INSTRUCTION MANUAL
Ultra Premium
Blood Pressure Monitor
featuring ComFitTMCuff
Model HEM-775
ESPAÑOL
ENGLISH
TABLE OF CONTENTS
Before Using the Monitor
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operating the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Risk of Electrical Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Operating Instructions
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Unit Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Display Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Irregular Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Movement Error Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
USER ID Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Morning Hypertension Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Average Value Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Morning Average Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Evening Average Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Using the AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Applying the Arm Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
2
TABLE OF CONTENTS
Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Using the Guest Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Selecting the USER ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Using the USER ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Selecting the TruRead
Using the Single Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Using the TruRead
Special Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Using the Memory Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Averaging Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
To Display the Measurement Values . . . . . . . . . . . . . . . . . . . . . . . .37
Morning and Evening Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Morning Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Evening Averages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
To Display Morning and Evening Averages . . . . . . . . . . . . . . . . . .40
Display Combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
To Delete All Values Stored in the Memory . . . . . . . . . . . . . . . . . .42
Care and Maintenance
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Error Indicators and Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . .45
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
TM
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
TM
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
3
Before Using the Monitor
INTRODUCTION
Thank you for purchasing the Omron®HEM-775 IntelliSense
®
Automatic Blood Pressure Monitor with ComFitTMCuff.
Fill in for future reference.
DATE PURCHASED: __________________
SERIAL NUMBER: ____________________
Staple your purchase receipt here
Your new digital blood pressure monitor uses the oscillometric method
of blood pressure measurement. This means the monitor detects your
blood’s movement through your brachial artery and converts the
movements into a digital reading. The monitor stores measurement
results for two people and features Morning and Evening Averages.
TruRead
intervals for an average reading.
The HEM-775 comes with the following components:
• Monitor • ComFit
• 4 “AA” Batteries • Warranty Card
• Instruction Manual printed in English and Spanish
The HEM-775 IntelliSense
intended for home use.
TM
allows for three consecutive measurements with timed
TM
Cuff • AC Adapter
®
Automatic Blood Pressure Monitor is
SAVE THESE INSTRUCTIONS
4
SAFETY INFORMATION
To assure the correct use of the product basic safety measures should
always be followed including the warnings and cautions listed in this
instruction manual.
SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL
Indicates a potentially hazardous situation
WARNING
CAUTION
OPERATING THE DEVICE
Contact your physician for specific information about your blood
pressure. Self-diagnosis and treatment using measured results may
be dangerous. Follow the instructions of your physician or licensed
healthcare provider.
If battery fluid should get in your eyes, immediately rinse with
plenty of clean water. Contact a physician immediately.
Read all of the information in the instruction manual and any other
literature in the box before operating the unit.
This device is intended for use in measuring blood pressure and
pulse rate in the adult population. Do not use this device on infants
or persons who cannot express their intentions.
which, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury to the user or patient or
damage to the equipment or other property.
5
SAFETY INFORMATION
OPERATING THE DEVICE (continued)
Read the Special Conditions section (page 35) of the instruction
manual if your systolic pressure is known to be more than 220
mmHg. Inflating to a higher pressure than necessary may result
in bruising where the cuff is applied.
Operate the device only as intended. Do not use the device for any
other purpose.
Dispose of the device, components and optional accessories
according to applicable local regulations. Unlawful disposal
may cause environmental pollution.
Do not use a cellular phone near the device. It may result in an
operational failure.
Use only Omron authorized parts and accessories. Parts and
accessories not approved for use with the device may damage
the unit.
Use only 1.5V manganese or alkaline batteries with this device.
Do not use other types of batteries. This may damage the unit.
RISK OF ELECTRICAL SHOCK
Do not plug or unplug the power cord into the electrical outlet with
wet hands.
Do not overload power outlets. Plug the device into the appropriate
voltage outlet.
6
SAFETY INFORMATION
CARE AND MAINTENANCE
Do not subject the monitor to strong shocks, such as dropping the
unit on the floor.
Do not submerge the device or any of the components in water.
Store the device and the components in a clean, safe location.
