One for All URC 4080, URC 4081 User Manual

Download
URC 4080/4081
VIDEO EXPERT
User’s Guide
INTRODUCTION
The One For All® 4-Device Video Expert remote control is our latest-generation universal remote control, designed specifically for controlling video components.
• Preprogrammed technology for easy setup of video components in your home entertainment system
• Preprogrammable Master Power key for master on/off control ofall of your equipment with a single keystroke
• A unique Video Configuration key that allow you to access home theater keys from various modes without changing device modes
• Keymover formapping (copying) keys from one mode to another
• Menu function to navigate and choose on-screen menu items for a selected component
• User-programmed macro keys to perform repetitive, time-consuming operations for easy,convenient access through the press ofa single key
• Color-coded keys to qu i c kly locate p opu l a r functions
• Code library for video components
• Co de S earch to hel p program control of older or disconti nu ed component s
Before using your new remote control,you will need to program it to operate the specific home entertainment components you wish to control.Please follow the instructions detailed in this manual and then enjoy your new One For All 4-Device Video Expert remote control.
3
TABLE OF CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions. . . . . . . . . . . . . . . . . . . . . . 4
Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming TV Control. . . . . . . . . . . . . . . . . . . . . 8
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . 8
Programming VCR Control . . . . . . . . . . . . . . . . . . 12
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . 12
Programming TV/VCR Combo Control . . . . . . . . 16
Setup Codes for TV/VCRs . . . . . . . . . . . . . . . . . . . 17
Programming Cable Converter or Satellite Receiver Control
. . . . . . . . . . . . . . . . . . . 18
Setup Codes for Cable Converters . . . . . . . . . . . . . 18
Setup Codes for Satellite Receivers. . . . . . . . . . . . 20
Programming DVD Player Control . . . . . . . . . . . . 21
Setup Codes for DVD Players. . . . . . . . . . . . . . . . . 22
Setup Codes for LD Players. . . . . . . . . . . . . . . . . . 22
Searching For Your Code
. . . . . . . . . . . . . . . . . . . . 23
Checking The Codes . . . . . . . . . . . . . . . . . . . . . . . 24
Programming The Power Key
. . . . . . . . . . . . . . . . 25
Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . 26
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . 27
To Change Volume Lock to the CBL/SAT Mode. . . . 27
To Change Volume Lock to the VCR Mode . . . . . . . 27
To Change Volume Lock to the DVD Mode . . . . . . . 27
To Change Volume Lock Back to the TV Mode . . . . 28
To Unlock Volume Lock . . . . . . . . . . . . . . . . . . . . . 28
Using The Menu Key . . . . . . . . . . . . . . . . . . . . . . . 28
Using Keymover . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using Macros. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Programming a Favorite Channel . . . . . . . . . . . . . 30
Programming a Secondary Master Power Key . . . . 31
Clearing a Macro . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using The Video Configuration Mode
. . . . . . . . . 32
An Example Video Configuration. . . . . . . . . . . . . . 33
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Additional Information. . . . . . . . . . . . . . . . . . . . . . 36
2
Key Charts
Use SET for all programming sequences.
The LED (red light) blinks to show that the remote control is working and is sending signals.
Use M.POWER to set up and turn on (or off) all your video components with a single key.Also see page 25.
Press POWER once to turn on (or off) a selected home entertainment component.
Press TV,DVD,VCR,or CBL/SAT once to select a home entertainment video component to cont rol .
Use the F1, F2, F3, or F4 keys to program macros.Also see page 30.
Use EXIT to exit out of your cable converter’s menu and guide.
Press MENU once to display th e selected component’s screen menu.Use the VOL +/- and CH +/- key s to navi gate menu s and press the MUTE key to select items.
Press TV/VID to switch view ing between TV and video sources.
Use VOL + (or VOL -) to raise (or lower) the sound volume.
Use CH + (or CH -) to select the next higher (or lower) channel.
Press MUTE/SELECT once to turn sound offor on.Also,use MUTE/SELECT to select items from the selected component’s screen menu after pressing MENU once.
After pressing MENU,use the Cursor Keysto move the cursor in the program guide and menu screens.
continued on next page...
5
FEATURES AND FUNCTIONS
Use the ill us tratio n belo w t o l oca t e One For All 4-Device Video Expert remo t e c o ntrol features and then study the Key Charts (on the next tw o pag e s) t o lea rn ho w th ey function.
4
FEATURES AND FUNCTIONS
Key Charts (Continued)
Press PIP once to view or turn offthe picture-in-picture feature.
Press SWAP once to exchange the PIP with the main TV picture.
Use MOVE to the picture-in-picture position on the TV screen.
Press SLEEP once to enable (or disable) a selected compon ent’s sleep t imer (if available).
Use DISPLAY to view a selected component’s information on the TV.
Use the keypad (0~ 9) to directly select channels (e.g.,09 or 31).
Press ENTER once a fter entering channel numbers on some TV models.
Press PREV.CH once to recall the last-viewed channel.
Use V .CONFIG to custom program and recall video configuration modes for home theater use.Also see page 32.
In the TV,DVD,or VCR mode,use the
FWD SCAN,REW SCAN,PLAY,STOP,and PAUSE keys to control your VCR or DVD
(or LD) player.To record a program on,
the VC R,press REC twice.
