Panasonic TC-P55GT31 Operating Instruction

Owner’s Manual

55” Class 1080p Plasma HDTV

(55.1 inches measured diagonally)

Manual de usuario

Televisión de alta definición de 1080p y clase 55” de Plasma

(55,1 pulgadas medidas diagonalmente)

Model No.

Número de modelo

TC-P55GT31

For assistance, please call:

1-877-95-VIERA (958-4372)

www.panasonic.com/help Para solicitar ayuda, llame al:

1-877-95-VIERA (958-4372)

www.panasonic.com/help

English

Español

Thank you for purchasing this Panasonic product. Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only.

Gracias por su decisión de comprar este producto marca Panasonic. Lea estas instrucciones antes de utilizar su televisor y guárdelas para consultarlas en el futuro. Las imágenes mostradas en este manual tienen solamente fines ilustrativos.

TQB2AA0625-2

Experience an amazing level of multimedia excitement

Enjoy rich multimedia

VCR

Amplifier with

Speaker system

USB device

DVD recorder/

Blu-ray Disc recorder

SD memory card

DVD player/

Blu-ray Disc player

Camcorder

■Do not display a still picture for a long time

This causes the image to remain on the plasma screen (“Image retention”). This is not considered a malfunction and is not covered by the warranty.

4 : 3

To prevent the “Image retention”, the screen saver is automatically activated after a few minutes if no signals are sent or no operations are performed.

Personal computer

Cable box

Typical still images

Channel number and other logos

●

Image displayed in 4:3 mode

●

SD Card photo ●Video game ●Computer image

●

■Set up

Do not place the unit where it’s exposed to sunlight or other bright light (including reflections).

●

Use of some types of fluorescent lighting may reduce the remote control’s transmission range.

●

VIERA Link™ is a trademark of Panasonic Corporation.

HDMI, the HDMI logo and HighDefinition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Contents

SDXC Logo is a trademark of SD3C, LLC.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

“RealD 3D” is a trademark of RealD. This product is covered by U.S. Patent 5,193,000 until August 28,

2011. DLNA®, the DLNA Logo and DLNA

CERTIFIED™ are trademarks, service marks, or certification marks of the Digital Living Network Alliance.

QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

HDAVI Control™ is a trademark of Panasonic Corporation. Skype™ is a trademark of Skype limited.

This product is licensed under the AVC patent portfolio license for the personal and non-commercial use of a consumer to (i) encode video in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to provide AVC Video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC. See http://www.mpegla.com.

See page 69 for more information.

●

Please read before using the unit

Safety Precautions··········································4

•

Getting started

Accessories/Optional Accessories ··················8

•

Connections ··················································11

•

Identifying Controls ·······································14

•

First Time Setup············································15

•

Basic Features

Watching TV ·················································19

•

Using VIERA TOOLS ····································22

•

Watching content from external devices ·······23

•

Viewing 3D images on TV ····························24

•

Using Media player ·······································28

•

Advanced Features

VIERA LinkTM “HDAVI ControlTM” ····················34

•

Using Network services ································40

•

Network Connections ··································41

•

Network settings ·········································42

•

VIERA Connect (Enjoy Internet Service) ····45

•

Using DLNA feature ····································47

•

Network Camera ·········································48

•

Editing and Setting Channels ·······················49

•

How to Use Menu Functions·························51

•

Picture settings ···········································52

•

Audio settings ·············································54

•

Timer settings ·············································54

•

Lock ····························································55

•

Closed caption ············································55

•

Setup ··························································56

•

Support Information

Ratings List for parental control ····················57

•

Technical Information ····································58

•

Care and Cleaning ········································62

•

Disposal ························································63

•

Frequently Asked Questions (FAQ) ··············64

•

Specifications················································67

•

Index ·····························································70

•

Limited Warranty ···········································71

•

Customer Services Directory ························72

•

Getting started

Basic Advanced Support Information

Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel.

WARNING:

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Do not place liquid containers (flower vase, cups, cosmetics, etc.) above the set (including on shelves above, etc.).

DO NOT OPEN

Important Safety Instructions

11) Only use attachments / accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

The lightning flash with arrowhead within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons.

The exclamation point within a triangle is intended to tell the user that important operating and servicing instructions are in the papers with the appliance.

WARNING

Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from being played with by young children, creating the potential risk of suffocation.

■Set up

This Plasma TV may fall and can cause personal injury or

even death if not installed correctly. To prevent personal injury or death, follow these warnings:

Install the Plasma TV in accordance with the

●

manufacturer’s recommended pedestal or stand, corresponding hardware and installation instructions.

This Plasma TV is for use only with the following

optional accessories. Use with any other type of optional accessories may cause instability. The following accessories are manufactured by Panasonic Corporation.

• Wall-hanging bracket (Angled) TY-WK5P1RW

WARNING/CAUTION (TV set)

Be sure to ask a qualified technician to carry out the

●

installation and set-up.

Two or more people are required to install or remove the

television.

Some wall mounts (wall-hanging brackets) are not

●

designed to be mounted to walls with steel studs or old cinder block constructions.

Ask your dealer or licensed contractor to properly secure

the wall-hanging bracket.

Do not route the TV’s power cord inside the wall.

