Nokia 5220 User Guide

Nokia 5220 XpressMusic User Guide

9208682

Issue 1

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this RM-411 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/ declaration_of_conformity/.

Nokia, Nokia Connecting People and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTEN TS OF T HIS DOC UMENT A RE PRO VIDED " AS IS". EXCEP T AS REQ UIRED BY APPL ICABL E LAW, N O WARRA NTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WIT HOUT PRIOR NOTICE.

The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. Th is device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.

Model number: 5220

9208682/Issue 1

Safety...........................................7

Predictive text input...............................20

1. General information................8

About your device......................................8

Network services.......................................8

Access codes...............................................8

Configuration setting service...................9

My Nokia.....................................................9

Download content.....................................9

Helpful hints.............................................10

Software updates....................................10

Nokia support..........................................10

Digital rights management....................11

2. Get started.............................11

Install SIM card and battery....................11

Insert a microSD card..............................12

Remove the memory card......................13

Charge the battery..................................13

Antenna....................................................13

Headset.....................................................13

Attach a lanyard......................................14

Keys and parts.........................................15

Switch the phone on and off..................16

Standby mode..........................................16

Display...................................................16

Active standby.......................................16

Shortcuts in the standby mode...........17

Indicators..............................................17

Flight mode..............................................17

Keypad lock..............................................18

Functions without a SIM card.................18

3. Calls.......................................18

Make a call................................................18

Incoming call...........................................19

Dialling shortcuts....................................19

Voice dialling...........................................19

Options during a call...............................19

4. Write text..............................20

Text modes...............................................20

Traditional text input..............................20

5. Navigate the menus..............21

6. Messaging..............................21

Text and multimedia messages.............21

Text messages......................................21

Multimedia messages..........................22

Create a text or multimedia

message.................................................22

Read a message and reply...................23

Send messages......................................23

E-mail........................................................23

E-mail setup wizard..............................23

Write and send an e-mail....................24

Read an e-mail and reply.....................24

New e-mail notifications.....................24

Flash messages........................................24

Nokia Xpress audio messages................25

Instant messaging...................................25

Info messages, SIM messages, and

service commands...................................25

Voice messages........................................25

Message settings.....................................26

7. Contacts.................................26

Manage contacts......................................26

Business cards..........................................27

Assign dialling shortcuts........................28

8. Call log ..................................28

9. Position log...........................28

10. Connectivity.........................28

Bluetooth wireless technology..............28

Packet data..............................................29

USB data cable.........................................30

Synchronisation and backup..................30

Nokia PC Suite..........................................30

11. Settings...............................30

Profiles......................................................30

Themes.....................................................31

Tones........................................................31

Lights........................................................31

Display......................................................31

Date and time..........................................31

My shortcuts.............................................32

Left and right selection keys...............32

Other shortcuts.....................................32

Call.............................................................32

Phone........................................................33

Voice commands.....................................33

Enhancements.........................................34

Configuration...........................................34

Software updates over the air...............34

Security.....................................................35

Restore factory settings..........................36

12. Operator menu....................36

13. Gallery.................................36

Folders and files......................................36

Print images.............................................36

Memory card............................................36

14. Media...................................37

Camera and video....................................37

Take a picture.......................................37

Record a video clip...............................38

Camera and video options...................38

Music player.............................................38

Music menu...........................................38

Play music tracks..................................39

Change the music player look.............39

Radio.........................................................39

Tune in to radio stations.....................40

Radio features.......................................40

Voice recorder..........................................40

Equaliser...................................................41

Stereo widening......................................41

15. Web ....................................41

Connect to a service................................42

