SIMPLY AMAZING
®
USER’S GUIDE
Table Top Air Purifier
AIR7
Series
•IMPORTANT•
SAVE THIS BOOKLET!
Includes:
• Warranty
• Safety Warnings
• Parts List
• Operating Instructions
• Accessories List
• Trouble Diagnosis
Polarized Plug Notice
BEFORE OPERATING AIR PURIFIER,
READ ALL INSTRUCTIONS IN
THIS MANUAL CAREFULLY.
This product is equipped with a polarized alternating current line plug (a
plug having one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact an electrician to replace the obsolete outlet.
Do not defeat the purpose of the polarized plug.
Table of Contents
Important Safety Instructions, Polarized Plug Notice, Warranty,
Maintenance and Customer Service, Introduction . . . . . . . . . page 2
How Your Electronic Air Purifier Works, Operation,
Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Cleaning, Replacing the Charcoal Odor Absorber (Optional) ,
Replacing Cell After Cleaning, Replacing Fragrance Cartridge,
Troubleshooting Guide, Accessories . . . . . . . . . . . . . . . . . . . . page 4
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic
precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS AIR PURIFIER
WARNING
To reduce the risk of fire,
• Do not use outdoors or on wet surfaces.
• Use only as described in this manual.
• Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service
center or call customer service at:
US: 1-800-989-3535 Canada: 1-888-676-7325
• Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair and anything
that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of body
away from openings and moving parts.
• Turn off all controls before unplugging.
Do not use appliance in an enclosed space where
•
oxygen, flammable, explosive or toxic vapors are given
of
substances, or in an area where flammable dust is present.
electric shock, or injury:
f by oil base paint, paint thinner, some mothproofing
SAVE THESE INSTRUCTIONS
Household Use Only
CAUTION
Installing a wet or even damp collection cell into the air
purifier may cause melting of internal components during use.
• DO NOT place a wet or damp collection cell in the air purifier.
• DO NOT wash the charcoal odor absorber. Replace, if
necessary.
• Dry the collection cell thoroughly outside of the air purifier
before reinstalling it into the air purifier
all areas including corners and areas that may trap water are
dry before reinstalling into the air purifier.
FOR COMMERCIAL USE:
High voltage from collection cell may cause ignition of
flammable or explosive gases/particles in the circulation air
• DO NOT use in an area that contains flammable or explosive
gases/particles in the circulating air.
. Ensure that
.
Warranty
ORECK MANUFACTURING COMPANY: (Oreck Manufacturing Company
gives you the following limited warranty for this product only if it was
originally purchased for residential use, not resale, from Oreck or an Oreck
Authorized Retail Dealer.)
Oreck will repair or replace, free of charge, to the original purchaser, any
part that is found to be defective in material or workmanship within one (1)
year of the date of purchase.
This limited warranty does not cover the replacement of expendable or
consumable parts such as filters, cells, cartridges, and other parts subject
to normal wear unless they are defective in material or workmanship.
This limited warranty does not apply to any part subjected to accident,
abuse, commercial use, alteration, misuse, damage caused by act of God,
the use of voltages other than indicated on the serial number displayed on
this product or service of this product by other than Oreck or a participating
Factory Authorized Service Center.
Oreck does not authorize any person or representative to assume or grant
any other warranty obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof of purchase from
Oreck or an Oreck Authorized Retail Dealer for this product. If you
purchase this product from any other source, your purchase is “AS IS,”
which means Oreck grants you no warranty, and that you, not Oreck,
assume the entire risk of the quality and performance of this product,
including the entire cost of any necessary servicing or repairs of any
defects.
Oreck’s liability for damages to you for any costs whatsoever arising out of
this statement of limited warranty shall be limited to the amount paid for this
product at the time of original purchase, and Oreck shall not be liable for
any direct, indirect, consequential or incidental damages arising out of the
use or inability to use this product.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply
to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT,
INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER
EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties,
so the above limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Maintenance and Customer Service
Your Oreck Air Purifier is a product of precise engineering. If you require
additional information or have problems with your Oreck appliance, you
may call ORECK
US: 1-800-989-3535 Canada: 1-888-676-7325
Please specify the model number and serial/code number which can be
found on the data plate on the back of the
Save your sales or purchase slip. Should your Oreck appliance require
warranty service in the U.S.A., present this slip to the Authorized Service
Center as your proof of purchase date or, in Canada, call customer service.
Introduction
The air you breathe is filled with thousands of particles of air pollution.
