smc PENTAX-FA INTERCHANGEABLE LENS
OPERATING MANUAL
Congratulations on your purchase of smc PENTAX lens. This operating manual applies to all of the smc PENTAX FA, FAJ and F lenses.
In this manual, smc PENTAX FA lens is referred to as FA lens.
Please also read your camera's operating manual.
Illustrations shown herein may differ from the actual appearance.
8
15
3
10
50
1.4
.8
2
4
5.6
8
11
16
22
A
CONTENTS
°
FOR SAFE USE YOUR LENS……………1
°
PRECAUTION AND LENS MAINTENANCE ……………………………2
°
smc PENTAX F, FA and FAJ LENSES …3
Mount compatibility
°
MOUNTING AND REMOVING OF LENS ………………………………………5
°
FINGER POINT ……………………………6
°
APERTURE CONTROL …………………6
°
FOCUSING …………………………………7
°
HOW TO USE INFRARED INDEX ………9
°
LENS HOOD………………………………10
Square lens hood
Round-type lens hood
Built-in lens hood
°
FILTER ……………………………………14
°
ZOOM LENS………………………………16
°
POWER ZOOM LENS……………………17
Power zoom ring
Aperture
Infrared index of the zoom lens
°
MACRO LENS ……………………………22
Focus range limiter
Clamp screw
Tripod mount
Magnification
°
WIDE-ANGLE LENS (FA
24mm f/2 AL (IF) ) …………………27
°
TELEPHOTO LENS FA
85mm f/1.4 (IF)
FA
200mm f/2.8ED (IF),
FA
300mm f/4.5ED (IF) …………………28
Note on (infinity) mark
°
PRECAUTIONS WHEN THE FLASH IS USED ………………………………………30
°
SOFT CASE FOR LENS…………………31
°
SPECIFICATIONS ………………………32
°
COMPATIBILITY OF LENSES WITH THE BUILT-IN FLASH ……………38
WARNING
Never look at the sun through the lens or camera. Serious damage to the reti­na, or total loss of eyesight may occur.
Wrapping the strap around your neck is dangerous. Make sure that small chil­dren do not get the strap caught their neck. (A strap is supply only with some large types of lenses)
CAUTION
Do not leave the lens in direct sunlight without lens caps. Sunrays passing through the lens will be intensified, and should they focus on flammable materi­als, fire may occur.
FOR SAFE USE OF YOUR LENS
1
Although we have carefully designed these lenses for safe operation, Please be sure to follow precautions given in this page.
WARNING This mark indicates precautions that if not followed,
could result in serious injury to the user.
CAUTION This mark indicates precautions that if not followed,
could result in minor or medium injury to the user or damage to the equipment.
Leaving the camera in the direct sunlight without covering the lens with the lens cap, may damage to the inside of the camera.
When storing the lens in a case, attach the front and near lens caps that come sup­plied with the lens to protect it from dust and scratches.
After removing the lens from the camera body, be careful not to let it roll over or fall. Be sure to place the lens with its front side down.
Moisture can cause serious damage to optical glass elements. Storage in a damp place may cause mildew, so avoid storing the lens in a place where temperature and
humidity are high. Keep you lens in as dry a place as possible.
If you do not expect to use the lens for an extended period, store it in the case with a desiccant or it is recommended that the lens occasionally be taken out of the case and placed in a cool, dry, well-ventilated place to avoid the possibility of damage due to condensation build-up.
Use a blower or lens brush to remove dust on the lens. If the lens becomes dirty, remove the dirty particle with a blower brush, then wipe it off with a clean cotton cloth or tissue paper moistened with lens cleaning solution. Wipe in a spiral pattern from the center to the outside.
PRECAUTION AND LENS MAINTENANCE
2
The Pentax FA lenses are primarily designed to work with the Pentax autofocus SLR (K
AF2-
or K
AF2-mount camera), making autofocus
shooting possible. When Pentax FA Zoom lenses with power zoom function are used on the Pentax K
AF2-
mount camera, the camera features a Power Zoom system.
An FA zoom lens without the power zoom contacts are shown in the illustration does not have the power zoom function.
Do not damage or dirty the power contacts.
smc PENTAX F, FA and FAJ LENSES
3
Focusing ring
Front-ring threads
Distance scale
8
15
2
3
10
50
1.4
2.8
4
5.6
8
11
16
22
A
Aperture-A-lock button
Aperture ring Depth-of-field scale
AF coupler
Lens-information contacts
Power zoom contacts
When using FA lens with the K-mount Pentax camera having no lens information contacts, be sure to set the lens aperture ring to any f-stop other then A. If set to the "A" position, the lens will automatically be set to the minimum aperture, causing improper exposure.
CAUTION :
Be careful not to damage or dirty the lens information contacts and AF coupler on the mount surfaces of the camera and lens. Otherwise, failure or malfunction may result. If this occurs, wipe them gently with a clean, dry cloth.
FAJ28-80mm f/3.5-5.6AL and FAJ75-300 mm f/4.5-5.8AL lenses have A (Auto) posi­tion only, no aperture ring to set a f-stop manually. The camera body controls aper­ture settings on "A" position. Camera bod­ies and accessories that not compatible with "A" cannot be used.
Camera/Lens Mount Compatibility
Pentax camera/lens mount compatibility chart is shown below.
4
KAF2
-mount
which is equipped with
°
Power contacts
°
AF coupler
°
Lens information contacts
KAF-mount
which is equipped with
°
AF coupler
°
Lens information contacts
K
A-mount
which is equipped with
°
Lens information contacts
K-mount
(base mount) -
-will not autofocus, autozoom or provide automatic electroni-
1.To mount the lens on the camera body
Align the red dots on the lens and camera body, and then turn the lens clockwise until it clicks into place.
After mounting the lens, try to turn the lens
counterclockwise to make sure it is locked in place.
2.To remove the lens
Hold down the lens unlock button on the camera body and turn the lens counter­clockwise.
MOUNTING AND REMOVING OF LENS
5
The lens can be mounted on the camera by aligning the finger point with the lens unlock button.
Following Limited lenses have finger point.
