or synthetic oil may also be used.
Warning: use only 5W40 oil for the 2.2 litre HDI engine.

Arduous conditions of use (see corresponding section).

* Whichever comes first.

1st service at 6,000 miles

(10 000 km) 6 months*.

This is necessary in order

to benefit from the warranty.

MILES (KM) 12,000 (20 000) 24,000 (40 000) 36,000 (60 000) 48,000 (80 000) 60,000 (100 000)

72,000 (120 000) 84,000 (140 000) 96,000 (160 000) 108,000 (180 000) 120,000 (200 000) 132,000 (220 000) 144,000 (240 000)

+ maintenance of the

particulate emission filter

+ maintenance of

particulate emission filter

12-05-2003

PEUGEOT SERVICING

23

Zero re-set

Your PEUGEOT dealer carries out
this operation after each service.

However, if you carry out the service
yourself, the re-set procedure is as
follows:

☞ Switch off the ignition,
☞ Press and hold the trip recorder

re-set button,

☞ Switch on the ignition.
The display begins a countdown.
When the display shows "= 0",

release the button; the spanner dis­appears.

Important: after this operation, if you
wish to disconnect the battery, lock
the vehicle and wait for at least five
minutes, otherwise the zero re-set
will not be registered.

MAINTENANCE OF PARTS SUBJECT TO WEAR
AND A CHECK OF CONSUMABLES

Certain essential components on your vehicle are subject to checks at specific
frequencies.

• The brake fluid is to be replaced at a maximum of every 36,000/40,000 miles
(60 000 km) or every two years;

• The passenger compartment filter must be checked at each service by a
PEUGEOT dealer (services and intermediate visits) or more often, depending
on the environment (dust, pollution, etc.);

• For HDI turbo diesel engines with particulate emission filter, maintenance
of the filter and topping up of the additive reservoir must be carried out at a
maximum of every 72,000 miles (120 000 km) by a PEUGEOT dealer;

• Replacement of the timing belt: contact a PEUGEOT dealer.

• Air bags and pretensioning parts on seat belts must be checked every
10 years.

• Tyre pressure sensors are to be replaced every 10 years.

• The check on tyre inflation presure must be carried out cold at least once a

month.

Note: the engine coolant does not need to be changed.

12-05-2003

DIESELDIESELPETROL PETROL

24

(1) Minimum quality standard: Petrol engines ACEA A3 and API SH/SJ; Diesel engines: ACEA B3 and API CF/CD

ACEA = Association des Constructeurs Européens Automobiles (Association of European Automobile

Manufacturers) - API = American Petroleum Institute.

If oil is used which does not conform to the ACEAA3-B3 standards, this requires the "Arduous Conditions"

servicing schedule to be followed, which involves shorter intervals between services.

Use only 5W40 synthetic oil for the HDI Turbo Diesel engines with particulate emissions filter.

*Fuel Economy Oil cannot be used for the 2.2 litre 16V petrol engine and the HDI Turbo Diesel engines

with particulate emissions filter.

TRADE NAMES OF RECOMMENDED LUBRICANTS IN EUROPE(*)

12-05-2003

Recommendations
for approved lubricants

The oils which appear in the table
opposite are suitable for most pur­poses.

The diagram opposite states the
optimum range of viscosity depend­ing on the temperatures at which the
oils are to be used.

It is also possible to use synthetic
oils of 'superior quality'.

In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJ
quality (for petrol engines), or
CD/CF quality (for diesel engines)
may be used by following the 'Ardu­ous Conditions' servicing schedule,
which specifies shorter service
intervals.

Do not hesitate to ask for advice
from a PEUGEOT dealer to maintain
driving pleasure and to minimise the
maintenance cost of your vehicle.

For countries outside Europe, please
contact a local PEUGEOT dealer.

