NordicTrack NTL19007.1 User Manual

Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.healthrider.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Serial No.
Write the serial number in the space above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are commit­ted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE STORE; please contact Customer Care.
IMPORTANT: You must note the product model number and serial number (see the drawing above) before contacting us:
USER'S MANUAL
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST Sat. 8 a.m.–4 p.m. MST
ON THE WEB: www.nordictrackservice.com
CAUTION
Read all precautions and instruc tions in this manual before using this equipment. Save this manual for future reference.
-
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
EFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
B
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE CHEST PULSE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING is attached in the center of this manual.
WARNING DECAL PLACEMENT
The warning decals shown here have been applied in the locations shown. If a decal is missing or il-
legible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decals
may not be shown at actual size.
NordicTrack is a registered trademark of ICON IP, Inc.
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. ICON as­sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
1. Before beginning this or any exercise pro­gram, consult your physician. This is espe­cially important for persons over the age of 35 or persons with pre-existing health problems.
2. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions.
3. Use the treadmill only as described.
4. Place the treadmill on a level surface, with at least 8 ft. (2.4 m) of clearance behind it and 2 ft. (0.6 m) on each side. Do not place the treadmill on any surface that blocks air open­ings. To protect the floor or carpet from dam­age, place a mat under the treadmill.
5. Keep the treadmill indoors, away from mois­ture and dust. Do not put the treadmill in a garage or covered patio, or near water.
6. Do not operate the treadmill where aerosol products are used or where oxygen is being administered.
7. Keep children under the age of 12 and pets away from the treadmill at all times.
8. The treadmill should be used only by persons weighing 350 lbs. (159 kg) or less.
Never allow more than one person on the
9. treadmill at a time.
10. Wear appropriate exercise clothes when using the treadmill. Do not wear loose clothes that could become caught in the treadmill. Athletic support clothes are recommended for both men and women.
Always wear athletic shoes. Never use the treadmill with bare feet, wearing only stockings, or in sandals.
When connecting the power cord (see page 12),
11. plug the power cord into a surge suppressor (not included) and plug the surge suppressor into a grounded circuit capable of carrying 15 or more amps. No other appliance should be on the same circuit. Do not use an extension cord.
12. Use only a single-outlet surge suppressor that meets all of the specifications described on page 12. To purchase a surge suppressor, see your local NordicTrack dealer or call the tele­phone number on the front cover of this man­ual and order part number 146148, or see your local electronics store.
13. Failure to use a properly functioning surge suppressor could result in damage to the con­trol system of the treadmill. If the control sys­tem is damaged, the walking belt may change speed, accelerate, or stop unexpectedly, which may result in a fall and serious injury.
14. Keep the power cord and the surge suppres­sor away from heated surfaces.
15. Never move the walking belt while the power is turned off. Do not operate the treadmill if the power cord or plug is damaged, or if the treadmill is not working properly. (See TROUBLESHOOTING on page 26 if the tread­mill is not working properly.)
16. Read, understand, and test the emergency stop procedure before using the treadmill (see HOW TO TURN ON THE POWER on page 14).
17. Never start the treadmill while you are stand­ing on the walking belt. Always hold the handrails while using the treadmill.
18. The treadmill is capable of high speeds. Adjust the speed in small increments to avoid sudden jumps in speed.
19. The pulse sensors are not medical devices. Various factors, including the user's move ment, may affect the accuracy of heart rate readings. The pulse sensors are intended only as an exercise aid in determining heart rate trends in general.
20. Never leave the treadmill unattended while it is running. Always remove the key, unplug the power cord, and switch the reset/off circuit breaker to the “off” position when the tread mill is not in use. (See the drawing on page 5 for the location of the reset/off circuit breaker.)
-
-
3
21. Do not attempt to raise, lower, or move the readmill until it is properly assembled. (See
t
SSEMBLY on page 6, and HOW TO FOLD
A AND MOVE THE TREADMILL on page 25.) You must be able to safely lift 45 lbs. (20 kg) to raise, lower, or move the treadmill.
22. Do not change the incline of the treadmill by
placing objects under the treadmill.
27. The treadmill is intended for in-home use nly. Do not use the treadmill in any commer-
o cial, rental, or institutional setting.
28. To protect the treadmill and TV during light-
ning storms, unplug the power cord from the
all outlet and disconnect the cable system.
w This will prevent damage due to lightning and power line surges.
23. When folding or moving the treadmill, make sure that the frame is locked in the storage position.
24. Inspect and properly tighten all parts of the treadmill regularly.
25. Never insert or drop any object into any opening on the treadmill.
26. DANGER: Always unplug the power
cord immediately after use, before cleaning the treadmill, and before performing the main­tenance and adjustment procedures de­scribed in this manual. Never remove the motor hood unless instructed to do so by an authorized service representative. Servicing other than the procedures in this manual should be performed by an authorized service representative only.
Power Lines
29. To reduce the risk of electric shock, do not re­move the cover or the back of the television. There are no user serviceable parts inside. Refer servicing to qualified service personnel.
30. Upon completion of any service or repairs to the treadmill or the television, ask the service technician to perform safety checks to con­firm that the unit is in proper operating condi­tion.
Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that pro­vides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Service
Entrance
Conductors
Service
Entrance
Equipment
Power Service Grounding Electrode System (e.g. Interior Metal Water Pipe)
SAVE THESE INSTRUCTIONS
75 Ohm Terminal
Ground Clamps
4
BEFORE YOU BEGIN
Thank you for selecting the revolutionary NordicTrack
LITE 7500 treadmill. The ELITE 7500 treadmill offers
E an impressive selection of features designed to make your workouts at home more enjoyable and effective. And when you’re not exercising, the unique ELITE
500 treadmill can be folded up, requiring less than half
7 the floor space of other treadmills.
For your benefit, read this manual carefully before using the treadmill
Personal Television/Console
Accessory Tray
Handrail
Pulse Sensor
. If you have questions after read-
®
ing this manual, please see the front cover of this man-
al. To help us assist you, note the product model
u number and serial number before contacting us. The model number and the location of the serial number decal are shown on the front cover of this manual.
Before reading further, please look at the drawing below and familiarize yourself with the labeled parts.
Book Holder
Key/Clip
Fan
Walking Belt
Foot Rail
Rear Roller Adjustment Bolts
Reset/Off
Circuit Breaker
Power Cord
Platform Cushion
5
ASSEMBLY
1/2” Silver Screw (48)–1
3/4” Tek Screw (58)–4
S
pacer Screw (60)–2
4 1/2” Bolt (78)–4
Washer (96)–8
Upright Star
Washer (90)–10
Upright Bolt (72)–4
3/4" Screw (4)–4
Handrail Bolt (64)–6
ssembly requires two persons.Set the treadmill in a cleared area and remove all packing materials. Do not
A dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor­mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex key and your own Phillips screwdriver .
For help identifying the assembly hardware, see the drawings below. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the parentheses is the quantity needed for assembly.
part is not in the parts bag, check to see if it has been preassembled. To avoid damaging plastic parts, do not use power tools for assembly.
Note: Some small parts may have been preassembled. If a
1. Make sure that the power cord is unplugged.
With the help of a second person, raise the front of the treadmill and insert the crossbar on the Base (83) into the cutout in the cardboard stand as shown. Serious injury may occur if the
treadmill moves forward or backward and falls off the cardboard stand. A second per­son must hold the treadmill until assembly step 2 is completed to prevent the treadmill from moving, tipping, or falling.
1
83
Cardboard
Stand
6
2. Identify the Left Upright (73) and the Right Upright (74). See the inset drawing. Tie the wire
ie in the Right Upright securely around the end
t of the Upright Wire Harness (75). With the help
f a second person, hold the Right Upright near
o the Right Base Cover (77). Then, pull the other end of the tie up through the rectangular hole in the bottom of the Right Upright until the Upright Wire Harness is routed completely through the Right Upright.
