Onkyo TX-8140 Instruction Manual

Network Stereo Receiver

TX-8140

Instruction Manual

Thank you for purchasing an Onkyo product. Please retain this manual for future reference.

Contents

Supplied accessories

Names and functions of parts 7

0 Front 7 0 Display 8 0 Remote control 9 0 Rear 10

Connections 11

0 Connecting speakers 11 0 Connecting a player 12 0 AM/FM antenna connections 13 0 Network connection 14

Listening to Internet radio 16

Playing music with Bluetooth

functions 22

Playing music with Spotify 23

Playing tracks stored on a USB storage device 24

Home network functions 25

0 Playing music stored on DLNA-compatible

devices 25

0 Music streaming from a shared folder

(Home Media) 26

Before use, check the packaging for the main unit and the accessories below.

∫ Remote control (RC-904S)

∫ Batteries for remote control (AAA/R03)

∫ AM loop antenna

∫ Indoor FM antenna

Listening to the sound from a connected player 28

Listening to AM/FM radio 29

Various settings 32

0 Adjusting sound quality, etc. 32 0 Sleep timer 32 0 Inputting characters 33 0 Setup menu 33 0 Firmware update 36

Troubleshooting 38

Compatible devices/media/file formats 40

WARNING:

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR

AVIS

S3125A

PORTABLE CART

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Important safety instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10.

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11.

Only use attachments/accessories specified by the manufacturer.

12.

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13.

Unplug this apparatus during lightning storms or when unused for long periods of time.

14.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15.

Damage Requiring Service Unplug the apparatus from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power-supply cord or plug is damaged, B. If liquid has been spilled, or objects have fallen into

the apparatus, C. If the apparatus has been exposed to rain or water, D. If the apparatus does not operate normally by

following the operating instructions. Adjust only

those controls that are covered by the operating

instructions as an improper adjustment of other

controls may result in damage and will often require

extensive work by a qualified technician to restore

the apparatus to its normal operation, E. If the apparatus has been dropped or damaged in

any way, and F. When the apparatus exhibits a distinct change in

performance this indicates a need for service.

16.

Object and Liquid Entry Never push objects of any kind into the apparatus through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the apparatus. Don’t put candles or other burning objects on top of this unit.

17.

Batteries Always consider the environmental issues and follow local regulations when disposing of batteries.

18.

If you install the apparatus in a built-in installation, such as a bookcase or rack, ensure that there is adequate ventilation. Leave 20 cm (8") of free space at the top and sides and 10 cm (4") at the rear. The rear edge of the shelf or board above the apparatus shall be set 10 cm (4") away from the rear panel or wall, creating a flue-like gap for warm air to escape.

Precautions

1. Recording Copyright—Unless it’s for personal use

only, recording copyrighted material is illegal without the permission of the copyright holder.

2. AC Fuse—The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact the dealer from whom you purchased this unit.

3. Care—Occasionally you should dust the unit all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because they may damage the finish or remove the panel lettering.

4. Power WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY. AC outlet voltages vary from country to country. Make sure that the voltage in your area meets the voltage requirements printed on the unit’s rear panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).

The power cord plug is used to disconnect this unit from the AC power source. Make sure that the plug is readily operable (easily accessible) at all times.

For models with [POWER] button, or with both [POWER] and [ON/STANDBY] buttons: Pressing the [POWER] button to select OFF mode does not fully disconnect from the mains. If you do not intend to use the unit for an extended period, remove the power cord from the AC outlet.

For models with [ON/STANDBY] button only: Pressing the [ON/STANDBY] button to select Standby mode does not fully disconnect from the mains. If you do not intend to use the unit for an extended period, remove the power cord from the AC outlet.

5. Preventing Hearing Loss Caution

Excessive sound pressure from earphones and headphones can cause hearing loss.

6. Batteries and Heat Exposure Warning

Batteries (battery pack or batteries installed) shall not be exposed to excessive heat as sunshine, fire or the like.

7. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by the dealer from whom you purchased this unit.

8. Handling Notes

0 If you need to transport this unit, use the original

packaging to pack it how it was when you originally bought it.

0 Do not leave rubber or plastic items on this unit for a

long time, because they may leave marks on the case.

0 This unit’s top and rear panels may get warm after

prolonged use. This is normal.

0 If you do not use this unit for a long time, it may not

work properly the next time you turn it on, so be sure to use it occasionally.

