Page 1
PEG1302004CE
Version:1401
Service Manual
Super Quiet Ventilating Fan/Light Combination
Whisper Fit-Lite
(North America Market)
FV-05VFL4
FV-08VFL4
FV-11VFL4
CONTENTS
1 Parts Identification
2 Wiring Diagram
3 Parts List
PAGE
1~2
3
4~12
Page 2
1.Parts Identification
FV-05VFL4
FV-08VFL4
Main Body Section
3
4
9
6
5
C
8
7
11
C
10
(2pcs)
D
(4pcs)
(10)
17
14
G
B
(4pcs)
16
12
13
E
15
FV-11VFL4
2
A
(4pcs)
1
B
32
33
F
Motor Lead
(Red)
Motor Lead
(Black)
18
19
(10)
35
Motor Lead
(White)
Cord
(White)
34
(5pcs)
Cord
(Black)
Cord
(Green)
Details of Junction Box
K
26
28
29
(2pcs)
30
31
L
27
20
D
H
(2pcs)
22
23
Details of Wiring
21
I
(3pcs)
36
H
J
(4pcs)
L
24
Fan Assembly
25
Grille Unit
1
Page 3
1.Parts Identification
FV-05VFL4
FV-08VFL4
Main Labels
37
(37)
(37)
Lam p Conta ins Mer vury.
Dis pose Acc ordin g to Loca l,
Sta te or Fed eral La ws.
