INSTRUCTION MANUAL
Automatic Blood Pressure Monitor
with ComFit
Model HEM-711DLX
TM
Cuff
ESPAÑOL
ENGLISH
TABLE OF CONTENTS
Before Using the Unit
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Risk of Electrical Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Before Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Operating Instructions
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Unit Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Display Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Irregular Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Average Value Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Movement Error Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Heartbeat Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Using the AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Applying the Arm Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Special Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Using the Memory Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Care and Maintenance
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Error Indicators and Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . .31
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
2
Before Using the Unit
INTRODUCTION
Thank you for purchasing the Omron®HEM-711DLX IntelliSense
Automatic Blood Pressure Monitor with ComFitTMCuff.
®
Fill in for future reference.
DATE PURCHASED: __________________
SERIAL NUMBER: ____________________
Staple your purchase receipt here
Your new digital blood pressure monitor uses the oscillometric method
of blood pressure measurement. This means the monitor detects your
blood’s movement through your brachial artery and converts the
movements into a digital reading. The monitor stores measurement
results.
The HEM-711DLX comes with the following components:
TM
• Monitor • ComFit
• Storage Case • Warranty Card
• Instruction Manual printed in English and Spanish
The HEM-711DLX IntelliSense®Automatic Blood Pressure Monitor is
intended for home use.
Cuff • AC Adapter
SAVE THESE INSTRUCTIONS
3
SAFETY INFORMATION
To assure the correct use of the product basic safety measures should
always be followed including the warnings and cautions listed in this
instruction manual.
SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL
Indicates a potentially hazardous situation
WARNING
CAUTION
OPERATING THE DEVICE
Contact your physician for specific information about your blood
pressure. Self-diagnosis and treatment using measured results may be
dangerous. Follow the instructions of your physician or licensed
healthcare provider.
If battery fluid should get in your eyes, immediately rinse with
plenty of clean water. Contact a physician immediately.
Read all of the information in the instruction manual and any other
literature in the box before operating the unit.
This device is intended for use in measuring blood pressure and
pulse rate in the adult population. Do not use this device on infants
or persons who cannot express their intentions.
Read the Special Conditions section (page 25) of the instruction
manual if your systolic pressure is known to be more than 220
mmHg. Inflating to a higher pressure than necessary may result in
bruising where the cuff is applied.
which, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury to the user or patient or
damage to the equipment or other property.
4
SAFETY INFORMATION
OPERATING THE DEVICE (continued)
Operate the device only as intended. Do not use the device for any
other purpose.
Dispose of the device, components and optional accessories
according to applicable local regulations. Unlawful disposal may
cause environmental pollution.
Do not use a cellular phone near the device. It may result in an
operational failure.
Use only Omron authorized parts and accessories. Parts and
accessories not approved for use with the device may damage the
unit.
Use only 1.5 V manganese or alkaline batteries with this device. Do
not use other types of batteries. This may damage the unit.
RISK OF ELECTRICALSHOCK
Do not plug or unplug the power cord into the electrical outlet with
wet hands.
Do not overload power outlets. Plug the device into the appropriate
voltage outlet.
5
SAFETY INFORMATION
CARE AND MAINTENANCE
Do not subject the monitor to strong shocks, such as dropping the
unit on the floor.
Do not submerge the device or any of the components in water.
Store the device and the components in a clean, safe location.
Changes or modification not approved by Omron Healthcare will
void the user warranty. Do not disassemble or attempt to repair the
unit or components.
6
BEFORE TAKING A MEASUREMENT
To ensure a reliable reading follow these recommendations:
1. Avoid eating, drinking alcohol, smoking, exercising, and bathing for
30 minutes before taking a measurement. Rest for at least 15 minutes
before taking the measurement.
2. Stress raises blood pressure. Avoid taking measurements during
stressful times.
3. Measurements should be taken in a quiet place.
4. Remove tight-fitting clothing from your arm.
5. Sit in a chair with your feet flat on the floor. Rest your arm on
a table so that the cuff is at the same level as your heart.
6. Remain still and do not talk during the measurement.
7. Keep a record of your blood pressure and pulse readings for your
physician. A single measurement does not provide an accurate
indication of your true blood pressure. You need to take and record
several readings over a period of time. Try to measure your blood
pressure at about the same time each day for consistency.
8. Wait 2-3 minutes between measurements. The wait time allows the
arteries to return to the condition prior to taking the blood pressure
measurement. You may need to increase the wait time depending on
your individual physiological characteristics.
