Oster CKSTWFBF05 User Manual

For product questions contact: Sunbeam Consumer Service

USA : 1.800.334.0759 Canada : 1.800.667.8623 www.oster.com

©2010 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.

Para preguntas sobre los productos llame:

Sunbeam Consumer Service EE.UU.: 1.800.334.0759 Canadá : 1.800.667.8623 www.oster.com

©2010 Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions. Todos los derechos reservados. Distribuido por Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, Boca Raton, Florida 33431.

SPR-030210 P.N. 139944

Printed in China

Impreso en China

FLIP BELGIAN WAFFLE MAKER

WAFLERA BELGA FLIP

User Guide/ Guía del Usuario:

CKSTWFBF05

Safety

Seguridad

How to use

Cómo usar

Cleaning

Cuidado y Limpieza

Recipes

Recetas

Warranty

Garantía

www.oster.com

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

Read all instructions before using. 1.

Make sure the voltage in your outlet is the same as the voltage indicated on the 2. appliance’s rating label.

To protect against risk of electric shock, do not immerse the cord, plug or cooking unit 3. in water or any other liquid.

Do not touch hot surfaces. Use handles. 4. This appliance should not be used by children. 5. Extreme caution must be exercised when any appliance is used near children. 6. Unplug from wall outlet when not in use and before cleaning. Allow to cool before 7.

cleaning or storing this appliance. Never yank the cord to disconnect the cooking unit from the outlet. Instead, grasp the 8.

plug and pull to disconnect. Do not operate any appliance if the cord is damaged. Do not use this appliance if the 9.

unit malfunctions, if it is dropped or has been damaged in any manner. In order to avoid the risk of an electric shock, never try to repair the Flip Belgian 10.

Wae Maker yourself. Take it to an authorized service center for examination and repair. An incorrect reassembly could present a risk of electric shock when the Flip Belgian Wae Maker is used.

The use of accessories or attachments not recommended by the manufacturer may 11.

cause re, electrical shock or injury. Do not use outdoors or for commercial purposes. 12. Do not use this appliance for purposes other than the one for which it was designed. 13. Do not let the electrical cord touch hot surfaces. The cord should be arranged so that it 14.

will not drape over the counter-top or table top where it can be pulled by children or

tripped over unintentionally. Do not place on or near a hot gas or electric burner or heated oven. 15. Use on a heat-resistant, at level surface only. 16. Use extreme caution when moving any appliance containing hot food, water, oil or 17.

other liquids. To disconnect, remove plug from outlet. 18.

Always unplug after use. The appliance will remain on unless unplugged. 19. CAUTION: This appliance generates heat during use. Surfaces are hot, proper 20.

precautions must be taken to prevent the risk of burns, re or other damage to persons or property.

When using this appliance, provide adequate ventilation above and on all sides for 21.

air circulation. Do not allow this appliance to touch curtains, wall coverings, clothing, dish towels or other ammable materials during use.

THIS UNIT IS INTENDED FOR

HOUSEHOLD USE ONLY.

This appliance has a polarized alternating current plug (one blade is wider than the other). To reduce the risk of electric shock, as a safety feature, this plug will t in a polarized outlet only one way. If the plug does not insert fully in the outlet, reverse the plug. If it still fails to t, contact a qualied electrician.

DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.

EXTENSION CORD USE

A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the electrical rating of the cord must be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

SAVE THESE INSTRUCTIONS

Thank you for purchasing the OSTER® Flip Belgian Wae

Maker. Before you use this product for the rst time, please take a few moments to read these instructions and keep it for reference. Pay particular attention to the Safety Instructions provided. Please review the product service and warranty statements. Please do not return to the place of purchase. To learn more about Oster® products, please visit us at www.oster.com or call us at 1-800-334-0759.

www.oster.com

LEARNING ABOUT YOUR FLIP BELGIAN WAFFLE MAKER

HOW TO:

Green Ready Light

Red Power Light

Folding Handle

Green Ready Light (bottom)

Bottom View of Wae Maker

Rotated 180 Degrees

Top View of Wae Maker

USING YOUR OSTER® FLIP BELGIAN WAFFLE MAKER

For best results, follow these simple instructions.

When your wae maker is heated for the rst time, it may emit slight smoke or odor. This is normal with many heating appliances. This does not aect the safety of your appliance. However, it may aect the avor of the rst set of waes prepared in your wae maker, and it is recommended that you discard these.

Preparing Your Flip Belgian Wae Maker

1 Close the wae maker and plug it into the wall outlet, you

will notice that the red power light will turn on. It will take approximately 5 to 8 minutes to reach baking temperature. When the Green Ready Light goes on, the wae maker is ready for use.

2 Before baking the rst waes of the day, use a pastry brush

to lightly coat the top and bottom wae grids with vegetable oil. A light coating of non-stick cooking spray also works well.

Baking

1 When the proper baking temperature is reached, the green

light will go on. Once heated up, cycle times will be faster.

