Panasonic HDC-HS250PC User Manual

VQT1Y31

For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or, contact us via the web at: http://www.panasonic.com/contactinfo

For Canadian assistance, please call: 1-800-561-5505 or visit us at www.panasonic.ca

High Definition Video Camera

Operating Instructions

Model No.

HDC-HS250P/PC

Before connecting, operating or adjusting this product, please read the instructions completely. Spanish Quick Use Guide is included. Guía para rápida consulta en español está incluida.

Things You Should Know

Date of Purchase Dealer Purchased From Dealer Address Dealer Phone No. Model No. Serial No.

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products on the market today. Used properly, we’re sure it will bring you and your family years of enjoyment. Please take time to fill in the information on the right. The serial number is on the tag located on the back of your camera. Be sure to retain this manual as your convenient camera information source.

Safety Precautions

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, ≥ DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND

THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

≥ USE ONLY THE RECOMMENDED ACCESSORIES. ≥ DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION!

DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THA T CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.

The socket outlet shall be installed near the equipment and easily accessible. The mains plug of the power supply cord shall remain readily operable. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from AC receptacle.

The following mark and symbols are located on bottom of the unit.

The lightning flash with arrowhead symbol, within an equilateral

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE SCREWS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

VQT1Y31

THE FOLLOWING APPLIES ONLY IN THE U.S.A.

FCC Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

≥ Reorient or relocate the receiving antenna. ≥ Increase the separation between the equipment and receiver. ≥ Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

≥ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: T o assure continued compliance, follow the attached installation instructions

and use only shielded interface cables with ferrite core when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this

equipment. Declaration of Conformity Trade Name: Panasonic Model No.: HDC-HS250P Responsible party: Panasonic Corporation of North America

One Panasonic Way, Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company

1-800-211-PANA (7262) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

HDC-HS250P

THE FOLLOWING APPLIES ONLY IN CANADA.

This Class B digital apparatus complies with Canadian ICES-003.

VQT1Y31

Batteries

A lithium ion/polymer battery that is recyclable powers the product you have purchased. Please call 1-800-8-BATTERY for information on how to recycle this battery.

U.S.A./CANADA CONSUMERS: ATTENTION:

1 Battery pack (Lithium ion battery pack)

≥ Use the specified unit to recharge the battery pack. ≥ Do not use the battery pack with equipment other than the specified unit. ≥ Do not get dirt, sand, liquids, or other foreign matter on the terminals. ≥ Do not touch the plug terminals (i and j) with metal objects. ≥ Do not disassemble, remodel, heat or throw into fire.

2 Button-type battery (Lithium battery)

≥ Insert with poles aligned. ≥ Do not touch the terminals (i and j) with metal objects. ≥ Do not recharge, disassemble, remodel, heat or throw into fire. ≥ Keep out of reach of children

If any electrolyte should come into contact with your hands or clothes, wash it off thoroughly with water. If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse eyes thoroughly with water, and then consult a doctor.

Warning

Risk of fire, explosion and burns. Do not disassemble. Do not heat the batteries above the following temperatures or incinerate.

Button-type battery 60 oC (140 oF) Battery pack 60 oC (140 oF)

AC adaptor

This AC adaptor operates on AC between 110 V and 240 V. But

≥ In the U.S.A. and Canada, the AC adaptor must be connected to a 120V AC power supply only . ≥ When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to suit the

AC outlet configuration.

≥ When connecting to a supply of greater than AC 125V, ensure the cord you use is suited to the

voltage of the AC supply and the rated current of the AC adaptor.

≥ Contact an electrical parts distributor for assistance in selecting a suitable AC plug adaptor or AC

cord set.

Product Identification Marking is located on the bottom of units.

This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate

VQT1Y31

IMPORTANT SAFETY INSTRUCTIONS

Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

VQT1Y31

Precautions

WARNING

CAUTION

USE & LOCATION

≥ TO AVOID SHOCK HAZARD ... Your camera

and power supply should not be exposed to rain or moisture. Do not connect the power supply or operate your camera if it gets wet. Your camera has been designed for outdoor use, however it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a direct splashing from a pool or even a cup of coffee. This action could permanently damage the internal parts of your camera. Do not attempt to disassemble this unit. There are no user serviceable parts inside. Unplug your camera from the power supply before cleaning.

≥ AS WITH ANY SMALL OBJECT , SD CARDS

CAN BE SWALLOWED BY YOUNG CHILDREN. DO NOT ALLOW CHILDREN TO HANDLE THE SD CARD.

≥ DO NOT AIM YOUR CAMERA AT THE SUN

OR OTHER BRIGHT OBJECTS

≥ DO NOT LEAV E THE CAMERA WITH THE

EVF AIMED DIRECTLY AT THE SUN AS THIS MAY CAUSE DAMAGE TO THE INTERNAL PARTS OF THE EVF

≥ DO NOT EXPOSE YOUR CAMERA TO

EXTENDED HIGH TEMPERATURE ... Such

as, in direct sunlight, inside a closed car, next to a heater, etc... This action could permanently damage the internal parts of your camera.