For U.S. models FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Product Name: Network Stereo Receiver Model Number: TX-8140 Responsible Party Name: Onkyo U.S.A. Corporation Address: 18 PARK WAY, UPPER

SADDLE RIVER, NEW JERSEY 07458, USA

Phone: 1-800-229-1687

FCC Information for User CAUTION:

The user changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

Precautions

For Canadian Models NOTE:

CAN ICES-3 B/NMB-3 B For models having a power cord with a polarized plug:

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Modèle pour les Canadien REMARQUE :

CAN ICES-3 B/NMB-3 B Sur les modèles dont la fiche est polarisée :

ATTENTION :

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

This device complies with Industry Canada licenceexempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

RF Exposure Compliance

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20 cm or more away from person’s body (excluding extremities: hands, wrists, feet and ankles).

DISCLAIMER

Through this device you are able to link to other services or websites which are not under the control of any company which has designed, manufactured or distributed/have distributed this device, and its affiliates (collectively, “Company”). We have no control over the nature, content and availability of those services. The inclusion of any links does not necessarily imply a recommendation or endorse the views expressed within them. All information, content and services available through this device belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property laws of applicable countries. The information, content and services provided through this device are for your personal, noncommercial use only. Any information, content or services may not be used in any manner other than previously approved by the appropriate content owner or service provider. You may not modify, copy, republish, translate, exploit, create derivative works, upload, post, transmit, sell or distribute in any manner any information, content or services available through this device, unless expressly permitted by the appropriate copyright, patent, trademark and/or other intellectual property owner, including, without limitation, content owner or service provider. THE CONTENT AND SERVICES AVAILABLE THROUGH THIS DEVICE ARE PROVIDED “AS IS”. COMPANY DOES NOT WARRANT INFORMATION, CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. COMPANY EXPRESSLY DISCLAIMS ANY WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF TITLE, NONINFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Company makes no representation or warranty of any kind, express or implied, about the completeness, accuracy, validity, legality, reliability, suitability or availability with respect to the information, content or services available through this device. Company shall not be liable, whether in contract or tort, including negligence and strict liability, for any direct, indirect, special, incidental or consequential damages or any other damages arising out of, or in connection with, any information contained in, or as a result of the use of any content or service by you or any third party, even if Company has been advised of the possibility of such damages, nor shall Company be liable for any third party claims against users of this device or any third party. In no event shall Company be responsible nor liable for, without limiting the generality of the foregoing, any interruption or suspension of any information, content or service available through this device. Company is neither responsible nor liable for customer service related to the information, content and services available through this device. Any question or request for service relating to the information, content or services should be made directly to the appropriate content owners and services providers.

Features

A wide range of playback possibilities with Network Features

Connect to the router to the network to access a vast store of music. You can connect to the network via a wireless LAN router by Wi-Fi

Many of the major Internet radio services such as TuneIn Radio are preregistered in the menu

Supports Spotify. Play music from Spotify with high sound quality

Home network feature that allows you to play music files from your computer (DLNA, Home Media)

Plays high-quality 192 kHz/24 bit high-res sources

You can play high-res sources in formats such as WAV, FLAC, or DSD files (*) distributed over the Internet by using the home network feature or connecting a USB storage device.

0 Playback through the home network feature

By connecting this unit to the same router as your computer, you can play the high-res sources you downloaded to your computer using the DLNA or Home Media features with simple operations on the remote control.

Other functions

Front USB port for playing music files on a USB storage device

0 Bluetooth 0

AM/FM tuner capable of presetting up to 40 stations

BGM button that gives you access to Internet radio or AM/FM radio at the touch of a button

Opt1 In Wakeup feature that starts this unit when a player connected with a digital optical cable starts

A wide variety of music files are supported, including MP3, WAV, FLAC, DSD, WMA, MPEG4 AAC (with the home network feature and connection of a USB storage device)

function

Onkyo Remote (smartphone app)

0 Playback from connected USB storage

devices

By connecting the USB storage device containing high-res sources to this unit, you can play them with simple operations on the remote control.

The unit supports WAV and FLAC files up to 192 kHz/24 bit (up

to 96 kHz when playing WAV and FLAC files from a USB storage device). The unit can play 2.8 MHz and 5.6 MHz DSD files (only 2.8 MHz when playing from a USB storage device). See “Compatible devices/media/file formats” (> 40) for details.