6
7
INSTALLING BATTERIES
1. On the back ofthe remote contro l, press the recess and slide the battery cover off(see above).
2. Obtain two (2) fully-charged AA alkaline batteries.Match the + and – marks on the batteries to the + and – marks in the battery case,then insert the new batteries.
3. Align the cover keys with the case openings and slide the cover on until it locks.
4. Test the unit by pressing POWER and any mode key (e.g.TV,DVD,VCR,or CBL/SAT).Ifbatteries are inserted correctly,the LED will blink once.
NOTE:When batteries need replacement,the One For All 4-Device Video Expert remote control will cease to operate.Simply replace the batteries and the unit will be restored to its full func­tionality,complete with your favorite settings.
❶
❷
❸
Ampro 0751 Anam 0180 Audio v ox 0451,0180,0092,0623 Baysonic 0180 Belcor 0019 Bell & Howell 0154 Bradford 0180 Brockwood 0019 Broksonic 0236,0463 CXC 0180 Candle 0030,0056 Carnivale 0030 Carver 0054 Celebrity 0000 Cineral 0451,0092 Citizen 0060,0030,0056,0039,0092 Concerto 0056 Contec 0180 Craig 0180 Crosley 0054 Crown 0180,0039 Curtis Mathes 0047,0054,0154,0051,0451,0093,0060,0030,0145,0056,
0039,0166,0466,1147,1347 Daewoo 0451,0019,0039,0092,0623,0624 Daytron 0019 Denon 0145 Dumont 0017,0019 Dwin 0720,0774 Electroband 0000 Emerson 0154,0236,0463,0180,0178,0019,0179,0039,0177,0623,
0624 Envision 0030 Fisher 0154 Fujitsu 0179,0683 Funai 0180,0179,0171 Futuretec h 0180 GE 0047,0051,0451,0093,0178,0135,1147,1347 Gibralter 0017,0030,0019 GoldStar 0030,0178,0019,0056 Gradiente 0053,0056 Grunpy 0180,0179 Hallmark 0178 Harley Davidson 0179 Harman/Kardo n 0054 Harvard 0180 Hitachi 0145,0056,0151 Infinity 0054 Inteq 0017 JBL 0054 JCB 0000 JVC 0053
continued on next page...
9
PROGRAMMING TV CONTROL
NOTE:If you own a TV/VCR combination,skip this section and perform “Programming TV/VCR Combo Control”on page 16.
Locate the brand name ofyour TV in the Setup Codes For TVssection below,and w rite it in the following space.
TV Brand: __________________________________ The brands are listed in alphabetical order with the most
popular codes listed first.To program TV control:
1. Turn on the TV.
2. On the remote control,press TV once.Press an d hold SET until the LED blinks twice,then release SET.
NOTE:The remote control will exit programming if more than 10 seconds elapse between key presses.
3. Enter the first four-digit code for your TV. If you perform this procedure correctly,the LED will blink twice.
NOTE:If the LED emits a long blink,the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote controlat your TV and press POWER once.The TV should turn off.If it does not respond,repeat steps 2-3,trying each code for your brand until you find one that works.If it still does not work,try searching for the code (see Searching For Your Codeon page 23).
5. Write your TV code in the boxes below for future reference.
NOTE:Remember,to use the One For All 4-Device Video Expert remote control to operate your TV,press TV first.
Setup Codes for TVs:
AOC 0030,0019,0052 Admiral 0093,0463 Aiko 0092 Akai 0030 Alaron 0179 Ambassador 0177 America Action 0180
8
Sansei 0451 Sansui 0463 Sanyo 0154 Scimitsu 0019 Scotch 0178 Scott 0236,0180,0178,0019,0179 Sears 0047,0054,0154,0156,0178,0179,0056,0171 Semivox 0180 Semp 0156 Sharp 0093,0165,0039 Shogun 0019 Sony 0000 Soundesign 0180,0178,0179 Squareview 0171 Starlite 0180 Supreme 0000 Sylvania 0054,0030 Symphonic 0171 TMK 0178,0056,0177 Tandy 0093 Technics 0051,0250 Technol A ce 0179 Techw ood 0051,0056 Teknika 0054,0180,0150,0060,0019,0179,0056,0039,0092 Telefunken 0056 Tera 0031 Toshiba 0154,0156, 0060,1256 Totevision 0039 Vector Research 0030 Victor 0053 Vidikron 0054 Vidtech 0178,0019 Wards 0054,0165,0030,0178,0019,0179,0056 White Westinghouse
0463,0623,0624 Yamaha 0030,0019 Zenith 0017,0463,0092,0624
11
PROGRAMMING TV CONTROL
Setup Codes for TVs (Continued):
KEC 0180 KTV 0180,0030,0039 Kaypani 0052 Kenw ood 0030,0019 LG 0056 LXI 0047,0054,0154,0156, 0178 Luxman 0056 MGA 0150,0030,0178, 0019 MTC 0060,0030,0019,0056 Magnavox 0054,0030,0179,1254 Marantz 0054,0030 Matsushita 0250 Megatron 0178,0145 Memorex 0154,0250,0463,0150,0178,0056 Midland 0047,0017,0051,0039,0135 Mitsubishi 0093,0150,0178,0019 Motor ola 0093 Multitech 0180 NAD 0156,0178,0166 NEC 0030,0019,0056 NTC 0092 Nikko 0030,0178,0092 Onwa 0180 Optimus 0154,0250,0166 Optonica 0093,0165 Orion 0236,0463,0179 Panasonic 0051,0250 Penney 0047,0156,0051,0060,0030,0178,0019,0056,0039,0135,
1347 Philco 0054,0463,0030,0145,0019 Philips 0054 Pilot 0030,0019,0039 Pioneer 0166 Portland 0019,0039,0092 Prism 0051 Proscan 0047 Proto n 0178,0031,0052,0466 Pulsar 0017,0019 Quasar 0051,0250, 0165 RCA 0047,0051,0093,0019,0090,0135,1047,1147,1247,1347,
1447 Radio Shack 0047,0154,0165,0180,0030,0178,0019,0056,0039 Realistic 0154,0165,0180,0030,0178,0019, 0056,0039 Runco 0017,0030 SSS 0180,0019 Sampo 0030,0039,0052 Samsung 0060,0030,0178,0019,0056 Samsux 0039
10
13
PROGRAMMING VCR CONTROL
NOTE:If you own a TV/VCR combination,skip this section and perform “Programming TV/VCR Combo Control”on page 16.