Gently pull up on the Upright Wire Harness (75) as you set the Right Upright (74) on the Base (83) inside the Right Base Cover (77).
ful not to pinch the Upright Wire Harness.
Attach the Right Upright (74) to the Base (83) with two Upright Bolts (72) and two Upright Star Washers (90). Note: It may be necessary to tip the tops of the Uprights forward slightly as you thread the Upright Bolts into the Uprights.
not tighten the Upright Bolts yet.
Hold Left Upright (73) near the Left Base Cover (76). Pull the TV Cable (49) and the AV Wire (97) up through the rectangular hole in the bot­tom of the Left Upright and out of the top of the Left Upright. Set the Left Upright on the Base (83) inside the Left Base Cover. Attach the Left Upright to the Base with two Upright Bolts and two Upright Star Washers (not shown). Do not
tighten the Upright Bolts yet.
Be care-
Do
2
76
97
49
3
7
Tie
75
74
75
Tie
74
77
83
90
72
With the help of a second person, lower the treadmill off the cardboard stand.
3. Identify the Right Upright Sleeve (96) and the Left Upright Sleeve (95); the Upright Sleeves are labeled. Slide the Right Upright Sleeve onto the Right Upright (74) and the Left Upright Sleeve onto the Left Upright (73).
3
73
95
“Left”
“Right”
96
74
7
4. With the help of a second person, hold the con­sole assembly near the Uprights (73, 74).
Remove the tie from the Upright Wire Harness
75).
(
Connect the Upright Wire Harness (75) to the Console Wire Harness (71). See the inset draw-
ing. The connectors should slide together easily and snap into place. If they do not, turn one connector and try again. IF THE CONNEC­TORS ARE NOT CONNECTED PROPERLY, THE CONSOLE MAY BE DAMAGED WHEN THE POWER IS TURNED ON.
4
75
Console
Assembly
73
71
75
Tie
74
71
5. Connect the TV Cable (49) and the AV Wire (97) to the cables extending from the console assembly. Then, insert the connectors down into the Uprights (73, 74).
Next, insert the brackets on the Handrails (99) into the Uprights (73, 74). Make sure that no
wires are pinched.
6. Finger tighten three Handrail Bolts (64) with three Upright Star Washers (90) into the Right Upright (74). Next, finger tighten three Handrail Bolts with three Upright Star Washers (not shown) into the Left Upright (73). Then, firmly tighten the six Handrail Bolts.
5
6
Console
Assembly
99
97
73
73
49
99
74
64
90
90
64
74
8
7. Slide the Right Upright Sleeve (96) up against the console assembly. Attach the Right Upright
leeve with two 3/4" Screws (4).
S
ttach the Left Upright Sleeve (not shown) to
A the Left Upright (73) in the same way.
7
3
7
4
6
9
8. With the help of a second person, raise the front of the treadmill and insert the crossbar on the Base (83) into the cutout in the cardboard stand as shown.
hold the treadmill to prevent it from moving forward or backward.
Firmly tighten the four Upright Bolts (72).
With the help of a second person, lower the treadmill off the cardboard stand.
Have the second person
4
8
83
72
74
72
Cardboard
Stand
9. Note the location of the 75 ohm terminal and the audio/video input jack on the treadmill. For the television to operate, the Audio/Video Wire Harness (115) must be connected to the audio/video input jack on the treadmill, a per­sonal audio/video player must be connected to the audio/video jack on the console, or a CATV cable must be connected to the 75 ohm terminal (see page 10).
10. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex key in a secure place; the hex key is used to adjust the walking belt (see page 27). To protect the floor or car-
pet from damage, place a mat under the treadmill.
9
Audio/
Video
Input
75 Ohm
Terminal
115
9
Before operating the television, you must connect a 75 ohm CATV cable to the 75 ohm terminal on the treadmill, a VCR or DVD player to the audio/video input jacks, or a personal audio/video player to the
udio/video jack below the television on the console. N
a
source such as a cable box, satellite TV box, VCR, or analog cable. No CATV cable is included.
ote: Use a CATV cable to connect to an external
OW TO CONNECT A 75 OHM CATV CABLE
H
1. Connect a 75 ohm
CATV cable to the 75 ohm terminal on the treadmill frame near the power cord.
HOW TO CONNECT AN EXTERNAL SOURCE USING A CATV CABLE
Connect one end of a 75 ohm CATV cable to the 75
1.
ohm output jack on your VCR.
2. Plug in the power cord of your VCR. See your VCR
user’s manual for proper grounding instructions.
3. Connect the 75 ohm CATV cable to the 75 ohm ter-
minal on the treadmill frame near the power cord.
75 Ohm CATV Cable
75 Ohm Terminal
OW TO CONNECT A DVD PLAYER OR VCR
H USING THE AUDIO/VIDEO INPUT JACK
1. Connect the three­pronged end of the in­cluded Audio/Video Wire Harness (115) to your DVD player or VCR.
2. Plug in the power cord of your DVD player or VCR. See your DVD player or VCR user’s manual for proper grounding instructions.
3. Connect the Audio/Video Wire Harness to the audio/video input jack on the treadmill frame near the power cord.
HOW TO CONNECT A PERSONAL AUDIO/VIDEO PLAYER DIRECTLY TO THE CONSOLE
Locate the audio/video jack below the television on the console, and plug it into a jack on your MP3 player, CD player, or personal video player.
115
10
HOW TO USE THE CHEST PULSE SENSOR
OW TO PUT ON THE CHEST PULSE SENSOR
H
he chest pulse sensor consists of two components—
T the chest strap and the sensor unit.
Chest Strap
Tabs
Tab
Sensor Unit
Insert the tab on one end of the chest strap into the hole in one end of the sensor unit, as shown in the inset drawing above. The tab should be flush with the front of the sensor unit.
Next, wrap the chest pulse sensor around your chest and attach the other end of the chest strap to the sensor unit. Adjust the length of the chest strap, if neces­sary. The chest pulse sensor should be under your clothes, tight against your skin, and as high under the pectoral muscles or breasts as is comfortable. Make sure that the logo on the sensor unit is facing forward and is right-side-up.
Pull the sensor unit away from your body a few inches and locate the two electrode areas on the inner side (the electrode areas are covered by shallow ridges). Using saline solution such as saliva or contact lens so­lution, wet both electrode areas. Return the sensor unit to a position against your chest.
Sensor
Unit
Buckle
Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
r other container that may trap moisture.
o
• Do not expose the chest pulse sensor to direct
unlight for extended periods of time; do not expose
s it to temperatures above 122° F (50° C) or below 14° F (-10° C).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest strap may be hand washed and air dried.
CHEST PULSE SENSOR TROUBLESHOOTING
The instructions on the following pages explain how the chest pulse sensor is used with the con­sole. If the chest pulse sensor does not function properly, try the steps below.
• Make sure that you are wearing the chest pulse sen-
sor as described at the left. Note: If the chest pulse sensor does not function when positioned as de­scribed, move it slightly lower or higher on your chest.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the sensor unit. If heart rate readings do not appear until you begin perspiring, rewet the electrode areas.
• As you walk or run on the treadmill, position your-
self near the center of the walking belt. For the
console to display heart rate readings, the user must be within arm’s length of the console.
The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate reading problems may be caused by medical conditions such as premature ventricular contrac­tions (pvcs), tachycardia bursts, and arrhythmia.
CHEST PULSE SENSOR CARE AND MAINTENANCE
• Thoroughly dry the chest pulse sensor after each use. The chest pulse sensor is activated when the electrode areas are wetted and the heart rate monitor is put on; the chest pulse sensor shuts off when it is removed and the electrode areas are dried. If the chest pulse sensor is not dried after each use, it may remain activated longer than nec­essary, draining the battery prematurely.
• The operation of the chest pulse sensor can be affected by magnetic interference caused by high power lines or other sources. If it is suspected that this is a problem, try relocating the treadmill.