≥ AVOID SUDDEN CHANGES IN

TEMPERATURE ... If the unit is suddenly

moved from a cold place to a warm place, moisture may form on the SD card and inside the unit.

≥ DO NOT LEAVE YOUR CAMERA OR THE

POWER SUPPL Y TURNED ON WHEN NOT IN USE.

≥ STORAGE OF YOUR CAMERA ... Store and

handle your camera in a manner that will not subject it to unnecessary movement (avoid shaking and striking). Your camera contains a sensitive pick-up device which could be damaged by improper handling or storage.

CARE

≥ TO CLEAN YOUR CAMERA ... Do not use

strong or abrasive detergents when cleaning your camera body.

≥ TO PROTECT THE LENS ... Do not touch the

surface of the lens with your hand. Use a commercial camera lens solution and lens paper when cleaning the lens. Improper cleaning can scratch the lens coating.

≥ TO PROTECT TH E FINISH OF YOUR

CAMERA ... Before handling your camera,

make sure your hands and face are free from any chemical products, such as suntan lotion, as it may damage the finish.

-If you see this symbolInformation on Disposal in other Countries

outside the European Union

This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

∫ Indemnity concerning recording

content

The manufacturer shall in no event be liable for the loss of recordings due to malfunction or defect of this unit, its accessories or recordable media.

IMPORTANT ∫ Carefully observe copyright laws

Whatever you have recorded and created can be used for your personal entertainment only. Under copyright laws, other materials cannot be used without obtaining permission from the holders of the copyrights.

VQT1Y31

∫ Cards that you can use with this

unit

SD Memory Card and SDHC Memory Card

≥ 4 GB (or more) Memory Cards that do not have

the SDHC logo are not based on SD Memory Card Specifications.

≥ Refer to page 24 for more details on SD cards.

∫ For the purposes of these

operating instructions

≥ SD Memory Card and SDHC Memory Card are

referred to as the “SD card”.

≥ Functions that can be used for motion picture

recording/motion picture playback are indicated by in these operating instructions.

≥ Functions that can be used for still picture

recording/still picture playback are indicated by

≥ “HD Writer AE 1.0 for HDC” is referred to as

≥ Pages for reference are indicated by an arrow,

in these operating instructions.

the “HD Writer AE 1.0”.

for example: l 00

∫ Licenses

≥ SDHC Logo is a trademark. ≥ “A VCHD” and the “AVCHD” Logo are

trademarks of Panasonic Corporation and Sony Corporation.

≥ Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

≥ HDMI, the HDMI Logo and the High-Definition

Multimedia Interface are the registered trademarks or trademarks of HDMI Licensing LLC.

≥ VIERA Link™ is a trademark of Panasonic

Corporation.

≥ EZ Sync™ is a trademark of Panasonic

Corporation.

≥ HDA VI Control™ is a trademark of Panasonic

Corporation.

≥ “x.v.Color” is trademark. ≥ LEICA is a registered trademark of Leica

Microsystems IR GmbH and DICOMAR is a registered trademark of Leica Camera AG.

≥ Microsoft

DirectX trademarks of the Microsoft Corporation in the United States and/or other countries.

, Windows®, Windows Vista® and

are either registered trademarks or

≥ Microsoft product screen shot(s) reprinted with

permission from Microsoft Corporation.

≥ IBM and PC/AT are registered trademarks of

International Business Machines Corporation of the U.S.

, Core™, Pentium® and Celeron® are the

≥ Intel

registered trademarks or trademarks of the Intel Corporation in the United S tat es and other countries.

≥ AMD Athlon

Micro Devices, Inc.

≥ Apple, Mac OS, and iMovie are either

registered trademarks or trademarks of Apple Inc. in the United States and/or other countries.

≥ PowerPC is a trademark of International

Business Machines Corporation.

≥ Other names of systems and products

mentioned in these instructions are usually the registered trademarks or trademarks of the manufacturers who developed the system or product concerned.

