Ideal for Application that Require Faithful Color Reproduction

High Brightness for Displaying
Easy-to-See Content in Bright Places

Performance with 700 cd/m2 of brightness is
required for some signage and other professional
applications. This allows images to be beautifully
displayed even in large, brightly lit spaces, such as
train stations and airports.

*The LF8 Series has 500 cd/m2 of brightness.

The IPS Panel Has a Wide Viewing Angle
and Minimal Color Fluctuations

There is very little change in color, compared with the
VA panel, when the screen is viewed at right or left
angles, so the images are crisp and clear. This is ideal
for providing correct information to places with a lot of
people present, such as public spaces and facilities.

Effective for drawing attention with
high visibility even in bright places
like shopping malls.

NEW

Easy Display of Images Optimized
for the Display Content and Viewing
Environment

Conventional display panels are preset with
display modes such as Standard and Dynamic.
The LF80/8 Series comes with an extensive
display menu to let you select the most
suitable mode for the content to be displayed
and the viewing environment. You can select
the best mode for the video source and the
place of display.

High-Performance Image Engine
for Flexible Image Adjustment Like
Never Before

.

6-segment Color Management Enables

adjustment of the color tone, color density and
brightness parameters individually for red,
green, and blue, as well as the complementary
colors of cyan, magenta and yellow.

.

Color Enhancement Displays images with

enhanced color.

.

Refine Enhancer Corrects blurry image

contours resulting from resizing, etc., to
improve the image resolution.

.

MPEG Noise Reduction Noise reduction

suppresses the block noise and mosquito noise
that are characteristic of digital video signals.
This faithfully reproduces the inherent beauty
of the image.

Vivid Signage

Displays images suitable for
signage in a bright environment.

Surveillance

Displays images with reduced
brightness and with priority on
gradation.

Color Enhancement

Refine Enhancer

MPEG Noise Reduction

* Images on screen are simulated.

Natural Signage

Displays images with priority
on natural color reproduction.

Graphic

Suitable for PC input.

*Although the term "DICOM" is used, this product is not medical equipment.

Do not use displayed images for medical purposes such as examination or diagnosis.

OFF

OFF

OFF

Standard

Displays images faithful to
the original.

DICOM*

Display images close to the DICOM
Part 14 Grayscale Standard.

HIgh

Max

ON

Product specification

Model
Display panel

Screen size (diagonal)
Aspect ratio
Panel type
Effective display area (W x H)
Number of pixels (H x V)
Brightness (typ.)
Contrast ratio
Dynamic contrast ratio
Response time
Viewing angle (Horizontal/Vertical)

Connection terminal

Video In/Audio In (L/R)
Component/RGB In/Audio In (L/R)
HDMI In
DVI-D In/Audio In (L/R)
DVI-D Out
PC In/Audio In (L/R)
Audio Out
USB

Control

Serial In/Out
LAN/DIGITAL LINK (LF80)
LAN (LF8)
IR In/Out

Audio

Built-in speakers

Electrical

Power requirements
Power consumption
On mode average power consuption*
Power off condition
Standby condition

Mechanical

Dimensions (W x H x D)

Dimensions (W x H x D)
Excluding handle part

Bezel width
Weight

Wall-hanging pitch

2

Orientation
Tilting angle

Environment

Operating environment

1

: Based on IEC 62087 Ed.2 measurement method. *2 : Please contact your sales representative with regard to the tilt angle before installation. *3 : for up to 1400 m (4593 ft) altitude.

*

4

*

: for between 1400 m (4593 ft) and 2800 m (9186 ft) altitude Depending on the temperature or humidity conditions, uneven brightness may be observed.

This is not a malfunction. This unevenness will disappear while applying current continuously. If not, consult the distributor.

