Norcent DP1800 Operating Instruction Manual

Download

DVD RECEIVER SYSTEM Operating Instruction Manual

DP1800

DVD RECEIVER SYSTEM

Norcent Technology, Inc.

550 Cliffside Dr. San Dimas, CA 91773 Customer Support: (800) 916-4011

www.norcent.net info@norcent.net support@norcent.net

MAN-DP1800

Built-in Dolby Digital decoding for maximum home entertainment enjoyment Unique laser-head over-current protection system doubles service life Special DVD deck features fully dust pro of and anti shock design as well as augmented error correction and better stability Fully functional DVD operating system offers many favorite functions and user-friendly operation Integrated DVD and built-in 6-channel Hi-Fi amplifier

PRECAUTIONS

A lightning bolt with an arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO AVOID THE DANGER OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NEVER OPEN THE CABINET, AS DANGEROUS HIGH VOLTAGES ARE CONTAINED INSIDE. ONLY A QUALIFIED SERVICE TECHNICIAN SHOULD ATTEMPT TO OPEN THE CABINET.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, AND FULLY INSERT INTO ELECTRICAL SOCKET.

CAUTION: This DVD receiver unit employs a laser system. To prevent direct exposure to the laser beam, do not open the enclosure. Visible laser radiation is present when enclosure is open. DO NOT STARE INTO BEAM. Additionally, the use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

To ensure proper use of this product, please read this owner's manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location, or contact Norcent Technology.

FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to section 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, this is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/ TV technician for help

FCC Caution: Any changes or modifications not expressly approved by Norcent Technology could void the user's authority to operate this equipment.

INDUSTRY CANADA REQUIREMENT

This Class B digital apparatus meets all requirements of the Canadian InterferenceCausing Equipment Regulations.

THE REGION CODE FOR THIS UNIT IS 1.

IMPORTANT: DVDs are divided into separate regions. The United States and Canada are designated as region 1 DVD. This DVD player only plays region 1 DVDs. Since it is common for DVD movies to be released at different times in different regions of the world, all players have region codes, while discs may have an optional region code. If you load a disc of a different region code in this unit, you will see the region code notice on the screen. The disc will not play, and should be unloaded.

PROTECT YOURSELF!

Record the model and serial numbers for this unit while it is easy to see them. These numbers are located on the back of the unit's cabinet. Retain this information for future reference.

Model No. DP1800 Serial No. _________________________

Retain this information for future reference.

WARNING

RISK OF ELECTRICSHOCK

DO NOT OPEN

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). THERE IS NO USER SERVICEABLE PART INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

IMPORTANT--SAFETY INFORMATION

Overloading---Do not overload wall outlets,

CAUTION: Is it important that you read and

follow all of the instructions in this booklet and

any marked on the unit itself. Retain this

booklet for future reference.

Accessories---Never place this product on an

unstable platform, stand, cart, wall mount, shelf,

or table. The product may fall, causing serious

personal injury to persons and pets, as well as

seriously damaging the product. Use only with

a stable platform, stand, cart, wall mount, shelf,

or table that has been recommended by Norcent

Technology or sold with the product . Any mounting

of the product should follow the manufacturer's

instructions, and use a mounting accessory recom-

mended by the manufacturer. This unit while positio-

ned on some type of cart must be moved with care.

Quick stops, excessive force, and uneven surfaces

may cause the product and cart combination to

overturn.

Attachments---Use only attachmentsrecommend-

ed by Norcent Technology, as they may cause

hazards.

Cleaning---Always unplug this unit from the wall

electrical outlet before cleaning. Do not use liquid or

aerosol cleaners; use a damp cloth for cleaning.

Grounding or Polarization - This product is

equipped with either a polarized AC plug (a plug

having one blade wider than the other) or with a

three-wire grounding-type plug. These plugs fit

into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into

the outlet, try reversing the plug. If the plug should

still fail to fit, contact an electrician. Do not defeat

the safety purpose of the polarized plug in any way

or manner.

Lightning---For added product protection during

a lightning storm or when it is left unattended and

unused for long periods of time, unplug it from the

wall outlet and/or disconnect the

wall outlet and/or disconnect the antenna or cable

system. This will prevent damage to the prod-

uct due to lightning and power-line surges.

Object and Liquid Entry---Never push

objects of any kind into this product through

openings as they may touch dangerous

voltage points or short-out parts that could

result in a fire or electric shock. Never spill

liquid of any kind on or into the product.

Outdoor Antenna Grounding---If an outside

antenna or cable system is connected to the

product, be sure the antenna or cable system

is grounded so as to provide protection

against

voltage surges and built-up static charges.

Article 810 of the National Electrical Code,

ANSI/NFPA 70, provides information with

regard to proper grounding of the mast and

supporting structure, grounding of the lead-in

wire to an antenna discharge unit, size or

grounding conductors, location of antenna-

discharge unit, connection to grounding

electrodes, and requirements for the grounding

electrode.

antenna or cable

Overloading---Do not overload wall outlets,

extension cords, or integral convenience receptacles,

as this may result in a fire or electric shock.

Power-Cord Protection - Power-supply cords

should be routed so that they are not likely to be

walked on or pinched by items placed upon or against

them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they

exit from the product.

Power Lines---An outside antenna system

should not be located in the vicinity of overhead

power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits.

When installing an outside antenna system, extreme

care should be taken to keep from touching such

power lines or circuits as contact with them might be

fatal.

Power Sources---This product should be oper-

ated only from the type of power source indicated

on the marking label. If you are not sure of the type

of power supply to your home, consult yourproduct

dealer or local power company. For products

intended to operate from battery power orother

sources, refer to the operating instructions.This

DVD player operates on 120V AC/60Hz. Donot turn

off unit immediately after turning on; wait at least 10

seconds.

Replacement Parts--- If replacement parts are

required, be sure the service technician has used

replacement parts specified by Norcent Technology

or have the same characteristics as the original

part. Unauthorized substitutions may result in fire,

electric shock, or other hazards.

Safety Check---Upon completion of any service

or repairs to this product, ask the service technician

to perform safety checks to determine that the

product is in proper operating condition.

Servicing---Do not attempt to service this

product yourself as opening or removing covers

may expose you to dangerous voltage or other

hazards. Refer all servicing to qualified service

personnel.

TV System---This unit is compatible with

television sets featuring either the NTSC or PAL

color system.

Ventilation---Slots and openings in the cabinet

are provided for ventilation and to ensure reliable

operation and protection from overheating. These

openings should never be blocked by placing the

product on a bed, sofa, rug, or other similar

surface. This product should not be placed

in a built-in installation such as a bookcase or

rack unless proper ventilation is provided. Ne-

ver place this product near a heat source,

suchas heat registers, stoves, radiators,or

any other product that produces heat.