Locate the brand name of your VCR in the Setup Codes For VCRssection below,and write it in the following space.
VCR Br and: __________________________________ The brands are listed in alphabetical order with the most
popular codes listed first.To program VCR control:
1. Turn on your VCR and insert a video cassette.
2. On the remote control,press VCR once.Press
and hold SET until the LED blinks twice,then release SET.
NOTE:The remote control will exit programming if more than 10 seconds elapse between key presses.
3. Enter the first four-digit code for your VCR.If
you perform this procedure correctly,the LED will blink twice.
NOTE:If the LED emits a long blink,the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote control at your VCR and press
POWER once.The VCR should turn off.If your VCR remote control does not have a POW ER key,press PLAY.If the VCR does not respond, repeat steps 2-3,trying each code listed for your brand until you find one that works.If the VCR still does not work ,try searching for the code (see Searching For Your Codeon page 23).
5. Write your VCR code in the boxes below for
future reference.
NOTE:Remember,to use the One For All 4-Device Video Expert remote control to operate your VCR,press VCR first.
Setup Codes for VCRs:
Admiral 0048,0209 Adventura 0000 Aiko 0278 Aiwa 0037,0000 Akai 0041
12
America Action 0278 American High 0035 Asha 0240 Audio v ox 0037 Beaumark 0240 Bell & Howell 0104 Broksonic 0184, 0121,0209,0002,0479 CCE 0072,0278 Calix 0037 Canon 0035 Carver 0081 Cineral 0278 Citizen 0037,0278 Colt 0072 Craig 0037,0047,0240,0072,0271 Curtis Mathes 0060,0035,0041,0162 Cybernex 0240 Daewoo 0045,0278 Denon 0042 Dynatech 0000 Electrohome 0037 Electrophonic 0037 Emerex 0032 Emerson 0037,0184,0000,0121,0043,0209,0002,0278,0479 Fisher 0047,0104 Fuji 0035,0033 Funai 0000 GE 0060,0035,0048,0202,0240 Garrard 0000 Go Video 0526 GoldStar 0037,0038 Gradiente 0000 HI-Q 0047 Harley Davidson 0000 Harman/Kardo n 0081,0038 Harwood 0072 Hitachi 0000,0042,0041 Hughes Network 0042 JVC 0067,0041 Jensen 0041 KEC 0037,0278 KLH 0072 Kenw ood 0067,0041,0038 Kodak 0035,0037 LXI 0037 Lloyd's 0000 Logik 0072 MEI 0035 MGA 0240,0043 MGN Te chnology 0240 MTC 0240,0000
continued on next page...
15
PROGRAMMING VCR CONTROL
Setup Codes for VCRs (Continued):
Magnasonic 0278 Magnavox 0035,0039,0081,0000, 0149 Magnin 0240 Marantz 0035,0081 Marta 0037 Matsushita 0035, 0162,0454 Memorex 0035,0037,0048,0039,0047,0240,0000,0104,0209,0454,
1037,1162,1262 Minolta 0042 Mitsubishi 0048,0067, 0043 Motor o la 0035,0048 Multitech 0000,0072 NEC 0104,0067,0041,0038 Nikko 0037 Noblex 0240 Olympus 0035 Optimus 0037,0048,0104,0162,0454, 1048,1062,1162,1262 Orion 0184,0209,0002,0479 Panasonic 0035,0162,0225,0454,0616,1062,1162,1262 Penney 0035,0037,0240,0042,0038 Pentax 0042 Philco 0035,0209,0479 Philips 0035,0081,0618 Pilot 0037 Pioneer 0067 Profitro nic 0240 Proscan 0060,0202 Protec 0072 Pulsar 0039 Quasar 0035,0162, 0454,1162 RCA 0060,0035,0048,0240,0042,0149,0202 Radio Shack 0000,1037 Radix 0037 Randex 0037 Realistic 0035,0037,0048,0047,0000,0104 ReplayTV 0614,0616 Runco 0039 STS 0042 Samsung 0240,0045 Sanky 0048,0039 Sansui 0000,0067,0209, 0041,0271,0479 Sanyo 0047,0240,0104 Scott 0184,0045,0121,0043 Sears 0035,0037,0047,0000,0042,0104 Semp 0045 Sharp 0048 Shintom 0072 Shogun 0240
14
Singer 0072 Sony 0035,0032,0000,0033 Sylvania 0035,0081,0000,0043 Symphonic 0000 TMK 0240 Tatung 0041 Teac 0000,0041 Technics 0035,0162, 0202 Teknika 0035,0037,0000 Thomas 0000 Tivo 0618 Toshiba 0045,0043 Totevision 0037,0240 Unitech 0240 Vector 0045 Vector Research 0038 Video Concepts 0045 Videosonic 0240 Wards 0060,0035,0048,0047,0081,0240,0000,0042,0072,0149 White Westinghouse
0209,0278 XR-1000 0035,0000,0072 Yamaha 0038 Zenith 0039,0000,0209,0033,0479
6. Write your TV/VCR Combo code in the boxes
below for future reference.
