User’s
Guide
Forever Series Gold
Powerful, Lightweight & Durable
Upright Vacuum
Important!
Read this manual carefully, and keep for
future reference.
ENGLISH
Enjoy
Call
Click
Contents
Thank you for purchasing your Oreck Gold
ghting inner bag is already installed in your unit, simply install the handle and enjoy your new
Oreck!
Welcome to our Call. Click. customer service program. To speak with an Oreck representative call
or click using the information below.
USA: 1•800•989•3535
Canada: 1•888•676•7325
On the web, point and click at: www.oreck.com
and click locate a store on the top right.
Safety ........................................................................................................................................... 3
General Warnings ..................................................................................................................... 3
Operation ..................................................................................................................................... 4
Parts List ................................................................................................................................... 4
Assembling the Handle Tube ................................................................................................... 5
Operating the Oreck Gold......................................................................................................... ............. 5
Replacing the HEPA Filtration Odor Fighting Inner Bags................................ ............................6
General Information ....................................................................................................................... ........... 7
The Endurolife Belt .............................................................................................................................. .. 7
Lubrication ............................................................................................................................... 7
Wood Floors, Soft (Vinyl, Asphalt Tile, etc.)
Floor Surfaces & Polished Floor Finishes ........ .......................................................................... 7
Storage ........ ............................................................................................................................... 8
Simple Operation Tips / Vacuum Care ....................................................................................... 8
HEPA Filtration Odor Fighting Inner Bags .................................................................................... ... 8
Maintenance ................................................................................................................................ 9
Replacing the Brush roll ............................................................................................................ ........... 9
Replacing the Edge Brush ........................................................................................................ ........... 9
Stufng or Blockage ................................................................................................................. 9
Motor Protection/Vacuum Shutdown ....................................................................................... 10
Troubleshooting ......................................................................................................................... 11
Parts ........................................................................................................................................... 11
Accessories & Replacement Parts ........................................................................................... 11
Warranty .................................................................................................................................... 12
Espanol ....................................................................................................................................... 13
Français ..................................................................................................................................... 25
Upright vacuum cleaner. A HEPA ltration odor
2
ENGLISH
Safety
General Warnings
IMPORTANT SAFETY INSTRUCTIONS!
When using an electrical appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
WARNING!: To reduce the risk of fire, electric shock, or injury:
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in use
and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not operate the unit while in the upright and locked position.
• Do not let the unit run while in any one stationary position for any period of time. Keep
the unit moving while in operation.
• Do not allow to be used as a toy. Close attention is necessary when used near children.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center or
call customer service at: US: 1-800-989-3535 Canada: 1-888-676-7325
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around
sharp edges or corners.
• Keep cord away from heated surfaces.
• Do not run appliance over cord.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of
dust, lint, hair and anything that may reduce air ow.
• Keep hair, loose clothing, ngers and all parts of body away from openings and
moving par ts.
• Do not use to pick up anything that is burning or smoking, such as cigarettes, matches,
or hot ashes.
• Do not use without disposable inner bag assembly in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up ammable or combustible liquids, such as gasoline or lighter uid,
or use in areas where they may be present.
• Do not use appliance in an enclosed space where ammable, explosive or toxic vapors
are given off by oil base paint, paint thinner, some mothproong substances, or in an area
where ammable dust is present.
• Do not pick up toxic material such as chlorine bleach, drain cleaner, gasoline, etc.
with this appliance.
• Use caution when vacuuming over area rug edges and fringe.
• WARNING!: Product contains chemicals know to the State of California
to cause cancer and birth defects or other reproductive harm
SAVE THESE INSTRUCTIONS
Household Use Only
To reduce the risk of electric shock, this equipment has a polarized
plug. A polarized plug has one rounded prong that is wider and one
straight prong. The rounded end goes into the longest socket slot.
This plug will t in a polarized outlet only one way. If the plug
does not t fully in the outlet, reverse the plug. If it still
does not t, contact qualied personnel to install
the proper outlet. Do not alter the
plug in any way.