1
1
OPERATION AND ADJUSTMENT
ric shock. This product is equipped with a cord having
HE PRE-LUBRICATED WALKING BELT
T
Your treadmill features a walking belt coated with high­performance lubricant. IMPORTANT: Never apply sil-
cone spray or other substances to the walking
i
elt or the walking platform. Such substances will
b deteriorate the walking belt and cause excessive wear.
t an equipment-grounding conductor and a grounding plug.
and plug the surge suppressor into an appropriate
utlet that is properly installed and grounded in
o
ccordance with all local codes and ordinances.
a Important: The treadmill is not compatible with GFCI-equipped outlets.
Plug the power cord into a surge suppressor,
HOW TO PLUG IN THE POWER CORD
DANGER: Improper connection
of the equipment-grounding conductor can result in an increased risk of electric shock. Check with a qualified electrician or service­man if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product—if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
Your treadmill, like any other type of sophisticated electronic equipment, can be seriously damaged by sudden voltage changes in your home’s power. Voltage surges, spikes, and noise interference can result from weather conditions or from other appliances being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge suppressor with your treadmill (see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call the telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.
This product is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the plug illus­trated in drawing 1 below. A temporary adapter that looks like the adapter illustrated in drawing 2 may be used to connect the surge suppressor to a 2-pole receptacle as shown in drawing 2 if a properly grounded outlet is not available.
1
Grounded Outlet Box
Surge Suppressor
Grounding Pin
Grounding Pin
Grounded Outlet
2
Grounded Outlet Box
Adapter
Grounding Plug
Surge Suppressor
Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup­pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps. There must be a moni­toring light on the surge suppressor to indicate whether it is functioning properly. Failure to use a properly functioning surge suppressor could result in damage to the control system of the treadmill. If the control system is damaged, the walking belt may change speed, accelerate, or stop unexpect­edly, which may result in a fall and serious injury.
This product must be grounded. If it should malfunc
tion or break down, grounding provides a path of least resistance for electric current to reduce the risk of elec
Lug
Metal Screw
The temporary adapter should be used only until a properly grounded outlet (drawing 1) can be installed by a qualified electrician.
The green-colored rigid ear, lug, or the like extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used it must be held in place by a metal screw.
covers are not grounded. Contact a qualified elec-
-
trician to determine if the outlet box cover is grounded before using an adapter.
-
Some 2-pole receptacle outlet box
12
TV
Power
CONSOLE DIAGRAM
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of features designed to make your workouts more effec­tive and enjoyable. When the manual mode of the con­sole is selected, the speed and incline of the treadmill can be changed with the touch of a button. As you ex­ercise, the screen will display continuous exercise feedback. You can even measure your heart rate using the handgrip pulse sensor or the chest pulse sensor.
The console also offers four event training workouts. Each workout counts down the distance as you com­plete a 5 kilometer, 10 kilometer, half marathon, or full marathon run.
In addition, the console features twenty-three preset workouts—eight Aerobic Fitness workouts, seven Performance workouts, and eight Weight Loss work­outs. Each workout automatically controls the speed and incline of the treadmill as it guides you through an effective workout. You can even create your own cus­tom workouts and save them for future use.
The console also features the new iFIT Interactive Workout system. The iFIT system enables the console to accept iFIT Interactive Workout Cards containing workouts designed to help you achieve specific fitness goals. For example, lose unwanted pounds with the 8-
week Weight Loss workout, or train for a long-distance run with the Marathon workout. iFIT workouts automati­cally control the treadmill while the voice of a personal trainer coaches you and motivates you through every step of your workout. One iFIT card is included. Additional iFIT cards are available separately.
To pur­chase iFIT cards at any time, see the front cover of this manual or go to www.iFIT.com. iFIT cards are also available at select stores.
The console also offers four heart rate workouts that control the speed and incline of the treadmill to help you keep your heart rate near target heart rate settings.
Whether you select the manual mode or a workout, you can enjoy the shows of your choice on the per­sonal television while you get in shape.
You can also listen to your favorite workout music or audio books with the console’s premium stereo sound system.
To turn on the power, see page 14. To use the man­ual mode, see page 14. To use an event training workout, see page 16. To use a preset workout, see
page 17.
To create and use a custom workout, see
pages 18 and 19. To use an iFIT card, see page 20.
To use a heart rate workout, see page 21. To oper­ate the personal television, see page 22. To use the information mode, see page 23. To use the stereo sound system, see page 24.
13
HOW TO TURN ON THE POWER
T
V
Power
HOW TO USE THE MANUAL MODE
MPORTANT: If the treadmill has been exposed to
I
1.
nsert the key into the console.
I
cold temperatures, allow it to warm to room tem-
erature before turning on the power. If you do not
p
ee HOW TO TURN ON THE POWER to the left.
S
do this, the console displays or other electrical components may become damaged.
Plug in the power cord (see page 12). Next, locate the reset/off circuit breaker on the treadmill frame near the
Reset
Position
power cord. Make sure that the circuit breaker is in the “reset” position.
2.
Select the manual mode.
Each time the key is inserted, the manual mode will be se­lected. If you have selected a workout, press any of the workout buttons (Event Training, Aerobic Fitness, Performance,
IMPORTANT: The console features a display demo mode, designed to be used if the treadmill is dis-
Custom, Heart Rate Control, or Weight Loss) re­peatedly until a track appears on the screen.
played in a store. If the screen lights as soon as you plug in the power cord and switch the reset/off
3.
Start the walking belt and adjust the speed. circuit breaker to the reset position, the demo mode is turned on. To turn off the demo mode, hold down the Stop button for a few seconds. If the screen remains lit, see THE INFORMATION MODE
To start the walking belt, press the Start button, the
Speed increase button, or one of the speed but-
tons numbered 1 to 12.
on page 23 to turn off the demo mode.
If you press the Start button or the Speed increase Next, stand on the foot rails of the treadmill. Locate the clip attached to the key (see the drawing the the right), and slide the clip se-
Clip
curely onto the waistband
Key
of your clothes. Then, insert the key into the console. After a moment, the screen will light. IMPORTANT: In
an emergency situation, the key can be pulled from
button, the walking belt will begin to move at 1
mph. As you exercise, change the speed of the
walking belt as desired by pressing the Speed in-
crease and decrease buttons. Each time you press
a button, the speed setting will change by 0.1 mph;
if you hold down the button, the speed setting will
change in increments of 0.5 mph. If you press one
of the numbered speed buttons, the walking belt
will gradually change speed until it reaches the se-
lected speed setting.
the console, causing the walking belt to slow to a stop. Test the clip by carefully taking a few steps backward; if the key is not pulled from the console, adjust the position of the clip.
To stop the walking belt, press the Stop button. To
restart the walking belt, press the Start button, the
Speed increase button, or one of the numbered
speed buttons.
IMPORTANT: If there is a sheet of clear plastic on the face of
the console, remove the plastic. To pre-
4.
Change the incline of the treadmill as desired. vent damage to the walking platform, wear clean athletic shoes while using the treadmill. The first time the treadmill is used, observe the alignment of
walking belt, and center the walking belt if nec
the
To change the incline of the treadmill, press the
Incline increase and decrease buttons or one of
-
the incline buttons numbered 0 to 12.
essary (see page 27).
Each time you press the Incline increase or de-
ote: The console can display speed and distance in
N either miles or kilometers. To find out which unit of measurement is selected or to change the unit of mea­surement, see THE INFORMATION MODE on page
For simplicity, all instructions in this section refer to
.
23
crease button, the incline will change by 0.5%. If
you press one of the numbered incline buttons, the
incline will gradually change until it reaches the se-
lected incline setting.
miles
14
5. Select a display mode and follow your progress
with the exercise information on the screen.
As you walk or run on the treadmill, the screen can
isplay the following exercise information:
d
• The elapsed time. Note: When a workout is se­lected, the screen will show the time remaining in the workout instead of the elapsed time.