NOTE:Remember,to use the One For All 4-Device Video Expert to operate your TV/VCR Combo,press VCR first.
Setup Codes for TV/VCR Combos:
Brocksonic 0002, 0479 (TV:0463) Citizen 0278 Colt 0072 Curtis Mathes 0035 (TV:0051) Daewoo 0278 (TV:0624) Emerson 0002,0479 (TV:0463),0278 (TV:0624) Funai 0000 GE 0060 (TV:0047),0048 (TV:0093),0035 ( TV:0051),0240 GoldStar 0037 (TV:0056) Harley Davidson 0000 Hitachi 0000 Lloyd's 0000 Magnasonic 0278 Magnavox 0000,0081 (TV:0054) Magnin 0240 Memorex 1162,1262,0162 (TV:0250), 0037 (TV:0056),1037 MGA 0240 Mitsubishi 0048 (TV:0093) Optimus 1162,1262,0162 (TV:0250) Orion 0002,0479 (TV:0463) Panasonic 1162,1262,0162 (TV:0250),0035 (TV:0051) Penney 0037 (TV:0056),0035 (TV:0051),0240 Quasar 0162 (TV:0250) ,0035 (TV:0051) Radio Shack 1037 RCA 0060 (TV:0047),0048 (TV:0093),0035 (TV:0051),0240 Sansui 0000,0479 (TV:0463) Sanyo 0240 Sears 0000,0037 (TV:0056) Sharp 0048 (TV:0093) Sony 0032 (TV:0000) Sylvania 0081 (TV:0054) Symphonic 0000 Thomas 0000 White Westinghouse
0278 (TV:0624) Zenith 0000,0479 (TV:0463)
17
PROGRAMMING TV/VCR COMBO CONTROL
Locate the brand name ofyour TV/VCR Combo in the Setup Codes For TV/VCR Combossection on the next page, and write it in the following space.
TV/VCR Combo Brand: ________________________ The brands are listed in alphabetical order with the most
popular codes listed first.To program TV/VCR control:
1. Turn on your TV/VCR Combo and insert a video cassette.
2. On the remote control,press VCR once.Press and hold SET until the LED blinks twice,then release SET.
NOTE:The remote control will exit programming if more than 10 seconds elapse between key presses.
3. Enter the first four-digit code for your TV/VCR Combo.Ifyou perform this procedure correctly, the LED will blink twice.
NOTE:If the LED emits a long blink,the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote control at your TV/VCR Combo and press POWER once.The unit should turn off.If it does not respond,repeat steps 2-3,try­ing each code listed for your brand until you find one that works.If it still does not work,try searching for the code (see Searching For Your Codeon page 23).
5. Ifyou’ve loca t ed a TV/VCR setup code that works yo ur TV/VCR Combo and a separate TV code is also listed,you’ll need to program this code into the remote control to access volume control (see Programming TV Control on page 8).
Ifthere is no separate TV code listed,you will need to perform the following steps to access volume control:
a. Press and hold SET until the LED blinks
twice,then release SET. b. Enter 9 - 9 - 3.The LED will blink twice. c. Press VCRonce.The LED wil l blink twice.
16
Archer 0153,0022,0797 Belcor 0056 Bell & Howell 0014 Bell South 0899 Cable Star 0056 Cabletenna 0022 Cableview 0022 Century 0153 Citizen 0153,0315 Colour Voice 0025 Comtronics 0040 Contec 0019 Digi 0637 Eastern 0002 Emerson 0797 Everq ues t 0015,0040 Focus 0400 GC Electronics 0056 Garrard 0153 Gemini 0015,0797 General Instrument
0476,0276,0011,0810 GoldStar 0144,0040 Goodmind 0797 Hamlin 0020,0259,0009,0034 Hitachi 0011 Hytex 0007 Jasco 0015,0153,0315 Jerrold 0003,0012,0476,0276,0014,0015,0011,0810 Linsay 0440 Memorex 0000 Movie Time 0063 NSC 0063 Novap le x 0618 Oak 0019,0007 Optimus 0021 Panasonic 0000,0107,0021 Panther 0637 Paragon 0000 Philips 0153, 0025 Pioneer 0144,0533,0877 Popular Mechanics
0400 Pulsar 0000 Quasar 0000 RCA 0021 Radio Shack 0015,0315,0797,0883 Recoton 0400 Regal 0020,0259 Regency 0002 Rembrandt 0011 Runco 0000 SL Marx 0040
continued on next page...
19
PROGRAMMING CABLE CONVERTER OR SATELLITE RECEIVER CONTROL
Locate the br and name of your Cable Converter or Satellite Receiver in the setup codessection starting below,and write it in the appropriate space.