FA31mm f/1.8AL Limited. FA43mm f/1.9 Limited. FA77mm f/1.8 Limited.
Setting the aperture to "A"(Auto)
Turn the aperture ring to align the aperture-A index with the line while depressing the Aperture-A-lock button. The aperture ring can be released from "A" in the same manner to set your desired f-stop manually.
FA28-105mm f/4-5.6(IF) and FA28-200 mm f/3.8-5.6AL lenses can set to "A" posi­tion without depressing the Aperture-A-lock button.
When using the camera body with no lens information contact, set the aperture ring to desired f-stop other than "A" position.
FINGER POINT
6
15
APERTURE CONTROL
8
10
16 8
22
ft m
3
2
50
22
16
A
11
8
5.6
4
To set the focus mode
Slide the focus mode switch on the camera body to change the focus mode to AF (Autofocus) or MF (Manual focus).
During autofocus, do not touch the focus­ing ring of your lens or you will interfere with proper lens movement.
In manual focus mode
You can adjust focus on the subjects by turn­ing the focusing ring manually and confirming the focus indicator in the viewfinder.
FA 28-90mm f/3.5-5.6, FAJ 28-80mm f/3.5-
5.6AL and FAJ 75-300mm f/4.5-5.8AL lenses have no distance scale, adjust focus with aid of the matte field for non-auto focus camera or using focus indicator in the viewfinder for auto focus camera.
FOCUSING
7
1586
10
A
ft
3
m
2
1.5
50
22
16
11
8
5.6
4
28
2
1
4
There is a white dot next to the maximum f­number engraved on the lens's aperture ring on many Pentax lenses. This white dot indi­cates an aperture which is darker by one stop (larger number). The illustration below shows the white dot next to f/4.5 is f/5.6.
F-STOPS OR F-NUMBERS AND CLICK STOPS
The click stops between two engraved f/stops are equivalent to intermediate f-stops. Some lenses do not have an intermediate click f­stop on the aperture ring due to limited space between the f-numbers engraved on the aperture ring.
8
1.4
1.221.7
2.8
2.443.4
5.6
4.886.7119.51613.5221932264538
When taking infrared pictures with infrared film and either a "R2" or "02" filter, it is neces­sary to adiust the focus because the point of focus is not the same with infrared light as it is with visible light. As shown above, memo­rize the focusing point on the lens distance scale when viewed through the viewfinder and turn the focusing ring until the point you memorized aligns with the infrared index.
Turn the focusing ring in the MANUAL focus mode only.
For the exposure control requierd in this special photography, see the information supplied with the infrared film.
Caution : Infrared film can not be used for MZ-S, MZ-60 and ist cameras since infrared ray is used for detecting device of film transport. It will expose infrared film in the camera.
HOW TO USE THE INFRARED INDEX
9
22
16
4
2.8
2
1.4
A
50
15
10
3
2
ft m
8
22
16 8
11
8
5.6
22
16
4
2.8
2
1.4
A
50
15
10
3
2
1
ft m
8
22
16 8
11
8
5.6
Square Hoods (Clip-on type)
PH-SA49 FA50mm f/1.4 & f/1.7 PH-SB49 FA28mm f/2.8AL, FA Sofy28mm f/2.8 Round Hoods (screw-in-type) PH-RA49 FA50mm f/1.4 & f/1.7 RH-RA49 F & FA Zoom 35-80mm f/4-5.6 RH-RB49 FA Zoom 70-200mm f/4-5.6
F & FA Zoom 80-200mm f/4.7-5.6
FA Macro 100mm f/3.5 RH-RC49 FA50mm f/1.4 & f/1.7 MH-RA49 FA43mm f/1.9 Limited RH-RA52 FA Macro 50mm f/2.8 RH-RB52 FA Zoom 28-70mm f/4AL MH-RB52 FA Soft 85mm f/2.8 RH-A58 FA Zoom 80-320mm f/4.5-5.6
F Zoom 100-300mm f/4.5-5.6
FA Zoom 100-300mm f/4.7-5.8 RH-RC58 FA Zoom 28-80mm f/3.5-5.6
FA Zoom 28-90mm f/3.5-5.6
FA Zoom 28-105mm f/4-5.6 MH-RB67 FA 20mm f/2.8 MH-RA112 FA★300mm f/2.8ED (IF)
Notes :
Do not use the built-in flash with lens hood because it blocks the flash light, except the FA43mmf/1.9 Limited lens.
Bayonet-type
PH-RBA49 FA 35mm f/2AL PH-RBA58 FA Zoom 20-35mm f/4AL PH-RBA62 FA Zoom 28-105mm f/4-5.6 (IF) PH-RBC58 FA Zoom 28-105mm f/3.2-4.5AL (IF) PH-RBE58 FAJ Zoom 28-80mm f/3.5-5.6AL PH-RBF58 FAJ Zoom 75-300mm f/4.5-5.8AL PH-RBB67 FA★24mm f/2AL (IF) PH-RBE67 FA Zoom 24-90mm f/3.5-4.5AL (IF) PH-RBG67 FA★Macro 200mm f/4ED (IF) MH-RBD67 FA★85mm f/1.4 (IF) MH-RBB77 FA
200mm f/2.8ED (IF)
FA★400mm f/5.6ED (IF) MH-RBC67 FA★300mm f/4.5ED (IF) PH-RBA72 FA Zoom 28-200mm f/3,8-5.6AL (IF) PH-RBC77 FA
Zoom28-70mm f/2.8AL
FA★Zoom 80-200mm f/2.8ED (IF)
PH = Plastic, RH = Rubber, MH = Metal
When using the FA28-70mmf/4AL lens with lens hood and filter, it may cause vignetting at edges of picture at focal length of 35mm and shorter.
The external flash can be used with lens hood attached to lens. FA
28-70mm f/2.8AL lens with the external flash, refer to page 30 for precautions.
LENS HOOD
10
Make sure to use a proper size lens hood specially designed for your lens.
How to Use the Square Hood
Attach the square hood to the front of the lens while pressing the knurled tabs on both sides of the hood.