Changes or modification not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
Do not store the AC adapter in the cuff compartment. This may
damage the cuff.
7
BEFORE TAKING A MEASUREMENT
To ensure a reliable reading follow these recommendations:
1. Avoid eating, drinking alcohol, smoking, exercising, and bathing for
30 minutes before taking a measurement. Rest for at least 15
minutes before taking the measurement.
2. Stress raises blood pressure. Avoid taking measurements during
stressful times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your arm.
5. Sit in a chair with your feet flat on the floor. Rest your arm on
a table so that the cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your
physician. A single measurement does not provide an accurate
indication of your true blood pressure. You need to take and record
several readings over a period of time. Try to measure your blood
pressure at about the same time each day for consistency.
8
Operating Instructions
KNOW YOUR UNIT
Main Unit:
Air Jack
Monitor Cover
Cuff
Compartment
USER ID
Symbol (A or B)
Display
SET Button
Memory ( ) Button
Battery Compartment
USER ID
Selection Switch
Start/Stop Button
Morning/Evening Average
( / ) Buttons
AC Adapter Jack
9
KNOW YOUR UNIT
Components:
Air Plug
(Connects to Air Jack)
Arm Cuff
Systolic Blood Pressure
Diastolic Blood Pressure
Heartbeat Symbol
Movement Symbol
Irregular Heartbeat Symbol
TruReadTMSymbol
Deflation Symbol
Low Battery Indicator
Housing
Air Tube
Cord
AC Adapter
Four “AA” Batteries
Instruction Manual
UNIT DISPLAY
USER ID Symbol (A or B)
Morning Hypertension Symbol
Morning Average Symbol
Evening Average Symbol
Average Value Symbol
Memory Symbol
Pulse Display
Week Display
Date/Time Display
10
DISPLAY SYMBOLS
IRREGULAR HEARTBEAT SYMBOL ( )
When the monitor detects an irregular rhythm two or more times during
the measurement, the Irregular Heartbeat Symbol ( ) will appear on
the display with the measurement values.
Pulse
Blood
pressure
Pulse
Blood
pressure
Normal Heartbeat
Irregular Heartbeat
Short Long
An irregular heartbeat rhythm is defined as
a rhythm that is more than 25% slower or
25% faster from the average rhythm
detected while the monitor is measuring the
systolic blood pressure and the diastolic
blood pressure.
If the irregular heartbeat symbol ( )
displays with your measurement results,
we recommend you consult your physician.
Follow the directions of your doctor.
MOVEMENT ERROR SYMBOL ( )
The Movement Error Symbol is displayed if you move your body during
the measurement. Please remove the arm cuff, and wait 2-3 minutes.
Take another measurement.
USER ID SYMBOL ( / )
The USER ID Symbol indicates USER A or USER B as selected by
the user to take a measurement or when using the memory function.
The USER ID Symbol is not displayed when using the Guest Mode
to take a measurement.
11
DISPLAY SYMBOLS
The American Heart Association1recommends the following guideline
for upper limit of normal for home blood pressure readings:
AHA Home Guideline for Upper Limit of Normal BP
Systolic Blood Pressure 135 mmHg
Diastolic Blood Pressure 85 mmHg
This is a general guideline because blood pressure depends on age
and morbidity. The AHA recommends a lower home blood pressure
goal for certain patients, including diabetic patients, pregnant women,
and patients with renal failure
The monitor is not intended to be a diagnostic device.
WARNING
Contact your physician for specific information about your blood
pressure. Self-diagnosis and treatment using measured results may
be dangerous. Follow the instructions of your physician or licensed
healthcare provider.
Omron Healthcare recommends you contact your physician if the
MORNING HYPERTENSION SYMBOL and/or the HEARTBEAT
SYMBOL appear on the display with your measurement values.
MORNING HYPERTENSION SYMBOL ( )
The Morning Hypertension Symbol is displayed if the morning average
reading for a week is above 135 for the Systolic Blood Pressure value
and/or 85 for the Diastolic Blood Pressure value when viewing the
Morning Averages and the Evening Averages in the memory.