Water and Moisture---Do not use this

product near sources of water and moisture,

such as bath tub, wash bowl, kitchen sink, or

wash machine; in a wet, damp basement; or

near a swimming pool or similar locations. If

moisture condensation occurs, remove any

disc, connect the unit's power cord to a wall

outlet, turn the unit on, and leave it on for two

to three hours. By then, the unit will have

warmed up and evaporated any moisture.

LIMITED WARRANTY NORCENT DVD PLAYER Warranty obligations of Norcent Technology, Inc. are limited to the terms set forth below:

1. Norcent Technology warrants to the original consumer purchaser that this Norcent DVD player will be free from defects in material and workmanship for the Standard Warranty Period of one year. The start of the warranty period is the date of purchase, verifiable by a dated sales receipt.

2. The warranty on a replacement player is the remainder of the warranty period on the original player or 90 days, whichever is longer.

3. If the original consumer purchaser discovers a defect, Norcent Technology will, at its option, repair the DVD player at no charge to the consumer, provided it is returned during the warranty period, with transportation charges prepaid, to Norcent Technology, Inc. at the address below. The unit must be sent properly packaged in original Norcent Technology packaging or in Norcent Technology-approved packaging.

4. For warranty service, contact Norcent Technology at (800) 916-4011 (in the U.S.A.) to obtain a Return Material Authorization (RMA) number. A copy of the original dated sales receipt bearing the appropriate Norcent Technology serial number may be required for warranty service.

The following are not covered under this warranty: Normal wear and tear Abuse, unreasonable use, mistreatment, or neglect Damage caused by the equipment or system with which the disc player is used Damage caused by modification or repair not made or authorized by Norcent Technology, Inc. Disc player whose Norcent Technology, Inc. serial number has been removed or defaced Damage caused by use of non-Norcent Technology, Inc. packaging Damage caused by improper or improperly used packaging Players that are determined to be stolen

THIS WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. NORCENT TECHNOLOGY, INC. SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITAION WARRANTY OF MERCHANT ABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND AGAINST INFRINGEMENT.

No Norcent Technology, Inc. dealer, agent, distributor, or employee is authorized to make any modification, extension, or addition to this warranty. NORCENT TECHNOLOGY, INC. IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR UNDER ANY OTHER LEGAL THEORY , INCLUDING, BUT NOT LIMITED TO, LOSS OF DATA, LOSS OF PROPERTY, AND ANY COSTS OF RECOVERING PROGRAMMING OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH NORCENT TECHNOLOGY, INC. PRODUCTS.

Some states do not allow the exclusion of limitation of incidental or consequential damages or exclusion of implied warranties, so the above limitations or exclusions may not apply to you. This warranty gives you special legal rights; you also have other rights that vary from state to state.

Norcent Technology, Inc. 550 Cliffside Dr. San Dimas, CA 91773

DVD DP-1800 TECHNICAL SPECIFICATIONS

TABLE OF CONTENTS

DVD Player

TV System NTSC/PAL Compatible Discs DVD, CD, MP3, CD-R, CD-RW Resolution Ratio Greater Than 500 lines Video S/N Ratio 65dB Frequency Response fs (96KHz/24bit) 4Hz - 44KHz:+/-2dB Audio S/N Ratio 95dB Degree of Distortion <0.01% D/A Converter 192KHz/24bit Video Out Y: 1Vp-p(75 ) S-Video Out C: 0.3Vp-p(75 );

2.0V 0.2V Audio Out 5.1 Channel,

Digital Audio Output Coaxial Connections CVBS S-Video, 2 Channel Output

FM Tuner

Tuning Range 87.5-108MHz (100kHz Space) S/N Ratio >46dB Monophonic >46dB Stereo >50dB (DIN)

Selectance 50dB THD Monophonic 2% Stereo 3% Frequency Response 30Hz-10kHz +/- 1dB Stereo Resolution 35dB (1kHz) 30dB (100Hz-10kHz)

AM Tuner

Tuning Range 530-1710kHz (10k Space) S/N Ratio 35dB THD 3%

Amplifier

Distortion Limited Output Power: Main Speakers 15W+15W (4 ) Surround Speakers 15W+15W (4 ) Center Speaker 15W (4 ) Subwoofer 30W (8 )

Frequency Response: Main Speakers 20Hz-20kHz +/- 3dB Surround Speakers 20Hz-20kHz +/- 3dB Center Speaker 20Hz-20kHz +/- 3dB Subwoofer 20Hz-20kHz +/- 3dB

S/N Ratio > 76dB Input Sensitivity 350mv, 47k Channel Resolution > 30dB (Normal)

Remote Control

Transmitter Infrared Ray Signal Range Approximately 15' Power Source 2 AAA Batteries

General

Power Supply AC 110-240V/50/60Hz Consumed Power 130W Size (WxHxD) DVD Player: 16.3 x2.8 x15.7 Speakers 4 x4.5 x5.3 Subwoofer: 8 Weight DVD Player: 16.2 lbs. Speakers: 0.75lbs. Subwoofer: 11 lbs.

Because its products are subject to continuous improvement, Norcent Technology reserves the right to modify product design and/or specifications without notice and without incurring any obligations.

"" "

"""

"x14.5"x17.2"

Precaution ................................................ .1

Safety Information .................................... ..2

Table of Contents ........................................3

About Your DVD Player ................................4

Best Location............................................................4

To Obtain a Clear Picture.......................................... .4

Playable Discs..........................................................4

Digital Audio Output ..................................................4

Laser-Head Over-Current Protection System ..............4

Disc Use .....................................................5

Handling...................................................................5

Cleaning...................................................................5

Storing.....................................................................5

Controls......................................................6

Front Panel...............................................................6

Back Panel...............................................................6

Remote Control...........................................7

Operating the remote control........................8

Connecting Devices....................................,9

Speakers...................................................10

Arrangement of speakers............................10

Connecting speakers..................................11

Connecting antenna...................................12

Connecting power supply............................13

Playing the radio........................................14

Basic DVD operation..................................15

Functions..................................................17

System setup.............................................19

Preference setup....................................... 23

Mp3 function..............................................24

JPEG files.................................................25

Trouble shooting........................................25

DVD DP-1800 technical specifications.........26

Warranty...................................................27

ABOUT YOUR DVD PLAYER

The following will help you get the most

enjoyment from your Norcent DVD receiver system.

BEST LOCATION

The unit should be placed on a firm, flat surface, away from VCRs, stereos, radios, or large speakers, as the magnetic flux from these devices may cause distortion in the sound and a poor picture. If placed in a cabinet, be sure there is at least 1 of free space completely around the unit for proper ventilation.

TO OBTAIN A CLEAR PICTURE

A DVD receiver is a precision device. If the optical pick-up lens and disc drive parts become dirty or worn down, picture quality will become poor. To obtain a clear picture, regular inspection and maintenance are recommended every 1,000 hours of use, depending on the operating environment. Contact dealer for details.