• The distance that you have walked or run.
• The speed of the walking belt.
• The approximate number of calories that you have burned.
• The incline level of the treadmill. Note: The in­cline level of the treadmill will be displayed only when you press the Incline buttons.
Before using the handgrip
ulse sensor,
p remove the
heets of clear
s plastic from the metal con­tacts. In addi­tion, make sure that your hands are clean.
To measure your heart rate,
and hold the metal contacts on the handrail—
rails avoid moving your hands. Hold the contacts for approximately ten seconds. When your pulse is detected, your heart rate will be shown. For the most accurate heart rate reading, continue to hold the contacts for about 15 seconds.
Contacts
stand on the foot
• Your heart rate. Note: Your heart rate will be dis­played only when you use the handgrip pulse sensor or the chest pulse sensor.
• When the manual mode is selected, the screen can show a track that represents 1/4 mile (400 meters). As you walk or run on the treadmill, the indicators around the track will appear in succes­sion until the entire track appears. The track will then disappear and the indicators will again begin to appear in succession.
While the television is off, you can select either of two display modes—a track and some of the exer­cise information, or all of the exercise information. While the television is on, you can select any of three display modes—the information can be dis­played on the right side of the screen, on the bot­tom of the screen, or the information can be turned off while you watch the television. Press the Display button repeatedly to select the desired display mode.
To reset the console, press the Stop button, re­move the key, and then reinsert the key.
7. Turn on the fan if desired.
The fan features low and high speed settings. Press the Fan button repeatedly to select a fan speed or to turn off the fan. Note: If the fan is on when the walking belt is stopped, the fan will turn off automatically after a few minutes.
8. When you are finished exercising, remove the key from the console.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when you fold the treadmill to the storage posi­tion, or you may damage the treadmill. Next, re-
move the key from the console and put it in a secure place.
When you are finished using the treadmill, the reset/off circuit breaker to the “off” position and unplug the power cord. IMPORTANT: If you do
not do this, the treadmill’s electrical compo nents may wear prematurely.
switch
-
6. Measure your heart rate if desired.
Note: If you use the handgrip pulse sensor and the chest pulse sensor at the same time, the console will not display your heart rate accu­rately. See page 11 for more information about the
chest pulse sensor.
15
HOW TO USE AN EVENT TRAINING WORKOUT
. Insert the key into the console.
1
ee HOW TO TURN ON THE POWER on page
S
14.
To stop the workout at any time, press the Stop button. To restart the workout, press the Start but-
on. The walking belt will begin to move at 1 mph.
t Adjust the speed of the walking belt as desired by
ressing the Speed increase or decrease button or
p one of the numbered speed buttons.
2. Select an event training workout.
To select an event training workout, press the Event Training button repeatedly; the name of the workout (5 kilometer, 10 kilometer, Half Marathon, or Full Marathon) and a track will appear on the screen.
3. Press the Start button to start the workout.
A moment after you press the button, the walking belt will begin to move at 4 mph. Hold the handrails and begin walking.
After several minutes, the speed setting will flash on the screen and a series of tones will sound. The speed of the walking belt will then increase to 5 mph.
After another minute, the speed setting will flash on the screen and a series of tones will sound. The speed of the walking belt will then increase to 6.5 mph.
Note: To change the speed of the walking belt or the incline of the treadmill at any time during the workout, press the Speed or Incline buttons.
Note: When you have completed an event, your total time and the words “Cool Down” will appear on the screen. If the speed of the walking belt was greater than 5 mph when you completed the event, the walking belt will then slow to 5 mph for one minute. After one minute, the walking belt will slow to 4 mph for 2 minutes. The walking belt will then slow to 3 mph for 2 minutes. The walking belt will then slow to a stop.
4. Select a display mode and follow your progress with the exercise information on the screen.
See step 5 on page 15.
5. Measure your heart rate if desired.
See step 6 on page 15.
6. Turn on the fan if desired.
See step 7 on page 15.
7. When you are finished exercising, remove the key from the console.
See step 8 on page 15.
During an event training workout, the screen will show the number of miles or kilometers still to be walked or run.
16
HOW TO USE A PRESET WORKOUT
1.
nsert the key into the console.
I
ee HOW TO TURN ON THE POWER on page
S
14.
2.
Select a preset workout.
To select a preset workout, press the Aerobic Fitness button, the Performance button, or the Weight Loss button repeatedly.
When only three seconds remain in the first seg­ment of the workout, a series of tones will sound. If
he speed and/or the incline of the treadmill is
t about to change, the new speed and/or incline set-
ing will appear on the screen to alert you. When
t the first segment ends, the arrow below the work­out profile will move one position to the right. Note: The workout profile can be displayed only when the television is in Console/MP3 mode. To select the Console/MP3 mode, press the TV Power but­ton repeatedly until the word “MP3” appears on the screen.
When a pre­set workout is selected, the screen will show the maximum speed setting, the maximum incline setting, and the duration of the workout. In addition, a profile of the workout in­tensity settings will be displayed. The arrow below the profile will indicate your progress during your workout.
Note: When a weight loss workout is selected, the screen will also show the calorie goal for the work-
Important: The calorie goal is an estimate
out.
of the number of calories that you will burn during the workout. The actual number of calo­ries that you burn will depend on your weight. In addition, if you manually change the speed or incline of treadmill during the workout, the number of calories you burn will be affected.
3. Enter your weight.
When the first segment ends, the treadmill will au­tomatically adjust to the speed and incline settings for the second segment.
The workout will continue in this way until the arrow reaches the right end of the workout profile. The walking belt will then slow to a stop.
If the speed and/or incline settings of the workout are too high or too low, you can override the set­ting by pressing the Speed or Incline buttons;
ever, when the next segment begins, the tread­mill will automatically adjust to the speed and incline settings for the next segment.
To stop the workout at any time, press the Stop button. To restart the workout, press the Start but­ton. The walking belt will begin to move at 1 mph. When the next segment of the workout begins, the treadmill will automatically adjust to the speed and incline settings for the next segment.
5. Select a display mode and follow your progress with the exercise information on the screen.
how-
For the most accurate calorie count, enter your weight by p crease buttons repeatedly. Note: Once you have entered your weight, it will be saved in memory.
Press the Start button to start
4.
A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings of the workout. Hold the handrails and begin walking.
Each workout is divided into several one-minute segments. One speed setting and one incline set­ting are programmed for each segment. Note: The same speed and/or incline setting may be pro grammed for consecutive segments.
ressing the Rate/Wt. increase and de
the workout.
See step 5 on page 15.
-
6. Measure your heart rate if desired.
See step 6 on page 15.
7. Turn on the fan if desired.
See step 7 on page 15.
8. When you are finished exercising, remove the key from the console.
See step 8 on page 15.
-
17
HOW TO CREATE A CUSTOM WORKOUT
. Insert the key into the console.
1
setting for the first segment, simply adjust the speed and incline of the treadmill as desired by
ressing the Speed and Incline buttons.
p
ee HOW TO TURN ON THE POWER on page
S
14.
2. Select one of the four custom workouts.
To select a custom workout, press the Custom but­ton repeatedly. When a custom workout is se­lected, the name of the workout (CUSTOM: 1, CUSTOM: 2, CUSTOM: 3, or CUSTOM: 4) will ap­pear on the screen.
Note: If the custom workout has not yet been designed, a workout time of three minutes will appear on the screen and the profile will have only three segments (see the drawing above). If the workout time is more than three minutes, see HOW TO USE A CUS­TOM WORKOUT on page 19.
3. Press the Start button and program the desired speed and incline settings.
A moment after you press the Start button, the walking belt will begin to move. Hold the handrails and begin walking.
Each custom workout is divided into several one­minute segments. One speed setting and one in­cline setting can be programmed for each seg­ment. To program a speed setting and an incline
hen the first segment of the workout ends, a se-
W ries of tones will sound and the current speed set­ting and the current incline setting will be saved in memory. Program a speed setting and an incline setting for the second segment as described above.