Cable Converter Brand: ________________________ or Satellite Receiver Brand:________________________
The brands are listed in alphabetical order with the most popular codes listed first.To program component control:
1. Turn on the Cable Converter or Satellite R ec ei ver.
2. On the remote control,press CBL/SAT once. Press and h old SET until the LED blinks twice, then release SET.
NOTE:The remote control will exit programming if more than 10 seconds elapse between key presses.
3. Enter the first four-digit code for your Cable Converter or Satellite Receiver.Ifperformed correctly,the LED will blink twice.
NOTE:If the LED emits a long blink,the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote control at y o ur Cab le Co nverter or Satellite Receiver and press POWER once.The unit should turn off.Ifit does not respond,repeat steps 2-3,trying each code listed for y our brand until you find one tha t works.Ifit still does not work , try searching for the cod e (see pag e 23).
5. Write your Cable Converter or Satellite Receiver code in the boxes below for future reference.
NOTE:Remember,to use the One For All 4-Device Video Expert remote control to operate your Cable Converter or Satellite Receiver,press CBL/SAT first.
Setup Codes for Cable Converters:
ABC 0003,0008,0014,0017,0007,0011,0013 Allegro 0153,0315 Americast 0899 Antronix 0022
18
PROGRAMMING DVD PLAYER CONTROL
Locate the brand name ofyour DVD (or LD) player in the Setup Codes For DVDs (or LDs) section on the next page, and write it in the following space.
DVD (or LD) Brand: __________________________ The brands are listed in alphabetical order with the
most popular codes listed first.To program DVD (or LD) player control:
1. Turn on your DVD (or LD) player.
2. On the remote control,press DVD once. Press and h old SET until the LED blinks twice, then release SET.
NOTE:The remote control will exit programming if more than 10 seconds elapse between key presses.
3. Enter the first four-digit code for your DVD (or LD) player.Ifyou perform this procedure cor­rectly,the LED wil l blink tw ice.
NOTE:If the LED emits a long blink,the code is invalid.Repeat steps 2 through 3 and try entering the same code again.
4. Aim the remote control at your DVD (or LD) player and press POWER once.The unit should turn off.If your DVD (or LD) player remote control does not have a POWER key,press PLAY.Ifthe DVD (or LD) player does not respond,repeat steps 2-3,trying each code list­ed for your brand until you find one that works. Ifthe DVD (or LD) player still does not work , try searching for the code (see Searching For Your Code on page 23).
5. Write your DVD (or LD) player code in the boxes below for future reference.
NOTE:Remember ,to use the One For All 4-Device V i de o Expert remote control to operate your
DVD (or LD) player,press DVD first.
21
PROGRAMMING CABLE CONVERTER OR SATELLITE RECEIVER CONTROL
Setup Codes for Cable Converters (Continued):
Samsung 0144,0040 Scientific Atlan ta 0008,0477,0017,0877 Signal 0015,0040 Signature 0011 Sprucer 0021 Starcom 0003,0015 Stargate 0015,0040,0797 Starquest 0015 TV86 0063 Tandy 0258 Teleview 0040 Timeless 0418 Tocom 0012,0013 Toshiba 0000 Tusa 0015 Unika 0153, 0022 United Artists 0007 Univ er sal 0153, 0022,0056,0191 Viewstar 0063,0258 Zenith 0000,0525,0899 Zentek 0400
Setup Codes for Satellite Receivers:
AlphaStar 0772 Echostar 0775,1005 Expressvu 0775 General Instrument
0627,0361,0869 HTS 0775 Hitachi 0819 Hughes Network 0749 JVC 0775 Jerrold 0627,0361 Magnavox 0724,0722 Memorex 0724 Next Level 0869 Panasonic 0701 Philips 0724, 0722 Primestar 0627,0361 RCA 0566,0143,0392,0855 Radio Shack 0869 Sony 0639 Star Choice 0869 Toshiba 0790 Uniden 0724,0722 Zenith 0856
20
23
SEARCHING FOR YOUR CODE
Ifyour video component does not respond to the One For All 4-Device Video Expert remote control after trying all ofthe codes listed for your brand,or ifyour brand is not listed at all,try searching for your code.
For example,to search for a code for your TV:
1. Turn on your TV.
2. On the remote control,press TV once. Press and h old SET until the LED blinks twice, then release SET.
3. Enter 9- 9 - 1.The LED will blink twice.
4. Aim the remote control at the the TV and slow­ly alternate between pressing POWER and TV. Stop when the TV turns off.
NOTE:In the search mode,the One For All 4-Device Video Expert remote control will send IR codes from its library to the selected component,starting with the most popular code first.
5. Pr ess SET once to lock in the code.
6. To search for the codes ofyour other compo­nents,repeat steps 1 through 5,but substitute the appropriate key (i.e., DVD,VCR,or CBL/SAT) for the (DVD/LD,VCR,or Cable/Satellite) com­ponent you are searching for.
PROGRAMMING DVD PLAYER CONTROL (Continued)
Setup Codes for DVD Players:
Denon 0490,0634 GE 0522 Harman/Kardo n 0582 JVC 0558,0623 Kenw ood 0534 Magnavox 0503 Marantz 0539 Mitsubishi 0521 Onkyo 0503,0627 Optimus 0571 Panasonic 0490,0632 Philips 0503, 0539 Pioneer 0525,0571,0632 Proscan 0522 RCA 0522 Samsung 0573 Sharp 0630 Sherwood 0633 Sony 0533 Technics 0490 Theta Digital 0571 Toshiba 0503 Yamaha 0490,0545 Zenith 0503,0591
Setup Codes for LD Players:
Aiwa 0203 Denon 0059,0172 Funai 0203 Mitsubishi 0059 NAD 0059 Optimus 0059 Panasonic 0204 Pioneer 0059 Quasar 0204 Realistic 0203 Sony 0193,0201 Technics 0204
22
2524
PROGRAMMING THE MASTER POWER KEY FOR ALL ON/OFF
With the One For All 4-Device Video Expert,you can program the M. POWER key to turn your TV,VCR,DVD, and Cable (or Satellite) components on and offwith the press of one button.