PLAYABLE DISCS

This Norcent DVD receiver system will play the following types of discs: DVD, MP3, CD, CD-R, and CD-RW with super-error correction ability. It is also capable of displaying picture CDs and digital photo albums. It supports eight languages, up to 32 subtitles, and multi-angle viewing. It features easy setup and operation with onscreen menus. It has full function CPU up grade able capability.

DIGITAL AUDIO OUTPUT

The unit's coaxial output capability enables you to connect an external six-channel AV amplifier and processor with built-in Dolby Digital codes and MPEG or DTS modulating capacity with just one cord. This enables you to conveniently enjoy different DVD, CD, and Mp3 discs.

ANALOG AUDIO OUTPUT

Speaker system plug-and-play convenience through the built-in six-channel power amplifier eliminates the use of an external power amplifier.

LASER-HEAD OVER-CURRENT PROTECTION SYSTEM

To extend the service life of the laser head, the unit includes a unique laser-head overcurrent protection system, ensuring a constant laser current.

JPEG FILES

The Joint Photographic Experts Group (JPEG) produces standards for continuous tone image coding. It is a widely used format for compressing and saving images. It uses highefficiency compression data to compress images up to 15x to 20x. JPEG is supported by most of the image processing software in use today, and is suitable for storing photo images. This Norcent DVD player can decode JPEG formatted picture CDs.

Play by Number Keys

1. Follow the basic operating instructions to insert the picture CD disc. Once the disc tray is closed, the machine will automatically search for the information on the disc and show it on the TV screen.

2. Press the number keys to select an image album. Note: The number keys are only functional within the current image album.

Play by Menu

1. Follow the basic operating instructions to insert the picture CD disc. Once the disc tray is closed, the machine will automatically search for the information on the disc and display the main menu on the TV screen.

2. Press the directional scroll buttons to select images and press the PLAY button.

3. To select other images, press STOP button, then press directional scroll keys. Once image is selected, press the PLAY button.

Other JPEG Functions

1. While playing a JPEG file, functions such as pause, random play, repeat play and others are still available.

2. Press the RESUME button when playing JPEG files to select various image display modes.

3. Press the PREV or NEXT buttons when playing JPEG files to select either the previous or next image.

4. The zoom function is operable while showing JPEG images. Press the ZOOM button to use the zoom function, press again to close it.

5. Press FAST FORWARD or FAST RETURN buttons when in zoom function to zoom in or out.

6. Press the directional scroll buttons when in zoom function to rotate an image.

TROUBLE SHOOTING

This handy trouble-shooting guide is provided to save you time in case you experience any inconvenience with this DVD player. If the problem is not listed or if the provided solution does not correct the problem please call our customer support department at (800) 916-4011.

Problem Possible Solution No power

1. Check to ensure that the power plug is securely in the wall outlet.

No sound

1. Check the connection between the DVD player and the TV set, amplifier, or any other unit it is connected to.

2. Check to ensure the TV and amplifier are in the correct mode (video 1).

No picture

1. Check the connection between the DVD player and the TV set or any other unit it is connected to.

2. Check to make sure TV is turned on.

Disc does not play

1. Check to make sure the disc is loaded correctly label side facing up on disc tray.

2. Check that disc is clean from dirt, dust, fingerprints, and smudges.

3. Check to ensure disc is within the guides on the tray.

4. Check if parental lock function is on.

5. Make sure disc is for use in region 1. Remote does not work. Check batteries; possibly replace.

2. Check to ensure there isn't any obstacles between the remote sensor on the unit's front panel and the remote control.

3. Be sure the remote is aimed at the remote sensor.

Divided picture

1. Check that disc is clean and has no scratches.

2. The unit is controlled by a micro computer, which may need to be reset. Turn off the unit's power, wait several seconds, then turn back on.

No color picture

1. Check to see if the S connector is damaged (bent pin).

MP3 discs don't play

1. Use another software edition to reburn disc, as the edition used may not be compatible with the player.

2. Use new editions of software such as Audiostation 4, asy CD Creator , Toast Titanium, etc.

3. Make sure MP3 file is not encoded with a variable bit rate, such as provided by Real Networks.

"E "

PREFERENCE SETUP

MP3 FUNCTION

USE OF DISCS

Password

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE DISC MENU LOCALE PARENTAL

PASSWORD

DEFAULTS SMART NAV

MAIN PAGE

PIN EDITION

CHANGE

The default password for this feature is

0000 It may be changed through this option.

Defaults

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE DISC MENU LOCALE PARENTAL PASSWORD

DEFAULTS

SMART NAV

MAIN PAGE

DEFAULT ENTRY

The factory preset defaults may be resumed through this option.

Smart Navigation Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE DISC MENU LOCALE PARENTAL PASSWORD DEFAULTS

SMART NAV

MAIN PAGE

SMARTNAN

RESET

NO MENU

WITH MENU

MP3 is an audio compression technology that uses MPEG3 standards, compressing at a rate of 12:1. Having CD-quality audio, an MP3 disc can record over 600 minutes of music.

Playing an MP3 Disc

1. Follow the basic operating instructions to insert the MP3 disc. Once the disc tray is closed, the machine will automatically search for the information on the disc and show it on the unit's display panel.

2. Press the directional scroll button to select the submenu to be played, then press the direction scroll key to select the desired track. Press the PLAY button. Or, press the appropriate number keys to select a desired track.

3. To select another submenu, press the STOP button then the directional scroll key.

Repeat Play With repeat play, the same song or all of the songs on an MP3 disc can be played over and over.

1.Choose the desired song to be repeated.

2.Press the REPEAT key. REPEAT ONE will appear on the TV screen.

3.If all songs are to be repeated, press the REPEAT key a second time. REPEAT ALL will appear on the TV screen. Press PLAY.

REPEAT

4.To exit the repeat function, press the REPEAT key a third time. EXIT REPEAT will appear on the TV screen.

Note: The mute, volume control, pause, and forward/backward search are still operable as an MP3 disc plays.

ROOT ROOT

1MP3 MP301 2MP3 Mp302 3MP3 Mp303

REPEAT ONE

REPEAT ALL

EXIT REPEAT

1MP3 2MP3 3MP3

This page contains valuable information regarding the handling, cleaning, and storage of discs played in this unit.

Handling

Do not touch the playback side of the disc. Do not attach paper or tape to discs. Do not stick or write anything on the surface. Protect against fingerprints. Always hold a disc by the center and edge portions.

Cleaning

Fingerprints and dirt on the disc may cause picture and/or sound deterioration. Wipe the disc from the center outward with a soft cloth. Always keep the disc clean. If you cannot wipe the dirt off, lightly use a slightly moistened soft cloth and finish with a dry cloth. Do not use any type of solvent such as: Paint thinner, benzene, commercially available cleaners or anti-static spray for vinyl LPs.

