Introduction
GT8 is the baseband/RF module NHE–5 cellular tranceiver. The GT8 module
carries out all the system and RF functions of the tranceiver. System module
GT8 is designed for a handportable phone, that operate in GSM system.
Technical Section
All functional blocks of the system module are mounted on a single multi layer
printed circuit board. The chassis of the radio unit has separating walls for
baseband and RF. All components of the baseband section are surface mountable. They are soldered using reflow. The connections to accessories are taken
through the bottom connector of the radio unit. The connections to the User Interface module (UIF) are fed through a connector. There is no physical connector between the RF and baseband sections.
External and Internal Connections
The system module has two connector, external bottom connector and internal
display module connector.
Technical Documentation
System Connector X103
S0001130
13
18
15
14
16
7
12
16
17 20
19
Page 4–4
Original 06/96
After Sales
NHE–5
Technical Documentation
Accessory Connector
Pin: Name: Description:
1 GND Digital ground
2 V_OUT Accessory output supply
3 XMIC External microphone input and accessory
ID Accessory identification
4 NC No connection
System Module
• min/typ/max: 3.25...10 V
(output current 50 mA)
identification
• nom/max: 8...50 mV (the maximum value
corresponds to 0 dBm network level with input
amplifier gain set to 20 dB, typical value is
maximum value –16 dB)
• 1.7...2.05 V headset adapter connected
• 1.15...1.4 V compact hadsfree unit connected
5 NC No connection
6 MBUS Serial control bus
• logic low level: 0...0.5 V
• logic high level: 2.4...3.2 V
7 NC No connection
8 SGND Signal ground
9 XEAR External audio output and mute control
• min/nom/max: 0...32...500 mV (typical level
corrensponds to –16 dBm0 network level with
volume control in nominal position 8 dB below
maximum. Maximum 0 dBm0 max. volume
codec gain –6 dB)
• mute on (HF speaker mute): 0...0.5 V d.c.
• mute off (HF speaker active): 1.0...1.7 V d.c.
10 HOOK Hook control, accessory connection detect
• hook off (handset in use) : 0...0.5 V
• hook on, (handset not in use): 2.4...3.2 V
11 NC No connection
12 V_IN Charging supply voltage
• max: 16 V
Original 06/96
Page 4–5
NHE–5
After Sales
System Module
Battery Connector
Pin: Name: Description:
13 BGND Battery ground
14 BSI Battery size indicator
15 BTEMP Battery temperature
16 VB Battery voltage
Charging connectors
Pin: Name: Description:
17, 19 V_IN Charging voltage input
Technical Documentation
(used also for SIM card detection)
• R2=47k pullup resistor in
(used also for vibration alert)
• 47 kΩ NTC in battery to gnd,
47 kΩ pullup in module
• min/typ/max: 5.3...6...8.6 V
• ACH–6 min/nom/max: 9.8...10.3...10.8 V
• ACH–8 min/nom/max: 12...14...16 V
module
18, 20 GND Charger ground
UI Connector X101
Pin: Name: Description:
1 EARP Earphone positive signal
2 EARN Earphone negative signal
3 VBKEY Battery supply
4 BUZZER Alert buzzer (audio codec PWM controlled)
5–7 ROW(0–2) Input
8–10 GND Shield ground
• min/typ/max: 0...14...220 mV (typical level
corrensponds to –16 dBm0 network level with
volume control giving nominal RLR (=+2 dB)
8 dB below maximum. Maximum 0 dBm0
with max. volume (codec gain –11 dB)
• min/typ/max: 0...14...220 mV (see above)
• min/max: 5.3...8.5 V
Page 4–6
11–13 ROW(3–5) Input
Original 06/96
After Sales
NHE–5
Technical Documentation
Pin: Name: Description:
14 LIGHTC Keyboard light
15–18 COL(0–3) Output
19 PWRKEY Power on/off
20 GND Digital ground
Flash Connector X103
Pin: Name: Description:
1 WDDIS Watchdog disable, signal pulled down to
2 FCLK Flash serial clock, test point J303
3 VPP Flash programming voltage
System Module
disable watchdog, test point J300
• min/typ/max: 11.4...12...12.6 V
(values when VPP active), test point J304
4 FTX Flash acknowledge transmit, test point J302
5 FRX Flash data receive, test point J301
SIM Connector X102
Pin: Name: Description:
1 GND Ground for SIM
2 VSIM SIM voltage supply
3 SDATA Serial data for SIM
4 SRES Reset for SIM
5 CLK Clock for SIM data (clock frequency minimum
• min/typ/max: 4.8...4.9...5.0 V
1 MHz if clock stopping not allowed)
Original 06/96
Page 4–7
NHE–5
After Sales
System Module
Baseband Block
Introduction
The GT8 module is used in NHE–5 products. The baseband is built around one
DSP, System ASIC and the MCU. The DSP performs all speech and GSM/PCN
related signal processing tasks. The baseband power supply is 3V except for
the A/D and D/A converters that are the interface to the RF section. The A/D
converters used for battery monitoring are integrated into the same device as
the signal processing converters.
The audio codec is a separate device which is connected to both the DSP and
the MCU. The audio codec support the internal and external microphone/earpiece functions. External audio is connected in a dual ended fashion to improve
audio quality together with accessories.
The baseband implementation support a 32 kHz sleep clock function for power
saving. The 32 kHz clock is used for timing purposes during inactive periods
between paging blocks. This arrangement allows the reference clock, derived
from RF to be switched off.
Technical Documentation
The baseband clock reference is derived from the RF section and the reference
frequency is 13 MHz. a low level sinusoidal wave form is fed to the ASIC which
acts as the clock distribution circuit. The DSP is running at 39 MHz using an internal PLL. The clock frequency supplied to the DSP is 13 MHz. The MCU bus
frequency is the same as the input frequency. The system ASIC provides both
13 MHz and 6.5 MHz as alternative frequencies. The MCU clock frequency is
programmable by the MCU. The baseband uses 6.5 MHz as the MCU operating frequency. The RF A/D, D/A converters are operated using the 13 MHz
clock supplied from the system ASIC
The power supply and charging section supplies several types of battery
technologies. such as , NiCd, NiMH and Lithium. The battery charging unit is
designed to accept constant current type chargers, that are approved by NMP.
The power supply IC contains three different regulators. The output voltage
from each regulator is 3.15V nominal. One of the regulator uses an external
transistor as the boost transistor.
Page 4–8
Original 06/96
After Sales
NHE–5
Technical Documentation
Modes of Operation
The baseband in operates in the following Modes
– Active, as during a call or when baseband circuitry is operating
– Sleep, in this mode the clock to the baseband is stopped and timing is kept
by the 32 KHz oscillator. All Baseband circuits are powered
– Acting dead, in this mode the battery is charged but only necessary func-
tions for charging are running
– Power off, in this mode all baseband circuits are powered off. The regulator
IC N301 is powered
Circuit Description
Power Supply
L308
CRFCONT
VBAT
5.3 ... 8.6 V
CHARGER
16.5 V max.
L301
CHARGND
BATGND
Not Assembled
L300
CHARGER
UNIT
N601
V305
AGND
L302
L304
L309
BGND
L310
L311
5,21,37
39,44
6,32
V450
41
VBAT to RF
Not Assembled
PSCLD
N301
35
VA
3.16 V
N200
VSIM
L451
4.50 V
40
VRF
N450
4,20,38
VSL
L152
L151
43
42
VSLRC
3.16 V
D151; pin 124
VSLC
D151
D402
D404
System Module
VB (to illumination leds)
V306
GND
3.16 V
VL
L306
L150
Not Assembled
L410
L153
VLDSP
D152
L450
VLCD
3.16 V3.16 V
VLC
3.16 V
D150
D400
VLCRAM
3.16 V
D410
D411
VLRFI
3.16 V
N450
The power supply for the baseband is the main battery. The main battery consists of 5 NiCd or NiMH cells with a nominal voltage of 6.0V. A charger input is
used to charge the battery. Two different chargers can be used for charging the
battery. A switch mode type fast charger that can deliver 780 mA and a standard charger that can deliver 265 mA. The idle voltage for the fast and standard
charger see NO TAG. Both chargers are of constant current type.
Original 06/96
Page 4–9
NHE–5
After Sales
System Module
The baseband has one power supply circuit, N301 delivering power to the different parts in the baseband. There are two logic power supply and one analog
power supply. The analog power supply VA is used for analog circuits such as
audio codec, N200 and microphone bias circuitry. Due to the current consumption and the baseband architecture the digital supply is divided into to parts.
Both digital power supply rails from the N301, PSCLD is used to distribute the
power dissipation inside N301, PSCLD. The main logic power supply VL has an
external power transistor, V306 to handle the power dissipation that will occur
when the battery is fully charged or during charging.
D151, ASIC and the MCU SRAM, D402/D403 are connected to the same logic
supply voltage. All other digital circuits are connected to the main digital supply.
The analog voltage supply is connected to the audio codec.
Charging Control Switch Functional Description
The charging switch transistor V304 controls the charging current from the
charger input to the battery. During charging the transistor is forced in saturation and the voltage drop over the transistor is 0.2–0.4V depending upon the
current delivered by the charger. Transistor V304 is controlled by the PWM output from N301, pin 23 via resistors R309, R308 and transistor V303. The output
from N301 is of open drain type. When transistor V304 is conducting the output
from N301 pin is low. In this case resistors R305 and R306 are connected in
parallel with R304. This arrangement increases the base current through V304
to put it into saturation.
Technical Documentation
Transistors V304, V302, V303 and V312 forms a simple voltage regulator circuitry. The reference voltage for this circuitry is taken from zener diode V301.
The feedback for the regulator is taken from the collector of V304. When the
PWM output from N301 is active, low, the feedback voltage is determined by
resistors R308 and R309. This arrangement makes the charger control switch
circuitry to act as a programmable voltage regulator with two output voltages
depending upon the state of the PWM output from N301. When the PWM is inactive, in high impedance the feedback voltage is almost the same as on the
collector of V304. Due to the connection the voltage on V303 and V302 emitters are the same. The influence of the current thru R305 and R306 can be neglected in this case.
The charging switch circuit diagram is shown in following figure. The figure is
for reference only.
Page 4–10
Original 06/96
After Sales
NHE–5
Technical Documentation
This feedback means that the system regulates the output voltage from V304 in
such a way that the base of V303 and V302 are at the same voltage. The voltage on V302 is determined by the V301 zener voltage. The darlington connection of V312 and V302 service two purposes 1 the load on the voltage reference V301 is decreased, 2 the output voltage on V304 is decreased by the
VBE voltage on V312 which is a wanted feature. The voltage reduction allows a
relative temperature stable zener diode to be used and the output voltage from
V304 is at a suitable level when the PWM output from N301 is not active.
System Module
The circuitry is self starting which means that an empty battery is initially
charged by the regulator circuitry around the charging switch transistor. The
battery is charged to a voltage of maximum 4.8V. This charging switch circuitry
allows for both NiCd, NiMH and Lithium type of batteries to be used.
When the PWM output from N301 is active the feedback voltage is changed
due to the presence of R308 and R309. When the PWM is active the charging
switch regulator voltage is set to 10.5V maximum. This means that even if the
voltage on the charger input exceeds 11.5V the battery voltage will not exceed
10.5 V. This protects N301 from over voltage even if the battery was to be detached while charging.
V305 is a schottky diode that prevents the battery voltage from reverse bias
V304 when the charger is not connected. The leakage current for V305 is increasing with increasing temperature and the leakage current is passed to
ground via R308, V303 and R304. This arrangement prevents V304 from being
reversed biased as the leakage current increases at high temperatures.
V300 is a 16V transient suppressor. V300 protects the charger input and in particular V304 for over voltage. The cut off voltage is 16V with a maximum surge
voltage up to 25V. V300 also protects the input for wrong polarity since the transient suppressor is bipolar.
Original 06/96
Page 4–11
NHE–5
After Sales
System Module
Power Supply Regulator PSCLD, N301
The power supply regulators are integrated into the same circuit N301. The
power supply IC contains three different regulators. The main digital power supply regulator is implemented using an external power transistor V306. The other two regulators are completely integrated into N301.
Technical Documentation
PSCLD, N301 External Components
N301 performs the required power on timing. The PSCLD, N301 internal power on and reset timing is defined by the external capacitor C330. This capacitor
determines the internal reset delay, which is applied when the PSCLD, N301 is
initially powered by applying the battery. The baseband power on delay is determined by C311. With a value of 10 nF the power on delay after a power on
request has been active is in the range of 50–150 ms. C310 determines the
PSCLD, N301 internal oscillator frequency and the minimum power off time
when power is switched off.
The sleep control signal from the ASIC, D151 is connected via PSCLD, N301.
During normal operation the baseband sleep function is controlled by the ASIC,
D151 but since the ASIC is not power up during the startup phase the sleep
signal is controlled by PSCLD, N301 as long as the PURX signal is active. This
arrangement ensures that the 13 MHz clock provided from RF to the ASIC,
D151 is started and stable before the PURX signal is released and the baseband exits reset. When PURX is inactive, high, sleep control signal is controlled
by the ASIC D151.
N301 requires capacitors on the input power supply as well as on the output
from each regulator to keep each regulator stable during different load and temperature conditions. C305 and C335 are the input filtering capacitors. Due to
EMC precautions a filter using C337, L310, C335, L311, C338 and C339 has
been inserted into the supply rail. This filter reduces the high frequency components present at the battery supply from exiting the baseband into the battery
pack. The regulator outputs also have filter capacitors for power supply filtering
Page 4–12
Original 06/96
After Sales
NHE–5
Technical Documentation
and regulator stability. A set of different capacitors are used to achieve a high
bandwith in the suppression filter.
PSCLD, N301 Control Bus
The PSCLD, N301 is connected to the baseband common serial control bus,
SCONB(5:0). This bus is a serial control bus from the ASIC, D151 to several
devices on the baseband. This bus is used by the MCU to control the operation
of N301 and other devices connected to the bus. N301 has two internal 8 bit
registers and the PWM register used for charging control. The registers contain
information for controlling reset levels, charging HW limits, watchdog timer
length and watchdog acknowledge.
The control bus is a three wire bus with chip select for each device on the bus
and serial clock and data. From PSCLD, N301 point of view the bus can be
used for writing only. It is not possible to read data from PSCLD, N301 by using
this bus.
The MCU can program the HW reset levels when the baseband exits/enters reset. The programmed values remains until PSCLD is powered off, the battery is
removed. At initial PSCLD, N301 power on the default reset level is used. The
default value is 5.1 V with the default hysteresis of 400 mV. This means that reset is exit at 5.5 V when the PSCLD, N301 is powered for the first time.
System Module
The watchdog timer length can be programmed by the MCU using the serial
control bus. The default watchdog time is 32 s with a 50 % tolerance. The complete baseband is powered off if the watchdog is not acknowledged within the
specified time. The watchdog is running while PSCLD, N301 is powering up the
system but PURX is active. This arrangement ensures that if for any reason the
battery voltage doesn’t increase above the reset level within the watchdog time
the system is powered off by the watchdog. This prevents a faulty battery from
being charged continuously even if the voltage never exceeds the reset limit.
