2/19/2019 DMC-G7KK_SpecSheet
MORE DETAILS
TIME LAPSE SHOT Yes
STOP MOTION ANIMATION Yes
SILENT MODE Yes
NOTE "* About motion picture recording / 4K Photo recording
NOTE - Use a card with SD Speed Class with ""Class 4"" or higher when recording motion pictures.
NOTE - Use a card with SD Speed Class with ""UHS-I / UHS-II UHS Speed Class 3 (U3)"" when recordin
motion pictures with [MP4] in [4K] or [4K PHOTO].
NOTE (SD speed class is the speed standard regarding continuous writing.)
NOTE - Maximum time to record motion pictures continuously with [MP4] in [4K] is 29 minutes 59 secon
NOTE - You can continuously record a motion picture with its size set to [4K] in [MP4] or [4K PHOTO]
without a pause even if the motion picture exceeds 4GB. However, the recorded content has to be played b
multiple files.
NOTE - Maximum time to record motion pictures continuously with [MP4] in [FHD] [HD] [VGA] is 29 m
59 seconds or up to 4 GB.
NOTE - Maximum time to record motion pictures continuously with [AVCHD] is 29 minutes 59 seconds in
Europe.
NOTE ** For [4K] video output, use an HDMI cable that has the HDMI logo on it, and that is described a
compatible".
TYPE
Type Digital Single Lens Mirrorless camera
Recording media SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I
UHS-II UHS Speed Class 3 standard SDHC / SDXC Memory Cards)
Image sensor size 17.3 x 13.0 mm (in 4:3 aspect ratio)
Lens mount Micro Four Thirds mount
IMAGE SENSOR
Type Live MOS Sensor
Total pixels 16.84 Megapixels
Camera effective pixels 16.00 Megapixels
LUMIX G7 4K Mirrorless Interchangeable Lens Camera Kit with 14-42 mm Lens – Black
DMC-G7KK
1/9
2/19/2019 DMC-G7KK_SpecSheet
Color filter Primary color filter
Dust reduction system Supersonic wave filter
RECORDING SYSTEM
Aspect ratio 4:3, 3:2, 16:9, 1:1
Image quality RAW, RAW+Fine, RAW+Standard, Fine, Standard
Image quality MPO+Fine / MPO+Standard (with 3D lens in Micro Four Thirds system standard)
Color Space sRGB, AdobeRGB
Continuous recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 130 min (rear monitor), 140 mi
(LVF) with H-FS1442A
Continuous recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 130 min (rear monitor), 130 mi
(LVF) with H-FS14140
Continuous recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 130 min (rear monitor), 140 mi
(LVF) with H-FS45150
Continuous recordable time (Motion picture) MP4 [4K/30p]: Approx. 100 min (rear monitor), 100 min (LV
with H-FS1442A
Continuous recordable time (Motion picture) MP4 [4K/30p]: Approx. 100 min (rear monitor), 100 min (LV
with H-FS14140
Continuous recordable time (Motion picture) MP4 [4K/30p]: Approx. 100 min (rear monitor), 110 min (LV
with H-FS45150
Actual recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 65 min (rear monitor), 70 min (LVF
H-FS1442A
Actual recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 65 min (rear monitor), 65 min (LVF
H-FS14140
Actual recordable time (Motion picture) AVCHD [FHD/60i]: Approx. 65 min (rear monitor), 70 min (LVF
H-FS45150
Actual recordable time (Motion picture) MP4 [4K/30p]: Approx. 50 min (rear monitor), 50 min (LVF) with
FS1442A
Actual recordable time (Motion picture) MP4 [4K/30p]: Approx. 50 min (rear monitor), 50 min (LVF) with
