Owner’s Manual
High Definition Video Camera
Model No. HC-V210
HC-V201
HC-V210M
HC-V110
Please read these instructions carefully before using this product, and save this manual for future
use.
Register online at www.panasonic.com/register (U.S. customers only)
VQT4T63
Read this first
∫ About the recording format for
recording motion pictures
You can select from AVCHD*1, iFrame or MP4
recording formats to record motion pictures
using this unit. (l 49)
*1 / /
It is compatible with the AVCHD
Progressive (1080/60p).
AVCHD:
It is suitable for viewing on a high-definition TV
or for saving to disc
*2 / /
To save an image recorded in 1080/60p, it
is required to copy to a disc using the
supplied software HD Writer LE 2.0.
iFrame:
This is a recording format suitable for playing
back or editing on Mac (iMovie’11).
≥ It is not compatible with motion pictures
recorded in AVCHD format.
MP4:
This is a recording format suitable for playing
back or editing on a PC.
≥ It is not compatible with motion pictures
recorded in AVCHD format.
∫ Indemnity about recorded
content
Panasonic does not accept any responsibility
for damages directly or indirectly due to any
type of problems that result in loss of recording
or edited content, and does not guarantee any
content if recording or editing does not work
properly. Likewise, the above also applies in a
case where any type of repair is made to the
unit (incl uding any other non-b uilt-in memory
related component).
*2
.
∫ Handling of built-in memory
[HC-V210M]
This unit is equipped with the built-in memory.
When using this component, pay attention to
the following points.
Back up data periodically.
The built-in memory is temporary storage. In
order to avoid erasing data due to static
electricity, electromagnetic waves, breakage,
and failures, back up the data to a PC or disc.
(l 90)
≥ Access lamp [ACCESS] (l 7) illuminates
while the SD card or built-in memory is being
accessed (initialization, recording, playback,
deleting, etc.). Do not perform the follow ing
operations when the lamp illuminates. It may
damage the built-in memory or cause a
malfunction in the unit.
j Turn the unit off (remove the battery)
j Insert and remove the USB cable
j Expose the unit to vibrations or shock
≥ About disposing of or giving away this unit.
(l 113)
- 2 -
∫ About Condensation (When
the lens or the LCD monitor is
fogged up)
Condensation occurs when there is a change in
temperature or humidi ty , such as wh en the unit
is taken from outside or a cold room to a warm
room. Please be careful, as it may cause the
lens or LCD monitor to become soiled, moldy,
or damaged.
When taking the unit to a place which has a
different temperature, if the unit is accustomed
to the room temperature of the destination for
about one hour, condensation can be
prevented. (When the difference in temperature
is severe, place the unit in a plastic bag or the
like, remove air from the bag, and seal the bag.)
When condensation has occurred, remove the
battery and/or the AC adapter and leave the
unit like that for about one hour. When the unit
becomes accustomed to the surrounding
temperature, fogginess will disappear naturally.
∫ Cards that you can use with
this unit
SD Memory Card, SDHC Memory Card and
SDXC Memory Card
≥ 4 GB or more Memory C ards th at do no t have
the SDHC logo or 48 GB or more Memory
Cards that do not have the SDXC logo are
not based on SD Memory Card
Specifications.
≥ Refer to page 16 for more details on SD
cards.
∫ For the purposes of this
owner’s manual
≥ SD Memory Card, SDHC Memory Card and
SDXC Memory Card are referred to as the
“SD card”.
≥ Functions that can be used for motion picture
recording/motion picture playback are
indicated by in this owner’s manual.
≥ Functions that can be used for still picture
recording/still picture playback are indicated
by in this owner’s manual.
≥ Scene(s) recorded in 1080/60p or
1080/60i: “AVCHD scene(s)”
≥ Pages for reference are indicated by an
arrow, for example: l 00
This owner’s manual are designed for use with
models , ,
and . Pictures may
be slightly different from the original.
≥ The illustrations used in this owner’s manual
show model , however, parts of
the explanation refer to different models.
≥ Depending on the model, some functions
are not available.
≥ Features may vary, so please read carefully.
≥ Not all models may be available depending
on the region of purchase.