High-quality, fully-fledged audio design

High-powered discrete amplifier that can drive even a large speaker system

WRAT (Wide Range Amplifier Technology)

High-power transformer with silicon steel shielding to reduce leakage flux

Closed loop circuit to stabilize the ground potential

Heavy duty parts supported from below by the oval chassis

Direct feature that outputs pure sound as it was intended by bypassing the tone control circuits during play

Optimum Gain Volume Circuitry

Two speaker terminal systems, A and B, SUBWOOFER PRE OUT jack

DIGITAL IN and LINE IN terminals to play external players. PHONO terminal that supports connection to a record player with a MM cartridge

Input source selection, volume adjustments, and other basic operations possible on your smartphone, which serves as the unit’s remote control

GUI screens that enable intuitive track selection operations on the Internet radio and DLNA

Streaming of music data stored on your smartphone Supports iOS and Android wireless LAN environment to use apps. The contents of network services are subject to change.

devices. You will need a

Names and functions of parts

Front

Í ON/STANDBY button:

unit on or put it in standby mode.

MENU/MEMORY button:

the menu or register a AM/FM station.

Playback (1)/Pause (;)/TUNING MODE button:

Press this button to playback (*), pause (*), or switch the AM/FM tuning mode.

HYBRID STANDBY LED:

Standby, Bluetooth Wakeup, or Opt1 In Wakeup are on.

Remote control signal receiver DISPLAY button: SLEEP button:

timer.

Display (> 8) SETUP button: Direction/4TUNING3/2PRESET1/ENTER buttons:

When listening to AM/FM broadcasting, tune in to the station with station with

RETURN button:

state during setting or operation.

VOLUME control:

Press this button to set the sleep

Used to display the setup menu.

Move the cursor and confirms the selection.

TUNING3 or select the registered

PRESET1.

Press this button to turn the

Press this button to display

Lights when any of Network

Change the information shown.

Returns the display to the previous

Used to adjust the volume.

PHONES terminal:

standard plug.

DIMMER button:

display’s brightness between normal, moderately dark

and dark.

SPEAKER A/B button:

audio from between SPEAKERS A/B.

INPUT control:

the control to switch the source in the following order;

BD/DVD

PHONO # TV/TAPE # AM # FM # NET

BLUETOOTH

BASS control:

TREBLE control:

BALANCE control:

between the left and right speakers.

BGM 1/2/3/4 buttons:

radio or AM/FM radio stations.

USB port:

music files stored in it can be played.

A USB storage device is connected so that

Operate with USB storage device play or the home network feature (DLNA, Home Media).

Connect headphones with a

Use this button to switch the

Select the terminals to output

Selects the source to playback.Turn

CBL/SAT

PC # GAME # CD

Adjusts the bass level.

Adjusts the treble level.

Adjusts the audio output balance

Preset your favorite Internet

Display

  



Names and functions of parts

DIRECT indicator:

of the audio quality setup is on.

Speaker selection display (A/B):

selected speaker terminals.

PCM/DSD:

signals.

Playback/Pause/Cursor display AM/FM reception statuses

AUTO: This indicator appears when Auto Tuning Mode is selected. FM STEREO: This indicator appears when the unit is tuned into a stereo FM broadcast.

TUNED2: This indicator appears when the unit is

tuned into a radio station.

Headphone indicator:

connected.

NET:

Lights when “NET” is selected as the input

source. It will flash if the connection is not correct.

MUTING indicator:

is muted temporarily.

Volume level

Lights when “USB” is selected as the input

USB:

source. It will flash if the connection is not correct.

SLEEP indicator:

sleep timer is set.

DIGITAL:

digital.

Lights when the selected input source is

This indicator appears when Direct

Displays the

Lights according to the type of input digital

Stays lit when headphones are

This indicator flashes when audio

This indicator appears when the

Message display area:

appear here.

The following icons appear.

: Folder : Track/Broadcast station name : Playing back : Paused : Searching forward : Searching backward : Artist name : Album name : Repeat all tracks : Repeat one track : Repeat tracks in the folder or playlist (DLNA) : Random

Track information and menus

Remote control

Remote control sensor

5 m (Approx. 16 ft.) or less

Batteries

(AAA/R03)

Names and functions of parts

Í button:

Press this button to turn the unit on or put it

in standby mode.

INPUT SELECTOR buttons:

Use these buttons to

select the source to playback.

Skip (:/9) buttons

Search (6/5) buttons

REPEAT button:

(*)

Turns repeat play on and off and

selects the mode. (*)

SPEAKER A/B button:

Select the terminals to output

audio from between SPEAKERS A/B.

Direction ( / / / )/ENTER buttons:

Select items with the direction buttons and press the ENTER button to confirm.

SETUP button: CH (i/j) buttons:

Used to display the setup menu.

Select registered stations.

Number buttons DISPLAY button: DIMMER button:

Change the information shown.