7
Operating Instructions
KNOW YOUR UNIT
Main Unit:
MEMORY Button
Date/Time Setting Button
Components:
Air Tube
Air Plug
(Connects to Air Jack)
Arm Cuff
Display
START/STOP Button
Air Jack
Housing
Cord
AC Adapter
8
Battery Compartment
AC Adapter Jack
Storage Case
INSTRUCTION MANUAL
Automatic Blood Pressure Monitor
TM
with ComFit
Cuff
ModelHEM-711DLX
ESPAÑOL
ENGLISH
Instruction Manual
Systolic Blood Pressure
UNIT DISPLAY
Diastolic Blood Pressure
Memory Symbol
Average Value Symbol
Movement Error Symbol
Low Battery Indicator
Heartbeat Symbol
Pulse Display
Deflation Symbol
Date/Time Display
Irregular Heartbeat Symbol
9
DISPLAY SYMBOLS
IRREGULAR HEARTBEAT SYMBOL ( )
When the monitor detects an irregular rhythm two or more times during
the measurement, the Irregular Heartbeat Symbol ( ) will appear on
the display with the measurement values.
Pulse
Blood
pressure
Pulse
Blood
pressure
Normal Heartbeat
Irregular Heartbeat
Short Long
An irregular heartbeat rhythm is defined as
a rhythm that is more than 25 % slower
or 25 % faster from the average rhythm
detected while the monitor is measuring
the systolic blood pressure and the
diastolic blood pressure.
If the Irregular Heartbeat Symbol ( )
displays with your measurement results,
we recommend you consult your
physician. Follow the directions of your
doctor.
AVERAGE VALUE SYMBOL ( )
The Average Value Symbol is displayed if the measurement values
displayed are an average of up to three measurements taken within 10
minutes of the last reading.
MOVEMENT ERROR SYMBOL ( )
The Movement Error Symbol is displayed if you move your body during
the measurement. Please remove the arm cuff, and wait 2-3 minutes.
Take another measurement.
10
DISPLAY SYMBOLS
The American Heart Association1recommends the following guideline
for upper limit of normal for home blood pressure readings:
AHA Home Guideline for UpperLimit of Normal BP
Systolic Blood Pressure 135 mmHg
Diastolic Blood Pressure 85 mmHg
This is a general guideline because blood pressure depends on age
and morbidity. The AHA recommends a lower home blood pressure
goal for certain patients, including diabetic patients, pregnant women,
and patients with renal failure
The monitor is not intended to be a diagnostic device.
WARNING
Contact your physician for specific information about your blood
pressure. Self-diagnosis and treatment using measured results may
be dangerous. Follow the instructions of your physician or licensed
healthcare provider.
Omron Healthcare recommends you contact your physician if the
HEARTBEAT SYMBOL appears on the display with your measurement
values.
HEARTBEAT SYMBOL ( )
TAKING A MEASUREMENT
The Heartbeat Symbol flashes on the display during
the measurement.The Heartbeat Symbol flashes at every heartbeat.
When the measurement is complete, the Heartbeat Symbol
flashes on the display with your blood pressure and pulse rate if
the reading is above 135 for the Systolic Blood Pressure value
and/or 85 for the Diastolic Blood Pressure value.
1
.
11
DISPLAY SYMBOLS
USING THE MEMORY FUNCTION
The Heartbeat Symbol flashes when the blood pressure reading
stored in the memory is above 135 for the Systolic Blood
Pressure value and/or 85 for the Diastolic Blood Pressure value.
12
BATTERY INSTALLATION
−
＋
−
＋
−
＋
−
＋
1. Press the ▼ indicator on the battery cover
and slide the cover off in the direction of
the arrow.
2. Install 4 “AA” size batteries so the +
(positive) and - (negative) polarities match
the polarities of the battery compartment
as indicated.
3. Replace the battery cover.
Battery Cover
13
BATTERY INSTALLATION
BATTERY REPLACEMENT
Low Battery Indicator
When the Low Battery Indicator appears on the display screen turn the
monitor off and remove all the batteries. Replace with four new batteries
at the same time. Longlife alkaline batteries are recommended.
CAUTION
If battery fluid should get in your eyes, immediately rinse with
plenty of clean water. Contact a physician immediately.
NOTES: • Turn the unit off before replacing the batteries. If the
batteries are removed while the unit is still on, the date and
time will be reset to that of the previous use. However, the
measurement results are not deleted.
• When the batteries are replaced, you may need to reset the
date and time. If the year is flashing on the display screen,
refer to page 16, SETTING THE DATE AND TIME.
CAUTION
Dispose of the device, components and optional accessories
according to applicable local regulations. Unlawful disposal may
cause environmental pollution.