As the time PURX is active is not exactly known, depends upon startup condition, the watchdog is internally acknowledged in PSCLD when PURX is released. This gives the MCU always the same time to respond to the first watchdog acknowledge.
Baseband power off is initiated by the MCU and power off is performed by writing the smallest value to the watchdog timer register. This will power off the
baseband within 0.5 ms after the watchdog write operation.
The PSCLD, N301 also contains switches for connecting the charger voltage
and the battery voltage to the baseband A/D converters. Since the battery voltage is present and the charger voltage might be present in power off the A/D
converter signals must be connected using switches. The switch state can be
changed by the MCU via the serial control bus. When PURX is active both
switches are open to prevent battery/charger voltage from being applied to the
baseband measurement circuitry which is powered off. Before any measurement can be performed both switches must be closed by MCU.
Original 06/96
Page 4–13
NHE–5
After Sales
System Module
Charger Detection
A charger is detected if the voltage on N301 pin 28 is higher than 0.5V. The
charger voltage is scaled externally to PSCLD, N301 using resistors R302 and
R303. With the implemented resistor values the corresponding voltage at the
charger input is 2.8V. Due to the multifunction of the charger detection signal
from PSCLD, N301 to ASIC, D151 the charger detection line is not forced ,active high until PURX is inactive. In case PURX is inactive the charger detection
signal is directly passed to D151. The active high on pin 14 generates and interrupt to MCU which then starts the charger detection task in SW.
SIM Interface and Regulator in N301
The SIM card regulator and interface circuitry is integrated into PSCLD, N301.
The benefit from this is that the interface circuits are operating from the same
supply voltage as the card, avoiding the voltage drop caused by the external
switch used in previous designs. The PSCLD, N301 SIM interface also acts as
voltage level shifting between the SIM interface in the ASIC, D151 operating at
3V and the card operating at 5V. Interface control in PSCLD is direct from
ASIC, D151 SIM interface using SIMI(5:0) bus. The MCU can select the power
supply voltage for the SIM using the serial control bus. The default value is 3V
which needs to be changed to 5V before power up the SIM interface in ASIC,
D151. Regulator enable and disable is controlled by the ASIC via SIMI(2). For
further operation of the SIM interface see section NO TAG.
Technical Documentation
Power Up Sequence
The baseband can be powered up in three different ways.
– When the power switch is pressed input pin 25 to PSCLD, N301 is con-
nected to ground and this switches on the regulators inside PSCLD.
– An other way to power up is to connect the charger. Connecting the charger
causes the baseband to power up and start charging the battery.
– The third way to power the system up is to attach the battery.
Page 4–14
Original 06/96
After Sales
NHE–5
Technical Documentation
PSCLD
N301
VBAT
Pwr
Switch
Watchdog
disable
CHARGER
UNITCHARGER
5,21,37
39,44
25
23
28
30
16,18,19
C310
VL VSL VA
40
35
26 120
17 130
14
13
CRFCONT
N601
Purx
Serial Bus
VCXO Enable
CHARGAlarm
1415
129
VCXO
SRAM, FLASH
D403 D400
22
13 MHz
Address Bus
ASIC
D151
Watchdog
Register
32 kHz
125 126
Data Bus
System Module
83
84
MCU Clock
82
MCU Reset
81
48 51
DSP Reset
DSP Clock
MCU
D150
Power up using Power on Button
This is the most common way to power the system up. This power up is successful if the battery voltage is higher than power on reset level set by the
MCU, default value 5.5V in PSCLD, N301. The power up sequence is started
when the power on input pin 25 at PSCLD is activated, low. The PSCLD then
internally enters the reset state where the regulators are switched on. At this
state the PWM output from PSCLD is forced active to support additional power
from any charger connected. The sleep control output signal is forced high enabling the regulator to supply the VCO and startup the clock. After the power on
reset delay of 50–150 ms PURX is released and the system exits reset. The
PWM output is still active until the MCU writes the first value to the PWM register. The watchdog has to be acknowledged within 16 s after that PURX has
changed to inactive state
Power Up with Empty Battery using Charger
When the charger is inserted into the DC jack or charger voltage is supplied at
the system connector surface contacts/pins PSCLD , N301 powers up the
baseband. The charging control switch is operating as a linear regulator, the
output voltage is 4.5V–5V. This allows the battery to be charged immediately
when the charger is connected. This way of operation guarantees successful
power up procedure with empty battery. In case of empty battery the only power source is the charger. When the battery has been initially charged and the
voltage is higher than the PSCLD, N301 switch on voltage the sleep control signal which is connected to the PSCLD for power saving function sleep mode,
enters inactive state, high, to enable the regulator that controls the power supply to the VCO to be started. The ASIC, D151 which normally controls the sleep
control line has the sleep output inactive, low as long as the system reset,
PURX is active, low, from PSCLD. After a delay of about 5–10 ms the system
Original 06/96
Page 4–15
NHE–5
After Sales
System Module
reset output PURX from PSCLD enters high state. This delay is to ensure that
the clock is stable when the ASIC exits reset. The sleep control output from the
PSCLD that has been driving an output until now, returns the control to the
sleep signal from the ASIC as the PURX signal goes inactive. When the PURX
signal goes inactive, high, the charge detection output at PSCLD, that is in input mode when PURX is active, switches to output and goes high indicating
that a charger is present. When the system reset, PURX, goes high the sleep
control line is forced inactive, high, by the ASIC, D151 via PSCLD, N301.
Once the system has exited reset the battery is initially charged until the MCU
writes a new value to the PWM in PSCLD. If the watchdog is not acknowledged
the battery charging is switched off when the PSCLD shuts off the power to the
baseband. The PSCLD will not enter the power on mode again until the charger
has been extracted and inserted again or the power switch has been pressed.
The battery is charged as long as the power on line, PWRONX is active low.
This is done to allow the phone to be started manually from the power button
with the charger inserted not having to extract the charger to get a power up if
the battery is empty.
Power On Reset Operation
Technical Documentation
The system power up reset is generated by the regulator IC, N301. The reset is
connected to the ASIC, D151 that is put into reset whenever the reset signal,
PURX is low. The ASIC, D151 then resets the DSP, D152 the MCU, D150 and
the digital parts in N450. When reset is removed the clock supplied to the ASIC,
D151 is enabled inside the ASIC. At this point the 32 kHz oscillator signal is not
enabled inside the ASIC, since the oscillator is still in the startup phase. To start
up the block requiring 32 kHz clock the MCU must enable the 32 kHz clock.
The MCU reset counter is now started and the MCU reset is still kept active,
low. 6.5 MHz clock is started to MCU in order to put the MCU, D150 into reset,
MCU is a synchronous reset device and needs clock to reset. The reset to
MCU is put inactive after 128 MCU clock cycles and MCU is started.
DSP, D152 and N450 reset is kept is kept active when the clock inside the
ASIC, D151 is started. 13 MHz clock is started to DSP, D152 and puts it into reset, D152 is a synchronous reset device and requires clock to enter reset.
N450 digital parts are reset asynchronously and do not need clock to be supported to enter reset.
As both the MCU, D151 and DSP, D152 are synchronous reset devices all interface signals connected between these devices and ASIC D151 which are
used as I/O are set into input mode on the ASIC, D151 side during reset. This
avoids bus conflicts to occur before the MCU, D150 and the DSP, D152 are actually reset.
Page 4–16
The DSP, D152 and N450 reset signal remains active after that the MCU has
exited reset. The MCU writes to the ASIC register to disable the DSP reset.
This arrangement allows the MCU to reset the DSP, D152 and N450 when ever
needed. The MCU can put DSP into reset by writing the reset active in the
ASIC, D151 register
Original 06/96
After Sales
NHE–5
Technical Documentation
MCU
The baseband uses a Hitachi H3001 type of MCU. This is a 16–bit internal
MCU with 8–bit external data bus. The MCU is capable of addressing up to 16
MByte of memory space linearly depending upon the mode of operation. The
MCU has a non multiplexed address/data bus which means that memory access can be done using less clock cycles thus improving the performance but
also tightening up memory access requirements. The MCU is used in mode 3
which means 8–bit external data bus and 16 Mbyte of address space. The
MCU operating frequency is equal to the supplied clock frequency. The MCU
has 512 bytes of internal SRAM. The MCU has one serial channel, USART that
can operate in synchronous and asynchronous mode. The USART is used in
the MBUS implementation. Clock required for the USART is generated by the
internal baud rate generator. The MCU has 5 internal timers that can be used
for timing generation. Timer TIOCA0 input pin 71 is used for generation of netfree signal from the MBUS receive signal which is connected to the MCU
USART receiver input on pin 2.
The MCU contains 4 10–bit A/D converters channels that are used for baseband monitoring. For A/D converter channel usage see section NO TAG.
System Module
The MCU, D150 has several programmable I/O ports which can be configured
by SW. Port 4 which multiplexed with the LSB part of the data bus is used
baseband control. In the mode the MCU is operating this port can be used as
an I/O port and not as part of the data bus, D0–D7.
MCU Access and Wait State Generation
The MCU can access external devices in 2 state access or 3 state access. In
two state access the MCU uses two clock cycles to access data from the external device In 3 state access the MCU uses 3 clock cycles to access the external device or more if wait states are enabled. The wait state controller can operate in different modes. In this case the programmable wait mode is used.
This means that the programmed amount of wait states in the wait control register are inserted when an access is performed to a device located in that area.
For area split see NO TAG. The complete address space is divided into 8 areas
each area covering 2 MByte of address space. The access type for each area
can be set by bits in the access state control register. Further more the wait
state function can be enabled separately for each area by the wait state controller enable register.
This means that in 3 state access two types of acccess can be performed with
a fixed setting:
– 3 state access without wait states
– 3 state access with the amount of wait states inserted determined by the
wait control register
Original 06/96
Page 4–17
NHE–5
After Sales
System Module
If the wait state controller is not enabled for a 3 state access area no waits
states are inserted when accessing that area even if the wait control register
contains a value that differs from 0 states.
MCU Flash Loading
The flash loading equipment is connected to the baseband by means of the test
connector before the module is cut out from the frame. Updating SW on a final
product is done by removing the battery and connect a special battery that contains the necessary contacting elements. The contacts on the baseband board
are test points that are accessable when the battery is detached. The power
supply for the base band is supplied via the adapter and controlled by the flash
programming equipment. The base band module is powered up when the power is connected to the battery contact pins.
Five signals are required for the flash programming, with the addition of the battery supply. The baseband MCU will automatically wait for flash down loading to
be performed if one of the two following criteria are met.
– The flash is found to be empty when tested by the MCU
Technical Documentation
– The serial clock line at the baseband MCU is forced low when the MCU is
exiting reset
The second alternative is used for reprogramming as the flash is not empty in
this case. To allow the serial clock line to be forced low during MCU initial boot
there is a requirement that the flash prommer can control the power on of the
baseband module. This is done by controlling the switching of the battery power supply. This arrangement allows the baseband module to operate in normal
mode even if the flash prommer is connected but not active. The flash prommer
also disables the power supply watchdog during flash programming to prevent
unwanted power off of the baseband. The programming voltage to the flash is
applied when the flash prommer has detected that the baseband module is
powered. This detection is performed by monitoring the serial interface RX line
from the baseband. The RX line is pulled high by a pullup resistor in idle. The
VPP voltage is set to 5V as it is not known at this point what type of device is
used.
The following diagram shows the block diagram for the baseband flash programming circuitry.
Page 4–18
Original 06/96
After Sales
NHE–5
Technical Documentation
X300
VPP
FRX
FTX
FCLK
WDDis
GND
VBAT
1
2
3
4
5
6
Flash Prommer
5... 22
26
PSCLD
N301
40
FLASH pin11 Vpp
PSCLD pin 22 WDDis
GND
Programming Voltage Vpp
ASIC pin 120
PurX
VL,VSL
ASIC pin 130 PwrDown
VLC
R315
11
FLASH
D400
ASIC pin 51 CSelX
2,71
1
MCU
D150
Internal
3
MCU pin 55 RdX
RAM
38(9)37(24)9(24)12(10)
MCU pin 56 WrX
PSCLD pin 26 PurX
Master Reset
56
55
MCUResX
51 82
MCUClk
MCUAdrress
MCUData
WrX
RdX
SRAM
D403
System Module
120
55
ASIC
56
D151
8148
BOOT
ROM
49
RAMCSelX
30
5
32
MCU pin 56 WrX
MCU pin 55 RdX
The following picture shows the location of the flash programming contact pads
on the PCB. These pads are used for SW updating at after sales locations. A
special battery pack is used for this purpose. The battery pack contains contacting elements that can access these pads without having to disassemble the
phone.
WDDIS FCLK VPP FTX FRX
D152
The interface lines between the flash prommer and the baseband are in low
state when power is not connected by the flash prommer. The data transfer between the flash programming equipment and the base band is synchronous
and the clock is generated by the flash prommer. The same MCU USART that
is used for MBUS communication is used for the serial synchronous communication. The PSCLD watchdog is disabled when the flash loading battery pack
and cable is connected.
Original 06/96
Page 4–19
NHE–5
After Sales
System Module
After the flash battery pack adapter has been mounted or the test connector
has been connected to the board the power to the baseband module is connected by the flash prommer or the test equipment. All interface lines are kept
low except for the data transmit from the baseband that is in reception mode on
the flash prommer side, this signal is called TXF. The MCU boots from ASIC
and investigates the status of the synchronous clock line. If the clock input line
from the flash prommer is low or no valid SW is located in the flash MCU forces
the initially high TXF line low acknowledging to the flash prommer that it is
ready to accept data.
The flash prommer sends data length, 2 bytes, on the RXF data line to the
baseband. The MCU acknowledges the 2 data byte reception by pulling the
TXF line high. The flash prommer now transmits the data on the RXF line to the
MCU. The MCU loads the data into the internal SRAM. After having received
the transferred data correctly MCU puts the TXF line low and jumps into internal SRAM and starts to execute the code. After a guard time of 1 ms the TXF
line is put high by the MCU. After 1 ms the TXF is put low indicating that the
external SRAM test is going on. After further 1 ms the TXF is put high indicating
that external SRAM test has passed. The MCU performs the flash memory
identification based upon the identifiers specified in the Flash Programming
Specifications. In case of an empty device, identifier locations shows FFH, the
flash device code is read and transmitted to the Flash Prommer.
Technical Documentation
TXF
Boot OK
Reset
External SRAM
Internal SRAM
execution begin External SRAM
Length OK
After that the device mounted on base band has been identified the Flash
Prommer down loads the appropriate algorithm to the baseband. The programming algorithm is stored in the external SRAM on the baseband module and
after having down loaded the algorithm and data transfer SW, MCU jumps to
the external SRAM and starts to execute the code.