PEUGEOT SERVICING

25

Manual ONLY ONLY
Gearbox ESSO GEAR OIL BV

TOTAL TRANSMISSION BV

75W-80 PR 9736.41 75W-80

Automatic ONLY
Gearbox ATF 4HP20-AL4

PR 9736.22

Power steering ESSO ATF D TOTAL FLUIDE AT42

PR 9730.94

Other recommended products

Power steering FLUIDE DA PR 9730.A1*
Brake circuit PEUGEOT DOT4
Cooling

PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000

circuit ONLY Protection to minus 35 degrees Celsius

* Only for extremely cold countries.

12-05-2003

26

PETROL/DIESEL CONTROL MODULE

1 - Dipped beam headlamps

indicator light.

2 - Main beam headlamps indicator

light.

3 - Left-hand direction indicator.
4 - Service indicator, oil level

indicator, automatic gearbox
indicator* and total distance
recorder.

5 - Front fog lamps indicator light.

6 - Right-hand direction

indicator.

7 - Dynamic stability control

ASR/ESP indicator light.

8 - Rear fog lamps indicator light.
9 - ABS system warning light.
10 -Engine diagnostics warning

light.

11 - Cruise control indicator light.

12 -Lighting rheostat.

13 -Handbrake, brake fluid level

and electronic brake force
distribution warning light.

14 -Engine oil pressure warning

light.

15 -Central (STOP) warning light.

16 -Battery charge warning light.

17 -Diesel engine preheating

indicator light.

18 -Trip recorder zero reset.

19 -Driver's seat belt warning light.

20 -Passenger air bag disarming

indicator light.

21 -Front, side and curtain air bags

warning light.

* According to specification.

INSTRUMENTS AND CONTROLS

12-05-2003

1 - Rev counter.
2 - Speedometer.
3 - Fuel gauge.
4 - Coolant temperature indicator.
5 - Maximum coolant temperature

warning.

6 - Low fuel level warning light.
7 - Monochrome or colour screen.

INSTRUMENTS AND CONTROLS

27

Instrument panel with colour screen

PETROL-DIESEL INSTRUMENT PANELS

Instrument panel with monochrome screen

12-05-2003

Maximum

Minimum

Check the level with
the dipstick and top it
up.

The figure shown is
only correct if the vehicle has been
on, level ground, with the engine
stopped, for 10 minutes.

No oil
The message "Top

up the oil" appears

on the multi-function

display, accompanied
by an audible signal.
It is essential to top up the oil to the
correct level, otherwise the engine
will be damaged.

Oil gauge fault

Flashing of the seg-

ments indicates a

fault.

Check the level using

the dipstick.
Consult a PEUGEOT dealer.

Control module display

After switching on the ignition, three
functions are shown in succession:

– service indicator (see correspond-

ing section),
– engine oil level indicator,
– total distance recorder (total and

trip distances).
Note: the total and trip distances are

displayed for thirty seconds, when
the ignition is switched off, on open­ing the driver's door as well as on
locking and unlocking the vehicle.

It also displays the automatic gearbox
positions and programmes selected
(see corresponding section).

Engine oil level

When the ignition is switched on, the
engine oil level is indicated for
approximately 10 seconds, after the
service information.

Note: never exceed the maximum
level as a surplus of oil may cause
damage to the engine.

Contact a PEUGEOT dealer without
delay.

Lighting rheostat

With the lights on,
press the button to
vary the intensity of
the lighting of the
instruments and con­trols. When the light-

ing reaches the mini­mum (or maximum) setting, release
the button then press it again to
increase (or reduce) the brightness.

As soon as the lighting is of the
required brightness, release the button.

Trip recorder zero

reset

With the ignition on,

press the button.

INSTRUMENTS AND CONTROLS

34

12-05-2003

THE KEYS

The keys allow you to switch on
the ignition and to independently
operate the front doors, the fuel
filler cap, the glove box, the pas­senger air bag disarming switch
and the mechanical child lock.

Central locking

From the driver's or passenger
door, the keys allow you to lock,
deadlock or unlock the doors and
the tailgate and to fold back the
exterior mirrors.

If one of the doors or the boot is
open, it is impossible to operate
the central locking.

The remote control performs
the same functions at a dis­tance.

The remote control key

Locking

Press button A to lock the vehi­cle.

Button A also locates the vehicle
and reinitialises the remote con­trol.

