Panasonic SC-AK14 User Manual
CD Stereo System
Operating Instructions
Model No. SC-AK14
P
Before connecting, operating or adjusting this product, please read these
instructions completely.
Please keep this manual for future reference.
RQT5539-P
Dear customer
Table of contents
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions
carefully.
These operating instructions are applicable to the following system.
System SC-AK14
Main unit SA-AK14
Speakers SB-AK18
The model number and serial number of this product can be
found on either the back or the bottom of the unit.
Please note them in the space provided below and keep for
Before using
future reference.
MODEL NUMBER
SERIAL NUMBER
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Before using
Supplied accessories .............................................. 2
Precautions .............................................................. 4
Placement of speakers............................................ 5
Concerning the remote control .............................. 5
Battery installation.......................................................... 5
Correct method of use ................................................... 5
Connections ............................................................. 6
Basic connections (for supplied accessories)................. 6
Optional antenna connections........................................ 7
External unit connection................................................. 7
Front panel controls ................................................ 8
Turning the demo function off.............................. 10
ECO mode .............................................................. 10
Auto-off function.................................................... 10
Setting the time...................................................... 11
Convenient functions ............................................ 11
Radio operations
Presetting radio broadcasts ................................. 12
Listening to radio broadcasts............................... 13
Compact disc operations
Concerning compact discs ................................... 14
Listening to compact discs .................................. 15
Direct access play........................................................16
Repeat play..................................................................16
Random play................................................................16
Program play ............................................................... 17
To listen to special CDs and tracks
(CD Manager function) .............................................. 18
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
PRODUCT DAMAGE, DO NOT EXPOSE THIS APPLIANCE TO
RAIN, SPLASHING, DRIPPING OR MOISTURE.
Cassette deck operations
Listening to tapes.................................................. 19
Concerning cassette tapes ................................... 20
Supplied accessories
Please check and identify the supplied
accessories.
Use numbers indicated in parentheses when
asking for replacement parts.
To order accessories contact 1-800-332-5368
or web site (http://www.panasonic.com).
AC power supply cord . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pc.
(RJA0065-A)
RQT5539
FM indoor antenna (RSA0006-J). . . . . . . . . . . . . . . . . . 1 pc.
2
Recording operations
Before recording (Deck 2 only) ............................ 21
Tape-to-tape recording.......................................... 21
Recording from radio broadcasts ........................ 22
Recording from compact discs ............................ 23
To record special CDs and tracks
(CD Manager function) ............................................. 24
Sound quality/sound field operations
Using the built-in sound quality/
sound field settings.......................................... 25
Adding bass ........................................................... 25
Varying the sound quality with the manual
equalizer ............................................................ 26
Varying the sound quality with
the acoustic image (Al) equalizer .................... 26
Timer operations
Using the timer ...................................................... 27
Using the play/record timer .......................................... 27
Using the sleep timer ................................................... 29
Reference
Using an external unit ........................................... 29
Troubleshooting guide .......................................... 30
Maintenance ........................................................... 31
Specifications .........................................Back Cover
Product service....................................... Back Cover
CAUTION:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
¡Reorient or relocate the receiving antenna.
¡Increase the separation between the equipment and re-
ceiver.
¡Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
¡Consult the dealer or an experienced radio/TV technician
for help.
Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Before using
AM loop antenna
(RSA0029) ..................... 1 pc.
Remote control transmitter (EUR648200)........................ 1 pc.
Batteries ........... 2 pcs.
(R6, AA, UM-3)
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
3
RQT5539
PRECAUTIONS
Before using this unit please read these operating instructions carefully.
Take special care to follow the warnings indicated on the unit itself as
well as the safety suggestions listed below.
Afterwards keep them handy for future reference.
Safety
1. Power Source —The unit should be connected to power supply
only of the type described in the operating instructions or as
marked on the unit.
2. Polarization—If the unit is equipped with a polarized AC power
plug (a plug having one blade wider than the other), that plug will
fit into the AC outlet only one way. This is a safety feature. If you
Before using
are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of
the polarized plug.
3. Power Cord Protection—AC power supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them. Never take hold of the plug
or cord if your hand is wet, and always grasp the plug body
when connecting or disconnecting it.
4. Nonuse Periods—When the unit is not used, turn the power off.
When left unused for a long period of time, the unit should be
unplugged from the household AC outlet.
Installation
Environment
1. Outdoor Antenna Grounding—If an outside antenna is connected to the receiver, be sure the antenna system is grounded
so as to provide some protection against voltage surges and
built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No. 70-1990, provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the
grounding electrode. See figure below.