FS14140
Actual recordable time (Motion picture) MP4 [4K/30p]: Approx. 50 min (rear monitor), 55 min (LVF) with
FS45150
Recording file format
Still image JPEG (DCF, Exif 2.3), RAW, MPO (When attaching 3D lens in Micro Four Thirds system stand
Motion picture AVCHD (Audio format: Dolby Digital 2ch), MP4 (Audio format AAC 2ch)
File size(Pixels)
Still Image [4:3] 4592x3448(L) / 3232x2424(M) / 2272x1704(S) / 1824x1368 (When attaching 3D lens in Mic
Four Third system standard)
Still Image [3:2] 4592x3064(L) / 3232x2160(M) / 2272x1520(S) / 1824x1216 (When attaching 3D lens in Mic
Four Third system standard)
Still Image [16:9] 4592x2584(L) / 3840x2160(M) / 1920x1080(S) / 1824x1024 (When attaching 3D lens in M
Four Third system standard)
2/9
2/19/2019 DMC-G7KK_SpecSheet
Still Image [1:1] 3424x3424(L) / 2416x2416(M) / 1712x1712(S) / 1712x1712 (When attaching 3D lens in Mic
Four Third system standard)
Motion picture*1
MP4*2:NTSC area N/A
MP4*2:PAL area N/A
AVCHD*3:NTSC area N/A
AVCHD*3:PAL area N/A
Motion picture*
MP4*:NTSC area [4K] 3840x2160:4K/30p 100Mbps, 4K/24p 100Mbps
MP4*:NTSC area [Full HD] 1920x1080:FHD/60p 28Mbps, FHD/30p: 20Mbps
MP4*:NTSC area [HD] 1280x720:HD/30p 10Mbps
MP4*:NTSC area [VGA] 640x480:VGA/30p 4Mbps
MP4*:PAL area N/A
AVCHD*:NTSC area [Full HD] 1920x1080:FHD/60p 28Mbps, 60p recording
AVCHD*:NTSC area [Full HD] 1920x1080:FHD/60i 17Mbps, 60i recording
AVCHD*:NTSC area [Full HD] 1920x1080:FHD/30p 24Mbps, 60i recording (sensor output is 30fps)
AVCHD*:NTSC area [Full HD] 1920x1080:FHD/24p 24Mbps
AVCHD*:PAL area N/A
WiFi FUNCTION
WiFi IEEE 802.11b/g/n, 2412 MHz - 2462 MHz (1-11 ch), Wi-Fi / WPA / WPA2, Infrastructure mode
NFC No
QR Code Connection Yes
Password-less connection Yes (ON / OFF selectable)
VIEWFINDER
Type OLED Live View Finder (2,360k dots)
Field of view Approx. 100%
Magnification Approx. 1.4x / 0.7x (35mm camera equivalent) with 50 mm lens at infinity; -1.0 m-1
Eye point Approx. 17.5 mm from eyepiece lens
Diopter adjustment -4.0 - +4.0 (dpt)
Eye sensor Yes
Eye sensor adjustment High / Low
FOCUS
Type Contrast AF system
DFD technology Yes
Focus mode AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF
AF mode Face/Eye Detection / Tracking / 49-Area / Custom Multi / 1-Area / Pinpoint
AF mode (Full area touch is available)
3/9
2/19/2019 DMC-G7KK_SpecSheet
AF detective range EV -4 - 18 (ISO100 equivalent)
Starlight AF Yes
AF assist lamp Yes
AF lock Yes (AF/AE LOCK button)
Others One Shot AF, Shutter AF, Half Press Release, Quick AF, Continuous AF (during motion picture
recording), Eye Sensor AF, AF+MF, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function,
Touch Pad AF, Touch Shutter
EXPOSURE CONTROL
Light metering system 1728-zone multi-pattern sensing system
Light metering mode Multiple / Center Weighted / Spot
Metering range EV 0 - 18 (F2.0 lens, ISO100 equivalent)
Exposure mode Program AE, Aperture Priority AE, Shutter Priority AE, Manual,
ISO sensitivity (Standard Output Sensitivity) Auto / Intelligent ISO / 100 (Extended) / 200 / 400 / 800 / 160
3200 / 6400 / 12800 / 25600 (Changeable to 1/3 EV step)
