Thank you for purchasing the OMRON HEM-7201 Automatic Blood Pressure Monitor.

The OMRON HEM-7201 is a compact, fully automatic blood pressure monitor, operating on the oscillometric principle. It measures your blood pressure and pulse rate simply and quickly. For comfortable controlled inflation without the need of pressure pre-setting or re-inflation the devices uses its advanced “IntelliSense” technology.

Intended Use

This product is designed to measure the blood pressure and pulse rate of people within the range of the designated arm cuff, following the instructions in this instruction manual. It is mainly designed for general household use. Please read the Important Safety Information in this instruction manual before using the unit.

Please read this instruction manual thoroughly before using the unit. Please keep for future reference. For specific information about your own blood pressure, CONSULT YOUR DOCTOR.

Consult your doctor prior to using in pregnancy or if diagnosed with arrhythmia or arteriosclerosis. Please read this section carefully before using the unit.

Warning:

• Indicates a potentially hazardous situation which, if not avoided, could result

in death or serious injury.

(General Usage)

• Always consult your doctor. Self-diagnosis of measurement results and

self-treatment are dangerous.

• People with severe blood flow problems, or blood disorders, should consult a

doctor before using the unit, as cuff inflation can cause internal bleeding.

(AC Adapter Usage)

• Never plug in or unplug the power cord from the electric outlet with wet

hands.

(Battery Usage)

• If battery fluid should get in your eyes, immediately rinse with plenty of clean

water. Consult a doctor immediately.

Caution:

• Indicates a potentially hazardous situation which, if not avoided, may result in

minor or moderate injury to the user or patient or damage to the equipment or other property.

(General Usage)

• Do not leave the unit unattended with infants or persons who cannot express

their consent.

• Do not use the unit for any purpose other than measuring blood pressure.

• Do not disassemble the unit or arm cuff.

• Use only the approved arm cuff for this unit. Use of other arm cuffs may result

in incorrect measurement results.

• Make sure that the air tube is not wrapped around other parts of your body

when taking measurements at night. This could result in injury when the air pressure in the air tube is increased.

• Do not leave the cuff wrapped on the arm if taking measurements during the

night. This could result in injury.

• Do not inflate the arm cuff over 299 mmHg.

• Do not use a mobile phone or other devices that emit electromagnetic fields,

near the unit. This may result in incorrect operation of the unit.

• Do not operate the unit in a moving vehicle (car, airplane).

• To inflate the cuff manually, refer to Section 3.3. If the cuff is over inflated, it

can cause internal bleeding.

(AC Adapter Usage)

• Use only the original AC adapter (optional) designed for this unit. Use of unsupported adapters may damage and/or may be hazardous to the unit.

• Plug the AC adapter into the appropriate voltage outlet. Do not use a

multiple-tap.

• Do not use the AC adapter if the unit or the power cord is damaged. Turn off

the power and unplug the power cord immediately.

(Battery Usage)

• If battery fluid should get on your skin or clothing, immediately rinse with

plenty of clean water.

• Use only four “AA” alkaline or manganese batteries with this unit. Do not use

other types of batteries.

• Do not insert the batteries with their polarities incorrectly aligned.

• Replace old batteries with new ones immediately. Replace all four batteries at

the same time.

• Remove the batteries if the unit will not be used for three months or more.

• Do not use new and used batteries together.

General Precautions

• Do not apply strong shocks and vibrations to or drop the unit and arm cuff.

• Do not take measurements after bathing, drinking alcohol, smoking, exercising or eating.

• Do not forcibly bend the arm cuff or bend the air tube excessively.

• When removing the air tube, pull on the air plug at the connection with the

main unit not the tube itself.

• Do not inflate the arm cuff when it is not wrapped around your arm.

• Do not wash the arm cuff or immerse it in water.

• Read and follow the “Important information regarding Electro Magnetic Compatibility (EMC)” in the Technical Data Section.

• Read and follow the “Correct Disposal of This Product” in the Technical Data

Section when disposing of the device and any used accessories or optional parts.

Important Safety Information

Introduction

1. Overview

Main unit:

Arm cuff:

M. Systolic blood pressure N. Diastolic blood pressure O. Heartbeat symbol

(Flashes during measurement)

P. User A/B symbol Q. Memory symbol R. Battery low symbol S. Average value symbol

2.1 Installing/Replacing the Batteries

2. Preparation

Remove the battery cover.

2.2 Setting the Date and Time

Press the button.

Set the monitor to the correct date and time before taking a measurement for the first time.

Press the START/STOP button to store the setting.

Notes:

• If the batteries have been removed for 30 seconds or more, the date

and time setting will need to be reset.

• If the date and time are not set, “-:--” appears during or after

measurement.

Insert four “AA” batteries as indicated in the battery compartment and then replace the battery cover.

Notes:

• If the battery low symbol ( ) appears on the display, turn the unit off

then replace all batteries at the same time.

• The measurement values continue to be stored in memory even after

the batteries are replaced.

Disposal of used batteries should be carried out in accordance with the national regulations for the disposal of batteries.

The bottom edge of the cuff should be 1 to 2 cm above the elbow.

Marker (arrow under tube) is centred on the middle of your inner arm.

Close the fabric fastener FIRMLY.

3. Using the Unit

4. Troubleshooting and Maintenance

1. Insert the air plug into the air jack.

2. Put your arm through the cuff loop.

3. Position the arm correctly.

Systolic Blood Pressure Above 135 mmHg

Diastolic Blood Pressure Above 85 mmHg

3.1 Applying the Arm Cuff

3.3 Taking a Reading

6. Technical Data

5. Optional Parts

4.1 The Icons and Error Messages

Blink

Lit

4.2 Troubleshooting

4.3 Maintenance

Problem

3.4 Using the Memory Function

Calibration and Service

To protect your unit from damage, please observe the following:

Cause Remedy

Notes:

• When you take a measurement on the right

arm, air tube will be at the side of your elbow. Be careful not to rest your arm on the air tube.

Notes:

• To cancel a measurement, press the START/STOP button to turn off

the unit and to release the air in the arm cuff.

• Remain still while taking a measurement.

To Delete All the Values Stored in Memory

• Press the START/STOP button and repeat

measurement.

• If the problem continues, try replacing the

batteries with new ones. If this still does not solve the problem, contact your OMRON retail outlet or distributor.

• Do not subject the main unit and the cuff to extreme

temperatures, humidity, moisture or direct sunlight.

• Do not fold the cuff or tubing tightly.

• Do not inflate the arm cuff over 299 mmHg.

• Do not disassemble the unit.

• Do not subject the unit to strong shocks or vibrations (for example, dropping the unit on the floor).

• Do not use volatile liquids to clean the main unit. The

unit should be cleaned with a soft, dry cloth.

• Use a soft, moistened cloth and soap to clean the arm

cuff.

• Do not wash the arm cuff or immerse it in water.

• Do not use petrol, thinners or similar solvents to clean

the arm cuff.