Appearance settings...............................42

Cache memory.........................................42

Browser security......................................42

Contents

16. Organiser.............................43

Alarm clock...............................................43

Calendar....................................................43

Maps..........................................................44

Download maps....................................44

Maps and GPS........................................44

Extra services........................................45

To-do list..................................................45

Notes.........................................................45

Calculator.................................................45

Countdown timer....................................46

Stopwatch................................................46

17. Applications.........................46

Launch an application.............................46

Download an application.......................47

18. SIM services.........................47

Enhancements...........................48

Battery.......................................48

Battery and charger information...........48

Nokia battery authentication

guidelines.................................................49

Authenticate hologram........................49

What if your battery is not

authentic?..............................................50

Care and maintenance..............50

Disposal....................................................51

Additional safety

information...............................51

Small children..........................................51

Operating environment..........................51

Medical devices........................................52

Implanted medical devices..................52

Hearing aids..........................................52

Vehicles.....................................................52

Potentially explosive

environments...........................................53

Emergency calls.......................................53

CERTIFICATION INFORMATION

(SAR)..........................................................54

Contents

Index.........................................55

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN RESTRICTED AREAS

Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

1. General information

About your device

The wireless device described in this guide is approved for use on the GSM 900, 1800, and 1900 MHz networks. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights.

Your device may have preinstalled bookmarks and links for third-party internet sites. You may also access other third-party sites through your device. Third-party sites are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you choose to access such sites, you should take precautions for security or content.

Warning: To use any features in this device, other than the alarm clock, the

device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.

Remember to make back-up copies or keep a written record of all important information stored in your device.

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

Network services

To use the phone you must have service from a wireless service provider. Many of the features require special network features. These features are not available on all networks; other networks may require that you make specific arrangements with your service provider before you can use the network services. Your service provider can give you instructions and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have a special configuration such as changes in menu names, menu order, and icons. Contact your service provider for more information.

Access codes

To set how your phone uses the access codes and security settings, select Menu > Settings > Security > Access codes.

● The PIN (UPIN) code, supplied with the SIM (USIM) card, helps to protect the card against unauthorised use.

General information

● The PIN2 (UPIN2) code, supplied with some SIM (USIM) cards, is required to access certain services.

● PUK (UPUK) and PUK2 (UPUK2) codes may be supplied with the SIM (USIM) card. If you enter the PIN code incorrectly three times in succession, you are asked for the PUK code. If the codes are not supplied, contact your service provider.

● The security code helps to protect your phone against unauthorised use. You can create and change the code, and set the phone to request the code. Keep the code secret and in a safe place separate from your phone. If you forget the code and your phone is locked, your phone will require service and additional charges may apply. For more information, contact a Nokia Care point or your phone dealer.

● The barring password is required when using the call barring service to restrict calls to and from your phone (network service).

● To view or change the security module settings for the web browser, select Menu > Settings > Security > Security module sett..

Configuration setting service

To use some of the network services, such as mobile internet services, the multimedia messaging service (MMS), Nokia Xpress audio messaging, or remote internet server synchronisation, your phone needs the correct configuration settings. For more information on availability, contact your service provider or the nearest authorised Nokia dealer, or visit the support area on the Nokia website.

support", p. 10.

When you have received the settings as a configuration message and the settings are not automatically saved and activated,

To save the settings, select Show > Save. If required, enter the PIN code supplied by the service provider.

Configuration settings received is displayed.

See "Nokia

My Nokia

Receive free tips, tricks, and support for your Nokia phone, plus free trial content, interactive demonstrations, a personalised web page, and news about the latest Nokia products and services.

Get the most out of your Nokia phone and register to My Nokia today! For more information and availability in your region, see www.nokia.com/mynokia.

Download content

You may be able to download new content (for example, themes) to your phone (network service).

Important: Use only services that you trust and that offer adequate security and

protection against harmful software.

General information

For the availability of different services and pricing, contact your service provider.

Helpful hints

If you have queries with your phone, or you are unsure how your phone should function, refer to the user guide. If this does not help, try the following:

● Reset the phone: switch off the phone, and remove the battery. After a few seconds, insert the battery, and switch on the phone.

● Restore the factory settings.