The MCU now asks the prommer to connect the flash programming power supply. This SW loads the data to be programmed into the flash and implements
the programming algorithm that has been down loaded.
test going on
test passed
1 ms
Ready to send
Flash ID
Page 4–20
Original 06/96
After Sales
NHE–5
Technical Documentation
Flash Prommer Connection Using Dummy Battery
For MCU SW updating in the field a special battery adapter can be used to connect to the test points which are accessable through 5 holes in the chassis, located behind the battery. Supply voltage must be connected to this dummy battery as well as the flash programming equipment
Flash, D400
A 4 MBit Boot Block flash is used as the main program memory, D400 the device is 3 V read/program with external 12V VPP for programming. The device
has a lockable boot sector. This function is not used since the complete code is
reprogrammed. The Boot sector is located at the ”bottom”, definition by Intel,
address 00000H–03FFFH. The block is unlocked by a logic high state on pin
12. This logic high level is generated from VPP. The device can be programmed by a VPP of 5V but the programming procedure takes longer. To improve programming the programming voltage used is 12V. The speed of the
device is 110 ns although the requirement is 150 ns. The MCU operating at 6.5
MHz will access the flash in 2 state access, requiring 150 ns access time from
the memory.
System Module
SRAM D402, D403
The baseband is designed to take two different size of SRAMs, 32kx8 and
128kx8, not at the same time. The required speed is 150 ns as the MCU will
operate at 6.5 MHz and the SRAM will be accessed in 2 state access. The
SRAM has no battery backup which means that the content is lost even during
short power supply disconnections. As shown in the memory map the SRAM is
not accessable after boot until the MCU has enabled the SRAM access by writing to the ASIC register.
EEPROM D401
The baseband is designed to take an 8kx8 parallel EEPROM. In addition to that
a serial 2kx8 device using I2C bus is also designed on the baseband. HD842
will use the 2kx8 serial device over the I2C bus. The I2C bus protocol is implemented in SW and the physical implementation is performed on MCU Port 4.
The parallel device is connected to the MCU data and address bus. The ASIC
generates chip select for the EERPROM. To avoid unwanted EEPROM access
there is an EERPOM access bit in the ASIC MCU interface. This bit mus be set
to allow for EERPOM access. This bit is cleared by default after reset. After
each access this bit should be cleared to prevent unwanted EEPROM access.
The parallel device used support page mode writing, 64 byte page. One page
can be written by the MCU and after that the internal programming procedure is
started. The page write operation is internally timed in the device and consecutive bytes must be written within 100 us. During this operation all interrupts
must be disabled.
Original 06/96
Page 4–21
NHE–5
After Sales
System Module
Technical Documentation
MCU and Peripherals
MCU Port P4 Usage
MCU, D150 port 4 is used for baseband control.
Port Pin MCU pin Control Function Remark
P40 5 Display driver reset Active low
P41 6
P42 7
P43 8
P44 9 EEPROM SCK
P45 10 EEPROM SDA
P46 11 EEPROM write enable Active low
P47 12 Headset mic amplifier bias Active loew
Baseband A/D Converter Channels usage in N450 and D150
The auxiliary A/D converter channels inside RFI2, N450 are used by MCU to
measure battery voltage. The A/D converters are accessed by the DSP, D152
via the ASIC, D151. The required resolution is 10 bit.
The MCU has 4 10 bit A/D channels which are used for baseband voltage monitoring. The MCU can measure charger voltage, battery size, battery temperature and accessory detection by using it’s own converters.
Page 4–22
Original 06/96
After Sales
NHE–5
Technical Documentation
Baseband N450 A/D Converter Channel Usage
Name: Usage: Input volt. range Remark
Chan 0 Battery voltage 5...9 V Battery voltage when
Chan 1 Charger voltage 5...16 V
Chan 2 Battery size indic. 0...3.2 V
Chan 3 Battery temperature 0...3.2 V
Chan 4 System board temp. 0...3.2 V Not used
Chan 5 Accessory detection 0...3.2 V
Chan 6 0...3.2 V Not used
Chan 7 Battery voltage 5...9 V Battery volt. TX inactive
MCU Baseband A/D Converter Channel Usage
Name: Usage: Input volt. range Remark
System Module
TX is active
Chan 0 Battery temperature 0...3.2 V
Chan 1 Charger voltage 5...16 V
Chan 2 Accessory detection 0...3.2 V
Chan 3 Battery size indicator0...3.2 V
Battery Voltage Measurement
The battery voltage is measured using RFI2, N450 A/D converter channel 0
and 7. The converter value supplied from channel 7 is measured when the
transmitter is active. This measurement gives the minimum battery voltage. The
value from channel 0 is measured when the transmitter is inactive. The battery
voltage supplied to the A/D converter input is switched off when the baseband
is in power off. The battery voltage measurement voltage is supplied by
PSCLD, N301 which performs scaling, the scaling factor is R1(R1+R2), and
switch off. The measurement voltage is filtered by a capacitor to achieve an average value that is not depending upon the current consumption behavior of the
baseband. To be able to measure the battery voltage during transmission pulse
the time constant must be short. The value for the filtering capacitor is set to
1 nF, C319. The scaling factor used to scale the battery voltage must be 1:3,
which means that 9V battery voltage will give 3V A/D converter input voltage.
The A/D converter value in decimal can be calculated using the following formula:
A/D = 1023xR1xU
where K is the scaling factor. K = R1/((R1+R2)xU
Original 06/96
/((R1+R2)xU
BAT
) = 1023xU
ref
BAT
ref).
xK
Page 4–23
NHE–5
After Sales
System Module
Charger Voltage Measurement
The charger voltage is measured to determine the type of charger used. MCU
A/D converter channel 1 is used for this purpose. The input circuitry to the charger measurement A/D channel implements an LP–filter. The input voltage must
be scaled before it is fed to the A/D converter input. Due to the high input voltage range scaling is performed outside PSCLD, N301. The scaling factor required is 22/(22+100) = 0.18. The charger voltage measurement switch is integrated into PSCLD, N301. Charger voltage is not supplied to the A/D converter
input in power off mode. This is done to protect the A/D converter input in case
power is switched off and the charger remains connected to the baseband. The
charger A/D converter value can be calculated using the same formula as described in above section. The resistor values are different since the scaling factor is larger.
Battery Size Resistor Measurement
The battery size, capacity is determined by measuring the voltage on the BSI
pin on the battery pack when the battery is attached to the phone. The MCU
A/D converter channel 3 is used for this purpose. The BSI signal is pulled up on
the base band using a 47 kohm resistor and the resistor inside the battery pack
is reflecting the capacity of the battery. There are two special cases to be detected by the MCU. The first case is the Lithium battery. The Lithium battery
has reserved values in the battery size table. Lithium type batteries are all the
same from charging point of view. Lithium batteries are charged to a constant
voltage and charging is aborted when the predefined voltage is reached. The
Lithium battery capacity is a function of the battery voltage. The battery voltage
drops linearly as the battery is discharged. The other case that has to be handled is the dummy battery. This battery is used for A/D converter field calibration at service centers and together with a defined voltage on the BTEMP pin
on the battery pack to put the baseband into Local mode in production. Battery
sizes below 250 mAh will be treated as dummy battery. The different battery
size values are shown in tthe table below . The battery size A/D converter value
can be calculated using the following formula:
Technical Documentation
Page 4–24
A/D = RSI/(RSI+47 kΩ)x1023
where RSI is the value of the resistor inside the battery pack.
Original 06/96
After Sales
NHE–5
Technical Documentation
Battery Size and A/D Converter Value
Battery Type Battery pack resistor Capacity BSI volt. A/D conv value
Dummy 1 kΩ 2 % <250 mAh0.07 21 (83)
Standar battery 6.19 kΩ 2 % 900 mAh 0.37 119 (467)
Extended battery 9.09 kΩ 2 % 1200 mAh0.52 166 (664)
Slim 3.3 kΩ 2 % 500 mAh 0.21 67 (268)
Lithium 68 kΩ 2 % 400 mAh 1.86 605 (2420)
Lithium 82 kΩ 2 % 8.6 V 2 650 (2601)
Battery Temperatur Measurement
The battery temperature is measured during charging. The BTEMP pin to the
battery is pulled up on baseband by a 47 kohm resistor to logic supply voltage,
3.2V. The voltage on the BTEMP pin is a function of the battery pack temperature. Auxiliary A/D channel 3 is used for this purpose. Inside the battery pack
there is a 47 kohm NTC resistor to ground. The A/D converter value can be calculated from the following formula:
System Module
A/D = RNTC/(RNTC+47 kohm)x1023
where RNTC is the value of the NTC resistor inside the battery pack.
The relation ship between different battery temperature, BTEMP voltage and
A/D converter values are shown in following table.
A/D Converter Values for Different Battery Temperatures
Bat. temp.NTC value BTEMP voltage A/D conv. value
Dummy 1 kΩ 0.06 V 21
–25 745.60 k Ω 2.96 V 962
0 164.96 kΩ 2.45 V 796
25 47 kΩ 1.58 V 512
50 16.26 kΩ 0.81 V 263
70 7.78 kΩ 0.45 V 145
Compact HF & Headset Detection
Auxiliary A/D channel 4 is used to detect accessories connected to the system
connector using the XMIC. To be able to determine which accessory has been
connected MCU measures the DC voltage on the XMIC input. The accessory is
detected in accordance with the CAP Accessory specifications. Not all accessories are supported by the HD842 base band that are specified in the CAP Accessory specification.
Original 06/96
Page 4–25
NHE–5
After Sales
System Module
The base band has a pull–up resistor network of 32 kohm to VA. The accessory
has a pull down. The A/D converter value can be calculated using the following
formula:
A/D = (ACCI+10 kΩ)/(ACCI+32 kΩ)x1023
where ACCI is the d.c. input impedance of the accessory device connected to
the system connector.
The different values for acceptable accessories are given in the following table.
The values in below table are calculated using 5 % resistor values and power
supply range 3–3.3 V. Due to that the pull up resistor in the XMIC line is divided
into two resistors the voltage at the A/D converter input is different from that on
the XMIC.
Accessory Detection Voltage
Acc. type Acc. resistance Voltage on A/D converter A/D converter
Headset 47 kΩ 2.1...2.3...2.45 717...758
Compact 22 kΩ 1.7...1.9...2.05 581...631
HF
Technical Documentation
channel 5 (min/typ/max) value(min/max)
Keyboard Interface
The keypad matrix is located on a PCB and the interface to the base band is by
using connector X101. The electrical specifications are shown in NO TAG. The
power on key is also connected to the PSCLD to switch power on. Due to the
internal pull up inside PSCLD, N301 to a high voltage, a rectifier, V203 is required in the keypad matrix for the power on keypad to prevent the high voltage
to interfere with the keypad matrix.
Series resistors, R261–R264 are implemented in the Column output to reduce
the EMI radiation to the UI PCB. Capacitors C257–C260 reduces the EMC radiation and absorbs any ESD produced over an air gap to the keymat. As the serial display driver interface uses ROW5 for data transmission series resistors
are needed to prevent keypad or double keypad pressing from interfering with
the display communication. In a similar way R265–R269 in the ROW lines reduces the EMI to the UI board. Capacitors C251–C256 implements a LP–filter
together with each resistor in the ROW line. The capacitors also absorbs ESD
pulses over an air gap to the keymat.
During idle when no keyboard activity is present the MCU sets the column outputs to ”0” and enables the keyboard interrupt. An interrupt is generated when
a ROW input is pulled low. Each ROW input on the ASIC, D151 has an internal
pull–up. The keyboard interrupt starts up the MCU and the MCU starts the
scanning procedure. As there are keypads to be detected outside the matrix
the MCU sets all columns to ”1” and reads the ROW inputs if a logic ”0” is read
on any ROW this means that one of the 6 possible non matrix keypads has
been pressed. If the result was a ”1” on each ROW the MCU writes a ”0” on
Page 4–26
Original 06/96
After Sales
NHE–5
Technical Documentation
each column consecutively while the rest of the column outputs are kept in tri–
state to allow dual keypad activation to be detected. After that the keyboard
scanning is completed and no activity is found the MCU writes ”0” to all columns, enables the keyboard interrupt and enters sleep mode where the clock
to the MCU is stopped. A key press will again start up the MCU.
Keyboard and Display Light
The display and keyboard are illuminated by LED’s. The light is normally
switched on when a keypad is pressed. The rules for light switching are defined
in the SW UI specifications. The display and keyboard light is controlled by the
MCU. The LED’s are connected two in series to reduce the power consumption. Due to the amount of LED’s required for the keyboard and display light
they are divided into three groups. Each group has it’s own control transistor.
The LED switch transistor is connected as a constant current source, which
means that the current limiting resistor is put in the emitter circuitry. This arrangement will reduce LED flickering depending upon battery voltage and momentary power consumption of the phone. The LED’s are connected straight to
the battery voltage. This connection allows two LED’s to connected in series.
The battery voltage varies a lot depending upon if the battery is charged, full or
empty. The switching transistor circuitry is designed to improve this as mentioned earlier.
System Module
The LED transistor control lines are coming from PSCLD. The MCU controls
these lines by writing to PSCLD using the serial control bus. There are two LED
control lines provided by the PSCLD. The display light control is connected to a
separate control line. The keyboard light control is common to the two transistors. This means that the keyboard and display light can be controlled separately. The advantage of this is that the power dissipation and heating of the
phone can be reduced by only having the required lights switched on.
Audio Control
The audio codec N200 is controlled by the MCU, D150. Digital audio is transferred on the CODECB(5:0). PCM data is clock at 512 kHz from the ASIC and
the ASIC also generates 8 kHz synchronization signal for the bus. Data is put
out on the bus at the rising edge of the clock and read in at the falling edge.
Data from the DSP, D152 to the audio codec, N200 is transmitted as a separate
signal from data transmitted from the audio codec, N200 to the DSP, D152. The
communication is full duplex synchronous. The transmission is started at the
falling edge of the synchronization pulse. 16 bits of data is transmitted after
each synchronization pulse.
Original 06/96
Page 4–27
NHE–5
After Sales
System Module
VB
BUZZER
BUZZER DRIVER
V201,V202
R209, 210, 211 ...
EARP
EARN
L205
XEAR
MICP
MICN
L204
R214L206
MIC BIAS
R201,V200..
R203L201 C203
R204L202
R205
C206
14
8
9
6
21
25
24
CODEC
N200
CLK
CSX
DATA
11
12
13,16
23
22
5
20
19
10
17
VA
BRIDGE
CIRCUIT
R207,R216,R217
R219,R220
C213,C216
C213,C216
Serial Bus
AUDIO DATA IN
AUDIO DATA OUT
X103
SYSTEM
CONNECTOR
10
R218
CLK 512 kHz
SYNC 8 kHz
VLC
R168
Technical Documentation
R215
R206
C218
C220 L200
MCU
D150
293727
31
DSP
D152
EXT AUDIO EQUIPM. INDICATION
R208
L208
IRQ1X
68
3341
MCU pin 64
A/D Converters
XMIC
X103
pin 8
SGND
Data, Addr Bus
78
42,44,46
40
41
ASIC
D151
Data, Addr Bus
R161
122
The 512 kHz clock is generated form 13 MHz using a PLL type of approach
which means that the output frequency is not 512 kHz at any moment. The frequency varies as the PLL adjusts the frequency. The average frequency is 512
kHz. The clock is not supplied to the codec when it is not needed. The clock is
controlled by both MCU and DSP. DTMF tones are generated by the audio codec and for that purposes the 512 kHz clock is needed. The MCU must switch
on the clock before the DTMF generation control data is transmitted on the serial control bus.