This product is licensed under the AVC patent portfolio license for the personal and noncommercial use of a consumer to (i) encode video in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to provide AVC Video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC. See http://www.mpegla.com

™

is a trademark of the Advanced

VQT1Y31

Contents

Accessories................................................. . 10

Features........................................................ 11

Quick Guide.................................................. 12

Preparation

Before using

[1] Handling of HDD

(Hard disk drive)................................ 15

[2] Parts identificatio n a nd ha ndling..... 17

Setup

[1] Power supply......................... ............ 20

Charging the battery............................ 20

Inserting/removing the battery............. 21

Charging and recording time............... 22

Connecting to the AC outlet................. 23

[2] Preparation of SD cards.................... 24

Cards that you can use with this unit... 24

Inserting/remov i ng an SD card............ 25

[3] Selecting a mode

(Turning the unit on/off).................... 26

Turning the power on and off with

the LCD monitor.................................. 26

[4] How to use the touch screen............ 27

[5] Using the menu screen..................... 28

Language selection ............................. 29

Menu list.............................................. 29

[6] Setting date and time........................ 33

World time setting (Displaying the

time of the travel destination) .............. 34

[7] Adjusting LCD monitor..... ................ 35

LCD monitor adjustment............. ......... 35

Touch screen calibration...................... 36

Recording Yourself.............................. 36

[8] Using with the remote control.......... 37

Operation of direction buttons/

OK button............................................ 38

Recording

Recording (Basic)

[1] Before recording............................... 39

Intelligent auto mode........................... 40

Quick start........................................... 42

Quick power on ................................... 43

[2] Recording motion pictures.............. 44

Recording modes/approximate

recordable time ................................... 46

PRE-REC............................................ 47

Shooting guide.................................... 47

[3] Recording still pictures .................... 48

Aspect ratio/Picture size...................... 49

Picture qual it y........ .. ............................ 50

Recording still pictures in Motion

Picture Recording Mode...................... 50

Number of recordable pictures............ 51

[4] Zoom in /out functio n .......... .. ............ 5 4

Digital zoom fu n ction....... .................... 54

Extra Optical Zoom ............................. 54

[5] Optical image stabilizer function..... 55

[6] AF tracking ........................................ 56

Recording (Advanced)

[1] Recording functions of operation

icons................................................... 58

Operation icons................................... 58

[2] Recording functions of menus........ 62

[3] Manual recording.............................. 70

White balance..................................... 71

Manual shutter speed/

iris adjustment..................................... 72

Manual focus adjustment.................... 73

Picture adju s tment ...... ........................ 73

VQT1Y31

Playback

With a PC

Playback

[1] Motion picture playback................... 74

Creating still picture from motion

picture............... ................. ................. . 77

Highlight&Time frame index................. 77

Playing back motion pictures by date

Intelligent scene selection ................... 78

Highlight playback............................... 79

Repeat playback.................................. 80

Resuming the previous playback......... 80

[2] Still picture playback......................... 81

Playing back still pictures by date........ 83

Editing

[1] Deleting scenes/still pictures ........... 84

[2] Dividing a scene to partially

delete.................... ................ .............. 86

[3] Protecting scenes/still pictures ....... 87

[4] DPOF setting...................................... 88

[5] Copying between SD card and

HDD..................................... ................ 89

Confirming remaining capacity on the

copy destination..... ................ .............. 89

Copying ........................... ................. ... 90

[6] Formatting..................................... ..... 92

With a TV

[1] Watching Video/Pictures on

your TV............................................... 93

Connecting with a HDMI mini cable..... 96

Listening in 5.1 channel sound............ 97

Connecting with the component

cable............................................. ....... 97

[2] Playback using VIERA Link

(HDAVI Control

™

)............................... 98

™

Backup

With other products

[1] Connecting a DVD burner to copy to/

play back a disc............................... 100

Preparing for copying/playing back

Copying to discs................................ 102

Playing back the copied disc ............. 105

Managing the copied disc (Formatting, Auto protect,

Displaying disc information)............... 106

[2] Dubbing images onto other video

devices......................... ................. ... 107

[3] With a printer (PictBridge).............. 108

..... 100

..... 78

Before using

[1] What you can do with a PC...... ....... 111

End User License Agreement........... 113

[2] Operating environment................... 114

Setup

[1] Installation....................................... 117

[2] Connecting to a PC......................... 119

About the PC display......................... 121

Using with a PC

[1] Starting HD Writer AE 1.0............... 122

Reading the operating instructions of

the software applications................... 122

[2] If usin g Macintosh ........................... 123

Others

Indications

[1] Indications....................................... 124

[2] Messages......................................... 127

About recovery.................................. 128

Helpful hints

[1] Functions that cannot be used

simultaneous l y ................................ 129

[2] Troubleshooting.............................. 131

Cautions for use........................................ 138

Specifications............................................ 141

Optional accessories................................ 144

Accessory Order Form (For USA and

Puerto Rico Customers) .................... 146

Request for Service Notice (USA and

Puerto Rico Only)...................................... 147

Limited Warr a nty (United State s an d

Puerto Rico)...................... ................. ........ 148

Customer Services Directory

(United States and Puerto Rico)............... 149

Warranty (For Canadian Customers)....... 150

Index........................................................... 151

Spanish Quick Use Guide/Guía española

para el uso rápi do..... ................. ............... 153

PreparationRecordingPlaybackBackupWith a PCOthers

VQT1Y31

Accessories

Check the accessories before using this unit.