●

The power cord was not designed for in-wall mounting.

Doing so can lead to fire hazard.

Do not place the Plasma TV or its stand on a sloped or

●

unstable surface.

The Plasma TV may fall or tip over.

Do not support the Plasma TV on a non-specified

●

pedestal. Do not place the Plasma TV on furniture that can easily

●

be used as steps, such as a chest of drawers. Do not climb or allow children to climb on the Plasma TV

●

Place or install the Plasma TV where it cannot be

●

pushed, pulled over or knocked down. Route all cords and cables such that they cannot be

●

tripped over or pulled by curious children.

Do not place any objects on top of the Plasma TV.

●

If water spills onto the Plasma TV or foreign objects get

inside it, a short-circuit may occur which could result in fire or electric shock. If any foreign objects get inside the Plasma TV, please consult an Authorized Service Center.

In the unlikely event that you receive a shock from this

product it is possible that your household outlet may be wired improperly. Have an electrician verify that the TV’s outlet is properly wired. If the symptom persists, have the TV serviced by a qualified authorized technician.

To prevent the spread of fire, keep candles

●

or other open flames away from this product at all times

■AC Power Supply Cord

To prevent fire or electric shock:

The Plasma TV is designed to operate on a 120 V AC,

●

60 Hz service. Insert the power cord plug as far as it will go into the wall socket.

If the plug is not fully inserted, heat may generate, which

could cause a fire.

The included power cord is for use with this unit only.

●

Do not use any power cord other than that provided

●

with this TV. Do not handle the power cord plug with wet hands.

●

Do not do anything that might damage the power

●

supply cord. When disconnecting the power supply cord, hold the

●

plug, not the cord. Do not use the power supply cord if the plug or cord is

●

damaged.

Replace the cord or contact your Authorized Service Center.

Do not use a 3-prong to 2-prong AC plug adapters to

●

connect your TV’s plug to the wall outlet.

Doing so will defeat the TV plug’s safety feature, which

can lead to a shock hazard. If the wall outlet does not accommodate a 3-prong plug, have a qualified electrician replace your outlet and check the associated wiring.

■Handling the power supply cord

Insert the power plug fully into the socket outlet. (If the

●

power plug is loose, it could generate heat and cause fire.) Ensure that the power plug is easily accessible.

●

Ensure the earth pin on the power plug is securely

●

connected to prevent electrical shock.

• An apparatus with CLASS I construction shall be connected to a power socket outlet with a protective earthing connection.

Do not touch the power plug with a wet hand. (This may

●

cause electrical shock.) Do not use any power cord other than that provided

●

with this TV. (This may cause fire or electrical shock.) Do not damage the power cord. (A damaged cord may

●

cause fire or electrical shock.)

• Do not move the TV with the cord plugged in the socket outlet.

• Do not place a heavy object on the cord or place the cord near a high-temperature object.

• Do not twist the cord, bend it excessively, or stretch it.

• Do not pull on the cord. Hold onto the power plug body when disconnecting cord.

• Do not use a damaged power plug or socket outlet.

If a problem occurs (such as no picture or no sound),

●

or if smoke or an abnormal odor is detected from the Plasma TV, unplug the power supply cord immediately.

Continued use of the TV under these conditions might

cause a fire or permanent damage to the TV. Have the TV evaluated by an Authorized Service Center. Servicing of the TV by unauthorized personnel is strongly discouraged due to its high voltage.

If water or an object gets inside the Plasma TV, if the

●

Plasma TV is dropped, or if the enclosure becomes damaged, unplug the power supply cord immediately.

A short-circuit may occur, which could cause a fire. Contact

an Authorized Service Center for an evaluation.

CAUTION

Do not cover the ventilation holes.

●

Doing so may cause the Plasma TV to overheat, which can

cause a fire or damage to the Plasma TV.

Leave a space of 3 15/16” (10 cm) or more at the top,

●

left and right, and 2 3/4” (7 cm) or more at the rear. When using the pedestal, keep the space between the

●

bottom of the TV and the pedestal or stand surface clear from objects that may obstruct ventilation.

■When Moving the Plasma TV

Be sure to disconnect all cables before moving the

●

Plasma TV.

Moving the TV with its cables attached might damage the

cables which, in turn, can cause fire or electric shock.

To prevent an electric shock, disconnect the power

●

plug from the wall outlet as a safety precaution before carrying out any cleaning.

Transport only in upright position.

●

Transporting the unit with its display panel facing upright or

downward may cause damage to the internal circuitry.

Using a dry cloth, clean any dust from the power supply

●

cord and plug regularly.

Build-up of dust on the power cord plug can increase

humidity, which might damage the insulation and cause a fire.

This Plasma TV radiates infrared rays;

therefore, it may affect other infrared communication

equipment. Install your infrared sensor in a place away from direct or reflected light from your Plasma TV.

The TV will still consume some power as long as the power supply cord is connected to the wall outlet.

Display panel is made of glass. Do not apply strong

●

force or impact to the display panel.

This may cause damage resulting in injury.

The TV is heavy. TV should be handled by 2 or more

●

people. Support as shown to avoid injury by the TV tipping or falling.