The serial control bus uses clock, data and chip select to address the device on
the bus. This interface is built in to the ASIC and the MCU writes the destination
and data to the ASIC registers. The serial communication is then initiated by
the ASIC. Data can be read form the audio codec, N200 via this bus.
Internal Audio
The bias for the internal microphone is generated from the PSCLD, N301 analog output, VA using a bias generator. The bias generation is designed in such
a way that common mode signals induced into the microphone capsule wires
are suppressed by the input amplifier in the audio codec. The bias generator is
controlled by the MCU to save power, the control signal is taken from the audio
codec, N200 output latch, pin 21, when the microphone is not used, in idle the
bias generator is switched off. The microphone amplifier gain is set by the MCU
to match with the used microphone, 35 dB. The microphone amplifier input to
the audio codec is a symmetrical input.
Page 4–28
The microphone signal is connected to the baseband using filtering to prevent
EMC radiation and RF PA signal to interfere with the microphone signal. L201
Original 06/96
After Sales
NHE–5
Technical Documentation
and C201 forms the first part of this filter. R203 and C202 forms the second
part of this filter. A similar filter is used in the negative signal path of the microphone signal. R205 is connected in the ground path for the microphone bias
current. R202 supplies the bias current to the microphone from the generator
circuitry R201, C200 and V200. A transient suppressor, V204, is connected
across the microphone terminals to protect the microphone against ESD.
The earpiece amplifier used for the internal earpiece is of differential type and
is designed as a bridge amplifier to give the output swing for the required sound
pressure. Since the power supply is only 3V a dynamic type ear piece has to be
used to achieve the sound pressure. This means that the ear piece is a low impedance type and represents a significant load to the output amplifier. Series
inductors are implemented to prevent EMC radiation from the connection on
baseband to the earpiece. The same filter also prevents the PA RF field from
causing interference in the audio codec, N200 output stage to the earpiece.
The buzzer is controlled by the PWM output provided by the audio codec,
N200. Transistors V201 and V202 acts as amplifier and, impedance conversion
for the low impedance buzzer. The buzzer is driven directly from the battery
voltage. As the buzzer is connected to the baseband via the keyboard the battery voltage provided by VBKEY and the buzzer driving signal BUZZER are
EMC protected. As the buzzer is a dynamic one the impedance shows a clear
inductance. Therefore a free running diode V203 is used to clip the voltage
spikes induced in the buzzer line when the buzzer is switched off.
System Module
The buzzer frequency is determined by the internal setup of N200. The frequency is determined by the MCU via the serial control bus. The output level
can be adjusted by the PWM function which is attached to the buzzer output in
N200.
External Audio
The external microphone audio signal is applied to the baseband system connector and connected to the audio block using signals XMIC and SGND. In order to improve the external audio performance the input circuitry is arranged in
a sort of dual ended. A wheatstone type of bridge configuration is created by
resistors R216, R217, R219 and R220. The signal is attenuated around 20 dB
to not cause distortion in the microphone amplifier. The microphone signal is
attenuated by resistors R216, R207 and R217. Two allow the external earpiece
to be driven dual ended the external microphone signal ground is connected to
the negative output of the external audio earpiece amplifier. This means that
with reference to audio codec, N200 ground there is a signal level on the SGND
line. This arrangement requires that the external microphone amplifier supplies
the signal on the SGND line to the XMIC line. With this arrangement the differential voltage over R207 caused by the signal in the SGND line is canceled.
There is however a common mode component which is relatively high presented at both the external microphone input pins at the audio codec input, pins
22 and 23. The microphone amplifier has a good common mode rejection ratio
but a slight phase shift in the signals will remove the balance. To compensate
Original 06/96
Page 4–29
NHE–5
After Sales
System Module
for this the signal from the external earpiece amplifier positive output, which
also feeds the external audio output from the baseband is feed to the remaining
resistors in the bridge, R219 and R220. This arrangement will attenuate the
common mode signal presented to the microphone amplifier caused by the audio signal in the SGND line. Since the positive output from the audio codec,
XEAR signal introduces a DC signal to the microphone amplifier the DC signal
on the XMIC and SGND lines are blocked by capacitors C218 and C220.
XMIC
R216
R207
Technical Documentation
XEAR
R219
Microphone +
Microphone –
R220R217
DSP
SGND
The external audio output is the XEAR signal on the system connector pin. The
XEAR signal is taken from audio codec N200 pin 6. The output impedance is
increased to 32 ohms by resistors R222 and R214. This resistors prevents the
output amplifier from being short circuited even if the pin at the system connector is short circuited. An ESD capacitor, C225, is connected to ground at the
connection point of R222 and R214. R222 is added to N200 pin 6 output as the
output amplifier can not be loaded directly with the ESD capacitor. The DC voltage at the XEAR output is used to control the mute function of the accessory.
When internal audio is selected the XEAR amplifier in N200 is switched off and
the DC voltage at the output on pin 5 is removed. External audio output level is
adjusted by the variable gain amplifier in the N200 by MCU via the serial control
bus from the ASIC, D151. L206 and C 214 is EMC protection for the XEAR signal at the system connector. This filter also prevents RF signals induced in the
external cables from creating interference in the audio codec output stage.
The DSP used in NHE–5 is the TI 320C541. This is a 16 bit DSP that can use
external and/or internal memory access. The DSP can operate in two modes
microprocessor mode or microcontroller mode. The difference between the two
modes are that in microprocessor mode the DSP boots from external memory
while in the microcontroller mode the DSP boots from internal ROM. The DSP
external memory access is devided into data, program and I/O access. The
type of access is indicated on three control pins that can be used for memory
control.
XEAR
Page 4–30
Original 06/96
After Sales
NHE–5
Technical Documentation
The DSP, D152 executes code from the internal ROM. The baseband also provides external memories for the DSP, D410, D411. The DSP is capable of addressing 64 kword of memory. The memory area is divided into a code execution area and a data storage area. The code execution area is located at
address 8000H–FFFFH in the internal ROM. The external memories are arranged in such a way that the DSP can access the external memories both as
data storage and code execution. The memory chip select is taken from the
memory access strobe signal from the DSP. This means that the memory is active during any memory access. The SRAMs are configured in chip select controlled write mode. This means that both the write signal and the output enable
signal are active at the same time, and the actual write occours at the rising
edge of the chip select signal. This implementation is required since the DSP
supports only one signal for write/read control.The DSP, D152 executes code
from the internal ROM. The baseband also provides external memories for the
DSP, D410, D411. The DSP is capable of addressing 64 kword of memory. The
memory area is divided into a code execution area and a data storage area.
The code execution area is located at address 8000H–FFFFH in the internal
ROM. The external memories are arranged in such a way that the DSP can access the external memories both as data storage and code execution. The
memory chip select is taken from the memory access strobe signal from the
DSP. This means that the memory is active during any memory access. The
memories are connected in such a way that the write control is CE controlled
write. This means that both the write signal and the output enable signal are
active at the same time. This implementation is required since the DSP supports only one signal for write/read control.
System Module
The DSP is operating from the 13 MHz clock. In order to get the required performance the frequency is internally increased by a PLL by a factor of 3. The
PLL requires a settling time of 50 us after that the clock has been supplied before proper operation is established. This settling counter is inside the DSP although the ASIC, D151 contains a counter that will delay the interrupt with a
programmable amount of clock cycles before the interrupt causing the clock to
be switched on is presented to the DSP. The DSP has full control over the clock
supplied to it. When the DSP is to enter the sleep mode the clock is switched
off by setting a bit in the ASIC register. The clock is automatically switched on
when an interrupt is generated.
The DSP also has two synchronous serial channels for communication. One
channel is used for data transmission between the DSP and the audio codec.
This channel is operating at 512 kbits and clock and synchronization signal is
provided by the ASIC, D151. The other channel is used for debugging purposes and uses the same clock and synchronization signals. The DSP has an
interrupt controller servicing four interrupts and one non maskable interrupt,
NMI. The interrupts have fixed priority which can only be changed by changing
the interconnection between the interrupt sources by HW
.
The ASIC contains DSP support functions as modulator,encryption/decryption
using algorithms A5/A51, RF power ramp generation/AGC control, AFC control,
Synthesiser serial interface, frame counters, timer, RFI2 interface, RX and TX
Original 06/96
Page 4–31
NHE–5
After Sales
System Module
power control timing. RF power ramp timing/AGC control, AFC control, synthesiser control are timed to the value of the frame counter. This means that data
is loaded into the registers and transferred when the frame counter and the reference value matches. This allows timing of synthesiser control power ramp
and start of TX data to be controlled very precisely.
As the receiver and the transmitter is not operating at the same time the TX
power ramp function is used to control the AGC in the receiver during the reception. This requires the DSP to continously modify the values in the TX ramp
SRAM to fit the ramp during TX and the AGC value during reception.
DSP ASIC Access
The DSP is accessing the ASIC in the DSP I/O area. 2 wait states are required
for the ASIC access. Some of the DSP registers located in the ASIC are retimed to the internal ASIC clock and requires special handling with respect to
consecutive writing. This means that the same register can not be written again
until a specified time has passed. To cope with this DSP is inserting NOP
instructions to satisfy this requirement.
Technical Documentation
DSP Interrupts
The DSP supports 4 external interrupts. Three interrupts are used. The ASIC,
D151 generates two of the interrupts. One interrupt is generated by RFI2, N450
auxiliary A/D converter. This interrupt is generated when a baseband measurement A/D conversion is completed. The interrupts to the DSP are active low.
INT0 which is the highest priority interrupt is used for data reception from the
receiver and is generated by the ASIC. INT1 signal is used for auxiliary A/D
channel conversions generated by the RFI2. This interrupt is generated by
RFI2 and is a result of measurement requests from the DSP. There are 8 auxiliary channels supported by the RFI2, not all are used in HD842 even if most of
the channels are connected. INT3 is a low priority interrupt generated by the
ASIC timer. The DSP programs the timer value and an interrupt is given when
the timer expires. The interrupt must be active at least 1 ??? DSP clock cycle
as it is sampled on the rising/falling edge by the DSP. All interrupts are active
low.
INT0 is used for the reveiver A/D converter in RFI2. The ASIC reads the data
from the receiver path A/D converter in RFI2 at every data available signal activation from the RFI2. After the data transfer when the data is stored in the
ASIC the ASIC generates a receiver interrupt to the DSP using INT1 signal.
The DSP enters the interrupt routine and services the interrupt and reads the
data from the ASIC.
Page 4–32
INT1 signal is used for the auxiliary A/D converter channels in RFI2. These A/D
channles are used for baseband battery voltage monitoring. Two channels are
used for battery monitoring. The start of the A/D conversion task is timed in
such a way that auxiliary channel 1 results are measured during transmission
whne the PA is active and channel 8 is measuring when the PA is off.
Original 06/96
After Sales
NHE–5
Technical Documentation
Unused interrupt controller inputs are tied high.
DSP Serial Communications Interface
The DSP contains two synchronous serial communications interface. One of
the interfaces are used to communicate with the audio codec, N200. The 512
kHz clock required for the data transfer is provided by D151 as well as the 8
kHz synchronization signal. Data is transferred on to lines, RX and TX creating
a full duplex connection. Data is presented on the bus on the first rising edge of
the clock after the falling edge of the synchronization pulse. Data is read in by
each device on the falling edge of the clock. Data transfer is 16 bits after each
synchronization pulse.
The DSP, D152 has control over the clock provided to the audio codec. The
DSP can switch on the clock to start the communication and switch it off when it
is not needed. This clock is also under control of MCU, D150.
RF Synthesizer Control
The synthesizer control is performed by the DSP, D152 using the ASIC, D151
as the interfacing and timing device. Different synthesizer interface are supported and the required interafce can be selected by the DSP at the initialisation stage of the ASIC. The synthesizer interface also includes timing registers
for programming synthesizer data. The DSP loads the synthesizer data into the
transmission registers in the ASIC synthesizer interface together with the timing
information. The system timing information is used for synthesizer data loading.
When the system timing register, frame counter, value matches with the timing
value programmed into the synthesizer interface the interface transmits the
loaded data to the RF synthesizer and the VCO frequency is changed accordingly. As the synthesizer may be powered off when not needed the interface
pins towards the synthesizer can be put in tri–state or forced low when the interface is not active.
System Module
RFI2, N450 Operation
The RFI2, N450 contains the A/D and D/A converters to perform the A/D conversion from the received signal and the D/A converters to perform the conversion for the modulated signal to be supplied to the transmitter section. In addition to this the RFI2 chip also contains the D/A converter for providing AFC
voltage to the RF section. This AFC voltage controls the frequency of the 13
MHz VCXO which supplies the system clock to the baseband. The RFI2, N450
also contains the D/A converter to control the RF transmitter power control. The
power control values are stored in the ASIC, D151 and at the start of each
transmission the values are read from the ASIC, D151 to the D/A converter producing the power control pulse. This D/A converter is used during the reception
to provide AGC for the receiver RF parts.
The RFI2 contains the interface between the baseband and the RF. RFI2 circuit
contains the A/D converters required for the receiver and the D/A converters
Original 06/96
Page 4–33
NHE–5
After Sales
System Module
required for the transmission. In addition to this the RFI2 contains a 10 bit D/A
convereter for AFC control and one of the receiver A/D converters has a multiplexed input for 8 additional channels used for baseband monitoring functions.
The A/D converters are 12 bit sigma delta type. This means that the digital output is centered around the reference voltage and the output value is both negative and positive. The RFI2 has an internal reference voltage for the A/D and
D/A converters that can be switched off to save power. The reference has external filtering capacitors to improve the converter performance. The transmitter
D/A converters are followed by interpolator and post filter. The filter is of switch
capacitor type and the filter parameters are taken into account when modulator
parameters are calculated. The AFC D/A converter is static and requires no
clock for operation. This means that the RFI2 clock can be switched off and the
AFC value will be kept.
One of the A/D converters used for receiver signal conversion can be used as
an auxiliary converter that supplies 8 channels for baseband measurement purposes. When the converter is used in this mode each conversion generates an
interrupt directly to the DSP. The DSP operates this converter via the ASIC,
D151.
Data communication between the ASIC, D151 and RFI2, N450 is carried out on
a 12 bit parallel data bus. The ASIC, D151 uses 4 address lines to access
RFI2, N450. Depending on the direction of the communication either the write
control signal is used to write data to RFI2, N450 or the read signal is used to
read data from RFI2, N450. The ASIC, D151 supplies 13 MHz clock to the
RFI2, N450. This clock is used as reference for the A/D and D/A converters.