Battery pack

VW-VBG130

AC adaptor

VSK0697

AC cable

K2CA2CA00025

DC cable

K2GJYDC00004

Remote control (Built-in battery)

N2QAEC000024

AV cable

K2KYYYY00054

Component cable

K1HY10YY0005

USB cable

K1HY04YY0032

Stylus pen

VFC4394

CD-ROM

VQT1Y31

Features





∫ Very cle ar high definition pictures

This unit can record detailed high definition images.

High definition images (1920k1080)

A Number of available scan lines 1080 * If the recording mode is HA/HG/HX.

Standard images (720k480)

B Number of available scan lines 480

What is AVCHD?

This is a format for recording and playing back highly detailed high definition images. Images are recorded based on the MPEG-4 AVC/H.264 codec for compressing images and audio is recorded with the Dolby Digital 5.1 Creator.

≥ Since the recording method is different from an ordinary DVD video etc., the data is not compatible.

∫ Compatibility with other products

With other products Available function Picture quality

Watching Video/ Pictures on your TV (l 93 to 99)

Using a DVD burner (l 100 to 106)

What you can do with a PC (l 111 to 112)

Dubbing images onto other video devices (l 107)

Playback with the HDMI mini cable

jPlayback using VIERA Link™ (HDAVI

Control™) (l 98) Playback with the component cable [1080i] Playback with the component cable [480i] Standard images Playback with the AV cable Connecting a DVD burner to copy to/play back a

disc

jPlaying back the copied disc (l 105)

Copying data to a PC and editing Writing data to BD/DVD discs and SD cards Converting the motion picture data to MPEG2 Standard images Creating a DVD Video disc Dubbing images when connecting with the AV cable S tandard images

High definition images

Standard images High definition

images

VQT1Y31

Quick Guide

Charging lamp [CHARGE] A

Lights up:

Charging

Goes off:

Charging completed

∫ Charging the battery

1 Connect the AC cable to the AC adaptor and

the AC outlet.

2 Insert the battery into the AC adaptor by

aligning the arrows.

∫ Inserting the battery

Install the battery by inserting it in the direction shown in the figure.

A Insert the battery until it clicks and locks.

∫ Inserting/removing an SD card

Access lamp [ACCESS] A

≥ When this unit is accessing the SD card, the

access lamp lights up.

1) Open the LCD monitor. ≥ Check that the access lamp has gone off.

2) Open the SD card cover by sliding the OPEN lever B.

3) Insert/remove the SD card.

≥ Face the label side C in the direction shown in

the illustration and press it straight in as far as it will go.

≥ Press the center of the SD card and then pull it

straight out.

4) Securely close the SD card cover.

≥ Securely close it until it clicks.

VQT1Y31

∫ How to turn on the power

≥ Rotate the mode dial while at the same

time pressing in the lock release button if changing from OFF to another mode.

≥ Align with the status indicator B.

OFF

Turn on the power by changing the mode to ,

or while pressing the lock release

button A.

∫ Recording motion pictures

1) Change the mode to .

2) Open the LCD monitor.

3) Press the MENU button, then touch [MEDIA SELECT] # [HDD] or [SD CARD].

4) Press the recording start/stop button to start recording.

≥ To turn off the power, change the mode to

OFF.

∫ How to use the touch screen

You can operate by directly touching the LCD monitor (touch screen) with your finger. It is easier to use the stylus pen (supplied) for detailed operation or if it is hard to operate with your fingers.

Touch and release the touch screen to select icon or picture.

∫ Language selection

1) Press the MENU button, then touch [SETUP] # [LANGUAGE].

2) Touch [English].

∫ Recording still pictures

1) Change the mode to .

2) Open the LCD monitor.

3) Press the MENU button, then touch [MEDIA SELECT] # [HDD] or [SD CARD].

4) Press the button fully to take the picture.

VQT1Y31

∫ Motion picture playback

0h00m00s0h00m00s0h00m00s

1) Change the mode to .

2) Touch the play mode select icon A to select desired media to be played back.

∫ Still picture playback

1) Change the mode to .

2) Touch the play mode select icon A to sele ct desired media to be played back.

≥ Touch [VIDEO/SD CARD ] to play back the SD

card. Touch [VIDEO/HDD] to play back the HDD.

3) Touch the scene to be played back.

4) Select the playback operation by touching the operation icon.

1/;: Playback/Pause 6: Rewind playback 5: Fast forward playback ∫: Stops the playback and shows the

thumbnails.

≥ Touch [PICTURE/SD CARD] to play back the

SD card. Touch [PICTURE/HDD] to play back the HDD.

3) Touch the still picture to be played back.

4) Select the playback operation by touching the operation icon.

1/;: Slide show (playback of the still pictures

in numerical order) start/pause.