ANTENNA LEAD
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC–NATIONAL ELECTRICAL CODE
2. Water and Moisture—Do not use this unit near water—for example, near a bathtub, washbowl, swimming pool, or the like.
Damp basements should also be avoided.
IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
3. Heat—The unit should be situated away from heat sources such
as radiators and the like.
It also should not be placed in temperatures less than 5°C (41°F)
or greater than 35°C (95°F).
4. Condensation—Moisture may form on the lens in the following
conditions...
immediately after a heater has been turned on.
•
in a steamy or very humid room.
•
when the unit is suddenly moved from a cold environment to a
•
warm one.
If moisture forms inside this unit, it may not operate properly. To
correct this problem, turn on the power and wait about one hour
for the moisture to evaporate.
Placement
1. Ventilation—The unit should be situated so that its location or
position does not interfere with its proper ventilation. Allow 10
"
) clearance from the rear of the unit.
cm (4
2. Foreign Material—Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or shock.
3. Magnetism—The unit should be situated away from equipment
or devices that generate strong magnetic fields.
4. Stacking—Do not place heavy objects, other than system components, on top of the unit.
5. Surface—Place the unit on a flat, level surface.
6. Carts and Stands—The unit should be used only
with a cart or stand that is recommended by the
manufacturer.
The unit and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces may cause the unit and cart combination to overturn.
7. Wall or Ceiling Mounting—The unit should not be mounted to
a wall or ceiling, unless specified in this operating instructions.
Maintenance
(See page 31 for details.)
Clean the cabinet, panel and controls with a soft cloth lightly moist-
ened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
1. Damage Requiring Service —The unit should be serviced by
qualified service personnel when:
(a)The AC power supply cord or the plug has been damaged; or
(b)Objects have fallen or liquid has been spilled into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not appear to operate normally or exhibits a
marked change in performance; or
(e)The unit has been dropped, or the enclosure damaged.
2. Servicing —The user should not attempt to service the unit
beyond that described in the operating instructions. All other
servicing should be referred to an authorized service personnel.
For the address of an authorized servicenter:
In the U.S.A. 1-800-211-7262 or web site
(http://www.panasonic.com)
RQT5539
4
Concerning the remote control
Listening caution
Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to
consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound
come through loud and clear without annoying blaring or
distortion—and, most importantly, without affecting your sensitive
hearing.
We recommend you to avoid prolonged exposure to excessive noise.
Sound can be deceiving. Over time your hearing “comfort level”
adapts to higher volumes of sound. So what sounds “normal” can
actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe level BEFORE
your hearing adapts.
To establish a safe level:
Start your volume control at a low setting.
•
Slowly increase the sound until you can hear it comfortably and
•
clearly, and without distortion.
Once you have established a comfortable sound level:
Set the dial and leave it there.
•
Battery installation
R6, AA, UM-3
1
2
Insert the batteries observing the correct polarities (e, d).
Use of batteries
Align the poles (+ and –) properly when inserting the batteries.
•
Do not mix old and new batteries or different types of batteries.
•
Do not recharge ordinary dry cell batteries.
•
Do not heat or disassemble the batteries. Do not allow them to
•
contact flame or water.
Remove the batteries if the unit is not to be used for a long time.
•
Do not keep together with metallic objects such as necklaces.
•
Do not use batteries if the covering has been peeled off.
•
Do not use rechargeable type batteries.
•
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
If electrolyte leaks from the batteries, consult your dealer.
Wash thoroughly with water if electrolyte comes in contact with any
part of your body.
Before using
Taking a minute to do this now will help to prevent hearing damage
or loss in the future. After all, we want you listening for a lifetime.
Placement of speakers
Speakers are designed identically so that no left or right channel
orientation is necessary.S
Notes
Keep your speakers at least 10 mm (13/32˝) away from the system
•
for proper ventilation.
These speakers do not have magnetic shielding. Do not place
•
them near televisions, personal computers or other devices easily
influenced by magnetism.
To avoid damage to the speakers, do not touch the speakers
•
cones if you have taken the nets off.
Correct method of use
Remote control
signal sensor
Transmission
window
30°
Operation notes
Do not place obstacles between the remote control signal sensor
•
and remote control unit.
Do not expose the remote control signal sensor to direct sunlight
•
or to the bright light of a fluorescent light.
Take care to keep the remote control signal sensor and end of the
•
remote control unit free from dust.