1
.
1
American Heart Association Scientific Statement 2004
12
DISPLAY SYMBOLS
HEARTBEAT SYMBOL ( )
TAKING A MEASUREMENT
The Heartbeat Symbol flashes on the display during
the measurement.
The Heartbeat Symbol flashes at every heartbeat.
When the measurement is complete, the Heartbeat Symbol
flashes on the display with your blood pressure and pulse rate if
the reading is above 135 for the Systolic Blood Pressure value
and/or 85 for the Diastolic Blood Pressure value.
USING THE MEMORY FUNCTION
The Heartbeat Symbol flashes when the blood pressure reading
stored in the memory is above 135 for the Systolic Blood
Pressure value and/or 85 for the Diastolic Blood Pressure value.
AVERAGE VALUE SYMBOL ( )
The Average Value Symbol is displayed when you press the memory
button. The most recent average reading appears on the display screen.
MORNING AVERAGE SYMBOL ( )
The Morning Average symbol is displayed when viewing Morning
Averages using the Memory Function.
EVENING AVERAGE SYMBOL ( )
The Evening Average symbol is displayed when viewing Evening
Averages using the Memory Function.
13
BATTERY INSTALLATION
1. Press the ▼ indicator on the battery cover
and slide the cover off in the direction of
the arrow.
2. Install 4 “AA” size batteries so the +
(positive) and - (negative) polarities match
the polarities of the battery compartment
as indicated.
3. Replace the battery cover.
Battery Cover
14
BATTERY INSTALLATION
BATTERY REPLACEMENT
Low Battery Indicator
When the Low Battery Indicator appears on the display screen turn the
monitor off and remove all the batteries. Replace with four new batteries
at the same time. Longlife alkaline batteries are recommended.
CAUTION
If battery fluid should get in your eyes, immediately rinse with
plenty of clean water. Contact a physician immediately.
NOTES: • Turn the unit off before replacing the batteries. If the
batteries are removed while the unit is still on, the date and
time will be reset to that of the previous use. However, the
measurement results are not deleted.
• When the batteries are replaced, you may need to reset the
date and time. If the year is flashing on the display screen,
refer to page 21, RESETTING THE DATE AND TIME.
• The supplied batteries may have a shorter life.
CAUTION
Dispose of the device, components and optional accessories
according to applicable local regulations. Unlawful disposal may
cause environmental pollution.
15
USING THE AC ADAPTER
Use only the authorized Omron AC Adapter, Model Number
HEM-ADPT1,with this monitor.
We recommend you install the batteries even if the AC Adapter
is used. If no batteries are installed, you may need to reset the date
and time if the AC Adapter is disconnected. The measurement results
will not be deleted.
CAUTION
Use only Omron authorized parts and accessories. Parts and
accessories not approved for use with the device may damage
the unit.
16
USING THE AC ADAPTER
2
1
TO CONNECT THE AC ADAPTER
① Insert the AC Adapter Plug
into the AC Adapter Jack on
the back side of the monitor
as illustrated.
② Plug the AC Adapter into a
120V AC outlet (60 cycles).
TO DISCONNECT THE AC ADAPTER
① Hold and pull the Housing to remove the AC Adapter from the
electrical outlet. Do not remove by pulling on the cord.
② Remove the AC Adapter plug from the monitor.
WARNING
Do not plug or unplug the power cord into the electrical outlet with
wet hands.
CAUTION
Do not overload power outlets. Plug the device into the appropriate
voltage outlet.
Housing
Cord
17
SETTING THE DATE AND TIME
Set the monitor to the current date and time before taking a
measurement for the first time. If the date and time are not set correctly,
the measurement values stored in the memory and the average values
may not be correct.
The Blood Pressure Monitor automatically stores up to 84 individual
measurement values with the dates and times. The monitor also
calculates weekly averages for measurements in the morning and in the
evening. Morning and Evening averages are stored for this week and the
last seven weeks.
The monitor can also calculate an average reading based on the three
most recent measurements taken within 10 minutes of the last reading.