• The accuracy of this blood pressure monitor has been

carefully tested and is designed for a long service life.

• It is generally recommended to have the unit inspected

every two years to ensure correct functioning and accuracy. Please consult your local authorised OMRON distributor or dealer.

• Do not carry out repairs of any kind yourself. If a defect

occurs, consult your local authorised OMRON distributor or dealer.

Automatic Blood Pressure Monitor HEM-7201 LCD Digital Display Oscillometric method

Pressure: 0 mmHg to 299 mmHg

Pulse: 40 to 180 beats/min.

Pressure: ±3 mmHg Pulse: ±5% of display reading Fuzzy-logic controlled by electric pump

Automatic pressure release valve

60 Measurements with date and time for each user (A and B)

DC6V 4W

4 “AA” batteries 1.5 V or AC adapter (optional) Capacity of new alkaline batteries is approximately 300 measurements

= Type B

Internally powered ME equipment

(When using only the batteries)

= Class II ME equipment

(Optional AC adapter) +10°C to +40°C / Maximum: 30 to 90% RH

-20°C to +60°C / Maximum: 10 to 95% RH /

700-1060 hPa

Approximately 340 g without batteries Approximately 120 g Approximately 123 (w) mm × 85 (h) mm × 141(l) mm Approximately 146 mm × 446 mm (Medium cuff: arm circumference 22 to 32 cm)

Nylon and polyester Main unit, cuff, instruction manual, storage case, battery set

Storage case:

Remove tight-fitting clothing or tight rolled up sleeve from your upper arm. Do not place the cuff over thick clothes.

3.2 How to Sit Correctly

To take a measurement, you need to be

relaxed and comfortably seated, under

comfortable room temperature. No eating,

smoking or exercising 30 minutes before

taking a measurement.

• Sit on a chair with your feet flat on the floor.

• Sit upright with your back straight.

• The cuff should be at the same level as your

heart.

1 to 2 cm

• The blood pressure can differ between the right arm and the left arm,

and therefore also the measured blood pressure values can be different. Omron recommends to always use the same arm for measurement. If the values between the two arms differ substantially, please check with your doctor which arm to use for your measurement.

Remove the arm cuff.

Press the START/STOP button to turn off the monitor. The monitor automatically stores the measurement in its memory.

It will automatically turn off after 5 minutes.

After the measurement, the backlight will automatically turn off without any operation within 1 minute.

The monitor automatically stores the result up to 60 sets in the memory

for two people (USER A and USER B) every time a measurement is

completed. It can also calculate an average reading based on the measurements from the last three readings taken within 10 minutes. If there are only two readings in memory for that period, the average will be based on two readings. If there is one reading in memory for that period, the average will be based on one reading. Notes:

• If the memory is full, the monitor will delete the oldest readings.

• When viewing the reading taken without setting the date and time,

“-:--” is displayed instead of the date and time.

Note: Wait 2-3 minutes before taking another blood pressure

measurement. Waiting between readings allows the arteries to return to the condition prior to taking the blood pressure measurement.

Note: You cannot partially delete the stored readings.

When the memory symbol ( ) appears, first press the Memory

button. Then while holding it down, press the START/STOP button

simultaneously for about 2-3 seconds.

Self-diagnosis of measured results and treatment are dangerous. Please follow the instructions of your doctor.

Warning:

• Recent research suggests that the following

values can be used as a guide to high blood pressure for measurements taken at home.

Important:

Irregular or weak pulses are detected.

The batteries are low.

The batteries are

exhausted.

Cuff is under inflated.

Movement during measurement.

Air plug disconnected.

Arm cuff not applied correctly.

Clothing is interfering with the arm cuff.

Air is leaking from the arm cuff.

The arm cuff was inflated

above 299 mmHg when

inflating the cuff manually.

Device error.

Remove the arm cuff. Wait

2-3 minutes and then take

another measurement. Repeat the steps in section

3.3. If this error continues to

appear, contact your doctor.

Movement during measurement.

Carefully read and repeat

the steps in section 3.3.

The reading is

extremely low (or high).

Arm cuff deflates too soon.

Arm cuff pressure does not rise.

Cannot measure or readings are too low or too high.

Nothing happens when you press the buttons.

Other problems.

Arm cuff not applied correctly.

Movement or talking during measurement.

Clothing is interfering with the arm cuff.

The air tube is not securely connected into the main unit.

Air is leaking from the arm cuff.

The arm cuff is loose.

The arm cuff has not been inflated sufficiently.

The batteries are empty.

The batteries have been inserted incorrectly.

Apply the arm cuff correctly.

Refer to section 3.1.

Remain still and do not talk during measurement.

Refer to section 3.3.

Remove any clothing interfering with the arm cuff.

Refer to section 3.2.

Make sure that the air tube is connected securely.

Refer to section 3.1.

Replace the arm cuff with a new one.

Refer to Chapter 5.

Apply the cuff correctly so that it is firmly wrapped around the arm.

Refer to section 3.1.

Inflate the cuff so that it

is 30 to 40 mmHg above

your previous measurement result.

Refer to section 3.3.

Replace the batteries with new ones. Refer to section 2.1.

Insert the batteries with

the correct (+/-) polarity.

Refer to section 2.1.

You should replace them with new ones ahead of time. Refer to section 2.1.

You should replace them with new ones at once. Refer to section 2.1.

Carefully read and repeat the steps listed under

section 3.3.

Repeat measurement. Remain still and do not talk during measurement.

Refer to section 3.3.

Insert the air plug securely.

Refer to section 3.1.

Apply the arm cuff correctly.

Refer to section 3.1.

Remove any clothing interfering with the arm cuff.

Refer to section 3.1.

Replace cuff with new one.

Refer to Chapter 5.

Do not inflate the arm cuff

above 299 mmHg. Refer to section 3.3.

Contact your OMRON retail outlet or distributor.

Cause RemedyError Display

1. Unplug the air tube from the air connector.

2. Gently fold the air tube into the arm cuff.

4.4 Storage

Keep the unit in its storage case when not in use.

Note:

Do not bend the air tube excessively.

Do not store the unit in the following situations:

• If the unit is wet.

• Locations exposed to extreme temperatures,

humidity, direct sunlight, dust or corrosive vapours.

• Locations exposed to vibrations, shocks or where it will be at an

angle.

Place the arm cuff and main unit in the storage case.

Using the Optional AC Adapter

Insert the AC adapter plug into the AC adapter jack on the rear side of the main unit.

Plug the AC adapter into an electrical outlet.