2;: Plays back the previous picture. ;1: Plays back the next picture. ∫: Stops the playback and shows the

thumbnails.

VQT1Y31

Preparation

Before using

This unit is equipped with the built-in 120 GB HDD. While the HDD is capable of storing a large amount of data, there are a few things to look out for. When using this component, pay att ention to the following points.

Handling of HDD (Hard disk drive)

Indemnity about recorded content

Panasonic does not accept any responsibility for damages directly or indirectly due to any type of problems that result in loss of recording or edited content, and does not guarantee any content if recording or editing does not work properly. Likewise, the above also applies in a case where any type of repair is made to the unit (including any other non-HDD related component).

∫ Do not expose the HDD to

vibrations and shocks.

Due to the environment and handling conditions, the HDD may be subject to partial damages or may not be able to read, record, and play back data. Do not expose the unit to vibrations or shock, and do not turn off the power during recording or playback.

If the unit is used in a place with loud sounds, such as a club or similar venue, the recording may stop due to sound vibrations. Recording data on an SD card is recommended in these places.

∫ Back up data periodically.

The HDD is temporary storage. In order to avoid erasing data due to static electricity, electromagnetic waves, breakage, and failures, back up the data to a PC or DVD disc. (l 100,

111)

∫ Operation may stop in hot or cold

environments.

The unit is disabled in order to protect the HDD.

∫ Do not use the unit in low

atmospheric pressures.

The HDD may fail if it is used at altitudes of 3000 m (9800 feet) or higher above sea level.

∫ Transportation

When the unit is transported, turn off the power and be careful not to shake, drop, or cause impact to the unit.

∫ Falling detection

[ ] is indicated on the screen when it detects a falling state (a weightless state). If the falling state is detected repeatedly, the unit may stop the recording or playback operation in order to protect the HDD.

∫ If the HDD experiences any

abnormality, back up data immediately.

Failure in the HDD may produce continuous noise or choppy sound during recording or playing back. Continuous use will cause further deterioration, and may eventually disable the HDD. If these phenomena are observed, copy the data on the HDD to a PC, a DVD disc etc. immediately and contact consumer support. (l 149, 150) Once the HDD is out of order, data cannot be restored.

VQT1Y31

∫ HDD access lamp [ACCESS HDD]

≥ The lamp illuminates while the HDD is being

accessed (initialization, recording, playback, deleting etc.).

≥ Do not perform the following operations when

the lamp illuminates. It may damage the HDD or cause a malfunction in the unit.

jTurn the unit off jInsert and remove the USB cable jExpose the unit to vibrations or shock

≥ About disposing of or giving away this unit.

(l 139)

VQT1Y31

Preparation

A/V

16 17 18

2345

8 9

19 20 21

11 12 13 14 15

Before using

1 LCD monitor (Touch screen) (l 27, 35)

≥ It can open up to 90o.

≥ It can rotate up to 180o A towards the lens or

90o B towards the opposite direction.

Due to limitations in LCD production technology, there may be some tiny bright or dark spots on the LCD monitor screen. However, this is not a malfunction and does not affect the recorded picture.

Parts identification and handling

2 Manual button [MANUAL] (l 70) 3 Optical image stabilizer button

[ , O.I.S.] (l 55)

4 Inlet (cooling fa n)

≥ The cooling fan rotates to prevent the internal

temperature from rising. Take care not to cover the inlet when using this unit.

5 Speaker 6 Intelligent auto button [iA] (l 40) 7 PRE-REC button [PRE-REC] (l 47) 8 Battery holder (l 21) 9 DC input terminal [DC IN] (l 23)

≥ Always use the supplied AC adaptor or a

genuine Panasonic AC adaptor (VW-AD21PP; optional).

10 USB terminal [ ] (l 100, 108, 119) 11 Sub recording start/stop button (l 39)

≥ This button functions in the same manner as

the recording start/stop button.

VQT1Y31

12 Zoom buttons (l 54)

22 23

25 2627

These buttons function in the same manner as

≥

the zoom lever. Changing the thumbnail display and adjusting the volume can be done.

13 Menu button [MENU] (l 28) 14 Delete button [ ] (l 84) 15 SD card open lever [OPEN] (l 25) 16 Audio-video output term inal [A/V]

(l 93, 107)

≥ Use the AV cable (only the supplied cable).

17 Component terminal [COMPONENT] (l93) 18 HDMI mini connector [HDMI] (l 93, 98) 19 Access lamp [ACCESS] (l 25) 20 Card slot (l 25) 21 SD card cover (l 25)

22 Built-in flash (l 60) 23 Lens (LEICA DICOMAR)

Lens cover A

≥The lens cover opens in

Motion Picture Recording Mode or Still Picture Recording Mode. (l 26)

24 Lens hood

Rotate the lens hood counter-clockwise A to remove it. In order to attach it, place into slot B, and then rotate it clockwise C.