Deadlocking

Press button A to lock the vehicle
and close the windows automati­cally.

Asecondpress on button Ain the
five seconds following locking,
changes locking to deadlocking.

Deadlocking renders the
internal and external
door locking controls
inoperative.

Do not leave anyone inside the
vehicle when it is deadlocked.

Unlocking/Ventilation

Press button Bto unlock the vehi­cle.

A second press on button B in
the five seconds following unlock­ing opens the windows.

Opening/Closing the electric
sliding side doors

Pressing button C or D unlocks
the vehicle, then permits opening
or closing of the corresponding
rear door.

Folding/Unfolding the key

Press button E to unfold or fold
the key in its case.

STARTING

1 - STOP position:

the ignition is off.

2 - 1st notch, Accessories

position:

the ignition is off but the
accessories can be used.

3 - 2nd notch, Running

position:

the ignition is on.

4 - Starting position:

operates the starter.

4

105

YOUR 807 AT A GLANCE

12-05-2003

ELECTRIC WINDOWS

1 - Driver's electric window
2 - Passenger's electric window.
3 - Rear right electric window.
4 - Rear left electric window.
5 - Disarming the rear window switches.

☞ Press or pull the switch lightly. The window stops as soon as the

switch is released.

Automatic mode:

☞ Press or pull the switch firmly. One touch completely opens or

closes the window. Pressing the switch again stops the win­dow.

Safety auto-reverse: When the window is closing and meets an
obstacle, it stops and lowers again.

ELECTRIC MIRRORS

Adjustment

☞ Slide button 6 to the right or left to select the corresponding mirror.
☞ Press the arrows on button 7 in all four directions to adjust.
☞ Slide button 6 back to the centre position.

Folding

When parking the vehicle, the mirrors can be folded back manu­ally or electrically by pulling button 6rearwards or automatically on
locking the vehicle.

121

YOUR 807 AT A GLANCE

5

STEERING WHEEL
ADJUSTMENT

☞ When stationary, lower control

A to unlock the steering wheel.

☞ Adjust the height and depth of

the steering wheel.

☞ Lock it by raising control A

fully.

CHILD MONITORING
MIRROR

Mounted on a ball joint and
retracting into its housing, it
enables the driver or front pas­senger to see all of the rear
seats.

122

12-05-2003

SEATS

Manual front seats
1 - Forwards-backwards adjustment.
2 - Seat back angle adjustment.
3 - Driver's seat height adjustment.
4 - Driver's seat lumbar adjustment.
5 - Head restraint height and angle adjustment.
6 - Seat rotation.
7 - Heated seat.

89

YOUR 807 AT A GLANCE

6

Electric front seats
A- Forwards-backwards adjust-

ment.

B - Driver's seat height adjust-

ment.

C - Seat back angle adjustment.
M - Storing of settings.

☞ Switch on the ignition, adjust

the seat and the mirrors.

☞ Press button "M" then "1" or

"2" within 4 seconds.
1 - Recall of the first position.
2 - Recall of the second posi-

tion.

90

12-05-2003

YOUR 807 AT A GLANCE

7

93

REAR SEATS

Side seat controls:

– Forwards-backwards adjust-

ment (1),

– Seat back angle adjustment,

folding, placing in the table
position, access to the 3rd row
(2),

– Folding, exit from the 3rd row

(3),

– Head restraint height adjust-

ment (4).

Centre seat controls:

– Forwards-backwards adjust-

ment (1),

– Seat back angle adjustment

(2),

– Placing in the table position

(3),
– Folding (4),
– Head restraint height adjust-

ment (5).

Bench seat controls:

– Forwards-backwards control

(1),
– Placing in the table position (2),
– Folding (3),
– Head restraint height adjust-

ment (4).

12-05-2003

YOUR 807 IN DETAIL

73

CD CHANGER

This is located on the floor between the two front seats and can hold up to 6
discs.

To insert a disc into the changer:
– open sliding panel A,
– press button B to eject the cartridge C,
– open one of the six compartments of the cartridge by pulling tab D,
– insert the disc with the printed face upwards and close the compartment,
– insert the cartridge into the changer,
– close the sliding panel A.