Medium Arm Cuff

Arm circumference

22 - 32 cm

Large Arm Cuff

Arm circumference

32 - 42 cm

AC Adapter “R”

Product Description Model Display Measurement Method Measurement Range

Accuracy

Inflation Deflation Memory Rating Power Source

Battery Life

Applied Part

Protection against Electric Shock

Operating Temperature/ Humidity Storage Temperature/ Humidity/ Air Pressure Console Weight Cuff Weight Outer Dimensions Cuff Dimensions

Cuff Material Package Content

Automatic Blood Pressure Monitor

Model HEM-7201

Instruction Manual

A. Display B. START/STOP button C. USER A/B button

D. Memory ( ) buttons E. Date/Time setting ( ) button

F. Air Jack G. Battery compartment

H. AC adapter jack (for optional AC

adapter)

I. Arm cuff (Medium cuff: arm

circumference 22-32 cm)

J. Coloured Marker K. Air tube L. Air plug

T. Deflation symbol U. Blood pressure level indicator V. Pulse display/Memory number W. Movement error symbol X. Cuff wrapping guide Y. Irregular heartbeat symbol Z. Date/Time display

Push or buttons to change.

Push the button to confirm.

Next setting appears.

Year

Month

Day

Hour

Minute

START INFLATE DEFLATE END

COMPLETE

If your systolic pressure is more than 220 mmHg

After the cuff starts to inflate, press and hold the

START/STOP button until the monitor inflates 30 to 40 mmHg higher than your expected systolic pressure.

Notes:

• The monitor will not inflate above 299 mmHg.

• Do not apply more pressure than necessary.

• Your blood pressure monitor includes an irregular

heartbeat feature. Irregular heartbeats can influence the results of the measurement. The irregular heartbeat algorithm automatically determines if the measurement is usable or needs to be repeated. If the measurement results are affected by irregular heartbeats but the result is valid, the result is shown

together with the irregular heartbeat symbol ( ). If the

irregular heartbeats cause the measurement to be

invalid, no result is shown. If the irregular heartbeat symbol ( ) is

shown after you have taken a measurement, repeat the

measurement. If the irregular heartbeat symbol ( ) is shown

frequently, please make your doctor aware of it.

View the Average Value

• If the previous

reading was taken without setting the date and time, the average value is not calculated.

View the Previous Reading

• The Memory number

appears for a second before the pulse rate is displayed. The newest set is numbered “1”.

View the Readings Stored in Memory

Display:

To disconnect the AC adapter, unplug the AC adapter from the electrical outlet first and then remove the AC adapter plug from the main unit.

5331366-8B

Notes:

• Subject to technical modification without prior notice.

• Disposal of this product and used batteries should be carried out in

accordance with the national regulations for the disposal of electronic products.

Please read this instruction manual carefully before using the device.

• This device fulfils the provisions of EC directive 93/42/EEC (Medical Device Directive).

• This blood pressure monitor is designed according to the European Standard

EN1060, Noninvasive sphygmomanometers Part 1: General Requirements

and Part 3: Supplementary requirements for electromechanical blood

pressure measuring systems.

Important information regarding Electro Magnetic Compatibility (EMC)

With the increased number of electronic devices such as PC’s and mobile

(cellular) telephones, medical devices in use may be susceptible to

electromagnetic interference from other devices. Electromagnetic interference may result in incorrect operation of the medical device and create a potentially unsafe situation. Medical devices should also not interfere with other devices.

In order to regulate the requirements for EMC (Electro Magnetic Compatibility)

with the aim to prevent unsafe product situations, the EN60601-1-2:2007 standard has been implemented. This standard defines the levels of immunity to

electromagnetic interferences as well as maximum levels of electromagnetic

emissions for medical devices.

This medical device manufactured by OMRON HEALTHCARE conforms to this EN60601-1-2:2007 standard for both immunity and emissions. Nevertheless, special precautions need to be observed:

• Do not use mobile (cellular) telephones and other devices, which generate

strong electrical or electromagnetic fields, near the medical device. This may result in incorrect operation of the unit and create a potentially unsafe situation. Recommendation is to keep a minimum distance of 7 m. Verify correct operation of the device in case the distance is shorter.

Further documentation in accordance with EN60601-1-2:2007 is available at OMRON HEALTHCARE EUROPE at the address mentioned in this instruction manual. Documentation is also available at www.omron-healthcare.com.

This marking shown on the product or its literature, indicates that it should not be disposed of, with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions

of the purchase contract. This product should not be mixed with other commercial

wastes for disposal.

This product does not contain any hazardous substances.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

Asia Pacific HQ

Production Facility

OMRON HEALTHCARE Co., Ltd.

53, Kunotsubo, Terado-cho, Muko, Kyoto

617-0002 JAPAN

OMRON HEALTHCARE EUROPE B.V.

Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS

OMRON HEALTHCARE SINGAPORE PTE LTD.

438A Alexandra Road, #05-05/08, Alexandra Technopark Singapore 119967

www.omron-healthcare.com.sg

OMRON HEALTHCARE MANUFACTURING VIETNAM CO., LTD.

Binh Duong Province, Vietnam

Cuff wrapping guide This monitor checks whether the cuff is applied correctly during the inflation. When the cuff is applied correctly, is displayed while taking a measurement or using the memory function. If the cuff is not applied correctly, is displayed. Carefully read and repeat the steps listed under this section.

Press the START/STOP button.

The cuff will start to inflate automatically. The backlight will turn on automatically when you turn on the monitor.

Press the START/STOP button to turn the monitor on.

All symbols appear on the display.

Select your USER ID (A or B).

To Display the Measurement Values

1. Press the START/STOP button to turn the monitor on.

2. Select your USER ID (A or B).

3. Press the Up button ( ) to display average reading and the most

recent set of measurement values on the screen.

Press the Down button ( ) to display the oldest set of

measurement values.

Average Value Previous Reading

Alternating date/time display

RecentOld

Notes:

• The measurement value number is

displayed briefly in the Pulse Display area when you press the Up/Down buttons

( / ).

• The date and time are alternately displayed

with the measurement values.

• If the date and time are not set, “-:--” is

displayed with the measurement values.

• Press the button repeatedly to display the next values.

• Press and hold the button to display the

values faster.

Alternating display

Cuff is not applied correctly.

Apply the arm cuff correctly. Refer to section 3.1.

This OMRON product is manufactured under the strict quality system of OMRON HEALTHCARE Co., Ltd., Japan. The Core component for OMRON blood pressure monitors, which is the Pressure Sensor, is produced in Japan for assembly.