*

2

*

Optional Accessories Peripheral Equipments

Pedestal

TY-ST43PE8

Weights and dimensions shown are approximate. Specifications and appearance are subject to

change without notice. Product availability differs depending on region and country. This product

may be subject to export control regulations. HDMI, the HDMI logo, and High-Definition Multimedia

Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and

other countries. All other trademarks are the property of their respective trademark owners. Images

on screen are simulated. © 2017 Panasonic Corporation. All rights reserved

DIGITAL LINK Switcher

ET-YFB200G (Optional)

TH-55LF80 TH-55LF8 TH-49LF80 TH-49LF8 TH-42LF80 TH-42LF8

55-inch (1387 mm)

1209 x 680 mm (47.6" x 26.7")

2

700 cd/m

BNC x 1 set (shared with Component /RGB Y/G) /Stereo mini-jack (M3) x 1 (shared with Component In)

1

190 W
145 W

1229 x 699 x 72 mm/

48.4" x 27.6" x 2.8"

1229 x 699 x 57 mm/

48.4" x 27.6" x 2.3"

24.7 kg/54.5 lbs

VESA compliant 400 x 400 mm (15.8" x 15.8")

0-45 degrees forward/backward with landscape/portrait setting ( Angle adjustment is not possible for forward/backward tilting installation.)

2

500 cd/m

BNC x 1 set /Stereo mini-jack (M3) x 1 (shared with Video In)

DVI-D 24-pin x 1 /Stereo mini-jack (M3) x 1 (shared with PC In)

Mini D-sub 15-pin x 1 /Stereo mini-jack (M3) x 1 (shared with DVI-D In)

USB connector Type A (DC 5V/1A) x 1 (USB 3.0 Incompitable)

RJ45 x 1, 10BASE-T/100BASE-TX, compatible with PJLink

185 W
140 W

Landscape/Portrait (Angle adjustment 0-45 degrees for both left and right)

Temperature: 0 °C to 40 °C (32 °F to 104 °F)*

Digital Interface Box

ET-YFB100G (Optional)

1073 x 604 mm (42.2" x 23.7")

700 cd/m

Stereo mini-jack (M3) x 1

D-sub 9-pin x 1/x 1, RS-232C compatible

RJ45 x 1, 100BASE-TX, compatible with PJLink

Stereo Mini-jack (M3) x 1 / x 1

110–127/220–240 V AC, 50/60 Hz

175 W
130 W

T/R/L/B: 6.3 mm (0.25")

Humidity: 20–80 % (non-condensation)

Auto Display Adjustment Upgrade Kit

TY-VUK10 (Optional)

*Supports Ver.1.1 or later

Early Warning Software

49-inch (1232 mm)

16:9

IPS Panel/Edge LED

1920 x 1080 pixels

2

1300:1

50000:1

8 ms (G to G)

178°/178° (CR 10)

Type A connector x 2

DVI-D 24-pin x 1

20 W [10 W + 10 W]

Approx. 0.3 W
Approx. 0.5 W

1093 x 623 x 72 mm/

43.1" x 24.6" x 2.8"

1093 x 623 x 57 mm/

43.1" x 24.6" x 2.3"

19.0 kg/41.9 lbs

3

: 0 °C to 35 °C (32 °F to 95 °F)*4/

500 cd/m

160 W
115 W

42-inch (1064 mm)

927 x 521 mm (36.5" x 20.5")

2

TM

TM

2

700 cd/m

155 W
110 W

947 x 541 x 72 mm/

37.3" x 21.3" x 2.8"

947 x 541 x 57 mm/

37.3" x 21.3" x 2.3"

15.3 kg/33.7 lbs

VESA compliant 200 x 200 mm

(7.9" x 7.9")

*

* PASS Website- panasonic.net/prodisplays/pass
Register your display to activate the upgrade kit
and get what you need.

ET-SWA100 series* (Optional)

*Suffix of the part number may differ depending on the
license type

For the latest information about Panasonic Professional Display, please visit:

Professional Display Global Website: panasonic.net/cns/prodisplays/
YouTube: www.youtube.com/PanasonicProDisplay
Facebook: www.facebook.com/panasonicprojector

All information included here is valid as of April 2017.

CT17-G01PF-LF8
Printed in Japan.