Continue programming speed and incline settings for as many segments as desired; custom work­outs can have up to forty segments. When you are finished with your workout, press the Stop button and then the Speed decrease button. The speed and incline settings that you have programmed and the workout time will then be saved in memory.
4. Select a display mode and follow your progress with the exercise information on the screen.
See step 5 on page 15.
5. Measure your heart rate if desired.
See step 6 on page 15.
6. Turn on the fan if desired.
See step 7 on page 15.
7. When you are finished exercising, remove the key from the console.
See step 8 on page 15.
18
HOW TO USE A CUSTOM WORKOUT
. Insert the key into the console.
1
ee HOW TO TURN ON THE POWER on page
S
14.
2. Select one of the four custom workouts.
To select a custom workout, press the Custom but­ton repeatedly. When a custom workout is se­lected, the name of the workout (CUSTOM: 1, CUSTOM: 2, CUSTOM: 3, or CUSTOM: 4) will ap­pear on the screen.
In addition, the maximum speed and incline set­tings of the workout, the workout time, and a profile of the intensity settings of the workout will appear.
Note: If the workout time is only three minutes, see HOW TO CREATE A CUSTOM WORKOUT on page 18.
3. Press the Start button to start the workout.
A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings that you programmed previ­ously. Hold the handrails and begin walking.
Each custom workout is divided into several one­minute segments. One speed setting and one in­cline setting are programmed for each segment. Note: The same speed setting and/or incline set­ting may be programmed for consecutive seg­ments.
If desired, you can redesign the workout while using it.
line setting for the current segment, s
c
press the Speed or Incline buttons. When the current
egment ends, the new setting will be saved in mem-
s ory. wait until the workout is completed. Then, press the Start button and program speed and incline settings for as many additional segments as desired. When you have added as many segments as desired, press the Stop button and then the Speed de­crease button.
out,
crease button at any time before the workout is com­pleted.
To stop the workout temporarily, press the Stop button. To restart the workout, press the Start but­ton. The walking belt will begin to move at 1 mph. When the next segment of the workout begins, the treadmill will automatically adjust to the speed and incline settings programmed for the next segment.
4.
Select a display mode and follow your progress with the exercise information on the screen.
See step 5 on page 15.
5. Measure your heart rate if desired.
See step 6 on page 15.
6. Turn on the fan if desired.
See step 7 on page 15.
To change the speed setting or the in-
To increase the length of the workout, first
To decrease the length of the work-
press the Stop button and then the Speed de-
imply
The custom workout will function in the same way as a preset workout (see step 4 on page 17).
7. When you are finished exercising, remove the key from the console.
See step 8 on page 15.
19
HOW TO USE AN IFIT CARD
1.
nsert the key into the console.
I
ee HOW TO TURN ON THE POWER on page
S
14.
2.
Insert an iFIT card and select a workout.
To use an iFIT workout, insert an iFIT card into the iFIT slot; make sure that the iFIT card is oriented so the metal contacts are face-down and are in­serted into the iFIT slot.
iFIT Slot
iFIT
Card
Next, select an iFIT workout by pressing the iFIT up and down buttons next to the iFIT slot. When an iFIT workout is selected, the display will show the name of the workout, duration, the maximum in­cline setting, and the maximum speed setting of the workout. In addition, a profile of the speed set­tings of the workout will appear in the display.
During the workout, a personal trainer will guide you through the workout. You can select an audio setting
or your personal trainer (see THE INFORMATION
f MODE on page 23).
If the speed or incline setting for the current seg­ment is too high or too low, you can manually over­ride the setting by pressing the Speed or Incline buttons; however, when the next segment be-
gins, the treadmill will automatically adjust to the speed and incline settings for the next seg­ment.
To stop the workout at any time, press the Stop button. To restart the workout, press the Start but­ton or the Speed increase button. The walking belt will begin to move at 1 mph. When the next seg­ment of the workout begins, the treadmill will auto­matically adjust to the speed and incline settings for the next segment.
4.
Select a display mode and follow your progress with the exercise information on the screen.
See step 5 on page 15.
5. Turn on the fan if desired.
See step 7 on page 15.
6. When you are finished exercising, remove the key from the console.
Each iFIT workout is divided into several one­minute segments. One speed setting and one in­cline setting are programmed for each segment. Note: The same speed and/or incline setting may be programmed for consecutive segments.
3.
Press the Start button to start
A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings of the workout. handrails and begin walking.
the workout.
Hold the
See step 8 on page 15.
CAUTION: Always remove iFIT cards from the iFIT slot when you are not using them.
20
HOW TO USE A HEART RATE WORKOUT
CAUTION: If you have heart prob-
ems, or if you are over 60 years of age and
l have been inactive, do not use the heart rate workouts. If you are taking medication regu­larly, consult your physician to find whether the medication will affect your exercise heart rate.
Follow the steps below to use a heart rate workout.
1.
Put on the chest pulse sensor.
Note: For best results, wear the chest pulse sensor to use a heart rate workout. See page 11 for infor­mation about the chest pulse sensor.
2. Insert the key into the console.
See HOW TO TURN ON THE POWER on page
14.
3. Select one of the four heart rate workouts.
To select a heart rate workout, press the Heart Rate Control button repeatedly. When a heart rate workout is selected, the name of the workout (HEART RATE: 1, HEART RATE: 2, HEART RATE: 3, or HEART RATE: 4) will appear on the screen.
If heart rate workout 1 is selected, a track will appear on the screen.
If heart rate workout 2, 3, or 4 is selected, a pro­file of the heart rate settings of the workout will ap­pear on the screen. The arrow below the profile will indicate your progress during the workout.
Enter a target heart rate setting.
4.
If heart rate workout 1 is selected, the target
heart rate setting for the entire workout will appear on the screen beside the words “Target BPM” (beats per minute). If desired, press the Rate/Wt. increase and decrease buttons to change the tar­get heart rate setting (see EXERCISE
on page 29).
INTENSITY
BPM.” If desired, press the Rate/Wt. increase and decrease buttons to change the maximum target
eart rate setting (see EXERCISE INTENSITY on
h page 29). Note: If you change the maximum target
eart rate setting, the intensity level of the entire
h workout will change.
5. Press the Start button to start the workout.
A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings of the workout. Hold the handrails and begin walking.
Heart rate workout 1 is divided into several one­minute segments. The same target heart rate set­ting is programmed for all segments (except for the first two segments). Heart rate workouts 2, 3, and 4 are divided into 30 one-minute segments. One tar­get heart rate setting is programmed for each seg­ment. Note: The same target heart rate setting may be programmed for consecutive segments.
During each segment of the workout, the console will compare your heart rate to the target heart rate setting for that segment. If your heart rate is too far below or above the target heart rate setting, the speed and/or incline will automatically increase or decrease to bring your heart rate closer to the tar­get heart rate setting. Each time the speed and/or incline of the treadmill is about to change, the speed and/or incline setting will flash on the screen to alert you, regardless of which display mode is selected.
If heart rate workout 2, 3, or 4 is selected, a se­ries of tones will sound when the first segment of the workout ends. The arrow below the workout profile will then move one position to the right. The workout will continue in this way until the arrow reaches the right end of the workout profile. The walking belt will then slow to a stop.
If the speed and/or incline settings are too high or too low, you can change the intensity level of the workout at any time by pressing the Speed and Incline buttons;
pares your heart rate to the target heart rate for the current segment, the speed and/or incline of the treadmill may change to bring your heart rate closer to the target heart rate setting.
however, when the console com
-
If heart rate workout 2, 3, or 4 is selected, the
maximum target heart rate setting of the workout will appear on the screen beside the words “Target
21
To stop the workout at any time, press the Stop button. To restart the workout, press the Start but-
on. The walking belt will begin to move at 1 mph;
t
however, when the console compares your
eart rate to the target heart rate setting for the
h current segment, the speed and/or incline of the treadmill may change to bring your heart rate closer to the target heart rate setting.