● Update your phone software with the Nokia Software Updater application, if

available.

● Visit a Nokia website, or contact Nokia Care.

If a query remains unresolved, contact your local Nokia Care point for repair options. Before sending your phone for repair, always back up or make a record of data in your phone.

See "Software updates", p. 10.

See "Restore factory settings", p. 36.

See "Nokia support", p. 10.

Software updates

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. You may be able to request these updates through the Nokia Software Updater PC application. To update the device software, you need the Nokia Software Updater application and a compatible PC with Microsoft Windows 2000, XP or Vista operating system, broadband internet access, and a compatible data cable to connect your device to the PC.

To get more information and to download the Nokia Software Updater application, visit www.nokia.com/softwareupdate or your local Nokia website.

If software updates over the air are supported by your network, you may also be able to request updates through the phone.

See "Software updates over the air", p. 34.

Important: Use only services that you trust and that offer adequate security and

protection against harmful software.

Nokia support

Check www.nokia.com/support or your local Nokia website for the latest version of this guide, additional information, downloads, and services related to your Nokia product.

Configuration settings service

Download free configuration settings such as MMS, GPRS, e-mail, and other services for your phone model at www.nokia.com/support.

Nokia PC Suite

You may find PC Suite and related information on the Nokia website at www.nokia.com/ support.

Get started

Nokia Care services

If you need to contact Nokia Care services, check the list of local Nokia Care contact centres at www.nokia.com/customerservice.

Maintenance

For maintenance services, check your nearest Nokia Care point at www.nokia.com/ repair.

Digital rights management

Content owners may use different types of digital rights management (DRM) technologies to protect their intellectual property, including copyrights. This device uses various types of DRM software to access DRM-protected content. With this device you can access content protected with WMDRM 10, OMA DRM 1.0, OMA DRM 1.0 forward lock, and OMA DRM 2.0. If certain DRM software fails to protect the content, content owners may ask that such DRM software's ability to access new DRM-protected content be revoked. Revocation may also prevent renewal of such DRM-protected content already in your device. Revocation of such DRM software does not affect the use of content protected with other types of DRM or the use of non-DRM-protected content.

Digital rights management (DRM) protected content comes with an associated activation key that defines your rights to use the content.

If your device has OMA DRM-protected content, to back up both the activation keys and the content, use the backup feature of Nokia PC Suite. Other transfer methods may not transfer the activation keys which need to be restored with the content for you to be able to continue the use of OMA DRM-protected content after the device memory is formatted. You may also need to restore the activation keys in case the files on your device get corrupted.

If your device has WMDRM-protected content, both the activation keys and the content will be lost if the device memory is formatted. You may also lose the activation keys and the content if the files on your device get corrupted. Losing the activation keys or the content may limit your ability to use the same content on your device again. For more information, contact your service provider.

2. Get started

Install SIM card and battery

Always switch the device off and disconnect the charger before removing the battery.

This phone is intended for use with a BL-5CT battery. Always use original Nokia batteries.

See "Nokia battery authentication guidelines", p. 49.

The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

Get started

1. Press the release

button to lift the back cover and remove it. Remove the battery to unlock the SIM card holder. Open the memory card cover.

2. Insert the SIM card with the contact surface facing

down into the holder.

3. Observe the battery contacts, and insert the battery.

Close the memory card cover, and replace the back cover.

Insert a microSD card

Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.

Your phone supports microSD cards up to 2 GB.

1. Open the cover

of the memory card slot.

2. Insert the card

into the memory card slot with the contact surface facing

Get started

down, and press until it locks into place.

Remove the memory card

Important: Do not remove the memory card in the middle of an operation when

the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

You can remove or replace the memory card card during phone operation without switching the device off.