DANGER/WARNING/CAUTION (3D Eyewear)

DANGER

■About Prohibition of Heating

Do not put 3D Eyewear in fire, heat it or leave it in

●

places that can get hot.

3D Eyewear contains a lithium-ion polymer rechargeable

battery, so heating may result in combustion or rupture that may cause burns or fire.

WARNING

■About Prevention of Accidental Ingestion

Do not store any 3D Eyewear parts in places where

●

small children can reach.

There is a danger small children could swallow such parts by mistake.

• If a child accidentally swallows such parts, seek

immediate medical attention.

■About Prohibition of Disassembly

Do not disassemble or modify the 3D Eyewear.

●

When disposing this product, refer “Disposal” (p. 62) and

disassemble properly for removing the rechargeable battery.

■About Charging

Charge by connecting the included charging cable to

●

the USB terminal of a Panasonic TV supporting 3D.

Charging with other devices may result in battery leakage,

heating or rupture.

Do not use the included charging cable for uses other

●

than charging 3D Eyewear.

Doing so may result in heating, combustion or damage.

CEA CHILD SAFETY NOTICES

WARNING

Flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations. Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and may cause personal injury or even death.

The consumer electronics industry (of which Panasonic is a member) is committed to making home entertainment enjoyable and safe. To prevent personal injury or death, be sure to follow the following safety guidelines:

TUNE INTO SAFETY:

• One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on “larger than life” flat panel displays. Care should be taken to install the display where it cannot be pushed, pulled over, or knocked down.

• Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

CAUTION

■About 3D Eyewear

Do not drop, exert pressure on, or step on the 3D Eyewear.

●

Doing so may damage the glass section, which may result in injury.

• Always store the 3D Eyewear in the case provided when not in use.

Be careful of the tips of the frame when putting on the

●

3D Eyewear.

Accidentally inserting the tip of the frame into the eye may cause injury.

Always keep the 3D Eyewear in a cool, dry place.

●

Failure to do so may cause fire or electric shock.

Be careful not to trap a finger in the hinge section of the 3D Eyewear.

●

Doing so may result in injury.

• Pay special attention when children are using this product.

■About Use of 3D Eyewear

Parents/guardians should monitor children’s viewing

●

habits to avoid their prolonged use without rest periods. Use only the 3D Eyewear recommended for this TV.

●

Only use the 3D Eyewear for the specified purpose.

●

Do not move around while wearing the 3D Eyewear.

●

The surrounding area appears dark, which may result in

falling or other accidents that may cause injury.

■About Viewing of 3D Images

In the event that you experience dizziness, nausea, or other discomfort

●

while viewing 3D images, discontinue use and rest your eyes.

• When you set the effect by using “3D adjustment”, take into account that the vision of 3D images varies among different individuals.

Do not use if the 3D Eyewear is cracked or broken.

●

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation.

• Make sure the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

• A minimum of two people are required for installation. Flat panel displays can be heavy.

Panasonic recommends that a qualified installer perform the wall-mount installation. See page 4.

The American Academy of Pediatrics discourages television viewing for children younger than two years of age.

WANING/CAUTION (Communication camera)

WARNING

■Disassembly

Do not disassembe or modify this camera.

●

Doing so may cause fire or electric shock.

CAUTION

■Drop prevention

Make sure that the camera is installed securely.

●

The camera may cause injury if it falls from its installation

location.

■Do not wet

Always keep the camera in a cool, dry place.

●

Failure to do so may cause fire or electric shock.

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the Panasonic Service Center or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when connecting to peripheral devices. Any changes or modifications not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate this device.

FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC Declaration of Conformity

Model No. TC-P55GT31

Responsible Party: Panasonic Corporation of North America

One Panasonic Way, Secaucus, NJ 07094

Contact Source: Panasonic Consumer Electronics Company

1-877-95-VIERA (958-4372)

email: consumerproducts@panasonic.com

This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of this device. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC and IC require this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this product. The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research.

Product Identification Marking is located on the bottom of the Wireless LAN Adapter.

Accessories/Optional Accessories

Accessories

Check you have all the items shown.

Accessories

Remote Control Transmitter

N2QAYB000571

Batteries for the Remote Control Transmitter (2)

AA Battery

Cable clamper

Wireless LAN Adapter (p. 41)

N5HBZ0000055 K2KYYYY00150

Converter cables (p. 11) Owner’s Manual Quick start guide Child safety Product Registration Card

(U.S.A.)

Optional Accessories

3D Eyewear

(Rechargeable type)

TY-EW3D2S ●TY-EW3D2M

●

TY-EW3D2L

●

Wall-hanging bracket

TY-WK5P1RW

●

a: 19.7” (500 mm) b: 11.8” (300 mm)

Warning

In order to maintain the TV’s performance and safety, be absolutely sure to ask your dealer or a licensed

●

contractor to secure the wall-hanging brackets. Carefully read the instructions accompanying optional accessories, and be absolutely sure to take steps to prevent

●

the TV from tipping over. Handle the TV carefully during installation since subjecting it to impact or other forces may cause product damage.

●

Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the

●

wall before hanging the bracket. When using the angled-type wall hanging bracket, please ensure that there is sufficient space for the connecting

●

cables not to press against the wall when the TV is tilted forward. For safety reasons, remove units no longer being used from their wall-mounted locations.