500 cd/m

145 W
100 W

LF80 Series
LF8 Series

FULL HD LCD Display

2

Professional Display with High Picture Quality and Excellent Versatility

55’’

49’’

Indoor Displays 700 cd/m2 model

55-inch TH-55LF80
49-inch TH-49LF80
42-inch TH-42LF80

42’’

Indoor Displays 500 cd/m2 model

55-inch TH-55LF8
49-inch TH-49LF8
42-inch TH-42LF8

E-mail notification enables
quick response

Monitoring system

(SNMP Manager)

US

LF80 Series

55’’

LF8 Series

High-brightness model for installation in bright,
open spaces.

49’’

42’’

Ideal for store signage use. Vertical installation also
possible to match the installation location.

Functions Ideal for Industrial Signage Use Come as Standard Equipment

A Variety of Software is Available for Efficiently Operating Multiple Devices

55’’

49’’

42’’

LF80 Series

Screen Size

Panel Brightness

LCD Panel
Orientation

Tilt Angle

DIGITAL LINK

24/ 7 Operation

* Please contact your sales representative with regard to the tilt angle before installation.

Featuring industrial durability
and reliability, as well as a
stylish appearance.

This stylish design blends in with surrounding
spaces and fills the screen with images.
The 6.3 mm (0.25") bezel width of the LF80/8 Series
is less than half the 16 mm (0.7") bezel width of the
LF60/6 Series. And the slim design makes the
depth only 57mm (2.3"). Since the LF80/8 Series
blends in with almost any surroundings and the
screen is nearly filled with images, this display has
a powerful, eye-catching impact.

55/49/42-inch 55/49/42-inch

700 cd/m

2

IPS/Edge LED

Landscape/Portrait

(Angle adjustment 0-45 degrees for both left and right)

0-45 degrees forward/backward withlandscape/portrait setting

(Angle adjustment is not possible for forward/backward tilting installation.)

Yes No

Yes

57mm*
(2.3")

16mm
(0.7")

LF60 Series
LF6 Series

6.3mm
(0.25")

LF8 Series

500 cd/m

even bezel

6.3mm
(0.25")

LF80 Series
LF8 Series

2

6.3mm
(0.25")

* Excluding handle part

Efficiency and Reliability for Continuous 24-hour Operation

The use of highly durable panel materials and quality electronic components
ensures dependable 24-hour operation seven days a week. This makes the
LF80/8 Series ideal for installation in public places, surveillance centers, and
other applications where absolute reliability is critical.

* Display of moving images is recommended when panels are in use for long periods to prevent image
retention. Note that image burn-in can be gradually rectified with the periodical display of moving images.

Choose the Installation to Match Your Application

The LF80/8 series is designed for use in either portrait or horizontal orientation
with no effect on panel color and lifespan, further reducing TCO. A tilt
installation up to 45 degrees forward or backward is also possible. The angle
can be adjusted for easy viewing when installed in a high location.

USB Media Player for Simple
Signage Use Without an STB

NEW

The LF80/8 Series features a USB media player.
Signage operation is possible by simply inputting the
desired content via USB, eliminating the need for a
set-top box. Both videos and still images can be
displayed, so a wide variety of original signage
content can be used.

Standalone Operation Saves Labor

NEW

by Making Content Changes
Over a Network

Multi Monitoring & Control Software makes it
possible to change the content in the USB memory
via LAN after installation. Content can be easily
changed even when the display is installed in a high
place or suspended from the ceiling. This enables
smooth, easy operation.

DIGITAL LINK Function Enables
Simple Installation and

System configuration

ET-YFB200G

Low System Costs (LF80 Series only)

Using DIGITAL LINK makes it possible to transmit
video, audio and control signals over a long distance
(up to 150 m

(492 ft)) with a single LAN cable.

Easy cabling also reduces labor during setup. This
provides transmission of high-quality images and
sounds, as well as remote control.