NOTE: • If only two readings are stored in the memory for the 10-
minute period, the average is based on the two readings.
• If one reading is stored in the memory for the 10-minute
period, this reading is displayed as the average.
1. TO START THE SETTING
Press and hold the SET button to
adjust the date and time.
The year flashes on the display.
18
SETTING THE DATE AND TIME
2. SETTING THE YEAR
The year can be set between 2007 and
2030. When the display reaches 2030,
it will return to 2007.
Press the Memory button ( ) to
advance by increments of one year.
Press the SET button to set the
current year.
The month flashes on the display.
NOTE: Press and hold the Memory button ( )
to advance the date and time values faster.
3. SETTING THE MONTH
Press the Memory button ( ) to advance by increments of one
month.
Press the SET button to set the current month.
The day flashes on the display.
19
SETTING THE DATE AND TIME
4. SETTING THE DAY
Press the Memory button ( ) to advance by increments
of one day.
Press the SET button to set the current day.
The hour flashes on the display.
5. SETTING THE HOUR
The time is set using AM or PM.
Press the Memory button ( ) to advance by increments of one
hour.
Press the SET button to set the current hour.
The minute flashes on the display.
6. SETTING THE MINUTE
Press the Memory button ( ) to advance by increments of one
minute.
Press the SET button to set the minute setting.
7. TO TURN THE MONITOR OFF
Press the START/STOP button.
NOTE: The monitor will automatically turn off after the minute has
been set after battery replacement.
20
SETTING THE DATE AND TIME
RESETTING THE DATE AND TIME
To adjust the date or time after it has been setup when you first
use the unit.
Start with the monitor in the off position.
1. Press and hold the SET button.
TM
The TruRead
will appear on the display for the USER ID selected.
To change the
the SET button.
The interval time flashes on the display. Press the Memory button
to select the desired interval time, then press the SET button.
The year flashes on the display.
2. Refer to page 18, SETTING THE DATE AND TIME.
NOTE: If you need to change the Date and Time,
symbol and the current setting (on or oFF)
on or oFF setting press the Memory button, then press
always adjust the Date and Time setting before taking
the next measurement.
21
APPLYING THE ARM CUFF
CAUTION
Read all of the information in the instruction manual and any other
literature in the box before operating the unit.
CAUTION
This device is intended for use in measuring blood pressure and
pulse rate in the adult population. Do not use this device on infants
or persons who cannot express their intentions.
APPLYING THE CUFF ON THE LEFT ARM
1. Make sure the air plug is securely inserted in the main unit.
2. Remove tight-fitting clothing from your upper left arm.
22
APPLYING THE ARM CUFF
3. Sit in a chair with your feet flat on the floor. Place your left arm on
a table so the cuff is level with your heart.
Thumb Grip
4. Hold the grip on the cuff securely with
your right hand, placing your thumb
on the thumb grip.
Cloth Strip
5. Turn the palm of your left
hand upward.
23
APPLYING THE ARM CUFF
6. Apply the cuff to your left upper arm so the blue strip is on the inside
of your arm and aligned with your middle finger. The air tube runs
down the inside of your arm. The bottom of the cuff should be
approximately 1/2" above your elbow.
Blue Strip
7. Wrap the cuff firmly in place around your arm using the cloth strip.
1/2 inch (1 - 2 cm)
Air Tube
24
APPLYING THE ARM CUFF
APPLYING THE CUFF ON THE RIGHT ARM
When taking a measurement using the right arm use this instruction
for Step 6 on page 24.
Apply the cuff to your right upper arm so the thumb grip is centered
on the inside of your inner arm. The bottom of the cuff should be
approximately 1/2'' above your elbow.
Thumb Grip
NOTE: Be careful not to rest your arm on the air tube. This will restrict
the flow of air to the cuff.
25
TAKING A MEASUREMENT
The monitor is designed to take measurements and store the
measurement values in the memory for two people using
USER ID A and USER ID B.
The monitor can also be used to take a single measurement for other
persons using the GUEST Mode. The USER ID symbol is not displayed
when using the GUEST Mode. Measurements taken using the GUEST
Mode are not stored in the memory.