The use of copied compact discs can cause malfunctions.
Insert circular compact discs only.

12-05-2003

YOUR 807 AT A GLANCE

8

103

6 seats "Pullman" 5 seats with "picnic" position

7 seats with access to the 3rd row "Cargo" configuration

5 seats 8 seats with bench seat

SEAT MODULARITY AND CONFIGURATIONS

YOUR 807 IN DETAIL

84

12-05-2003

12-05-2003

YOUR 807 IN DETAIL

85

VENTILATION

1 - Windscreen de-icing or demisting vents
2 - Front window de-icing or demisting vents
3 - Side vents
4 - Centre vents
5 - Air outlets to the front footwells
6 - Air outlets to the 2nd row rear footwells
7 - Side vents for the 2nd row rear footwells
8 - Air outlets to the 3rd row rear footwells
9 - Side vents for the 3rd row rear footwells

Note: The 2nd row side vents are fitted with knobs for adjustment of the air flow to the rear seats. Additional blowers

provide improved diffusion of the air to the 2nd and 3rd row passengers.

Recommendations for use

For an even air distribution, make sure that you do not block the air inlet grille at the base of the windscreen, the air outlets
on the floor and the air extractor at the tailgate pillars.

12-05-2003

The driver and front passenger can
each adjust the air temperature to
suit their requirements.

They can also activate or disarm the
rear ventilation adjustment controls.

Do not cover the passenger com­partment temperature sensor,
located on the right upright of the
centre console. It helps to regu­late the air conditioning.

1 - Air conditioning on/off

☞

Pressing this button acti­vates the automatic opera­tion of the air conditioning.

The symbol and the indicator light 1
are displayed.

☞ Pressing this button again swit-

ches the air conditioning off.

The symbol and the indicator light 1
go out.

2 - Passenger's

side adjustment

3 - Driver's

side adjustment

The required value is displayed (from
14 to 28; comfort value = 21; maxi­mum driver/passenger difference = 5).

☞ Press the corresponding "+" and

"–" buttons to change it.

YOUR 807 IN DETAIL

86

AUTOMATIC AIR CONDITIONING WITH SEPARA TE ADJUSTMENTS

Located on the centre console, the control panel is to the right of the gear lever.

12-05-2003

To make the setting on the passen­ger side the same as that on the
driver's side:

– air conditioning with "MONO" but-

ton, press button A.

– air conditioning with "REAR" but-

ton, press button 2 or 3 for more
the two seconds.

4 - Adjustment

of the air distribution

☞ Pressing the corresponding

button(s) 4 directs the flow
of air to:

– the windscreen,
– the side vents and the central

vents,

– the side vents, the central vents

and the feet,
– the windscreen and the feet,
– the feet.
The indicator light corresponding to

the required direction 4 comes on.

5 - Adjustment of the rear

ventilation

T o enable the rear passengers to adjust
the rear ventilation, press button B.

YOUR 807 IN DETAIL

87

8 - Demisting the rear

screen

☞ Press button 8, with the engine

running, to demist the rear screen
and the mirrors.

The demisting indicator light 8
comes on.

It switches off automatically after
approximately twelve minutes.

☞ Pressing the button again switches

it on again. If the engine is
switched off before the twelve
minutes have elapsed, demisting
will resume when the engine is
switched on again.

Note: it is possible to switch off the
demisting before it is switched off
automatically by pressing this button
again.

9 - Comfort programme

This is the normal air condi­tioning system operating

mode.
☞ Press the "AUTO" button.
The system adjusts automatically to

the required value by switching on
the air conditioning.

It also controls the air distribution,
flow and intake so that there is suffi­cient air circulation in the passenger
compartment.

The "AUTO" symbol is displayed.

The rear ventilation symbol 5 is dis­played.

The air flow adjustment controls
5 for the 2nd row side vents are
operational.

To disarm the rear ventilation controls,
press button B again.

The rear ventilation symbol 5 goes
out.