Make sure to keep the top and bottom of the hood parallel with the top and bottom covers of the camera. The improper fitting will cause the vignetting in the picture corners.
How to Use the Round Hood
The round hood screws into the front of the lens.
The round type rubber hood can be folded when not in use.
11
How to Use the Built-in Hood
To use a lens with a built-in hood, first extend the hood to the fullest position. The 600mm f/4 lens and 250-600mm f/5.6 zoom lenses come in screw-fixed-type. Extend these hoods while rotating them for use. See the lens instruction manual for details.
Lenses with Built-in Hoods
FA 31mm f/1.8 AL Limited FA 77mm f/1.8 Limited FA 135mm f/2.8 (IF) FA 600mm f/4 ED (IF) FA Zoom 250-600mm f/5.6 ED (IF)
*
The built-in flash of the camera can be used when the built-in hood is utilized on the FA 77mmf/1.8 and FA 135 mm f/2.8 lens.
For more details of Bayonet hoods, refer to page 28.
LENS HOOD for FA
24mm f/2
How to attach
To attach the hood to the lens, align ( | ) on the hood and ( ) on the lens front, then turn the hood clockwise to lock it in place. To remove it, reverse the above procedure.
When the hood is not in use, align ( | ) on the hood and ( ) on the lens front, then turn the hood counterclockwise to lock it in place.
Always attach the lens hood to avoid stray light.
12
24
How to Use the Lens Hood with polarizing filter window
1.Remove the PL filter window cap by sliding it in the direction shown.
The hood is designed for use with a polar­izing filter or circular polarizing filter, and includes a "PL filter window" for adjusting the polarizing effect.
When attaching the hood, align the white dots on the lens and hood so that the PL filter window positions on the bottom.
2. Turn the outer rim of the polarizing filter or circular polarizing filter from the PL filter window as shown.
3.Attach the PL filter window cap.
13
Notes :
Be sure that the PL filter window cap is in place if no polarizing filter or circular polar­izing filter is used.
If strong light is entering the PL filter win­dow, either attach the PL filter window cap or reverse the position of the PL filter win­dow (to top or bottom of lens). Strong light entering the PL filter window will defeat the effect of the lens hood and prevent the tak­ing of clear, sharp images.
When the Pentax circular polarizing filter 58mm, which has the knurl ring on the back is used with the FA Zoom24-90mm f/3.5-4.5AL (IF) or FA Zoom 28-105mm f/3.2-4.5AL (IF) lens, the special lens hood cannot be attached. When a non-Pentax circular polarizing filter is attached, it also may not be attached.
Screw-in Type Filters
This type of filter screws into the front of the lens. Make sure to use the proper size Pentax filter specially designed for your lens.
Precaution on filters
Attaching the filter to your lens becomes a part of the optic. Avoid using no more than one filter exception of with a polarizing filter, as deterioration in image quality may results.
Attach the 43mm filters supplied with fol­lowing lenses to the filter holder in the rear of lens. FA
300mm f/2.8ED (IF)
FA
600mm f/4ED (IF)
FA
250-600mm f/5.6ED (IF)
A filter cannot be attached to the F Fish­Eye Zoom 17-28mm lens.
14
FILTERS
15
FILTERS
Precautions for using a polarizing filter
The circular polarizing filter is thicker than an ordinary filter. For this reason, using the circular polarizing filter with lenses as shown on the chart on the right may cause vignetting at the edges of picture.
Size Lens
52mm FA Zoom 28-70mm f/4AL 58mm FA Zoom 20-35mm f/4AL
FA Zoom 28-80mm f/3.5-5.6 FA Zoom 28-90mm f/3.5-5.6 FA Zoom 28-105mm f/4-5.6
67mm FA Zoom 24-90mm f/3.5-4.5AL (IF)
FA
Zoom 28-70mm f/2.8AL
FA 20mm f/2.8
Use a circular polarizing filter with Autofocus camera for proper exposure and auto focusing.
Size Lens
49mm FA 28mm f/2AL, FA Soft 28mm f/2.8, FA 35mm f/2AL, FA 43mm f/1.9 Limited, FA 50mm f/1.4 & f/1.7,
FA 77mm f/1.8, FA Zoom 70-200mm f/4-5.6, F & FA Zoom 35-80mm f/4-5.6,
F & FA Zoom 80-200mm f/4.7-5.6, FA Macro 100mm f/3.5 52mm FA 135mm f/2.8 (IF), FA Soft 85mm f/2.8, FA Macro 50mm f/2.8, FA Zoom 28-70mm f/4 AL 58mm FA 31mm f/1.8AL Limited, FA Zoom 20-35mm f/4AL, FA Zoom 28-80mm f/3.5-5.6,
FAJ Zoom 28-80mm f/3.5-5.6AL, FA Zoom 28-90mm f/3.5-5.6, FA Zoom 28-105mm f/3.2-4.5AL (IF),
FA Zoom 28-105mm f/4-5.6, FAJ Zoom 75-300mm f/4.5-5.8AL, FA Zoom 80-320mm f/4.5-5.6,
F Zoom 100-300mm f/4.5-5.6, FA Zoom 100-300mm f/4.7-5.8, FA Macro 100mm f/2.8 62mm FA 28-105mm f/4-5.6 (IF) 67mm FA 20mm f/2.8, FA★24mm f/2AL (IF), FA★85mm f/1.4 (IF), FA★Macro 200mm f/4ED (IF),
FA★300mm f/4.5ED (IF), FA Zoom 24-90mm f/3.5-4.5AL (IF), FA★Zoom 28-70mm f/2.8AL 72mm FA 28-200mm f/3.8-5.6 77mm FA★200mm f/2.8ED (IF), FA★400mm f/5.6ED (IF), FA★Zoom 80-200mm f/2.8ED (IF)
16
*
An FA Zoom lens without the power supply con­tacts on its mount does not have the zoom set button and auto zoom switch.