- 3 -
Contents
Read this first............. .................................... 2
Preparation
Names and Functions of Main Parts ............6
Power supply..................................................9
Inserting/removing the battery............... 10
Charging the battery.............................. 11
Charging and recording time ................. 14
Recording to a card .....................................16
Cards that you can use with this unit..... 16
Inserting/removing an SD card.............. 17
Turning the unit on/off.................................18
Selecting a mode .........................................19
Setting date and time...................................20
Basic
Before recording.. ...... ..... ..... ..... ...... ..... ........21
Selecting a media to record
[HC-V210M]................................................... 22
Recording motion pictures.........................23
Recording still pictures ...............................25
Intelligent Auto Mode ..................................26
Motion picture/Still picture playback .........28
Using the menu screen ...............................31
Using the Setup Menu ................................. 32
Advanced (Recording)
Using the Zoom............................................ 41
Image stabilizer function............................. 42
Recording functions of
operation icons ......................... ...... ..... ..... ... 43
Operation icons ..................................... 43
Recording functions of menus...................47
Manual recording .........................................53
White Balance ....................................... 54
Manual shutter speed/
Iris adjustment ....................................... 55
Recording with Manual Focus ............... 56
Advanced (Playback)
Playback Operations .............................. ..... .57
Motion picture playback using
operation icon ........................................ 57
Creating still picture from
motion picture ........................................ 58
Repeat playback .................................... 58
Resuming the previous playback........... 58
Zooming in on a still picture
during playback (Playback zoom).......... 59
Various playback functions.........................60
Playing back motion pictures/
still pictures by date ............................... 60
Highlight Playback
[HC-V210]/[HC-V201]/[HC-V210M]........ 61
Changing the playback settings and
playing back the slide show................... 63
Deleting scenes/still pictures......................64
Dividing a scene (AVCHD)..................... 66
Dividing a scene to partially delete
(iFrame, MP4)........................................ 67
Protecting scenes/still pictures............... 68
Relay scene combining [HC-V210M]..........69
Watching Video/Pictures on your TV .........71
Connecting with a HDMI mini cable....... 73
Playback using VIERA Link™.....................74
Copy/Dubbing
Copying between SD card and Built-in
Memory [HC-V210M] ....................................76
Copying/playing back with a USBHDD
[HC-V210]/[HC-V201]/[HC-V210M]...............78
Preparing for copying/playing back........ 78
Simple copy ........................................... 80
Copy selected files................................. 81
Playing back the USB HDD ................... 82
Dubbing with a Blu-ray disc recorder,
video devices, etc. .......................................83
Using the Eye-Fi™ card...............................87
- 4 -
With a PC
What you can do with a PC.........................90
End User License Agreement................ 92
Operating environment ...............................94
Installation....................................................97
Connecting to a PC...................................... 98
About the PC display ........................... 100
Starting HD Writer LE 2.0 ..........................101
Reading the operating instructions of
the software applications ..................... 101
If using Mac ................................................ 102
Others
Indications..................................................103
Messages.................................................... 105
About recovery .................................... 106
Troubleshooting.........................................107
Cautions for use.........................................112
About copyright ......................................... 116
Recording modes/
approximate recordable time.................... 118
Approximate number of
recordable pictures.................................... 119
- 5 -
Preparation
A/V
1
3
4
5
867
2
10
Names and Functions of Main Parts
//
1
A/V
867
1 Speaker
2 USB terminal [ ] (l 83, 98)
3 Intelligent auto/Manual button
[iA/MANUAL] (l 26, 53)
4 //
Optical image stabilizer/Delete button
[ O.I.S./ ] (l 42, 64)
Delete button [ ] (l 64)
2
3
4
5
5 Power button [ ] (l 18)
6 HDMI mini connector [HDMI]
(l 71)
7 A/V connector [A/V]
(l 71, 86)
8 Battery release lever [BATT] (l 10)
9
11
9 Lens cover opening/closing switch
When not using the unit, close the lens cover to
protect the lens.
≥ Slide the opening/clo si ng switch to open /
close the cover.
10 Lens cover
11 Lens
12 Internal stereo microphones
12
- 6 -
15 16
22
23
24
21
1413
20191817
13 Menu button [MENU] (l 31)
14 Mode switch (l 19)
15 Status indicator (l 18)
16 Recording start/stop button (l 23)
17 Cursor button (l 28, 31, 43)
≥ Use the cursor button to select the recording
functions and playback operations, and to
operate the menu screen.
≥ In this owner’s manual, the cursor button is
denoted as shown below or as 3/4/2/1.
Example: For pressing the (down) button
or Press 4
18 Enter butt on [ENTER] (l 28, 31, 43)
19 LCD monitor (l 21)
≥ It can open up to 90o.