3
ENGLISH
Operation
Parts List
1 Comfort Fit® Handle with soft grip
2 On/Off Switch
3 Cord Dump
4 Handle Tube
5 Deector
6 Bag Dock
7 Carry Handle
8 Zipper
9 Fascia (includes light lens)
10 Main Bumper
11 Edge Brush
12 Belt Door
13 Power Cord
14 Cord Assembly
15 Handle Collar
25
1
2
3
4
5
6
7
18
13
17
16
7
19
14
15
23
9
10
11
16 Deector (rear view)
17 Carry Handle Clamp
18 Collars
19 Lower Tube
20 Fan Housing
21 Rear Wheels
22 Cover
23 Outer Bag
24 Power Head
25 HEPA Filtration Odor
Fighting Inner Bag
8
12
22
20
21
11
24
4
ENGLISH
Operation
continued
Assembling the Handle Tube
Align slot in handle tube with tab in connector. Insert the handle tube into the
1
connector. Tighten collar at base of handle tube onto connector until it locks
with a “snap”.
Snap cord assembly into the cord clip located on the left side of the collar.
2
Leave excess cord at the power head to allow movement. Position wire
assembly along tube between rear of outer bag and outer bag covers.
1
Operating the Oreck Gold
Cord
Clip
2
Cord
Clip
Make sure the disposable inner bag is in place. DO NOT operate the vacuum without a
disposable inner bag. Plug the power cord into an electrical outlet and press the On Low
( l ) - On High ( ll ) - OFF ( O ) switch on the handle assembly when ready to operate.
Up-Position Lock - Place foot on power head and lean handle
3
back gently to release lock for vacuum use. Return handle to
the full upright position to engage lock.
Note: Do not operate the vacuum while in the upright and
locked position. Do not let the vacuum run while in any one
stationary position for any period of time. Keep the vacuum
moving while in operation.
Carry Handle - Raise the carry handle
4
located on back of the vacuum for
easy lifting, carrying, and vacuuming
stairs. Lower the handle during use to
eliminate obstruction.
3
4
6
Easy Power Cord Storage - Raise carry handle and wrap power
5
cord around carry handle and Comfort Fit® handle.
Cord Dump - To release cord, twist cord dump located on Comfort
6
Fit® handle 1/2 turn. Slide cord off handle.
5
5
ENGLISH
Operation
continued
Replacing the HEPA Filtration Odor Fighting Bag
WARNING: Unplug cord from electrical outlet before servicing.
INNER BAG REMOVAL:
Unzip outer bag completely.
1
Pull plastic tab on bag dock to release bag dock from connector. Bag dock
2
door will hinge downward.
Gently pull bag cardboard collar upward out of the bag dock. Saniseal®
3
dust seal will close automatically.
2
1
INNER BAG INSTALLATION:
Slide the cardboard collar completely onto bag dock door.
4
Firmly push bag dock door with both thumbs on indication point until it snaps.
5
4
3
5
6
ENGLISH
General
Information
The Endurolife Belt
The Oreck Gold is equipped with the Endurolife Belt, which is designed for long life and
doesn’t need changing. If the vacuum sucks up a large obstruction, the Endurolife Belt is
designed to shut the upright down.
WARNING: Unplug cord from electrical outlet before servicing.
1. Clear any large obstruction or blockage from the vacuum.
2. Once the blockage is cleared, plug the vacuum back in and it will reset.
NOTE: If the vacuum continues to shut down, contact an Oreck Authorized
Service Center.
Lubrication
The vacuum motor bearings are factory lubricated and sealed. Further lubrication is not
required.
CAUTION
Wood Floors, Soft (Vinyl, Asphalt Tile, etc.)
Floor Surfaces and
Polished Floor Finishes
Use oor and oor nish manufacturer’s recommended
methods of cleaning. The brushroll may also scuff very
soft nishes. Do not operate the vacuum while in the
upright and locked position. Do not let the vacuum run
while in any one stationary position for any period of
time. Keep the vacuum moving while in operation.
Note: At least once a month, check for and remove
excessive lint, string or hair from the revolving
brushroll. Patented cleaning grooves on the brushroll
will allow easier cleaning. Wipe the outside of the
vacuum with a damp cloth. Also clean the connector
deector assembly area, base of vacuum and fan
housing area. If there is dust in the outer bag, vacuum it
or shake it out.
A little preventative maintenance will keep your Upright
vacuum looking new and will ensure continued cleaning
effectiveness.
7
ENGLISH
General
Information
continued
Storage
Both the Comfort Fit® handle and carry handle can be used for convenient, space saving storage
of cleaner. Hang cleaner by carry handle on a sturdy fastener or Comfort Fit® handle on a closet
rod.
Simple Operation Tips / Vacuum Care
You’ll love the way your Oreck cleans under things, and is SO lightweight and easy to use.