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 5.The LED will blink twice.
3. Pr ess M.POWER once.
4. Enter the following sequence*: a. P ress TV once. b. Press VCR once. c. Press DVD once. d. Press CBL/SAT once.
5.
Press and h old SET until the LED blinks twice, then release SET.
6. Now, when you press M.POWERonce,the remote control w ill direct power to your TV, VCR,DVD (or LD) player,and Cable/Satellite component and leave the remote control in the TV mode.
* NOTE:If you do not want all ofyour equipment to power up
all ofthe time,you can shorten step 4 to include only those devices you want to tur n on or off.For example, to just power up your TV and DVD (or LD) player,enter the following sequence for step 4 :
a. Press TV once.
b. Press DVD once.
Now whe n you press M.POWER once,the One For All 4 - D evice Video Expert remote control will only direct power to your DVD (or LD) player and TV,and still leave the remote control in the TV mode.
CHECKING THE CODES
Ifyou have set up the One For All 4-Device Video Expert remote cont rol us ing the Searching For Your Codeproce- dure,you may need to find out which four-digit code is operating your equipment.For example,to find out which code is operating your TV:
1. Turn on your TV.
2. On the remote control,press TV once. Press and h old SET until the LED blinks twice, then release SET.
3. Enter 9- 9 - 0.The LED will blink twice.
4. To view the code for the first digit,press 1once. Count the number ofLED blinks (e.g.,3 blinks =3) and write down the number in the left­most TV Code box below.
NOTE:If a code digit is “0”,the LED wil l not blink.
5. Repeat step 4 three more times for remaining digits.U se 2 for the second digit,3 for the third digit,and 4for the fourth digit.Finish writing down the code in the TV Code boxes below.
6. To check for the codes of your other compo­nents,repeat steps 1 through 5,but substitute the appropriate key (i.e., DVD,VCR,or CBL/SAT) for the (DVD/LD,VCR,or Cable/Satellite) com­ponent you are checking.Write down the codes in the appropriate boxes below.
TV Code
DVD (or LD) Code
VCR Code
Cable/Satellite Code
2726
CHANGING VOLUME LOCK
The One For All 4-Device Video Expert remote control is preset to control the volume ofa component through your TV.
Ifyour TV is not remote controllable,or ifyou would like the volume to be controlled by a different component,you can change the Volume Lock setting to control a volume through a non-associated mode (e.g.,through the cable in the TV mode).
To change Volume Lock to the CBL/SAT mode:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 3 and then press CBL/SAT once. The LED will blink twice.
3. Now, whenever you press VOL +,VOL –,or MUTE on the re mote c o ntrol, the volume will be controlled by your Cable Converter or Satellite Receiver.
To change Volume Lock to the VCR mode:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 3 and then press VCR once. The LED will blink twice.
3. Now, whenever you press VOL +,VOL –,or MUTE on the remote control, vo l ume will be controlled by your VCR.
To change Volume Lock to the DVD mode:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 3 and then press DVD once. The LED will blink twice.
3. Now, whenever you press VOL +,VOL –,or MUTE on the remote control, vo l ume will be controlled by your DVD (or LD) player.
RE-ASSIGNING DEVICE KEYS
The One For All 4-Device Video Expert remote control can be set up to control a second TV or VCR,or any com­bination offour video components.For example,to have the unit control a TV,a Cable Converter,and two VCRs, you will need to re-assign the unused DVD key to op e rate the second VCR as follows:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 2.The LED will blink twice.
3. Pr ess VCR once,then press DVD once.The LED will blink twice.
4. Program the DVD key as a second VCR.See Programming VCR Controlon page 12.
To re-assign other device keys,repeat steps 1 through 4 by substituting the key sequence from the following chart for a desired component:
To Re-Assign Perform Key Sequence
VCR as 2nd TV key: SET - 9 - 9 - 2 - TV - VCR VCR as 2nd DVD key: SET- 9 - 9 - 2 - DVD - VCR VCR as 2nd Cbl/Sat key: SET- 9 - 9 - 2 - CBL/SAT - VCR VCR back to VCR: SET - 9 - 9 - 2 - VCR - VCR DVD as 2nd TV key: SET - 9 - 9 - 2 - TV - DVD DVD as 2nd VCR key: SET- 9 - 9 - 2 - VCR - DVD DVD
as 2nd
Cbl/Sat
key:
SET- 9 - 9 - 2 - CBL/SAT - DVD
DVD
back to
DVD
:
SET- 9 - 9 - 2 - DVD - DVD CBL/SAT as 2nd TV key: SET- 9 - 9 - 2 - TV - CBL/SAT CBL/SAT as 2nd DVD key: SET - 9 - 9 - 2 - DVD - CBL/SAT CBL/SAT as 2nd VCR key: SET- 9 - 9 - 2 - VCR - CBL/SAT CBL/SAT back to CBL/SA T: SET- 9 - 9 - 2- CBL/SAT- CBL/SAT
Upon c o mpletion ofa re-assignment,the LED will blink twice to confirm your selection.At that time,you will also need to program the re mo t e c o ntrol to co ntrol the new co m­ponent (see previous sections o n Pr ogramming VCR Control,
Programmin g C able C o nverter or Satellit e Receiver C o n tr o l,or Programming D VD Pl a yer Control).