≥ It can rotate up to 180o A towards the lens or
90o B towards the opposite direction.
20 Battery holder (l 10)
21 SD card cover (l 17)
22 Tripod receptacle
≥ If you attach a tripod which has a 5.5 mm
(0.22 q) screw or larger, it may damage this
unit.
23 Access lamp [ACCESS] (l 17)
24 Card slot (l 17)
- 7 -
//
2625
28
2625
28
27
25 Photoshot button [ ] (l 25)
26 Zoom lever [W/T] (In Recording Mode)
(l 41)
Thumbnail display switch [ / ]/
Volume lever [sVOLr] (In Playback
Mode) (l 29)
27 //
DC input terminal [DC IN] (l 11)
≥ Do not use any other AC adaptors except the
supplied one.
28 Grip belt
Adjust the length of the grip belt so that it fits
your hand.
1 Flip the belt.
2 Adjust the length.
3 Replace the belt.
- 8 -
Preparation
Power supply
∫ About batteries that you can use with this unit
The battery that can be used with this unit is VW-VBT190/VW-VBT380.
≥ The unit has a function for distinguishing batteries which can be used safely. The
dedicated battery (VW-VBT190/VW-VBT380) supports this function. The only batteries
suitable for use with this unit are genuine Panasonic products and batteries manufactured
by other companies and certified by Panasonic. Panasonic cannot in any way guarantee
the quality, performance or safety of batteries which have been manufactured by other
companies and are not genuine Panasonic products.
The battery that can be used with this unit is VW-VBY100/VW-VBT190/VW-VBT380.
It has been found that counterfeit battery packs which look very similar to the genuine
product are made available to purchase in some markets. Some of these battery packs
are not adequately protected with internal protection to meet the requirements of
appropriate safety standards. There is a possibility that these battery packs may lead to
fire or explosion. Please be advised that we are not liable for any accident or failure
occurring as a result of use of a counterfeit battery pack. To ensure that safe products are
used we would recommend that a genuine Panasonic battery pack is used.
/
/
- 9 -
Inserting/removing the battery
Removing the battery
Be sure to hold down the power button until the
status indicator goes off. Then remove the
battery while supporting the unit to prevent it
from dropping.
Move the battery release lever in th e
direction i ndica ted by t he ar row an d remove
the battery when unlocked.
Insert the battery until it clicks and
locks.
≥ Press the power button to turn off the unit. (l 18)
Install the battery by inserting it in the direction shown in the figure.
ャモヵヵ
- 10 -
Charging the battery
When this unit is purchased, the battery is not charged. Charge the battery fully before
using this unit for the first time.
∫ Charging with an AC adaptor.
The unit is in th e st an dby co ndi tio n wh en th e AC adap tor is connec te d. The pr im ary circ uit i s alw ays
“live” as long as the AC adaptor is connected to an electrical outlet.
Important:
≥ It is recommended to charge the battery in a temperature between 10 oC and 30 oC (50 oF
and 86 oF). (The battery temperature should also be the same.)
≥ Use the supplied AC adaptor. Do not use the AC adaptor of another device.
≥ Do not use the AC cable with any other equipment as it is designed only for this unit. Also,
do not use the AC cable from other equipment with this unit.
≥ The battery will not be charged if the unit is turned on.
≥ The AC adaptor and USB cable are for use with this unit only. Do not use them with other
equipment. Similarly, do not use AC adaptors and USB cables from other equipment with
this unit.
≥ The battery cannot be charged when the power is on. Press the power button to turn off
the power. (l 18)
//
//
A DC input terminal
≥ Insert the plugs as far as they will go.
1 Connect the AC cable to the AC adaptor, then the AC outlet.
2 Connect the AC adaptor to the DC input terminal [DC IN].
≥ Be careful not to pinch the DC input terminal cover.
≥ The status indicator will flash red for approx. 2 seconds (off for approx. 1 second, on for approx. 1
second), indicating that charging has begun.
It will turn off when the charging is completed.
- 11 -
A USB terminal
B To the AC outlet
≥ Insert the plugs as far as they will go.
1 Op en the LCD mon itor.
2 Con nect the USB cable to the AC adaptor.
≥ Check that the plug portion of the AC adaptor is not loose or misaligned.