Communication between the ASIC, D151 and the RFI2, N450 is related to the
clock.
Technical Documentation
The signal from the RF receiver is attenuated at the RFI2 converter input. R454
forms together with the output impedance from the receiver section an attenuator for the input signal to N450. This attenuator is symmetric as it is connected
between the two input signals, improving the S/N compared to an attenuator
towards ground.The attenuation is done in a symmetric way by series resistors
and a resistor between the two inputs. The benefit of this is that the attenuator
ground noise is removed and the bias voltage error between the two inputs are
reduced. This also affects the settling time in case the analogue supply to RFI2
is switched off. The settling time is reduced due to this attenuator.
The auxiliary channels supported by the RFI2 uses one of the receiver A/D
converters as the A/D converter. Due to the type of converter used for the receiver converters the value read from the auxiliary channels can be negative.
The input voltage applied to the auxiliary channels must be within 0.5–3.0 V. A
12 bit value is received from the auxiliary channel measurement. The auxiliary
channel conversion complete is sent direct to the DSP as an interrupt, INT1.
The DSP reads the value using direct access through the ASIC to the RFI2
converter. The conversion is started by the DSP writing the address of the
channel to be measured to the ASIC register. The ASIC then writes the selected channel to RFI2 and the conversion is started. The DSP may sample the
same channel for more than one value as the A/D converter will produce conti-
Page 4–34
Original 06/96
After Sales
NHE–5
Technical Documentation
nuosly new values. Several samples may be used for example in battery voltage measurement to calculate an avarage value from the results.
The RFI2, N450 digital supply is taken from the baseband main digital supply.
The analog power supply, 4.5V is generated by a regulator supplied from the
RF section. The external transistor required for the regulator is provided by the
baseband, V450. The analog power supply is always supplied as long as the
baseband is powered, if R342 is assembled. The RFI2, N450 analog power
supply can be switched off during sleep by removing R342 and adding R349. In
this case the RFI2, N450 analog power supply is in the control of the PSCLD,
N301 sleep control signal.
Receiver Timing and AGC
RF receiver power on timing is performed by the ASIC, D151. The DSP, D152,
can program the time when the receiver is to be powered on. The timing information is taken from the system timing that is based upon the frame counter
inside the ASIC, D151 which is synchronised to the base station carrier frequency using AFC to tune the receiver. As transmission and reception takes
place at different time the D/A converter used for transmitter power control is
used to control the AGC of the receiver during reception. This requires the DSP,
D152 to alter the content of the SRAM containing the information that is written
to the D/A converter for the reception and the transmission.
System Module
RF Transmitter Timing and Power Control
The RF Power Amplifier (PA) timing control is performed by the ASIC, D151.
The power control is performed by the ASIC D151 using the D/A converter in
N450. The ASIC, D151 controls the power supply voltage to the RF transmitter
sections. As the first step the relevant circuits are powered on using the TX
power control output from the ASIC, D151. The timing for powering on the TX
circuits is generated from the ASIC internal system timing circuitry, frame counter. As the RF TX circuitry needs time to stabilize after power on before the actual transmitter can be started there is a programmable delay before the ASIC,
D151 starts to write the power ramp data to the D/A converter inside N450. The
TXC signal which is generated in this way controls the power ramp of the PA
and the power level for that burst. At the end of the burst the power ramp is
written to the D/A converter inside N450. The data that creates the power ramp
and final power level is stored in a SRAM inside the ASIC, D151. At the start of
the ramp the contents of the SRAM is read out in increasing address order. At
the end of the ramp the contents is read out in decreasing adress order. The
power level during the burst is determined by the last value in the SRAM, this
value is the value that will remain in the D/A converter during the burst. The
DSP, D152 may change the shape of the falling slope of the poer ramp by writing new values to the power ramp SRAM during the burst.
As the transmitter may have to adjust the transmitter burst due to the distance
from the base station there is an additional timer for this purpose. This timing is
Original 06/96
Page 4–35
NHE–5
After Sales
System Module
called the timing advance and will cause the transmission to start earlier when
the distance to the base station increases.
SIM Interface
The SIM interface is the serial interface between the smart card and the baseband. The SIM interface logic levels are 5V since no 3V technology SIM is yet
available. The baseband is designed in such a way that a 3V technology SIM
can be used whenever it is available. The SIM interface signals are generated
inside the ASIC. The signals coming from the ASIC are converted to 5V levels.
The PSCLD circuit is used as the logic voltage conversion circuit for the SIM
interface. The PSCLD circuit also contains the voltage regulator for the SIM
power supply. The control signals from the ASIC to PSCLD are at 3V level and
the signals between PSCLD and the SIM are 5V levels. An additional control
line between the ASIC and the PSCLD is used to control the direction of the
DATA buffer between the SIM and the PSCLD. In a 3V technology environment
this signal is internal to the ASIC only. The pull up resistor required on the SIM
DATA line is integrated into the PSCLD and the pull–up is connected to the SIM
regulator output inside PSCLD. In idle the DATA line is kept as input by both the
SIM and the interface on the base band. The pull–up resistor is keeping the
DATA line in it’s high state.
Technical Documentation
The power up and power down sequences of the SIM interface is performed
according to ISO 7816–3. To protect the card from damage when the power
supply is removed during power on there is a control signal, CARDIN, that automatically starts the power down sequence. The CARDIN information is taken
from the battery size indicator signal, BSI, from the battery connector. The battery connector is designed in such a way that the BSI signal contact is disconnected first, while the power is still supplied by the battery, and the battery power contacts are disconnected after that the battery pack has moved a specified
distance.
Since the power supply to the SIM is derived from PSCLD also using 3V
technology SIM the power supply voltage of the SIM regulator is programmable
3.15/4.8 V. The voltage is selected by using the serial control bus to PSCLD.
The default value is set to 3.2V nominal.
For cross compatibility reasons the interface should always be started up using
5V. The 3V technology SIM will operate at 5V but a 5V SIM will not operate at
3V. The supply voltage is switched to 3V if the SIM can accept that. The SIM
has a bit set in a data field indicating it’s capability of 3V operation.
The regulator control signal is derived from the ASIC and this signal controls
the operation of the SIM power supply regulator inside PSCLD. To ensure that
the powered off ASIC doesn’t cause any uncontrolled operations at the SIM interface the PSCLD signals to the SIM are forced low when the PURX signal is
active, low. This implementation will ensure that the SIM interface can not be
activated by any external signal when PSCLD has PURX active. When PURX
goes inactive the control of the interface signals are given back to the ASIC signals controlling PSCLD SIM interface operations.
Page 4–36
Original 06/96
After Sales
NHE–5
Technical Documentation
The clock to the SIM can be switched off if the SIM card allows stopping of the
clock. The clock can be stopped either in high or low state, determined by the
card data. For cards not allowing the clock to be stopped there is a 1.083 MHz
clock frequency that can be used to reduce the power consumption while the
clock is running. In this case the VCO must be running all the time. When the
clock is stopped and the status of the CARDIN signal changes, battery is removed, the clock to the SIM is restarted inside the ASIC and the SIM power
down sequence is performed.
To be able to handle current spikes as specified in the SIM interface specifications the SIM regulator output from PSCLD must have a ceramic capacitor of
100 nF connected between the output and ground close to the SIM interface
connector. To be able to cope with the fall time requirements and the disconnected contact measurements in type approval the regulator output must be
actively pulled down when the regulator is switched off. This active pull–down
must work as long as the external battery is connected and the battery voltage
is above the PSCLD reset level.
The SIM power on procedure is controlled by the MCU. The MCU can power
up the SIM only if the CARDIN signal is in the inactive state, low. Once the power up procedure has been started the ASIC takes care of that the power up procedure is performed according to ISO 7816–3.
System Module
The SIM interface uses two clock frequencies 3.25 MHz or 1.625 MHz during
SIM communication. The data transfer speed in the SIM GSM session is specified to be the supplied clock frequency/372. The ASIC SIM interface supplies all
the required clock frequencies as well as the required clock frequency for the
UART used in the SIM interface data transmission/reception.
SIM Interface and Support in D151
The signal from the BSI input from the battery is fed to D151, pin 25. This pin
has a special input cell that has specific input levels to convert the BSI signal
into the card detection logical control signal for the SIM interface in the ASIC.
When the input voltage has been low, less than 1.5V the output from the cell
will remain low until the input voltage exceeds 2.3V. If the input voltage has
been more than 2.8V the input will remain high until the input voltage has decreased to at least 1.9V. For all specified battery types the BSI voltage will stay
below 2.3V. If the voltage on this pin exceeds 2.3V the card detection signal will
be active and the card will be powered down. It is not possible to power up the
card as long as the card detection signal is active, high.
BART ASIC
Display Driver Interface
The display driver used is Seiko SD1232. The display driver has internal voltage triple circuitry for LCD voltage generation. Capacitors C266 and C267 are
used in the voltage converter. Capacitor C 268 is the filtering capacitor for the
Original 06/96
Page 4–37
NHE–5
After Sales
System Module
voltage generator output. Capacitors C261–C264 are filtering capacitors for the
supply voltage to the display driver back plane voltages. Resistor network R271
and R272 forms the feedback network for setting the contrast for the display.
The HD842 Base Band uses a serial interface to the Seiko LCD driver. The serial interface is designed in the ASIC. The MCU writes data into the serial interface in the ASIC and it is then transmitted to the LCD driver. The LCD driver reset is controlled by the MCU on P40. The display driver reset is dual edge
active. The P40 pin on the MCU has a pull down resistor, R166 to ensure that
the LCD driver reset is low at power up. After exiting reset one of the first tasks
for the MCU is to set the P40 to output and low, ”0”. After at least 100 us the
reset signal to the display driver is taken high, ”1”. This rising edge reset selects 80XX type MCU interface. The serial interface setting of the driver will
override this. After resetting the display driver the MCU starts the initialization
procedure using the serial interface in the ASIC, D151.
Communication with the serial driver takes place on the LCDSIOCONB(5:0).
The display driver requires serial data, serial clock and command/display information during the serial transfer. The display driver has it’s own chip select
which is active during the transfer, there are other devices on the same serial
bus as well. The command/display information is transmitted on the keyboard
ROW5 output. Due to the fact that the keyboard interface is used during display
driver transfers the keyboard activities must be disabled during display driver
communication. This means that the column output from the ASIC must be put
in high impedance state not to interfere with the data transmission if keypads
are pressed.
Technical Documentation
The timing required for the serial interface is provided by the ASIC and the operation of ROW5 depends upon the display driver interface initialization. For the
serial interface it is used for command/display data control. The serial clock is
541 kHz.
The clock to the display driver interface in the ASIC is automatically switched
on when a write operation to the interface has taken place. The MCU can force
the clock to be continuously on by writing the clock on to the CTSI block. The
default assumption is that the MCU forces the clock to be continuously on only
when a large amount of data is to be transmitted, such as segment test at power up.
Page 4–38
Original 06/96
After Sales
NHE–5
Technical Documentation
RF Block
Introduction
The RF module carries out all the RF functions of the transceiver. This module
works in the GSM system.
Components are located on both sides of the PWB. All components with height
more than 2 mm are on side two and lower than 2 mm components are on
both sides of PWB.
EMC leakage is prevented with magnesium shields. Shields conducts also heat
out of the inner parts of the phone thus preventing excessive temperature rise.
Receiver
The receiver is a double conversion receiver.
The received RF signal from the antenna is fed via a duplex filter to the receiv-
er unit. The signal is amplified by a discrete low noise preamplifier. The gain of
the amplifier is controlled by the AGC control line (PDATA0). The nominal gain
of 16.5 dB is reduced in the strong field condition about 36 dB. After the preamplifier the signal is filtered by SAW RF filter. The filter rejects spurious signals
coming from the antenna and spurious emissions coming from the receiver
unit.
System Module
In GSM systems the filtered RF–signal is down converted by the passive diode
mixer. The first IF frequency is 71 MHz in GSM. The first local signal is generated by the UHF synthesizer. The IF signals 71 MHz is amplified and filtered by
SAW filter in GSM. The filter rejects adjacent channel signal, intermodulating
signals and the last IF image signal.
The filtered IF signal is fed to the receiver part of the integrated RF circuit
CRFRT. In CRFRT the filtered IF signal is amplified by an AGC amplifier which
has gain control range of 57 dB. The gain is controlled by an analog signal via
TXC line. The amplified IF signal is down converted to the last IF in the mixer of
CRFRT. The last local signal is generated from VHF VCO by dividing the original signal by 4 in the dividers of CRFRT.
The last IF frequency is 13 MHz. The last IF is filtered by a ceramic filter. The
filter rejects signals of the adjacent channels. The filtered last IF is fed back to
CRFRT where it is amplified and fed out to RFI via RXINN and RXINP lines.
Duplex Filter
The duplex filter consists of two functional parts; RX and TX filters. The TX filter
rejects the noise power in the RX frequency band and TX harmonic signals.
The RX filter rejects blocking and spurious signals coming from the antenna.
Original 06/96
Page 4–39
NHE–5
After Sales
System Module
Pre–Amplifier
The bipolar pre–amplifier amplifies the received signal coming from the antenna. In the strong field conditions the gain of the amplifier is reduced 36 dB in
GSM, typically.
Parameter
Frequency band:
Supply voltage (min/typ/max):
Current consumption (min/typ/max):
Insertion gain (min/typ/max):
Gain flatness: ±
Noise figure (typ/max):
Reverse isolation (min):
Gain reduction (min/typ/max):
IIP3: (min/typ):
Technical Documentation
Value
935–960 Mhz
4.27...4.5...4.73 V
5...6....7 mA
15...16.5...17 dB
0.5 dB
2.0...2.5 dB
15 dB
33...36...39 dB
–12...–10 dBm
Input VSWR; zo=50 Ω (max):
Output VSWR; zo=50 Ω (max):
RF Interstage Filter
The RX interstage filter is a SAW filter in GSM. The filter rejects spurious and
blocking signals coming from the antenna. It rejects the local oscillator signal
leakage, too.
2.0
2.0
Page 4–40
Original 06/96
After Sales
NHE–5
Technical Documentation
First Mixer
The first mixer is a single balanced passive diode mixer. The local signal is balanced by a printed circuit transformer. The mixer down converts the received
RF signal to IF signal.
Parameter
RX frequency range:
LO frequency range:
IF frequency:
Conversion loss (min/typ/max):
IIP3 (min/typ):
LO – RF isolation (min):
LO power level (min):
First IF Amplifier
System Module
Value
935–960 Mhz
1006–1031 Mhz
71 Mhz
5...6...7 dB
2...5 dBm
15.0 dB
3 dBm
The first IF amplifier is a bipolar transistor amplifier.
Parameter
Operation frequency:
Supply voltage (min/typ/max):
Current consumption (typ/max):
Insertion gain (min/typ/max):
Noise figure (typ/max):
IIP3 (min/typ):
First IF Filter
In GSM the first IF filter is a SAW filter. The IF filter rejects some spurious and
blocking signals coming from the front end of the receiver.