●

3D Eyewear (2) (p. 24)

N5ZZ00000223

Communication Camera (p. 46)

N5ZZ00000193

Please contact your nearest Panasonic dealer to purchase the recommended Optional accessories. For additional details, please refer to the Optional accessories installation manual.

•

Product information (Model No. and release date etc.) is subject to change without notice.

• For more product information http://www.panasonic.com

Rear of the TV

Holes for wall-hanging bracket installation

Screw for fixing the TV onto the wall-hanging bracket (not supplied with the TV)

(View from the side)

Pedestal

TBL5ZX0058

How to assemble (p. 9)

Depth of screw: minimum 0.39” (10.0 mm), maximum 0.63” (16.0 mm)

Attaching the pedestal to TV

■

Assembling the pedestal

Fix securely with assembly screws (Total 4 screws).

Tighten screws firmly.

Assembly screws

Front

■

Set-up

Carry out work on a horizontal and level surface.

Tighten assembly screws (total 4 screws) loosely at first,

then tighten them firmly to fix securely.

Assembly screws

Bottom view

Accessories

Assembly screws (8)

THEL090N size (M5 x 25) (Black)

Poles (2)

or R is printed at the

●

front of the poles.

Base (1)

Getting started

Accessories/Optional Accessories

Rear side

Hole for pedestal installation

Pole

Arrow mark

Base

Removing the pedestal from the TV

Be sure to remove the pedestal in the following way when using the wall hanging bracket or repacking the TV.

Remove the assembly screws (Total 4 screws) from the TV. Pull out the TV from the pedestal. Remove the assembly screws (Total 4 screws) from the pole.

Warning

Do not disassemble or modify the pedestal.

Otherwise the TV may fall over and become damaged, and personal injury may result.

Caution

Do not use any pedestal other than that provided with this TV.

Otherwise the TV may fall over and become damaged, and personal injury may result.

Do not use the pedestal if it becomes warped or physically damaged.

If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic Dealer immediately.

During set-up, make sure that all screws are securely tightened.

If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal will not be strong

enough to support the TV, and it might fall over and become damaged, and personal injury may result.

When removing the pedestal, do not remove the pedestal by any methods other than the specified procedure. (above)

Otherwise the TV and/or pedestal may fall over and become damaged, and personal injury may result.

Hook

Installing the remote’s batteries

Pull open

Note the correct polarity (+ or -).

Caution

Incorrect installation may cause

battery leakage and corrosion, resulting in damage to the remote control.

Do not mix old and new batteries.

•

Do not mix different battery types (such

•

as alkaline and manganese batteries).

Do not use rechargeable (Ni-Cd)

•

batteries.

Do not burn or break batteries.

Connections

Connection Panels

Back of the TV

USB1 terminal

LAN connector

PC terminal

Back of the TV

SD card slot (p.28)

USB2/3 terminal

DIGITAL AUDIO OUT

Antenna or Cable connection

Antenna adapter

Accessories

Antenna adapter (1)

K1TYYYY00158

●

VIDEO adapter (1)

K2KYYYY00136

●

Component adapter (1)

K2KYYYY00137

●

Audio adapter (1)

K2KYYYY00138

●

Optical adapter (1)

K7CXGYC00002

●

PC adapter (1)

K1HY20YY0007

●

VHF/UHF Antenna

Getting started

Connections

Accessories/Optional Accessories

Cable TV

Power Cord (Connect after all the other connections have been made.)

VHF/UHF Antenna

• NTSC (National Television System Committee): ATSC (Advanced Television Systems Committee): Digital TV Standards include digital high-definition television (HDTV), standard-definition television (SDTV), data broadcasting, multichannel surround-sound audio and interactive television.

Cable

You need to subscribe to a cable TV service to enjoy viewing their programming.

●

You may need to subscribe to a high-definition (HD) cable service to enjoy HD programming.

●

The connection for high-definition can be done with the use of an HDMI or Component Video cable. (p. 12)

Note

When using a Cable box, external equipment and video cables shown in this manual are not supplied with the TV.

●

When disconnecting the power cord, be absolutely sure to disconnect the power cord plug from the wall outlet first.

●

For additional assistance, visit us at: www.panasonic.com/help

●

AV cable connection

Best

Good

Basic

(Not HD)

To use HDMI terminals

HDMI-DVI Conversion cable

white white

VIERA Link connection, please refer to p. 35

●

The HDMI connection is required for a 1080p signal.

●

red red

Audio adapter

To use COMPONENT terminals

Component adapter

Audio adapter

green

white

blue

red

green

blue

red

white

red

To use COMPOSITE terminals

green

blue

red

white

red

green

blue

red

white

red

HDMI AV OUT

DVI OUT

AUDIO OUT

COMPONENT VIDEO OUT

AUDIO OUT

AV Equipment

e.g. Blu-ray Disc player

AV Equipment

e.g. Blu-ray Disc player

AV Equipment

e.g. Blu-ray Disc player

VIDEO adapter

yellow

white

red

yellow

white

red

yellow

white

red

yellow

white

red

COMPOSITE OUT

AV Equipment

e.g. DVD Recorder

e.g. VCR

Audio connection

Optical adapter

For HDMI-ARC (Audio Return Channel) connection, see p. 34

●

Optical cable

PC / Computer connection (VGA)

Audio cable

RGB PC cable

PC adapter

Audio adapter

white white

red red

Cable Binding Instructions

DIGITAL AUDIO IN

Connect cable which matches the audio out terminal on the computer

Audio OUT

PC OUT

Conversion adapter (if necessary)

Audio equipment

e.g. Amplifier

Getting started

Computer

Connections

To attach

Cable clamper

To bundle

hooks

Do not bundle the Antenna cable and AC cord together (could cause distorted image).