14
USING THE AC ADAPTER
NOTES: • Use only the authorized Omron AC Adapter, Model Number
CAUTION
TO CONNECT THE AC ADAPTER
① Insert the AC Adapter Plug into
the AC Adapter Jack on the back
side of the monitor as illustrated.
② Plug the AC Adapter into a 120V
AC outlet (60 cycles).
TO DISCONNECT THE AC ADAPTER
① Hold and pull the Housing to remove the AC Adapter from the
electrical outlet. Do not remove by pulling on the cord.
② Remove the AC Adapter plug from the monitor.
WARNING
HEM-ADPT1,with this monitor.
• We recommend you install the batteries even if the AC
Adapter is used. If no batteries are installed, you may need
to reset the date and time if the AC Adapter is disconnected.
The measurement results will not be deleted.
Use only Omron authorized parts and accessories. Parts and
accessories not approved for use with the device may damage the
unit.
Housing
1
Do not plug or unplug the power cord into the electrical outlet with
wet hands.
2
Cord
CAUTION
Do not overload power outlets. Plug the device into the appropriate
voltage outlet.
15
SETTING THE DATE AND TIME
Set the monitor to the current date and time before taking a
measurement for the first time. If the date and time are not set correctly,
the measurement values stored in the memory and the average values
may not be correct.
The Blood Pressure Monitor automatically stores up to 60 individual
measurements values with the dates and times.
The monitor can also calculate an average reading based on the three
most recent measurements taken within 10 minutes of the last reading.
NOTES: • If only two readings are stored in the memory for the 10-
minute period, the average is based on the two readings.
• If one reading is stored in the memory for the 10-minute
period, this reading is displayed as the average.
1. TO START THE SETTING
Press the Date/Time Setting button to
adjust the date and time.
The year flashes on the display.
STOP
16
SETTING THE DATE AND TIME
START
2. SETTING THE YEAR
The year can be set between 2006 and
2030. When the display reaches 2030,
it will return to 2006.
Press the MEMORY button to advance
by increments of one year.
Press the Date/Time Setting button to
set the current year.
The month flashes on the display.
NOTE: Press and hold the MEMORY
button to advance the date and time values faster.
3. SETTING THE MONTH
Press the MEMORY button to advance by increments of one month.
Press the Date/Time Setting button to set the current month.
STOP
STOP
The day flashes on the display.
STOP
17
SETTING THE DATE AND TIME
4. SETTING THE DAY
Press the MEMORY button to advance by increments of one day.
Press the Date/Time Setting button to set the current day.
The hour flashes on the display.
5. SETTING THE HOUR
The time is set using AM or PM.
Press the MEMORY button to advance by increments of one hour.
Press the Date/Time Setting button to set the current hour.
The minute flashes on the display.
6. SETTING THE MINUTE
Press the MEMORY button to advance
by increments of one minute.
Press the Date/Time Setting button to set the minute setting.
7. TO TURN THE MONITOR OFF
Press the START/STOP button.
18
STOP
STOP
APPLYING THE ARM CUFF
CAUTION
Read all of the information in the instruction manual and any other
literature in the box before operating the unit.
CAUTION
This device is intended for use in measuring blood pressure and
pulse rate in the adult population. Do not use this device on infants
or persons who cannot express their intentions.
APPLYING THE CUFF ON THE LEFT ARM
1. Make sure the air plug is securely inserted in the main unit.
2. Remove tight-fitting clothing from your upper left arm.
19
APPLYING THE ARM CUFF
3. Sit in a chair with your feet flat on the floor. Place your left arm on a
table so the cuff is level with your heart.
Thumb Grip
4. Hold the grip on the cuff securely with
your right hand, placing your thumb on
the thumb grip.
5. Turn the palm of your left hand
upward.
Cloth Strip
20
APPLYING THE ARM CUFF
6. Apply the cuff to your left upper arm so the blue strip is on the inside
of your arm and aligned with your middle finger. The air tube runs
down the inside of your arm. The bottom of the cuff should be
approximately 1/2" above your elbow.
Blue Strip
1/2 inch (1 - 2 cm)
Air Tube
7. Wrap the cuff firmly in place around your arm using the cloth strip.
21
APPLYING THE ARM CUFF
APPLYING THE CUFF ON THE RIGHT ARM
Apply the cuff to your right upper arm so the thumb grip is centered on
the inside of your inner arm. The bottom of the cuff should be
approximately 1/2'' above your elbow.
Thumb Grip
NOTE: Be careful not to rest your arm on the air tube. This will restrict
the flow of air to the cuff.
22
Loading...