2928
USING KEYMOVER
The One For All 4-Device Video Expert remote control includes a K eymov er fea ture that allow s you to map (or
copy) k e ys from one mode (i.e.,source mode)to another (i,e,destination mode).
NOTE:The following keys cannot be mapped:TV,DVD,VCR, CBL/SAT,SET,M.POWER,V.CONFIG,and macro keys F1~F4.
For example, if your VCR does not have volume control, you can map the volume and mute keys from the TV mode to the VCR mode as follows:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 4.
3. For the source mode,press TV once.
4. For the source key,press VOL +once.
5. For the destination mode,press VCR once.
6. For the destination key,press VOL +once. The LED will blink twice indicating the key­moved sequence is correct.
7. Repeat steps 1 through 6 twice more, substituting VOL – and MUTE as source and destination keys in steps 4 and 6.
Upon completion ofthe above procedure,you can now use your One For All 4-Device Video Expert remote con­trol t o control the TV’s volume and mute in th e VCR mode,as well as in the TV mode.
CHANGING VOLUME LOCK (Continued)
To change Volume Lock back to the TV mode:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 3 and then press TV once. The LED will blink twice.
3. Now, whenever you press VOL +,VOL –,or MUTE on the remote control, vo l ume will be again controlled by your TV.
To Unlock Volume Lock:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 3 and then press VOL+ once. The LED will blink twice.
USING THE MENU KEY
On your One For All 4-Device Video Expert remote con­trol,the MENUkey works just like the MENUkey of your original remote control and allows you to access the on­screen menu ofthe component you have selected (e.g.,TV, VCR, DVD,or CBL/SAT).
When you press MENU,the VOL+,VOL–,CH+,and CH– keys will allow you to navigate and adjust the on screen menu settings just like you would with your original remote cont rol.Also, the MUTE key becomes the Menu Select key.
To exit out of the Menu mode, press MENU or EXIT to return to normal oper ation.
Programming A Secondary Master Power Key With Instant Channel Selection
Just like the M.POWER key,any F key can be programmed to turn on and offyour equipment.As an example,you want your child to be able to easily turn on the equipment and select a favorite premium channel.You can setup a sequence using two macros on one F key – the first macro will turn on the TV and tune it to channel3,and the second macro will turn on the Cable Box and tune it to a desired channel (e.g.,11).
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 5.The LED will blink twice.
3. Select an open F key (e.g.,F2) and press it once.
4. Enter the following sequence:
TV, POWER,and 0-3 (or 0-0-3 if access is over 100 channels)
5. Press and hold SET until the LED blinks twice, then release SET.
6. Repeat steps 1 through 5,but this time in step 4 enter the following sequence:
CBL/SAT, POWER,and 1-1 (or 0 -1-1 if access is over 100 channels)
Now when you press F2 once,the TV will turn on and tune to channel 03.When you press F2once again,the Cable Box will turn on and tune to channel 11.
Clearing A Macro
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 5.The LED will blink twice.
3. Select an F key (e.g.,F1~F4) you want to clear and press it once.
4. Press and hold SET until the LED blinks twice, then release SET.
3130
USING MACROS
With programming,the F1 through F4 keys on your One For All 4-Device Video Expert remote control can be setup to perform repetitive,time-consuming operations for easy, convenient access through the press of a single key.
The F keys are ideal for home theater operations,setti ng a favorite channel,adding to multiple component uses, guide steps,or other multiple functions you would like to control with one key press.
For the optimum in individual customization,you can define and program a sequence of events,since each F key can hold up to three macros or 12 key presses total. Below are a few examples to get you started.
NOTE:Programming a new macro over an existing one will erase the original macro.
Programming A Favorite Channel
With so many channels available through your cable system or satellite provider,you can program a macro that directly selects a favorite channel with one key press.
For example,let’s assume your favorite cable programs are on channel 71.Use the following instructions to pro­gram an F key for direct access of this channel:
1. On the remote control,press and hold SET until the LED blinks twice,then release SET.
2. Enter 9- 9 - 5.The LED will blink twice.
3. Select an open Fkey (e.g.,F1) and press it once.
4. PressTV once.
5. Enter the channel number,7 - 1.
NOTE:If you have access to over 100 channels,enter in 071.
6. Press and hold SET until the LED blinks twice, then release SET.
Now when you press F1,you will instantly see cable channel 71 on your TV set.