●

Fasten the cables with the Cable clamper as necessary.

●

When using the options, follow the option’s assembly manual to fix cables.

●

hole

Insert

Set

To remove

To loosen

knob

Snaps

Keep pushing both sides till they snap

Keep pushing the knob

Identifying Controls

TV controls/indicators

Front of the TV Back of the TV

Remote control sensor POWER button

Note

The TV consumes a small amount of electric energy even when turned off.

●

Do not place any objects between the TV remote control sensor and remote control.

●

Within about 23 feet

(7 meters) in front of

the TV set

Power indicator (on: red, off: no light)

C.A.T.S. sensor Plasma C.A.T.S. (Contrast Automatic Tracking System) (p. 52)

3D Eyewear transmitter

Selects channels in sequence

Volume up/down Displays the

Main Menu Changes the input mode Chooses Menu and Submenu entries

Remote control

Switches TV On or Off (Standby)

Displays 3D settings. (p. 27) Lights the buttons for 5 seconds

Press again to turn off the button lights Select source to watch (p. 23) Switches to input terminal

that has “GAME” label (p. 23) Displays Main Menu (p. 51)

Displays Sub Menu for special functions (when available) (p. 20)

Colored buttons (used for various functions)

Volume up/down

Closed caption On/Off (p. 19) Selects Secondary Audio Programming (p. 19)

Exits from Menu screen VIERA Link menu (p. 38-39) Displays VIERA Connect (includes VIERA

CAST) Home screen (p. 45) Displays VIERA TOOLS menu (p. 22) Selects/OK/Change Go back to previous menu

Channel up/down, when viewing from ANT/

Cable source Sound Mute On/Off Changes aspect ratio and zoom

(p. 20, 58)

Switches to previously viewed channel or input

External equipment operations (p. 39)

Displays or removes the channel banner (p. 19)

Operates the Favorite channel list function

(p. 20)

Numeric keypad to select any channel or

press to enter alphanumeric input in menus

Use for digital channels (p. 19)

First Time Setup

The first time setup screen is displayed only when the TV is turned on for the first time after the power cord is inserted into a wall outlet and when “Auto power on” (p. 56) is set to “No”.

Turn the TV On with the POWER button

(Remote)(TV)

Configure your viewing mode

Select your language

Language / Idioma / Langue

Select your language Seleccione su idioma Sélection de la langue

English Español Français

Getting started

Step 1 of 7 / Paso 1 de 7 / Étape 1 de 7

select

Select Selección Sélection

Select your country

Country

Select the country where this TV is being used.

U.S.A. Canada Other

Step 2 of 7

select

First Time Setup

Identifying Controls

Select

RETURN

Select your viewing mode (Be sure to select “Home use”)

Set viewing mode

Select your viewing environment

Home use Store Demonstration

Step 3 of 7

select

Select

RETURN

Please confirm your selection (Home Use) before pressing OK button.

●

■If you select “ Store Demonstration” by mistake in ,

confirmation screen will be displayed.

You are selecting the store demonstration mode.

Yes

If you select “Yes”, the picture mode will regularly reset to “Vivid” and a Picture Refresh message will be displayed on the screen.

Select “No” and return to previous screen

●

If you select “Yes”, Screen enters the store demonstration mode.

●

To display the “Set viewing mode” screen again as shown above and select “Home Use”, do one of the following:

• Press and hold down the front POWER button for at least five seconds.

• Unplug power cord for 30 seconds and plug it again.

select

Note

If you use any other step other than

●

then turn the TV off, or if you used the EXIT button to quit before completing the settings, the next time you turn the TV on, “First time setup” will not be automatically displayed.

• The settings up to that point are saved.

• You can start “First time setup”. (p. 56) Language, ANT/Cable setup, Input labels, and Clock can also be changed

●

in the Settings Menu. (p. 56)

Press to exit from

RETURN

Select

GHI

PQRS

ABC

JKL

TUV

DEF

MNO

WXYZ

- ,

LAST

ABC abc

GAME

Video

GAME

a menu screen

Press to go back to the previous screen

Note

About broadcasting

systems

Analog (NTSC): Conventional

broadcasting

Digital (ATSC): New programming

that allows you to view more channels featuring high-quality video and sound

ANT/Cable setup

Do you use a Cable, Satellite or Fiber Optic box with this TV?

ANT/Cable setup

Do you use a Cable, Satellite or Fiber Optic box with this TV?

Yes No

Select

Return

a Select signal type

(Cable/Antenna)

ANT/Cable setup

How does the TV receive its programming content?