ISO sensitivity (Standard Output Sensitivity) (Up to ISO6400 in motion picture recording) (ISO Auto in M
mode)
Exposure compensation 1/3 EV step ±5EV (±3EV for motion picture)
AE lock Yes (AF/AE LOCK button)
AE bracket 3, 5, 7 frames in 1/3, 2/3 or 1 EV Step, Max. ±3 EV, single/burst
WHITE BALANCE
White balance Auto / Daylight / Cloudy / Shade / incandescent / Flash / White Set 1, 2, 3, 4 / Color tempera
setting
White balance adjustment Blue/Amber bias, Magenta/Green bias
Color temperature setting 2500-10000K in 100K
White balance bracket 3 exposures in blue/amber axis or in magenta/green axis
SHUTTER
Type Focal-plane shutter
Shutter speed Still image: Bulb (Max. 2 minutes), 1/4,000 - 60
Shutter speed Motion picture: 1/16,000 - 1/25
Shutter speed Electronic shutter: 1/16,000 - 1
Self timer 10sec, 3 images / 2sec / 10sec
Remote control Remote control with Bulb function by DMW-RSL1 (Optional)
SCENE GUIDE
Still image Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet Child
Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Glistening Water /
Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Glittering Illuminat
Handheld Night Shot / Clear Night Portrait / Soft Image of a Flower / Appetizing Food / Cute Dessert / Fre
Animal Motion / Clear Sports Shot / Monochrome
Motion picture Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet C
Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow / Clear Nightscape /
Night Sky / Warm Glowing Nightscape / Artistic Nightscape / Handheld Night Shot / Clear Night Portrait
Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports Shot / Monochrome
4/9
2/19/2019 DMC-G7KK_SpecSheet
PANORAMA SHOT
Panorama shot Yes (Standard / Wide)
BURST SHOOTING
Burst speed Mechanical shutter: H: 8 frames/sec (with AFS), 6 frames/sec (with AFC), M: 6 frames/sec (w
Live View), L: 2 frames/sec (with Live View)
Burst speed Electronic shutter: SH: 40 frames/sec, H: 10 frames/sec, M: 6 frames/sec (with Live View), L:
frames/sec (with Live View)
Number of recordable images More than 13 images (when there are RAW files with the particular speed)
Number of recordable images More than 100 images (when there are no RAW files)
Number of recordable images (depending on memory card type, aspect, picture size and compression)
4K PHOTO MODE
4K Photo mode* 4K Pre-Burst: 30 frames/sec, approx. 2 seconds
4K Photo mode* 4K Burst: 30 frames/sec, max. 29 minutes 59 seconds
4K Photo mode* 4K Burst (S/S): 30 frames/sec, max. 29 minutes 59 seconds
4K Photo mode* (depending on memory card size and battery power)
Exif information Yes
Selectable aspect ratio Yes (4:3 / 3:2 / 16:9 / 1:1 are selectable)
Exposure mode Program AE/ Aperture-Priority / Sutter-Priority / Manual Exposure
Marking function Yes (in 4K Burst (S/S) mode)
FLASH Built in flash type TTL Built-in-Flash, GN9.3 equivalent (ISO200 ・m) / GN6.6 equivalent (ISO100 ・m),
in Pop-up (Reference
）
Flash type N/A
Flash Mode Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow
Sync./Red-eye Reduction, Forced Off * For iA, iA+ only.
Synchronization speed Less than 1/160 second
Flash output adjustment 1/3EV step ±3EV
Flash synchronization 1st. Curtain Sync, 2nd Curtain Sync.