Storing

Do not store discs in places subject to direct sunlight or near heat sources. Do not store discs in places subject to moisture and dust. Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

NOTE: Norcent Technology is not responsible for damage that may occur to any disc that is operated in this unit or not handled, cleaned, or stored as suggested above.

Select NO MENU if playing an MP3 or picture CD without a menu; or select MENU if playing an MP3 or picture CD with a menu.

FRONT AND BACK PANELS

PREFERENCE SETUP

Front Panel Functions

DP1800

DVD & AMPLIFIER SYSTEM

1. POWER Before plugging the power cord into the AC

outlet, check to make sure all of the connection s have been properly completed. When they have been, carefully plug power cord into outlet. Press the POWER button on the front panel to power the unit. When the unit is initially powered, a brief surge of electricity may cause interference with other electronic equipment on the same circuit. If this occurs, connect the unit to an outlet on a different circuit.

. /PRE/TUN

Use this button to open and close the disc tray

while in DVD mode. It is disabled when another signal source is used. When in the Tuner mode, this button is used to select preseting or tuning mode.

3. /AUTO Use this button to begin play function while in

DVD mode. When in the tuner mode, you may press this button for automatic search..

Back Panel Functions

1. ANTENNA Use to connect the provided indoor FM and

AM loop antennas.

2. AUX IN Use to connect input for both auxiliary 1 and

2 music sources.

3. AUDIO OUT Use to connect both the right and left channel

line outputs as well as subwoofer output.

4. VIDEO OUTPUT

5. S-VIDEO OUTPUT

6. REAR Use to connect the four terminals of the left

and right surround sound speakers.

DVD/CD/MP3/CD-R/CD-RW

3 4

5 6

4. /MEMO Use this button to stop play function while

in DVD mode. While in the tuner mode, this button is used to memory station.

5. /DOWN

While in the DVD status, you may press this button for previous track.

While in the tuner mode, you may press this button for radio down search.

6. /UP Button. While in the DVD status, you may press this button for next track. .

While in the tuner mode, you may press this button for radio up search.

7. INPUT SIGNAL SOURCE Use this button to select the proper input

signal source. (Note: The selected input will correspond to the selected input terminal on the rear panel.

8. VOLUME Use this button to control the unit's volume. It

controls all six channels simultaneously.

7. FRONT/MAIN Use to connect the four terminals of the left

and right front or main speakers.

8. CENTER/SUBWOOFER Use to connect the four terminals of the

center and subwoofer speakers.

9. COAXIAL OUTPUT

10. 110V/60Hz This unit comes with an AC power cord. Be

sure its prongs are dry before plugging it into an electrical outlet. Take caution not to overextend the cord or walk on it.

11. COMPONENT VIDEO OUTPUT

Model No.:

DP1800 MADE IN CHINA

Used by North America only!

50X15mm

Audio/Video Apparatus

C US

58WJ

221338

LISTED

DOUBLE INSULATIONWHEN SERVICING USE ONLY

IDENTICAL REPLACEMENT PARTS. HongPu International Development(Shanghai) Co., Ltd. Plant 25, No.30 FuTeDongSan RD WaiGaoQiao Free Trade Zone PuDong Shanghai.P.R.C.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: SHOCK HAZARD- DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE- NE PAS OUVRIR

110V~60Hz110V~60Hz

ATTENTION

RISQUE D ELECTROCUTION

NE PAS OUVRIR

While the DVD player is in the stop mode, press the SETUP key to access the initial setup menu, which includes audio, subtitle, disc menu, locale, parental control, password, defaults, smart navigation, and the main menu. These preset values are essential to a DVD player. These items may be changed as desired.

Audio Language

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO

SUBTITLE DISC MENU LOCALE PARENTAL PASSWORD DEFAULTS SMART NAV

MAIN PAGE

DUBBING LANGUAGE

ENGLISH

FRENCH SPANISH CHINESE JAPANESE GERMAN ITALIAN

This Norcent DVD player has English, French, Spanish, Chinese, and Japanese as its built-in disc-dubbing language options.

Subtitle

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO

SUBTITLE

DISC MENU LOCALE PARENTAL PASSWORD DEFAULTS SMART NAV

MAIN PAGE

SUBTITLE

This Norcent DVD player has English, French, Spanish, Chinese, and Japanese as its built-in subtitle languages. When a DVD disc is played, the subtitle feature may be selected through this menu. It is also possible to hide the feature through this menu.

ENGLISH

FRENCH SPANISH CHINESE JAPANESE GERMAN ITALIAN OFF

Disc Menu

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE

DISC MENU

LOCALE PARENTAL PASSWORD DEFAULTS SMART NAV

MAIN PAGE

DISC MENU LANGUAGE

ENGLISH

FRENCH SPANISH CHINESE JAPANESE GERMAN ITALIAN

This Norcent DVD player has English, French, Spanish, Chinese, Japanese, and off as its built-in film's menu language options.

Locale

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE DISC MENU

LOCALE

PARENTAL PASSWORD DEFAULTS SMART NAV

MAIN PAGE

REGION CODE

CHINA

FRANCE HONG KONG JAPAN TAIWAN GBR USA

Since different countries have different language choices, this DVD unit offers specific locale choices.

Parental Lock

Follow the instructions in DVD Menu Setup in combination with the desired option from graphic below.

PREFERENCES SETUP

AUDIO SUBTITLE DISC MENU LOCALE

PARENTAL

PASSWORD DEFAULTS SMART NAV

MAIN PAGE

FILM CLASS

By selecting a specific rating, films in that group and above are blocked from being shown.

1 G

2 3 PG 4 PG 13 5 6 PG-R 7 NC-17 8 ADULT NO-PARENTAL

SYSTEM SETUP

REMOTE CONTROLLER

AUDIO SETUP

The audio setting includes audio out, OP mode, L+R, dynamic, and LPCM out.

Audio Out

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AUDIO SETUP

AUDIO OUT

OP MODE L+R DYNAMIC LPCM OUT

MAIN PAGE

AUDIO OUTPUT

ANALOG

SPDIF/RAW SPDIF/PCM

This DVD player provides three types of audio output:

1. Analog Needs connection of terminals on the back panel to the left and right speakers.

2. SPDIF/RAW This surrounding form is realized through optical and coaxial output of Dolby Digital signals from the back panel.

3. SPDIF/PCM The same as #2. Note: This unit outputs both Dolby Digital signal

and analog signal. If you want to use the unit for karaoke, select the analog signal output. Also, there is no DTS decoder. If you play a DTS encoded disc, set the output to either SPDIF/ RAW or SPDIF/PCM status. This will output the digital audio signal through the optical/coaxial mode.