Cable service

Over-the-Air Antenna

(No box)

Select

Return

Select scan type

Auto program

Start scanning for available channels in your area?

Yes No

Antenna Cable In

Step 4 of 7

Yes

select

Select connection type for Cable or Satellite box and go to

ANT/Cable setup

Which wiring method is used to connect your box to the TV?

VIDEO IN

HDMI

Component

Composite

Select

Return

Select

Return

Yes

Start scanning

Auto program

Progress

Number of analog channels Number of digital channels

This may take some time to complete. Press RETURN to quit

RETURN

Complete scanning

Auto program completed. Press OK to continue.

Number of analog channels

Number of digital channels

OK RETURN

10 20

Label the inputs for easy identification (Label inputs)

To name each input, follow the instructions on screen. When done, select NEXT and press OK to go to the next step.

Label inputs

What is connected to HDMI 1 ? For your convenience, you may name each input for easy identification. The labels will be shown in the “Input select” menu.

HDMI 1

HDMI 2 HDMI 3 HDMI 4 Component Video PC Next

Select

Return

Customize label

--> To edit the labels to match your connected devices.

Label: [BLANK] Blu-ray/CABLE/SATELLITE/DVD/DVD REC/DVR/GAME/HOME

THTR/RECEIVER/COMPUTER/MEDIA CTR/MEDIA EXT/VCR/CAMERA/ MONITOR/AUX/OTHER/Not used

• Select “Not used” for any back-panel input that has no device connected to it. Afterward, the input will be skipped when pressing INPUT, for your convenience.

• The input labels can be changed at any time from the TV’s setup menu

Step 5 of 7

HDMI

select set

Follow the instructions on screen to complete the following operations.

(Input labels)

Step 4 of 7

Antenna/Cable in

Antenna Cable In

Configure Network settings

RETURN

0 9

DST

Minutes

Select the Network type

Network settings

Select Ethernet cable of wireless network.

Ethernet cable Wireless(Wifi) Set later

Select

Return

Select the setting mode

Network settings

Checks for proper network connection, settings and communication to the Internet and server automatically.

Automatic Manual

Step 6 of 7

Set later: Go to You can set in “Setup” menu later. Wireless (WiFi)

Automatic: Press OK to start setup automatically. Error screen is displayed when

Manual: Go to Manual setting.

: Start “Wireless network” (p. 18)

Network connection has failed.

Press to exit from

a menu screen

■

Press to go back to the previous screen

Select

RETURN

Manual

Automatic

Start connection test

Network settings

Connection test

Check Ethernet cable connection Validate IP address Check for IP address duplication

Check connection to the Internet Check communication with VIERA Connect server.

Test in progress...

RETURN

Step 6 of 7

Complete “Network settings”

Connection test

Connection error

■Manual setting

Network settings

Configure settings of the network connection.

IP setting mode

Automatic

IP address

192.168.0.4

Subnet mask

255.255.255.0

Default gateway

192.168.0.1

DNS setting mode

Automatic

DNS

192.168.0.1

Proxy address Proxy port Connect test Mac address

00-00-aa-cc-33-ab

Select

Change

RETURN

Manual Helpful information is displayed when you successfully complete “Network settings”.

Network settings

Network settings are complete. You can use VIERA Connect. VIERA Connect lets you enjoy Internet contents on your VIERA TV.

OK Return

Step 6 of 7

■Error screen

Network settings

Connection test

Check Ethernet cable connection Validate IP address Check for IP address duplication

Check connection to the Internet Check communication with VIERA Connect server.

Connection to local network (router) failed. Ensure wireless network availability

Retry Manual Set later

Select

RETURN

Retry: Go to “Start connection test” Set later: Go to

Adjust the Clock (Set clock)

When done, select NEXT and press OK to go to the next step.

■Manual setting

Set clock

Adjust the TV's date and time

Select

Change

Mode

Year

Month Day Hour Minute Time zone DST Next

Edit RETURN

0-9

Manual

- - -

Step 7 of 7

select set

Follow the instructions on screen to complete the following operations.

■Auto setting

Set clock

Adjust the TV's date and time

2011/4/5 6:00 AM

Mode

Year Month Day Hour Minute Time zone DST Next

Select

Change

RETURN

Mode

Time zone

DST

Auto

EST Off

Manual: Adjust the clock manually (Year/Month/Day/Hour/Minute) Auto: The clock is adjusted automatically via Internet service. Only available when the TV is on a network. -->Set “Network settings” first.

Select your time zone. (EST/CST/MST/PST/AKST/HST/NST/AST) Set DST (Daylight Saving Time) setting. (On/Off)

On: Advances the clock one hour from the time it is set according to the time zone.

Step 7 of 7

Getting started

Step 6 of 7

First Time Setup

Step 6 of 7

Press to exit from

a menu screen

■

Press to go back to the previous screen

Complete First time setup

Congratulations! You are done. The First time setup can be repeated at any time.

Press MENU and select SETUP; then “First time setup”.

Congratulations! Setup is complete.

Enjoy your Panasonic VIERA TV.

OK RETURN

To watch TV via a Cable box, Satellite receiver, or any other source (DVD, DVR, gaming device, etc.), press the INPUT button and select the appropriate input.