3 Plug the AC adaptor into the AC outlet.
4 Con nect the USB cable to the unit.
≥ The status indicator C will flash red
approx. 1 second),
It will turn off when the charging is completed.
indicating that charging has begun.
∫ Connecting to the AC outlet
If you turn on the unit while connecting with the AC adaptor, you can use the unit with power
supplied from the outlet.
When recording for a long time, keep the AC adaptor connected and use it together with the battery.
with approx. 2 seconds period (off for approx. 1 second, on for
- 12 -
∫ Connecting to a PC and charging.
Charge the unit if you do not have the AC adaptor handy.
//
A USB cable (supplied)
≥ Insert the plugs as far as they will go.
≥ Press the power button and turn the unit off. (l 18)
1 Turn the power of the PC on.
2 Con nect the USB cable
≥ The status indicator B will flash red
approx. 1 second),
It will turn off when the charging is completed.
≥ Do not use any other USB cables except the supplied one. (Operation is not guaranteed with any
other USB cables.)
≥ Always connect directly to a PC.
≥ You cannot charge when the status indicator flashes rapidly, or when it does not light at all.
Charge using the AC adaptor. (l 11)
≥ It will take 2 or 3 times longer to charge compared to when using the AC adaptor.
indicating that charging has begun.
with approx. 2 seconds period (off for approx. 1 second, on for
≥ If the status indicator flashes at a particularly fast or slow rate, refer to page 114.
≥ We recommend using Pana sonic bat ter i es (l 9).
≥ If you use other batteries, we cannot guarantee the quality of this product.
≥ Do not heat or expose to flame.
≥ Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with
doors and windows closed.
≥ If you do not intend to use the unit for an extended period, disconnect the USB cable from the unit
for safety.
≥ Charging may not be possible depending on the operating environment of the PC being used
(such as custom-made PC).
≥ Charging will stop when turning the power of the PC off or forcing it into sleep mode. Charging will
start again when turning the power of the PC on again, or waking from sleep mode.
≥ When connected to a PC, an error message may be displayed at the top of the PC screen. For
more details, refer to page 110.
≥ The unit will be charged if it is connected to a Panasonic Blu-ray disc recorder or DVD recorder
with a USB cable, even if the unit is turned off.
- 13 -
Charging and recording time
∫ Charging/Recording time
≥ Temperature: 25 oC (77 oF)/humidity: 60%RH
≥ Charging times in parentheses are when charging from th e USB terminal.
Battery model number
Supplied battery/VW-
VW-VBT380 (optional)
Battery model number
Supplied battery/VW-
VW-VBT190 (optional)
//
[Voltage/Capacity
(minimum)]
VBT190 (optional)
[3.6 V/1940 mAh]
[3.6 V/3880 mAh]
[Voltage/Capacity
(minimum)]
VBY100 (optional)
[3.6 V/970 mAh]
[3.6 V/1940 mAh]
Charging
time
2h20min
(5h20min)
3h45min
(9h45min)
Charging
time
2h20min
(3h10min)
2h20min
(5h20min)
HC-V210/HC-V210M
Maximum
Recording
format
AVCHD
iFrame -
MP4 -
AVCHD
iFrame - 5h10min 2h40min
MP4 - 5h20min 2h45min
HC-V201
Recording
format
AVCHD
iFrame -
MP4 - 45 min
AVCHD
iFrame -
MP4 -
Recording
mode
[1080/60p] 2 h 1 h
[HA] 2 h 10 min 1 h 5 min
[HG], [HE] 2h15min 1h10min
[1080/60p] 4 h 10 min 2 h 10 min
[HA], [HG] 4 h 30 min
[HE] 4 h 35 min
Recording
mode
[1080/60p] 1 h
[HA], [HG],
[HE]
[1080/60p] 2 h 1 h
[HA] 2 h 10 min 1 h 5 min
[HG], [HE] 2h15min 1h10min
continuously
recordable
2h35min 1h20min
Maximum
continuously
recordable
1h5min
1h15min
2h35min 1h20min
time
time
Actual
recordable
time
2h20min
Actual
recordable
time
35 min
40 min
- 14 -
HC-V201
Battery model number
[Voltage/Capacity
(minimum)]
VW-VBT380 (optional)
[3.6 V/3880 mAh]
≥ Time in the parenthesis is charging time when this unit is connected to a PC, Panasonic Blu-ray
disc recorder, or DVD recorder.
