PAMS Technical Documentation
NSE–6 Series Transceivers
Chapter 2
General Information
Original 08/98
NSE–6
PAMS
General Information
CONTENTS
Product Selection 2 – 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handportables 2 – 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Desktop Option 2 – 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product and Module List 2 – 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Specifications 2 – 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications of Transceiver NSE–6 2 – 6. . . . . . . . . . . .
Technical Documentation
Page 2 – 2
Original 08/98
PAMS
NSE–6
Technical Documentation
Product Selection
Handportables
The NSE–6 is a handportable mobile telephone for the GSM network.
1.
General Information
ACP–7E
2.
3.
Item Name: Type code: Material code:
1. Transceiver See variant Appendices
2. Standard battery (NiMH 600 mAh) BMP–1D 0670240
3. AC Travel Charger (Euro plug) 207–253 Vac ACP–7E 0675144
4. AC Travel Charger (US plug) 108–132 Vac ACP–7U 0675143
AC Travel Charger
5. AC Travel Charger (UK plug) 207–253 Vac ACP–7X 0675145
AC Travel Charger (UK plug) 180–220 Vac ACP–7H 0675146
6. AC Travel Charger (Australia) 216–264 Vac ACP–7A 0675148
(US plug) 198–242 Vac ACP–7C 0675158
ACP–7U
ACP–7C
ACP–7X
ACP–7H
ACP–7A
4.
5.
6.
Original 08/98
Page 2 – 3
NSE–6
PAMS
General Information
Desktop Option
The desktop option allows the user to charge the handportable and spare
battery from mains.
2.
3.
Technical Documentation
6.
7.
4.
1.
8.
5.
9.
Item Name: Type code: Material code:
1. Desktop stand CGE–1 0675180
2. AC Travel Charger (Euro plug) 207–253 Vac ACP–7E 0675144
3. AC Travel Charger (US plug) 108–132 Vac ACP–7U 0675143
AC Travel Charger
(US plug) 198–242 Vac ACP–7C 0675158
4. AC Travel Charger (UK plug) 207–253 Vac ACP–7X 0675145
AC Travel Charger
(UK plug) 180–220 Vac ACP–7H 0675146
5. AC Travel Charger (Australia) 216–264 Vac ACP–7A 0675148
6. Performance Travel Chg. (Euro plug) 90–264 Vac ACT–1E 0675183
7. Performance Travel Chg.
(US plug) 90–264 Vac ACT–1U 0675184
8. Performance Travel Chg. (UK plug) 90–264 Vac ACT–1X 0675185
9. Performance Travel Chg .(Australia) 90–264 Vac ACT–1A 0675186
Page 2 – 4
Original 08/98
PAMS
NSE–6
Technical Documentation
Product and Module List
Unit/type: Product code:
Transceiver NSE–6 See variant
Standard Battery BMP–1D 600 mAh NiMH, black 0670240
Glossy Chrome Battery BMP–1A 600 mAh NiMH 0670230
AC Travel Charger ACP–7E (EUR) 207–253 Vac 0675144
AC Travel Charger ACP–7U (US) 108–132 Vac 0675143
AC Travel Charger ACP–7C (US) 198–242 Vac 0675158
AC Travel Charger ACP–7X (UK) 207–253 Vac 0675145
AC Travel Charger ACP–7H (UK) 180–220 Vac 0675146
AC Travel Charger ACP–7X (AUS) 216–264 Vac 0675148
Performance Travel Charger ACT–1E (EUR)
90–264 Vac
General Information
Appendixes
0675183
Performance Travel Charger ACT–1U (US)
90–264 Vac
Performance Travel Charger ACT–1X (UK)
90–264 Vac
Performance Travel Charger ACT–1A (AUS)
90–264 Vac
Cigarette Lighter Charger LCH–9 0675120
Desktop Stand CGE–1 0675180
Headset HDC–9 0694053
0675184
0675185
0675186
Original 08/98
Page 2 – 5
NSE–6
PAMS
General Information
Technical Documentation
Technical Specifications
General Specifications of Transceiver NSE–6
Parameter Unit
Cellular system GSM
RX frequency band 935 ... 960 MHz
TX frequency band 890 ... 915 MHz
Output power +5 ...+33 dBm / 3.2 mW ... 2 W
Duplex spacing 45 MHz
Number of RF channels 124
Channel spacing 200 kHz
Number of TX power levels 15
Sensitivity, static channel –102 dBm/ BER < 2.439 %
Frequency error, static channel < 0.1 ppm
RMS phase error < 5.0
Peak phase error < 20.0
o
o
Page 2 – 6
Original 08/98