*1 When connected with the [Long reach] mode, the maximum transmission
distance is 150 m (492 ft). In this case, the unit can receive the signals of up
to 1080/60p. A CAT5e (STP) cable or higher is required.

1

*

HDMI 1 VIDEOCOMPUTER 1 COMPUTER 2HDMI 2

PC

Blu-ray Disc

player

Forward tilting

Angle adjustment

(0-45° for both left and right)

45° 45°

45°

Landscape
orientation

Backward tilting Angle adjustment

Portrait
orientation

45°

Power Indicator
Landscape

(0-45° for both left and right)

45° 45°

45°

Landscape
orientation

*Angle adjustment is not possible for forward/backward tilting installation.
Be sure that the Power Indicator comes to the downside.

USB

45°

Portrait
orientation

Power Indicator
Portrait

Easy to update
the contents!

USB

CAT5e (STP) cable or higher

(Up to 150 m/492 ft)

Document

camera

LAN

DIGITAL LINK 1

DIGITAL LINK 2

VCRPC

Failover and Failback Safeguards

NEW

for Mission Critical Situations

The LF80/8 Series is equipped with a variety of signal
input terminals. If the main video and audio signals are
interrupted, the system immediately switches to
alternative signals. This makes it ideal for mission critical
control rooms and surveillance centers. If the main
signals are restored, the original image is displayed.

* The usable combinations of main and backup signals are limited.
For details, see the LF80/8 product website.

Multi Monitoring & Control Software

NEW

(Free) Lets You Control Devices
in Groups

This free Panasonic software enables you to monitor and
control up to 2048 devices over a LAN network from a
single PC. As a monitoring function, the status of multiple
devices can be listed in groups, and then detailed
information on each device can be separately displayed. As
a control function, control commands such as power
ON/OFF, input switching and command inputs can be
executed, and a schedule function can be used.

Cloning Function Saves Labor

NEW

When Setting Up Multiple Devices

You can easily copy the setting data of a master display
to other displays using USB memory. This saves labor
when making screen settings during the installation of
multiple devices.

* If the inch sizes/series (LF8, LF80) for the displays differ, the cloning
function does not operate. Use common inch sizes/series.

Compatible with "Early Warning Software"
for Sensing Display Problems in Advance

The LF80 and LF8 Series support Early Warning Software
(optional: ET-SWA100), which monitors the status of devices
(projectors or flat-panel displays) connected to an intranet,
reports device failures, and gives advance warnings by
detecting predicted abnormalities, after installation to the PC
has been completed. The status of displays in an intranet is
observed, and problems are forecast, the occurrence of other
problems is sensed, and notification is sent to the user.

* The use of this software will not detect malfunctions in all devices and
equipment in advance.

When the signals suddenly stop...

Going abroad? Join us now!

International
Travel
Insurance

Main input Backup input Main input Backup input

Have a
wonderful
vacation without
worries.

Failback

Monitoring & Control

Controls up to 2048 displays!!

* To download software: https://panasonic.net/cns/prodisplays/download/software/multi/

Master display

Monitoring display and projectors

Error occurrence

SNMP manager

Monitoring system

Monitoring system

(SNMP Manager)

(SNMP Manager)

Remote monitoring

Failover

When the signals are restored

Going abroad? Join us now!

International
Travel
Insurance

Main input Backup input Main input Backup input

USB

Data that can be copied

Settings and set values of [Picture], [Sound], [Setup],
[Position] and [Options] menus

Error information Warning information

Access point

Monitoring server

Monitoring

Internet

Have a
wonderful
vacation without
worries.

Copy installation data

E-Mail transmissions

Immediate recovery

Going abroad? Join us now!

International
Travel
Insurance

Main input Backup input

The original image is displayed

Going abroad? Join us now!

International
Travel
Insurance

Monitoring Station

* PC with Multi
Monitoring Software

LAN

Warning occurrence

E-mail notification enables

E-mail notification enables

quick response

quick response

Have a
wonderful
vacation without
worries.

Have a
wonderful
vacation without
worries.

INTRANET