If this system is installed in a rack with glass doors, the glass
•
doors’ thickness or color might make it necessary to use the remote
control a shorter distance from the system.
30°
About 7 meters in front of
the signal sensor
To prevent damage
Never place heavy items on top of the unit.
•
Do not disassemble or reconstruct the unit.
•
Do not spill water or other liquids into the unit.
•
5
RQT5539
Before using
1
3
2
4
Connections
Basic connections (for supplied accessories)
Plug the AC power cord into a household AC outlet only after all
•
other connections have been made.
To prepare the antenna wires and speaker cords, twist the vinyl
•
cover tip and pull off.
Connect the FM indoor antenna.
Tape the antenna to a wall or column, in a position where radio
signals are received with the least amount of interference.
Note
For best reception sound quality:
An FM outdoor antenna is recommended. (See page 7.)
1
2
3
Connect the AM loop antenna.
After attaching the antenna, turn on the system and tune in a
Adhesive tape
FM ANT
1
( )
GND
AM ANT
LOOP
EXT
2
FM indoor antenna
AM loop
antenna
broadcast station. Then, turn the antenna to the angle of best
reception and least interference.
Connect the speaker cables.
Connect each end of the speaker cables to the terminal lever of
the same color.
Caution
Use only the supplied speakers.
•
The combination of the main unit and speakers provide the
best sound. Using other speakers can damage the unit and
sound quality will be negatively affected.
To prevent damage to circuitry, never short-circuit positive (+)
•
and negative (–) speaker wires.
Caution
• Use the speakers only with the re-
commended system.
Failure to do so may lead to damage to the
amplifier and/or the speakers, and may result
in the risk of fire.
Consult a qualified service person if damage
has occurred or if you experience a sudden
change in performance.
• Do not attach these speakers to walls or
ceilings.
RQT5539
Connect the AC power cord.
Red (+)
Black (–)
Note
The included AC power supply cord is for use with this unit
only. Do not use it with other equipment.
6
Connections
A
B
75 Ω coaxial cable (not included)
FM ANT
( )
GND
1
2
3
AM outdoor antenna (not included)
5 -12 m
(16 – 40
ft.)
AM ANT
LOOP
EXT
FM outdoor antenna
(not included)
30 mm
3/16˝)
(1
Shield braid
15 mm
19
/
˝)
(
32
Core wire
AM loop antenna
(included)
Optional antenna connections
You may need an outdoor antenna if you use this system in a
mountainous region or inside a reinforced-concrete building, etc.
FM outdoor antenna A
Disconnect the FM indoor antenna if an FM outdoor antenna is installed.
1 Remove a piece of the outer vinyl insulator.
2 Twist the shield braid.
3 Expose the core wire.
Note
An outdoor antenna should be installed by a qualified technician only.
AM outdoor antenna B
Connect the outdoor antenna without removing the AM loop antenna.
Run 5 to 12
other convenient location.
Note
When the unit is not in use, disconnect the outdoor antenna to prevent
possible damage that may be caused by lightning. Never use an
outdoor antenna during an electrical storm.
External unit connection
An analog player with a built-in phono equalizer can be connected.
•
For details, refer to the instruction manual of the units which are to
•
be connected.
When units other than those described above are to be connected,
•
please consult with your audio dealer.
m of vinyl-covered wire horizontally along a window or
C
Before using
C
R L
Analog player (not included)
(L)(R)
Rear panel of this unit
7
RQT5539
Front panel controls
A
1
2
3
4
5
6
Before using
7
B
10
11
12
13
15
16
17
Main unit A
8
9
14
No. Name Ref. page
1 MODE button (NORMAL/ECO) (MODE) ................... 10
2 Standby/on switch (f/I, POWER)............................. 10
Press to switch the unit from on to standby mode or vice versa.
In standby mode, the unit is still consuming a small amount of
power.
3 AC supply indicator (AC IN)
This indicator lights when the unit is connected to the AC mains
supply.
4 Play timer/record timer button and indicator
(rPLAY/rREC) ..........................................................27
5 Clock/timer button
(CLOCK/TIMER)..............................................11, 27, 28
6 Display
7 Deck 1 cassette holder..............................................19
8 Disc direct play, open/close buttons and indicators
(CD 1 ~ CD 5, c) ........................................................15
9 CD manager button
(CD MANAGER) ...................................................18, 24
! Random play button (RANDOM).............................. 16
Disc tray
# Display select/demonstration button
(-DISP/–DEMO) .................................................... 10, 11
$ V.BASS on/off button (V.BASS)............................... 25
% Volume control (VOLUME) ....................................... 13
& 3D AI EQ button (3D AI EQ) ..................................... 26
( Headphone jack (PHONES) ...................................... 29
) Deck 2 cassette holder..............................................19
18 19 20 21
22 26252423 27 28
Center console B
No. Name Ref. page
~ Tape/deck select button (TAPE, DECK 1/2) ............ 19
+ CD button (CD)...........................................................18
, Tuner/band select button (TUNER, BAND) ............. 12
- AUX button (AUX) ......................................................29
. Deck 1 open button (c DECK 1 OPEN) .................. 19
/ Basic operating buttons
Functions change according to the source.