The following are a few simple suggestions regarding its operation:
• When inserting a new disposable inner bag, rst puff out and OPEN the bag.
• When the disposable inner bag is full, replace it.
• Check the disposable inner bag at least once a month.
• Do not run the vacuum over the cord. The revolving brushroll could damage the cord.
• Use caution when vacuuming over area rug edges and fringe.
• If at any time the machine does not pick up properly or makes an unusual noise, stop
operation and service.
• Although your upright will pick up pins, paper clips, and other small objects, it is
recommended that these be removed from the oor before you vacuum. Failure to do
so may result in permanent damage to the motor suction fan and its housing.
• At least once a month, check for and remove excessive lint, string or hair from revolving
brushroll. Wipe the outside of the vacuum with a damp cloth. Also clean the connector
deector assembly area, base of vacuum and fan housing area. If there is dust in the outer
bag, vacuum it or shake it out.
The performance of your new vacuum greatly depends upon care and maintenance. The
instructions in this manual will guide you in performing basic care and maintenance. To obtain
the most satisfying years of service read the instructions and keep them handy for future
reference.
HEPA Filtration Odor Fighting Inner Bag
Your Oreck includes a HEPA Filtration Odor Fighting Inner Bag. The
disposable inner bag plays a very important role in the efciency of
your ORECK vacuum. The purpose of the disposable inner bag is to
trap dirt, but at the same time it must be porous enough to allow air to
pass through. If the disposable inner bag becomes clogged, no air can
pass through the vacuum and cleaning cannot take place, regardless of
the vacuum’s power.
To keep your Upright vacuum operating at maximum efciency,
change the disposable inner bag frequently. DO NOT FILL ABOVE THE
LINE INDICATED ON THE DISPOSABLE INNER BAG.
Be sure the disposable inner bag is installed properly. Note: All
disposable inner bags are not the same. Oreck offers HEPA and nonHEPA inner bags. Your Oreck HEPA or non-HEPA inner bags have
been designed to be used with the ORECK Upright vacuum. Using
bags other than genuine Oreck HEPA or non-HEPA disposable inner
bags will affect the cleaning ability of your vacuum and could cause
damage to it.
8
ENGLISH
Maintenance
Replacing the Brushroll
The brushroll is designed for long life. Should it ever become worn or frayed, it can be replaced
by an Oreck Authorized Service Center.
Replacing Edge Brush
WARNING: Unplug cord from electrical outlet before servicing.
Turn the power head over. With baseplate facing up,
remove the screw located in the center of each edge
brush. Remove both edge brushes and replace with new
ones. Replace both screws and tighten.
Stuffing or Blockage
IMPORTANT: On plush and new carpets, stufng may occur inside the intake tube and the
lower tube assembly. This is due to excessive fuzz and loose cuttings in the carpet. Stufng
could occur for the rst few cleanings until all the loose material is removed. Due to the
high efciency of the vacuum, many older carpets will cause stufng when the vacuum is
rst used on them. If your vacuum does not pick up properly, or makes unusual noise and the
outer bag does not uff up or balloon open, follow these steps:
WARNING: Unplug cord from electrical outlet before servicing.
Check for blockage at the mouth of the intake opening. If there
1
is blockage, remove it with long-nose pliers, a screwdriver or
coat hanger.
If the blockage is not at the base, remove lower tube. Unhook
2
bag spring, releasing bottom of bag.
3
Twist lower collar counterclockwise to slide up. Pull tube out
of base. Check for blockage. If blockage is in the tube, remove
with a coat hanger.
4
If tube is not blocked, look into fan housing. Remove debris
with long-nose pliers, a screwdriver or coat hanger.
3
1
2
3
4
9
ENGLISH
Maintenance
continued
To reassemble, check O-ring on tube, and replace if damaged. Replace tube by
5
rst lining up slot at base of tube with tab inside fan housing.
Insert tube and push down until the tube is seated. Make sure O-ring is in place
6
against fan housing opening. Replace and tighten collar until collar locking
tabs are locked in place. Reattach bag spring.
Many times blockage occurs due to a full disposable inner bag causing dirt to
7
back down the air ow system. When that happens, the blockage will be at the
top of the system, starting in the area where the disposable inner bag connects
to the deector.