ZOOM LENS
28-105
5
2
ft m
A
22
16
11
8
5
.6
PA
AS
P
O
W
E
R
ZOOM
105
5
0
28
Focusing ring
Zoom ring
Aperture-A lock button
Aperture index (for longer focal length)
Aperture index (for shorter focal length)
Auto zoom switch
Zoom set button
17
Pentax FA and F zoom lens incorporate "two­hand" type rings: it has separate focusing and zooming ring. You can set your desired focal length by turning the zoom ring. It may shift the focusing point slightly by changing the focal length. First, adjust zoom­ing and then adjust focus using Autofocus or focus indicator in the viewfinder. The following zoom lenses also refer to its operating manual. FA
28-70mmf/2.8AL
FA
80-200mmf/2.8ED
FA
250-600mmf/5.6ED
The following lenses have power supply con­tacts to capable power zoom function with the K
AF2-mount cameras. Refer to the camera's
operating manual for more details. FA
28-70mmf/2.8AL FA28-105mmf/4-5.6 FA70-200mmf/4-5.6 FA
80-200mmf/2.8ED(IF) FA
250-600mmf/5.6ED(IF)
Auto zoom functions
The FA Zoom lens with power contacts com­bined with K
AF2-mount cameras can use fol-
lowing functions. Please refer to your cam­era's operating manual for more details.
1. Zoom clip mode to pre-set or re-call the focal length
2. Image size tracking mode to maintain the image size (magnification value) regardless of the distance to the subject.
3. Zoom effect mode to zoom automatically during an exposure.
Auto zoom switch and Zoom set button
1.P (Power zoom), PZ in some lenses Set to this position in power zooming
2.A (Auto zoom), AZ in some lenses Set to this position for Auto zoom
3.AS (Auto zoom set), MODE in some lenses Set this position to select the type of Auto zoom function.
POWER ZOOM LENS
18
Automatic lens retraction
When the power zoom lens is used with K
AF2-
mount cameras, the following functions work when the main switch is turned off.
1. The zoom ring automatically retracts to its shortest length.
2.The focusing ring is set to infinity(). With the combination of MZ-S camera, the zoom ring retracts to shortest length only.
Note on Tulip mark ( )
The zoom lens provide with the tulip mark ( ) on the focusing ring that enable to take a picture at closest distance as a fixed focal length lens, even set at wide-angle position. However, at the edges of picture may be darkened due to reducing brightness of image field.
When combined with non-K
AF2-mount cam-
eras, FA Zoom lens with power supply con­tacts does not work following functions.
As the Power Zoom function does not work, set the manual zoom mode. Pull the zoom ring towards the camera side until the words "POWER ZOOM" disappears to set the manual zoom mode.
The Auto Zoom switch and Zoom Set but­ton do not work.
19
Using the power zoom
Push the zoom ring forward until the word "POWER ZOOM "appears on the ring, and move the zoom ring to right or left to change the focal length.
Using the manual zoom
Pull the zoom ring back to use as manual zoom ring, the word "POWER ZOOM" disap­pears.
R
E
ZO
W
O
P
O
M
28
50
80
35
A2216118 5.6
3.5
20
Manual aperture
To set the aperture of the zoom lens manual­ly, align the aperture-A index with the white­bar index. The dot on the left-hand side of the white-bar index serves as an index to align an f-stop other than "A" when shooting at a longer focal length. For example, when using the FA Zoom 28-80 mm lens and wishing to set the aperture to f/8 with the focal length at 80 mm, align "8" on the aperture ring with the dot on the left-hand side.
"A" (Auto) position
To set the aperture to "A" (Auto), align the aperture-A index with the white-bar index, regardless of focal length selected.
80
A2216 11
POWER
80
8 5.6 3.5
ZOOM
28
65
80
POWER
80
A22161185.6
28
65
3.5
ZOOM
21
Infrared Index of the Zoom Lens
When taking infrared photographs with the zoom lens, compensation in focus is neces­sary depending upon the focal length. The distance scale of the zoom lens has infrared indexes for each focal length. Compensate for the focus according to the focal length in use (see page 9.).
With lenses having indexes only for the longest and shortest focal length, such as FA Zoom 70-200mm, obtain the compensation value for intermediate focal length by using the scale as a guide.
The red line on the lens barrel of the FA28­105mm f/4-5.6 (IF) is the infrared index line. Compensate for focus according to the focal length in use. See more details on page 9.
The following lenses have no infrared index line.
FA Zoom 28-90mm f/3.5-5.6 FA Zoom 28-200mm f/3.8-5.6
70
200
50
15
7
20
70
200
ft m
28-105
15 8 5 3 2 1.6ft
∞
5 3 2 1.2 0.7 0.5m
MACRO LENS
22
23
FA Macro 50mm f/2.8, FA Macro 100mm f/2.8 and FA
Macro 200mm f/4ED (IF) lens­es adjust focus from infinity to life-size. FA Macro 100mm f/3.5 lens adjust focus from infinity to 1/2x.
Focus-range limiter
FA Macro100mm f/2.8 and FA
Macro 200mm f/4ED (IF) lenses equipped with the focus-range limiter that control the focusing ranges to adjust Autofocus quickly.
To set the focus-range limiter
Turn the focus limiter to "LIMIT" with the focusing ring at infinity, the focusing range is set to long-distance range, and do the same with the focusing ring at minimum distance for short-distance range. Refer to chart for focusing range on page22.
FOCUS RANGE
FULL
A
F
LIMT
MF
24
When the focus range-limiter is set to
"MANUAL", you can adjust focus manually.
The focus range limiter may not turn where
the focus range changes between long and short distances.
Using with the K
AF2-mount cameras, manu-
al focus will work with the focus-range lim­iter is set to MANUAL in autofocus mode.
FA
Macro 200mm f/4ED (IF) lens has a focusing ring which provides autofocus and manual focus settings. Push the focusing ring forward or pull to change the focus mode from autofocus to manual.
Focusing range
With the K
AF2-mount camera, when the
focusing ring is set to MANUAL, the shutter cannot be released unless the focus indica­tion appears in the view finder if camera is set to the autofocus mode (AF single mode).