■About wireless LAN

To use the Wireless LAN Adapter, an access point needs to be obtained.

●

For the additional information for Wireless LAN Adapters, check the following website: http://Panasonic.com/NetConnect It is recommended to use the Wireless LAN Adapter with the supplied extension cable.

●

Do not use the Wireless LAN Adapter to connect to any wireless network (SSID*) for which

●

you do not have usage rights. Such networks may be listed as a result of searches. However, using them may be regarded as illegal access.

* SSID is a name for identifying a particular wireless network for transmission.

Do not subject the Wireless LAN Adapter to high temperatures, direct sunlight or moisture.

●

Do not bend, or subject the Wireless LAN Adapter to strong impacts.

●

Do not disassemble or alter the Wireless LAN Adapter in any way.

●

Do not attempt to install the Wireless LAN Adapter in any incompatible device.

●

When VIERA Connect, Network camera, DLNA, or other device is using the network, do not

●

disconnect the Wireless LAN Adapter. Check that the Access point supports WPS*.

●

(If it does not support WPS, the encryption key of the Access point is required when configuring settings.) Follow the instructions on the Access point setup screen and configure the appropriate

●

security settings. For more details on setting of Access point, please refer to operating manual for the Access point. We recommend using 11n (5 GHz) for the wireless system between the Wireless LAN Adapter

●

and Access point. Communication is also possible with 11a, 11b, and 11g (2.4 GHz), but the communication speed may be slower. If the wireless system of the Access point is changed, devices that could connect by wireless

●

LAN may no longer be able to connect. Data transmitted and received over radio waves may be intercepted and monitored.

●

Keep the TV away from the following devices as much as possible:

●

Wireless LAN, microwaves, and other devices that use 2.4 GHz and 5 GHz signals. Otherwise, the TV failures such as malfunction may occur due to the radio wave interference. When noises occur due to the static electricity, etc., the TV might stop operating for the protection

●

of the devices. In this case, turn the TV Off with power On / Off switch, then turn it On again.

* WPS: Wi-Fi Protected Setup

■Wireless network (First time setup) in

Display “Wireless network” Select the connection method

Wireless network

Please choose connection method:

Search for wireless networks WPS (Wi-Fi Protected Setup using push button)

Follow the directions on screen to complete the setting.

●

See page 43 for more information.

●

select

Watching TV

Turn power on

(Remote)

(TV)

■VIERA Connect Banner appears

Press OK/INTERNET (or VIERA CAST) button to enter VIERA Connect. (p. 45)

To hide the banner Press any button except OK/INTERNET (or VIERA CAST)

●

You can also set the banner display status (on/off) in the Setup menu. (p. 56)

●

Menu > Setup > Advanced setup > VIERA Connect Banner

button (Time-out period of this banner is 5 sec.)

Select a channel number

down

• Also available side CH button on the unit.

[For Cable/Satellite box connection]

- Use your connected box’s remote control.

Note

Reselect “Cable” or “Antenna” in “ANT in” of “ANT/Cable setup” to switch the signal

reception between cable TV and antenna. (p. 16, 49) The channel number and volume level remain the same even after the TV is turned off.

■Other Useful Functions

Listen with SAP (Secondary Audio Programming)

■Select the Audio mode for watching TV

Digital mode

Press SAP to select next Audio track (if available) when receiving a digital channel.

Audio track 1 of 2

Analog mode

Press SAP to select the desired Audio mode.

• Each press of SAP will change the Audio mode. (Stereo/SAP/Mono) SAP is not available when watching TV with a Cable or Satellite box connected via HDMI. Contact your Cable or Satellite operator for instructions on enabling SAP with their box.

(English)

Closed Caption

■Switches the Closed Caption mode On or Off

Closed caption OnClosed caption Off

Closed caption On mute

Note

Please select correct input --> (p. 23)

To directly enter the digital channel

number

When tuning to a digital channel, press the button to enter the minor number in a compound channel number.

example: CH15-1:

Getting started

Basic

Watching TV

First Time Setup

Closed Caption is not available when watching TV with a Cable or Satellite box connected via HDMI. Contact your Cable or Satellite operator for instructions on enabling CC with their box.

Displaying Information

■Displays and removes information. When watching programming via the Antenna/Cable input,

shows the channel banner.

Channel

15-2 12:30 PM ABC-HD

Station identifier

THE NEWS

CC SAP

SAP indication

TV-G 1080i Standard 4:3

Signal resolution

Rating Level

Picture mode

Aspect ratioClosed caption

Clock

Sleep timer remaining time

Change aspect ratio and Zoom the picture

Favorite channels

1/3

26-1

1 2 3 4 5

Set favorite 1/3

26-1

1 2 3 4 5

Set favorite 1/3

26-1

1 2 3 4 5

■Press FORMAT to cycle through the aspect modes (p. 58)

• 480i, 480p: FULL/JUST/4:3/ ZOOM

• 1080p, 1080i, 720p: FULL/H-FILL/JUST/4:3/ZOOM Use when the picture does not fill the whole screen (bars appears on either side of

the image) or portions of the picture is trimmed.