Value
71 Mhz
4.27...4.5...4.73
12...15 mA
18...20...22 dB
3.5...4.0 dB
–5...–3 dBm
Original 06/96
Page 4–41
NHE–5
After Sales
System Module
Receiver IF Circuit, RX part of CRFRT
The receiver part of CRFRT consists of an AGC amplifier of 57 dB gain, a mixer
and a buffer amplifier for the last IF. The mixer of the circuit down converts the
received signal to the last IF frequency. After external filtering the signal is amplified and fed to baseband circuitry. The supply current can be switched OFF
by an internal switch, when the RX is OFF.
Parameter
Supply voltage (min/typ/max):
Current consumption (max):
Input frequency range (min/max):
Local frequency range of mixer
(min/max):
2nd IF range (min/max):
Voltage gain (max gain) of AGC
amlifier (min):
Technical Documentation
Value
4.27...4.5...4.73 V
35 mA
45 MHz (–1 db point)
...87 MHz (–3 dB point)
42.5...100 MHz
2...17 MHz
47 dB
Noise figure (max):
AGC gain control slope (min/typ/max):
Mixer output 1 dB compression
point (typ):
Gain of the last IF buffer:
Max output level after last IF buffer (typ):
Last IF Filter
The last IF is 13 MHz. The ceramic filter on last IF makes part of the channel
selectivity of the receiver.
Transmitter
The TX intermediate frequency is modulated by an I/Q modulator contained on
transmitter section of CRFRT IC. The TX I and Q signals are generated in the
RFI interface circuit and they are fed differentially to the modulator.
Modulated intermediate signal is amplified or attenuated in temperature compensated controlled gain amplifier (TCGA). The output of the TCGA is amplified
and the output level is typically –10 dBm.
15 max gain
40...84...100 dB/V
1.0 V
PP
30
1.6 V
PP
Page 4–42
The output signal from CRFRT is band–pass filtered to reduce harmonics and
the final TX signal is achieved by mixing the UHF VCO signal and the modulated TX intermediate signal with passive mixer. After mixing the TX signal is
Original 06/96
After Sales
NHE–5
Technical Documentation
amplified and filtered by amplifier and filters. These filters are dielectric filters.
After these stages the level of the signal is typically 1 mW (0 dBm) in GSM.
The discrete power amplifier amplifies the TX signal to the desired power level.
The maximum output level is typically 0.8...2.0 W.
The power control loop controls the output level of the power amplifier. The
power detector consists of a directional coupler and a diode rectifier. Transmitted power is controlled with controlled gain amplifier (TCGA) on TX path of
CRFRT. Power is controlled with TXC and TXP signals. The power control signal (TXC), which has a raised cosine form, comes from the RF interface circuit,
RFI.
Modulator Circuit, TX part of CRFRT
The modulator is a quadrature modulator contained in TX section of CRFRT IC.
The I and Q inputs generated by RFI interface are d.c. coupled and fed via buffers to the modulator. The local signal is divided by two to get accurate 90 degrees phase shifted signals to the I/Q mixers. After mixing the signals are combined and amplified with temperature compensated controlled gain amplifier
(TCGA). Gain is controlled with power control signal (TXC). The output of the
TCGA is amplified and the maximum output level is –10 dBm, typically.
System Module
Parameter
Supply voltage (min/typ/max):
Supply current (max):
Transmit frequency input
LO input frequency (min/max):
LO input power level (typ):
LO input resistance (min/typ/max):
LO input capacitance (typ):
Modulator Inputs (I/Q):
Input bias current, balanced (max):
Input common mode voltage
(min/typ/max):
Value
4.27...4.5...4.73 V
35 mA
Value
170...400 MHz
0.2 V
PP
70...100...130
Ω
4 pF
Value
100 nA
2.05...2.2...2.4 V
Input level, balanced (max):
Input frequency range (min/max):
Input resistance, balanced (min):
Input capacitance, balanced (max):
Original 06/96
1.1 V
PP
0...300 kHz
200 k
Ω
4 pF
Page 4–43
NHE–5
After Sales
System Module
Modulator Output:
Output frequency (min/max):
Available linear RF power (typ):
Available saturated RF power (typ):
Total gain control range (min):
Gain control slope (typ):
Suppression of 3rd order prods (min):
Carrier suppression (typ):
Single sideband suppression:
Noise floor
Transmitted I/Q phase balance:
drift in whole temperature range:
Transmitted I/Q amplitude balance:
drift in whole temperature range:
Technical Documentation
Value
85...200 MHz
–10 dBm, ZiL=50 k
0 dBm, ZiL=50 k
Ω
45 dB
84 dB/V
35 dB
35 dB
–135 dBm/Hz avg.
–5...5 deg
–2...2 deg
–0.5...0.5 dB
–0.2...0.2 dB
Ω
Upconversion Mixer
The upconversion mixer is a single balanced passive diode mixer. The local
signal is balanced by a printed circuit transformer. The mixer upconverts the
modulated IF signal coming from quadrature modulator to RF signal.
Parameter:
RX frequency range:
LO frequency range:
IF frequency (nom):
Conversion loss (min/typ/max):
IIP3 (min):
LO – RF isolation (min):
LO power level (max):
TX Interstage Filters
The TX filters reject the spurious signals generated in the upconversion mixer.
They reject the local, image and IF signal leakage and RX band noise, too.
Value
860...915 MHz
1006...1031 MHz
116 MHz
6.0...7.0...8.0 dB
0.0 dBm
15 dB
3.0 dBm
Page 4–44
Original 06/96
After Sales
NHE–5
Technical Documentation
1st TX Buffer
The TX buffer is a bipolar transistor amplifier. It amplifies the TX signal coming
from the upconversion mixer.
Parameter:
Operating frequency range:
Supply voltage (min/typ/max):
Current consumption (typ/max):
Insertion gain (min/typ/max):
Input VSWR, Zo=50 Ω (max):
Output VSWR, Zo=50 Ω (max):
2nd TX Buffer
The TX buffer is a bipolar transistor amplifier. It amplifies the TX signal coming
from the first interstage filter.
System Module
Value
890...915 MHz
4.25...4.5...2.8 V
4.5...5.0 mA
11...12...13 dB
2.0
2.0
Parameter:
Operation frequency range:
Supply voltage (min/typ/max):
Current consumption (typ/max):
Insertion gain (min/typ/max):
Output power, Zo=50 Ω (min/typ):
Input VSWR, Zo=50 Ω (max):
Output VSWR, Zo=50 Ω (max):
Power Amplifier
The power amplifier is a three stage discrete amplifier. It amplifies the 0 dBm
TX signal to the desired output level. It has been specified for 6 volts operation.
Parameter:
D.C. supply voltage, no RF (max):
D.C. supply voltage (min/typ/max):
Value
890...915 MHz
4.25...4.5...4.8 V
9.0...10.0 mA
11...12...13 dB
0...3 dBm
2.0
2.0
Value
10 V
5.3...6.0...8.5 V
Operation frequency:
Operating case temp. range (max):
Max output power (min/typ/max):
Max output power (min/typ/max):
Original 06/96
890...915 MHz
90 °C
34.5...35...36 dBm, norm cond.
33.5...34...35 dBm, extreme cond.
VCC=5.4 V, Ta=55°C
Page 4–45
NHE–5
After Sales
System Module
Parameter:
Input power (min):
Gain (min/typ/max):
Effiency (typ):
Input VSWR, Zo=50 Ω (max):
Output VSWR, Zo=50 Ω (max):
Harmonics, 2 fo:
3 fo, 4 fo, 5 fo:
Noise power (max):
Ruggedness (min):
Stability, load VSWR 6:1 (min):
Power Control Circuitry
The power control loop consists of a power detector and a differential control
circuit. The power detector is a combination of a directional coupler and a diode
rectifier. The differential control circuit compares the detected voltage and the
control voltage (TXC) and controls voltage controlled amplifier (in CRFRT) or
the power amplifier. The control circuit is a part of CRFRT.
Technical Documentation
Value
0 dBm
34.5...35...36 dB
42 %, Po=35 dBm
2.0
2.0
–30 dBc, Po=35 dBm
–40 dBc, Po=35 dBm
–114 dBm at receiver band
8 V VSWR=7, P
OUT
=4 W
60 dBc, all spurious
Parameter:
Supply voltage (min/typ/max):
using CRFRT:
Supply current (typ/max):
Power control range (min):
Power control inaccuracy (max): ±
Dynamic range (min):
Input control voltage range (min/max):
Value
4.5...4.7...4.9
4.27...4.5...4.73
3.0...5.0 mA
20 dB
1.0 dB
80 dB
0.1...2.8 V
Page 4–46
Original 06/96
After Sales
NHE–5
Technical Documentation
Frequency Synthesizers
The stable frequency source for the synthesizers and base band circuits is discrete voltage controlled crystal oscillator, VCXO in GSM. The frequency of the
oscillators is controlled by an AFC voltage, which is generated by the base
band circuits. The ON/OFF switching of the oscillator is controlled by the sleep
clock in the baseband via VCXOPWR.
The UHF PLL generates the down conversion signal for the receiver and the up
conversion signal for the transmitter. The UHF VCO is a discrete oscillator. The
working assumption for PLL circuits are from Philips UMA1018 for GSM.
The VHF PLL signal (divided by 4 in CRFR is used as a local for the last mixer.
Also the VHF PLL signal (divided by 2 in CRFRT) is used in the I/Q modulator
of the transmitter chain.
Frequencies; see RF frequency plan.
Referency Oscillator
In GSM the reference oscillator is a discrete VCXO and the frequency is
13 MHz. The oscillator signal is used for a reference frequency of the synthesizers and the clock frequency for the base band circuits.
System Module
Parameter:
Centre frequency:
Frequency tolerance:
Frequency control range:
Supply voltage (min/typ/max):
Current consumption (typ/max):
Output voltage (min/typ/max):
Harmonics (max):
Control voltage range (min/max):
Nominal voltage for centre frequency:
Control sensitivity (min/typ/max):
Frequency stability
• temperature:
• supply voltage:
• load:
• aging:
Value
13 MHz
–18....18 ppm, VC=2.1 V
67 ppm
4.275...4.5...4.725 V
2.5..3.0 mA
1.3...1.7...2.0 VPP, sine
wave for PLLs
5 dBc
0.3...3.9 V
2.1 V
12...18...25 ppm/V
10 ppm, –25...+75 °C
1 ppm, 4.7 V ±5 %
0.1 ppm, load ±10 %
1 ppm, year
Operating temperature range (min/max):
Load impedance, resistive part:
parallel capacitance:
Original 06/96
–20...70 °C
2 k
Ω
20 pF
Page 4–47
NHE–5
After Sales
System Module
VHF PLL
The VHF PLL consists of the VHF VCO, PLL integrated circuit and loop filter.
The output signal is used for the 2nd mixer of the receiver and for the I/Q modulator of the transmitter.
Parameter:
Start up setting time (max):
Phase error (max):
Sidebands (typ/max)
• ±200 kHz:
• ±400 kHz:
• ±1 MHz:
• ±2 MHz:
• ±3 MHz:
• >4 MHz:
VHF VCO + Buffer
Technical Documentation
Value
5 ms
1 deg., rms
–75...–70 dB
–84...–70 dB
<–85...–70 dB
<–85...–75 dB
<–85...–85 dB
<–85...–85 dB
The VHF VCO uses a bipolar transistor as a active element and a combination
of a chip coil and varactor diode as a resonance circuit. The buffer is combined
into the VCO circuit so, that they use same collector current.
Parameter:
Supply voltage (min/typ/max):
Control voltage (min/max):
Supply current (typ/max):
Operation frequency (typ):
Output power level (typ):
Control voltage sensitivity (typ):
Phase noise (max)
• fo ±200 kHz
• fo ±1600 kHz
• fo ±3000 kHz
Harmonics (typ/max):
Value
4.2...4.5...4.8 V
0.5...4.0 V
2.5...5.0 mA
232 MHz
168 mV
RMS
/1 k
12 MHz/V
–123 dB
–133 dB
–143 dB
–32...–30 dB
Ω
Page 4–48
Original 06/96
After Sales
NHE–5
Technical Documentation
UHF PLL
The UHF PLL consists of a UHF VCO, divider, PLL circuit and a loop filter. The
output signal is used for the 1st mixer of the receiver and the upconversion mixer of the transmitter.
Parameter:
Start up setting time (max):
Phase error (max):
Settling time ±93 MHz (typ/max):
Sidebands (typ/max)
• ±200 kHz:
• ±400 kHz:
• ±600 kHz:
• 1.4...3.0 MHz:
• >3.0 MHz:
UHF VCO + Buffer
System Module
Value
5 ms
4 deg., rms
525...800 µs
–80...–60 dB
–87...–65 dB
<–90...–70 dB
<–90...–80 dB
<–80 dB
The UHF VCO uses a bipolar transistor as a active element and a combination
of a microstripline and a varactor diode as a resonance circuit.
UHF VCO Buffers
The UHF VCO output signal is divided into the 1st mixer of the receiver and the
upconversion mixer of the transmitter. The UHF VCO signal is amplified after
division. There is one buffer for TX and one for RX.
Parameter:
Supply voltage (min/typ/max):
Supply current (typ/max):
Input power (typ):
Harmonics (max):
Output amplitude (typ):
Value
4.2...4.5...4.8 V
5.5...6.5 mA
–3 dBm
–10 dBc
700 mV
RMS
/1 k
Ω
Original 06/96
Page 4–49
NHE–5
After Sales
System Module
PLL Circuit
The PLL is PHILIPS UMA1018. The circuit is a dual frequency synthesizer including both the UHF and VHF synthesizers.
Parameter:
Supply voltage (min/max):
Supply current (typ):
Principal input frequency (min/max):
Auxiliary input frequency (min/max):
Input reference frequency (min/max):
Input signal level (min/max):
Technical Documentation
Value
2.7...5.5 V
8.5 mA
500...1200 MHz, VDD = 4.5 V
20...300 MHz, VDD = 4.5 V
3...40 MHz, VDD = 4.5 V
50...500 mV
RMS
Page 4–50
Original 06/96
After Sales
NHE–5
Technical Documentation
Interconnection Diagram of Baseband
VL VSL VA
CHARGER
VCHAR
VBATT
4/8 Mbit
FLASH
D400
UNIT
Addr 19...0
data 7...0
PSCLD
SIM
control
N301
D2BB2
ASIC
D151
SIM control
SBus
13 MHz
32 kHz
Sync
Clock
SBus
System Module
SIM
READER
DISPLAY
AUDIO
CODEC
ST5090
N200
SRAM
1 Mbit
D403
Flash
loading
MBUS
H3001
MCU
D150
SBus
EEPROM
D404
DSPdata15...0
DSP addr 15...0
Synthe
Control
TxP
TxPwr
RxPwr
RFI
N450
TMS320C5
DSP
D152
SRAM
256 kbit
15 ns
D410
SRAM
256 kbit
15 ns
D411
TxC
Original 06/96
TxI,TxQ
RxI,RxQ
Page 4–51
NHE–5
After Sales
System Module
Block Diagram of RF
RXINNRXINP
CRFRT
f/2
f
f/2
f
f/2
f
AFC
TXC
TXP
TX power control
Technical Documentation
TXIP
TXIN
TXQP
TXQN
PCN
VHF
VCO
PLL
UHF
VCO
(21 – 27 dB PCN)
step AGC (25 – 30 dB)
RFC to ASIC
clipped sinewave
VCXO
PCN
Batt.volt.