CAUTION
Operate the device only as intended. Do not use the device for any
other purpose.
USING THE GUEST MODE
1. Press and hold the START/STOP button.
The A and B Symbols disappear from the display.
A and B Symbols disappear
2. Release the START/STOP button.
The cuff starts to inflate automatically.
NOTE: To stop the inflation press the START/STOP button.
The monitor will stop inflating, start deflation and turn off.
26
TAKING A MEASUREMENT
3. Inflation stops and the measurement is started. When the
measurement is completed, your blood pressure and pulse rate appear
on the display.
SELECTING THE USER ID
Select your USER ID. Always use the same USER ID when taking a
measurement. The monitor stores the measurement values in the
memory by the USER ID selected. These measurement values are used
to calculate the Morning Averages and Evening Averages.
Slide the USER ID Selection Switch up or down to select USER A or B.
USING THE USER ID
When you select a USER ID the monitor can be set to take one
measurement using the Single Mode or three consecutive measurements
using the TruRead
NOTE: The default value is set to the Single Mode to take one
measurement.
The TruRead
monitor will inflate, take a measurement, and deflate three times
separated by a short interval of time between each measurement.
TM
Mode when you press the START/STOP button.
TM
Mode takes three consecutive measurements. The
27
TAKING A MEASUREMENT
SELECTING THE TruReadTMMODE
1. Select your USER ID (A or B).
2. Press and hold the SET button.
TM
The TruRead
on the display.
3. Press the Memory button ( )
to select
NOTE: Press the Memory button to
symbol and the oFF setting appears
on.
alternate between
on and oFF.
28
TAKING A MEASUREMENT
4. Press the SET button to confirm the change.
The number of seconds between each measurement is displayed.
NOTE: The default value between each measurement is 60 seconds.
5. Press the MEMORY button ( ) to change the interval of time
between each measurement.
The interval can be set to 15 seconds, 30 seconds, 60 seconds or 120
seconds. Continue to press the MEMORY button until the desired
interval appears on the display.
6. Press the SET button to confirm
the setting.
The year flashes on the display.
29
TAKING A MEASUREMENT
7. If the date and time are correct, press the
START/STOP button to turn the monitor
off.
To change the date and time refer to page
18, SETTING THE DATE AND TIME.
CAUTION
Do not use a cellular phone near the device. It may result in an
operational failure.
USING THE SINGLE MODE
1. Select your USER ID (A or B).
30
TAKING A MEASUREMENT
2. Press the START/STOP button.
All symbols appear on the display. The USER ID Symbol you
selected flashes on the display.
The cuff starts to inflate automatically. As the cuff inflates, the
monitor automatically determines your ideal inflation level. This
monitor detects the pulse during inflation. Do not move your arm and
remain still until the entire measurement process is completed.
NOTE: To stop the inflation or measurement, press the START/STOP
button. The monitor will stop inflating, start deflating and will
turn off.
3. Inflation stops automatically and the measurement is started.
As the cuff deflates, decreasing numbers appear on the display.
The Heartbeat Symbol ( ) flashes at every heartbeat.
31
TAKING A MEASUREMENT
4. When the measurement is complete, the arm cuff
completely deflates. Your blood pressure and pulse
rate are displayed.
5. Press the START/STOP button to turn the
monitor off.
NOTE: The monitor will automatically turn
off after five minutes.
32
TAKING A MEASUREMENT
USING THE TruReadTMMODE
1. Select your USER ID (A or B).
2. Press the START/STOP button.
All symbols appear on the display. The USER ID Symbol you
selected flashes on the display. The cuff starts to inflate automatically.
NOTE: To stop the inflation or measurement, press the START/STOP
button. The monitor will stop inflating, start deflating and will
turn off.
3. Inflation stops automatically and the measurement is started.
As the cuff deflates, decreasing numbers appear on the display.
The Heartbeat Symbol ( ) flashes at every heartbeat. When the
measurement is complete, the arm cuff completely deflates.