Limiter set
Short-distance range Long-distance range
FA Macro 100mm f/2.8 0.306m(1x) - 0.57m(1/4x) Approx.0.6m - infinity FA★Macro 200mm f/4ED (IF)
0.514m(1x) - 0.7m(1/2x) Approx.0.7m - infinity
25
Clamp Screw
FA Macro 50mm f/2.8 and 100mm f/2.8 lens­es are equipped with a clamp screw that is used when focusing manually. With manual close-up photography using the copy stand in any situation or with the lens pointing down , if you turn the clamp screw to the ON posi­tion, rotation of the focusing ring becomes tight. This helps to prevent the rotation of the focusing ring due to the lens's own weight and avoid any shift in focus.
When shooting in the autofocus mode, turn the clamp screw to the OFF position. Activating the autofocus mode while the clamp screw is in the ON position slows down the focusing speed.
OFF
CLAMP
O
N
26
Tripod Mount
FA
200mm f/4 ED (IF) is equipped with the tripod mount. To position the camera vertical­ly or horizontally, loosen the camera position shift lock screw, turn the camera 90° to the right or left as desired, and tighten the lock screw firmly. The tripod mount is not detachable.
Magnification Scale
The magnification is indicated by denomina­tors on the distance scale. "5" indicates "1/5x". When determining the magnification first, set the magnification in the MANUAL focus mode and adjust the position of the camera by moving the camera closer or fur­ther from the subject.
100
32
16
MACRO
3
0.7
2
4
5
1/x ft m
27
FA★24mm f/2 lens has a focusing ring which provides autofocus and manual focus set­tings. Push the focusing ring or pull it towards you to set the autofocus or manual focus mode respectively.
When used on the K
AF2-mount camera, you
can use the manual focus mode by setting the manual mode on the lens even if the aut­ofocus mode is set on the camera.
When the lens is set to manual focus posi­tion and the focusing ring is fully rotated to the right or left to manually focus the lens, it will keep rotating as no stoppers are pro­vided at the or shortest distance posi­tions.
When the focusing ring on the lens is set to the autofocus position, the focusing ring is released, allowing a full 360° rotation and providing a click stop at each 30° turn.
When used on the K
AF-mount camera, set
the same focus mode on the camera and lens. When the camera is set to the autofo­cus mode (AF single) and the lens is set to the manual mode, the shutter cannot be released unless the focus indication appears in the viewfinder.
When used on the non-K
AF2- or KAF-mount
camera, focus the lens manually with the focusing ring.
WIDE-ANGLE LENS (FA★24mm f/2 (IF) )
24
FOCUS
AUTO
22
16
A
11
8
5.6
4
28
2
28
*
The illustration depicts the FA
300mm
f/4.5 lens : when using the FA
85mm
f/1.4, FA
200mm f/2.8 and FA★Macro 200mm f/4, the operation is similar to the FA
300mm f/4.5.
*
For FA
300mmf/2.8 and FA★600mm f/4
lenses, refer to their own manual, too.
FA
300mm f/4.5 lens has a focusing ring which provides autofocus and manual focus settings. Push the focusing ring or pull it towards you to set the autofocus or manual focus mode respectively.
When used on the K
AF2-mount camera, you
can use manual focus mode by setting the manual mode on the lens even if the autofo­cus mode is set on the camera.
TELEPHOTO LENS (FA★85mm f/1.4(IF), FA★200mm f/2.8ED(IF), FA★300mm f/4.5ED(IF)
FA
Macro 200mm f/4ED(IF) )
29
When the lens is set to manual focus position and the focusing ring is fully rotated to the right or left to manually focus the lens, it will keep rotating as no stoppers are provided at the (infinity) or shortest distance positions.
When the focusing ring on the lens is set to the autofocus position, the focusing ring is locked.
When used on the K
AF-mount camera, set
the same focus mode on the camera and lens. When the camera is set to the autofo­cus mode (AF single) and the lens to man­ual focus mode, the shutter cannot be released unless the focus indication appears in the viewfinder.
Note : infinity (∞) mark except the FA
85mm f/1.4 lens
The focusing ring of the telephoto lens stops slightly past the mark. This is because tem­perature change causes the focusing point to shift, making the lens focus on a point past the mark. Even when shooting at infinity, be sure the image is in focus utilizing the focus indicator before releasing the shutter.
30
Built-in FLASH
With the built-in flash in popped-up position, the flash can be used if no warning indication appears when the shutter release button is pressed halfway down. However, some lens­es cause vignetting in the picture corners, even though warning indication does not appear. For more details, refer to page 38 and 39.
Remove the lens hood when the built-in flash is used because the flash light will be blocked by the lens hood.
The vignetting will not occur without the lens hood.
Flash A : AF500FTZ, AF360FTZ, AF400FTZ,
AF240FT, AF400T Flash B : AF330FTZ Flash C : AF280T, AF200T, AF200SA,
AF200S Flash D : AF100, AF140 *1 No vignetting occur at focal distance more
than 2.5m.
*2 No vignetting occur at focal distance more
than 1.1m with focal length 35mm.
*3 No vignetting occur at focal distance more
than 1.8m with focal length 50mm.
*4 No vignetting occur at focal distance more
than 1.0m
*5 No vignetting occur at focal distance more
than 1.5m with focal length 35mm.
PRECAUTIONS WHEN THE FLASH IS USED
PRECAUTIONS WHEN USING THE FA★28-70mm f/2.8 LENS AND LENS HOOD WITH THE EXTERNAL FLASH.