VQT1Y31

≥ When fitting the tele conversion lens

(VW-T4314H; optional) or the wide conversion lens (VW-W4307H; optional), first remove the lens hood.

25 Remote control sensor (l 38) 26 Recording lamp (l 30) 27 AF assist lamp (l 68)

28 Recording start/stop button (l 44)

3536

3231

29 Status indicator (l 26) 30 Mode dial (l 26) 31 HDD access lamp [ACCESS HDD] (l 16) 32 Photoshot button [ ] (l 48) 33 Zoom lever [W/T] (In Recording Mode)

(l 54) Thumbnail display switch/Volume lever [s /VOLr] (In Playback Mode) (l 75)

34 Internal microphones (5.1 channel

support)

35 Grip belt

Adjust the length of the grip belt so that it fit s your hand.

1 Flip the belt. 2 Adjust the length. 3 Replace the belt.

36 Shoulder strap fixture

37 38

37 Battery release lever [BATT] (l 21) 38 Tripod receptacle

This is a hole for attaching the unit to the optional tripod. (For details on mounting the tripod, refer to the operating instructions for the tripod.)

A Camera base

VQT1Y31

Preparation

Charging lamp [CHARGE] A

Lights up:

Charging (Battery charging time: l 22)

Goes off:

Charging completed

Flashing:

Make sure that the terminals of the battery or the AC adaptor are not exposed to dirt, foreign objects or dust, then reconnect them properly. (l 140)

Setup

Power supply

∫ About batteries that you can use with this unit

The battery that can be used with this unit is VW-VBG130/VW-VBG260/VW-VBG6. ≥ This unit has a function to distinguish the batteries that can be used, and the batteries

(VW-VBG130/VW-VBG260/VW-VBG6) are compatible with this function. (The batteries that are not compatible to this function cannot be used.)

≥ To use the VW-VBG6 for this unit, the battery pack holder kit VW-VH04 (optional) is required.

It has been found that counterfeit battery packs which look very similar to the genuine product are made available to purchase in some markets. Some of these battery packs are not adequately protected with internal protection to meet the requirements of appropriate safety standards. There is a possibility that these battery packs may lead to fire or explosion. Please be advised that we are not liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that safe products are used we would recommend that a genuine Panasonic battery pack is used.

Charging the battery

When this unit is purchased, the battery is not charged. Charge the battery before using this unit.

Important: If the DC cable is connected to the AC adaptor, then the battery will not charge. Remove the DC cable from the AC adaptor.

1 Connect the AC cable to the AC adaptor and the AC outlet. 2 Insert the battery into the AC adaptor by aligning the arrows.

VQT1Y31

≥ We recommend using Panasonic batteries (l 10, 22, 144).

Removing the battery

Make sure that the power is off and that the status indicator is turned off, and then remove by holding onto it taking care not to drop.

Move the BATTERY lever in the direction indicated by the arrow and remove the battery when unlocked.

BATT

A Insert the battery until it clicks and locks.

≥ If you use other batteries, we cannot guarantee the quality of this product. ≥ Do not heat or expose to flame. ≥ Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period of time with

doors and windows closed.

Inserting/removing the battery

Install the battery by inserting it in the direction shown in the figure.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

VQT1Y31

Charging and recording time

∫ Charging/Recording time ≥ Temperature: 25 oC (77 oF)/humidity: 60%

Battery model

number

[Voltage/Capacity

(minimum)]

Supplied battery/

VW-VBG130

(optional)

[7.2 V/1250 mAh]

VW-VBG260

(optional)

[7.2 V/2500 mAh]

VW-VBG6 (optional)

[7.2 V/5400 mAh]

* The battery pack holder kit VW-VH04 (optional) is necessary.

≥ These times are approximations. ≥ The indicated charging time is for when the battery has been discharged completely. Charging

time and recordable time vary depending on the usage conditions such as high/low temperature.

≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping recording,

turning the unit on/off, moving the zoom lever etc.

≥ The batteries heat up after use or charging. This is not a malfunction.

Charging

time

2h35min

4h40min

9h25min

Recording

destination

HDD

Recording

mode

HA/HG/HX/

HA/HG/HX 3 h

HE 3h5min

HA/HG/HX/

Maximum

continuously

recordable time

1h35min 55min

1h40min 1h

3h10min 2h

7h35min 4h40min

7h55min 4h55min

Actual

recordable

1h50min

time

Battery capacity indication

≥ The display changes as the battery capacity reduces. ####

If there is less than 3 minutes remaining, then will become red. If the battery discharges, then ( ) will flash.

≥ The remaining battery capacity is displayed when using the Panasonic battery that you can use for

this unit. It may take time to display the remaining battery capacity. The actual time can vary depending on your actual use.