Battery model number
[Voltage/Capacity
(minimum)]
Supplied battery/VW-
VBY100 (optional)
[3.6 V/970 mAh]
VW-VBT190 (optional)
[3.6 V/1940 mAh]
VW-VBT380 (optional)
[3.6 V/3880 mAh]
≥ These times are approximations.
≥ The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as high/
low temperature.
Charging
time
3h45min
(9h45min)
Charging
time
2h20min
(3h10min)
2h50min
(5h20min)
4h45min
(9h45min)
Recording
format
AVCHD
iFrame - 5h10min 2h40min
MP4 - 5h20min 2h45min
HC-V110
Recording
format
AVCHD
iFrame -
MP4 -
AVCHD
iFrame - 2h40min 1h20min
MP4 - 2h45min 1h25min
AVCHD
iFrame - 5h25min 2h50min
MP4 - 5h35min 2h55min
Recording
mode
[1080/60p] 4 h 10 min 2 h 10 min
[HA], [HG] 4 h 30 min
[HE] 4 h 35 min
Recording
mode
[HA], [HG] 1 h 5 min
[HE] 1 h 10 min
[HA], [HG],
[HE]
[HA], [HG] 4 h 40 min
[HE] 4 h 45 min
Maximum
continuously
recordable
time
Maximum
continuously
recordable
time
1h20min 45min
2h20min 1h10min
Actual
recordable
time
2h20min
Actual
recordable
time
40 min
2h25min
- 15 -
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping
32
recording, turning the unit on/ off, moving the zoom lever etc.
≥ The batteries heat up after use or char gi n g. This is not a malfunct ion.
Battery capacit y indica tion
≥ The display changes as the battery capacity reduces. ####
If the battery discharges, then will flashes red.
Preparation
Recording to a card
The unit can record still pictures or motion pictures to an SD card or built-in memory. To record to an
SD card, read the following.
Cards that you can use with this unit
Use SD cards conforming to Class 4 or higher of the SD Speed Class Rating* for motion
picture recording.
Card type Capacity
SD Memory Card 512MB/1GB/2GB
SDHC Memory Card 4GB/6GB/8GB/12GB/16GB/24GB/32GB
SDXC Memory Card 48 GB/64 GB
* SD Speed Class Rating is the speed
standard regarding continuous writing.
Check via the label on the card, etc .
≥ Please check the latest information on the support website below.
http://panasonic.jp/support/global/cs/e_cam
(This website is in English only.)
≥ When using an SDHC Memory Card/SDXC Memory Card with other equipment, check the
equipment is compatible with these Memory Cards.
≥ An Eye-Fi X2 series SD card is required to use functions related to Eye-Fi. (l 87)
≥ We do not guarantee the operation of SD cards other than the ones above. Further, SD cards
with a capacity of less than 32 MB cannot be used for motion picture recordi ng.
≥ 4 GB or more Memory Cards that do not have the SDHC logo or 48 GB or more Memory Cards
that do not have the SDXC logo are not based on SD Memory Card Specifications.
≥ When the write-protect switch A on SD card is locked, no recording, deletion
or editing will be possible on the card.
≥ Keep the Memory Card out of reach of children to prevent swallowing.
e.g.:
- 16 -
Inserting/removing an SD card
When using an SD card not from Panasonic, or one previously used on other equipment, for the
first time on this unit, format the SD card. (l 38) When the SD card is formatted, all of the
recorded data is deleted. Once the data is deleted, it cannot be restored.
Caution:
Check that the access lamp has gone off.
Access lamp [ACCESS] A
≥ When this unit is accessing the SD card or
built-in memory, the access lamp lights up.
1 Open the SD card cover and insert
(remove) the SD card into (from)
the card slot B.
≥ Face the label side C in the direction shown
in the illustration and press it straight in as far
as it will go.
≥ Press the center of t he SD ca rd and th en pu ll
it straight out.
2 Sec urely close the SD card cover.
≥ Securely close it until it clicks.
≥ Do not touch the terminals on the back of the
SD card.
≥ Do not apply strong shocks, bend, or drop the
SD card.
≥ Electrical noise, static electricity or the failure
of this unit or the SD card may damage or
erase the data stored on the SD card.
≥ When the card access lamp is lit, do not:
j Remove the SD card
j Turn the unit off
j Insert and remove the USB cable
j Expose the unit to vibrations or shock
Performing the above while the lamp is on
may result in damage to data/SD card or this
unit.
≥ Do not expose the terminals of the SD card to
water, dirt or dust.