Z Series MZ Series
Flash A
Flash B
(*1)
Flash C
(*2) (*4)
Flash D
(*3) (*5)
Code Lens S70-70 FA 20mm f/2.8, FA 28mm f/2.8AL, FA 50mm f/1.4, FA 50mm f/1.7,
FA SOFT 28mm f/2.8
S80-80 FA 35mm f/2AL, F Fish-Eye 17-28mm f/3.5-4.5, FA 28-70mm f/4AL,
FA 35-80mm f/4-5.6
S80-120 FA 135mm f/2.8 (IF), FA 28-80mm f/3.5-5.6, FA28-90mm f/3.5-5.6,
FA 28-105mm f/4-5.6, FA MACRO 50mm f/2.8, FA SOFT 85mm f/2.8, F, FA 80-200mm f/4.7-5.6, FA MACRO 100mm f/3.5
S80-160 FA 70-200mm f/4-5.6, FA 80-320mm f/4.5-5.6, F 100-300mm f/4.5-5.6,
FA 100-300mm f/4.7-5.8, FA MACRO 100mm f/2.8
S90-100 FA
24mm f/2 (IF), FA 20-35mm f/4AL, FA 24-90mm f/3.5-4.5AL (IF), FAJ 28-80mm f/3.5-5.6AL, FA 28-105mm f/3.2-4.5AL (IF), FA 28-105mm f/4-5.6 (IF), FAJ 75-300mm f/4.5-5.8AL
S90-160 FA 28-200mm f/3.8-5.6AL (IF), FA★300mm f/4.5ED (IF) S110-160 FA★200mm f/2.8ED (IF) S120-150 FA★85mm f/1.4 (IF), FA★28-70mm F2.8AL S110-210 FA★MACRO 200mm f/4ED (IF) S110-230 FA★400mm f/5.6ED (IF) S120-230 FA★80-200mm f/2.8ED (IF) S135-340 FA★300mm f/2.8ED (IF) Trunk case FA★600mm f/4ED (IF), FA★250-600mm f/5.6ED
The limited series lenses include special soft lens case.
SOFT CASE FOR LENS
31
m ft.
ULTRA- FA 20mm f/2.8 22 94° 10-9 0.25 0.80 WIDE-ANGLE FA
24mm f/2AL (IF) 22 84° 11-9 0.30 1.00
WIDE-ANGLE FA 28mm f/2.8AL 22 75° 5-5 0.30 1.00
FA 31mm f/1.8AL Limited 22 70° 9-7 0.30 1.00 FA 35mm f/2AL 22 63° 6-5 0.30 1.00
STANDARD FA 43mm f/1.9 Limited 22 53° 7-6 0.45 1.60
FA 50mm f/1.4 22 47° 7-6 0.45 1.50 FA 50mm f/1.7 22 47° 6-5 0.45 1.50
MEDIUM- FA 77mm f/1.8 Limited 22 31.5° 7-6 0.70 2.30 TELEPHOTO FA
85mm f/1.4 (IF) 22 28.5° 8-7 0.85 2.80
FA 135mm f/2.8 (IF) 32 18° 8-7 0.70 2.30
TELEPHOTO FA
200mm f/2.8ED (IF) 32 12.5° 9-8 1.20 3.90 FA★300mm f/2.8ED (IF) 32 8.2° 10-7 2.00 6.60 FA★300mm f/4.5ED (IF) 32 8.2° 9-7 2.00 6.60
ULTRA-TELEPHOTO
FA★400mm f/5.6ED (IF) 45 6.2° 9-8 2.00 6.60 FA★600mm f/4ED (IF) 32 4.1° 9-7 5.00 16.50
MACRO FA MACRO 50mm f/2.8 32 47° 8-7 0.195 0.64
FA MACRO 100mm f/2.8 32 24.5° 9-8 0.306 1.00 FA MACRO 100mm f/3.5 22 24.5° 5-4 0.43 1.41 FA
MACRO 200mm f/4ED (IF) 32 12.5° 12-9 0.514 1.70
AL = Aspherical lens
ED = Achromatic lens including elements of the Extra-low Dispersion glass
IF = Lens featuring the inner focusing mechanism
SPECIFICATIONS
32
Minimum Aperture
AngleofView
Elements-Groups
Lens
Type
Minimum
FocusDistance
Specifications and external dimensions are subject to change without notice.
33
Xmm× mm g oz. mm 1.4 × S
0.12 70 × 44 255 9.0 67 ○○××
0.12 72.5 × 65.5 405 14.3 67 ○○××
0.13 65 × 40.5 185 6.5 49 ○○××
0.16 65 × 68.5 345 12.2 58 ○○××
0.17 64 × 44.5 195 6.9 49 ○○××
0.12 64 × 27 155 5.5 49 ○○××
0.15 65 × 37 220 7.8 49 ○○××
0.15 65 × 37 170 6.0 49 ○○××
0.14 64 × 48 270 9.5 49 ○○××
0.11 79 × 70 550 19.4 67 ○○××
0.25 68 × 80 375 13.2 52 ○○××
0.20 83 × 134 785 27.7 77 ×○○○
0.17 123 × 247 2500 88.2 43(112) ○○○○
0.17 72.5 × 160 935 33.0 43 ×○××
0.23 83 × 199 1140 40.2 77 ○○××
0.13 176 × 457 7000 247.0 43(150) ××○○
1.00 68 × 70 385 13.6 52 ○○××
1.00 74 × 103.5 600 21.2 58 ○○××
0.50 68 × 71.5 220 7.8 49 ○○××
1.00 75.5 × 191.5 1080 38.2 67 ○○××
= Weight with the tripod mount= Figures in ( ) of Filter size indicate the thread diameter of the front ring.
Note : Lens length does not include mount portion.
Filter size
Maximum
Magnification
Max. Diameter
× Length
Weight
Rear Converter
Compatibility
34
m ft.