Use this button to switch the display’s brightness between normal, moderately dark and dark.

Pause (;) button Playback (1) button Stop (∫) button RANDOM button:

(*)

Plays tracks in the folder or playlist

(DLNA) randomly. (*)

MENU button: RETURN button:

Press this button to display the menu.

Returns the display to the previous state during setting or operation.

VOLUME 3/4 buttons AUDIO button:

Use this button to adjust sound quality,

etc.

MUTING button: CLR button:

Temporarily mutes audio.

Use this button to clear the characters

that you have input.

SLEEP button:

Press this button to set the sleep

timer.

Operate with USB storage device play or the home network

feature (DLNA, Home Media).

If you do not use the remote control for a long time, remove the batteries to prevent leakage. Note that keeping consumed batteries inside may cause corrosion resulting in damage of the remote control.

Names and functions of parts

90°90°

180°

90°

180°

90°

Rear

REMOTE CONTROL jack:

RI jack can be connected and synchronized with this unit.

FM 75h and AM ANTENNA terminals:

antennas are connected.

ETHERNET port:

Connect to the router with an

Ethernet cable.

IR IN/OUT terminals:

Connected to the multi-room remote control kit. Special devices or cables are necessary. For more information about preparation, contact the specialized stores.

Wireless antenna:

Bluetooth

using a

Used for Wi-Fi connection or when

enabled device. Adjust their angles

according to the connection status.

An Onkyo product with

The supplied

Power cord:

Connect the power cord to an AC outlet. Disconnect the power cord only after putting the unit into standby mode.

Turning on the unit may cause a momentary power surge that

might interfere with other electrical equipment on the same circuit. If this is a problem, plug the unit into a different branch circuit.

DIGITAL IN OPTICAL/COAXIAL terminals:

Connected to players. Use a digital optical cable or digital coaxial cable for connection with the digital audio output jack of a player.

GND terminal:

Connect if the record player has a

ground wire.

LINE IN terminals:

Connected to players. Use an RCA cable for connection with the LINE OUT terminal of a player.

LINE OUT terminals:

Use when connecting recording devices, such as a cassette tape deck. Use an RCA cable to connect to the LINE IN terminal on a recording device.

SUBWOOFER PRE OUT jack:

Connect a subwoofer

with built-in amplifier to amplify bass output.

SPEAKERS A/B terminals:

You can connect a set of

left and right speakers to each of the A/B terminals.

Connections

Left speaker

Right speaker

12 - 15 mm (1/2” - 5/8”)

Banana plug

The power cord must be connected only after all other

cable connections are completed.

Connecting speakers

When connecting only one set of speakers, connect to the SPEAKERS A terminals as shown in the illustration. Make correct connection between the unit’s jacks and

speaker’s jacks ( connection is wrong, a bass sound may become poor due to reverse phase.

Connect speakers with 4 h to 16 h impedance. You have to change the impedance setting if any of the speakers have 4 impedance. See setup menu “3. Hardware” - “Speaker Impedance” (

to i and j to j) for each channel. If

or more to less than 6 h

34).

Twist the wires of the speaker cable tightly before inserting into the terminals. After inserting the cables, tighten the terminals firmly by turning to the right. Note that when using commercially available banana plugs, first tighten the speaker terminals and then insert the banana plugs. It is not possible to connect by inserting the core of the speaker cable directly into the hole for a banana plug.

When also connecting to the SPEAKERS B terminals:

Connect using the same method described for SPEAKERS A. Connect speakers with 8 impedance to the both A/B terminals. In this case, change the impedance setting on this unit. See setup menu “3. Hardware”-“Speaker Impedance” (

Press the SPEAKER A/B button on the unit or the remote control to switch the speakers. (The selection changes in the order SPEAKER A SPEAKER AiB.)

34).

to 16 h

SPEAKER B

Connections

Subwoofer with built-in amplifier

Short-circuiting the i cable and j cable

Contacting the cable core to the rear panel of the unit

Connecting two or more cables to one speaker terminal of this unit

Connecting two or more cables to one terminal of a speaker

When connecting a subwoofer:

Use a subwoofer cable to connect the SUBWOOFER PRE OUT jack to the LINE INPUT terminal on a subwoofer with built-in amplifier.

Audio is not output from the SUBWOOFER PRE OUT jack when you set SPEAKER B as the speakers to output audio.

Connecting a player

You can enjoy the audio from players such as televisions, Blu-ray disc players, and game consoles.

DIGITAL IN connection

If the player has an optical or coaxial digital output terminal, connect using either a digital optical cable or digital coaxial cable to one of the DIGITAL IN terminals. To play, select the terminal name with the INPUT SELECTOR.