HEM-7201-C1_B_M03_100331.pdf

Q R

IJ K

Omron _mn Ho$ {bE h_oem g_mZ ^wOm H$m Cn`moJ H$aZo H$s AZwe§gm H$aVm h¡& AJa Xmo ^wOmAm| Ho$

~rM Ho$ _mZ ~hþV A{YH$ {^Þ hmoVo h¢, Vmo H¥$n`m AnZo S>m°ŠQ>a go nyN|> {H$ AnZo _mn Ho$ {bE H$m¡Z-gr ^wOm H$m Cn`moJ H$a|&

H$μ\$ bnoQ>Zo H$s _mJ©X{e©H$m

`h _m°ZrQ>a Om±M H$aVm h¡ {H$ Š`m \w$bmZo Ho$ Xm¡amZ H$μ\$ ghr VarHo$ go bnoQ>m J`m Wm& O~ H$μ\$ ghr VarHo$ go bnoQ>m J`m hmoVm h¡, Vmo _mn boVo g_` `m ñ_¥{V μ\§$ŠeZ H$m Cn`moJ H$aVo g_` àX{e©V hmoVm h¡& AJa H$μ\$ ghr VarHo$ go Zht bnoQ>m J`m hmoVm h¡, Vmo àX{e©V hmoVm h¡& Bg AZw^mJ Ho$ A§VJ©V gyMr~Õ MaUm| H$mo Ü`mZnyd©H$ n‹T|> Am¡a XmohamE±&

{Q>ßn{U`m±:

• O~ Amn XmBª ^wOm na _mn boVo h¢, Vmo dm`w Q>çy~ AmnH$s H$mohZr

H$s ~Jb _| hmoJr& Ü`mZ aI| {H$ AmnZo AnZr ^wOm dm`w Q>çy~ Ho$ D$na Z aIr hmo&

• aº$Mmn XmBª ^wOm Am¡a ~mBª ^wOm Ho$ ~rM {^Þ hmo gH$Vm h¡ Am¡a Bg{bE _mno JE aº$Mmn _mZ ^r {^Þ hmo gH$Vo h¢&

n[ad{V©V H$aZo Ho$ {bE `m ~Q>Z X~mE±& nw{ï> H$aZo Ho$ {bE ~Q>Z X~mE±& AJbr goqQ>J àH$Q> hmoVr h¡&

ñdMm{bV aº$Mmn _m°ZrQ>a

HEM-7201 LCD

{S>{OQ>b àXe©Z Am°{gbmo{_{Q´>H$ nÕ{V X~md:

0 mmHg go 299 mmHg

ZãO: 40 go 180 ñn§XZ/{_ZQ> X~md: ±3 mmHg ZãO: àXe©Z arqS>J H$m ±5% BbopŠQ´>H$ n§n Ûmam {Z`§{ÌV μ\$μÁμOr-bm°{OH$ ñdMm{bV X~md [abrμO dmëd àË`oH$ Cn`moJH$Vm

(A Am¡a B) Ho$ {bE {V{W Am¡a g_` Ho$ gmW 60 _mn

DC6V 4W 4 “AA”

~¡Q>ar 1.5 V `m AC AS>mßQ>a (d¡H$pënH$) ZB© jmar` ~¡Q>ar H$s j_Vm bJ^J

300 _mn h¡

= àH$ma B

Am§V[aH$ ê$n go Mm{bV ME CnH$aU (Ho$db ~¡Q>ar H$m Cn`moJ H$aZo na)

= loUr II ME CnH$aU

(d¡H$pënH$

AC AS>mßQ>a)

+10°C go +40°C / A{YH$V_: 30 go 90% RH

-20°C

go +60°C / A{YH$V_: 10 go 95% RH /

700-1060 hPa

{~Zm ~¡Q>ar Ho$ bJ^J 340 J«m. bJ^J

120 J«m.

bJ^J

123 (Mm¡) {__r. × 85 (D±$) {__r. × 141 (b§) {__r.

bJ^J

146 {__r. × 446 {__r. (_Ü`_ AmH$ma H$m H$μ\$:

^wOm n[a{Y

22 go 32 go_r)

Zm`bm°Z Am¡a nm°{bEñQ>a _w»` `y{ZQ>, H$μ\$, {ZX}e _¡Ý`wAb, g§J«hU Ho$g, ~¡Q>ar goQ>

OMRON HEM-7201 ñdMm{bV aº$Mmn _m°ZrQ>a IarXZo Ho$ {bE YÝ`dmX&

OMRON HEM-7201 EH$ H$m°ån¡ŠQ>, nyU©V… ñdMm{bV aº$Mmn _m°ZrQ>a h¡, Omo Am°{gbmo{_{Q´>H$ {gÕm§V na H$m`©

H$aVm h¡& `h AmgmZr Am¡a VoμOr go AmnHo$ aº$Mmn Am¡a ZãO Xa H$mo _mnVm h¡& X~md nyd©-goqQ>J `m nwZ… \w$bmd H$s Amdí`H$Vm Ho$ {~Zm Amam_Xm`H$ {Z`§{ÌV \w$bmd Ho$ {bE, CnH$aU AnZr CÞV "B§Qo>{bg|g' VH$ZrH$ H$m Cn`moJ H$aVm h¡&

A{^àoV Cn`moJ

`h CËnmX Bg {ZX}e _¡Ý`wAb _| {XE JE {ZX}em| H$m nmbZ H$aVo hþE, {Z{X©ï> Am_© H$μ\$ Ho$ \¡$bmd _| bmoJm| Ho$ aº$Mmn Am¡a ZãO Xa H$mo _mnZo Ho$ {bE {S>μOmBZ {H$`m J`m h¡& Bgo _w»` ê$n go gm_mÝ` Kaoby Cn`moJ Ho$ {bE {S>μOmBZ {H$`m J`m h¡& H¥$n`m Bg `y{ZQ> H$m Cn`moJ H$aZo go nhbo Bg {ZX}e _| Xr JB© _hËdnyU© gwajm OmZH$mar n‹T|>&

H¥$n`m Bg `y{ZQ> H$m Cn`moJ H$aZo go nhbo Bg {ZX}e _¡Ý`wAb H$mo AÀN>r Vah n‹T|>& H¥$n`m Bgo ^{dî` Ho$ g§X^© Ho$ {bE aI b|& AmnHo$ ñd`§ Ho$ aº$Mmn Ho$ ~mao _| {d{eï> OmZH$mar Ho$ {bE, AnZo S>m°ŠQ>a go nam_e© b|&

J^m©dñWm Ho$ Xm¡amZ AWdm Ear{W{_`m `m Y_Zr H$m{R>Ý` {ZXmZ {H$`m J`m hmo, Vmo Cn`moJ go nhbo AnZo S>m°ŠQ>a go nam_e© H$a|& H¥$n`m Bg `y{ZQ> H$m Cn`moJ H$aZo go nhbo Bg AZw^mJ H$mo Ü`mZnyd©H$ n‹T|>&

MoVmdZr:

• g§^m{dV ê$n go Omo{I_nyU© n[apñW{V H$mo B§{JV H$aVr h¡, ~Mmd Z {H$E OmZo na {OgH$m n[aUm_ _¥Ë`w `m J§^ra j{V

hmo gH$Vm h¡&

(gm_mÝ` Cn`moJ)

• h_oem AnZo S>m°ŠQ>a go nam_e© b|& _mn n[aUm_m| H$m ñd`§ amoJ {ZXmZ Am¡a ñd`§ BbmO IVaZmH$ h¢&

• J§^ra aº$ àdmh g_ñ`mAm| `m aº$ Aì`dñWmAm| dmbo bmoJm| H$mo `y{ZQ> H$m Cn`moJ H$aZo go nhbo S>m°ŠQ>a go nam_e©

boZm Mm{hE, Š`m|{H$ H$μ\$ go \w$bmd go Am§V[aH$ aº$òmd hmo gH$Vm h¡&

(AC AS>mßQ>a Cn`moJ)