TXC
PCN
TXP (GSM)
TXP
BIAS
Page 4–52
+6 V
CRFCONT
+4.5V
PCN
+6 V
–4 V
Original 06/96
After Sales
NHE–5
Technical Documentation
RF Frequency Plan
GSM
1st IF 2nd IF
935–960
LO 1
1006–
1031
890–915
71 13
116
58
f/2
System Module
CRFRT
f
f
f/2
f
f/2
LO 2
232
PLL
VCXO:
13 MHz
Original 06/96
Page 4–53
NHE–5
After Sales
System Module
Power Distribution Diagram of RF
Battery
6 V
(min 5.3 V)
CRFCONT
Switch
Power
Amplifier
Technical Documentation
TXP
GSM: 1300 mA
PCN: 700 mA
VXOPWR
RFIPWR
VR1 VR2 VR3 VR4 VR5 VR6 VR7 VR8Vbias
+4V5_TX:
TX buffers
GSM: 13 mA 17 mA
PCN: 21 mA
VHLO:
VHF LO
VCXO
2 mA
VPLL:
UMA1018
Negat.volt.
18.5 mA
+4V5_RX:
RF LNA
IF amps
GSM: 18 mA
PCN: 31 mA
V_prot
RFI:
Analog blocks
VTX:
CRFRT (VTX)
CRFRT (VTX_slow)
39 mA
VRX:
CRFRT (VRX)
35 mA
SYNTHPWR
TXPWR
RXPWR
15 mA
Page 4–54
Figure 1. Power distribution diagram
CRFRT (VB_ext)
< 1 mA
Original 06/96
RFREF
RFI
After Sales
NHE–5
Technical Documentation
Circuit Diagram of Charger Control (Version 1.0 ; Edit 15)
System Module
Original 06/96
Page 4–55
NHE–5
After Sales
System Module
Technical Documentation
Circuit Diagram of 4 MBit Flash Memory (Version 3.0 ; Edit 22)
Page 4–56
Original 06/96
After Sales
NHE–5
Technical Documentation
Block Diagram of Baseband
System Module
Original 06/96
Page 4–57
NHE–5
After Sales
System Module
Technical Documentation
Circuit Diagram of Power Supply & Charging
Page 4–58
Original 06/96
After Sales
NHE–5
Technical Documentation
Circuit Diagram of Central Processing Unit
System Module
Original 06/96
Page 4–59
NHE–5
After Sales
System Module
Circuit Diagram of MCU Memory Block
Technical Documentation
Page 4–60
Original 06/96
After Sales
NHE–5
Technical Documentation
System Module
Circuit Diagram of Keyboard & Display Interface
Original 06/96
Page 4–61
NHE–5
After Sales
System Module
Circuit Diagram of Audio
Technical Documentation
Page 4–62
Original 06/96
After Sales
NHE–5
Technical Documentation
Circuit Diagram of DSP Memory Block
System Module
Original 06/96
Page 4–63
NHE–5
After Sales
System Module
Circuit Diagram of RFI
Technical Documentation
Page 4–64
Original 06/96
After Sales
NHE–5
Technical Documentation
Circuit Diagram of Receiver
System Module
Original 06/96
Page 4–65
NHE–5
After Sales
System Module
Circuit Diagram of Transceiver
Technical Documentation
Page 4–66
Original 06/96
After Sales
NHE–5
Technical Documentation
Layout Diagrams of GT8
System Module
Original 06/96
Page 4–67
NHE–5
After Sales
System Module
Layout Diagrams of GT8
Technical Documentation
Page 4–68
Original 06/96
After Sales
NHE–5
Technical Documentation
System Module
Parts list of GT8 (EDMS Issue 4.5)
ITEM CODE DESCRIPTION VALUE TYPE
R150 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R151 1430718 Chip resistor 47 5 % 0.063 W 0402
R152 1430718 Chip resistor 47 5 % 0.063 W 0402
R155 1430726 Chip resistor 100 5 % 0.063 W 0402
R156 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R161 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R166 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R168 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R201 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R202 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R203 1430726 Chip resistor 100 5 % 0.063 W 0402
R204 1430726 Chip resistor 100 5 % 0.063 W 0402
R205 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R206 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R207 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R208 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R209 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R210 1430788 Chip resistor 22 k 5 % 0.063 W 0402
R211 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R212 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R214 1430710 Chip resistor 22 5 % 0.063 W 0402
R215 1430788 Chip resistor 22 k 5 % 0.063 W 0402
R216 1430029 Chip resistor 12.1 k 0.5 % 0.063 W 0603
R217 1430029 Chip resistor 12.1 k 0.5 % 0.063 W 0603
R218 1430710 Chip resistor 22 5 % 0.063 W 0402
R219 1430029 Chip resistor 12.1 k 0.5 % 0.063 W 0603
R220 1430029 Chip resistor 12.1 k 0.5 % 0.063 W 0603
R222 1430700 Chip resistor 10 5 % 0.063 W 0402
R223 1430700 Chip resistor 10 5 % 0.063 W 0402
R250 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R251 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R252 1430716 Chip resistor 39 5 % 0.063 W 0402
R253 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R254 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R255 1430724 Chip resistor 82 5 % 0.063 W 0402
R256 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R257 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R258 1430726 Chip resistor 100 5 % 0.063 W 0402
R259 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R260 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R261 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R262 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R263 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
Original 06/96
Page 4–69
NHE–5
After Sales
System Module
R264 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R265 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R266 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R267 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R268 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R269 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R270 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R271 1430061 Chip resistor 511 k 1 % 0.063 W 0603
R272 1430113 Chip resistor 348 k 1 % 0.063 W 0603
R300 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R301 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R302 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R303 1430788 Chip resistor 22 k 5 % 0.063 W 0402
R304 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R305 1430726 Chip resistor 100 5 % 0.063 W 0402
R306 1430726 Chip resistor 100 5 % 0.063 W 0402
R307 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R308 1430027 Chip resistor 2.43 k 1 % 0.063 W 0603
R309 1430025 Chip resistor 2.0 k 1 % 0.063 W 0603
R310 1430718 Chip resistor 47 5 % 0.063 W 0402
R311 1430796 Chip resistor 47 k 5 % 0.063 W 0402
R312 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R313 1430796 Chip resistor 47 k 5 % 0.063 W 0402
R314 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R315 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R316 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R317 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R318 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R319 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R320 1430726 Chip resistor 100 5 % 0.063 W 0402
R321 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R322 1430726 Chip resistor 100 5 % 0.063 W 0402
R323 1430726 Chip resistor 100 5 % 0.063 W 0402
R324 1430718 Chip resistor 47 5 % 0.063 W 0402
R326 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R327 1430718 Chip resistor 47 5 % 0.063 W 0402
R328 1430726 Chip resistor 100 5 % 0.063 W 0402
R329 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R330 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R331 1430718 Chip resistor 47 5 % 0.063 W 0402
R332 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R334 1430718 Chip resistor 47 5 % 0.063 W 0402
R336 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R337 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R340 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R343 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R344 1430744 Chip resistor 470 5 % 0.063 W 0402
R345 1430804 Chip resistor 100 k 5 % 0.063 W 0402
Technical Documentation
Page 4–70
Original 06/96
After Sales
NHE–5
Technical Documentation
R348 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R349 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R400 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R401 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R402 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R403 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R404 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R405 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R406 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R407 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R408 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R409 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R410 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R411 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R412 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R413 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R415 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R416 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R430 1430790 Chip resistor 27 k 5 % 0.063 W 0402
R431 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R433 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R452 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R453 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R454 1430758 Chip resistor 1.5 k 5 % 0.063 W 0402
R455 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R501 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R502 1430732 Chip resistor 180 5 % 0.063 W 0402
R503 1430732 Chip resistor 180 5 % 0.063 W 0402
R504 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R505 1430772 Chip resistor 5.6 k 5 % 0.063 W 0402
R507 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R508 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R509 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R511 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R512 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R513 1430740 Chip resistor 330 5 % 0.063 W 0402
R514 1430710 Chip resistor 22 5 % 0.063 W 0402
R541 1430710 Chip resistor 22 5 % 0.063 W 0402
R542 1430734 Chip resistor 220 5 % 0.063 W 0402
R543 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R544 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R545 1430758 Chip resistor 1.5 k 5 % 0.063 W 0402
R546 1430724 Chip resistor 82 5 % 0.063 W 0402
R547 1430744 Chip resistor 470 5 % 0.063 W 0402
R551 1430772 Chip resistor 5.6 k 5 % 0.063 W 0402
R552 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R553 1430772 Chip resistor 5.6 k 5 % 0.063 W 0402
R554 1430772 Chip resistor 5.6 k 5 % 0.063 W 0402
System Module
Original 06/96
Page 4–71
NHE–5
After Sales
System Module
R555 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R556 1430772 Chip resistor 5.6 k 5 % 0.063 W 0402
R557 1430732 Chip resistor 180 5 % 0.063 W 0402
R558 1430730 Chip resistor 150 5 % 0.063 W 0402
R559 1430740 Chip resistor 330 5 % 0.063 W 0402
R560 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402
R562 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R566 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R570 1430726 Chip resistor 100 5 % 0.063 W 0402
R571 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R572 1430796 Chip resistor 47 k 5 % 0.063 W 0402
R573 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R574 1430788 Chip resistor 22 k 5 % 0.063 W 0402
R578 1430794 Chip resistor 39 k 5 % 0.063 W 0402
R579 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R580 1430790 Chip resistor 27 k 5 % 0.063 W 0402
R583 1430794 Chip resistor 39 k 5 % 0.063 W 0402
R601 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R602 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R603 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R701 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R702 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R703 1430710 Chip resistor 22 5 % 0.063 W 0402
R704 1430740 Chip resistor 330 5 % 0.063 W 0402
R705 1430724 Chip resistor 82 5 % 0.063 W 0402
R708 1430690 Chip jumper 0402
R711 1430758 Chip resistor 1.5 k 5 % 0.063 W 0402
R712 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R713 1430744 Chip resistor 470 5 % 0.063 W 0402
R714 1430700 Chip resistor 10 5 % 0.063 W 0402
R715 1430693 Chip resistor 5.6 5 % 0.063 W 0402
R716 1430693 Chip resistor 5.6 5 % 0.063 W 0402
R717 1430734 Chip resistor 220 5 % 0.063 W 0402
R725 1430792 Chip resistor 33 k 5 % 0.063 W 0402
R726 1430790 Chip resistor 27 k 5 % 0.063 W 0402
R727 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R728 1430730 Chip resistor 150 5 % 0.063 W 0402
R736 1430786 Chip resistor 18 k 5 % 0.063 W 0402
R737 1430804 Chip resistor 100 k 5 % 0.063 W 0402
R738 1430780 Chip resistor 12 k 5 % 0.063 W 0402
R739 1430778 Chip resistor 10 k 5 % 0.063 W 0402
R740 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R741 1430746 Chip resistor 560 5 % 0.063 W 0402
R742 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R743 1430700 Chip resistor 10 5 % 0.063 W 0402
R744 1430734 Chip resistor 220 5 % 0.063 W 0402
R755 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R756 1412279 Chip resistor 2.2 5 % 0.1 W 0805
Technical Documentation
Page 4–72
Original 06/96
After Sales
NHE–5
Technical Documentation
R765 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R766 1430748 Chip resistor 680 5 % 0.063 W 0402
R767 1430732 Chip resistor 180 5 % 0.063 W 0402
R768 1430752 Chip resistor 820 5 % 0.063 W 0402
R769 1430693 Chip resistor 5.6 5 % 0.063 W 0402
R780 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R781 1430740 Chip resistor 330 5 % 0.063 W 0402
R782 1430726 Chip resistor 100 5 % 0.063 W 0402
R784 1430726 Chip resistor 100 5 % 0.063 W 0402
R785 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R800 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R801 1430796 Chip resistor 47 k 5 % 0.063 W 0402
R802 1430796 Chip resistor 47 k 5 % 0.063 W 0402
R803 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R804 1430788 Chip resistor 22 k 5 % 0.063 W 0402
R805 1430786 Chip resistor 18 k 5 % 0.063 W 0402
R806 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402
R807 1430760 Chip resistor 1.8 k 5 % 0.063 W 0402
R808 1430754 Chip resistor 1.0 k 5 % 0.063 W 0402
R811 1430764 Chip resistor 3.3 k 5 % 0.063 W 0402
R820 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R821 1430762 Chip resistor 2.2 k 5 % 0.063 W 0402
R822 1430798 Chip resistor 56 k 5 % 0.063 W 0402
R823 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R824 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R825 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R826 1430780 Chip resistor 12 k 5 % 0.063 W 0402
R827 1430774 Chip resistor 6.8 k 5 % 0.063 W 0402
R828 1430786 Chip resistor 18 k 5 % 0.063 W 0402
R829 1430718 Chip resistor 47 5 % 0.063 W 0402
R830 1430726 Chip resistor 100 5 % 0.063 W 0402
R840 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R841 1430770 Chip resistor 4.7 k 5 % 0.063 W 0402
R842 1430844 Chip resistor 3.9 k 1 % 0.063 W 0402
R843 1430832 Chip resistor 2.7 k 5 % 0.063 W 0402
R844 1430734 Chip resistor 220 5 % 0.063 W 0402
R845 1430700 Chip resistor 10 5 % 0.063 W 0402
R846 1430726 Chip resistor 100 5 % 0.063 W 0402
R847 1430718 Chip resistor 47 5 % 0.063 W 0402
R860 1430716 Chip resistor 39 5 % 0.063 W 0402
C151 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C153 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C154 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C155 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C156 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C158 2320538 Ceramic cap. 12 p 5 % 50 V 0402
C159 2320538 Ceramic cap. 12 p 5 % 50 V 0402
C160 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
System Module
Original 06/96
Page 4–73
NHE–5
After Sales
System Module
C161 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C162 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C165 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C166 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C167 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C168 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C169 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C170 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C200 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C201 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C202 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C203 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C204 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C205 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C206 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C207 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C208 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C211 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C212 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C213 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C214 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C215 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C216 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C217 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C218 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C220 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C221 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C222 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C223 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C224 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C225 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C250 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C261 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C262 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C263 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C264 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C265 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C266 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C267 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C268 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C300 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C301 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C302 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C303 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C304 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C305 2604431 Tantalum cap. 10 µ 20 % 16 V 6.0x3.2x2.8