6 - Adjustment

of the air flow

☞ Turn the adjument con-

trol 6 respectively to the
right or to the left to
increase or reduce the
flow of air.

The air flow symbol 6 is filled in
according to the required value.

7 - Air recirculation

☞ Press this button to recir-

culate the interior air.

The air recirculation symbol and indi­cator light 7 are displayed.

The recirculation isolates the pas­senger compartment from outside
smells and smoke.

Avoid prolonged operation in interior
air recirculation mode (risk of con­densation and deterioration of the air
quality).

☞ Pressing this button again returns

the system to automatic control of
the air intake.

12-05-2003

Important precaution

Operate the air conditioning system
for 5 to 10 minutes, once or twice a
month, to keep it in perfect working
order.

If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.

Note: the condensation created by
the air conditioning system causes
a flow of water under the vehicle
when stationary, which is perfectly
normal.

10 - Visibility programme

The comfort programme
may prove inadequate to

demist or de-ice the win­dows quickly (humidity, many pas­sengers, ice).

☞ In this situation, select the visibility

programme.

The visibility programme indicator
light 10 comes on.

It manages the air conditioning, air
flow, the rear screen demisting and
distributes the ventilation to the wind­screen and side windows as effec­tively as possible.

It switches off the air recirculation.
Note: for your comfort, between two

starting operations the settings are
retained if the temperature of the
passenger compartment has not va­ried a great deal. If it has, operation
will resume in automatic mode.

11 - Switching the system off

☞ Turn the air flow adjustment con-

trol 6 to the left until the display is
switched off.

This action switches off all of the sys­tem's functions, with the exception of
the rear screen demisting.

☞ Turning the control 6 again, or

pressing button 10 or the "AUTO"
button again, switches the system
on again with the same settings
as before.

Flashing of the points in
the temperature setting
values indicates that
there is a malfunction of

the air conditioning.
Contact your PEUGEOT dealer.

YOUR 807 IN DETAIL

88

12-05-2003

YOUR 807 AT A GLANCE

9

AUTOMATIC AIR
CONDITIONING WITH
SEPARATE SETTINGS

N° Function

1 Air conditioning

on/off.

2 Passenger side

adjustment.

3 Driver's side adjustment.
4 Air distribution

adjustment.

5 Rear ventilation

adjustment.

6 Air flow adjustment.
7 Air recirculation.
8 Rear screen and

mirrors demisting.

9 Comfort programme.

10 Visibility programme.

A Equalisation of settings

2 and 3.

B Activation/deactivation

of setting 5.

86

12-05-2003

YOUR 807 IN DETAIL

93

THE REAR SEATS

Forwards/backwards adjustment

Lift bar A and slide the seat towards
the front or the rear.

From the third row you can pull on
strap B and slide the seat towards
the front.

This makes it easier for passengers
to exit the 3rd row of seats, when
folding down the second row seat.

Adjusting the angle
of the seat back

Push lever C upwards and adjust the
angle as required.

Release the lever to lock.

Folding a side seat

Access to the third row:

Place the head restraint in the low
position.

Push control C upwards as far as
possible.

Tilt the seat back towards the front until
the rear anchorages are unlocked.

Fold the seat back onto the seat
cushion.

Place the seat in the closed position.

Exiting the third row:

Place the head restraint in the low
position.

Push control D upwards as far as
possible.

Tilt the seat back towards the front until
the rear anchorages are unlocked.

Fold the seat back onto the seat
cushion.

Place the seat in the closed position.

Table position of a side seat

Fold the corresponding seat.
Tilt the folded seat rearwards, until

the rear anchorages lock.
You now have a shelf with two cup

holders.

Folding a side seat from the table
position

Lift the seat back.
Fold as described opposite.

12-05-2003

Removing a seat

Fold the corresponding seat.
Grasp the two bars G under the seat

and tighten them securely.
The front anchorages unlock.
Lift the seat and carry it using the

carrying handle H.

Refitting a seat
Check that there is no obstacle

obstructing the slides or preventing
correct locking of the seat.

Locate the front anchorages in the
slides (if necessary tighten the two
bars G securely).