≥ Do not place SD cards in the following areas:
j In direct sunlight
j In very dusty or humid areas
j Near a heater
j Locations susceptible to significant
difference in temperature (condensation
can occur.)
j Where static electricity or electromagneti c
waves occur
≥ To protect SD cards, return them to their
cases when you are not using them.
≥ About disposing of or giving away the SD
card. (l 115)
- 17 -
Preparation
To turn off the unit
Hold down the power button until the status
indicator goes off.
Turning the unit on/off
You can turn the unit on and off using the power button or by opening and closing the LCD monitor.
Turning the unit on and off with the power button
Open the LCD monitor and press the power button to turn on the unit.
A The status in dica tor li ghts on.
Turning the unit on and off with the LCD monitor
Unit is turned on when the LCD monitor is opened, and unit is turned off when it is closed.
During normal use, opening and closing of the LCD monitor can be conveniently used to
turn the unit on/off.
≥ The unit will not turn off while recording motion pictures even if the LCD monitor is closed.
≥ In the following cases, opening the LCD monitor does not turn on the unit. Press the power button
to turn on the unit.
j When the unit is originally purchased
j When you have turned off the unit using the power button
- 18 -
Preparation
Selecting a mode
Operate the mode switch to change the mode to or .
Recording Mode (l 23, 25)
Playback Mode (l 28, 57)
- 19 -
Preparation
Setting date and time
The clock is not set at the time of purchase. Make sure to set the clock.
¬ Change the mode to .
1 Select the menu. (l 31)
: [SETUP] # [CLOCK SET]
2 S elect the date or time using 2/1 and set the desired value using 3/4.
A Displaying the World time setting
(l 32):
[HOME]/ [DESTINATION]
≥ The year can be set between 2000 and 2039.
3 P ress the ENTER but ton.
≥ A message prompting for World Time setting
may be displayed. Perform the World Time setting by pressing the ENTER button. (l 32)
≥ Press the MENU button to complete the setting.
≥ When the unit is turned on for the first time, a message asking you to set the date and time will
appear. Select [YES] and perform
≥ The date and time function is driven by a built-in lithium battery.
≥ If the time display becomes [- -], the built-in lithium battery needs to be charged. To recharge the
built-in lithium battery, connect the AC adaptor or attach the battery to this unit. Leave the unit as
it is for approx. The battery is still being recharged even if the unit is off. 24 hours and the battery
will maintain the date and time for approx. 4 months.
Step
s 2 to 3 to set the date and time.
- 20 -
Basic
Before recording
∫ Basic cam era positi oning
1 Hold the unit with both hands.
2 Put your hand through the grip belt.
≥ When recording, make sure your footing is stable and there is no danger of colliding with another
person or object.
≥ When you are outdoors, record pictures with the sunlight behind you. If the subject is backlit, it will
become dark in the recording.
≥ Keep your arms near your body and separate your legs for better balance.
≥ Do not cover the microphones with your hand etc.
∫ Basic motion picture recording
≥ The unit should normally be hel d steady when recor ding .
≥ If you move the unit when recording, do so slowly, maintaining a constant speed.
≥ The zoom operation is useful for recording subjects you cannot get close to, but overuse of zoom
in and zoom out can make the resulting motion picture less enjoyable to watch.
∫ Recording yoursel f
Rotate the LCD monitor towards the lens side.
≥ The image is horizontally flipped as if you see a mirror image.
(However, the image recorded is the same as a normal recording.)
≥ Only some indications will appear on the screen. When appears,
return the direction of the LCD monitor to normal position and check
the warning/alarm indication. (l 105)
- 21 -
Basic
Selecting a media to record
[HC-V210M]
The card and built-in memory can be selected separat ely to record motion pictures or still pictures.
1 Chan ge the mode to .
2 Select the menu. (l 31)
: [MEDIA SELECT]
3 Select the media for recording the motion pictures and the media for
recording the still pictures using 3/4/2/1, and press the ENTER button.
≥ The media is selected separately to motion pictures or still pictures is highlighted in yellow.
≥ Select and press the ENTER button to return to the previous screen. (settings will not be
changed)
4 Press the MENU button to complete the settings.
- 22 -
Basic
0h00m00s0h00m00s0h00m00s
R 1h20mR 1h20mR 1h20m
Recording motion pictures
≥ Open the lens cover before turning on the unit. (l 6)
1 Chan ge the mode to and
open the LCD monitor.