2 Pour batter onto bottom grid of wae maker. Ladle just

enough batter to ll lower grid so that the peak area of the grid is covered. If necessary, use a spatula to spread the batter into the corners of the grid. At this point the green light will go o as the baking cycle begins.

www.oster.com

3 Close wae maker and rotate unit 180º to the left

(counterclockwise). Do not open for at least 1

⁄2 minutes.

Opening the lid too soon will cause under-baked waes to split, making them dicult to remove.

4 When the green light goes on again, rotate wae maker 180º

to the right (clockwise). Your waes should be done. If you want them darker, close the lid and continue baking until the desired color is achieved.

5 Remove waes from the grid using non-metallic utensils. 6 If additional baking is to be done, close wae maker to

retain heat. Always be sure the green light goes on again before making more waes.

7 If you need to take a short break, close wae maker to

maintain heat. When you return to baking, you will notice that the rst waes will bake faster because extra heat has been allowed to build up.

8 Close supervision is necessary when any appliance is being

used by or near children.

9 When baking is complete, simply unplug the power cord

from wall outlet. Leave wae maker open to cool. Do not clean until unit has cooled.

Wae Baking Tips

1 Cooking times may vary. Depending on your taste

preference, leave the wae in longer for darker, crispier waes or shorter for light and uy waes. Dierent wae batters will also cook up dierently.

2 When preparing wae batter, do not over mix or waes will

be tough. Stir batter only until large lumps of dry ingredients disappear.

3 The optimal amount of batter to produce a full-shaped

wae, without overowing, will vary with dierent wae batters. Pouring batter from a measuring cup will help you gauge how much batter to use each time. Fill bottom grid of wae maker with enough batter to cover peak areas of the grid.

4 For more evenly shaped waes, spread thick batters to

outer edge of grid, using a heat proof rubber spatula or other non-metallic utensil before closing lid.

5 Cake-based waes, such as the Chocolate Waes are more

tender than regular waes, and may require more care when removing from wae maker. You may want to break these waes into halves or quarters before removing. Use a spatula to support waes when removing from the wae maker.

6 To retain crispness, move baked waes to a wire cooling

rack to prevent steam from accumulating underneath.

7 When serving several waes at one time, keep waes

hot and crisp by placing on a rack in a preheated 200°F oven until ready to serve.

8 Baked waes freeze well. Cool completely on wire rack.

Store in plastic freezer bag or in covered container, separating waes with wax paper. Reheat frozen waes in toaster oven, oven or toaster until hot and crisp.

www.oster.com

CARE & CLEANING

RECIPES

Here are a few easy steps to keep your wae maker looking and working like new:

1 Always unplug the wae maker and allow it to cool before

cleaning. There is no need to disassemble the wae maker for cleaning. Never immerse the wae maker in water or place in dishwasher.

2 Brush away any loose crumbs from the grooves. Wipe grids

clean with a paper towel, absorbing any oil or butter that might be down in the grooves of the grid. You can also wipe grids with a damp cloth. Do not use anything abrasive that can scratch or damage the non-stick coating.

3 Wipe the outside of the wae maker with a damp cloth only.

Do not clean the outside with any abrasive scouring pad or steel wool, as this will damage the nish. Do not immerse in water or any other liquid. Do not place in the dishwasher.

4 Should any batter become baked onto the grids, pour a little

cooking oil onto the hardened batter. Let sit 5 minutes to soften batter, then wipe o with a paper towel or soft cloth.

5 Do not use metal utensils to remove your waes, they can

damage the non-stick surface.

Classic Waes

1 1⁄2 cups all-purpose our 3 large eggs, separated

⁄2 cup cornstarch 2 tbsp. granulated sugar 2 tbsp. cornmeal (optional) 1 3⁄4 cups milk 1 tbsp. baking powder 1 tsp. salt melted

In large bowl, sift or whisk together our, cornstarch, cornmeal, baking powder and salt to blend thoroughly; set aside. In mixer bowl, beat egg whites until soft peaks form. Add sugar; continue beating just until sti peaks form; set aside. Whisk together egg yolks, milk and vanilla. Using rubber spatula, stir milk mixture into our mixture, blending just until dry ingredients are moistened. (There should still be small lumps; do not over mix). Stir in melted butter. Fold in beaten egg whites until combined. Pour batter onto hot, greased wae maker and bake.

Makes about 5

⁄2 cups batter

Wae Tip: Cornstarch makes the waes crisper. If you don’t have cornstarch, you could still make great waes by omitting cornstarch and increasing our to 2 cups. Bake as directed.

Toasted Pecan & Cranberry Waes

Sprinkle chopped pecans onto bottom grid of hot, greased wae maker. Pour batter over pecans. Sprinkle dried cranberries over batter. Close wae maker and bake as directed.

⁄2 tsp. pure vanilla extract

⁄2 cup (1 stick) unsalted butter,