Tilt the folded seat towards the rear.
The rear anchorages lock.
Lift the seat back (for the centre seat,

move control E).

Turning a seat round

The rear seats can be placed in the
'rearwards facing' position.

For this, after the seat has been fol­ded, carry out the removal and
replacing operations for the seat and
turn it round.

YOUR 807 IN DETAIL

94

Table position of the centre seat

Place the head restraint in the low
position.

Push control E upwards.
Tilt the seat back forwards.
You now have a table with two cup

holders.

Folding the centre seat

Place the seat in the table position.
Lift control F.
Place the seat in the closed position.

This turning operation
must be carried out with
the engine switched off.

It is prohibited to sit facing
the rear when the vehicle is being
driven.

Never use the adjusting straps to
remove, refit or transport a seat.

When the vehicle is being driven,
it is prohibited to place a side seat
in the closed position, when a
passenger is sitting in the 3rd row.

12-05-2003

THE REAR SEAT

Forwards/backwards adjustment

Lift bar A and slide the seat towards
the front or the rear.

Note: to make it easier to load the
vehicle through the tailgate, you can
pull on strap B and slide the seat for­wards.

Rear parcel shelf position

Place the head restraints in the low
position.

Push control C upwards, from the
tailgate.

Tilt the seat back on the seat
cushion.

Folding the seat

Place the head restraints in the low
position.

Push control C upwards, from the
tailgate.

Fold the seat back onto the seat
cushion.

Pull on strap D to unlock the rear
anchorages.

Place the seat in the closed position.

When driving, attach the retaining
straps to the handles.

Removing the seat

Fold down the seat.
Grasp the two bars E underneath the

seat.
The front anchorages unlock.

Note: for removal and refitting, pass
the rear seat, in the "folded" position,
through the sliding side doors.

Refitting the seat
Check that there is nothing

blocking the runners which could
prevent correct locking of the seat
anchorages.

Position the front anchorages at the
front stop of the runners.

Tilt the folded seat rearwards.
The rear anchorages then lock.
Unlock the seat back using control C

and pull it up using the strap.

YOUR 807 IN DETAIL

95

Never use the adjustment
straps to remove, refit or
transport the seat.

12-05-2003

YOUR 807 IN DETAIL

96

REAR HEAD RESTRAINTS

The rear head restraints can be
removed and have two positions:

– high, position for use.
– low, storage position.

To raise or lower a head restraint,
pull it forwards sliding it at the same
time.

To remove it, place it in the high posi­tion, push the lug and pull it forwards
and upwards.

To refit it, engage the head restraint
rods in the holes taking care to
remain in the centreline of the seat
back.

Never drive with the head
restraints removed, they
must be in place and cor­rectly adjusted.

12-05-2003

YOUR 807 IN DETAIL

97

Rules for transporting children
on the front passenger seat**

Children under the age of 10 must
not travel in the forwards facing
position, unless the rear seats are
already occupied by other children
or the rear seats cannot be used
(absent or folded). In this case,
adjust the front passenger seat to
the most rearward position and arm
the passenger air bag.

The rearwards facing position is per­mitted from birth to 13 kg or 18 kg. In
this position, it is essential to disarm
the passenger air bag.

GENERAL POINTS RELATING TO CHILD SEATS

Although one of PEUGEOT's main criteria when designing your vehicle, the safe­ty of your children also depends on you.

For maximum safety, please follow these precautions:

– Since 1992, all children under the age of 10 must travel in approved child

seats* suited to their weight, on seats fitted with a seat belt.
In order to recognise a child seat which conforms to current legislation, check

that it bears an orange label indicating the weight range for its use and
its approval number.

– A child weighing less than 9 kg must travel in the rearwards facing

position both in the front and in the rear. PEUGEOT recommends that
children should travel in the "rearwards facing" position up to the age of
two.

– Statistically, the safest seats in your vehicle for the transportation of

children are the rear seats.

– If a child is travelling on a booster seat, check that the lap section of the seat

belt passes over the child's thighs correctly. The chest section of the seat belt
must be positioned on the child's shoulder without touching the neck.
PEUGEOT recommends that you use a booster seat with a back, fitted with a
seat belt guide.