Synchronization for flash dimming and exposure compensation Yes
REAR MONITOR
Type TFT LCD monitor with static touch control
Monitor size Free-angle 3.0-inch / 3:2 aspect / Wide viewing angle
Pixels Approx. 1,040k dots
Filed of view Approx. 100%
Monitor adjustment Brightness, Contrast, Saturation, Red-Green, Blue-Yellow
LIVE VIEW
Digital zoom 2x, 4x
Extra Tele Conversion Still image: Max. 2x
5/9
2/19/2019 DMC-G7KK_SpecSheet
Extra Tele Conversion Motion picture: 2.4x (FHD), 3.6x (HD), 4.8x (VGA)
Other functions Level Gauge, Real-time Histogram, Guide Lines (3 patterns), Center Marker, Highlight d
(Still image / motion picture), Zebra pattern (Still image / motion picture)
DIRECTION DETECTION FUNCTION
Direction Detection Function Yes
SELF SHOT
Self Shot Mode N/A
Shutter N/A
Effect N/A
FUNCTION BUTTON
Fn1, Fn2, Fn3, Fn4, Fn5, Fn6 N/A
Fn1, Fn2, Fn3, Fn4, Fn5, Fn6, Fn7, Fn8, Fn9, Fn10, Fn11 Exposure Comp. / Wi-Fi / Q.MENU / LVF/Moni
Switch / AF/AE LOCK / AF-ON / Preview / One Push AE / Touch AE / Level Gauge / Focus Area Set / Zoo
Control / Cursor Button Lock / Dial Operation Switch / Photo Style / Filter Select / Aspect Ratio / Picture
Quality / AFS/AFF / Metering Mode / Burst Rate / 4K PHOTO / Auto Bracket / Self Timer / Highlight Sha
i. Dynamic / i. Resolution / HDR / Electronic Shutter / Flash Mode / Flash Adjust. / Ex. Tele Conv. / Digital
Zoom / Stabilizer / Snap Movie / Motion Pic. Set / Picture Mode / Mic. Directivity Adjust / Silent Mode /
Peaking / Histogram / Guide Line / Zebra Pattern / Monochrome Live View / Rec Area / Step Zoom / Zoom
Speed / Touch Screen / Sensitivity / White Balance / AF Mode/MF / Restore to Default
PHOTO STYLE
Still image and motion picture Standard / Vivid / Natural / Monochrome / Scenery / Portrait / Custom / Ci
D* / Cinelike V* *When Creative Video Mode is selected.
CREATIVE CONTROL
Still image Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochr
Rough Monochrome / Silky Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / T
Pop / Bleach Bypass / Miniature Effect / Soft Focus / Fantasy / Star Filter / One Point Color / Sunshine
Motion picture Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic
Monochrome / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass /
Miniature Effect / Fantasy / One Point Color
CREATIVE VIDEO MODE
Exposure mode Program AE / Aperture-Priority / Sutter-Priority / Manual Exposure
MOTION PICTURE FUNCTION
Cinelike gamma Cinelike D / Cinelike V
Flicker reduction [1/50] / [1/60] / [1/100] / [1/120] / OFF
PLAYBACK
Playback function 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max
Slideshow (All / Picture Only / Video Only / 4K PHOTO / 3D / Category Selection / Favorite, duration & e
is selectable), Playback Mode (Normal / Picture / Video / 4K PHOTO / 3D Play / Category / Favorite), Loc
Logging, RAW Processing, Clear Retouch, Title Edit, Text Stamp, Video Divide, Time Lapse Video, Stop
Motion Video, Resize, Cropping, Rotate, Rotation Display, Favorite, DPOF Print Set, Protect, Face Recogn
Edit, Picture Sort, Creating Still Pictures from a Motion Picture
6/9
2/19/2019 DMC-G7KK_SpecSheet
IMAGE PROTECTION / ERASE
Protection Single / Multi
Erase Single / Multi / All / Except Favorite
PRINT
Direct Print PictBridge compatible
INTERFACE
USB USB 2.0 High Speed Multi
HDMI** microHDMI TypeD / VIERA Link
HDMI** Video: Auto / 4K / 1080p / 1080i / 720p / 480p
HDMI** Audio: Stereo
HDMI N/A
Audio video output Monaural Type, NTSC
Audio video output *Check the website of the Panasonic sales company in your country or region for deta
the products that are available in your market.
Remote input φ2.5mm for remote
External microphone input φ3.5mm for external microphone
External microphone input Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching
DMW-MS2 (optional).