NOTE: Do not move your arm and remain still until the entire
measurement process is completed.
4. Check the progress of the consecutive measurements.
NOTE: If a measurement fails, the monitor will repeat taking a
measurement up to five times during the consecutive
measurement process.
The first measurement is complete, waiting to start the next
measurement. The interval of time set between each measurement
will appear on the display.
33
TAKING A MEASUREMENT
The second measurement is complete, waiting to start the next
measurement.
The consecutive measurements are complete. The average for three
measurements appears on the display.
5. Press the SET button to display the blood pressure and pulse rate for
the first measurement. Press the SET button again to display the next
measurement.
6. Press the START/STOP button to turn the monitor off.
34
TAKING A MEASUREMENT
SPECIAL CONDITIONS
CAUTION
Inflating to a higher pressure than necessary may result in bruising
where the cuff is applied.
If your systolic pressure is known to be more than 220 mmHg, press
and hold the START/STOP button until the monitor inflates 30 to 40
mmHg higher than your expected systolic pressure.
NOTES: • Do not apply more pressure than necessary.
• The monitor will not inflate above 299 mmHg.
When the measurement is complete, the arm cuff completely deflates.
Your blood pressure and pulse rate are displayed.
35
USING THE MEMORY FUNCTION
The monitor is designed to store the blood pressure and the pulse rate in
the memory for two people (USER A and USER B) every time a
measurement is completed.
The monitor automatically stores up to 84 sets of measurement values
(blood pressure and pulse rate) for each user (A and B). When 84 sets of
measurement values are stored, the oldest record is deleted to save the
most recent values. The monitor also stores 8 weeks of Morning
Averages and 8 weeks of Evening Averages for each user (A and B).
AVERAGING FUNCTION
The monitor calculates the average reading based on the three most
recent sets of measurement values taken within 10 minutes of the most
recent reading.
NOTE: If two sets of measurement values are stored in the memory for
the 10 minutes period, the average is based on the two sets of
measurement values. If one set of measurement values is stored,
this is displayed as the average.
36
USING THE MEMORY FUNCTION
TO DISPLAY THE MEASUREMENT VALUES
1. Select your USER ID (A or B).
2. Press the Memory button ( ).
The Average Symbol ( ) appears on the display when the average
reading is shown.
37
USING THE MEMORY FUNCTION
3. Press the Memory button ( ) to display the most recent set of
measurement values on the screen. The values are displayed from the
most recent to the oldest.
NOTE: The date and time are
alternately displayed with
the measurement values.
Alternating display
Press the Memory button to display the
next set of values.
Press and hold the Memory button to display the values faster.
TruReadTMMode
The average for the consecutive measurements appears on the display
with the TruRead
individual measurements press the SET button while the average is
displayed.
TM
symbol ( ). To display the values for the
4. Press the START/STOP button to turn the power off.
38
USING THE MEMORY FUNCTION
MORNING AND EVENING AVERAGES
The monitor calculates and displays a weekly average for measurements
taken in the morning ( ) and evening ( ). The monitor stores 8 weeks
of Morning Averages and 8 weeks of Evening Averages for each user
(A and B).
NOTE: The week begins Sunday at 4:00 AM
MORNING AVERAGES
Morning averages are based on the first average reading using the
TruReadTMMode or the first reading using the Single Mode.
Measurement times must be between:
4:00 AM and 9:59 AM.
EVENING AVERAGES
Evening averages are based on the last average reading using the
TruReadTMMode or the last reading using the Single Mode.
Measurement times must be between:
7:00 PM and 1:59 AM.
39
USING THE MEMORY FUNCTION
TO DISPLAY MORNING AND EVENING AVERAGES
1. Select your USER ID (A or B).
2. Press the Morning Average button
( ) or the Evening Average
button ( ).
The average for the current
week “THIS WEEK” appears
on the display.
3. Continue to press the Morning Average button ( ) or the Evening
Average button ( ) to display the previous weeks. The monitor
displays “-1 WEEK” for the previous week to “-7 WEEK” for the
oldest set of averages.