– Remember to fasten the seat belt or the child seat harness keeping the slack

in relation to the child's body to a minimum, even for short journeys.

* According to current legislation in the country.
**Consult the relevant administration in your country for information regarding

the rules for transporting children on the front passenger seat.

12-05-2003

YOUR 807 IN DETAIL

98

"ISOFIX" MOUNTINGS

The two rear side seats of your
vehicle are fitted with ISOFIX
mountings. These are two rings
located between the seat back and
the seat cushion.

The ISOFIX child seats are fitted
with two locks which are secured
easily on these rings. All this
guarantees reliable, safe and fast
fitting.

The ISOFIX child seat approved for
PEUGEOT vehicles and sold by
PEUGEOT dealers is the ISOFIX
KIDDY* child seat. It can be fitted in
the "rear-facing" position from birth
to 13 kg and in the "forwards-facing"
position from 9 kg to 18 kg.

In the front, in the "rear facing" posi­tion, the front passenger seat must
be moved as far forward as possible
so that the body of the child seat is in
contact with or as close as possible
to the fascia.

In the rear, in the "forwards facing"
position, it is imperative that the front
passenger seat is in the mid-way
position on the runner, seat back
upright.

The ISOFIX KIDDY child seat must
not be installed on the 3rd row
rear side seats.

This seat can also be used on seats
not fitted with ISOFIX mountings. In
this case, it is compulsory to secure
it to the vehicle's seat using the
three-point seat belt for both the
"rear facing" and "forwards facing"
positions.

When the ISOFIX KIDDYseat is fit­ted in the "rear facing" position on
the front passenger seat, it is
imperative that the passenger air
bag is disarmed.

Follow the instructions for fitting
the child seat given in the seat
manufacturer's instruction booklet.

Refer to the "Summary table for
fitting child seats".

* You can only fit ISOFIX child seats

approved by PEUGEOT and sold
by PEUGEOT dealers on your
vehicle's ISOFIX mountings.

12-05-2003

YOUR 807 IN DETAIL

99

CHILD SEATS RECOMMENDED BY PEUGEOT

In addition to the ISOFIX child seats, PEUGEOT offers a complete range of child seats which are secured using the seat
belt:

Group 0+: from birth to 13 kg

L1 – "Britax Babysure": installed in the rear-facing position in the front or in the rear using a three-point seat belt.

In the front, it is compulsory to disarm the passenger air bag and the passenger seat must be adjusted to the 'mid-way'
position on the runner.

Group 1: from 9 to 18 kg

L2 – "Römer Prince": installed in the rear using a two or three-point seat belt.

For the safety of your child, the seat and the restraining cushion must never be separated.

Group 2: from 15 to 25 kg

L3 – "Römer Vario'': installed in the rear with a two or three-point seat belt.

12-05-2003

YOUR 807 IN DETAIL

100

Never leave one or
more children alone
and unsupervised in a
vehicle.

Never leave a child or an animal in
a vehicle which is exposed to the
sun and has the windows closed.

To protect your young children
from the sun, fit blinds on the rear
windows.

Never leave the keys within reach
of children inside the car.

Disarm the passenger air bag
when installing a "rearwards fac­ing" child seat on the front passen­ger seat. Otherwise, the child
would risk being killed or seriously
injured were the air bag to inflate.

Observe strictly the recommenda­tions for assembling and securing
the child seat as shown in the
child seat instructions.

T o prevent the doors from opening
accidentally, use the child lock*.

Also, do not open the rear win­dows more than a third*.

Groups 2 and 3: from 15 to 36 kg

L4 – ''Recaro Start'': installed in the rear with a three-point seat belt.

The height and width of the seat back and length of the seat cushion must
be adjusted according to the age and build of your child.

L5 – "Klippan Optima": installed in the rear with a three-point seat belt.

From the age of 6 years (approximately 22 kg), the booster is used on its
own.

Refer to the "Summary table for the installation of child seats".

* According to model.