: Tape edit button (TAPE EDIT).................................. 21
; Recording start/stop button (a REC/STOP)............ 22
< Reverse mode select button (REV MODE).............. 19
= Deck 2 open button (c DECK 2 OPEN) .................. 19
> Sound equalizer control (SOUND EQ)..................... 25
RQT5539
8
29
32
19
15
34
30
31
18
33
13
14
Front panel controls
Remote control
Buttons such as 2 functions in exactly the same way as the buttons
on the main unit.
No. Name Ref. page
2 Standby/on button (f) ...............................................10
? Auto off button (AUTO OFF) .................................... 10
@ Numeric buttons (≥10, 1–0) ................................ 13, 16
[ Program button (PROGRAM) ................................... 17
35
2
36
37
10
38
21
20
39
40
41
\ Cancel button (CANCEL)...........................................17
~ Tape/deck select button (TAPE) .............................. 19
+ CD button (CD)...........................................................18
] EQ select button (EQ)................................................25
& 3D AI EQ select button (3D AI) ................................ 26
$ V.BASS on/off button (V.BASS)............................... 25
^ Reverse side playback/preset channel
select button (//3).............................................13, 19
% Volume buttons (– VOLUME +)................................ 13
_ Sleep button (SLEEP) ................................................29
{ Muting button (MUTING) ...........................................11
| Disc button (DISC) .....................................................16
! Random button (RANDOM) ...................................... 16
} Repeat button (REPEAT)...........................................16
- AUX button (AUX) ......................................................29
, Tuner/band select button (TUNER) ......................... 12
gg
((
))
V Skip/search buttons (
0 Play/pause/preset channel select
button (-/J/4) ..............................................13, 15, 19
1 Stop button (L) ....................................................15, 19
g/
gg
(,
((
ff
)/
f)........ 15, 20
))
ff
Before using
9
RQT5539
Turning the demo function off
A
A
Before using
B
If the clock has not been set, a demonstration of the display is shown
when the unit is switched to standby.
This function is set to on at the time of purchase.
Turn this function off to get the most from the eco mode (see below).
Press and hold [-DISP/–DEMO] until “NO DEMO” is displayed.
The display changes each time the button is held down.
NO DEMO (off) ↔ DEMO (on)
ECO mode
When this mode is used, the display remains blank when the unit is
switched to standby mode and the power consumed is reduced to
0.25 W from a maximum of 18 W.
The mode is set to on at the time of purchase.
ECO mode
Note
To get the most from this mode, turn the demo function off or set the
clock.
Turning ECO on and off
B
Condition in standby
off clock 18 W
on blank 0.25 W
Display Power consumption
Press [f/7, POWER] to turn the unit on.
Press [MODE].
The current ECO mode is displayed. Press again to change the mode.
The display changes each time the button is pressed.
NORMAL (off) ↔ ECO (on)
The eco mode can be turned on if the unit is in standby but it cannot
be turned off.
Conserving Power
The unit consumes 0.25 W even when it is turned off with [f/7, POWER]
or Auto-off function and ECO mode is turned on. To save power when
the unit is not to be used for a long time, unplug it from the household
AC outlet. Remember to reset the radio stations and any other memory
items before using the unit again.
10
RQT5539
C
Auto-off function
by remote control only
When CD or tape is selected as the source
To save power, the unit turns off if it is left unused for four minutes.
Note
This function does not work if the source is tuner or AUX.
Press [AUTO OFF].
“AUTO OFF” is shown on the display.
To cancel
Press [AUTO OFF] again to clear “AUTO OFF” from the display.
For your reference
The setting is maintained even if the unit is turned off. When the unit
is turned on again, “AUTO OFF” is displayed and the unit functions as
described above.
“AUTO OFF” disappears from the display if either tuner or AUX is
selected as the source but continues to function normally.
“AUTO OFF” remains displayed if CD or tape is selected as the source.
C
Loading...