NOTE: If no measurement is taken in a given
week, the display will appear
as illustrated.
4. Press the START/STOP button to turn the monitor off.
40
USING THE MEMORY FUNCTION
DISPLAY COMBINATIONS
In addition to the Morning Average and Evening Average Symbols,
the monitor may also display the Morning Hypertension Symbol if the
morning average for that week is above the AHA guidelines. (See page
12 for details.) Depending on your measurement results, these may be
displayed in the following combinations.
Display
Morning
Average
Morning average from 7 weeks ago
Morning average from This Week
with Morning Average Symbol
Evening
Average
Evening average from This Week
with Evening Average Symbol
with Morning Average Symbol +
blinking Heartbeat Symbol + Morn-
ing Hypertension Symbol
Evening average from 7 weeks ago
with Evening Average Symbol +
blinking Heartbeat Symbol + Morn-
ing Hypertension Symbol
Average within AHA guidelines
Average above AHA guidelines +
Morning Hypertension
41
USING THE MEMORY FUNCTION
The Morning Hypertension Symbol ()appears if the weekly average
for morning measurements is above 135/85.
In this case the Morning Hypertension Symbol
the Evening Average is displayed, regardless of the values for the
Evening Average.
()is displayed when
TO DELETE ALL VALUES STORED IN THE MEMORY
The values stored in the memory are deleted by USER ID.
You cannot partially delete values stored in the memory. All values for
the user you select will be deleted.
1. Select your USER ID (A or B).
2. While holding the Memory button ( ) and the START/STOP
button simultaneously for more than 2 seconds all values will
be deleted.
42
Care and Maintenance
CARE AND MAINTENANCE
To keep your digital blood pressure monitor in the best condition and
protect the unit from damage, follow the directions listed below:
Close the monitor cover when not in use.
Do not forcefully bend the arm cuff or air
tube. Do not fold tightly.
CAUTION
Do not store the AC adapter in the cuff compartment. This may
damage the cuff.
Clean the monitor with a soft dry cloth. Do not use any abrasive or
volatile cleaners. Do not attempt to clean the cuff.
CAUTION
Do not submerge the device or any of the components in water.
Do not subject the monitor to extreme hot or cold temperatures,
humidity or direct sunlight.
CAUTION
Store the device and the components in a clean, safe location.
CAUTION
Do not subject the monitor to strong shocks, such as dropping the
unit on the floor.
43
CARE AND MAINTENANCE
Remove the batteries if the unit will not be used for three months or
longer. Always replace all the batteries with new ones at the same time.
Use the unit consistent with the instruction provided in this manual.
CAUTION
Changes or modification not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
CAUTION
Use only Omron authorized parts and accessories. Parts and
accessories not approved for use with the device may
damage the unit.
44
ERROR INDICATORS AND TROUBLESHOOTING TIPS
ERROR INDICATORS
SYMBOL CAUSE CORRECTION
Cuff under-inflated.
Cuff not applied
correctly.
Cuff over-inflated
Monitor could not
detect pulse wave.
Air plug is not
connected.
Single Mode
Remove the arm cuff. Read,
“Taking a Measurement”.
Take another measurement.
TruReadTMMode
The monitor will repeat the
process up to 5 times.
Take another measurement and
remain still until the
measurement is complete.
Batteries are worn
Replace the four batteries. Refer
to “Battery Installation.”
45
ERROR INDICATORS AND TROUBLESHOOTING TIPS
TROUBLESHOOTING TIPS
PROBLEM CAUSES AND SOLUTIONS
No power.
No display appears on the unit.
Measurement values appear
too high or too low.
Replace all four batteries with new
ones.
Check the battery installation
for proper placement of the
battery polarities.
Blood pressure varies constantly.
Many factors including stress, time
of day, and how you wrap the cuff,
may affect your blood pressure.
Review the sections “Before Taking
a Measurement” and “Taking a
Measurement.”
46
FCC STATEMENT
Note:
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)
This product has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. The product generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If the product does cause harmful interference to radio or television
reception, which can be determined by turning the product on and off, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for Canada only)
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the interference-causing equipment
standard entitled “Digital Apparatus”, ICES-003 of the Canadian Department of
Communications.