38
LIST EN
A375 682G8
41
US
FAN
8B68
FV-11VFL4
39
43
C
40
42
mm
60
50
40
30
20
10
I
n
c
h
1
_
2
2
2
1
_
1
44
2
1
1
_
2
Packing Section
45
50
46
51
52
47
Fan Body
53
48
54
49
2
Page 4
2.Wiring diagram
FV-05VFL4
FV-08VFL4
FV-11VFL4
3
Page 5
3.Parts List
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV0420024S Bracket Cover 1
2 FFV1600064S Frame Assembly 1 Include Frame Packing
3 FFV0000053S Adapter Assembly 1
4 FFV0000038S Adapter Connector 1
5 FFV2800004S Junction Cover 1
6 FFV0900013S Connector Assembly 1
7 FFV0900010S Connector Assembly N.L 1 For Night Lamp
8 FFV0900011S Connector Assembly L 1 For Fluorescent Lamp
9 FFV7020015S Hexagon Nut 1 For Fixing Earth Wire
10 FFV3402103S Earth Wire 2
11 FFV0900014S Connector Plate 1
12 FFV7020022S Nut 1 For Fixing Blade
13 FFV4670002S Blade Set Plate 1 For Fixing Blade
14 FFV0400102S Blade 1
15 FFV7010025S Plain Washer 1 For Fixing Blade
16 FFV3702203S Motor Assembly 1
17 FFV3730027S Motor Support 2 1 With Earth Mark
18 FFV3730028S Motor Support 1 1
19 FFV3730029S Motor Support 3 1
20 FFV0790033S Casing 1 Include 1pc Packing A&2pcs Packing
21 FFV5710020S Support 1
22 FFV0740007S Cord Clip 1
23 FFV0960001S Nylon Clamp 1 For Fixing Cord Assembly
24 FFV0730034S Cord Assembly 1
25 FFV3420065S Grille Unit 1
26 FFV3420066S Light Kit Cover Assembly 1
27 FFV3420071S Lamp Holder Section 1
28 FFV3420005S Night Lamp 1
29 FFV3420067S Fluorescent Lamp 2
30 FFV3420028S Grille Section 1 Include Lamp Cover
31 FFV3420029S Lamp Cover 1
32 FFV0750126S Capacitor 1 220V,1.7uF
33 FFV3400067S Lead Wire 1 For Wire Connection
34 FFV0900024S Connector 5
FV-05VFL4
4
Page 6
Main Body Section
No. Part No. Part Name Q'ty Remark
35 FFV0730022S Cord 1
36 FFV1610063S Fan Assembly 1
A FFV7000018S Truss Tap Screw 4 For Fixing Bracket Cover to Frame Assembly
B FFV7000137S Truss Screw 2
C FFV7000091S Pan Tap Screw 2
D FFV7000168S Earth Screw Assembly 2 For Fixing Earth Wire
E FFV7000081S Truss Screw 4 For Fixing Motor Assembly to Motor Support 3
F FFV7000110S Flush Head Screw 1 For Fixing Support to Casing
G FFV7000088S Flush Head Screw 4 For Fixing Motor Support 1&2 to Casing
H FFV7000097S Truss Tap Screw 3
I FFV7000111S Truss Head Screw 3 For Fixing Motor Support 3 to Casing
J FFV7000080S Plus Bind Screw 4 For Fixing Casing to Frame Assembly
K FFV7000191S Bind Screw 1 For Fixing Light Kit Cover Assembly
L FFV7000089S Truss Tap Screw 2
Main Labels
No. Part No. Part Name Q'ty Remark
37 FFV4020788S Name Plate 1
38 FFV6730056S Warning Label 1
39 FFV0810010S Caution Label 1
40 FFV2260002S HVI Mark 1
41 FFV1320001S ESP Mark 1
42 FFV4730001S T24 Mark Label 1
43 FFV2260003S Holograph Label 1
44 FFV5720015S Scale Tape 1
3.Parts List
FV-05VFL4
5
Page 7
Packing Section
No. Part No. Part Name Q'ty Remark
45 FFV0010206S Accessory A 1 Included Installation Screws
46 FFV2540161S Installation Instruction 1 English,
47 FFV2540162S Installation Instruction 1 Spanish,For USA Market.
(47) FFV2540163S Installation Instruction 1 French,For CA Market.
48 FFV5710017S
Suspension Bracket Ⅲ
1
49 FFV5710018S Suspension Bracket II 1
50 FFV5710019S
Suspension Bracket Ⅰ
1
51 FFV4710360S Grille Case Assembly 1
52 FFV4710219S Left Pad 1
53 FFV4710220S Right Pad 1
54 FFV9001063S Packing Case Assembly 1
3.Parts List
FV-05VFL4
6
Page 8
3.Parts List
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV0420024S Bracket Cover 1
2 FFV1600064S Frame Assembly 1 Include Frame Packing
3 FFV0000053S Adapter Assembly 1
4 FFV0000038S Adapter Connector 1
5 FFV2800004S Junction Cover 1
6 FFV0900013S Connector Assembly 1
7 FFV0900010S Connector Assembly N.L 1 For Night Lamp
8 FFV0900011S Connector Assembly L 1 For Fluorescent Lamp
9 FFV7020015S Hexagon Nut 1 For Fixing Earth Wire
10 FFV3402103S Earth Wire 2
11 FFV0900014S Connector Plate 1
12 FFV7020022S Nut 1 For Fixing Blade
13 FFV4670002S Blade Set Plate 1 For Fixing Blade
14 FFV0400102S Blade 1
15 FFV7010025S Plain Washer 1 For Fixing Blade
16 FFV3702204S Motor Assembly 1
17 FFV3730027S Motor Support 2 1 With Earth Mark
18 FFV3730028S Motor Support 1 1
19 FFV3730029S Motor Support 3 1
20 FFV0790033S Casing 1 Include 1pc Packing A&2pcs Packing
21 FFV5710020S Support 1
22 FFV0740007S Cord Clip 1
23 FFV0960001S Nylon Clamp 1 For Fixing Cord Assembly
24 FFV0730034S Cord Assembly 1
25 FFV3420065S Grille Unit 1
26 FFV3420066S Light Kit Cover Assembly 1
27 FFV3420071S Lamp Holder Section 1
28 FFV3420005S Night Lamp 1
29 FFV3420067S Fluorescent Lamp 2
30 FFV3420028S Grille Section 1 Include Lamp Cover
31 FFV3420029S Lamp Cover 1
32 FFV0750127S Capacitor 1 250V,2.4uF
33 FFV3400067S Lead Wire 1 For Wire Connection
34 FFV0900024S Connector 5
FV-08VFL4
7
Page 9
Main Body Section
No. Part No. Part Name Q'ty Remark
35 FFV0730022S Cord 1
36 FFV1610064S Fan Assembly 1
A FFV7000018S Truss Tap Screw 4 For Fixing Bracket Cover to Frame Assembly
B FFV7000137S Truss Screw 2
C FFV7000091S Pan Tap Screw 2
D FFV7000168S Earth Screw Assembly 2 For Fixing Earth Wire
E FFV7000081S Truss Screw 4 For Fixing Motor Assembly to Motor Support 3
F FFV7000110S Flush Head Screw 1 For Fixing Support to Casing
G FFV7000088S Flush Head Screw 4 For Fixing Motor Support 1&2 to Casing
H FFV7000097S Truss Tap Screw 3
I FFV7000111S Truss Head Screw 3 For Fixing Motor Support 3 to Casing
J FFV7000080S Plus Bind Screw 4 For Fixing Casing to Frame Assembly
K FFV7000191S Bind Screw 1 For Fixing Light Kit Cover Assembly
L FFV7000089S Truss Tap Screw 2
Main Labels
No. Part No. Part Name Q'ty Remark
37 FFV4020789S Name Plate 1
38 FFV6730056S Warning Label 1
39 FFV0810010S Caution Label 1
40 FFV2260002S HVI Mark 1
41 FFV1320001S ESP Mark 1
42 FFV4730001S T24 Mark Label 1
43 FFV2260003S Holograph Label 1
44 FFV5720015S Scale Tape 1
3.Parts List
FV-08VFL4
8
Page 10
Packing Section
No. Part No. Part Name Q'ty Remark
45 FFV0010206S Accessory A 1 Included Installation Screws
46 FFV2540161S Installation Instruction 1 English,
47 FFV2540162S Installation Instruction 1 Spanish,For USA Market.
(47) FFV2540163S Installation Instruction 1 French,For CA Market.