6.
Select a display mode and follow your progress with the exercise information on the screen.
See step 5 on page 15.
7. Turn on the fan if desired.
See step 7 on page 15.
8.
When you are finished exercising, remove the key from the console.
See step 8 on page 15.
HOW TO OPERATE THE PERSONAL TELEVISION
IMPORTANT: Before operating the television, you must connect a 75 ohm CATV cable to the 75 ohm terminal on the treadmill, a VCR or DVD player to the audio/video input jack, or a personal audio/video player to the audio/video jack below the television on the console. See page 10 for in­structions.
Follow the steps below to operate the television.
If you have connected a 75 ohm CATV cable to the 75 ohm terminal on the treadmill, select the Tuner
ource. If you have plugged a DVD player or VCR
s into the audio/video input jack, select the RCA
ource. If you have connected a personal
s audio/video player to the audio/video jack below the television on the console, select the MP4 source. If you do not wish to use the television, se­lect the Console/MP3 mode.
3. Press the Channel buttons to select the desired cable channel.
Note: Complete this step only if you are using ana­log cable. Otherwise, change channels through an external source such as your cable box or your VCR.
When you turn on the television, the screen will show the last cable channel that was selected. To select a different channel, press the Channel (Chan) buttons. The selected cable channel num­ber will appear on the screen for a few seconds. Note: The television is equipped with a channel memorizing function that allows you to go directly from the current channel to the next channel saved in memory. Before channels can be selected in this way, they must be saved in the television’s mem­ory. See THE INFORMATION MODE on page 23.
4. Press the Volume buttons to adjust the volume.
Press the Volume (VOL.) increase or decrease button to change the volume. When either button is pressed, the volume level indicator will appear on the screen for a few seconds.
1. Insert the key into the console.
See HOW TO TURN ON THE POWER on page
14.
Press the TV Power button to select a televi-
2. sion source or the Console/MP3 mode.
Select a television source or the Console/MP3 mode by pressing the TV Power button repeatedly.
To use earphones or headphones (not included), plug them into the headphone jack beside the key on the console.
22
THE INFORMATION MODE
he console features an information mode that allows
T you to view treadmill usage information, select a sys-
em of measurement for the console, and turn on and
t turn off the demo mode. The information mode also al­lows you to adjust the settings of the television and to save channels into the television’s memory.
Follow the steps below to use the information mode.
Next, press the Channel (CHAN.) buttons until the contrast, color, sharpness, or hue level indicator ap-
ears. Adjust the settings, if desired, by pressing the
p Volume buttons.
3. Press the TV button again and add or delete channels.
Note: Complete this step only if you are using ana­log cable.
1. Press the Stop button while inserting the key into the console.
When the information mode is selected, the lower part of the screen will show the total number of miles or kilometers that the walking belt has moved (Distance) and the total number of hours that the treadmill has been used (Time).
In addition, the center of the display will show the word “English” for English miles or the word “Metric” for metric kilometers. Press the Speed increase button to change the unit of measurement if de­sired.
Note: The console features a display demo mode, designed to be used if the treadmill is displayed in a store. While the demo mode is turned on, the console will function normally when you plug in the power cord, switch the reset/off circuit breaker to the reset position, and insert the key into the con­sole. However, when you remove the key, the dis­plays will remain lit, although the buttons will not function. If the demo mode is turned on, the words “DEMO ON” will appear on the screen while the in­formation mode is selected. To turn on or turn off the demo mode, press the Speed decrease button until the words “DEMO OFF” appear on the screen.
While the information mode is selected, you can select an audio setting for the iFIT personal trainer, if desired. If you select the All setting, the personal trainer will give you detailed instructions to help you through your workout. If you select the On set­ting, the personal trainer will simply guide you through the workout. If you select the Off setting, the personal trainer will be silent. To select a per­sonal trainer audio setting, press the incline in­crease or decrease button.
2. Press the TV Power button and adjust the brightness, contrast, color, sharpness, and/or hue of the television.
After all valid cable channels available in your area have been saved into the television’s memory (see step 5 on this page), you can manually add chan­nels or delete unwanted channels.
To add or delete a cable channel, first press the Channel buttons until the desired channel number appears on the screen. Then, press the Volume in­crease button to add the channel, or the Volume decrease button to delete the channel. Continue this process until you have added all desired chan­nels and deleted all unwanted channels.
4. Press the TV Power button again and select a cable connection if necessary.
If you have connected a CATV cable, one of the three Cable settings should be selected; try all three Cable settings, if necessary, to find the opti­mal setting. Press the Volume increase button to select the Standard Cable setting, the Channel de­crease button to select the Cable IRC setting, or the Channel increase button to select the Cable HRC setting.
5. Press the TV button again and save cable chan­nels into the television’s memory.
When you press the TV button, the television will begin scanning all of the cable channels available in your area. When no cable signal is detected on a channel, the channel will be skipped. When a cable signal is detected, the channel will be saved into memory and the next channel will be selected. This process will continue until the highest channel is reached. television is scanning channels. Note: If you are viewing channels through an external source such as a cable box or a VCR, the television will save only the channel used by the external source.
6. When you are finished using the information mode, remove the key from the console.
Do not remove the key while the
When you press the TV Power button, the brightness level indicator will appear on the television screen Press the Volume (VOL.) buttons to adjust the brightness setting if desired.
.
To exit the information mode at any time (except while saving channels), remove the key from the console.
23
HOW TO USE THE STEREO SOUND SYSTEM
HOW TO ADJUST THE CUSHIONING SYSTEM
o play music or audio books through the console’s
T stereo speakers, you must connect your MP3 player,
D player, or other personal audio/video player to the
C console. Locate the audio/video cable below the televi­sion on the console, and plug it into a jack on your MP3 player, CD player, or other personal audio/video player.
plugged in.
Next, select the MP4 source on the console by press­ing the TV Power button repeatedly until “MP4” ap­pears on the screen.
Then, press the Play button on your MP3 player, CD player, or other personal audio/video player. Adjust the volume on your personal audio/video player. You can also adjust the volume on the console by pressing the Volume (VOL.) increase and decrease buttons.
If you are using a personal CD player or DVD player and the CD or DVD skips, set the CD player or DVD player on the floor or another flat surface instead of on the console.
Make sure that the audio/video cable is fully
he treadmill features a cushioning system that re-
T duces the impact as you walk or run on the treadmill.
o increase the firmness of the walking platform, step
T off the treadmill and slide the platform cushions toward the front of the treadmill. To decrease the firmness, step off the treadmill and slide the platform cushions toward the back of the treadmill.
both cushions are set at the same firmness level. The faster you run on the treadmill, or the more you weigh, the firmer the walking platform should be.
Platform Cushion
Increase
Decrease
Note: Make sure that
Platform Cushion
Walking Platform
24
HOW TO FOLD AND MOVE THE TREADMILL
HOW TO FOLD THE TREADMILL FOR STORAGE
efore folding the treadmill, adjust the incline to the
B lowest position. If you do not do this, you may damage the treadmill when you fold it. Remove the key and unplug the power cord. CAUTION: You must be able to safely lift 45 lbs. (20 kg) to raise, lower, or move the treadmill.
1. Hold the metal frame firmly in the location shown by the arrow at the right. CAUTION: To decrease the pos­sibility of injury, do not lift the frame by the plastic foot rails. To raise the frame, bend your legs, keep your back straight, and lift with your legs.
about halfway to the vertical position.
2. Raise the frame until the latch knob locks into the storage
position.
the storage position.
To protect the floor or carpet from damage, place a mat under the treadmill. Keep the treadmill out of di­rect sunlight. Do not leave the treadmill in the stor­age position in temperatures above 85° F (30° C).