Cet appareil numérique respecte les limites de bruits radioeléctriques
applicables aux appareils numériques de Clase B prescrites dans la norme sur le
materiel brouilleur: “Appareils Numériques”, ICES-003 édictée par le minister
des communications.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
47
WARRANTY
Your HEM-775 IntelliSense®Automatic Blood Pressure Monitor, excluding the
arm cuff, is warranted to be free from defects in materials and workmanship appearing
within 5 years from the date of purchase, when used in accordance with the
instructions provided with the monitor. The arm cuff is warranted to be free from
defects in materials and workmanship appearing within one year from the date of
purchase when the monitor is used in accordance with the instructions provided
with the monitor. The above warranties extend only to the
original retail purchaser.
We will, at our option, repair or replace without charge any monitor or arm cuff
covered by the above warranties. Repair or replacement is our only
responsibility and your only remedy under the above warranties.
To obtain warranty service contact Omron Healthcare for the address
of the repair location. Shipping instructions and repair information is available by
calling 1-800-634-4350 or visit our website at www.omronhealthcare.com.
Enclose the Proof of Purchase. Include $5.00 for the return shipping and handling.
Include a letter, with your name, address, phone number, and description of the
specific problem. Pack the product carefully to prevent damage in transit.
Because of possible loss in transit, we recommend insuring the product with
return receipt requested.
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF
THE APPLICABLE WRITTEN WARRANTY ABOVE.
allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER
INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES
OR DAMAGES.
or consequential damages, so the above exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights
which may vary from state to state.
Visit our web site at: www.omronhealthcare.com
Call toll free: 1-800-634-4350
Some states do not allow the exclusion or limitation of incidental
FOR CUSTOMER SERVICE
Some states do not
48
SPECIFICATIONS
Model: HEM-775
Display: LCD Digital Display
Measurement Range: Pressure: 0 to 299 mmHg, Pulse: 40-180/min.
Accuracy/Calibration: Pressure: ±3mmHg or 2% of reading
Inflation: Automatic by electric pump
Deflation: Automatic pressure release valve
Rapid Air Release: Automatic exhaust valve
Pressure Detection: Capacitive pressure sensor
Measurement Method: Oscillometric method
Pulse Wave Detection: Capacitance type pressure sensor
Power Source: 120V 60Hz AC adapter or 4 “AA” batteries
Battery Life: Approx. 1400 uses when used 6 times a day
Operating Temperature 50ºF to 104ºF (10ºC to 40ºC) /30 to 85% RH
/Humidity:
Storage Temperature -4ºF to 140ºF (-20ºC to 60ºC) /10 to 95% RH
/Humidity/Air Pressure: /700 - 1060 hPa
Main Unit Weight: Approximately 33.9 oz. (960 g)
Main Unit Dimensions: Approximately 9 3/4" (l)
Cuff Size: Approximately 6" (w) (152 mm)
Cuff Circumference: Fits arm circumferences 9" to 17"
Memory: Up to 84 per user
Weekly Averages: Up to 8 weeks
Contents: Main Unit, ComFit
UPC Code: 0 73796 85775 2
NOTE: These specifications are subject to change without notice.
Pulse: ±5% of reading
with 4 new alkaline batteries
not including batteries
(Approximately 249 mm × 178 mm × 110 mm)
Cuff tube 23 5/8" (l) (600 mm)
220 mm to 420 mm
Instruction Manual, 4 “AA” Batteries and Warranty Card
× 7" (w) × 4 3/8" (h)
TM
Cuff, AC Adapter,
49
NOTES
50
NOTES
51
Manufactured by OMRON HEALTHCARE
Made in China
Distributed by:
OMRON HEALTHCARE, INC.
1200 Lakeside Drive
Bannockburn, Illinois 60015
www.omronhealthcare.com
Copyright © 2006 Omron Healthcare, Inc.
HEM-775INST Rev
Loading...