Some of the pollutants like dust and lint are large enough to be visible to
the naked eye, but pollutants such as pollen, smoke, germs, bacteria,
etc., are microscopic in size.
designed to trap and remove visible and invisible pollutants and provide
your home or of
Airborne particles and odors are removed from air passing through the
unit by the process of electrostatic precipitation and an activated charcoal
odor absorber. The fragrance feature releases a pleasant aroma with the
newly cleaned air.
2
customer service at:
Air Purifier
our electronic air purifier has been
Y
fice with the luxury of clean air living.
.
PRE-FILTER ELECTRONIC CELL
ELECTRONIC IONIZER
CHARCOAL ODOR
ABSORBER
POWERFUL FAN
NEGATIVE ION GENERATOR
1
3
4
5
2
1
2 3
4 5 6
7
How Your Electronic Air Purifier Works
Polluted air enters the air purifier through the front grill. As the air is
pulled through, a pre-filter helps trap large particles (hair, lint, etc.). Then
an electronic ionizer electrostatically charges smaller particles (dust,
smoke, pollen). The positive charged particles then enter the negatively
charged electronic cell, where the aluminum plates attract and retain the
particles. It works like a powerful magnet and the particles remain until
the electronic cell is cleaned. The air then passes through a charcoal
odor absorber that helps remove household odors. Next, the negative
ion generator releases negative ions to freshen the air. Finally,
electronically cleaned air passes back into the room through the top grill.
Operation
1. MAIN POWER SWITCH: T
to the blower speed you prefer: High ( ) for maximum cleaning Medium ( ) for normal use - Low ( ) for quiet operation.
2. FRAGRANCE CARTRIDGE: Fragrance compartment switch ejects
drawer for access to fragrance cartridge. Insert fragrance cartridge
and close drawer. One fragrance cartridge included.
3. IONIZER POWER SWITCH: Turns the ionizer ON or OFF. The
indicator light will glow green when ON and functioning properly.
4. POWER INDICATOR LIGHT: The indicator light will glow green when
the unit is operating normally. It will flash red when the collector cell
requires cleaning. NOTE: The light will glow red for a moment
when unit is first turned on. This is normal and only a test of the
system.
. AIR DIRECTION CONTROL: Slide switch on top of unit controls the
5
louvers and enables you to direct airflow to desired areas.
NOTE: Y
ou may notice an occasional infrequent sharp snapping
sound coming from your unit. This is a normal occurrence called
“arcing” and results as large particles of dust are collected in the
ionizing-collecting cell. Should prolonged or continuous arcing
occur, the ionizing-collecting cell should be thoroughly cleaned
and dried completely (See “Cleaning Collector Cell”).
urn the unit on by sliding the power switch
Instructions
WARNING: DO NOT USE THIS ELECTRONIC AIR PURIFIER WHEN
OXYGEN TANKS ARE BEING USED OR IN THE PRESENCE OF
COMBUSTIBLE GASES.
3
IMPORTANT NOTES:
●
Your air purifier works best if you leave it in operation all the time.
●
Place or mount the air purifier near a standard electrical outlet. Do
not block either the air intake or outlet grill.
●
Never place your air purifier on soft surfaces (such as bed, sofas or
carpet), near computers or next to sources of heat (such as stove
tops, ovens, etc.)
●
Make sure the front grill is securely locked in place.
●
A safety switch is installed behind the grill of your electronic air
purifier. If the grill is not properly secured in place, the unit will not
operate. If your unit fails to operate, remove the front grill and reinstall
it, being sure that the lower right-hand side of the grill (next to the
control panel) is firmly locked in place.
●
Plug the power cord into the nearest available standard electrical
outlet. (See data label on bottom of your air purifier for electrical
specifications and power consumption.)
●
Do not use an extension cord to supply power to your air purifier.
Cleaning
every two months or as needed.
charcoal odor absorber. Replace, if necessary.
Replacing Cell After Cleaning
1. Snap in the charcoal odor absorber. (fig. 3)
2. Slide in the pre-filter. (fig. 4)
3. Slide cell into cabinet, using handles. (fig. 2)
4. Replace front grill. Unit is now ready for operation. (fig. 1)
NOTE: An occasional “arcing” sound is normal when operating the
unit immediately after cleaning the cell and should stop after a few
minutes of operation.
Replacing Fragrance Cartridge
1. Open cartridge compartment by sliding the compartment release switch.
(fig. 5)
2. Remove fragrance disk from center of cartridge and replace with a
new one.
3. Close compartment until it locks. (fig. 7)
NOTE: One fragrance cartridge is included.
(fig. 6)
IMPORTANT: DO NOT wash the
Troubleshooting Guide
The Cabinet
You can clean the air purifier cabinet with mild, non-abrasive cleanser and a
soft cloth. IMPORTANT: Unplug the unit from its electrical power source.
Do not spray cleansers or furniture polish into the louver or grill areas.