OP Mode

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AUDIO SETUP

AUDIO OUT

OP MODE

L+R DYNAMIC LPCM OUT

MAIN PAGE

DYNAMIC

OPERATIONAL MODE SETUP

LINE OUTPUT

RF ADJUSTMENT

Both of the line output and RF adjustment options are applicable in all conditions. Due to its suitability and convenience in most cases, line output is used.In some conditions, for instance when headphones are used, the RF mode may be used.

L+R

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AUDIO SETUP

AUDIO OUT OP MODE

L+R

DYNAMIC LPCM OUT

MAIN PAGE

L+R SETUP

STEREO

L-MONO R-MONO MIX-MONO

If an amplifier/decoder is being used with this DVD player and it has Dolby Digital output, the following selections may be made: stereo, left, right, or mixed sound accordingly.

Dynamic

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AUDIO SETUP

AUDIO OUT OP MODE L+R

DYNAMIC

LPCM OUT

MAIN PAGE

PULL

6/8 4/8 2/8 OFF

DYNAMIC RANGE COMPRESSION

To avoid a disturbing trembling sound, the dynamic function lowers the volume without changing the original tone.

LPCM Out

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AUDIO SETUP

AUDIO OUT OP MODE L+R DYNAMIC

LPCM OUT

MAIN PAGE

SET LPCM OUTPUT TO 48K OR 96K

LPCM48K

LPCM96K

OPEN/CLOSE

TUNER

LANGUAGEANGLE

PROG L/R

DISPLAY

ENTER

PAUSE

AUX 1 AUX 2

SLOW

PLAY

DOWN

DVD

N/P

SUBTITLE

+10

TITLE

FM MODE

SETUP

PBC STEP ZOOM RESUME

STOP

MEMO AUTO

MUTE

TIME

VOLUME

PRE/TUN

REPEAT

A-B

OPEN/CLOSE

MUTE

DVD SELECTOR

AM/FM TUNER

AUX1 SELECTOR

AUX2 SELECTOR

N/P SELECTOR

SUBTITLE

LANGUAGE

ANGLE

0-9 NUMBER KEYS +10

TIME

13 14

TITLE PROG

15 16

L/R CHANNEL SELECTOR VOL INCREASE

17 18

VOLUME DECREASE SCREEN DISPLAY

SLOW MOTION

21 22

FM STEREO MODE

PRESET/TUNING

SCROLL UP

SCROLL RIGHT

SCROLL DOWN

SCROLL LEFT

ENTER

SETUP

REPEAT PBC

STEP

32 33

ZOOM

RESUME PLAY

STOP

PAUSE

PLAY

A-B REPEAT

DOWN (search down for radio stations/rewind skip)

UP (search up for radio stations/forward skip) MEMO (memory/previous track)

AUTO (automatic search/next track)

OPERATING THE REMOTE CONTROL

SYSTEM SETUP

Battery Installation

1. Push down and out on the battery

Compartment cover to remove it.

2. Insert the two AAA batteries into the battery

compartment of the remote control, making

sure the + and - signs on the batteries and

inside the battery compartment match up.

3. Replace the battery compartment cover.

Notes:

Do not mix batteries from different manu-

facturers, nor old ones with new.

If the remote control will not be used for an

extended period of time, remove the

batteries to prevent damage-causing

corrosion.

Remove dead batteries immediately to

prevent damage-causing corrosion.

If battery leakage occurs, wipe the battery

liquid from the battery compartment, then

replace both batteries.

Always replace both batteries at the same

time, using new, fully charged batteries.

Life expectancy of batteries may vary

depending on amount of use.

Using the Remote Control

Point the remote control at the remote

sensor on the DVD receiver. When the signal is

received from the remote, the unit will function

accordingly. The remote will operate to

approximately 16' from the remote sensor at an

angle of around 30 each direction.

Notes:

Do not direct the remote sensor toward any light source, such as direct sunlight or a strong fluorescent light, as it may cause the unit to not operate correctly. When other remote controls are used nearby or when the remote is used near equipment using infrared rays, interference may occur. Placing an object on the remote control may cause it to inadvertently depress a button, changing a function and shortening battery life. Do not glaze the front of the DVD receiver with colored glass, as it may cause interference with normal operation of the controller. Make sure there is no barrier between the remote control and remote sensor, as it could prevent the unit from receiving the signal. Do not spill water or put wet items on the remote control. Never disassemble remote control.

BATTERIES INCORRECT USE OF BATTERIES MAY

CAUSE THEM TO LEAK, CORRODE OR EXP LODE.

SPEAKER SETUP

DOWNMIX

CETR

REAR SUB WOOFER CETR DELAY REAR DELAY TEST TONE

MAIN PAGE

CENTER SPEAKER

OFF

This turns the center speaker on or off.

Rear Speaker

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX CETR

REAR

SUB WOOFER CETR DELAY REAR DELAY TEST TONE

MAIN PAGE

REAR SPEAKER

OFF

This turns the rear speaker on or off.

Subwoofer

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX CETR REAR

SUB WOOFER

CETR DELAY REAR DELAY TEST TONE

MAIN PAGE

WOOFER SPEAKER

OFF

This turns the subwoofer speaker on or off.

Center Delay

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX CETR REAR SUB WOOFER

CETR DELAY

REAR DELAY TEST TONE

MAIN PAGE

CENTER DELAY

5ms

3ms

1ms OFF

A Dolby Digital 3-D surround sound system ideally delivers realistic sound effects, enhancing the enjoyment of viewers. Some amplifying systems need help in this regards. Delaying the sound output of the central and rear speakers is a way to overcome this problem. The center delay is used to set the delay time of the center speaker.

Rear Delay

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX CETR REAR SUB WOOFER CETR DELAY

REAR DELAY

TEST TONE

MAIN PAGE

REAR DELAY

15ms

9ms

3ms OFF

The sound output of the rear speakers is delayed to ensure the best quality Dolby Digital 3-D surround sound system is delivered. (See Center Delay for details.)

Test Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX CETR REAR SUB WOOFER CETR DELAY REAR DELAY

TEST TONE

MAIN PAGE

TEST TONE

ON OFF

This tests the sound coming from each speaker in the system. The speaker being tested is indicated in the lower left corner of the screen.

SYSTEM SETUP

This Norcent DVD player supports output

of various systems, including auto, NTSC, and PAL. If the TV set has only NTSC or PALsystems, the picture will blink and become colorless when the wrong system is selected.If this occurs, press the SYS button on the remote control to return to the normal screen. Remember to always select the correct system. For more information on output format, refer to the TV set's manufacturer's instructions.