Microphone Stereo, Wind-cut: OFF / Low / Standard / High / AUTO
Speaker Monaural
LANGUAGE
OSD language Japanese, English, German, French, Italian, Spanish, Portuguese, Chinese (Traditional)
GENERAL
POWER
Battery Li-ion Battery Pack (7.2V, 1200mAh, 8.7Wh) (Included)
Battery Battery Charger
Battery life (CIPA standard) Approx. 360 images with H-FS1442A
Battery life (CIPA standard) Approx. 350 images with H-FS14140
Battery life (CIPA standard) Approx. 350 images with H-FS45150
DIMENSIONS / WEIGHT
Dimensions (W x H x D) 124.9 x 86.2 x 77.4 mm / 4.92 x 3.39 x 3.05 inch (excluding protrusions)
Weight Approx. 410g / 0.90 lb (SD card, Battery, Body)
Weight Approx. 360g / 0.79 lb (Body only)
Weight Approx. 520g / 1.15 lb (SD card, Battery, H-FS1442A lens included)
Weight Approx. 675g / 1.49 lb (SD card, Battery, H-FS14140 lens included)
Weight Approx. 610g / 1.34 lb (SD card, Battery, H-FS45150 lens included)
Weight Approx. 720g / 1.59 lb (SD card, Battery, H-FS1442A + H-FS45150 lenses included)
7/9
2/19/2019 DMC-G7KK_SpecSheet
OPERATING ENVIRONMENT
Operating temperature 0℃ to 40℃ (32°F to 104°F)
Operating humidity 10%RH to 80％RH
STANDARD ACCESSORIES
Software PHOTOfunSTUDIO 9.7 PE
Software (Windows Vista / Windows 7 / Windows 8 / Windows 8.1)
Software SILKYPIX® Developer Studio 4.3 SE
Software (Windows Vista / Windows 7 / Windows 8 / Windows 8.1, Mac OS X v10.5 - v10.10
）
Software LoiLoScope (Trial version)
Software (Windows Vista / Windows 7 / Windows 8 / Windows 8.1)
Standard accessories DMC-G7K Kit
Standard accessories Hot Shoe Cover, Body Cap, Battery Pack, Battery Charger, USB Connection Cable,
Shoulder Strap, DVD, AC Cable*, Lens Hood, Lens Cap, Lens Rear Cap
Standard accessories * Depends on the country or region.
INTERCHANGEABLE LENS-1
Lens Name LUMIX G VARIO 14-42mm / F3.5-5.6 ASPH. / MEGA O.I.S.
Lens Construction 12 elements in 9 groups (1 Aspherical lens)
Nano Surface Coating N/A
Mount Micro Four Thirds mount
Optical Image Stabilizer Yes
Focal Length f=14mm to 42mm (35mm camera equivalent 28mm to 84mm)
Aperture Type 7 diaphragm blades / Circular aperture diaphragm
Aperture range N/A
Aperture F3.5(Wide) - F5.6(Tele)
Maximum Aperture N/A
Minimum Aperture F22
Closest Focusing Distance 0.3m / 1ft
Maximum magnification Approx. 0.16x / 0.32x (35mm camera equivalent)
Diagonal Angle of View 75°
（Ｗ）～29°
（Ｔ）
General
Filter Size φ52mm / 2.05 in
Max. Diameter φ60.6mm / 2.39 in
Overall Length Approx. 63.6mm / 2.50 in (from the tip of the lens to the base side of the lens mount)
Weight [g] Approx. 165g
Weight [oz] Approx. 5.82oz
8/9
2/19/2019 DMC-G7KK_SpecSheet
Others N/A
INTERCHANGEABLE LENS-2
Lens Name N/A
Lens Construction N/A
Nano Surface Coating N/A
Mount N/A
Optical Image Stabilizer N/A
Focal Length N/A
Aperture Type N/A
Aperture range N/A
Aperture N/A
Maximum Aperture N/A
Minimum Aperture N/A
Closest Focusing Distance N/A
Maximum magnification N/A
Diagonal Angle of View N/A
General
Filter Size N/A
Max. Diameter N/A
Overall Length N/A
Weight [g] N/A
Weight [oz] N/A
Others N/A
UPC885170250710
9/9
Loading...