Collector Cell
Indicator light is green under normal operation and flashes red
when the cell requires cleaning. To clean, proceed as follows:
The red "WASH CELL" light will flash or illuminate when it is
time to clean your cell. However, it is recommended that every four to
eight weeks or if snapping sounds become frequent, clean your
electronic air purifier. Your electronic air purifier is still filtering the air
when the red light illuminates. Cleaning your electronic air purifier is a
snap too... and a must for efficient operation.
1. Turn the unit off and unplug it from the electric power source. If wall
mounted, remove unit from wall.
2. Remove front grill by unscrewing the retainer screw under the grill on
the cabinet bottom.
3. Pull the cell out of the cabinet by using the two small handles on the
front of the cell. (fig. 2)
4. Snap off the charcoal odor absorber from the back of the cell. Change
as necessary for continued odor removal. (fig. 3)
5. Slide off pre-filter. This can be cleaned with the cell and reused. (fig. 4)
NOTE: Handle the electronic cell with care. Damaged metal plates
and/or broken wires will cause the air purifier to malfunction. (Do
not wash charcoal odor absorber; it is disposable.)
Cleaning with Assail-A-Cel
Assail-A-Cell
Using
6.
filter. Be sure to spray between each cell plate and cover every
surface. Allow product to soak for a few minutes, not allowing it to dry.
Rinse thoroughly with water. For extremely heavy deposits, repeat the
process.
IMPORTANT:
air purifier before reinstalling it into the air purifier. Ensure
that all areas including corners and areas that may trap
water are dry before reinstalling into the air purifier. DO NOT
place a wet or damp collection cell in the air purifier.
(fig. 1)
®
l
Cell Cleaner:
®
Dry the collection cell thoroughly outside of the
, thoroughly saturate the cell and pre-
Cleaner
Replacing the Charcoal Odor
Absorber (Optional)
In addition to air purification, your Oreck provides the additional benefit
of odor removal. The odor removal function is optional. Your Oreck Air
Purifier will continue to remove harmful airborne particles with its
permanent electronic collector cell even if you choose not to use the
optional charcoal odor absorber.
Odor absorption effectiveness will gradually deteriorate over time unless
the charcoal odor absorber is replaced. While every environment is
different, Oreck suggests that the charcoal odor absorber be replaced
© 2006 Oreck Holdings, LLC. All Rights Reserved. All word mark, logos, product configurations, and registered trademarks are
owned and used under the authority of Oreck Holdings, LLC.
Service problems that appear to be major can often be solved easily
can be your own troubleshooter by reviewing the chart below. It pinpoints
problems and how to correct them. Remember, check the simple things first.
PROBLEM CHECK WHAT TO DO
UNIT
DOES NOT TURN
ON
INDICATOR LIGHT ON
UNIT IS FLASHING RED
OR HAS TURNED RED
UNIT DOES NOT
REMOVE POLLUTANTS
UNIT SPARKS,
CRACKLES AND POPS
DOES NOT REMOVE
ODOR
UNIT STILL DOES NOT
OPERATE PROPERLY
1. Power Cord
2. Selector Switch
3. Front Grill
Ionizer/collector cell
Ionizer/collector cell
Ionizer/collector cell
Old Charcoal Odor
Absorber
Check all the above
points
ALL OTHER SERVICING SHOULD BE DONE BY AN
ORECK AUTHORIZED SERVICE CENTER.
CALL CUSTOMER SERVICE HOT LINE
US:1-800-989-3535 Canada:
Whenever calling, please be sure to have your model and serial
number from data plate.
Accessories
ITEM PART #
1. Pre-Filter 7780-8041
Ionizer/Collector Cell
2.
Charcoal Odor
3.
4. Wall Mounting Kit 8660-0201
5. Oreck Fresh Air
Spring Mulberries®, 8pk.
Blooming Jasmine
4
Absorber (Set of 4)
®
Scent Cartridges
®
, 8pk. FA3PK
3323-3018 REV H 01/06 ECN# R-8239, R-8240
. You
1. Plug in power cord
2. Set selector switch
for desired blower
speed.
3. Reinsert front grill
until it is flush with
cabinet front. Tap grill
lightly, if necessary, to
fully insert.
Wash ionizer/collector
cell. Make sure it is
thoroughly clean & dry
before re-installing it.
Wash cell
A little is normal. Make
sure the cell is
thoroughly dry before
re-installing it.
If it persists, clean cell.
If that doesn’t help, cell
may be damaged and
needs replacing.
Replace Charcoal
Odor Absorber.
Return unit to the
Service Center.
1-888-676-7325
09-5510-7065
T4PK7
A
A2PK
F
Loading...
