Nokia 2780 Flip
User Guide
Isyu 2023-03-28 fil-PH
Nokia 2780 Flip User Guide
Talaan ng Nilalaman
1 Tungkol sa gabay para sa user na ito 4
2 Magsimula 5
Keys and parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Set up and switch on your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
I-charge ang iyong telepono . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Mga tawag, contact, at mensahe 10
Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Send messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Send mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 I-personalize ang iyong telepono 12
Change the ringtone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Change the look of your home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Personalize the shortcut key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Camera 14
Photos and videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 Internet at mga koneksyon 15
Browse the web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Bluetooth® connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7 Orasan, kalendaryo, at calculator 16
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 2
Nokia 2780 Flip User Guide
8 Copy content and check the memory 18
Kumopya ng nilalaman . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
File manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Security and privacy 19
Mga setting ng seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
10 Impormasyon ng produkto at kaligtasan 20
Para sa iyong kaligtasan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Mga emergency na tawag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Pangangalagaan ang iyong device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Recycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Simbolo ng nakaekis na basurahan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Impormasyon sa baterya at charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Maliliit na bata . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Mga medical na device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Mga naka-implant na medical na device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Pandinig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Protect your device from harmful content . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Mga Sasakyan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Mga kapaligirang potensyal na sumasabog . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Impormasyon ng sertipikasyon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Tungkol sa Digital Rights Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Copyrights and other notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 3
Nokia 2780 Flip User Guide
1 Tungkol sa gabay para sa user na ito
Mahalaga: Para sa mahalagang impormasyon tungkol sa ligtas na paggamit sa iyong device
at baterya, basahin ang “Impormasyon ng produkto at pangkaligtasan” bago mo gamitin ang
device. Para alamin kung paano magsimula sa bago mong device, basahin ang user guide.
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 4
Nokia 2780 Flip User Guide
2 Magsimula
KEYS AND PARTS
Your phone
This user guide applies to the following model: TA-1420.
1. Call key
2. Shortcut key
3. Left selection key
4. Scroll key
5. Earpiece
6. Right selection key
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 5
7. Back key
8. Power/ End key
9. Camera
10. Flash
11. Microphone
12. Back cover opening slot
Nokia 2780 Flip User Guide
13. Headset connector
14. Volume keys
15. SOS call key
16. USB connector
Do not connect to products that create an output signal, as this may damage the device. Do
not connect any voltage source to the audio connector. If you connect an external device
or headset, other than those approved for use with this device, to the audio connector, pay
special attention to volume levels. Parts of the device are magnetic. Metallic materials may be
attracted to the device. Do not place credit cards or other magnetic storage media near the
device, because info stored on them may be erased.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable,
may be sold separately.
Note: You can set the phone to ask for a security code to protect your privacy and personal
data. Press the scroll key and select Settings . Scroll right to Privacy & Security , and select
Screen Lock > Screen lock > On , and create a four-digit code. Note, however, that you
need to remember the code, as HMD Global is not able to open or bypass it.
SET UP AND SWITCH ON YOUR PHONE
Nano-SIM
Important: This device is designed to be used with a nano-SIM card only. Use of incompatible
SIM cards may damage the card or the device, and may corrupt data stored on the card.
Tandaan: I-off ang device at idiskonekta ang charger at anumang iba pang device bago
mag-alis ng anumang mga takip. Iwasang hawakan ang mga electronic na bahagi habang
pinapalitan ang anumang mga takip. Palaging iimbak at gamitin ang device nang nakakabit ang
anumang takip.
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 6
Nokia 2780 Flip User Guide
Open the back cover
1. Put your fingernail in the small slot at the bottom of the phone, lift and remove the cover.
2. If the battery is in the phone, lift it out.
Insert the SIM card
1. Slide the SIM card holder to the left and open it up.
2. Place the nano-SIM in the slot face down.
3. Close down the holder and slide it to the right to lock it in place.
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 7
Nokia 2780 Flip User Guide
Insert the memory card
1. Slide the memory card holder to the left
and open it up.
2. Place the memory card in the slot face
down.
Tip: Use a fast, up to 32 GB microSD memory card from a well-known manufacturer.
I-on ang iyong telepono
Pindutin at diinan ang key.
3. Close down the holder and slide it to the
right to lock it in place.
4. Put back the battery.
5. Put back the back cover.
I-CHARGE ANG IYONG TELEPONO
Ang iyong baterya ay na-charge nang bahagya sa factory, ngunit maaaring kailanganin mo itong
i-charge muli bago mo magamit ang iyong telepono.
I-charge ang baterya
1. Isaksak ang charger sa isang saksakan.
2. Ikonekta ang charger sa telepono. Kapag tapos na, alisin ang pagkakasaksak ng charger sa
telepono, pagkatapos ay alisin sa saksakan.
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 8
Nokia 2780 Flip User Guide
Kung ganap na nadiskarga ang baterya, maaaring tumagal nang ilang minuto bago lumabas ang
indicator ng pag-charge.
Tip: Maaari mong gamitin ang pag-charge gamit ang USB kapag walang available na saksakan.
Maaaring maglipat ng data habang china-charge ang device. Malaki ang pagkakaiba ng lakas
ng power ng pagcha-charge gamit ang USB, at maaaring matagal bago magsimula ang pagcharge at magsimulang gumana ang device. Tiyaking naka-on ang iyong computer.
KEYPAD
Use the phone keys
• To open the apps list, press the scroll key.
• To open an app or select a feature, press the scroll key right, left, up, or down to scroll to
the app or feature, and press the scroll key to select SELECT .
• To go back to the previous view, press the back key.
• To go back to the home screen, press .
Lock the keypad
To lock your keys, press and hold the * key, or close the fold. To unlock the keys, select
Unlock >
Write with the keypad
Press a key repeatedly until the letter is shown. To type in a space, press 0. To type in a
special character or punctuation mark, press * . To switch between character cases, press #
repeatedly. To type in a number, press and hold a number key.
© 2023 HMD Global Oy. Nakalaan ang lahat ng karapatan. 9