• nmda H$m°S©> H$mo H$^r ^r Jrbo hmWm| go BbopŠQ´>H$ AmCQ>boQ> _| ßbJ `m Cggo AZßbJ Z H$a|&

(~¡Q>ar Cn`moJ)

• AJa ~¡Q>ar H$m Vab nXmW© AmnH$s Am±Im| _| Mbm OmVm h¡, Vmo Vwa§V AË`{YH$ gm\$ nmZr go YmoE±& Vwa§V S>m°ŠQ>a go nam_e© b|&

gmdYmZr:

• g§^m{dV ê$n go Omo{I_nyU© n[apñW{V H$mo B§{JV H$aVr h¡, {OgHo$ n[aUm_ñdê$n Cn`moJH$Vm© `m amoJr H$mo N>moQ>r `m

gm_mÝ` j{V`m± AWdm CnH$aU `m AÝ` g§n{Îm H$mo j{V hmo gH$Vr h¢&

(gm_mÝ` Cn`moJ)

• `y{ZQ> H$mo ZdOmVm| `m CZ ì`{º$`m| Ho$ nmg Cno{jV Z N>mo‹S|> Omo AnZr gh_{V ì`º$ Zht H$a gH$Vo h¢&

• aº$Mmn _mnZo Ho$ A{V[aº$ {H$gr ^r CÔoí` Ho$ {bE `y{ZQ> H$m Cn`moJ Z H$a|&

• `y{ZQ> `m Am_© H$μ\$ H$mo AbJ Z H$a|&

• Bg `y{ZQ> Ho$ {bE Ho$db AZw_mo{XV Am_© H$μ\$ H$m Cn`moJ H$a|& AÝ` Am_© H$μ\$ H$m Cn`moJ H$aZo Ho$ JbV _mn n[aUm_

hmo gH$Vo h¢&

• gw{ZpíMV H$a| {H$ amV _| _mn boVo g_` dm`w Q>çy~ AmnHo$ eara Ho$ AÝ` ^mJm| na Zht {bnQ>r hþB© h¡& dm`w Q>çy~ _| dm`w X~md

~‹T>Zo na Bggo j{V nhþ±M gH$Vr h¡&

• AJa amV _| _mn bo aho hm| Vmo H$μ\$ H$mo ^wOm na {bnQ>m Z N>mo‹S|>& Bggo j{V nhþ±M gH$Vr h¡&

• Am_© H$μ\$ H$m 299 mmHg go A{YH$ Z \w$bmE±&

• _mo~mBb μ\$moZ `m {dÚwV-Mw§~H$s` joÌ ~ZmZo dmbo AÝ` CnH$aUm| H$m `y{ZQ> Ho$ {ZH$Q> Cn`moJ Z H$a|& Bggo `y{ZQ> JbV H$m`©

H$a gH$Vm h¡&

• `y{ZQ> H$mo MbVo dmhZ (H$ma, {d_mZ) _| g§Mm{bV Z H$a|&

• H$μ\$ H$mo _¡Ý`wAb ê$n go \w$bmZo Ho$ {bE, AZw^mJ 3.3 XoI|& AJa H$μ\$ AË`{YH$ \y$b OmVm h¡, Vmo Bggo Am§V[aH$ aº$òmd

hmo gH$Vm h¡&

(AC AS>mßQ>a Cn`moJ)

• Ho$db Bg `y{ZQ> Ho$ {bE {Z{X©ï> _yb AC AS>mßQ>a (d¡H$pënH$) H$m Cn`moJ H$a|& Ag_{W©V AS>mßQ>a H$m Cn`moJ `y{ZQ> H$mo

j{V nhþ±Mm gH$Vm h¡ Am¡a/`m CgHo$ {bE Omo{I_nyU© hmo gH$Vm h¡&

• AC AS>mßQ>a H$mo C{MV dmoëQo>O AmCQ>boQ> _| ßbJ H$a|& EH$m{YH$-Q¡>n H$m Cn`moJ Z H$a|&

• AJa `y{ZQ> `m nmda H$m°S©> j{VJ«ñV h¡, Vmo AC AS>mßQ>a H$m Cn`moJ Z H$a|& Vwa§V nmda ~§X H$a X| Am¡a nmda H$m°S©> H$mo

AZßbJ H$a X|&

(~¡Q>ar Cn`moJ)

• AJa ~¡Q>ar H$m Vab nXmW© AmnH$s ËdMm `m H$n‹S>m| na bJ OmVm h¡, Vmo Vwa§V AË`{YH$ gm\$ nmZr go YmoE±&

• Bg `y{ZQ> Ho$ gmW Ho$db Mma ‘AA’ jmar` `m _¢JZrμO ~¡Q>ar H$m Cn`moJ H$a|& AÝ` àH$ma H$s ~¡Q>ar H$m Cn`moJ Z H$a|&

• ~¡Q>ar H$mo CZH$s Y«wdVm H$mo JbV g§ao{IV H$aHo$ Z bJmE±&

• nwamZr ~¡Q>ar H$mo Vwa§V ZB© ~¡Q>ar go ~Xb|& g^r Mmam| ~¡Q>ar H$mo EH$ gmW ~Xb|&

• AJa `y{ZQ> H$m VrZ `m A{YH$ _hrZm| Ho$ {bE Cn`moJ Zht {H$`m OmZm h¡ Vmo ~¡Q>ar {ZH$mb X|&

• ZB© Am¡a Cn`moJ H$s JB© ~¡Q>ar H$m gmW _| Cn`moJ Z H$a|&

gm_mÝ` gmdYm{Z`m±

• `y{ZQ> Am¡a Am_© H$μ\$ H$mo VoμO PQ>Ho$ Am¡a H§$nZ Z X| `m CÝh| {JamE± Zht&

• g³mZ, _{XamnmZ, Yw_«nmZ, ì`m`m_ `m ^moOZ H$aZo Ho$ ~mX _mn Z b|&

• Am_© H$μ\$ H$mo ~bnyd©H$ Z _mo‹S|> `m dm`w Q>çy~ H$mo AË`{YH$ Z _mo‹S|>&

• dm`w Q>çy~ H$mo {ZH$mbVo g_`, _w»` `y{ZQ> go H$ZoŠeZ na dm`w ßbJ H$mo ItM|, Z {H$ ñd`§ Q>çy~ H$mo&

• O~ Am_© H$μ\$ AmnH$s ^wOm na Z {bnQ>m hmo, V~ Bgo Z \w$bmE±&

• Am_© H$μ\$ H$mo Z YmoE± `m Bgo nmZr _| Z {^JmoE±&

_hËdnyU© gwajm OmZH$mar

^y{_H$m

1. AdbmoH$Z

_w»` `y{ZQ>:

Am_© H$μ\$:

M. àHw§$MZ aº$Mmn N. àgaU aº$Mmn O. öX`ñn§XZ àVrH$

(_mn boZo Ho$ Xm¡amZ μâb¡e H$aVm h¡)