Note

1. Some content, such as film-based movies, are available in extra-wide format. Top and bottom bars are unavailable.

2. Connected devices, such as Cable/Satellite box, DVD/Blu-ray players and game consoles have their own aspect (format) settings. Adjust the device’s aspect settings.

Display the SUB MENU

■Press SUB MENU to show the Sub Menu screen

This menu consists of shortcuts to convenient functions. Sub menu is only available when the TV is using the Antenna/Cable input, not when using Cable or Satellite box.

Setup SUB MENU

Channel surf mode

All Set favorite Edit CH caption Signal meter

Specify favorites or type of channels to view when pressing the channel up/ down button.

Set favorite channel (below) Edit the channel identifier (p. 50) Check the signal strength (p. 50)

Call up a favorite channel

■ FAVORITE

Channel numbers registered in Favorite are displayed on the favorite tune screen. Select the desired broadcast station with the cursor or use the number buttons. (p. 19)

select

■Set the Favorite channel

■Delete a favorite channel

■To change the page

Setup SUB MENU

Channel surf mode

All

Set favorite

Edit CH caption Signal meter

Press repeatedly to change between pages (1/3, 2/3, 3/3 or exit)

Changes the page forward/backward

Favorite channels cannot be set when using Cable or Satellite box.

●

select the list

number save the displayed

channel

select the list number (to save the channel without pressing OK)

select

delete

(while holding down)

■Other Useful operations

RETURN

GHI

PQRS

ABC

JKL

TUV

DEF

MNO

WXYZ

- ,

LAST

Select

DeleteABC → abc

Proxy setting

Proxy address

Proxy port

1 4 8

Entering characters

You can use the remote control keys to enter the alphanumeric characters.

■Switches input mode

ABC → abc → 123

↑

_____________

■Press each number key

to cycle through the alphanumeric character

Navigation area

You can also use a USB keyboard (not supplied) to enter the alphanumeric characters.

●

Keyboard type (p. 56)

●

Password setting/entering

You need to enter the password when you access locked channel or inputs.

Input your 4-digit password

Password

Enter password.

* * * -

If it is your first time entering the password, enter the password twice in

●

order to register it. Make a note of your password. Do not forget it. (If you have forgotten

●

your password, consult your local dealer.) When you select a locked channel, a message will be displayed that

●

allows you to view the channel after you input your password. Change password (p. 55)

●

Operate USB keyboard

You can operate non-character keys as remote control keys.

■Key chart

Keyboard key Remote key Keyboard key Remote key

UP/DOWN/LEFT/RIGHT Cursor key F4 Input

Enter OK F5 Channel Down(-)

BackSpace Return (when you do not

input character)

F6 Channel up(+)

0-9 0-9 F7 Volume Down(-)

F1 Menu F8 Volume up(+) F2 VIERA Tools F9(Red)/F10(Green)/ F3 Submenu

For more details on setting and operation of the USB keyboard, please also read the operating manuals for the USB

●

F11(Blue)/F12(Yellow)

Color key

(Red/Blue/Yellow/Green)

keyboard. Some keyboards do not have these keys.

●

Basic

Watching TV

Using VIERA TOOLS

VIERA TOOLS is the easy way to access the TV’s special features. They are displayed as shortcut icons on the TV screen.

Display VIERA TOOLS

Select the item

select next

Set each item

Change the view 3D⇔2D (p. 27)

Press to exit from

a menu screen

Press to go back

to the previous screen

THX

VIERA Connect

Media player

DLNA

VIERA Link

Eco mode

Change to “THX” mode. Picture mode (p. 52)

Displays VIERA Connect Home Screen for Enjoying Internet Services (p. 45)

Media player (p. 28-33)

Using DLNA feature (p. 47)

VIERA Link (p. 38-39)

ECO/energy saving (p. 56)

Watching content from external devices

With the connected equipment turned On

Display the Input select menu

Select the input mode

Input select

ANT/Cable In

HDMI 1

HDMI 2

HDMI 3

HDMI 4

Component

Video

HDMI 1

GAME

Not used

GAME

AUX

(example)

Input label

Setup ANT/Cable (p. 49) Edit Device labels

Input labels (p. 56)

Terminal Label

(example)

(shortcut) Press the corresponding NUMBER button on the remote control to select the input of your choice. Or, press the INPUT button repeatedly, to cycle through the available inputs. * set unused input to “Not used”

select

enter

(below) for quick skipping.

Select the input of your choice, then press OK.

During the selection, if no action

●

is taken for several seconds, the “Input select” menu disappears. The terminal and label (names)

●

of the connected equipment are displayed.

Basic

Watching content from external devices

Using VIERA TOOLS

Note

The input label will be displayed on the “Input select” screen if the Input label was

●

customized.

■Press Game to switch to the game screen

Switches to input terminal that has “GAME” label.

Operate the connected equipment directly or using the remote control supplied with the equipment

Note

For details, see the manual for the connected equipment.

●

PC adjustments (p. 53)

●

Cycle through the input terminals if there are

●

multiple input terminals that have “GAME” label. (p. 56) If there is no input terminal with “GAME” label,

●

you cannot switch the input terminal to any other input terminal than the one currently selected.

HDMI 1

HDMI 3

Video

GAME

+ 51 hidden pages