Make sure that the latch knob is locked in
Raise the frame
Frame
Frame
HOW TO MOVE THE TREADMILL
Before moving the treadmill, convert the treadmill to the stor­age position as described above. Make sure that the latch
knob is locked in the storage position.
1. Hold the handrails and place one foot against one of the wheels.
2. Tilt the treadmill back until it rolls freely on the wheels. Carefully move the treadmill to the desired location. Never
move the treadmill without tipping it back. To reduce the risk of injury, use extreme caution while moving the treadmill. Do not attempt to move the treadmill over an uneven surface.
3. Place one foot against one of the wheels, and carefully lower the treadmill until it is resting in the storage position.
HOW TO LOWER THE TREADMILL FOR USE
Latch Knob
Handrails
Wheel
1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. Pivot the
frame downward and release the latch knob. Note: To release the latch knob, it may be necessary to push the frame forward as you pull the latch knob to the left.
2. Hold the metal frame firmly with both hands, and lower it to the floor. CAUTION: To decrease the possi-
bility of injury, do not lower the frame by gripping only the plastic foot rails. Do not drop the frame to the floor. Make sure to bend your legs and keep your back straight.
25
TROUBLESHOOTING
Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual.
PROBLEM: The power does not turn on
SOLUTION: a. Make sure that the power cord is plugged into a surge suppressor, and that the surge suppressor
is plugged into a properly grounded outlet (see page 12). Use only a single-outlet surge suppres­sor that meets all of the specifications described on page 12. IMPORTANT: The treadmill is not
compatible with GFCI-equipped outlets.
b. After the power cord has been plugged in, make sure that the key is inserted into the console.
c. Check the reset/off circuit breaker located on the
treadmill frame near the power cord. If the switch pro­trudes as shown, the circuit breaker has tripped. To reset the circuit breaker, wait for five minutes and then press the switch to the reset position.
PROBLEM: The power turns off during use
SOLUTION: a. Check the reset/off circuit breaker (see the drawing above). If the circuit breaker has tripped, wait
for five minutes and then press the switch to the reset position.
b. Make sure that the power cord is plugged in. If the power cord is plugged in, unplug it, wait for five
minutes, and then plug it back in.
c. Remove the key from the console. Reinsert the key into the console.
d. If the treadmill still will not run, please see the front cover of this manual.
PROBLEM: The displays of the console do not function properly
SOLUTION:
a. Remove the key from the console and UNPLUG THE
POWER CORD. Place the treadmill in the storage po-
sition (see HOW TO FOLD AND MOVE THE TREAD­MILL on page 25).
c
Tripped
a
4
Reset
Next, remove the two indicated 3/4" Screws (4).
Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR indicated 3/4" Screws (4), and remove the Hood (44).
USE on page 25). Remove the four
26
44
4
4
4
Next, locate the Reed Switch (20) and the Magnet (12) on the left side of the Pulley (11). Turn the Pulley
ntil the Magnet is aligned with the Reed Switch.
u
Make sure that the gap between the Magnet and
he Reed Switch is about 1/8 in. (3 mm).If neces-
t
sary, loosen the indicated 3/4" Tek Screw (29), move the Reed Switch slightly, and then retighten the Tek Screw. Reattach the Hood (not shown) with the six 3/4" Screws (not shown). Run the treadmill for a few minutes to check for a correct speed reading.
PROBLEM: The walking belt slows when walked on
op
T
View
20
9
2
1/8 in.
1
1
12
SOLUTION:
PROBLEM: The walking belt is off-center or slips when walked on
SOLUTION: a. If the walking belt is off-center, remove the key and
a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 12.
b. If the walking belt is overtightened, treadmill perfor-
mance may decrease and the walking belt may be­come damaged. Remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both rear roller bolts counterclockwise, 1/4 of a turn. When the walking belt is properly tightened, you should be able to lift each edge of the walking belt 3 to 4 in. (7 to 10 cm) off the walking platform. Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and run the treadmill for a few min­utes. Repeat until the walking belt is properly tight­ened.
c. If the walking belt still slows when walked on, please see the front cover of this manual.
UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left rear roller bolt clockwise 1/2 of a turn; if the walk­ing belt has shifted to the right, turn the left rear
roller bolt counterclockwise 1/2 of a turn. Be careful not to overtighten the walking belt. Plug in the power cord, insert the key, and run the treadmill for a few minutes. Repeat until the walking belt is centered.
b
3–4 in.
Rear Roller Bolts
a
If the walking belt slips when walked on, first remove
b.
the key and UNPLUG THE POWER CORD. Using the hex key, turn both rear roller bolts clockwise, 1/4 of a turn. When the walking belt is correctly tightened, you should be able to lift each edge of the walking belt 3 to 4 in. (7 to 10 cm) off the walking platform. Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and carefully walk on the treadmill for a few minutes. Repeat until the walking belt is properly tightened.
27
b
PROBLEM: The incline of the treadmill does not change correctly
OLUTION: a
S
PROBLEM: The console displays remain lit when you remove the key from the console
SOLUTION: a. The console features a display demo mode, designed to be used if the treadmill is displayed in a
PROBLEM: Television reception is poor
SOLUTION: a. Check for the problems listed below and follow the applicable instructions.
. With the key in the console, press one of the Incline buttons. While the incline is changing, re-
move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the
aximum incline level and then return to the minimum level. This will recalibrate the incline system.
m
store. If the displays remain lit when you remove the key, the demo mode is turned on. To turn off the demo mode, hold down the Stop button for a few seconds. If the displays are still lit, see THE INFORMATION MODE on page 23 to turn off the demo mode.
• Ignition (black spots or horizontal streaks that appear or a picture that flutters or drifts)—Usually this is caused by interference from automobile ignition systems, neon lamps, electric drifts, or other electric appliances. Try changing the position of other electric appliances to correct the problem. Make sure that the treadmill is plugged into its own electrical circuit.
• Ghosts—Ghosts are caused by the television signal following two paths—one is the direct path and the other is reflected from tall buildings, hills, or other objects.
• Blue Screen—If the cable channel signal is weak, the picture may be of poor quality or a blue screen may appear.
Note: If one of these symptoms appears, the symptom may be caused by the local cable com­pany signal reception. Contact the local cable company.
PROBLEM: The chest pulse sensor does not function properly
SOLUTION:
a. If the chest pulse sensor does not function properly, see CHEST PULSE SENSOR TROU-
BLESHOOTING on page 11.
28
EXERCISE GUIDELINES
WARNING: Before beginning any
exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems.
The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. The pulse sensor is in­tended only as an exercise aid in determining heart rate trends in general.
These guidelines will help you to plan your exercise program. For detailed exercise information, obtain a reputable book or consult your physician. Remember, proper nutrition and adequate rest are essential for successful results.
Burning Fat—To burn fat effectively, you must exer­cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your body uses the first few minutes of exercise does your body begin
o use stored
t burn fat, adjust the intensity of your exercise until your heart rate is near the lowest number in your training zone. For maximum fat burning, exercise with your heart rate near the middle number in your training zone.
Aerobic Exercise—If your goal is to strengthen your cardiovascular system, you must perform aerobic exer­cise, which is activity that requires large amounts of oxygen for prolonged periods of time. For aerobic ex­ercise, adjust the intensity of your exercise until your heart rate is near the highest number in your training zone.
carbohydrate calories
at calories
f
or energy. If your goal is to
f
for energy. Only after
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your cardiovascular system, exercising at the proper inten­sity is the key to achieving results. You can use your heart rate as a guide to find the proper intensity level. The chart below shows recommended heart rates for fat burning and aerobic exercise.
To find the proper intensity level, find your age at the bottom of the chart (ages are rounded off to the near­est ten years). The three numbers listed above your age define your “training zone.” The lowest number is the heart rate for fat burning, the middle number is the heart rate for maximum fat burning, and the highest number is the heart rate for aerobic exercise.
WORKOUT GUIDELINES
Warming up—Start with 5 to 10 minutes of stretching
and light exercise. A warm-up increases your body temperature, heart rate, and circulation in preparation for exercise.