P. Cn`moJH$Vm© A/B àVrH$ Q. ñ_¥{V àVrH$ R. ~¡Q>ar H$_ hmoZo H$m àVrH$ S. Am¡gV _mZ àVrH$

2.1 ~¡Q>ar bJmZm/~XbZm

2. V¡`mar

~¡Q>ar H$da H$mo {ZH$mb|&

2.2 {V{W Am¡a g_` goQ> H$aZm

~Q>Z X~mE±&

nhbr ~ma _mn boZo go nhbo _m°ZrQ>a H$mo ghr {V{W Am¡a g_` na goQ> H$a|&

goqQ>J H$mo g§J«hrV H$aZo Ho$ {bE START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±&

{Q>ßn{U`m±:

• AJa 30 goH§$S> `m A{YH$ g_` Ho$ {bE ~¡Q>ar H$mo {ZH$mb {X`m OmVm h¡, Vmo {V{W Am¡a g_` goqQ>J H$mo argoQ>

H$aZo H$s Amdí`H$Vm hmoJr&

• AJa {V{W Am¡a g_` goQ> Zht {H$E OmVo h¢, Vmo _mn boZo Ho$ Xm¡amZ `m CgHo$ ~mX “-:--” àH$Q> hmoVm h¡&

Mma “AA” ~¡Q>ar H$mo ~¡Q>ar H§$nmQ©>_|Q> _| {XImE JE AZwgma bJmE± Am¡a {\$a ~¡Q>ar H$da H$mo dmng bJm X|&

{Q>ßn{U`m±:

• AJa àXe©Z na ~¡Q>ar H$_ hmoZo H$m àVrH$ ( ) àH$Q> hmoVm h¡,

Vmo `y{ZQ> H$mo ~§X H$a X| Am¡a {\$a EH$ gmW g^r ~¡Q>ar H$mo ~Xb X|&

• ~¡Q>ar H$mo ~Xb {XE OmZo na ^r _mn Ho$ _mZ {Za§Va ñ_¥{V _|

g§J«hrV hmoVo ahVo h¢&

~¡Q>ar Ho$ {ZnQ>mZ Ho$ {bE amï´>r` {d{Z`_m| Ho$ AZwgma Cn`moJ H$s JB© ~¡Q>ar H$m {ZnQ>mZ {H$`m OmZm Mm{hE&

H$μ\$ H$m {ZMbm {H$Zmam H$mohZr go 1 go 2 go_r D$na hmoZm Mm{hE& _mH©$a (Q>çy~ Ho$ ZrMo _m¡OyX Vra) AmnH$s ^wOm Ho$ Am§V[aH$ ^mJ Ho$ _Ü` na H|${ÐV hmo& μ\¡${~«H$ ~§YZ H$mo AÀN>r Vah go ~§X H$a|&

3. `y{ZQ> H$m Cn`moJ H$aZm

1. dm`w ßbJ H$mo dm`w O¡H$ _| bJmE±&

2. AnZr ^wOm H$mo H$μ\$ byn _| go {ZH$mb|&

3. ^wOm H$mo R>rH$ VarHo$ go aI|&

àHw§$MZ aº$Mmn

135 mmHg go A{YH$

àgaU aº$Mmn

85 mmHg go A{YH$

3.1 Am_© H$μ\$ bnoQ>Zm

3.3 arqS>J boZm

3.4 ñ_¥{V μ\§$ŠeZ H$m Cn`moJ H$aZm

{Q>ßn{U`m±:

• _mn aÔ H$aZo Ho$ {bE, `y{ZQ> H$mo ~§X H$aZo Am¡a Am_© H$μ\$ _| _m¡OyX dm`w H$mo {ZH$mbZo Ho$ {bE

START/STOP

(àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±&

• _mn boVo g_` pñWa ah|&

ñ_¥{V _| g§J«hrV g^r _mZm| H$mo hQ>mZo Ho$ {bE

g§J«hU Ho$g:

3.2

ghr VarHo$ go H¡$go ~¡R|>

_mn boZo Ho$ {bE, AmnH$mo Amam_Xoh H$_ao Ho$ Vmn_mZ _| {e{WbVm Am¡a Amam_Xoh VarHo$ go ~¡R>Zo H$s Amdí`H$Vm hmoVr h¡& _mn boZo go nhbo 30 {_ZQ> VH$ Hw$N> Z ImE±, Yw_«nmZ `m ì`m`m_ Z H$a|&

• gVh na AnZo n¡a grYo aIH$a Hw$gu na ~¡R|>&

• AnZr nrR> grYr aIH$a grYo ~¡R|>&

• H$μ\$ AmnHo$ öX` {OVZo g_mZ ñVa na hmoZm Mm{hE&

1 go 2 go_r

Am_© H$μ\$ H$mo {ZH$mb|&

_m°ZrQ>a H$mo ~§X H$aZo Ho$ {bE START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±& _m°ZrQ>a _mn H$mo ñdMm{bV ê$n go AnZr ñ_¥{V _| g§J«hrV H$aVm h¡& `h

5 {_ZQ> Ho$ ~mX ñdMm{bV ê$n go ~§X hmo OmEJm&

_mn Ho$ ~mX, ~¡H$bmBQ

1 {_ZQ> Ho$ ^rVa {H$gr ^r g§MmbZ Ho$

{~Zm ñdMm{bV ê$n go ~§X hmo OmEJr&

_m°ZrQ>a àË`oH$ ~ma _mn nyU© hmo OmZo na Xmo bmoJm| (Cn`moJH$Vm© A Am¡a Cn`moJH$Vm© B) Ho$ {bE ñ_¥{V _|

60 goQ> VH$ Ho$ n[aUm_ H$mo ñdMm{bV ê$n go g§J«hrV H$aVm h¡&

10 {_ZQ> Ho$ ^rVa {nN>br VrZ arqS>J go _mn Ho$ AmYma na EH$ Am¡gV arqS>J H$m

n[aH$bZ ^r H$a gH$Vm h¡& AJa Cg Ad{Y Ho$ {bE ñ_¥{V _| Ho$db Xmo arqS>J h¢, Vmo Am¡gV Xmo arqS>J na AmYm[aV hmoJm& AJa Cg Ad{Y Ho$ {bE ñ_¥{V _| EH$ arqS>J h¡, Vmo Am¡gV EH$ arqS>J na AmYm[aV hmoJm& {Q>ßn{U`m±:

2-3 {_ZQ> VH$ àVrjm H$a|&

arqS>J Ho$ ~rM H$m àVrjm g_` Y_{Z`m| H$mo aº$Mmn H$m _mn boZo go nhbo H$s pñW{V _| bm¡Q>Zo XoVm h¡&