TV DISPLAY TV TYPE VIDEO OUTPUT ANGLE MARK

OSD LANG

CAPTIONS

GENERAL

ENGLISH

CONNECTING DEVICES

Video Output Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

GENERAL

TV DISPLAY TV TYPE

VIDEO OUTPUT

ANGLE MARK OSD LANG CAPTIONS

MAIN PAGE

VIDEO OUTPUT

CVBS

RGB YUV

There are three video output choices: Use the CVBS output if the S-Video output jack has been selected; use the RGB output if the RGB output jack has been selected; or use the YUV output if the component output jack has been selected.

Angle Mark Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

GENERAL

TV DISPLAY TV TYPE VIDEO OUTPUT

ANGLE MARK

OSD LANG AUDIO OUTPUT CAPTIONS

MAIN PAGE

ANGLE MARK

OFF

When a DVD with multiple angles is played, a particular camera angle may be selected by the viewer.

OSD Lang. Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

MAIN PAGE

SCREEN LANGUAGE

This is used to set the language of the setup menu and screen display.

Captions

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

GENERAL

TV DISPLAY TV TYPE VIDEO OUTPUT ANGLE MARK OSD LANG

CAPTIONS

MAIN PAGE

CAPTIONS

OFF

SPEAKER SETUP

This submenu option includes downmix mode, center, rear, subwoofer, center delay, rear delay, test, and main. Downmix Mode Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

SPEAKER SETUP

DOWNMIX

CETR REAR SUB WOOFER CETR DELAY REAR DELAY TEST TONE

MAIN PAGE

DOWNMIX

LT/RT STEREO VSS

5.1CH

Center Speaker

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

AMPLIFIER

Connection terminals for this DVD receiver are found on the rear panel. Read carefully and follow the manufacturers' instructions of any video and audio device being connected to this unit.

Do not connect the power until all connec tions have been properly completed.

Model No.:

DP1800 MADE IN CHINA

Used by North America only!

50X15mm

Audio/Video Apparatus

C US

58WJ

221338

LISTED

DOUBLE INSULATIONWHEN SERVICING USE ONLY

IDENTICAL REPLACEMENT PARTS. HongPu International Development(Shanghai) Co., Ltd. Plant 25, No.30 FuTeDongSan RD WaiGaoQiao Free Trade Zone PuDong Shanghai.P.R.C.

110V~60Hz110V~60Hz

CAUTION

ATTENTION

RISQUE D ELECTROCUTION

RISK OF ELECTRIC SHOCK

NE PAS OUVRIR

DO NOT OPEN

WARNING: SHOCK HAZARD- DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE- NE PAS OUVRIR

Red terminal (marked R) is for connecting the right channel. The white terminal (ma rked L) is for connecting the left channel. The yellow terminal is for video connection. Make sure all connections are securely made. Improper connections may cause noise, poor performance, or cause damage to the equipment. Do not tie the AV cord with any other cords, such as the power cord or speaker wires, as it may result in poor picture and/or sound quality.

SPEAKERS

ARRANGEMENT OF SPEAKERS

FUNCTIONS

SYSTEM SETUP

The configuration and arrangement of a surround sound system's speakers is critical. For maximum listening enjoyment, refer to the Arrangement of Speakers section in this manual prior to connecting speakers.

Surround Sound Speakers Front or main right and left speakers; center speaker

These three speakers provide extensive sound imaging and augment the dynamic effect of the audio. A movie's principal dialogue comes through these speakers.

Rear or surround sound speakers

These two speakers provide 3-D dynamic sound effects, and create an enveloping atmosphere, as they add background sounds. .

Subwoofer speaker

Provides rich and powerful bass, adding a powerful dimension of realism.

Note: Audio recorded for the center speaker and subwoofer will be assigned to the front and 3-D rear speakers to obtain the optimum 3-D surround sound effect.

1.TV set or screen

2. Front or main left speaker

3.Subwoofer

4.Center speaker

5.Front or main right speaker

The ideal surround sound speaker configuration may vary according to room size and wall material. The figure below illustrates a typical arrangement.

Hints:

Front or main speakers and central speaker should be placed at the same level and in a way that sound is oriented toward the listener's ears. 3D surround sound or rear speakers should be placed 3' higher than the height of listener's ears. Subwoofer speaker may be placed anywhere within the room, as its location produces little effect on a listener's sensation to sound. To obtain the optimum bass effect, a subwoofer is recommended in home theater systems.

6.3-D surround sound left speaker

7.3-D surround sound right speaker

8.Viewer's location

The repeat mode changes each time the REPEAT key is pressed (i.e., from title repeat to chapter repeat, etc.)

Zoom

A picture may be enlarged up to four times during either playback or slow motion through the unit's zoom function. Press the ZOOM key once and it enlarges the image 1.5x; press a second time and the image enlarges 2x; while a third pressing enlarges the image 4x. To return to normal-size playback, press the ZOOM key a fourth time. Enlargement takes place in the center of the picture.

L/R When a DVD disc is played, the active language will be displayed. When a CD disc is played, the left or right track, or stereo will be displayed accordingly.

Volume and Mute

The volume on this Norcent DVD receiver is easily controlled with the remote control by pressing either the VOL + key to raise the volume or the VOL- key to lower it. By pressing the MUTE key, no audio will be heard. To reinstate the audio, press the MUTE key again.

Program Pressing the PBC button followed by pressing the PROG button, the program status of a playing DVD will appear. When a CD is playing, by pressing the PBC button followed by the PROG button allows you to program specific tracks in a desired order of play. To exit the Programmed play mode, press the PBC button again.

DVD Menu Setup By pressing the SETUP key on the remote control, the main setup menu appears. You will be asked to enter the Personal Identification Number (PIN), which is “0000”. From the setup menu, you may choose the following options: general setup, speaker setup, audio setup, and preferences setup.

1. After accessing the setup menu, press the scroll key for up or down movement to select a desired item. Once an item is selected, press the PLAY key to confirm your entry and to move to the sub-entry.

2. Use the left or right scroll key to move the pointer and the up or down scroll key to select the desired option. Once an item is selected, press the PLAY key to confirm your selection. This completes the setup of the selected function.

3. To end the setup, press the SETUP button again.

GENERAL SETUP

This option is used to set up the TV-screen format, video functions, and DVD functions with options of TV display, TV type, video output, angle mark, OSD lang., and captions.

TV Display

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

GENERAL

TV DISPLAY

TV TYPE VIDEO OUTPUT ANGLE MARK OSD LANG CAPTIONS

MAIN PAGE

TV DISPLAY

NORMAL/PS

NORMAL/LB WIDE SCREEN16:9

Note: Regardless of what screen format is chosen, if the screen displays in 4:3 format, the picture can only be shown in that format. With DVDs, the screen format is convertible. If the screen displays only in 4:3 format, when a DVD with 16:9 display format is used, the picture will be flattened.

Film format

4:3

16:9

TV screen

Normal

4:3

Full view

Mailbox

16:9

Wide screen

TV Type

Follow the instructions above in DVD Menu Setup in combination with the desired option from graphic below.