*
2F Fish-Eye ZOOM 17-28mmf/3.5-4.5 22-32 180 - 90° 9-7 0.45 1.50
Zoom FA ZOOM 20-35mmf/4AL 32 94 - 63° 10-8 0.30 1.00
FA ZOOM 24-90mmf/3.5-4.5AL (IF) 22-32 84 - 27° 13-11 0.50 1.65 FA★ZOOM 28-70mmf/2.8AL 22 75 - 34.5° 14-11 0.43 1.40 FA ZOOM 28-70mmf/4AL 22 75 - 34.5° 9-7 0.40 1.30 FA ZOOM 28-80mmf/3.5-5.6 22-38 75 - 30.5° 8-8 0.50 1.65
*
1FAJ ZOOM 28-80mmf/3.5-5.6AL 22-38 75 - 30.5° 8-8 0.40 1.30
FA ZOOM 28-90mmf/3.5-5.6 22-32 75 - 27° 10-8 0.40 1.30 FA ZOOM 28-105mmf/3.2-4.5AL (IF) 22-32 75 - 23.5° 12-11 0.50 1.65 FA ZOOM 28-105mmf/4-5.6 22-32 75 - 23.5° 13-11 0.43 1.40 FA ZOOM 28-105mmf/4-5.6 (IF) 22-32 75 - 23.5° 15-12 0.50 1.65 FA ZOOM 28-200mmf/3.8-5.6AL (IF) 22-32 75 - 12.5° 16-14 0.52 1.70 FA ZOOM 35-80mmf/4-5.6 22-32 63 - 30.5° 7-6 0.40 1.30 FA ZOOM 70-200mmf/4-5.6 32-45 34.5 - 12.5° 10-8 1.10 3.60
*
1FAJ ZOOM 75-300mmf/4.5-5.8AL 32-38 32 - 8.2° 12-10 1.30 4.30
FA★ZOOM 80-200mmf/2.8ED (IF) 32 30.5 - 12.5° 16-13 1.40 4.60 FA ZOOM 80-200mmf/4.7-5.6 32-38 30.5 - 12.5° 11-7 1.10 3.60 F ZOOM 80-200mmf/4.7-5.6 32-38 30.5 - 12.5° 11-7 1.10 3.60 FA ZOOM 80-320mmf/4.5-5.6 32-38 30.5 - 7.7° 13-10 1.50 4.90 FA ZOOM 100-300mmf/4.7-5.8 32-38 24.5- 8.2° 11-9 1.50 4.90 F ZOOM 100-300mmf/4.5-5.6 32-38 24.5- 8.2° 12-8 1.50 4.90 FA★ZOOM 250-600mmf/5.6ED (IF) 32 9.9- 4.1° 18-16 3.50 11.50
*
1 The lens does not have aperture ring to set f-stop, camera body controls aperture on "A"
position.
Minimum Aperture
AngleofView
Elements-Groups
Lens
Type
Minimum
FocusDistance
35
Xmm× mm g oz. mm
*
3 1.4×S2×S 1.4×L2×L
0.07 65 × 61 255 9.0 − ×○○××
0.16 69.5 × 68 245 8.6 58 ×○○××
0.18 72 × 74.5 355 12.5 67 ×○○××
0.25 84.5 × 104 800 28.2 67 ○○○××
0.23 65.5 × 66 240 8.5 52 ×○○××
0.19 66.5 × 78 275 9.7 58 ×○○××
0.25 63 × 67 180 6.3 58 ×○○××
0.28 66.5 × 67.5 195 6.8 58 ×○×××
0.19 66 × 65.5 255 9.0 58 ×○○××
0.33 72.5 × 95.5 515 18.2 58 ○○○××
0.18 72 × 74 305 10.8 62 ×○○××
0.21 78 × 83 465 16.4 73 ×○○××
0.25 66.5 × 58 160 5.6 49 ×○○××
0.25 73 × 116.5 465 16.4 49 ○○○××
0.30 69 × 116 385 13.6 58 ×○○××
0.19 87.5 × 191.5 1570 55.4 77 ○○○××
0.25 65 × 97.5 270 9.5 49 ×○○××
0.25 65 × 97.5 295 10.4 49 ×○○××
0.28 74.5 × 129 550 19.4 58 ×○○××
0.26 70 × 128.5 410 14.5 58 ×○○××
0.25 71.5 × 154.5 605 21.3 58 ×○○××
0.20 134 × 442 5600 198.0 43(112) ○×○○○
*
2 This lens deliberately emphasizes distortion (barrel aberration) of the images at the pic-
ture corners throughout the entire focal length of 17mm to 28mm this allows you to obtain special effect photographs different from ordinary photographs.
*
3 indicates the power zoom lens, X indicates the non-power zoom lens.
Filter size
Powerzoom
Maximum
Magnification
Max. Diameter
× Length
Weight
Rear Converter
Compatibility
36
m ft.
SOFT FA SOFT 28mmf/2.8 22 75° 5-5 0.25 0.82
FA SOFT 85mmf/2.8 32 28.5° 5-4 0.50 1.65
Minimum Aperture
AngleofView
Elements-Groups
Lens
Type
Minimum
FocusDistance
37
Xmm× mm g oz. mm
*
3 1.4×S2×S 1.4×L2×L
0.13 65.6 × 40.3 195 6.9 49 −○○××
0.25 66 × 60 305 10.8 52 −○○××
Filter size
Powerzoom
Maximum
Magnification
Max. Diameter
× Length
Weight
Rear Converter
Compatibility
COMPATIBILETY OF LENSES WITH THE BUILT-IN FLASH
[= compatible × = incompatible because of vignetting]
Lens name
Compatibility
Z/PZ series Cameras *1 MZ series Cameras *1 MZ-S series Cameras *1 FA 20mm f/2.8 ××× FA 24mm f/2 AL (IF) ××× FA 28mm f/2.8 AL ○○○ FA 31mm f/1.8 AL Limited ○○○ FA 35mm f/2 AL ○○○ FA 43mm f/1.9 Limited ○○○ FA 50mm f/1.4 ○○○ FA 50mm f/1.7 ○○○ FA 77mm f/1.8 Limited ○○○ FA
85mm f/1.4 (IF) ○○○ FA 135mm f/2.8 (IF) ○○○ FA
200mm f/2.8 ED (IF) ○○○ FA
300mm f/2.8 ED (IF) ××× FA
300mm f/4.5 ED (IF) * 2 * 2 * 2 FA
400mm f/5.6 ED (IF) ○○○ FA
600mm f/4 ED (IF) ××× F FISH EYE 1728mm f/3.54.5 ××× FA MACRO 50mm f/2.8 * 19 ○○ FA MACRO 100mm f/2.8 * 19 ○○ FA MACRO 100mm f/3.5 ○○○ FA
MACRO 200mm f/4 ED (IF) * 20 ○○ FA SOFT 28mm f/2.8 ○○○ FA SOFT 85mm f/2.8 ○○○
38
39
Lens name
Compatibility
Z/PZ series Cameras *1 MZ series Cameras *1 MZ-S series Cameras *1 FA 2035mm f/4 AL * 3 * 3 * 4 FA 2490mm f/3.54.5 AL (IF) * 5 * 6 * 7 FA
2870mm f/2.8 AL ××△
*
8 FA 2870mm f/4 AL * 9 ○○ FA 2880mm f/3.55.6 * 10 * 10 FAJ 2880mm f/3.55.6 AL * 11 ○○ FA 2890mm f/3.55.6 * 11 ○○ FA 28105mm f/3.24.5AL (IF) ○○○ FA 28105mm f/45.6 * 12 * 13 FA 28105mm f/45.6 (IF) * 14 * 14 FA 28200mm f/3.85.6 (IF) * 15 * 15 * 16 FA 3580mm f/45.6 ○○○ FA 70200mm f/45.6 ○○○ FAJ 75300mm f/4.55.8 AL ○○○ FA
80200mm f/2.8 ED (IF) * 17 * 18 FFA 80200mm f/4.75.6 ○○○ FA 80320mm f/4.55.6 ○○○ F 100300mm f/4.55.6 ○○○ FA 100300mm f/4.75.8 ○○○ FA