48 FFV5710017S
Suspension Bracket Ⅲ
1
49 FFV5710018S Suspension Bracket II 1
50 FFV5710019S
Suspension Bracket Ⅰ
1
51 FFV4710360S Grille Case Assembly 1
52 FFV4710219S Left Pad 1
53 FFV4710220S Right Pad 1
54 FFV9001064S Packing Case Assembly 1
3.Parts List
FV-08VFL4
9
Page 11
3.Parts List
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV0420024S Bracket Cover 1
2 FFV1600064S Frame Assembly 1 Include Frame Packing
3 FFV0000053S Adapter Assembly 1
4 FFV0000038S Adapter Connector 1
5 FFV2800004S Junction Cover 1
6 FFV0900013S Connector Assembly 1
7 FFV0900010S Connector Assembly N.L 1 For Night Lamp
8 FFV0900011S Connector Assembly L 1 For Fluorescent Lamp
9 FFV7020015S Hexagon Nut 1 For Fixing Earth Wire
10 FFV3402103S Earth Wire 2
11 FFV0900014S Connector Plate 1
12 FFV7020022S Nut 1 For Fixing Blade
13 FFV4670002S Blade Set Plate 1 For Fixing Blade
14 FFV0400102S Blade 1
15 FFV7010025S Plain Washer 1 For Fixing Blade
16 FFV3702205S Motor Assembly 1
17 FFV3730027S Motor Support 2 1 With Earth Mark
18 FFV3730028S Motor Support 1 1
19 FFV3730029S Motor Support 3 1
20 FFV0790033S Casing 1 Include 1pc Packing A&2pcs Packing
21 FFV5710020S Support 1
22 FFV0740007S Cord Clip 1
23 FFV0960001S Nylon Clamp 1 For Fixing Cord Assembly
24 FFV0730034S Cord Assembly 1
25 FFV3420065S Grille Unit 1
26 FFV3420066S Light Kit Cover Assembly 1
27 FFV3420071S Lamp Holder Section 1
28 FFV3420005S Night Lamp 1
29 FFV3420067S Fluorescent Lamp 2
30 FFV3420028S Grille Section 1 Include Lamp Cover
31 FFV3420029S Lamp Cover 1
32 FFV0750127S Capacitor 1 250V,2.4uF
33 FFV3400067S Lead Wire 1 For Wire Connection
34 FFV0900024S Connector 5
FV-11VFL4
10
Page 12
Main Body Section
No. Part No. Part Name Q'ty Remark
35 FFV0730022S Cord 1
36 FFV1610065S Fan Assembly 1
A FFV7000018S Truss Tap Screw 4 For Fixing Bracket Cover to Frame Assembly
B FFV7000137S Truss Screw 2
C FFV7000091S Pan Tap Screw 2
D FFV7000168S Earth Screw Assembly 2 For Fixing Earth Wire
E FFV7000081S Truss Screw 4 For Fixing Motor Assembly to Motor Support 3
F FFV7000110S Flush Head Screw 1 For Fixing Support to Casing
G FFV7000088S Flush Head Screw 4 For Fixing Motor Support 1&2 to Casing
H FFV7000097S Truss Tap Screw 3
I FFV7000111S Truss Head Screw 3 For Fixing Motor Support 3 to Casing
J FFV7000080S Plus Bind Screw 4 For Fixing Casing to Frame Assembly
K FFV7000191S Bind Screw 1 For Fixing Light Kit Cover Assembly
L FFV7000089S Truss Tap Screw 2
Main Labels
No. Part No. Part Name Q'ty Remark
37 FFV4020790S Name Plate 1
38 FFV6730056S Warning Label 1
39 FFV0810010S Caution Label 1
40 FFV2260002S HVI Mark 1
41 FFV1320001S ESP Mark 1
42 FFV4730001S T24 Mark Label 1
43 FFV2260003S Holograph Label 1
44 FFV5720015S Scale Tape 1
3.Parts List
FV-11VFL4
11
Page 13
Packing Section
No. Part No. Part Name Q'ty Remark
45 FFV0010206S Accessory A 1 Included Installation Screws
46 FFV2540161S Installation Instruction 1 English,
47 FFV2540162S Installation Instruction 1 Spanish,For USA Market.
(47) FFV2540163S Installation Instruction 1 French,For CA Market.
48 FFV5710017S
Suspension Bracket Ⅲ
1
49 FFV5710018S Suspension Bracket II 1
50 FFV5710019S
Suspension Bracket Ⅰ
1
51 FFV4710360S Grille Case Assembly 1
52 FFV4710219S Left Pad 1
53 FFV4710220S Right Pad 1
54 FFV9001065S Packing Case Assembly 1
3.Parts List
FV-11VFL4
12