≥ The maximum amount of remaining battery capacity able to be indicated is 9 hours 59 minutes. If

the actual remaining time exceeds 9 hours 59 minutes, the indication will stay green and will not change until the remaining time falls below 9 hours 59 minutes.

≥ When changing modes, the time indication will turn off momentarily in order to recalculate the

remaining battery capacity time.

≥ When using the AC adaptor or batteries made by other companies, the remaining battery capacity

will not be shown.

VQT1Y31

Connecting to the AC outlet



Important: While the DC cable is connected to the AC adaptor, the battery will not charge. ≥ Do not use the AC cable with any other equipment as it is designed only for this unit. Also, do

not use the AC cable from other equipment with this unit.

DC IN



A DC output terminal B DC input terminal

Insert the DC cable matching the [ ] mar k of the DC input terminal.



1 Connect the AC cable to the AC adaptor and the AC outlet. 2 Connect the DC cable to the AC adaptor. 3 Connect the DC cable to the DC input terminal [DC IN].

≥ Make sure to set the mode to OFF and that the status indicator is turned off when disconnecting the

AC adaptor.

VQT1Y31

Preparation

Setup

Preparation of SD cards

This unit (an SDHC compatible device) is compatible with both SD Memory Cards and SDHC Memory Cards. When using an SDHC Memory Card on another device, confirm that the device supports the SDHC Memory Card.

Cards that you can use with this unit

Use SD cards conforming to Class 4 or higher of the SD Speed Class Rating* for motion picture recording.

Card type Capacity

8MB

16 MB 32 MB

SD Memory

Card

SDHC

Memory

Card

* The SD Speed Class Rating is the speed standard for successive writes.

64 MB 128 MB 256 MB 512 MB

1 GB RP-SDV01G 2 GB RP-SDV02G, RP-SDM02G 4 GB RP-SDV04G, RP-SDM04G 6 GB RP-SDM06G

8 GB RP-SDV08G 12 GB RP-SDM12G 16 GB RP-SDV16G 32 GB RP-SDV32G

The following models of Panasonic SD cards can be used.

Cannot be used. Can be

Cannot be guaranteed in operation. The recording may suddenly stop during motion picture recording depending on the SD card you use. (l 132)

Motion picture recording

Still pictur e

recording

used.

≥ 4 GB or more Memory Cards that do not have

the SDHC logo are not based on SD Memory Card Specifications.

≥ When the write-protect

switch A on SD card is locked, no recording, deletion or editing will be possible on the card.

≥ Keep the Memory Card out of reach of children

to prevent swallowing.

VQT1Y31

Inserting/removing an SD card

When using an SD card not from Panasonic, or one previously used on other equipment, for the first time on this unit, format the SD card. (l 92) When the SD card is formatted, all of the recorded data is deleted. Once the data is deleted, it cannot be restored. Copy valuable data onto a PC, DVD disc etc. before proceeding with the formatting. (l 100, 111)

Caution: When the SD card is removed while the access lamp is lit, this unit may malfunction or the data recorded on the SD card may be lost.

Access lamp [ACCESS] A

≥ When this unit is accessing the SD card, the

access lamp lights up.

1 Open the LCD monitor.

≥ Check that the access lamp has gone off.

2 Open the SD card cover by

sliding the OPEN lever B.

3 Insert/remove the SD card.

≥ Face the label side C in the direction shown in

the illustration and press it straight in as far as it will go.

≥ Press the center of the SD card and then pull it

straight out.

4 Securely close the SD card cover.

≥ Securely close it until it clicks.

≥ Do not touch the terminals on the back of the SD card. ≥ Do not apply strong shocks, bend, or drop the SD card. ≥ Electrical noise, static electricity or the failure of this unit or the SD card may damage or erase the

data stored on the SD card.

≥ When the card access lamp is lit, do not:

jRemove the SD card jTurn the unit off jInsert and remove the USB cable jExpose the unit to vibrations or shock

Performing the above while the lamp is on may result in damage to data/SD card or this unit.

VQT1Y31

Preparation

≥ Rotate the mode dial while at the same

time pressing in the lock release button if changing from OFF to another mode.

≥ Align with the status indicator B.

OFF



Setup

Change the mode to recording, playback or power OFF.

Selecting a mode (Turning the unit on/off)

Turn on the power by changing the mode to , or while pressing the lock release button A.

The status indicator lights.

To turn off the power

Change the mode to OFF. The status indicator goes off.

Motion Picture Recording Mode (l 44)

Still Picture Recording Mode (l 48)

Playback Mode (l 74, 81)

OFF

Turning the power on and off with the LCD monitor

When the mode is set to or , power is turned on when the LCD monitor is opened, and power is turned off when it is closed.

∫ To turn on the power



A The status indicator lights.