The following connections can cause damage so please be careful.

Note that this unit is equipped with an “Opt1 In Wakeup feature” so that when play starts on a player connected to the OPTICAL 1 (GAME) terminal, this unit comes on and

the INPUT SELECTOR automatically changes. (

The DIGITAL IN terminals can only handle PCM

34)

signals.

As the digital in optical jack of the unit has a cover, push in the cable straight against the cover as it is turned inside.

Connections

LINE IN connection

Use an RCA cable to connect to the LINE OUT terminal on the player to one of the LINE IN terminal on this unit. To play, select the terminal name with the INPUT SELECTOR.

Connect the record player (MM cartridge) to the LINE IN PHONO terminal. If the record player has a ground wire, connect it to the GND terminal of this unit. Note that if the connected record player has a built-in audio equalizer, connect it to a LINE IN terminal other than PHONO.

AM/FM antenna connections

Connect the antennas to listen to AM/FM broadcast.

You may be unable to receive radio transmissions in some areas even if you connect an antenna.

AM antenna

Assemble the AM loop antenna (supplied) and connect it to the AM terminal.

FM antenna

Connect the supplied FM antenna to the FM 75h terminal. Make sure the plug is pushed in all the way. Use a tack or similar to fix the antenna to a wall.

Connections

Network connection

This enables you to enjoy Internet radio services (*), Spotify, and the home network features. Connect to the same router as the smartphone, computer, or NAS you are going to use.

You need to be able to connect to the Internet.

Wired connection

Wi-Fi® connection

Set up the Wi-Fi connection with the access point (a wireless LAN router, for example). Set with the remote control while watching the display on the main unit.

Make the following preparations.

Write down the SSID and password (key) of the access point if they are shown in the label of the main body.

The unit supports Wi-Fi connection with 2.4 GHz access point.

, , , ,

ENTER

SETUP

RETURN

Connect to the router to this unit’s ETHERNET port with an Ethernet cable (*).

Use a shielded CAT5 Ethernet cable (straight-type).

1. Turn on the unit.

2. Press the SETUP button. The setup menu appears on the display.

3. Use the direction ( / ) buttons to select “5. Network” on the display and press the ENTER button.

If it is not displayed, wait for a moment until the network feature starts.

4. Use the direction ( / ) buttons to select “Wi-Fi” on the display, and then use the direction ( / ) buttons to select “On”.

Connections

SSID

5. Use the direction ( / ) buttons to select “Wi-Fi Setup”, and then press the ENTER button when “Start” is displayed.

6. Press the ENTER button when “Scan Networks” is displayed.

7. Use the direction ( / ) buttons to select the SSID of the access point and press the ENTER button.

If you changed the initial setting of the access point to skip password entry, step 8 is unnecessary.

If you changed the initial setting of the access point to hide the SSID, see “When the access point is not displayed”.

8. Press the direction ( / ) buttons to select an authentication method from the following and press the ENTER button.

Enter Password:

Enter the password of the access point to establish connection. Enter the password on the display.

For information on how to input characters, see

“Inputting characters” (

33) under “Various

settings”.

Push Button:

Use the automatic setting button of the access point to establish connection. Hold down the automatic setting button of the access point for the necessary seconds, select “OK” on the display and press the ENTER button.

PIN code:

Select this method when the automatic setting button of the access point is beyond the reach. The 8-digit PIN code is displayed. Register the displayed PIN code to the access point, select “OK” on the display and press the ENTER button. For how to register the PIN code to the access point, refer to its instruction manual.

When the access point is not displayed

Use the direction ( ) button to select the “Other...” on the display and press the ENTER button. Input the SSID. When “Security” is displayed on the display, make the following settings according to the router setting.

0 For information on how to input characters, see

“Inputting characters” (> 33) under “Various settings”.

∫ WPA/WPA2 method

Use the direction ( / ) buttons to select the “WPA” or “WPA2” on the display and press the ENTER button. Input the password.

∫ WEP method

Use the direction ( / ) buttons to select the “WEP” on the display and press the ENTER button. Input the password. When “Default Key” is displayed on the display, select the Default Key ID and press the ENTER button.

0 If encryption setting has not been made on the

wireless LAN router, use the direction ( / ) buttons to select the “None” on the “Security” display and press the ENTER button.

When connection is successful:

The setup menu ends

automatically.

You can confirm the connection status by pressing the SETUP button and selecting “5. Network”-“Status”.

+ 33 hidden pages