{Q>ßnUr: Amn g§J«hrV arqS>J H$mo Am§{eH$ ê$n go Zht hQ>m gH$Vo h¢&

O~ ñ_¥Vr àVrH$ ( ) àH$Q> hmoVm h¡, Vmo nhbo ñ_¥{V ~Q>Z X~mE±& {\$a Cgo X~mE aIVo hþE, bJ^J 2-3 goH§$S> Ho$ {bE START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z H$mo gmW-gmW X~mE±&

_mno JE n[aUm_m| H$m ñd`§ amoJ {ZXmZ Am¡a BbmO IVaZmH$ h¢& H¥$n`m AnZo S>m°ŠQ>a Ho$ {ZX}em| H$m nmbZ H$a|&

MoVmdZr:

• hmb H$m AZwg§YmZ gwPmVm h¡ {H$ {ZåZ _mZm| H$m Ka na {bE

_hËdnyU©:

ñdMm{bV aº$Mmn _m°ZrQ>a

_m°S>b HEM-7201

{ZX}e _¡Ý`wAb

n[a{Y

T. g§Hw$MZ àVrH$ U. aº$Mmn ñVa g§Ho$VH$ V. ZãO àXe©Z/ñ_¥{V g§»`m W. {hbZo-Sw>bZo go hmoZo dmbr Ìw{Q> H$m àVrH$ X. Cuff-wrapping guide

df©

_hrZm

{XZ

K§Q>m

{_ZQ>

AJa AmnH$m àHw§$MZ X~md 220 mmHg go A{YH$ h¡

H$μ\$ Ho$ \y$bZm àma§^ H$aZo Ho$ ~mX, _m°ZrQ>a Ho$ AmnHo$ Ano{jV àHw§$MZ X~md go

go 40 mmHg A{YH$ \y$bZo VH$ START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z H$mo

X~mE aI|&

{Q>ßn{U`m±:

• _m°ZrQ>a, 299 mmHg go A{YH$ Zht \y$bmEJm&

• Amdí`H$Vm go A{YH$ X~md Z S>mb|&

• AmnHo$ aº$Mmn _m°ZrQ>a _| EH$ A{Z`{_V öX`ñn§XZ gw{dYm em{_b h¡&

A{Z`{_V öX`ñn§XZ _mn Ho$ n[aUm_m| H$mo à^m{dV H$a gH$Vo h¢& A{Z`{_V öX`ñn§XZ EëJmo[aÙ ñdMm{bV ê$n go {ZYm©[aV H$aVm h¡ {H$ Š`m _mn Cn`moJ H$aZo `mo½` h¡ `m Cgo {\$a go boZo H$s Amdí`H$Vm h¡& AJa _mn Ho$ n[aUm_ A{Z`{_V öX`ñn§XZ Ûmam à^m{dV h¢ bo{H$Z n[aUm_ _mÝ` h¡, Vmo n[aUm_ {Z`{_V öX`ñn§XZ àVrH$ ( ) Ho$ gmW {XIm`m OmVm h¡& AJa A{Z`{_V öX`ñn§XZ go _mn A_mÝ` hmo OmVm h¡, Vmo H$moB© n[aUm_ Zht {XIm`m OmVm& AJa AmnHo$ Ûmam _mn boZo Ho$ ~mX A{Z`{_V öX`ñn§XZ àVrH$ ( ) {XImB© XoVm h¡, Vmo {\$a go _mn b|& AJa A{Z`{_V öX`ñn§XZ àVrH$ ( ) ~ma-~ma {XImB© XoVm h¡, Vmo H¥$n`m AnZo S>m°ŠQ>a H$mo BgHo$ ~mao _| ~VmE±&

Am¡gV _mZ XoI|

• AJa {nN>br arqS>J {V{W

{nN>br arqS>J XoI|

EH$ nb Ho$ {bE ñ_¥{V g§»`m àH$Q> hmoVr h¡& g~go ZE goQ> H$mo “1” g§»`m Xr OmVr h¡&

ñ_¥{V _| g§J«hrV arqS>J XoI|

àXe©Z:

START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±&

H$μ\$ ñdMm{bV ê$n go \y$bZm àma§^ H$a XoJm& AmnHo$ Ûmam _m°ZrQ>a H$mo Mmby H$aZo na ~¡H$bmBQ> ñdMm{bV ê$n go Mmby hmo OmEJr&

_m°ZrQ>a H$mo Mmby H$aZo Ho$ {bE START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±&

1. _m°ZrQ>a H$mo Mmby H$aZo Ho$ {bE START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE±&

Am¡gV _mZ {nN>br arqS>J

hmb H$mnwamZm

{Q>ßn{U`m±:

• AmnHo$ Ûmam D$na/ZrMo ~Q>Z ( / ) X~mE OmZo na _mn

hmoVo h¢&

• AJa {V{W Am¡a g_` goQ> Zht h¢, Vmo _mn Ho$ _mZm| Ho$ gmW “-:--”

4. g_ñ`m {ZdmaU Am¡a aIaImd

4.1 {M• Am¡a Ìw{Q> g§Xoe

pãb§H$

àH$m{eV

A{Z`{_V `m H$_μOmoa ZãO Xa H$m nVm bJm`m J`m&

~¡Q>ar H$_ h¢&

~¡Q>ar [aº$ h¢&

H$μ\$ H$_ \y$bm h¡&

_mn boZo Ho$ Xm¡amZ {hbZm-Sw>bZm&

dm`w ßbJ {S>ñH$ZoŠQ> hmo J`m&

299 mmHg go

A{YH$ \y$b J`m Wm&

CnH$aU Ìw{Q>&

Am_© H$μ\$ H$mo {ZH$mb|& 2-3 {_ZQ> àVrjm H$a| Am¡a {\$a EH$ AÝ` _mn b|& AZw^mJ 3.3 _| {XE JE MaUm| H$mo XmohamE±& AJa `h Ìw{Q> àH$Q> hmoVr ahVr h¡, Vmo AnZo S>m°ŠQ>a go g§nH©$ H$a|&