250600mm f/5.6 ED (IF) ×××
*
1 Minimum focal length with the built-in flash.
Z-1, Z-5, Z-10 35mm lens & longer focal length.
ist, MZ & Z series cameras except MZ-S, Z-1, Z-5 & Z-10. 28mm lens & longer focal length.
MZ-S 24mm lens & longer focal length.
*
2 Vignetting will occur, even if the inappropriate lens warning is blinking.
*
3 Vignetting will occur at focal length between 20mm28m.
*
4 Vignetting will occur at focal length between 20mm24m.
*
5 Vignetting will occur at focal lengths between 20mm-50mm. With the focal length set at
50mm, it will occur when the camera-to-subject distance is closer than 1m.
*
6 Vignetting will occur at focal lengths between 24mm-35mm. With the focal length set at
35mm, it will occur when the camera-to-subject distance is closer than 1m.
*
7 Vignetting will occur at focal lengths between 24mm-28mm.
*
8 Vignetting will occur at focal lengths between 28mm-35mm. With the focal length set at
40mm, it will occur when the camera-to-subject distance is closer than 1m.
*
9 With the Z-1
P and Z-5P camera vignetting will occur at focal length 28mm when the camera-
to-subject distance is closer than 1m.
*
10 Vignetting will occur at focal lengths between 28mm-35mm and focal distance is less than
1m. No vignetting will occur when focal distance is 50mm and/or longer toward tele-side.
*
11 Vignetting will occur at focal lengths between 28mm-35mm.
*
12 Vignetting will occur at focal lengths between 28mm-35mm and with the focal length set at
35mm and focus distance is closer than 3m and with 40mm at 1m. No vignetting will occur when focal distance is 50mm and/or longer toward tele-side.
*
13 Vignetting will occur at focal lengths between 28mm-35mm and with the focal length set at
35mm and focus distance is closer than 1.5m and with 35mm.
*
14 Vignetting will occur at focal lengths between 28mm-40mm.
*
15 Vignetting will occur at focal lengths between 28mm-70mm.
40
*
16 Vignetting will occur at focal lengths between 28mm-35mm and focus distance is less than
1m at 35mm.
*
17 Vignetting will occur at focal lengths between 80mm-135mm.
*
18 Vignetting will occur at focal lengths between 80mm-90mm.
*
19 Even the Lens warning is blinking with Z-1, Z-5 and Z10, built-in flash can be used if the
focus distance is more than 0.7m which is within distance of Minimum Auto flash distance.
*
20 Vignetting will occur at focus distance less than 1m.
Even the Lens waning is blinking with Z-1, Z-5 and Z10, built-in flash can be used freely at focus distance more than 1m.
STATEMENT OF FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harm­ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not approved by the patry responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These lim­its are designed to proviede reasonable protec­tion against harmful interference in a residential
installation, This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equip-
ment and receiver.
41
56808ENG Printed on recycled paper.
This Class B digital apparatus meets all require­ments of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada.
PENTAX Corporation 2-36-9, Maeno-cho, Itabashi-ku, Tokyo 174-8639, JAPAN (http://www.pentax.co.jp) PENTAX Europe GmbH (European Headquarters) Julius-Vosseler-Strasse, 104, 22527 Hamburg, GERMANY
(HQ - http://www.pentaxeurope.com) (Germany - http://www.pentax.de)
PENTAX U.K. Limited Pentax House, Heron Drive, Langley, Slough, Berks SL3 8PN, U.K.(http://www.pentax.co.uk) PENTAX France S.A.S. 12/14, rue Jean Poulmarch, 95106 Argenteuil Cedex, FRANCE PENTAX Benelux B.V. (for Netherlands) Spinveld 25, 4815 HR Breda, NETHERLANDS (http://www.pentax.nl)
(for Belgium & Luxembourg) Weiveldlaan 3-5, 1930 Zaventem, BELGIUM (http://www.pentax.be)
PENTAX (Schweiz) AG Widenholzstrasse 1 Postfach 367 8305 Dietlikon, SWITZERLAND (http://www.pentax.ch) PENTAX Scandinavia AB P.O. Box 650, 75127 Uppsala, SWEDEN (http://www.pentax.se) PENTAX U.S.A., Inc. 35 Inverness Drive East, Englewood, Colorado 80112, U.S.A. (http://www.pentax.com) PENTAX Canada Inc. 3131 Universal Drive, Mississauga, Ontario L4X 2E5, CANADA (http://www.pentaxcanada.ca)
for your
precious moments
PENTAX
Only the power zoom lenses are subject to comply with Part 15 of FCC Rules and the Canadian Interference-Causing Equipment Regulation.
The CE marking assures that this product complies with the requirements of the EC directive for safety.
Copyright C PENTAX Corporation 2002
3 3-2 0 0 3 0 2 Printed in Japan
Loading...