5
6
7
Motor Protection/Vacuum Shutdown
If the vacuum becomes overloaded, which could occur by sucking up a large obstruction or on
extremely thick carpet, the electronics are designed to shut down the vacuum. If this happens,
the vacuum will be turned off but the headlights will remain on. To reset the vacuum turn the
unit off, wait 5 seconds, and then turn it back on. If it shuts down again there may be a large
obstruction in the vacuum.
Note: If the above actions do not correct the problem, contact an Oreck authorized service
center or call the customer service center. US: 1-800-989-3535 Canada: 1-888-676-7325
10
Troubleshooting
Service problems that
appear to be major can
often be solved easily.
You can be your own
troubleshooter by
reviewing this guide.
All other servicing
should be done by an
Oreck authorized
service center.
ENGLISH
Vacuum will not run.
Vacuum does not
pick up.
• Not plugged in properly.
• No electricity in wall outlet.
• The Brushroll is blocked.
• Did the vacuum shutdown on
very dense material or large
obstruction?
• HEPA Filtration Odor
Fighting Inner Bag is full.
• Nozzle or intake pivot clogged.
• Brush is worn.
• Bag tube clogged.
• Bag pores are clogged
with ne dust.
• Impeller fan is broken
• Brushroll is not even at both ends
What to doProblem Check
• Be sure power cord is rmly plugged into wall outlet.
• Check electrical source – fuse or circuit breaker.
• Clear blockage. Unit will reset (see page 9).
• Turn the unit off and wait 5 seconds and vacuum will
reset. You can also unplug unit and vacuum will reset.
See steps on clearing an obstruction on page 9.
• Replace HEPA Filtration Odor
Fighting Inner Bag (see page 8).
• Clear blockage (see page 9).
• Contact Oreck Authorized Service Center
• Clear blockage (see page 9).
• Change HEPA Filtration Odor
Fighting Inner Bag (see page 8).
• Contact Oreck Authorized Service Center
• Contact Oreck Authorized Service Center
Parts
Vacuum still does not
operate properly.
All accessories and replacement parts are sold separately. To order, call our customer service
hotline or visit our website. Please have your model number from the data label on the bottom of
the unit.
• Check all the above points.
• Contact Oreck Authorized Service Center.
Accessories
Item
Crystal Aroma® Carpet and Room Freshener AROMAII
Oreck Dry Carpet® Cleaning System 303088
Replacement Parts
Part NumberItem
HEPA Filtration Odor Fighting Inner Bag, 8 Pack CCPK8OH
Customer Service Hotline
USA: 1-800-989-3535 Canada: 1-888-676-7325
website: www.oreck.com
11
ENGLISH
Warranty
ORECK MANUFACTURING COMPANY: (Oreck Manufacturing Company gives you the
following limited warranty for this product only if it was originally purchased for residential
use, not resale, from Oreck or an Oreck Authorized Retail Dealer.)
Oreck will repair, replace, free of charge to the original purchaser, any part that is found to be
defective in material or workmanship for the lifetime of the product. This lifetime limited
warranty applies to normal domestic use. Any commercial use of this product will void this
limited warranty.
This limited warranty does not cover the replacement of expendable or consumable parts
such as carbon motor brushes, edge brushes, brushrolls, gaskets, microsweep, wheels,
disposable inner bags and other parts subject to normal wear unless they are defective in
material or workmanship.
This limited warranty does not apply to any part subjected to accident, abuse, commercial use,
alteration, misuse, damage caused by an act of God, the use of voltages other than indicated
on the serial number displayed on this product or service of this product by other than Oreck
or a participating Factory Authorized Service Center. Oreck does not authorize any person or
representative to assume or grant any other warranty obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof of purchase from Oreck or an Oreck
authorized retail dealer for this product. If you purchase this product from any other source,
your purchase is “AS IS,” which means Oreck grants you no warranty, and that you, not Oreck,
assume the entire risk of the quality and performance of this product, including the entire cost
of any necessary servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever arising out of this statement of
limited warranty shall be limited to the amount paid for this product at the time of original
purchase, and Oreck shall not be liable for any direct, indirect, consequential or incidental
damages arising out of the use or inability to use this product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
HOW TO FILE A CLAIM FOR WARRANTY
If there is an issue with your vacuum you believe is covered by this warranty, contact Oreck
customer service at 1-800-989-3535.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD,
AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER
THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above
limitation may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary
from state to state. If appropriate, see additional information for extended warranty.
12
Loading...