GENERAL

TV DISPLAY

TV TYPE

VIDEO OUTPUT

SCREEN LANGUAGE

ANGLE MARK OSD LANG CAPTIONS

MAIN PAGE

TV SYSTEM

MULTI

NTSC PAL

FUNCTIONS

CONNECTING SPEAKERS

Time

This DVD receiver can display various data regarding the disc being played. Press the TIME button for the following.

1. Press once, the number of titles and chapters in each title appears

TIME

TITLE 01/02 CHAPTER 06/28

2. Press again, the time of a selected title appears.

TIME

TITLE 01/02 TIME : :

Pressing the TIME button while playing a CD disc allows you to enter, using the number keys, the amount of time you want the CD to play. For example, 55:50, stands for 55 minutes and 50 seconds.

A TO B SET A

A-B

2. Press the A-B button again while the disc is playing to set point B, the ending spot. The section between A and B will replay.

A TO B SET B

3. Press the A-B button a third time to cancel.

A TO B CANCELLED

This well-designed DVD receiver provides optimum sound quality when the speakers used are within the range of their rated impedance.

Important

The minimum impedance of the five speaker terminals is 4 ohm; for the subwoofer, it is 8 ohm.

If you want to use only one speaker or listen to monophonic music, do not parallel connect individual speakers to the left and right channel terminals. See the figure on the left below.

Connecting Speaker Cables

1.Peel off approximately 1/ 2¡± of cable insulation

2.Tighten the wire end (#2 below)

3.Open cable terminal by pressing back on tab

4.Insert wire end into terminal

5.Release tab; make sure wire is in terminal securely

Note: To prevent damage to the circuit, care should be taken to prevent short circuiting from occurring at the positive and negative poles of the speaker cord.

1 2

3 4

TIME

GOTO :

PBC

With the PBC function on, choosing a song on a CD can only be done when at the main menu. With the PBC function off, song selections can be made by entering the relevant number keys. The format content of the disc will appear when the PBC button is pressed while a DVD disc is playing.

PBC

DISK TOTAL TITLES: 12 PLAY ENTRIES: 21 PLAY TIME: 01:16:35 AUDIO STREAMS: 08 SUBPIC STREAMS: 08 MPG2.NTSC 4:3/16:9 LB/PS AC3-2 AC3-5.1

A-B Repeat

The A-B repeat function allows you to reshow sections between two specific points (A and B) on a disc.

1. Press the A-B button while the disc is playing to set point A, the beginning spot.

Repeat Play

This DVD receiver allows repeated playback of specific titles, chapters/tracks, or segment. It even allows switching between two items that are being repeated.

1. Select the item to repeat.

2. Press the REPEAT key.

REPEAT

CHAPTER REPEAT ON

REPEAT ONE

REPEAT ALL

Ö÷ÒôÏä

Main speaker

Subwoofer speaker

Center speaker

Model No.:

DP1800 MADE IN CHINA

Main speaker

Used by North America only!

50X15mm

C US

LISTED

DOUBLE INSULATIONWHEN SERVICING USE ONLY

IDENTICAL REPLACEMENT PARTS. HongPu International Development(Shanghai) Co., Ltd. Plant 25, No.30 FuTeDongSan RD WaiGaoQiao Free Trade Zone PuDong Shanghai.P.R.C.

Audio/Video Apparatus

58WJ

221338

110V~60Hz110V~60Hz

CAUTION

ATTENTION

RISQUE D ELECTROCUTION

RISK OF ELECTRIC SHOCK

NE PAS OUVRIR

DO NOT OPEN

WARNING: SHOCK HAZARD- DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUE- NE PAS OUVRIR

Surround speaker Surround speaker

CONNECTING ANTENNA

FUNCTIONS

Radio signals may be difficult to receive in some buildings and under certain conditions. The provided antennas will help in their reception.They are intended for indoor use only.

AM Loop Antenna The placement of the AM loop antenna should be in a direction that provides the clearest reception. Keep as far as possible from DVD receiver, TV set, and speaker and power cords. If reception remains poor, an outdoor antenna may be necessary.

To connect the AM loop antenna:

1.Hold down handle

2.Insert wire end into hole

3.Release handle Position for best reception

FM Indoor Antenna

The FM antenna should be fully extended and in a direction that provides the clearest signal. Secure the antenna ends in a location where distortion is a minimum. If reception remains poor, an outdoor antenna may be necessary.

To connect the FM antenna:

1.Open cable terminal by pressing back on tab

2.Insert wire end

3.Release tab; make sure wire is in terminal securely

Outdoor AM antenna

Coaxial cable(75 ohm)

Coaxial cable (75 ohm)

Outdoor FM antenna

N/P

This Norcent DVD receiver supports output of various systems, including auto, NTSC, and PAL. The picture will blink and become colorless when the wrong system is selected. If this occurs, press the N/P key on the remote control,then select the correct system (NTSC for North America, PAL for Europe). For more information on output format, refer to the TV set's manufacturer's instructions.

Subtitles

The unit has the capability to display subtit les in any of 32 different languages.

1. Press the SUBTITLE key. The subtitle menu will appear. Scroll to the desired lang uage, then press the SUBTITLE key again.

SUBTITLE 02/08 ENGLISH

SUBTITLE

2. To remove the subtitles from view, press the SUBTITLE key until they disappear.

SUBTITLE OFF

Note: The disc being played must be multi subtitle encoded.

Camera Angle

The ability to change the camera angle allows viewer to play director and watch a movie from different perspectives.

1. Press the ANGLE key on the remote control. With each press, the camera angle changes.

2. The key may be pressed only when the flashing angle icon appears in the unit's display panel.

ANGLE

Note: Camera angle may be changed only in discs with multi-angle capability encoded into them.

1/4

Language

The unit has the capability to show movies in one of eight languages.

1. Press the LANGUAGE key. The language menu will appear. Scroll to the desired language, then press the LANGUAGE key again.

LANGUAGE

Note: The disc being played must be multi-language encoded.

LOCATING A TITLE

DVD discs are normally divided into titles, which are then sub-divided into chapters. A specific title can be easily found with this unit. Specific titles can be found using either the title menu function, if the DVD disc contains a title menu, or through its unique title number.

Title Menu Function

1. Press the TITLE/RETURN key. The title menu will appear on the TV screen.

2. Press the appropriate scroll key to select the desired title. A title may also be located by pressing its assigned number with the number buttons.

3. Press the TITLE/RETURN key again. This will start playback from chapter 1 of the selected title.

Note: Some discs do not respond to this function. If different instructions appear on the TV screen, follow those instructions. The Instructions given here describe the basic procedure. Procedures may vary depending on the content of the DVD disc.

Title Number

1. Press the appropriate numbers in the number section of the remote control. For example, for title 15, press the 10 and the 5 keys; for title 25,press the 10, 10, 5 keys.