Training Zone Exercise—Exercise for 20 to 30 min­utes with your heart rate in your training zone. (During the first few weeks of your exercise program, do not keep your heart rate in your training zone for longer than 20 minutes.) Breathe regularly and deeply as you exercise–never hold your breath.
Cooling down— ing. Stretching increases the flexibility of your muscles and helps to prevent post-exercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three workouts each week, with at least one day of rest be­tween workouts. After a few months of regular exer­cise, you may complete up to five workouts each week, if desired. Remember, the key to success is to make exercise a regular and enjoyable part of your everyday life.
Finish with 5 to 10 minutes of stretch-
29
PART LIST—Model No. NTL19007.1 R
To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual.
Key No. Qty. Description Key No. Qty. Description
1207A
1 2 Foot Rail Cover 2 2 Foot Rail 3 16 Isolator Screw 4 58 3/4" Screw 5 4 Fan Screw 6 1 Walking Platform 7 2 Belt Guide 8 4 Belt Guide Screw
9 2 Front Isolator 10 2 Platform Bolt, Front 11 1 Front Roller/Pulley 12 1 Magnet 13 17 1/2" Screw 14 1 Reed Switch Clip 15 2 Incline Rod Bushing 16 2 Lift Arm 17 2 Lift Pivot Bolt 18 2 Hood Mount 19 2 Lift Arm Spacer 20 1 Reed Switch 21 2 Cushion Track 22 1 Power Cord Grommet 23 4 Console Clamp Screw 24 1 Lift Motor Bolt, Bottom 25 1 4" Wire Harness 26 4 Base Pad Spacer 27 1 Reset/Off Circuit Breaker 28 1 Motor Belt 29 9 3/4" Tek Screw 30 2 Lift Pivot Bolt 31 1 Drive Motor 32 2 Motor Bolt 33 4 Electronic Bracket Nut 34 1 Electronic Bracket 35 1 Front Endcap 36 37 1 Incline Rod 38 10 Nut 39 1 40 1 Lift Motor Bolt, Top 41 42 43 1 Power Cord Bracket 44 1 45 4 46 2 Grommet 47 1 Walking Belt 48 49
1 Controller
Lift Motor
1 2
1 1
AV Cover Platform Cushion
Hood Hood Clip
Frame
Cable
TV
50 1 Chest Pulse Sensor 51 1 Right Rear Foot 52 4 Rear Wheel 53 2 Rear Wheel Bolt 54 1 Right Rear Endcap 55 4 Bracket Washer 56 2 Rear Roller Adjustment Bolt 57 1 Hex Key 58 1 Left Rear Foot 59 1 Left Rear Endcap 60 1 Rear Roller 61 2 Platform Nut 62 2 Platform Bolt, Rear 63 1 Console Fan 64 6 Handrail Bolt 65 1 Console Base 66 1 Console 67 1 TV Console 68 2 Motor Bushing 69 6 Electronics Screw 70 1 Pulse Receiver Cover 71 1 Console Wire Harness 72 4 Upright Bolt 73 1 Left Upright 74 1 Right Upright 75 1 Upright Wire Harness 76 1 Left Base Cover 77 1 Right Base Cover 78 8 Console Screw 79 1 Hood Cowling 80 4 Console Crossbar Star Washer 81 4 Base Pad 82 4 1" Tek Screw 83 1 Base 84 1 Motor Plate 85 86 2 Wheel 87 3 Caution Decal 88 1 89 1 Key/Clip 90 91 92 2 Tie Clamp 93 8 94 2 95 1 Left Upright Sleeve 96 1 Right Upright Sleeve 97 98
2 Wheel Bolt
Power Cord
10
4
1 1
Upright Star Washer Releasable Tie
Plastic Tie Handrail Cover
AV Wire Ground Nut
30
Key No. Qty. Description Key No. Qty. Description
99 1 Handrail
100 1 Latch Assembly 101 1 Latch Warning Decal 102 1 AV Wire Nut 103 1 iFIT Card Kit
04 1 Chest Pulse Strap
1 105 2 Rear Roller Washer 106 1 Incline/Controller Wire 107 1 Incline Stop Bracket 108 1 Stop Bracket Spacer 109 1 Static Decal 110 1 Console Plate 111 2 TV Cable Nut 112 1 TV Cable Star Washer 113 1 Lower Latch Bolt 114 4 Handrail Cover Fastener 115 1 Audio/Video Wire Harness 116 2 Console Clamp
117 1 Upper Latch Bolt 118 1 Latch Knob 119 1 Latch Endcap 120 1 Left Grip 121 1 Right Grip
22 3 4" Ground Wire
1 123 1 Console TV Cable 124 1 Speaker Cover 125 1 Speaker 126 4 Speaker Screw 127 1 6" Wire Harness 128 1 Ferrite Clamp 129 3 #8 x 1/2" Ground Screw
* 4" White Wire, M/F * User’s Manual
*These parts are not illustrated. Specifications are subject to change without notice.
31
42
4
21
3
3
3
3
3
21
42
4
3
3
3
43
22
69
69
88
25
4
44
4
4
4
45
45
79
38
24
127
28
31
20
29
14
1
9
10
101
62
60
105
56
58
4
6
47
62
10
57
7
8
7
39
38
40
29
54
29
59
12
15
16
19
18
51
38
53
4
4
17
32
35
33
33
27
37
18
17
19
16
15
2
2
13
29
11
53
38
52
52
34
4
4
4
4
13
46
29
4
4
4
30
30
9
8
61
61
105
56
48
106
107
108
1
69
50
98
553355
55
115
100
117
38
113
38
119
118
36
68
84
128
EXPLODED DRAWING—Model No. NTL19007.1 R1207A
To identify the parts shown on this EXPLODED DRAWING, see the PART LIST near the end of this manual.
78
99
94
89
73
74
83
38
86
85
87
87
29
92
91
93
86
85
38
64
87
38
38
82
81
82
81
82
81
95
96
90
64
64
90
90
70
4
94
75
65
67
75
63
64
90
114
114
4
4
82
81
4
4
4
4
4
80
4
49
76
77
4
4
4
4
90
72
90
72
90
41
13
4
4
4
110
13
111
112
102
97
97
49
116
116
23
80
4
4
4
4
4
4
4
120
121
66
71
122
129
123
46
13
124
126
4
4
125
109
50
104
23
4
78
78
78
4
103
78
78
5
5
5
13
13
13
13
127
26
26
26
26
4
69
69
XX
EXPLODED DRAWING—Model No. NTL19007.1 R
1207A
ORDERING REPLACEMENT PARTS
To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us:
the model number and serial number of the product (see the front cover of this manual)
• the name of the product (see the front cover of this manual)
• the key number and description of the replacement part(s) (see the PART LIST near the end of this manual and the EXPLODED DRAWING in the center of this manual)
LIMITED WARRANTY
ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and material, under normal use and service conditions. The frame is warranted for a lifetime. The drive motor for fifteen (15) years after the date of purchase. Parts are warranted for five (5) years after the date of purchase. Labor is warranted for one (1) year after the date of purchase.
This warranty extends only to the original purchaser. ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product through one of its authorized service centers. All re­pairs for which warranty claims are made must be pre-authorized by ICON. If the product is shipped to a service center, freight charges to and from the service center will be the customer’s responsibility. For in­home service, the customer will be responsible for a minimal trip charge. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, im­proper or abnormal usage or repairs not provided by an ICON authorized service center; products used for commercial or rental purposes; or products used as store display models. No other warranty beyond that specifically set forth above is authorized by ICON.
ICON is not responsible or liable for indirect, special or consequential damages arising out of or in con nection with the use or performance of the product or damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyment or use, costs of removal or installation or other consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation of in cidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above limitation may not apply to you.
-
-
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813
2007 ICON IP, Inc.
Part No. 260094 R1207A
Printed in USA
©
Loading...