Change the mode to OFF when this unit is not being used.

VQT1Y31

∫ To turn off the power

A The status indicator goes off.

Preparation

Setup

How to use the touch screen

You can operate by directly touching the LCD monitor (touch screen) with your finger. It is easier to use the stylus pen (s upplied) for detail ed operation, or i f it is hard to operate w ith your fingers.

∫ Touch

Touch and release the touch screen to select icon or picture.

≥ Touch the center of the icon. ≥ Touching the touch screen will not operate

while you are touching another part of the touch screen.

∫ About the Stylus pen

The stylus pen (supplied) can be stored on the unit as shown when it is not being used. Remove the stylus pen from the unit when it is to be used.

∫ About the operation icons

///: These icons are used to switch between the menu and thumbnail display page, for item selection and setting etc.

: Touch to return to the previous screen such as when setting menus

≥ Only use the supplied stylus pen. ≥ Do not tuck the stylus pen with the LCD

monitor.

≥ Wipe the LCD monitor with a soft cloth, such

as eye glass cleaner, when it gets dirty with finger prints etc.

≥ Do not touch on the LCD monitor with hard

pointed tips, such as ball point pens.

≥ Do not touch the LCD monitor with your finger

nails, or rub or press with strong force.

≥ It may become hard to see or hard to

recognize the touch when the LCD protection sheet is affixed.

≥ Perform the touch screen calibration when the

touch is not recognized or wrong location is recognized. (l 36)

VQT1Y31

Preparation

Setup

Using the menu screen

A It is recommended to hold the LCD monitor with your thumb and index finger when pressing the

buttons on the LCD monitor.

1 Press the MENU button.

2 Touch the top menu A.

4 Touch the desired item to enter

the setting.

3 Touch the submenu B.

≥ Next (previous) page can be displayed by

touching / .

≥ Information display setting is completed when

is surrounded by yellow after touching it.

VQT1Y31

5 Touch [EXIT] or press the MENU

button to exit the menu setting.

∫ About information display

setting

An explanation or setting confirmation message of the submenu or item being touched gets displayed in step 3 and 4. Touch the to cancel the information display setting.

Language selection

You can select the language on the screen display and the menu screen.

1 Press the MENU button, then touch [SETUP] # [LANGUAGE]. 2 Touch [English].

Menu list

Part of the menu will not be used depending on the used functions. (l 129)

Motion Picture Recording Mode

*1 It is not displayed when the Intelligent Auto Mode is on. *2 When the [MEDIA SELECT] is set to [SD CARD] *3 It will be displayed only when the [MEDIA SE LECT] is set to [HDD].

RECORD SETUP

[SCENE MODE] (l 62) [D.ZOOM] (l 54) [GUIDE LINES] [REC MODE] (l 46) [DIGITAL CINEMA] [FADE] (l 59) [FADECOLOR] (l 59) [AGS] (l 63) [AUTO SLOW SHTR] [FACE FRAMING] (l 64) [BACKLIGHT COMPENS.] (l 59) [INTELLIGENT CONTRAST] [SOFT SKIN MODE]

(l 63)

(l 64)

(l 59) (l 59)

[TELE MACRO] (l 59) [MAGICPIX] [Digital Cinema Color] [SHOOTING GUIDE] (l 47) [WIND CUT] [MIC SETUP] [MIC LEVEL] [PICTURE ADJUST] [MF ASSIST]

(l 60) (l 64)

(l 64) (l 65) (l 66) (l 73) (l 73)

VQT1Y31


NOV 15 2009

0h00m00s

1h30m

R 1h20m

[PICTURE SIZE] (l 49) [QUALITY] (l 50) [HI-SPEED BURST]

(l 67) [SELF TIMER] (l 60) [FLASH] (l 60) [FLASH LEVEL] [RED EYE]

(l 60)

(l 61) [SHTR SOUND] (l 68)

MEDIA SELECT

Media to record can be set to [HDD] or [SD CARD].

SETUP

[DISPLAY] The screen indications are selected as shown in the illustration below.

[OFF] [ON]

[CLOCK SET] (l 33) [SET WORLD TIME] (l 34) [DATE/TIME] (l 33) [DATE FORMAT] (l 33) [ECONOMY]

[OFF]:

The power saving function is not activated.

[5 MINUTES]:

When about 5 minutes have passed without any operation, this unit automatically turns off to save battery life. ≥ The power save function will not activate

when:

jconnected to AC adaptor jusing the USB cable for PC, DVD

burner, printer etc.

jPRE-REC is used

[QUICK POWER ON]

(l 43) [QUICK START] (l 42) [REMOTE CONTROL] (l 37) [REC LAMP] The recording lamp lights up during

recording and flashes when the unit receives a signal from the remote control or when the self-timer is counting down. When this is set to [OFF], it does not light during recording.

VQT1Y31