C306 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C307 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
Technical Documentation
Page 4–74
Original 06/96
After Sales
NHE–5
Technical Documentation
C308 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C309 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C310 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C311 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C312 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C313 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C314 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C315 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C316 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C317 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C318 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C319 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C320 2610153 Tantalum cap. 10 µ 20 % 6.0x3.2x2.5
C321 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C322 2610153 Tantalum cap. 10 µ 20 % 6.0x3.2x2.5
C323 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C324 2610153 Tantalum cap. 10 µ 20 % 6.0x3.2x2.5
C325 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C326 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C328 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C329 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C330 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C331 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C334 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C335 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C337 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C338 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C339 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C341 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C400 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C401 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C402 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C403 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C404 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C410 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C411 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C412 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C413 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C414 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C450 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C451 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C452 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C453 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C456 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C457 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C458 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C459 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C460 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
System Module
Original 06/96
Page 4–75
NHE–5
After Sales
System Module
C462 2320110 Ceramic cap. 10 n 10 % 50 V 0603
C501 2320522 Ceramic cap. 2.7 p 0.25 % 50 V 0402
C502 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C503 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C504 2320544 Ceramic cap. 22 p 5 % 50 V 0402
C505 2320544 Ceramic cap. 22 p 5 % 50 V 0402
C506 2320526 Ceramic cap. 3.9 p 0.25 % 50 V 0402
C511 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402
C512 2320550 Ceramic cap. 39 p 5 % 50 V 0402
C513 2320518 Ceramic cap. 1.8 p 0.25 % 50 V 0402
C514 2320520 Ceramic cap. 2.2 p 0.25 % 50 V 0402
C515 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C516 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C517 2320550 Ceramic cap. 39 p 5 % 50 V 0402
C521 2320554 Ceramic cap. 56 p 5 % 50 V 0402
C536 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C541 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C542 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C543 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C544 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C545 2320728 Ceramic cap. 220 p 10 % 50 V 0402
C546 2320728 Ceramic cap. 220 p 10 % 50 V 0402
C551 2320536 Ceramic cap. 10 p 5 % 50 V 0402
C552 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C553 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C554 2320566 Ceramic cap. 180 p 5 % 50 V 0402
C555 2320566 Ceramic cap. 180 p 5 % 50 V 0402
C556 2320752 Ceramic cap. 2.2 n 10 % 50 V 0402
C557 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C558 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C559 2320752 Ceramic cap. 2.2 n 10 % 50 V 0402
C560 2320752 Ceramic cap. 2.2 n 10 % 50 V 0402
C561 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C562 2320075 Ceramic cap. 470 p 5 % 50 V 0603
C563 2320552 Ceramic cap. 47 p 5 % 50 V 0402
C566 2320552 Ceramic cap. 47 p 5 % 50 V 0402
C569 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C570 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C571 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C572 2310791 Ceramic cap. 33 n 20 % 50 V 0805
C573 2320554 Ceramic cap. 56 p 5 % 50 V 0402
C574 2320554 Ceramic cap. 56 p 5 % 50 V 0402
C575 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402
C580 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C601 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C602 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C603 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C604 2310784 Ceramic cap. 100 n 10 % 25 V 0805
Technical Documentation
Page 4–76
Original 06/96
After Sales
NHE–5
Technical Documentation
C605 2312410 Ceramic cap. 1.0 µ 10 % 16 V 1206
C607 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C608 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C609 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C610 2310784 Ceramic cap. 100 n 10 % 25 V 0805
C701 2320548 Ceramic cap. 33 p 5 % 50 V 0402
C702 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C703 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C704 2320518 Ceramic cap. 1.8 p 0.25 % 50 V 0402
C705 2320520 Ceramic cap. 2.2 p 0.25 % 50 V 0402
C710 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402
C711 2320558 Ceramic cap. 82 p 5 % 50 V 0402
C712 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402
C713 2320516 Ceramic cap. 1.5 p 0.25 % 50 V 0402
C716 2320530 Ceramic cap. 5.6 p 0.25 % 50 V 0402
C720 2320552 Ceramic cap. 47 p 5 % 50 V 0402
C721 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C722 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402
C723 2320518 Ceramic cap. 1.8 p 0.25 % 50 V 0402
C725 2320552 Ceramic cap. 47 p 5 % 50 V 0402
C726 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402
C728 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402
C730 2320552 Ceramic cap. 47 p 5 % 50 V 0402
C731 2320522 Ceramic cap. 2.7 p 0.25 % 50 V 0402
C732 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402
C735 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C736 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C737 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C738 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402
C739 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402
C740 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C741 2320556 Ceramic cap. 68 p 5 % 50 V 0402
C742 2320536 Ceramic cap. 10 p 5 % 50 V 0402
C743 2320526 Ceramic cap. 3.9 p 0.25 % 50 V 0402
C744 2320536 Ceramic cap. 10 p 5 % 50 V 0402
C755 2320556 Ceramic cap. 68 p 5 % 50 V 0402
C756 2320578 Ceramic cap. 560 p 5 % 50 V 0402
C757 2320578 Ceramic cap. 560 p 5 % 50 V 0402
C758 2320556 Ceramic cap. 68 p 5 % 50 V 0402
C759 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C760 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C761 2320532 Ceramic cap. 6.8 p 0.25 % 50 V 0402
C762 2320526 Ceramic cap. 3.9 p 0.25 % 50 V 0402
C764 2320536 Ceramic cap. 10 p 5 % 50 V 0402
C768 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C770 2320538 Ceramic cap. 12 p 5 % 50 V 0402
C780 2320536 Ceramic cap. 10 p 5 % 50 V 0402
C781 2320536 Ceramic cap. 10 p 5 % 50 V 0402
System Module
Original 06/96
Page 4–77
NHE–5
After Sales
System Module
C782 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C783 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C784 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C800 2604079 Tantalum cap. 0.22 µ 20 % 35 V 3.2x1.6x1.6
C801 2310752 Ceramic cap. 10 n 20 % 50 V 0805
C802 2320524 Ceramic cap. 3.3 p 0.25 % 50 V 0402
C803 2320568 Ceramic cap. 220 p 5 % 50 V 0402
C804 2320554 Ceramic cap. 56 p 5 % 50 V 0402
C805 2320728 Ceramic cap. 220 p 10 % 50 V 0402
C806 2610100 Tantalum cap. 1 µ 20 % 10 V 2.0x1.3x1.2
C807 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C809 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C820 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C821 2313104 Ceramic cap. 1.0 n 2 % 50 V 1206
C822 2320053 Ceramic cap. 56 p 5 % 50 V 0603
C823 2310248 Ceramic cap. 4.7 n 5 % 50 V 1206
C824 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C828 2610100 Tantalum cap. 1 µ 20 % 10 V 2.0x1.3x1.2
C829 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C830 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C831 2610100 Tantalum cap. 1 µ 20 % 10 V 2.0x1.3x1.2
C832 2320756 Ceramic cap. 3.3 n 10 % 50 V 0402
C840 2320548 Ceramic cap. 33 p 5 % 50 V 0402
C841 2610100 Tantalum cap. 1 µ 20 % 10 V 2.0x1.3x1.2
C842 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C843 2320546 Ceramic cap. 27 p 5 % 50 V 0402
C844 2320538 Ceramic cap. 12 p 5 % 50 V 0402
C845 2320604 Ceramic cap. 18 p 5 % 50 V 0402
C846 2320534 Ceramic cap. 8.2 p 0.25 % 50 V 0402
C847 2320602 Ceramic cap. 4.7 p 0.25 % 50 V 0402
C848 2320560 Ceramic cap. 100 p 5 % 50 V 0402
C849 2320744 Ceramic cap. 1.0 n 10 % 50 V 0402
C850 2320604 Ceramic cap. 18 p 5 % 50 V 0402
C851 2320550 Ceramic cap. 39 p 5 % 50 V 0402
C862 2320602 Ceramic cap. 4.7 p 0.25 % 50 V 0402
C863 2320522 Ceramic cap. 2.7 p 0.25 % 50 V 0402
L151 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L152 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L153 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L200 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L201 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L202 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L203 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L204 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L205 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L206 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L207 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L208 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
Technical Documentation
Page 4–78
Original 06/96
After Sales
NHE–5
Technical Documentation
L300 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L301 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L302 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L304 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L307 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L308 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L310 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L311 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L410 3640011 Filter Z>600Ω/100M 0.6Ω max 0.2 A
L511 3641550 Chip coil 120 n 10 % Q=35 0805
L532 3641550 Chip coil 120 n 10 % Q=35 0805
L541 3641550 Chip coil 120 n 10 % Q=35 0805
L542 3608326 Chip coil 330 n 5 % 1206
L543 3641560 Chip coil 220 n 10 % Q=30/100 MHz 0805
L544 3641560 Chip coil 220 n 10 % Q=30/100 MHz 0805
L545 3608326 Chip coil 330 n 5 % 1206
L546 3608326 Chip coil 330 n 5 % 1206
L551 3641538 Chip coil 39 n 20 % Q=40 0805
L700 3606946 Ferrite bead 0.2Ω 26Ω/100MHz 1206
L705 3640013 Chip coil 8 n 5 % Q=50/250 MHz 0805
L710 3641626 Chip coil 220 n 2 % Q=30/100 MHz 0805
L711 3641542 Chip coil 56 n 10 % Q=40 0805
L800 3641324 Chip coil 10 µ 10 % Q=25/2.52 MHz 1008
L840 3641574 Chip coil 68 n 5 % Q=40 0805
L841 3641538 Chip coil 39 n 20 % Q=40 0805
L842 3641558 Chip coil 8 n 10 % Q=50 0805
B150 4510029 Crystal 32.768 k 20PPM 20PPM
B800 4510075 Crystal 13.000 M +–5/TSTAB+–7PPM
G001 4352933 Vco 1006–1031 MHz 4.5 V 15 mA
Z500 4512046 SM, dupl. 890–915/935–960 MHz
Z505 4511016 Saw filter 947.5±12.5 M RXJP
Z541 4511026 SM, SAW IF filter 71 MHz 10 dBm
Z551 4510009 SM, cer.bpf 13 MHz±90kHz/1 dB 330Ω
Z713 4550101 SM, cer bpf 902.5±12.5MHz tx
V200 4210100 Transistor BC848W npn 30 V SOT323
V201 4210100 Transistor BC848W npn 30 V SOT323
V202 4210100 Transistor BC848W npn 30 V SOT323
V203 4110014 Sch. diode x 2 BAS70–07 70 V 15 mA SOT143
V250 4864370 Led Green 1208
V251 4864370 Led Green 1208
V252 4864378 Led Green V 0805
V253 4864378 Led Green V 0805
V254 4864378 Led Green V 0805
V255 4864378 Led Green V 0805
V256 4864370 Led Green 1208
V257 4864370 Led Green 1208
V258 4864378 Led Green V 0805
V259 4864378 Led Green V 0805
System Module
Original 06/96
Page 4–79
NHE–5
After Sales
System Module
V260 4864378 Led Green V 0805
V261 4864378 Led Green V 0805
V262 4210100 Transistor BC848W npn 30 V SOT323
V263 4210100 Transistor BC848W npn 30 V SOT323
V264 4210100 Transistor BC848W npn 30 V SOT323
V300 4110028 Trans. supr. 16V 23 A 600 W DO214AA
V301 4110130 Zener diode BZX84 2 % 5.1 V 0.3 W SOT23
V302 4210100 Transistor BC848W npn 30 V SOT323
V303 4210100 Transistor BC848W npn 30 V SOT323
V304 4210092 Transistor SOT223
V305 4110034 Schottky diode MBRS140 40 V 1 A DO214AA
V306 4210092 Transistor SOT223
V307 4219928 TR+RX2 RN2302 p 50V 50mA 10k
V308 4219926 TR+RX2 RN2302 p 50V 50mA 10k
V309 4219926 TR+RX2 RN2302 p 50V 50mA 10k
V310 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V312 4210100 Transistor BC848W npn 30 V SOT323
V450 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V501 4210046 Transistor BFP182 npn 20 V 35 mA SOT143
V502 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V503 4210100 Transistor BC848W npn 30 V SOT323
V511 4115802 Sch. diode x 2 4V 30 mA SOT23
V512 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V541 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V701 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V702 4100567 Sch. diode x 2 BAS70–04 70V15 mA SERSOT23
V710 4200755 Transistor BFR92A npn 15 V 25 mA SOT23
V725 4200755 Transistor BFR92A npn 15 V 25 mA SOT23
V726 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V735 4210100 Transistor BC848W npn 30 V SOT323
V736 4217070 Transistor x 2 IMD
V737 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V738 4210090 Transistor BFG540/X npn 15 V 129 mA SOT143
V755 4210102 Transistor BC858W pnp 30 V 100 mA 200MW
V756 4210133 Transistor BFG10W/X npn 10 V 0.25 A SOT343
V765 4210100 Transistor BC848W npn 30 V SOT323
V766 4210100 Transistor BC848W npn 30 V SOT323
V767 4100285 Diode x 2 BAV99 70 V 200 mA SER.SOT23
V768 4210135 Transistor BLT82 npn 10 V SO8S
V780 4110014 Sch. diode x 2 BAS70–07 70 V 15 mA SOT143
V800 4111092 Cap. diode BB639 30 V SOD323
V801 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V802 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V840 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V841 4210066 Transistor BFR93AW npn 12 V 35 mA SOT323
V842 4110018 Cap. diode BB135 30 V SOD323
D150 4340307 IC, MCU TQFP80
D151 4370124 Cf70131 gsm/pcn asic bart SQFP144
Technical Documentation
Page 4–80
Original 06/96
After Sales
NHE–5
Technical Documentation
D152 4371025 IC, tms320lc541/d36818 gh4 DSP SQF100
D400 4340305 IC, 512kx8 110ns 3V E28F004BVBT SO40
D402 4340045 IC, SRAM TSO28
D404 4343280 IC, EEPROM 2kx8 bit SO8S
D410 4340045 IC, SRAM TSO28
D411 4340045 IC, SRAM TSO28
N200 4340013 St5090 audio codec SO28W
N301 4370199 Stt225b pscld–c pw supply QFP44
N450 4370207 St7522 rfi2 v2.2 tdma codec QFP64
N551 4370091 Crfrt_st tx.mod+rxif+pwc SQFP44
N601 4370095 Crfcontf 8xreg4.5v vref2v5 VSOP28
N820 4340069 IC, 2xsynth 3v UMA1018M/C1/S1 SSO20
X100 5409019 SM, fpc connector 24 poles p 0.8
X101 5460007 20 pole spring type direct board
X102 5408807 Sim card reader ccm04–5002 3CO2x3con
X103 5469001 System connector
X501 9510245 Antenna clip 3D25495 NHE–5NX
9854060 PC board GT8 48.3x150.4x1.0 m6 3/pa
System Module
Original 06/96
Page 4–81
NHE–5
After Sales
System Module
Technical Documentation
This page intentionally left blank.
Page 4–82
Original 06/96
Loading...