_mn boZo Ho$ Xm¡amZ {hbZm-Sw>bZm&

MaU

3.3 _| {XE JE MaUm| H$mo

2.1 XoI|&

AZw^mJ

3.3 Ho$ A§VJ©V

{\$a go _mn b|& pñWa ah| Am¡a _mn boVo g_` ~mV Z H$a|& AZw^mJ

3.3 XoI|&

3.1 XoI|&

H$μ\$ H$mo ZE H$μ\$ go ~Xb|& AÜ`m`

5 XoI|&

299 mmHg go

A{YH$ Z \w$bmE±& AZw^mJ 3.3 XoI|&

AnZo

OMRON [aQo>b AmCQ>boQ>

H$μ\$ H$mo ghr VarHo$ go Zht bnoQ>m J`m&

3.1 XoI|&

4.2 g_ñ`m {ZdmaU

g_ñ`m H$maU CnMma

• START/STOP (àma§^ H$a|/~§X H$a|) ~Q>Z X~mE± Am¡a {\$a go _mn b|&

arqS>J AË`{YH$ {ZåZ (`m Cƒ) h¡&

_mn Zht bo gH$Vo `m arqS>J ~hþV {ZåZ `m ~hþV Cƒ h¢&

O~ Amn ~Q>Z X~mVo h¢ Vmo Hw$N> Zht hmoVm&

AÝ` g_ñ`mE±&

_mn boZo Ho$ Xm¡amZ {hbZm-Sw>bZm `m ~mV H$aZm&

~¡Q>ar [aº$ h¢&

3.1 XoI|&

pñWa ah| Am¡a _mn boVo g_` ~mV Z H$a|& AZw^mJ

3.3 XoI|&

3.2 XoI|&

3.1 XoI|&

5 XoI|&

3.1 XoI|&

H$μ\$ H$mo \w$bmE± Vm{H$ dh AmnHo$ {nN>bo _mn n[aUm_ go

30 go 40 mmHg

A{YH$ hmo OmE& AZw^mJ

3.3 XoI|&

2.1 XoI|&

~¡Q>ar H$mo ghr

(+/-) Y«wdVm Ho$

gmW bJmE±& AZw^mJ

2.1 XoI|&

4.3 aIaImd

AnZo `y{ZQ> H$mo j{V go ~MmZo Ho$ {bE, H¥$n`m {ZåZ H$m Ü`mZ aI|:

• _w»` `y{ZQ> Am¡a H$μ\$ H$mo AË`{YH$ Vmn_mZ, AmÐVm, Z_r

`m grYr Yyn _| Z aI|&

• H$μ\$ `m Q>çy~ H$mo H$gH$a Z _mo‹S|>&

• `y{ZQ> H$mo AbJ Z H$a|&

• `y{ZQ> H$mo VoμO PQ>Ho$ Am¡a H§$nZ Z X|

• _w»` `y{ZQ> H$mo gmμ\$ H$aZo Ho$ {bE dmînerb Vab nXmWm] H$m Cn`moJ Z H$a|&

`y{ZQ> H$mo Za_, gyIo H$n‹So> go gm\$ {H$`m OmZm Mm{hE&

H¡${b~«oeZ Am¡a godm

Am¡a Bgo b§~o godm H$mb Ho$ {bE {S>μOmBZ {H$`m J`m h¡&

àË`oH$ Xmo dfm] _| {ZarjU H$aZo H$s AZwe§gm H$s OmVr h¡& H¥$n`m AnZo ñWmZr` àm{YH¥$V

dm`w Q>çy~ H$mo dm`w H$ZoŠQ>a go AZßbJ H$a|&

4.4

g§J«hU

O~ Cn`moJ _| Z hmo Vmo `y{ZQ> H$mo CgHo$ g§J«hU Ho$g _| aI X|&

{Q>ßnUr: dm`w Q>çy~ H$mo ~hþV A{YH$ Z _mo‹S|>&

`y{ZQ> H$mo {ZåZ n[apñW{V`m| _| g§J«hrV Z H$a|:

• AJa `y{ZQ> Jrbm hmo&

• AË`{YH$ Vmn_mZ, AmÐVm, grYr Yyn, Yyb `m j`H$mar dmîn dmbo ñWmZ&

• H§$nZ, PQ>H$m| dmbo ñWmZ `m Ohm± dh {H$gr H$moU na hmoJm&

d¡H$pënH$ nwO

d¡H$pënH$

AC AS>mßQ>a H$m Cn`moJ H$aZm

AC AS>mßQ>a ßbJ H$mo

_w»` `y{ZQ> Ho$ nrNo> H$s Amoa

AC AS>mßQ>a O¡H$ _| bJmE±&

AC AS>mßQ>a H$mo BbopŠQ´>H$b

AmCQ>boQ> _| ßbJ H$a|&

^wOm n[a{Y

22-32 go_r

^wOm n[a{Y 32-42 go_r

AC AS>mßQ>a “R”

AS>mßQ>a H$mo {S>ñH$ZoŠQ> H$aZo Ho$ {bE,

nhbo

AC AS>mßQ>a H$mo BbopŠQ´>H$ AmCQ>boQ> go

AZßbJ H$a| Am¡a {\$a

AC AS>mßQ>a H$mo

_w»` `y{ZQ> go {ZH$mb|&

gQ>rH$Vm

\y$bZm g§Hw$MZ ñ_¥{V aoqQ>J nmda òmoV

~¡Q>ar OrdZ

bmJy nyOm©

{dÚwVr` PQ>Ho$ go gwajm

g§MmbZ Vmn_mZ/AmÐVm

g§J«hU Vmn_mZ/AmÐVm/ dm`w X~md T>m±Mo H$m dμOZ H$μ\$ H$m dμOZ ~mhar Am`m_ H$μ\$ Am`m_

H$μ\$ gm_J«r n¡Ho$O gm_J«r

{Q>ßn{U`m±:

• BboŠQ´>m°{ZH$ CËnmXm| Ho$ {ZnQ>mZ Ho$ {bE amï´>r` {d{Z`_m| Ho$ AZwgma

• `h CnH$aU EC {ZX}e 93/42/EEC ({M{H$Ëgr` CnH$aU {ZX}e) Ho$ àmdYmZm| H$mo nyam H$aVm h¡&

• Bg aº$Mmn _m°ZrQ>a H$mo `yamonr` _mZH$ EN1060, J¡a-AmH«$m_H$ pñμ\$½_mo_¡Zmo_rQ>a

^mJ 1: gm_mÝ` Amdí`H$VmAm| Am¡a ^mJ 3: {dÚwV-`m§{ÌH$ aº$Mmn _mnZ àUm{b`m| H$s nyaH$ Amdí`H$VmAm| Ho$ AZwgma {S>μOmBZ {H$`m J`m h¡&

6. VH$ZrH$s So>Q>m

E{e`m n¡{g{μ\$H$ _w»`mb`

CËnmXZ gw{dYm

{H$`m J`m h¡& OMRON aº$Mmn _m°ZrQ>a H$m _w»` KQ>H$, Omo X~md g|ga hmoVm h¡, Ag|~br Ho$ {bE OmnmZ _| CËnm{XV {H$`m OmVm h¡&

{Z{_©V

OMRON OMRON HEALTHCARE Co., Ltd.,

CËnmX,

{H$`m J`m h¡& OMRON aº$Mmn _m°ZrQ>a H$m _w»` KQ>H$, Omo X~md g|ga hmoVm h¡, Ag|~br Ho$ {bE OmnmZ _|

CËnm{XV

{H$`m OmVm h¡&

OMRON HEALTHCARE Co., Ltd.

53, Kunotsubo, Terado-cho, Muko, Kyoto 617-0002 JAPAN

OMRON HEALTHCARE EUROPE B.V.

Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS

OMRON HEALTHCARE SINGAPORE PTE LTD.

438A Alexandra Road, #05-05/08, Alexandra Technopark Singapore 119967 www.omron-healthcare.com.sg

OMRON HEALTHCARE MANUFACTURING VIETNAM CO., LTD.

Binh Duong Province, Vietnam

Omron HEM-7201 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