AUDIO 1/8 AC-3 2CH ENGLISH

BASIC DVD OPERATION

FUNCTIONS

CONNECTING POWER SUPPLY

FF2X

FR2X

REV

To activate either function, simply press the FWD key or REV key on the remote control. The speed changes each time the key is pressed. To resume normal playback, press the PLAY key.

Memory Playback

This unit allows the viewer to stop playback, then later continue playback from that exact disc location. Press the STOP key to halt playback. The unit then will memorize the location where playback was stopped. To resume watching, press the RESUME key and the unit will resume playback from the exact location where playback was stopped.

Screen Display

While a disc is playing, the status of various functions may be checked, such as the tile, track number, and several time categories.

1. Press the DISPLAY key once and the title appears along with the chapter and how much time has played.

DISPLAY

2. Press the DISPLAY key again and the remaining time for that particular title appears.

3. Press the DISPLAY key again and the total elapsed time for that particular title appears.

TITLE 01/02 CHAPTER 02/028 00:21:05

SINGLE REMAIN 01 44 34

TOTAL ELAPSED

POWER

DP1800

DVD & AMPLIFIER SYSTEM

Before plugging the power cord into the AC outlet, check to make sure all of the connections have been properly completed. When they have been, carefully plug power cord into outlet.

Press the POWER button on the front panel to power the unit. The display panel will light. When the unit is initially powered, a brief surge of electricity may cause interference with other

electronic equipment on the same circuit. If this occurs, connect the unit to an outlet on a different circuit.

DVD/CD/MP3/CD-R/CD-RW

RESUME

Slow Motion

This Norcent DVD receiver has the ability to play discs in slow motion in either forward or reverse direction. Each time the SLOW key is pressed, the speed will slow from 1/2, to 1/4, to 1/8 normal speed. To resume normal playback, press the PLAY key.

SLOW

PLAY

4. Press the DISPLAY key again and the total remaining time for that particular title appears.

TOTAL REMAIN

5. Press the DISPLAY key again and the display turns off.

BASIC OPERATION

Selecting Sound Source

1. Press any function button (DVD, AM/FM,

VCR, AUX) to select the desired sound source. The appropriate symbol will appear in the display.

2. When the AM/FM tuner button is pressed, the last station listened to will play.

Note: The desired program source will not play unless it and the selected signal button coincide with the active program source signal input.

Volume Control

The volume may be adjusted by either turning the large volume knob on the front panel or using the appropriate volume button on the remote control.

Mute Pressing the MUTE button temporarily mutes every speaker. To resume audio, press MUTE button again.

PLAYING THE RADIO

BASIC DVD OPERATION

DP1800

DVD & AMPLIFIER SYSTEM

DVD/CD/MP3/CD-R/CD-RW

Positioning

1.Press TUNER button to select desired wave band (AM or FM).

2.Press UP or DOWN button to find a station. The frequency will change with each press. When a station's signal is received, it will appear in the display.

3.To lock onto a station quickly, hold the UP or DOWN button for two seconds. The unit will start automatic tuning. When a station is found, automatic tuning stops.

4.To add a station to memory, press the MEMO button. The memory storage number will blink for four seconds in the display. Press MEMO again to store the station.

Memory number

Wave band

Station frequency

5. To reduce noise when an FM-stereo program has been received, press the FM button. The word STEREO will disappear from the display. The program is now heard in monographic form, reducing the noise. To resume stereo play, press the FM button again.

TUNER

LANGUAGEANGLE

PROG L/R

DISPLAY

ENTER

PAUSE

MUTE

AUX 1 AUX 2

VOLUME

SLOW

PRE/TUN

REPEAT

PLAY

DOWN

TIME

A-B

OPEN/CLOSE

DVD

N/P

SUBTITLE

+10

TITLE

FM MODE

SETUP

PBC STEP ZOOM RESUME

STOP

MEMO AUTO

Automatic Tuning

This unit will store up to 30 individual AM and 30 individual FM radio stations in its memory.

1.Press the AUTO button. The word AUTO will appear in the display and the automatic tuning mode is activated.

2.Stations will be stored in ascending order until 30 stations of that particular wave band have been saved. When a station is stored, the memory storage number, as well as the station's frequency, will flash for four seconds in the display.

3.When the total number of stations reaches 30, in a particular wave's (AM or FM) memory, no further station in that wave band will be saved.

To Play Preset Stations

1.Press the TUNER button to select the desired wave band.

2.Press the PRE/TUN button.

3.Press any of the numbered buttons to select the desired station's memory number. For example, to play the station at memory #5, simply press the 5 button; for memory #17, press the 10 button followed by the 7 button.

4.Stations in the memory function may also be accessed by pressing the UP or DOWN button.

Once the unit is connected to a television set and any other accessory equipment, you are ready to enjoy the excitement of DVD videos or your favorite CDs and MP3 files.

To play a DVD video disc:

Turn on the TV and select the A/V mode. If the set features an S-Video connection, be sure the S-Video mode is selected from the TV menu. Turn on amplifier, if connected. Select AC-3 or DVD mode.

To play an audio disc:

Turn on the audio system and choose the input source that is connected to the DVD player. Set the AUDIO OUTPUT to DIGITAL OUTPUT OFF from the SETUP MENU display if you don't have the proper equipment for Dolby Digital surround sound.

1. Press the POWER key on front panel.

¡°DISC LOADING¡± appears on screen.

DISC LOADING

POWER

If there is no disc, NO DISC shown on screen:

NO DISC

2. Press the OPEN/CLOSE key. The disc tray will open.

OPEN/CLOSE

OPEN

3. Place the disc on the disc tray. Be sure play side is face down on the tray.

4. Press OPEN/CLOSE key to close tray. The disc tray will close. The disc type will appear in the upper-left-hand corner of the screen.

Once it has read the disc, the unit automatically will begin playback. When playing a DVD, the DVD or title menu will appear. CD tracks are played in sequence.

Note: It is possible to damage a disc if it is not placed correctly on the guides in the disc tray. This may also cause the DVD player to malfunction. Do not force or place anything other than a 5 DVD or CD onto the disc tray.

Never move the DVD player during playback, as this may cause damage to the disc as well as the player. To open and close the disc tray, only use the OPEN/CLOSE key found on both the remote control and on the unit's front panel.

PLAY

Press PAUSE key:

PAUSE

Press PREV key:

Press NEXT key:

PAUSE

Fast Forward/Reverse Playback The unit features both fast forward and fast reverse playback. Either mode will speed up: DVD disc playing 2x, 4x, 6x, 8x, or 20x normal play speed; MP3 disc playing 2x, 4x, 6x, 8x normal play speed; and other disc playing 2x, 3x, or 4x normal play speed.

Norcent DP1800 Operating Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