3332
USING THE VIDEO CONFIGURATION MODE
The One For All 4-Device Video Expert remote control includes a powerful Video Configurationfeature t h at allows you to combine the most used functions ofyour Audio/Video equipment into one V.CONFIG mode.The features you can combine are organized into five groups and can be defined by specific modes as follows:
Funct ion Groups
• Function Group 1 – Transport Keys (Play,Stop,Fast
Forward,Rewind,Pause, Record, Forward Scan,and Rewind Scan)
• Function Group 2 – Volume Keys (Volume Up, Volume
Down,and Mute)
• Function Group 3 – Channel Keys (Channel Up,
Channel Down,Dig its 0-9,Enter,Previous Channel, Sleep,and Display)
• Function Group 4 – Menu Keys (Menu,Up,Down,Left,
Right,and Select)
• Function Group 5 – PIP Keys (Picture-In-Picture,Swap,
and Move)
Component (Mode) Groups
• Comp onent Group 1 – VCR and DVD
• Comp onent Group 2 – T V,VCR,and Cable/Sat
• Comp onent Group 3 – T V,VCR,and Cable/Sat
• Comp onent Group 4 – T V,VCR,Cable/Sat,and DVD
• Comp onent Group 5 – T V,VCR,and Cable/Sat
To enable the Video Configurationfeature,you’ll need to perform the following programming sequence:
1. On the remote control,press V.CONFIG once.
2. Press and hold SET until the LED blinks twice, then release SET.
3. Enter 9- 7 - 9.The LED will blink twice.
At this p oint,yo u’ll assign Component Groupsto Function Groups up to five times,depending on how many combi­nations you need.You can perform any ofthe following steps in any order,as long as you finish the sequence with step 9.
4. Select a key from Component Group 1(i.e.,VCR or DVD) and press it once.Press PLAYto assign Function Group 1 (i.e.,the transport keys).The LED will blink twice.
5. Select a key from Component Group 2 (i.e.,TV, VCR,or CBL/SAT) and press it once.Press VOL+ to assign Fun ction Group 2 (i.e.,the volume keys).The LED will blink twice.
6. Select a key from Component Group 3(i.e.,TV, VCR,or CBL/SAT) and press it once.Press CH+ to assign Fun ction Group 3 (i.e.,the channel keys).The LED will blink twice.
7. Select a key from Component Group 4(i.e.,TV,
DVD,VCR,or CBL/SAT) and press it once.Press MENUto assign Function Group 4 (i.e.,the
menu keys). The LED w i l l blink tw ice.
8. Select a key from Component Mode Group 5 (i.e.,TV,VCR,or CBL/SAT) and press it once. Press PIP to as si gn Function Group 5 (i.e.,the PIP keys).The LED will blink twice.
9. To lock in the Video Configuration,press SET until the LED blinks twice,then release SET.
An Example Video Configuration
From one mode,you would like to play your DVD,use the Volume control on the TV,change channels on your Cable Box,control the Menu on the Cable Box,and use the PIP feature of your TV. To program this Video Configuration you would perform the following steps:
1. On the remote control,press V.CONFIG once.
2. Press and hold SET until the LED blinks twice, then release SET.
3. Enter 9- 7 - 9.The LED will blink twice.
4. Pr ess DVDonce and then press PLA Y.The LED will blink twice.
...continued on next page
35
USING THE VIDEO CONFIGURATION MODE
An Example Video Configuration (Continued)
5. Pr ess TV once and then press VOL+.The LED will blink twice.
6. Pr ess CBL/SAT once and then press CH+.The LED will blink twice.
7. Pr ess CBL/SAT once and then press MENU.The LED will blink twice.
8. Pr ess TV once and then press PIP.The LED wil l blink twice.
9. To lock in the Video Configuration,press SET until the LED blinks twice,then release SET.
34
TROUBLESHOOTING
PROBLEM: LED does not blink when you press a key. SOLUTION: Replace the batteries with two (2) new AA
alkaline batteries (see page 7).
PROBLEM: LED blinks when you press a key,but home
entertainment component does not respond.
SOLUTION: Make sure you are aiming the remote control at
your home entertainment component and that you are within 15feet of the component you are trying to c o ntrol.
PROBLEM: The remote control does not control home enter-
tainme nt components or commands a re not per­forming prop erly.
SOLUTION: Try all listed codes for the component brand
being set up. Make sure all components can be
operated with an infrared remot e control. PROBLEM: TV/VCR combo does not respond properly. SOLUTION: Use the VCR codes for your brand. Some combo
units may require both a TV code and a VCR
code for full operation (see page 16). PROBLEM: No volume on a second TV. SOLUTION: Follow instructions in Changing Vol ume Lock
(see page 27). PROBLEM: CH+ , CH– ,and PREV.CH do not work for your
RCA TV. SOLUTION: Due to RCA design (1983-1987),only the original
remote control will operate these functions. PROBLEM: Changi ng channels does not work properly. SOLUTION: If original remote control required pressing
ENTER to change channels,press ENTER on the
remote control after entering a channel number. PROBLEM: Tried “Search Method”and still could not find a
working co de. SOLUTION: For help,call our technical support group at
1-330-405-8608 on any business day,between
9 A.M.and 5 P.M.,EST. PROBLEM: Remote control does not turn on Sony or Sharp
TV/VCR Combo. SOLUTION: For power on,these products require program-
ming TV codes on t he rem ote control.For Sony,
use TV code 0000 and VCR code 0032.For Sharp,
use TV code 0093 and VCR code 0048.
ADDITIONAL INFORMATION
The One For All 4-Device Video Expert remote control does not have any user-serviceable parts.Opening the case,except for the battery cover,may cause permanent damage to your remote control.
©2000 by Universal Electronics Inc.No part of this publi­cation may be reproduced,transmitted,transcribed, stored in any retrieval system, or translated to any lan­guage,in any form or by any means,electronic,mechani­cal,mag net ic,optical,manual,or otherwise,without the prior written permission ofUniversal Electronics Inc. One For All®is a registered trademark ofUniversal Electronics Inc.
Part No.URC4080 7/00
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