1. Ensure that no application is currently accessing the memory card.

2. Open the cover of the memory card slot.

3. Press the memory card slightly in to release the lock, and remove it.

Charge the battery

1. Connect the charger to a wall socket.

2. Connect the lead from the charger to the charger connector of your phone.

If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

The charging time depends on the charger used. Charging a BL-5CT battery with the AC-3 charger takes approximately 1 hour 30 minutes while the phone is in the standby mode.

Antenna

Your device may have internal and external antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contact with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed and may reduce the battery life.

The figure shows the antenna area marked in grey.

Headset

Warning: Listen to music at a moderate level. Continuous exposure to high

volume may damage your hearing. Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.

Get started

Warning: When you use the headset, your ability to hear outside sounds may

be affected. Do not use the headset where it can endanger your safety. When connecting any external device or any headset, other than those approved by

Nokia for use with this device, to the Nokia AV Connector, pay special attention to volume levels.

Do not connect products that create an output signal as this may cause damage to the device. Do not connect any voltage source to the Nokia AV Connector.

Attach a lanyard

Fix a strap through the eyelet, and tighten it.

Keys and parts

1 Earpiece 2 Charger connector

3 Music key (rewind) 4 Music key (play/pause)

5 Music key (fast forward) 6 Left selection key

7 Call key 8 Keypad

9 Eyelet for lanyard 10 Display

11 Navi™ key; hereafter referred to as

scroll key

13 Power key and end key 14 Memory card slot

15 Volume down key 16 Volume up key

17 Mini USB cable connector 18 Nokia AV Connector (3.5 mm)

19 Back cover release button 20 Camera lens

21 Effect light 22 Loudspeaker

12 Right selection key

Get started

Switch the phone on and off

To switch the phone on or off, press and hold the power key.

If the phone prompts for a PIN code, enter the code (displayed as ****).

If the phone prompts you for the time and date, enter the local time, select the time zone of your location in terms of the time difference with respect to Greenwich Mean Time (GMT), and enter the date.

When you switch on your phone for the first time, you may be prompted to get the configuration settings from your service provider (network service). For more information, refer to Connect to support. See

"Configuration setting service", p. 9.

See "Date and time", p. 31.

"Configuration", p. 34, and

Standby mode

When the phone is ready for use, and you have not entered any characters, the phone is in the standby mode.

Display

Signal strength of the cellular network

Battery charge status

3 Indicators

4 Name of the network or the operator logo

5 Clock

6 Display

7 Function of the left selection key

8 Function of the Navi key

9 Function of the right selection key

You may change the function of the left and right selection key. See "Left and right

selection keys", p. 32.

Active standby

The active standby mode displays a list of selected phone features and information that you can directly access.

To activate or deactivate the active standby mode, select Menu > Settings >

Display > Active standby > Active standby mode.

Get started

In the active standby mode, scroll up or down to navigate in the list, and choose Select or View. The arrows indicate that further information is available. To stop navigation, select Exit.

To organise and change the active standby mode, select Options and from the available options.

Shortcuts in the standby mode

To access a list of numbers you have dialled, press the call key once. To call a number from the list, scroll to the number or name, and press the call key.

To open the web browser, press and hold 0.

To call your voice mailbox, press and hold 1.

You can use keys as shortcuts.

See "Dialling shortcuts", p. 19.

Indicators

You have unread messages.

You have unsent, cancelled, or failed messages.

You have missed calls.

The keypad is locked.

The phone does not ring for an incoming calls or text messages.

An alarm is set.

/ The phone is registered to the GPRS or EGPRS network.

/ The phone has an open GPRS or EGPRS connection.

/ The GPRS or EGPRS connection is suspended (on hold).

Bluetooth is turned on.

If you have two phone lines, the second phone line is selected.

All incoming calls are diverted to another number.

Calls are limited to a closed user group.

The currently active profile is timed.

Flight mode

Use the flight mode in radio sensitive environments—on board aircraft or in hospitals —to deactivate all radio frequency functions. You still have access to offline games, the

calendar, and phone numbers. When the flight mode is active,

is displayed.

+ 39 hidden pages