2 Press the recording start/stop
button to start recording.
A When you begin recording, ; changes to ¥.
3 Press the recording start/stop button again to pause recording.
∫ About the screen indications in the motion picture recording
Recording f ormat/Recording mode
R1h20m
0h00m00s
Approximate remaining recordable time
≥ When the remaining time is less than
1 minute, R 0h00m flashes red.
Recording time elapsed
≥ “h” is an abbreviation for hour, “m” for
minute and “s” for second.
≥ Each time the unit is put into recording
pause, the counter display will be reset to
0h00m00s.
- 23 -
≥ To change the recording format, change the [REC FORMAT] or [REC MODE]. (l 48, 49)
≥ The images recorded between pressing the recording start/stop button to start recording and
pressing it again to pause recording become one scene.
When you record with the [REC FORMAT] set to [iFrame] or [MP4], the scenes longer than
approximately 20 minutes will be automatically divided. (Recording will continue.)
≥ (Maximum recordable scenes on a single SD card or built-in memory)
Recording formats [AVCHD] [iFrame]/[MP4]
Recordable scenes Approx. 3900 Approx. 89100
Different dates (l 60) Approx. 900 Approx. 900
≥ Maximum number of recordable scenes and maximum number of different dates will be less than
above table when there are iFrame or MP4 scenes and still pictures recorded on an SD card or
the built-in memory.
≥ While recording is in progress, the recording will not stop even if the LCD monitor is closed.
≥ Please refer to page 118 for details about approximate recordable time.
- 24 -
Basic
R3000R3000R3000
10
M
Recording still pictures
≥ Open the lens cover before turning on the unit. (l 6)
1 Chan ge the mode to and
open the LCD monitor.
2 Press the button.
≥ The still picture operating display ( ) will
turn red while recording still pictures.
∫ About the screen indications in Still Picture Recording
Size of still pictures (l 52)
R3000
≥ During motion picture recording or when set to PRE-REC, you cannot record still pictures.
≥ Using a tripod is recommended when recording still pictures in dark places because the shutter
speed becomes slow.
≥ The edges of still pictures recorded on this unit with a 16:9 aspect ratio may be cut at printing.
Check the printer or photo studio before printing.
≥ Maximum number of recordable pictures that can be displayed is 9999. If the number of
recordable pictures exceeds 9999, R 9999+ is displayed. The number will not change when the
picture is taken until the number of recordable pictures is 9999 or less.
≥ The recording time may be long depending on the recording condition.
Remaining number of still pictures
≥ Flashes in red when [0] appea rs.
Still picture operation indicator (l 104)
M
10
- 25 -
Basic
Intelligent auto/Manual button
Press this button to switch Intelligent Auto
Mode/Manual Mode (l 53).
/MANUAL
Intelligent Auto Mode
The following modes (appropriate for the condition) are set just by pointing the unit to what you want
to record.
Mode Effect
Portrait Faces are detected and focused automatically, and the brightness
Scenery The whole landscape will be recorded vividly without whiting out
Spotlight Very bright object is recorded clearly.
Low light It can record very clearly even in a dark room or twilight.
Normal In modes other than those described above, the contrast is
≥ Depending on the recording conditions, the unit may not enter the desired mode.
≥ In the Portrait, Spotlight and Low light mode, the face will be surrounded by white frame when
detected. In the Portrait mode, a subject that is bigger and close to center of the screen will be
surrounded by an orange frame. (l 50)
≥ Faces cannot be detected depending on the recording conditions, such as when faces are of
certain sizes or at certain tilts or when digital zoom is used.
is adjusted so it is recorded clearly.
the background sky, which may be very bright.
adjusted to give a clear picture.
- 26 -
∫ Intelligent Auto Mode
4)
5)
6)
7)
8)
10 000K
9 000K
8 000K
7 000K
6 000K
5 000K
4 000K
3 000K
2 000K
2)
1)
3)
9)
When switching to Intelligent Auto Mode, the Auto White Balance and Auto Focus operate and
automatically adjust the color balance and focusing.
Depending on the brightness of the subject, etc., the aperture and shutter speed are automatically
adjusted for optimum brightness.
≥ Color balance and focus may not be adjusted automatically depending on light sources or
scenes. If so, manually adjust these settings. (l 54, 56)
Automatic White Balance
The illustration shows the range over which Automatic White Balance functions.
1) The effective range of Automatic White Balan ce adjustment
on this unit
2) Blue sky
3) Cloudy sky (rain)
4) Sunlight
5) White fluorescent lamp
6) Halogen light bulb
7) Incandescent light bulb
8) Sunrise or sunset
9) Candlelight
If the Automatic White Balance is not functioning normally, adjust
the White Balance manually. (l 54)
Auto Focus
The unit focuses automatically.
≥ Auto Focus does not work correctly in the following situations.
Record pictures in the Manual Focus Mo de. (l 56)
j Recording distant and close-up objects at the same time
j Recording a subject behind dirty or dusty window
j Recording a subject that is surrounded by objects with glossy surfaces or by highly reflective
objects
- 27 -
Basic
NOV 15 2013
0
h00m15s
is displayed only for //
Motion picture/Still picture playback
1 Chan ge the mode to .
2 Select the play mode select icon A
using 3/4/2 and press the
ENTER button.
≥ This can also be set from the menu.
[VIDEO SETUP] or [PICT. SETUP] # [MEDIA, VIDEO/PICTURE]
3 / /
Select still picture B or motion picture C to playback using 3/4/2/1 and
press the ENTER button.
/
Select media D and still picture B or motion picture C to playback using 3/
4/2/1 and press the ENTER button.
≥ If you press the MENU button, or select motion picture/still picture and press the ENTER button,
the setting is complete.
≥ When a motion picture item is selected, an icon will appear on the thumbnail display. ( ,
≥ is displayed in the 1080/60p scene when [ALL AVCHD] is selected.
* / / only
*
*
,
, , )
- 28 -
*
4 Select the scene or the still picture
NOV 15 2013
0
h00m15s
0h00m00s0h00m00s0h00m00s
to be played back using 3/4/2/1,
then press the ENTER button.
≥ When you select / and press the
ENTER button, the next (previous) page is
displayed.
5 Select the operation icon using
3/4/2/1.
E Operation icon
≥ Press the ENTER button to display/not display the
operation icon.
Motion picture playb ac k Still picture playback
1/;: Playback/Pause
6: Rewind playback*
5: Fast forward playback*
∫: Stops the playback and shows the
thumbnails.
* When pressed two times, the fast forward/fast rewind speed increases. (The screen display
changes / .)
∫ Change the thumbnail display
While the thumbnail is displayed, the thumbnail display changes in the
following order if the zoom lever is operated to side or side.
20 scenes () 9 scenes () 1 scene
≥ 9 scenes display returns if the unit is turned off or the mode is
changed.
∫ Speaker volume adjustment
Operate the volume lever to adjust the speaker
volume during motion picture playback.
1/;: Slide show (playback of the still
pictures in numerical order) st art/
pause.
2;: Plays back the previous picture.
;1: Plays back the next picture.
∫: Stop s the pl ayba ck and sho ws the
thumbnails.
Towards “r”: Increases the volume
Towards “s”: Decreases the volume
- 29 -
≥ Sound will be heard only during normal playback.
≥ If pause play is continued for 5 minutes, the screen returns to the thumbnails.
≥ The elapsed time for playback indication will be reset to 0h00m00s for each scene.
≥ //
When playe d b ac k with [ALL AV C HD] sel e c ted , t he sc r e en m ay be c om e bl ac k m om e nt ar i l y a t t h e
time the scene switches.
Motion picture compatibility
≥ //
This unit is based on AVCHD Progressive/AVCHD format/MPEG-4 AVC file format.
≥
This unit is based on AVCHD format/MPEG-4 AVC file format.
≥ Even if the devices used have compatible standards, when playback of motion pictures
recorded using another device is performed using this unit, or when motion pictures recorded
using this unit is played back in another device, playback may not proceed normally, or may
not be possible. ( is displayed for motion pictures that cannot be played back with this
unit)
Please check compatibility in the operating instruction of your device.
≥ MP4 motion pictures that can be played back on this unit are limited to those recorded using
this unit.
Still picture compatibility
≥ This unit is compliant with the unified standard DCF (Design rule for Camera File system)
established by JEITA (Japan Electronics and Information Technology Industries Association).
≥ The file format of still pictures supported by this unit is JPEG. (Not all JPEG formatted files
will be played back.)
≥ This unit may degrade or not play back still pictures recorded or created on other products
and other products may degrade or not play back still pictures recorded on this unit.
- 30 -
Loading...
